HIK VISION DS-K3B631TX Series User manual

DS-K3B631TX Series Swing Barrier
User Manual

Legal Informaon
©2022 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
About this Manual
The Manual includes instrucons for using and managing the Product. Pictures, charts, images and
all other informaon hereinaer are for descripon and explanaon only. The informaon
contained in the Manual is subject to change, without noce, due to rmware updates or other
reasons. Please nd the latest version of this Manual at the Hikvision website ( hps://
www.hikvision.com/ ).
Please use this Manual with the guidance and assistance of professionals trained in supporng the
Product.
Trademarks
and other Hikvision's trademarks and logos are the properes of
Hikvision in various jurisdicons.
Other trademarks and logos menoned are the properes of their respecve owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS IS" AND "WITH
ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR
PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION
BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY,
OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DS-K3B631TX Series Swing Barrier User Manual
i

DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED
TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN
RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATTER
PREVAILS.
Data Protecon
During the use of device, personal data will be collected, stored and processed. To protect data,
the development of Hikvision devices incorporates privacy by design principles. For example, for
device with facial recognion features, biometrics data is stored in your device with encrypon
method; for ngerprint device, only ngerprint template will be saved, which is impossible to
reconstruct a ngerprint image.
As data controller, you are advised to collect, store, process and transfer data in accordance with
the applicable data protecon laws and regulaons, including without limitaon, conducng
security controls to safeguard personal data, such as, implemenng reasonable administrave and
physical security controls, conduct periodic reviews and assessments of the eecveness of your
security controls.
DS-K3B631TX Series Swing Barrier User Manual
ii

Regulatory Informaon
FCC Informaon
Please take aenon that changes or modicaon not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protecon against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instrucon manual, may cause harmful
interference to radio communicaons. Operaon of this equipment in a residenal area is likely to
cause harmful interference in which case the user will be required to correct the interference at his
own expense.
FCC Condions
This device complies with part 15 of the FCC Rules. Operaon is subject to the following two
condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operaon.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE"
and comply therefore with the applicable harmonized European standards listed
under the EMC Direcve 2014/30/EU, RE Direcve 2014/53/EU,the RoHS Direcve
2011/65/EU
2012/19/EU (WEEE direcve): Products marked with this symbol cannot be disposed
of as unsorted municipal waste in the European Union. For proper recycling, return
this product to your local supplier upon the purchase of equivalent new equipment,
or dispose of it at designated collecon points. For more informaon see:
www.recyclethis.info
2006/66/EC (baery direcve): This product contains a baery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentaon for specic baery informaon. The baery is marked with this
symbol, which may include leering to indicate cadmium (Cd), lead (Pb), or mercury
(Hg). For proper recycling, return the baery to your supplier or to a designated
collecon point. For more informaon see:www.recyclethis.info
DS-K3B631TX Series Swing Barrier User Manual
iii

This device complies with Industry Canada licence-exempt RSS standard(s). Operaon is subject to
the following two condions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired
operaon of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radioexempts de licence. L'exploitaon est autorisée aux deux condions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'ulisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est suscepble d'en compromere le fonconnement.
COMPLIANCE NOTICE
The thermal series products might be subject to export controls in various countries or regions,
including without limitaon, the United States, European Union, United Kingdom and/or other
member countries of the Wassenaar Arrangement. Please consult your professional legal or
compliance expert or local government authories for any necessary export license requirements if
you intend to transfer, export, re-export the thermal series products between dierent countries.
DS-K3B631TX Series Swing Barrier User Manual
iv

