HERA PD 60 DYNAMIC WHITE SERIES Installation and operating instructions

www.heraled.com
Index
PD 60 DYNAMIC WHITE SERIES
User’s Manual & Installation Guide
V.1.0
www.heraled.com
Congratulations on choosing a HERA product!
We thank you for your custom.
Please note that this product, as all the others in the rich HERA range, has been designed and made with total quality to ensure excellent performance and best meet your
expectations and requirements. Carefully read this instruction manual in its entirety and keep it safe for future reference. It is essential to know the information and comply
with the instructions given in this manual to ensure the fitting is installed, used and serviced correctly and safely. HERA disclaims all liability for damage to the fitting or to
other property or persons deriving from installation, use and maintenance that have not been carried out in conformity with this instruction manual, which must always
accompany the fitting. HERA reserves the right to modify the characteristics stated in this instruction manual at any time and without prior notice.
RDM Monitoring Wiring Diagram
6
2Safety Information / Warning / Warranty / Marking
Explanation / Dimension
3
Product Specifications
4
1Cover & Index
5
Standart DMX Wiring Diagram
9Installation Instruction
Ordering Information
Accessories / Recommended Products
11
7Connection Diagram
Back Cover
12

www.heraled.com 2
Safety InformationSafety Information
Warranty
Caution – unplug the power supply from the main power before connecting any cables as this can damage the products.
Caution – avoid looking directly into the led light source at close range for your own safety.
Any people installing this product should comply with local standards and regulations and must be qualified for the handling of
electrical equipment.
• Do not attempt to install or use the product until installation instructions and safety labels are fully understood.
This product is designed for indoor and outdoor usage.
• Ensure product operates within the specified temperature range.
• Do not attempt to open the product.
• Do not use the product if the power cables are damaged.
• Only use product for specified voltage.
• Always maintain connection to ensure waterproofing.
• If the product has been subjected to drastic temperature variances, for example, following transportation,
do not connect the fixture until it has reached room temperature, as moisture condensation may cause electric
shock and product damages.
• When installing the products and system power supplies, please ensure they will not be exposed to moisture and extreme heat
(and direct sunlight for outdoor products). Besides, keep a clean operating environment for the fixtures and system power supplies..
• Any non-compliance of the Installation Guide will void the Hera warranty.
Hera warrants the products for a period of five (5) years from date of purchase, provided that
the purchased items are used under the conditions stated in this user manual.
Warning
Please study this Installation Guide throughly and check the latest Technical Specification Sheets available from the
our website www.heraled.com before setup.
Marking
DMX
RDM
67
Risk of
Electric
Shock
Do Not Open
Products
Warning!
Refer to User
Manual.
Not Suitable
for Household Room
Illumination
DIRECTIVE 2012/19/EU
Waste Electrical
and Electronic Equipment
PD 60 DYNAMIC WHITE SERIES

www.heraled.com 3
Explanation
Dimension
34mm
1.4"
72mm
2.8"
34mm
1.4"
44mm
1.7"
60mm/ 2,3"
90mm
3.54"
73mm / 2.87"
34mm
1.4"
44mm
1.7"
34mm
1.4"
72mm
2.8"
60mm/ 2,3"
90mm
3.54"
73mm / 2.87"
P D60 DW Series is used in industrial application where high brightness, broad color scale, customization and very long pixel pitch distances
are needed with excellent color consistency. Splendid effects can be animated with large fixtures without limitation of geometry, shape and
range. Any animation can be animated in desired color temperature with 2700K and 6500K LEDs. PD60 connectors’ are on back side, PD60S
DW connectors’ are on side face. Opaque covered dome models are mostly used in extraordinary designs. It can be seen from long distances
owe to its 48 LEDs per pixel. This product presents direct view and spotlighting solutions for media facades lighting, bridges, stadiums and
major projects.
• It includes LEDs that have configurable white light options to find right lighting temperatures. Product is suitable for animations can be made
in intended warm or cool color by using 2700K and 6500K LEDs.
• It communicates with other fixtures by standard DMX 512 and RDM protocols without requirements of any special communication protocols
or production identity. It can be addressed remotely as a group. By courtesy of this feature pixel mapping and addressing are easier.
• It can be used with very long starting cables and jumper cables for flexible and easy application due to its 12-48 VDC working voltage range.
• Working status of fixtures, local temperature values voltage input and output, serial number and DMX address can be monitored. User is
informed by mail and system can response automatically according to data.
• Fixtures work compatibly with Madrix® software and hardware. You can choose fixtures in library in order to have easy pixel mapping.
• There are Direct View and Dome options. PD60 DW connectors’ are on back side, PD60S DW connectors’ are on side face. Transparent and
opaque covers are resistant to UV light and impact. Due to its PMMA and PC materials, it will not go yellow.
• Fixtures are designed for harsh outdoor condition and resistant against vibration, impact and thermal shock owe to their solid aluminum
structures, special filling material and IP67 class protection markings.
• Power and data are transmitted by input and output connectors. IP68 connectors can be installed easily by rotating. Interspaces between
fixtures are enough. Therefore additional junction boxes are not needed.
• Fixtures are produced in RAL9005 black color but according to customers’ demand fixture can be painted to different
RAL colors.
PD 60 DYNAMIC WHITE SERIES

