1 Overview
The purpose of this document is to provide clear instructions on how to install and use
RR3740A Controller on Uniontech OS Server 20 system.
2 Installing Uniontech OS Server 20 on RR3740A
controller
If you would like to install Uniontech OS Server 20onto drives attached to RR3740A
controller, please perform the following operations:
Step 1 Prepare Your Hardware for Installation
Notcie: If your FT2000 motherboard is not directly connected to the SSD disk, it is normal for the
buzzer to sound continuously. You can communicate with the motherboard supplier to mute it.
After you attach your hard disks to RR3740Acontroller, you can use RR3740A EFI
Utility Utility to configure your hard disks as RAID arrays, or just use them as single
disks.
Before installation, you must remove all the disk drives, which are not physically attached
to RR3740Acontroller, from your system.
Note
If you have other SCSI adapters installed, you must make sure the RR3740A controller
EFI will be loaded firstly. If not, try to move it to another PCI slot. Otherwise you may be
unable to boot up your system.
Step 2 Check System EFI Settings
In your system BIOS SETUP menu, change Boot Sequence in such a way that the system
will first boot from EFI CDROM, and then from SCSI. Refer to your SCSI manual to see
how to set boot sequence.
If your EFI settings do not support such a boot sequence, you can first set it to boot from
EFI CDROM.After you finish installation, set SCSI as the first boot device to boot up the
system.
Step 3 Flash UEFI Rom to RR3740A
a. Unzip RR3740A UEFI package to root dir (/) of a USB flash driver, and insert the
USB flash drive to the motherboard;
b. Booting from the UEFI USB flash and enter the UEFI environment;
c. Command with “rr3740.nsh”, flash UEFI rom to RR3740A Controller and reboot;

RocketRAID 37xx/8xx/28xx Uniontech OS Server 20 Installation Guide
- 2 -
Step 4 Create Array
a. Attach two SATA to RR3740A Controller;
Note
Make sure your USB flash partition format is FAT32.
b. Boot, in the presence of the motherboard Log screen, there will be SATA
information：
c. Enter the motherboard’s Boot List and select start from UEFI USB flash:
d. Command ”Arraycreate.efi” to enter the Utility:

RocketRAID 37xx/8xx/28xx Uniontech OS Server 20 Installation Guide
- 3 -
e. Command “create RAID1 ”.
Create RAID1 array with all disks and with maximum capacity.
f. Command “exit”,exit the UEFI environment；
g. For more command usages, refer to Appendix A.
Step 5 Prepare the Driver Diskette
Extract RR3740A_UOS20_Server_1050d_aarch64_vx.x.x_xx_xx_xx.tar.gz
to top(/) directory of an USB flash drive. It will look like:
Step 6 Install Uniontech OS Server 20
Insert the USB diskette in to the USB port.
1) Start installing Uniontech OS Server 20 by booting from the installation CD/DVD.
2) On the startup screen. Just select “Install UnionTech OS Server 20(Graphic)”, and
then press ENTER to start installation.

RocketRAID 37xx/8xx/28xx Uniontech OS Server 20 Installation Guide
- 4 -
3) When the installation switches to the graphical installation, press “Ctrl+ALT+F2”to
switch the shell on console 2 before select "Next".
Type the following commands to load the RR3740Adriver:
# sudo su //get root
# mkdir /hptdd
# mount /dev/sdb1 /hptdd
# cp –r /hptdd/hptdd /tmp/
# umount /dev/sdb1

RocketRAID 37xx/8xx/28xx Uniontech OS Server 20 Installation Guide
- 5 -
Unplug all USB storage devices from system before execute following command:
# sh /tmp/hptdd/preinst.sh
4) Then type the following commands to restart the system installer:
# systemctl restart lightdm
The system installer will restart and select “Next”to continue installation.
5) When the installation program comes to selecting the installation location, full
installation is recommended.
6) When the screen shows that “Restart”，

RocketRAID 37xx/8xx/28xx Uniontech OS Server 20 Installation Guide
- 6 -
press “CRL+ALT+F2”to switch console 2 and type the following commands:
sh /tmp/hptdd/postinst.sh /dev/sdb
Press “Ctrl+ALT+F7”to switch back to installation screen and finish the
installation.
3 Installing RR3740A driver on an Existing System
Note
If you use a SCSI adapter to boot your system, you must make sure the RR3740A
controller EFI will be loaded after that adapter’s EFI. If not, try to move it to another PCI
slot. Otherwise you may be unable to boot up your system.