Safety Instrucon
These instrucons are intended to ensure that user can use the product correctly to avoid danger
or property loss.
The precauon measure is divided into Dangers and Cauons:
Dangers: Neglecng any of the warnings may cause serious injury or death.
Cauons: Neglecng any of the cauons may cause injury or equipment damage.
Dangers: Follow these safeguards to prevent
serious injury or death.
Cauons: Follow these precauons to prevent
potenal injury or material damage.
Danger:
●In the use of the product, you must be in strict compliance with the electrical safety regulaons
of the naon and region.
●The equipment must be connected to an earthed mains socket-outlet.
●Shock hazard! Disconnect all power sources before maintenance.
●Do not touch the bare metal contacts of the inlets aer the circuit breaker is turned o.
Electricity sll exists.
● indicates hazardous live and the external wiring connected to the terminals requires
installaon by an instructed person.
●Keep body parts away from fan blades. Disconnect the power source during servicing.
●Keep body parts away from motors. Disconnect the power source during servicing.
●To prevent possible hearing damage, do not listen at high volume levels for long periods.
●All the electronic operaon should be strictly compliance with the electrical safety regulaons,
re prevenon regulaons and other related regulaons in your local region.
●Do not connect several devices to one power adapter as adapter overload may cause over-heat
or re hazard.
●Please make sure that the power has been disconnected before you wire, install or dismantle the
device.
If the top caps should be open and the device should be powered on for maintenance, make
sure:
1. Power o the fan to prevent the operator from geng injured accidentally.
2. Do not touch bare high-voltage components.
3. Make sure the switch’s wiring sequence is correct aer maintenance.
●Please make sure that the power has been disconnected before you wire, install or dismantle the
device.
●When the product is installed on wall or ceiling, the device shall be rmly xed.
●If smoke, odors or noise rise from the device, turn o the power at once and unplug the power
cable, and then please contact the service center.
DS-K3B631TX Series Swing Barrier User Manual
v

●Do not ingest baery, Chemical Burn Hazard.
This product contains a coin/buon cell baery. If the coin/buon cell baery is swallowed, it
can cause severe internal burns in just 2 hours and can lead to death.
Keep new and used baeries away from children. If the baery compartment does not close
securely, stop using the product and keep it away from children. If you think baeries might have
been swallowed or placed inside any part of the body, seek immediate medical aenon.
●If the product does not work properly, please contact your dealer or the nearest service center.
Never aempt to disassemble the device yourself. (We shall not assume any responsibility for
problems caused by unauthorized repair or maintenance.)
Cauons:
●The equipment shall not be exposed to dripping or splashing and that no objects lled with
liquids, such as vases, shall be placed on the equipment.
●Ensure correct wiring of the terminals for connecon to an AC mains supply.
●The equipment has been designed, when required, modied for connecon to an IT power
distribuon system.
●+ idenes the posive terminal(s) of equipment which is used with, or generates direct current.
+ idenes the negave terminal(s) of equipment which is used with, or generates direct
current.
●No naked ame sources, such as lighted candles, should be placed on the equipment.
●This equipment is suitable for mounng on concrete or other non-combusble surface only.
●Install the equipment according to the instrucons in this manual.
●To prevent injury, this equipment must be securely aached to the oor/wall in accordance with
the installaon instrucons.
●Stainless steel may be corroded in some circumstances. You need to clean and care the device by
using the stainless steel cleaner. It is suggested to clean the device every month.
●Do not drop the device or subject it to physical shock, and do not expose it to high
electromagnesm radiaon. Avoid the equipment installaon on vibraons surface or places
subject to shock (ignorance can cause equipment damage).
●Do not place the device in extremely hot (refer to the specicaon of the device for the detailed
operang temperature), cold, dusty or damp locaons, and do not expose it to high
electromagnec radiaon.
●The device cover for indoor use shall be kept from rain and moisture.
●Exposing the equipment to direct sun light, low venlaon or heat source such as heater or
radiator is forbidden (ignorance can cause re danger).
●Do not aim the device at the sun or extra bright places. A blooming or smear may occur
otherwise (which is not a malfuncon however), and aecng the endurance of sensor at the
same me.
●Please use the provided glove when open up the device cover, avoid direct contact with the
device cover, because the acidic sweat of the ngers may erode the surface coang of the device
cover.
●Please use a so and dry cloth when clean inside and outside surfaces of the device cover, do
not use alkaline detergents.
DS-K3B631TX Series Swing Barrier User Manual
vi

●Please keep all wrappers aer unpack them for future use. In case of any failure occurred, you
need to return the device to the factory with the original wrapper. Transportaon without the
original wrapper may result in damage on the device and lead to addional costs.
●Improper use or replacement of the baery may result in hazard of explosion. Replace with the
same or equivalent type only. Dispose of used baeries according to the instrucons provided by
the baery manufacturer.
●Biometric recognion products are not 100% applicable to an-spoong environments. If you
require a higher security level, use mulple authencaon modes.
●Do not stay in the lane when the device is reboong.
●RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED
BATTERIES ACCORDING TO THE INSTRUCTIONS.
●SUITABLE FOR MOUNTING ON CONCRETE OR OTHER NON-COMBUSTIBLE SURFACE ONLY.
●The instrucons shall require connecon of the equipment protecve earthing conductor to the
installaon protecve earthing conductor.
DS-K3B631TX Series Swing Barrier User Manual
vii

