HERA 3D VERTICAL TUBE RGB SERIES Installation and operating instructions

Congratulations on choosing a HERA product!
We thank you for your custom.
Please note that this product, as all the others in the rich HERA range, has been designed and made with total quality to ensure excellent performance and best meet your
expectations and requirements. Carefully read this instruction manual in its entirety and keep it safe for future reference. It is essential to know the information and comply
with the instructions given in this manual to ensure the fitting is installed, used and serviced correctly and safely. HERA disclaims all liability for damage to the fitting or to
other property or persons deriving from installation, use and maintenance that have not been carried out in conformity with this instruction manual, which must always
accompany the fitting. HERA reserves the right to modify the characteristics stated in this instruction manual at any time and without prior notice.
Index V.1.0
Cover & Index
1
Safety Information / Warning / Warranty /Marking
2
Installation Instruction
8
Product Specifications
4
Standart DMX Wiring Diagram
5
Explanation / Dimension
3
RDM Monitoring Wiring Diagram
6
DMX Personality
7
11
Back Cover
12
Ordering Information
Accessories & Recommended Products
www.heraled.com
www.heraled.com
3D VERTICAL TUBE RGB SERIES
User’s Manual & Installation Guide
All manuals and user guides at all-guides.com
all-guides.com

www.heraled.com 2
www.heraled.com
Safety Information
Warranty
Caution – unplug the power supply from the main power before connecting any cables as this can damage the products.
Caution – avoid looking directly into the led light source at close range for your own safety.
Any people installing this product should comply with local standards and regulations and must be qualified for the handling of
electrical equipment.
• Do not attempt to install or use the product until installation instructions and safety labels are fully understood.
This product is designed for indoor and outdoor usage.
• Ensure product operates within the specified temperature range.
• Do not attempt to open the product.
• Do not use the product if the power cables are damaged.
• Only use product for specified voltage.
• Always maintain connection to ensure waterproofing.
• If the product has been subjected to drastic temperature variances, for example, following transportation,
do not connect the fixture until it has reached room temperature, as moisture condensation may cause electric
shock and product damages.
• When installing the products and system power supplies, please ensure they will not be exposed to moisture and extreme heat
(and direct sunlight for outdoor products). Besides, keep a clean operating environment for the fixtures and system power supplies..
• Any non-compliance of the Installation Guide will void the Hera warranty.
Hera warrants the products for a period of five (5) years from date of purchase, provided that
the purchased items are used under the conditions stated in this user manual.
Warning
Please study this Installation Guide throughly and check the latest Technical Specification Sheets available from the
our website www.heraled.com before setup.
Marking
DMX
RDM
65
Risk of
Electric
Shock
Do Not Open
Products
Warning!
Refer to User
Manual.
Not Suitable
for Household Room
Illumination
DIRECTIVE 2012/19/EU
Waste Electrical
and Electronic Equipment
3D VERTICAL TUBE RGB SERIES
All manuals and user guides at all-guides.com

Explanation
500mm / 18.68"
1000mm / 39.37"
1500mm / 59.05"
2000mm / 78.07"
30mm
1.37"
VT100-RGB 3D Vertical Tube
VT50-RGB 3D Vertical Tube
VT150-RGB 3D Vertical Tube®
VT200-RGB 3D Vertical Tube
35mm
1.18"
Dimension
3D Vertical Tube RGB Series are designed 3D visual lighting for night club, atrium shopping center; high ceilinged hotel lobbies
atriums and rental companies. It can be seen with large outlook angle (130°x2) and very lightweight body. 2D objects are
converted into 3D objects and effects by pixel mapping and advanced programming technology. It gives dynamic lighting
solutions with its unlimited pixel options, advanced accessories and easy assembly.
• It communicates with other fixtures by standard DMX 512 and RDM protocols without requirements of any special
communication protocols or production identity. It can be addressed remotely as a group. By courtesy of this feature pixel
mapping and addressing are easier.
• It can be used with very long starting cables and jumper cables for flexible and easy application due to its 12-48 VDC working
voltage range.
• Fixtures’ working characteristics may be changed with DMX Personality. By this means pixel number can be changed.
Number of pixels may change in order to optimize for appearances and scenarios. For example it is possible that 1 LED can be
chosen for 1 pixel for each 35mm, also 2 LEDs can be chosen for 1 pixel, 4 LEDs can be chosen 1 pixel, 8 LEDs can be chosen
1 pixel and so on.
• Working status of fixtures, local temperature values, voltage input and output, serial number and DMX address can be
monitored. User is informed by mail and system can response automatically according to data.
• Fixtures work compatibly with Madrix® software and hardware. You can choose fixtures in library in order to have easy pixel
mapping.
• Profiles are resistant to UV light and impact. Due to its PMMA and PC materials, it will not go yellow.
• Fixtures are installed very easily by push lock thanks to special top cover and mounting device.
• Fixtures are produced in 500mm / 1000mm / 1500mm / 2000mm length for different and long formed application.
• Power and data are transmitted via T cables in 60 cm and 120 cm length as standard. IP68 connectors can be installed easily
by rotating. Interspaces between fixtures are enough. Therefore additional junction boxes are not needed.
• It has clear body as standard but opaque and translucent bodies can be produced as well.
3D VERTICAL TUBE RGB SERIES
www.heraled.com 3
All manuals and user guides at all-guides.com

