HERA SWORD SINGLE COLOR Radius Diffused Installation and operating instructions

Congratulations on choosing a HERA product!
We thank you for your custom.
Please note that this product, as all the others in the rich HERA range, has been designed and made with total quality to ensure excellent performance and best meet your
expectations and requirements. Carefully read this instruction manual in its entirety and keep it safe for future reference. It is essential to know the information and comply
with the instructions given in this manual to ensure the fitting is installed, used and serviced correctly and safely. HERA disclaims all liability for damage to the fitting or to
other property or persons deriving from installation, use and maintenance that have not been carried out in conformity with this instruction manual, which must always
accompany the fitting. HERA reserves the right to modify the characteristics stated in this instruction manual at any time and without prior notice.
Cover & Index
1
Safety Information / Warning / Waranty /Marking
2
Product Specifications
4
Explanation / Dimension
3
Connection Diagram
5
Ordering Information
Accessories & Recommended Products
7
Back Cover
Installation Instruction
6
9
SWORD SINGLE COLOR SERIES
User’s Manual & Installation Guide
R
Index V.1.0

www.heraled.com 2
Safety Information
Warranty
Caution – unplug the power supply from the main power before connecting any cables as this can damage the products.
Caution – avoid looking directly into the led light source at close range for your own safety.
Any people installing this product should comply with local standards and regulations and must be qualifed for the handling of
electrical equipment.
• Do not attempt to install or use the product until installation instructions and safety labels are fully understood.
This product is designed for indoor and outdoor usage.
• Ensure product operates within the specifed temperature range.
• Do not attempt to open the product.
• Do not use the product if the power cables are damaged.
• Only use product for specifed voltage.
• Always maintain connection to ensure waterproofing.
• If the product has been subjected to drastic temperature variances, for example, following transportation,
do not connect the fixture until it has reached room temperature, as moisture condensation may cause electric
shock and product damages.
• When installing the products and system power supplies, please ensure they will not be exposed to moisture and extreme heat
(and direct sunlight for outdoor products). Besides, keep a clean operating environment for the fixtures and system power supplies..
• Any non-compliance of the Installation Guide will void the Hera warranty.
Hera warrants the products for a period of five (5) years from date of purchase, provided that
the purchased items are used under the conditions stated in this user manual.
Warning
Please study this Installation Guide thougly and check the lates Tecnical Specification Sheets available from the
our website www.heraled.com before setup.
Marking
67
Rısk of
Electric
Shock
Do Not Open
of Pruoducts
Warning!
Refer to User
Manual.
Not Suitable
for Household Room
Illumination
DIRECTIVE 2012/19/EU
Waste Electrical
and Electronic Equipment
R
SWORD SINGLE COLOR SERIES

Explanation
1200 mm / 47"
300 mm / 11.8"
1500 mm / 59 "
900 mm / 36"
600 mm / 23.6"
Dimension
www.heraled.com 3
25 mm / 1"
65 mm / 2.55"
46 mm / 1.8"
41mm / 1.6"
65mm / 2.55"
41mm / 1.6"
50 mm / 1.9"
41mm / 1.6"
94.5mm / 3.72"
41mm / 1.6"
R
SWORD SINGLE COLOR SERIES
Sword® Single Color Series provide ideal lighting with excellent color rendering on media facades lighting, bridges,
stadiums, creative scene lighting and special design lighting. There are 48 LEDs on system. Product has Red, Green, Blue,
Amber, 2700 K, 4000K and 6500K color options and works with 24VDC. It provides dynamical lighting where long and linear
view is needed. Therefore product is suitable for private demands. Equipment like 1-10V, DALI, DMX is needed for dimmable
effects.
• Lighting can be provided in any desired fixed colors.
• Equipment like 1-10V, DALI, DMX in order to dim and animate.
• It can be used with very long starting cables and jumper cables for flexible and easy application due to its 12-48 VDC
working voltage range.
• There are Direct View, Radius Diffused, Round Diffused, Flat Diffused options. Diffusers’ profiles are resistant to UV light and
impact. Due to its PMMA and PC materials, it will not go yellow.
• Fixtures can assembled side by side and create no gap due to its special design. It forms linear view.
• Fixtures are produced 300mm, 600mm, 900mm, 1200mm, and 1500mm for long and different forms. It gives flexible installment
advantage in limited area with moveable assembly parts on fixture.
• Fixtures are designed for harsh outdoor condition and resistant against vibration, impact and thermal shock owe to their
solid aluminum structures, special filling material and IP67 class protection markings.
• Power and data are transmitted by input and output connectors. IP68 connectors can be installed
easily by rotating. Interspaces between fixtures are enough. Therefore additional junction boxes are not needed.
• Fixtures can easily integrate and camouflage on different facade linings owe to their thin section (30mm). Fixtures are
produced in RAL9005 black color but according to customers’ demand fixture can be painted to different RAL colors.