Available Models
Product Name Model Descripon
Swing Barrier DS-K3B631TX-L Le Pedestal
DS-K3B631TX-M Middle Pedestal
DS-K3B631TX-R Right Pedestal
DS-K3B631TX Series Swing Barrier User Manual
viii

Contents
Chapter 1 Overview .................................................................................................................... 1
1.1 Introducon ........................................................................................................................... 1
1.2 Main Features ........................................................................................................................ 1
Chapter 2 Light Introducon ....................................................................................................... 3
2.1 Light Descripon .................................................................................................................... 3
2.2 Side Light Board DIP Switch Descripon ................................................................................ 4
Chapter 3 System Wiring ............................................................................................................ 8
Chapter 4 Installaon ............................................................................................................... 12
Chapter 5 General Wiring ......................................................................................................... 14
5.1 Components Introducon .................................................................................................... 14
5.2 Wiring .................................................................................................................................. 16
5.3 Terminal Descripon ............................................................................................................ 18
5.3.1 Main Lane Control Board Terminal Descripon .......................................................... 18
5.3.2 Sub Lane Control Board Terminal Descripon ............................................................ 18
5.3.3 Main Access Control Board Terminal Descripon ....................................................... 19
5.3.4 Sub Access Control Board Terminal Descripon ......................................................... 20
5.3.5 Main User Extended Interface Board .......................................................................... 22
5.3.6 Sub User Extended Interface Board ............................................................................ 25
5.3.7 User Core Board Terminal Descripon ........................................................................ 27
5.3.8 Card Reader Board Terminal Descripon .................................................................... 27
5.3.9 Arrow Light Board Terminal Descripon ..................................................................... 28
5.3.10 Upper IR Adapter Board Terminal Descripon .......................................................... 28
5.3.11 Lower IR Adapter Board Terminal Descripon .......................................................... 29
5.3.12 RS-485 Wiring ........................................................................................................... 29
5.3.13 RS-232 Wiring ........................................................................................................... 30
5.3.14 Wiegand Wiring ........................................................................................................ 30
DS-K3B631TX Series Swing Barrier User Manual
ix

5.3.15 Barrier Control Wiring ............................................................................................... 31
5.3.16 Alarm Output Wiring ................................................................................................. 31
5.3.17 Alarm Input Wiring ................................................................................................... 32
Chapter 6 Device Sengs ......................................................................................................... 34
6.1 Set Study Mode .................................................................................................................... 34
6.2 Pair Keyfob (Oponal) .......................................................................................................... 35
6.3 Inialize Device .................................................................................................................... 36
Chapter 7 Acvaon ................................................................................................................. 39
7.1 Acvate via Device ............................................................................................................... 39
7.2 Acvate via Web Browser .................................................................................................... 41
7.3 Acvate via SADP ................................................................................................................. 41
7.4 Acvate Device via iVMS-4200 Client Soware ................................................................... 43
Chapter 8 Quick Operaon ....................................................................................................... 44
8.1 Set Device Hotspot ............................................................................................................... 44
8.2 Acvate via Device ............................................................................................................... 45
8.3 Set Applicaon Mode .......................................................................................................... 47
8.4 Set Network Parameters ...................................................................................................... 49
8.5 Privacy Sengs .................................................................................................................... 50
8.6 Keyfob Sengs .................................................................................................................... 51
8.7 Set Administrator ................................................................................................................. 53
Chapter 9 Operaon via Web Browser ...................................................................................... 56
9.1 Login .................................................................................................................................... 56
9.2 Overview .............................................................................................................................. 56
9.3 Person Management ............................................................................................................ 58
9.4 Search Event ........................................................................................................................ 59
9.5 Device Management ............................................................................................................ 60
9.6 Conguraon ....................................................................................................................... 61
9.6.1 View Device Informaon ............................................................................................. 61
DS-K3B631TX Series Swing Barrier User Manual
x