Product Specifications
Light Source:
Lumen Maintenance:
Color Resolution:
Maximum in Chain:
Luminous Intensity:
Efficacy (lm/W):
Operating Voltage:
Power Consumption:
Control Interface:
Addressing:
Monitoring:
Housing:
Environment:
Operating Temperature:
Storage Temperature:
Voltage Monitoring,Temperature Monitoring, Status Monitoring,Power Cycle Monitoring, Lumen-Maintenance Life Monitoring
Plastic Extrusion Polycarbonate Body
-40°C - 50°C - (-40° - 122° F)
-40°C - 85°C - (-40°C - 185° F)
Model
56pcs/m High intensity 3 in 1 Chip RGB LEDs (Double Sided)
60.000+ hours L70 @ 25° C (full output)
3 x 14-bit (Gamma correction)
Max 20 meters or 32 pieces (varies by selected DMX personality)
12VDC ~ 48VDC
USITT DMX 512 A
RDM (Group of Remote Addressable Systems)
VT 50RGB
35mm
Color Range: 16.7 Million additive RGB colors, white CCT 6500K
VT 100RGB VT 200RGB VT 150RGB
Dimensions (H x W x D):
( Ø1.18x19.7 in )
Ø30x500 mm Ø30x1500 mm
( Ø1.18x59 in )
Ø30x1000 mm
( Ø1.18x39.4 in )
Ø30x2000 mm
( Ø1.18x78.7 in )
Weight: 0.521kg (1.14lb) 0.487kg (1.07lb)
0.479kg (1.05lb)
0.444kg (0.98lb)
Certification:
Viewing Angle: 130°x2
Pixel Pitch: Pixel pitch is configurable via RDM, max 28pixel/m
LED Pitch:
PWM Frequency: 1,600Hz flicker free dimming to 0.1%
Product Specifications
8W 16W 32W24W
Please check IES and LTD files out
Please check IES and LTD files out
3D VERTICAL TUBE RGB SERIES
www.heraled.com 4
EU EMC: EN 55024:2010/A1:2015, EN 55032:2015/AC:2016-07, -EN 61000-4-3, EN 61000-4-4, EN 61000-4-6, EN 61000-4-8
US Safety: UL 60950-22, UL 60950-1
US EMC: FCC Part 15 Class A
EU Safety: EN 60950-22:2006 + AC: 2008, EN 60950-1:2006+A2:2013, EN 62262:2002
I P65, I K07
All manuals and user guides at all-guides.com

Connection DiagramConnection DiagramConnection Diagram
Standart DMX Wiring Diagram
DMX 1 DMX 2 DMX 3 DMX 4 DMX 5 DMX 6 DMX 7 DMX 8 DMX IN USB Ethernet
8
5 Pole Female XLR Connector
5 Pole Male XLR Connector
Neutrik® powerCon 20A
RJ45
RJ45
Indoor Zone
Ethernet
DMX Signal
RISK OF
ELECTRIC
SHOCK
90~264VAC 50/60Hz
AC Input
3-Pin VDE
RISK OF
ELECTRIC
SHOCK
90~264VAC 50/60Hz
The MADRIX Software is the ultimate
control tool for LED lighting.
Use pixel mapping at its best in 2D or 3D
PC
DMX IN
PIN DETAILS
(-)
DMX (+)
(+)
DMX (-)
DMX & POWER OUT
1
3
2
1 GND
3 DMX +
2 DMX -
4
5
4 NC
5 NC
1
3
2
1 GND
3 DMX +
2 DMX -
4
5
4 NC
5 NC
Standart DMX Wiring Diagram
Power Pack 1000 125W Per Port
Power Pack 2000 250W Per Port
4 Pin Female
Connector
Outdoor Zone
4 Pin Male
Connector
www.heraled.com 5
www.heraled.com
3D VERTICAL TUBE RGB SERIES
All manuals and user guides at all-guides.com