RocketRAID 37xx/8xx/28xx Uniontech OS Server 20 Installation Guide
- 7 -
Step 1 Obtain and install the Driver Module
Extract the driver archive to a temporary directory and execute the install.sh to install the
driver to the system. For example:
# mkdir /tmp/dd
# tar xzvf RR3740A_UOS20_Server_1050d_aarch64_vx.x.x_xx_xx_xx.tar.gz
-C /tmp/dd
# cd /tmp/dd
# sh install.sh
If the driver of previous version has been in the initrd image, the installer will update the
initrd image or it will make the driver automatically loaded while system up.
Step 2 Configure System to Mount Volumes when Startup
Now you can inform the system to automatically mount the array by modifying the file
/etc/fstab. E.g. you can add the following line to tell the system to mount /dev/sda1 to
location /mnt/raid after startup:
/dev/sda1 /mnt/raid ext3defaults 0 0
4 Monitoring the Driver
Once the driver is running, you can monitor it through the Linux proc file system support.
There is a special file under /proc/scsi/rr3740a/. Through this file you can view driver
status and send control commands to the driver.
Note
The file name is the SCSI host number allocated by OS. If you have no other SCSI cards
installed, it will be 0. In the following sections, we will use x to represent this number.
Using the following command to show driver status:
# cat /proc/scsi/rr3740a/x
This command will show the driver version number, physical device list and logical device
list.
5 Installing RAID Management Software
HighPoint RAID Management Software is used to configure and keep track of your hard
disks and RAID arrays attached to RR3740A controller. Installation of the management
software is optional but recommended.
Please refer to HighPoint RAID Management Software documents for more information.
6 Rebuilding Driver Module for System Update
When the system updates the kernel packages, the driver module rr3740a.ko should be
built and installed manually before reboot.

RocketRAID 37xx/8xx/28xx Uniontech OS Server 20 Installation Guide
- 8 -
To build the driver module, the RR3740A open source package and the following building
packages are needed: gcc, kernel-devel. The open source package can be got from
HighPoint website: http://www.highpoint-tech.com while the building tools can be
installed from UOS website: https://www.chinauos.com
Note: the package version of kernel-devel should be the same to the updated kernel
package.
Refer to the REAME file distributed with HighPoint RR3740A open source package on
how to build and install the driver module.

RocketRAID 37xx/8xx/28xx Uniontech OS Server 20 Installation Guide
- 9 -
Appendix A
Support command:
help/info/quit/exit/create/delete.
Create Command
Syntax
Create Array Type (RAID0/RAID1/RAID10) Member Disk list
(1/1,1/2|*)Capacity(100|*)
Examples
<<< create RAID0
<<< create RAID0 *
<<< create RAID0 * *
Create RAID1 array with all disks and with maximum capacity.
<<< create RAID1 1/1, 1/3 10
Create RAID1 array with disk 1/1 and 1/3 and with 10GB
capacity.
<<< create RAID10 *
Create RAID10 array with all disk and with maximum capacity.
Delete Command
Syntax
delete {array ID}
Examples
<<< delete 1
Delete the first array from Logical device list.
<<< delete 2
Delete the second array from Logical device list.
Info Command
Syntax
info
Display physical device list and logical list
Exit Command
Syntax
Q/q/quit/exit
Quit the application
Help Command
Syntax
H/h/help
This is help message.
