Hi-Tec ECLIPSE 7 User manual

DUPLEX TF module fits this transmitter well but you can also use Duplex TU and mount it
inside the transmitter. Antenna can be placed to the ori inal place. In this case we
recommend to use HE7 assembly kit. Durin handlin with the transmitter, it must be
switched off.It is necessary to solder. Put the transmitter on a soft pad to avoid dama e.
Switch off the transmitter
Turn upside down
Unscrew 6 screws
Open rear casin
Hitec Eclipse 7

Hitec Eclipse 7
Screw off the antenna
Solder conductors to the
connectors
red – power supply
black – round
yellow – PPMimpulses
Screw off ori inal transmittin antenna. There is connectin cabel in Duplex TU packa e.
Cut off connector on one side. Solder carefully each electric conductor to the „instructor-
student“ connector as shown on a picture.

Insert distance bars
Use carrier board from
assembly kit
Screw the carrier board
For Duplex TU module fixation, it is recommended to use parts from assembly kit HE7.
Use two lon er distance bars and screw the carrier board . Insert remainin distance bars
for mountin Duplex TU module.
Hitec Eclipse 7

Screw Duplex TU module
to the carrier board
Connect Duplex module
with the transmitter by
cable
Fix Duplex TU module with remainin distance bars and screws from assembly kit.
Connect Duplex TU module with the transmitter by cabel from assembly kit.
Hitec Eclipse 7

Hitec Eclipse 7
Put connector throu h out
from the transmitter
Put plastic part on
Screw the nut
Stick antenna part to the
transmitter
Unscrew nut and washer from antenna connector, put connector throu h out from the
transmitter. Put inlay from assembly kit on antenna connector, put in the washer and screw
the nut. Stick antenna part with lue to the transmitter.

Hitec Eclipse 7
Mount rear casin of
transmitter
Screw 2.4GHz antenna
Incase the transmitter with reverse procedure see pa e 1. Screw enclosed antenna.
Installation is completed. Before usin it is necessary to pair off new receiver and
transmitter, see receiver manual.