Indoor Zone
Outdoor Zone
www.heraled.com
www.heraled.com
Power Pack 1000 125W Per Port
Power Pack 2000 250W Per Port
4 Pin Female
Connector
4 Pin Male
Connector
DMX / RDM Universes
Voltage Monitoring,Temperature Monitoring,
Status Monitoring,Power Cycle Monitoring,
Lumen-Maintenance Life Monitoring
DMX Data Sending RDM Monitoring
Luminex Lighting Control Equipment ©
The MADRIX Software is the ultimate
control tool for LED lighting.
Use pixel mapping at its best in 2D or 3D
Luminex
Luminex Lighting Control Equipment ©
1 2 3 4 5 6 7 8 Ethernet
Ethernet- DMX8 MK II
RJ45
RJ45 Ethernet
Luminex
PC
5 Pole Male XLR Connector
DMX Signal
5 Pole Famele XLR Connector
1
3
2
1 GND
3 DMX +
2 DMX -
4
5
4 NC
5 NC
RISK OF
ELECTRIC
SHOCK
90~264VAC 50/60Hz AC Input
3-Pin VDE
Neutrik®
powerCon 20A
90~264VAC 50/60Hz
RISK OF
ELECTRIC
SHOCK
DMX IN
PIN DETAILS
(-)
DMX (+)
(+)
DMX (-)
DMX & POWER OUT
1
3
2
1 GND
3 DMX +
2 DMX -
4
5
4 NC
5 NC
RDM Monitoring Wiring Diagram
6
3D VERTICAL TUBE RGB SERIES
All manuals and user guides at all-guides.com
all-guides.com