Light Source:
Lumen Maintenance:
Color Resolution:
Maximum in Chain:
Luminous Intensity:
Efficacy (lm/W):
Operating Voltage:
Power Consumption:
Control Interface:
Addressing:
Monitoring:
Housing:
Environment:
Operating Temperature:
Storage Temperature:
Voltage Monitoring,Temperature Monitoring, Status Monitoring,Power Cycle Monitoring, Lumen-Maintenance Life Monitoring
Die-Cast Aluminium Body
-40°C - 50°C - (-40° - 122° F)
-40°C - 85°C - (-40°C - 185° F)
Model
48pcs High intensity 3528 LEDs
60.000+ hours L70 @ 25° C (full output)
2 x 14-bit (Gamma correction)
Max 32pcs
12VDC ~ 48VDC
5W (all LEDs on)
USITT DMX 512 A
RDM (Group of Remote Addressable Systems)
Direct View
Color Range: White CCT 2700-6500K
Diffused View
Product Specifications
Dimensions (H x W x D): 44x90x73 mm ( 1.73x3.54x2.87 in ) 72x90x73 mm ( 2.83x3.54x2.87 in)
Weight:
Viewing Angle: 120° 180°
0.305 kg (0.672 lb) 0.325 kg (0.716 lb)
Certification:
www.heraled.com 4
PWM Frequency: 1,600Hz flicker free dimming to 0.1%
PD 60 DYNAMIC WHITE SERIES
I P67, IK09
EU Safety: EN 60950-22:2006 + AC: 2008, EN 60950-1:2006+A2:2013, EN 62262:2002
EU EMC: EN 55024:2010/A1:2015, EN 55032:2015/AC:2016-07, -EN 61000-4-3, EN 61000-4-4, EN 61000-4-6, EN 61000-4-8
US Safety: UL 60950-22, UL 60950-1
US EMC: FCC Part 15 Class A
Please check IES and LTD files
Please check IES and LTD files

DMX 1 DMX 2 DMX 3 DMX 4 DMX 5 DMX 6 DMX 7 DMX 8 DMX IN USB Ethernet
8
5 Pole Male XLR Connector
RJ45
RISK OF
ELECTRIC
SHOCK
90~264VAC 50/60Hz
AC Input
3-Pin VDE
The MADRIX Software is the ultimate
controll tool for LED lighting.
Use pixel mapping at its best in 2D or 3D
PC
Ethernet
RJ45
Power pack 320
RISK OF
ELECTRIC
SHOCK
90~264VAC 50/60Hz
3 Pole Female XLR Connector
3 Pole
Female XLR
Connector
5 Pin Female
Connector
Max. in chain 32 Pcs.
RISK OF
ELECTRIC
SHOCK
90~264VAC 50/60Hz
RISK OF
ELECTRIC
SHOCK
90~264VAC 50/60Hz
DMX Signal
5 Pin Female
Connector
5 Pin Male
Connector
Standart DMX Wiring Diagram
POWER PACK 320 PIN DETAILS
DMX IN DMX & POWER OUT
Outdoor Zone
Indoor Zone
Max. in chain 32 Pcs.
www.heraled.com 5
AC Input
3 Pin VDE
Maximum 50 meter Leader Cable
Max. in chain 32 Pcs. Max. in chain 32 Pcs. Max. in chain 32 Pcs. Max. in chain 32 Pcs. Max. in chain 32 Pcs.
PD 60 DYNAMIC WHITE SERIES