Product Specifications
www.heraled.com 4
RR
SWORD SINGLE COLOR SERIES
Viewing Angle:
Storage Temperature: -40°C - 85°C - (-40°C - 185° F)
Dimensions (H x W x D):
300mm
(1.6x11.8x1.8 in)
41x300x46 mm 41x300x94.5 mm
(1.6x11,8x3.72 in)
41x300x65 mm
(1.6x11,8x2.55 in)
41x300x65 mm
(1.6x11.8x2.55 in)
600mm 41x600x46 mm
(1.6x23.6x1.8 in)
41x600x94.5 mm
(1.6x23.6x3.72 in)
41x600x65 mm
(1.6x23.6x2.55 in)
41x600x65 mm
(1.6x23.6x2.55 in)
Weight:
300mm 0.521kg (1.14lb) 0.487kg (1.07lb)
0.479kg (1.05lb)
0.444kg (0.98lb)
600mm 0.809kg (1.78lb) 0.963kg (2.12lb) 0.895kg (1.97lb)
0.879kg (1.94lb)
1.13kg (2.49lb)
900mm 1.36kg (2.99lb) 1.26kg (2.87lb)
1.23kg (2.71lb)
1200mm 1.44kg (3.17lb) 1.74kg (3.83lb) 1.61kg (3.54lb)
1.57kg (3.46lb)
Certification:
1200mm 41x1200x46 mm
(1.6x47.2x1.8 in)
41x1200x94.5 mm
(1.6x47.2x3.72 in)
41x1200x65 mm
(1.6x47.2x2.55 in
41x1200x65 mm
(1.6x47.2x2.55 in)
1500mm 1.77kg (3.90lb) 2.15kg (4.73lb) 1.98kg (4.36lb)1.94kg (4.27lb)
1500mm 41x1500x46 mm
(1.6x59x1.8 in)
41x1500x94.5 mm
(1.6x59x3.72 in)
41x1500x65 mm
(1.6x59x2.55 in)
41x1500x65 mm
(1.6x59x2.55 in)
900mm 41x900x46 mm
(1.6x35.4x1.8 in)
41x900x94.5 mm
(1.6x35.4x3.72 in)
41x900x65 mm
(1.6x35.4x2.55 in)
41x900x65 mm
(1.6x35.4x2.55 in)
Light Source: 48pcs/m High intensity 3528 LEDs
Lumen Maintenance:
280
Color Range: Red, Green, Blue, Amber, Warm White, Natural White, Cool White
Luminous Intensity: Please check IES and LTD files out
Efficacy: Please check IES and LTD files out
20mm
LED Pitch:
Maximum in Chain: Max 20 meters
Operating Voltage: 24VDC
Power Consumption: 6W/m (all LEDs on)
Control Interface: PWM (can be dimmable by 1-10V, DALI, DMX etc. with using proper power supply)
Housing: Aluminium Extrusion Body
Environment: I P67, I K09
Operating Temperature: -40°C - 50°C - (-40° - 122° F)
175° 280° 175°
60.000+ hours L70 @ 25° C (full output)
EU EMC: EN 55024:2010/A1:2015, EN 55032:2015/AC:2016-07, -EN 61000-4-3, EN 61000-4-4, EN 61000-4-6, EN 61000-4-8
US Safety: UL 60950-22, UL 60950-1
US EMC: FCC Part 15 Class A
EU Safety: EN 60950-22:2006 + AC: 2008, EN 60950-1:2006+A2:2013, EN 62262:2002

