HERA DS Series Installation and operating instructions

www.heraled.com
Index V.1.0
User’s Manual & Installation Guide
Congratulations on choosing a HERA product!
We thank you for your custom.
Please note that this product, as all the others in the rich HERA range, has been designed and made with total quality to ensure excellent performance and best meet your
expectations and requirements. Carefully read this instruction manual in its entirety and keep it safe for future reference. It is essential to know the information and comply
with the instructions given in this manual to ensure the fitting is installed, used and serviced correctly and safely. HERA disclaims all liability for damage to the fitting or to
other property or persons deriving from installation, use and maintenance that have not been carried out in conformity with this instruction manual, which must always
accompany the fitting. HERA reserves the right to modify the characteristics stated in this instruction manual at any time and without prior notice.
Explanation / Dimension
3Back Cover
7
Ordering Information
6
Safety Information / Warning / Warranty / Marking
2
Product Specifications
4
1Cover & Index 5Standart DMX Wiring Diagram
DS DMX SPLITTER SERIES

www.heraled.comwww.heraled.com 2
DS DMX SPLITTER SERIES
www.heraled.com
20
Safety Information
Warranty
Caution – unplug the power supply from the main power before connecting any cables as this can damage the products.
Caution – avoid looking directly into the led light source at close range for your own safety.
Any people installing this product should comply with local standards and regulations and must be qualified for the handling of
electrical equipment.
• Do not attempt to install or use the product until installation instructions and safety labels are fully understood.
This product is designed for indoor and outdoor usage.
• Ensure product operates within the specified temperature range.
• Do not attempt to open the product.
• Do not use the product if the power cables are damaged.
• Only use product for specified voltage.
• Always maintain connection to ensure waterproofing.
• If the product has been subjected to drastic temperature variances, for example, following transportation,
do not connect the fixture until it has reached room temperature, as moisture condensation may cause electric
shock and product damages.
• When installing the products and system power supplies, please ensure they will not be exposed to moisture and extreme heat
(and direct sunlight for outdoor products). Besides, keep a clean operating environment for the fixtures and system power .
• Any non-compliance of the Installation Guide will void the Hera warranty.
Hera warrants the products for a period of five (5) years from date of purchase, provided that
the purchased items are used under the conditions stated in this user manual.
Warning
Please study this Installation Guide throughly and check the latest Technical Specification Sheets available from the
our website www.heraled.com before setup.
supplies.
Marking
DMX
RDM
Risk of
Electric
Shock
Do Not Open
Products
Warning!
Refer to User
Manual.
DIRECTIVE 2012/19/EU
Waste Electrical
and Electronic Equipment
Avoid Contact with
Liquids

Explanation
DS-2, DS-4, DS-8 products are used to protect devices and split outputs which uses DMX 512. Splitter's
main objective is to protect data clearly that makes DMX signals work properly. Splitter can amplify
weakened signal to original level. DMX may break down due to bad cabling and bad connection. DS
series splitter can amplify signal to desired level.
· DS-2 2Ch. and DS-4 4Ch. have Full isolated feature and DS-8 8Ch. has Full isolated DMX Splitter /Booster features.
It has 90 ~ 264VAC 50/60HZ Universal AC input 3-Pin VDE input
All DMX inputs are performed with Neutrik® 3 Pin XLR connectors.
· They isolated input signal both optically and inductively and transmit them to output.
· Owe to full isolated feature, even one of the output breaks down, others will not be affected.
· Each input and output signal can be monitored by LEDs on device.
· DS-2 can be installed as wall mount, DS-4 and DS-8 can be installed as rack mount and wall mount.
· It has aluminum sheet metal with powder finishing body.
· Power packs are produced in RAL9005 black color and have black iron screws but according to
customers' demand fixture can be painted to different RAL color.
www.heraled.comwww.heraled.com 3 www.heraled.com
DS DMX SPLITTER SERIES
44.5mm
1.75"
256mm /10"
483mm / 19"
44.5mm
1.75"
DS-4 / DS-8 DMX SPLITTER
DS-2 DMX SPLITTER
Dimension
50mm
1.97"

www.heraled.comwww.heraled.com 4 www.heraled.com
DS DMX SPLITTER SERIES
Power Input:
Power Connections:
Input & Output Interface:
Operating Temperature:
Housing:
Screw and Mounting:
Storage Temperature:
Dimensions (H x W x D):
Weight:
Certification:
Model
90 ~ 264VAC 50/60Hz Universal AC input
AC Input 3-Pin VDE
I P20
-40°C - 85°C (-40°C - 185° F)
Interface Connections:
Output Models:
Aluminium Sheet Metal With Powder Finishing
Type of Installation
EU safety: EN 60950
EU EMC: EN 55103-1, EN 55103-2, EN 55022, EN 55024, EN 61000-3-2, EN 61000-3-3
US safety: UL 60950-1, UL 60950-22
US safety: ANSI/UL 60950-1
Neutrik® 5 Pin XLR
2 x Full Isolated Splitted
44.5x256x50 mm
(1.75x10x1.97 in)
0.42 kg (0.92 lb)
4 x Full Isolated Splitted
44.5x483x50 mm
(1.75x19x1.97 in)
0.73 kg (1.6 lb)
8 x Full Isolated Splitted
44.5x483x50 mm
(1.75x19x1.97 in)
0.76 kg (1.67 lb)
Product Specifications
Black Iron
Wall Mount Wall Mount / 1U Rack Mount Wall Mount / 1U Rack Mount
Environment:
-40°C - 85°C (-40°C - 185° F)
USITT DMX 512 A

Connection DiagramConnection DiagramConnection Diagram
Standart DMX Wiring Diagram
DMX 1 DMX 2 DMX 3 DMX 4 DMX 5 DMX 6 DMX 7 DMX 8 DMX IN USB Ethernet
8
5 Pole Male XLR Connector
RJ45
RISK OF
ELECTRIC
SHOCK
90~264VAC 50/60Hz
AC Input
3 Pin VDE
The MADRIX Software is the ultimate
control tool for LED lighting.
Use pixel mapping at its best in 2D or 3D
PC Ethernet
RJ45
5 Pole Male XLR Connector
5 Pole Female XLR Connector
AC Input
3 Pin VDE
DMX Signal
AC Input
3 Pin VDE
www.heraled.comwww.heraled.com 5 www.heraled.com
*ANSI E1.20 - 2010 Entertainment Technology - RDM over USITT DMX 512 Networks.
Outdoor Zone
DS DMX SPLITTER SERIES
DS SERIES PIN DETAILS
1
3
2
1 GND
3 DMX +
2 DMX -
4
5
4 NC
5 NC
DMX IN

www.heraled.comwww.heraled.com 6 www.heraled.com
AccessoriesOrdering Information
P08005 DS-2 1in 2 Out Full Isolated Splitter
DS DMX SPLITTER SERIES
P08006 DS-4 1in 4 Out Full Isolated Splitter
P08007 DS-8 1in 8 Out Full Isolated Splitter
*Standart product codes that we provided is above. Please contact us for special orders.
P21001 Ethernet to XLR Cable
AccessoriesAccessories