DMX / RDM Universes
Voltage Monitoring,Temperature Monitoring,
Status Monitoring,Power Cycle Monitoring,
Lumen-Maintenance Life Monitoring
DMX Data Sending RDM Monitoring
Luminex Lighting Control Equipment ©
The MADRIX Software is the ultimate
control tool for LED lighting.
Use pixel mapping at its best in 2D or 3D
Luminex
Luminex Lighting Control Equipment ©
1 2 3 4 5 6 7 8 Ethernet
Ethernet- DMX8 MK II
RJ45
RJ45
RISK OF
ELECTRIC
SHOCK
90~264VAC 50/60Hz
Ethernet
Luminex
AC Input
3-Pin VDE
PC
5 Pole Male XLR Connector
Power pack 320
RISK OF
ELECTRIC
SHOCK
90~264VAC 50/60Hz
3 Pole Female XLR Connector
3 Pole
Female XLR
Connector
5 Pin Female
Push LockConnector
Max. in chain 32 Pcs.
RISK OF
ELECTRIC
SHOCK
90~264VAC 50/60Hz
RISK OF
ELECTRIC
SHOCK
90~264VAC 50/60Hz
Maximum 50 meter Leader Cable
5 Pin Famale
Connector
5 Pin Male
Connector
www.heraled.com 6
PUSH THE BUTTON
TO USE AS RDM
Indoor Zone
Outdoor Zone
Max. in chain 32 Pcs. Max. in chain 32 Pcs. Max. in chain 32 Pcs. Max. in chain 32 Pcs. Max. in chain 32 Pcs.
RDM Monitoring Wiring Diagram
POWER PACK 320 PIN DETAILS
DMX IN
DMX & POWER OUT
DMX Signal
PD 60 DYNAMIC WHITE SERIES

www.heraled.comwww.heraled.com
www.heraled.com 7
Connection Diagram
2Turn to left and pull for removing.
3For instance diagram
Max.cable length 50 meter for pixel pitch
Turn
1
Push arrow direction
Pull
Push
Lock
Input Output
DMX +
DMX -
(+) 48VDC
(-) 48VDC
GND
(+) 48VDC
(-) 48VDC
GND
White DMX +
Blue DMX -
PD60 PIN DETAILS
PD 60 DYNAMIC WHITE SERIES

Connection Diagram
Push
Lock
Turn
1
Push arrow direction
2Turn to left and pull for removing.
Pull
3For instance diagram
Max.cable length 50 meter for pixel pitch
Connection Diagram
www.heraled.comwww.heraled.com
www.heraled.com 8
Input Output
DMX +
DMX -
(+) 48VDC
(-) 48VDC
GND
(+) 48VDC
(-) 48VDC
GND
White DMX +
Blue DMX -
PD60 PIN DETAILS
PD 60 DYNAMIC WHITE SERIES

www.heraled.com 9
Installation Instruction
Screwing diagram as shown at figure 1
Connector connection diagram as shown at figure 2
Finished Installation as shown at figure 3
1
3
PD 60 DYNAMIC WHITE SERIES

www.heraled.com 10
Screwing diagram as shown at figure 1 Connector connection diagram as shown at figure 2
Finished Installation as shown at figure 3
2
1
3
Installation Instruction
PD 60 DYNAMIC WHITE SERIES

Color Selection
Ordering Information
www.heraled.com 11
PD 60 DYNAMIC WHITE SERIES
Color Selection
Ordering Information
P01003105 PD60-RGBW 4Ch. DMX Direct View Pixel Dot
P01004105 PD60S-RGBW 4Ch. DMX Direct View Pixel Dot
AccessoriesAccessories / Recommended Products
P20005
5 Pin Jumper Cable 2 Meter
P20006
5 Pin Leader Cable 5 Meter
P20001 5
5 Pin Jumper Cable 0,75 Meter P20002
5 Pin Jumper Cable 1 Meter
P20003
Pin Jumper Cable 1,2 Meter
P20004
5 Pin Jumper Cable 1,5 Meter
P20009
5 Pin Leader Cable 20 Mete
P20019
Waterproof Cap For 5 Pin
P20008
5 Pin Leader Cable 15 Meter
P20007
5 Pin Leader Cable 10 Meter
P08002
Power Pack 320-48
Full Isolated DMX Splitter
P01005105 PD60-RGBW 4Ch. DMX Dome Pixel Dot
P01009105 PD60S-RGBW 4Ch. DMX Dome Pixel Dot
*Standart product codes that we provided is above. Please contact us for special orders.