www.heraled.com 5
Connection DiagramConnection DiagramConnection Diagram
Connection Diagram
4 Pin Male
Connector
RISK OF
ELECTRIC
SHOCK
90~264VAC 50/60Hz
R
SWORD SINGLE COLOR SERIES
PIN DETAILS
(-)
NC
(+)
NC
POWER IN & OUT
RISK OF
ELECTRIC
SHOCK
90~264VAC 50/60Hz
RISK OF
ELECTRIC
SHOCK
90~264VAC 50/60Hz
RISK OF
ELECTRIC
SHOCK
90~264VAC 50/60Hz
RISK OF
ELECTRIC
SHOCK
90~264VAC 50/60Hz

Installation Instruction
www.heraled.com 6
R
SWORD SINGLE COLOR SERIES
Installation Instruction
P20039 Waterproof Cap
*In order to protect pin, use
*No need to space between
two products
1234
12
3
4

www.heraled.com 7
Ordering Information
P01058XX5 Sword® Single Color 300mm Direct View
P01059XX5 Sword® Single Color 600mm Direct View
P01060XX5 Sword® Single Color 900mm Direct View
P01061XX5 Sword® Single Color 1200mm Direct View
P01062XX5 Sword® Single Color 1500mm Direct View
P01094XX5 Sword® Single Color 300cm Flat Diffused
P01095XX5 Sword® Single Color 600mm Flat Diffused
P01096XX5 Sword® Single Color 900mm Flat Diffused
P01097XX5 Sword® Single Color 1200mm Flat Diffused
P01098XX5 Sword® Single Color 1500mm Flat Diffused
P01066XX5 Sword® Single Color 300mm Radius Diffused
P01067XX5 Sword® Single Color 600mm Radius Diffused
P01068XX5 Sword® Single Color 900mm Radius Diffused
P01069XX5 Sword® Single Color 1200mm Radius Diffused
P01070XX5 Sword® Single Color 1500mm Radius Diffused
P01078XX5 Sword® Single Color 300mm Round Diffused
P01079XX5 Sword® Single Color 600mm Round Diffused
P01080XX5 Sword® Single Color 900mm Round Diffused
P01081XX5 Sword® Single Color 1200cm Round Diffused
P01082XX5 Sword® Single Color 1500cm Round Diffused
R
SWORD SINGLE COLOR SERIES
AccessoriesAccessories & Recommended Products
P20022
4 Pin Leader Cable 2 Meter
P20023
4 Pin Leader Cable 5 Meter
P20024
4 Pin Leader Cable 10 Meter
P20025
4 Pin Leader Cable 15 Meter
P20026
4 Pin Leader Cable 20 Meter
P20039
Waterproof Cap For 4 Pin
P20027
4 Pin Female
IP67 Cable & Connector 30cm
P20028
4 Pin Male
IP67 Cable & Connector 30cm
P 1 2 3 4 7XX
01-Red
02-Green
03-Blue
04-Amber
05-Warm White
06-Natural White
07-Cool White

*Standart product codes that we provided is above. Please contact us for special orders.
P08018
Mean Well ELG150-24A 150Watt
24V 8.4A IP67 SMPS
P08019
Mean Well ELG220-24A 200Watt
24V 8.4A IP67 SMPS
P08016
Mean Well ELG75-24A 75Watt
24V 8.4A IP67 SMPS
P08017
Mean Well ELG100-24A 100Watt
24V 8.4A IP67 SMPS
P08020
Mean Well ELG240-24A 240Watt
24V 8.4A IP67 SMPS
AccessoriesAccessories & Recommended Products
R
SWORD SINGLE COLOR SERIES
www.heraled.com 8