9.6.2 Set Time ...................................................................................................................... 61
9.6.3 Set DST ........................................................................................................................ 62
9.6.4 Change Administrator's Password ............................................................................... 63
9.6.5 Online Users ................................................................................................................ 63
9.6.6 View Device Arming/Disarming Informaon .............................................................. 63
9.6.7 Network Sengs ......................................................................................................... 63
9.6.8 Set Video and Audio Parameters ................................................................................ 65
9.6.9 Set Image Parameters ................................................................................................. 67
9.6.10 Event Linkage ............................................................................................................ 68
9.6.11 Access Control Sengs ............................................................................................. 70
9.6.12 Turnsle .................................................................................................................... 75
9.6.13 Card Sengs ............................................................................................................. 80
9.6.14 Set Privacy Parameters .............................................................................................. 82
9.6.15 Set Biometric Parameters ......................................................................................... 83
9.6.16 Set Screen Display ..................................................................................................... 86
9.6.17 Noce Publicaon ..................................................................................................... 87
9.6.18 Prompt Schedule ....................................................................................................... 87
9.6.19 Upgrade and Maintenance ....................................................................................... 89
9.6.20 Device Debugging ..................................................................................................... 90
9.6.21 Component Status .................................................................................................... 91
9.6.22 Log Query .................................................................................................................. 93
9.6.23 Cercate Management ........................................................................................... 94
Chapter 10 Congure the Device via the Mobile Browser ......................................................... 96
10.1 Login .................................................................................................................................. 96
10.2 Overview ............................................................................................................................ 96
10.3 Conguraon ..................................................................................................................... 97
10.3.1 Turnsle Basic Parameters ........................................................................................ 97
10.3.2 User Management .................................................................................................... 98
DS-K3B631TX Series Swing Barrier User Manual
xi

10.3.3 Keyfob Sengs ........................................................................................................ 100
10.3.4 Light Sengs ........................................................................................................... 101
10.3.5 Network Sengs ..................................................................................................... 105
10.3.6 Device Basic Sengs ............................................................................................... 108
10.3.7 Access Control Sengs ........................................................................................... 110
10.3.8 Face Parameters Sengs ........................................................................................ 118
10.3.9 View Device Informaon ......................................................................................... 122
10.3.10 Device Capacity ..................................................................................................... 122
10.3.11 Log Export ............................................................................................................. 122
10.3.12 Restore and Reboot .............................................................................................. 122
Chapter 11 Client Soware Conguraon ............................................................................... 123
11.1 Conguraon Flow of Client Soware ............................................................................. 123
11.2 Device Management ........................................................................................................ 124
11.2.1 Add Device .............................................................................................................. 124
11.2.2 Reset Device Password ........................................................................................... 126
11.2.3 Manage Added Devices .......................................................................................... 127
11.3 Group Management ......................................................................................................... 128
11.3.1 Add Group ............................................................................................................... 128
11.3.2 Import Resources to Group ..................................................................................... 128
11.4 Person Management ........................................................................................................ 129
11.4.1 Add Organizaon .................................................................................................... 129
11.4.2 Import and Export Person Idenfy Informaon ...................................................... 130
11.4.3 Get Person Informaon from Access Control Device .............................................. 132
11.4.4 Issue Cards to Persons in Batch ............................................................................... 133
11.4.5 Report Card Loss ..................................................................................................... 133
11.4.6 Set Card Issuing Parameters .................................................................................... 134
11.5 Congure Schedule and Template ................................................................................... 135
11.5.1 Add Holiday ............................................................................................................. 135
DS-K3B631TX Series Swing Barrier User Manual
xii

11.5.2 Add Template .......................................................................................................... 136
11.6 Set Access Group to Assign Access Authorizaon to Persons .......................................... 137
11.7 Congure Advanced Funcons ........................................................................................ 139
11.7.1 Congure Device Parameters .................................................................................. 140
11.7.2 Congure Other Parameters ................................................................................... 147
11.8 Door/Elevator Control ...................................................................................................... 149
11.8.1 Control Door Status ................................................................................................. 150
11.8.2 Check Real-Time Access Records ............................................................................ 151
Appendix A. Tips When Collecng/Comparing Face Picture .................................................... 153
Appendix B. DIP Switch ........................................................................................................... 154
B.1 DIP Switch Descripon ....................................................................................................... 154
B.2 DIP Switch Corresponded Funcons .................................................................................. 154
Appendix C. Event and Alarm Type ......................................................................................... 156
Appendix D. Error Code Descripon ........................................................................................ 157
Appendix E. Communicaon Matrix and Device Command ..................................................... 159
DS-K3B631TX Series Swing Barrier User Manual
xiii