3D Vertical Tube® RGB DMX Personality
www.heraled.com
www.heraled.com 7
No Fixture Personality Value Function Description
10-255 Red: 0-100%
20-255 Green: 0-100%
30-255 Blue: 0-100%
10-255 Red: 0-100%
20-255 Green: 0-100%
30-255 Blue: 0-100%
10-255 Red: 0-100%
20-255 Green: 0-100%
30-255 Blue: 0-100%
10-255 Red: 0-100%
20-255 Green: 0-100%
30-255 Blue: 0-100%
VT100 RGB (Raw Mode)
4 RGB Raw Mode 14 LEDs:1px (3Ch.) Each colour (RGB) can be controlled
indiv idually
2 RGB Raw Mode 2 LEDs:1px (21Ch.) Each colour (RGB) can be controlled
indiv idually
3 RGB Raw Mode 7 LEDs:1px (6Ch.) Each colour (RGB) can be controlled
indiv idually
VT50 RGB (Raw Mode)
Channel
1 RGB Raw Mode 1 LED:1px (42Ch.) Each colour (RGB) can be controlled
indiv idually
No Fixture Personality Value Function Description
10-255
20-255
30-255
10-255
20-255
30-255
10-255
20-255
30-255
10-255
20-255
30-255
Red: 0-100%
Green: 0-100%
Blue: 0-100%
Red: 0-100%
Green: 0-100%
Blue: 0-100%
Red: 0-100%
Green: 0-100%
Blue: 0-100%
Red: 0-100%
Green: 0-100%
Blue: 0-100%
3 RGB Raw Mode 7 LEDs:1px (12Ch.) Each colour (RGB) can be controlled
indiv idually
4 RGB Raw Mode 14 LEDs:1px (6Ch.) Each colour (RGB) can be controlled
indiv idually
1 RGB Raw Mode 1 LED:1px (84Ch.) Each colour (RGB) can be controlled
indiv idually
2 RGB Raw Mode 2 LEDs:1px (42Ch.) Each colour (RGB) can be controlled
indiv idually
Channel
No Fixture Personality Value Function Description
1 0-255 Red: 0-100%
2 0-255 Green: 0-100%
3 0-255 Blue: 0-100%
1 0-255 Red: 0-100%
2 0-255 Green: 0-100%
3 0-255 Blue: 0-100%
1 0-255 Red: 0-100%
2 0-255 Green: 0-100%
3 0-255 Blue: 0-100%
1 0-255 Red: 0-100%
2 0-255 Green: 0-100%
3 0-255 Blue: 0-100%
VT150 RGB (Raw Mode)
Channel
1 RGB Raw Mode 1 LED:1px (126Ch.) Each colour (RGB) can be controlled
indiv idually
2 RGB Raw Mode 2 LEDs:1px (63Ch.) Each colour (RGB) can be controlled
indiv idually
3 RGB Raw Mode 7 LEDs:1px (18Ch.) Each colour (RGB) can be controlled
indiv idually
4 RGB Raw Mode 14 LEDs:1px (9Ch.) Each colour (RGB) can be controlled
indiv idually
No Fixture Personality Value Function Description
1 0-255
2 0-255
3 0-255
1 0-255
2 0-255
3 0-255
1 0-255
2 0-255
3 0-255
1 0-255
2 0-255
3 0-255
Red: 0-100%
Green: 0-100%
Blue: 0-100%
Red: 0-100%
Green: 0-100%
Blue: 0-100%
Red: 0-100%
Green: 0-100%
Blue: 0-100%
Red: 0-100%
Green: 0-100%
Blue: 0-100%
VT-200 RGB (Raw Mode)
Channel
1 RGB Raw Mode 1 LED:1px (168Ch.) Each colour (RGB) can be controlled
indiv idually
2 RGB Raw Mode 2 LEDs:1px (84Ch.) Each colour (RGB) can be controlled
indiv idually
3 RGB Raw Mode 7 LEDs:1px (24Ch.) Each colour (RGB) can be controlled
indiv idually
4 RGB Raw Mode 14 LEDs:1px (12Ch.) Each colour (RGB) can be controlled
indiv idually
3D VERTICAL TUBE RGB SERIES
All manuals and user guides at all-guides.com

White
DMX (+)
Blue
DMX(-)
Red
(+)48VDC
Black
GND
4
12
Assemble bracket and body of product
www.heraled.comwww.heraled.com
www.heraled.com 8
Turn right body of product 3Keep constant bracket and pull body of product
Installation Instruction
3D VERTICAL TUBE RGB SERIES
All manuals and user guides at all-guides.com

Installation Instruction
www.heraled.com 9
www.heraled.com
3D VERTICAL TUBE RGB SERIES
Assemble connector and body of product
1
23Screw body of product and finished installation
All manuals and user guides at all-guides.com

Installation Instruction
www.heraled.com 10
www.heraled.com
3D VERTICAL TUBE RGB SERIES
Installation Instruction
1
2
3
Pass connector through the bracket
Assemble connector and body of product
Screw body of product and finished installation
All manuals and user guides at all-guides.com

Accessories
www.heraled.com 11
www.heraled.com
P20022
4 Pin Leader Cable 2 Meter
P20023
4 Pin Leader Cable 5 Meter
P20024
4 Pin Leader Cable 10 Meter
P20025
4 Pin Leader Cable 15 Meter
P20026
4 Pin Leader Cable 20 Meter
P20039
Waterproof Cap For 4 Pin P08004 Power Pack
1000-48 1000W 8 Outputs
Power Supply
P08013 Power Pack
2000-48 2000W 8 Outputs
Power Supply
P20028
4 Pin Male IP67
Cable & Connector 30cm
AccessoriesAccessories & Recommended Products
P20020
60cm 4 Pin T Cable
P20021
120cm 4 Pin T Cable
P20027
4 Pin Female IP67
Cable & Connector 30cm
P01040085 VT50-RGB 3D Vertical Tube
P01041085 VT100-RGB 3D Vertical Tube
P01042085 VT150-RGB 3D Vertical Tube
P01043085 VT200-RGB 3D Vertical Tube
* Standart product that we provided is above. Please contact us for special orders
3D VERTICAL TUBE RGB SERIES
All manuals and user guides at all-guides.com
all-guides.com

www.heraled.com
All manuals and user guides at all-guides.com