Chapter 1 Overview
1.1 Introducon
Figure 1-1 Appearance
The ap barrier with two barriers and 20 IR lights is designed to detect unauthorized passing from
the entrance or exit. By adopng the ap barrier integratedly with the access control system,
person should authencate to pass through the lane via swiping IC or ID card, scanning QR code,
etc. It is widely used in aracons, stadiums, construcon sites, residences, etc.
1.2 Main Features
●32-bit high-speed processor
●IP address conict detecon
●Remote control and management
●Online/oine operaon
●Conguraon via local operaon, PC web and mobile web
●TCP/IP network communicaon
The communicaon data is specially encrypted to relieve the concern of privacy leak
●Person authencaon
●Permissions validaon and an-tailgang
●Control mode, inducve mode, remaining open/closed mode and free passing mode selectable
Bidireconal (Entering/Exing) lane
DS-K3B631TX Series Swing Barrier User Manual
1

The barrier opening and closing speed can be congured according to the visitor ow
●Single or mulple IR detector triggering
●Opens/Closes barrier according to the schedule template
●Cross controller an-passback
●The barrier will be locked or stop working when people are nipped
●An-forced-accessing
The barrier will be locked automacally without open-barrier signal. It can bear the force of up
to 120 Nm
●Self-detecon, Self-diagnoscs, and automac alarm
●Audible and visual alarm will be triggered when detecng intrusion, tailgang, reverse passing,
and climbing over barrier
●Barrier is in free status when powered down; If the device is installed with lithium baery
(oponal), the barrier remains open when powered down
●Fire alarm passing
When the re alarm is triggered, the barrier will be open automacally for emergency
evacuaon
●Valid passing duraon sengs
System will cancel the passing permission if a person does not pass through the lane within the
valid passing duraon
●Up to 10,0000 faces, up to 50,0000 cards and up to 100,000 events except can be added
●Custom broadcasng content
●LED indicates the entrance/exit and passing status
●White indicators for card and QR code authencaon;
Red and green arrow indicators;
Adjustable brightness and color of entrance light and side light
●IR emergency mode and Custom An-pinch for Door Closing
DS-K3B631TX Series Swing Barrier User Manual
2

Chapter 2 Light Introducon
Descripon of light and how to set light via DIP switch.
2.1 Light Descripon
Figure 2-1 Light Posion
Side Light
The side light indicates dierent status of the lane, including inducve, prohibited and
authencated passing.
Note
●When the device detects people within 1.5 m, the side light will be ashing.
●Only the right side light indicates the lane status.
●Light stays blue: inducve mode
●Light ashes green: authencated passing
●Light stays red: passing prohibited
DS-K3B631TX Series Swing Barrier User Manual
3

Barrier Light
The barrier light stays white by default. You can set the barrier light color at your needs.
The barrier light will not change color according to the lane status or authencaon results.
Card Reader Light
The card reader light will stay white when the device detects people approaching unl people pass
through.
Arrow Light
●The arrow light stays o when the device is on standby mode.
●The light on the right side will ash green ready for authencaon.
●The light on both le and right side will stay green for authencated passing.
●The light on the right side will ash red when authencaon fails.
Welcome Light
The welcome light stays white at the boom of the pedestal.
2.2 Side Light Board DIP Switch Descripon
Congure the DIP switch address of side light.
Figure 2-2 Side Light Board
DS-K3B631TX Series Swing Barrier User Manual
4

Table 2-1 Light Board DIP Switch Descripon
Posion Address Value (Start from Le)
0 65 0 0000
1 81 1 1000
2 97 10 0100
3 113 11 1100
4 129 100 0010
5 130 101 1010
6 131 110 0110
7 132 111 1110
8 133 1000 0001
9 134 1001 1001
10 135 1010 0101
11 136 1011 1101
12 137 1100 0011
13 138 1101 1011
14 139 1110 0111
15 140 1111 1111
DS-K3B631TX Series Swing Barrier User Manual
5

Figure 2-3 Side Light Posion
Single-Lane Scenario
In single-lane scenario, the side lights are located at the posion of NO. 1, 3, 4, 6. Side light No. 1 is
near the main user extended interface board.
Table 2-2 Single-Lane DIP Switch Descripon
Posion Address Value
No. 1 65 0000
No. 3 113 1100
No. 4 81 1000
No. 6 97 0100
Dual-Lane Scenario
Table 2-3 Dual-Lane DIP Switch Descripon
Posion Address Value
No. 1 65 0000
No. 2 65 0000
No. 3 113 1100
No. 4 81 1000
DS-K3B631TX Series Swing Barrier User Manual
6
