HIK VISION Wiegand DS-2CD4A26FWD-IZS/P-WG User manual

Wiegand Camera
Operation Manual

Wiegand Camera ·Operation Manual
1
Table of Contents
1 About This Manual.......................................................................................1
2 Cameras .......................................................................................................2
2.1 Available Models ...................................................................................................................... 2
2.2 Basic Parameters ...................................................................................................................... 2
2.3 Wiegand Interface Appearance................................................................................................ 3
3 Solutions ......................................................................................................4
3.1 Access Control Card No. ........................................................................................................... 4
3.1.1 Overview ........................................................................................................................... 4
3.1.2 Advantage.......................................................................................................................... 4
3.1.3 Software Version ............................................................................................................... 4
3.1.4 Applicable Wiegand Protocol ............................................................................................ 4
3.1.5 Card No. Encoding Mode................................................................................................... 4
3.1.6 Use Wiegand Protocol to Transfer Card No........................................................................ 4
3.2 Configure Parameters............................................................................................................... 5
3.2.1 Set Wiegand Type as CardID.............................................................................................. 5
3.2.2 Enable Vehicle Detection................................................................................................... 6
3.2.3 Configure Blacklist & Whitelist .......................................................................................... 6
3.3 Transfer Plate Number via Wiegand Interface........................................................................ 10
3.3.1 Overview ......................................................................................................................... 10
3.3.2 Advantage........................................................................................................................ 10
3.3.3 Applicable Wiegand Protocol .......................................................................................... 10
3.3.4 Plate Number Encoding Mode......................................................................................... 10
3.3.5 Configure Parameters...................................................................................................... 10
4 Appendix....................................................................................................11
4.1 Paxton Configuration.............................................................................................................. 11
4.1.1 Connect Net2 ACU........................................................................................................... 11
4.1.2 View ANPR Captured Image in Net2................................................................................ 13
4.2 FTP Server Creation ................................................................................................................ 15

Wiegand Camera ·Operation Manual
1
1About This Manual
This manual is about the Wiegand configuration and features of network cameras.
The manual is created as a guide for the technical support engineer, sales engineer, etc.

Wiegand Camera ·Operation Manual
2
2Cameras
2.1 Available Models
The available models of network cameras are:
DS-2CD4A26FWD-IZS/P-WG (2.8-12mm)
DS-2CD4A26FWD-IZS/P-WG (8-32mm)
DS-2CD4A26FWD-LZS/P-WG (2.8-12mm)
2.2 Basic Parameters
Image sensor
1/1.8"Progressive Scan CMOS
Max. resolution
1920 × 1080@ 60fps
Illumination
Ultra-low
Iris
Auto
WDR
120 dB
Protection level
IP 67
Supplement light
IR Light/White Light
ANPR technology
Supported

Wiegand Camera ·Operation Manual
3
2.3 Wiegand Interface Appearance
Figure 2-1 Wiegand Interface
Connection:
Connect the block’s D0, D1 and GND to those of receiving terminal accordingly.

Wiegand Camera ·Operation Manual
4
3Solutions
3.1 Access Control Card No.
3.1.1 Overview
Map the license plate number with the access control card number.
Find the related card number in black and white list, then transfer the card information
via Wiegand interface.
3.1.2 Advantage
1. Compatible with any standard access control system
2. Use camera as card-reader
3.1.3 Software Version
V5.4.5 build 171116 (Software may update, check with the R&D engineer)
3.1.4 Applicable Wiegand Protocol
26-bit Wiegand Protocol
3.1.5 Card No. Encoding Mode
Figure 3-1 Card No. Encoding Mode
3.1.6 Use Wiegand Protocol to Transfer Card No.
Even Parity
Bit
8-bit
（To express the site
code ID, if the site
code ID is less than 8
digits, 0 will be added
before the ID until it is
16-bit
（To express the card
ID, if the card ID is
less than 8 digits, 0
will be added before
the ID until it is
Odd
parity bit

Wiegand Camera ·Operation Manual
5
8-digit number.）
16-digit number.）
Here we take card number 12345 011 as example.
The coding process are show as below.
Split the card number as the card data (12345) and site data (011).
Convert 12345 to binary format, as: 0011000000111001.
Convert 011 to binary format, as: 00001011.
Site data and card data as: 00001011 0011000000111001
Bit 1 is an even parity bit for the following 8 bits (bit 2 to bit 9), as 1.
Bit 26 is an odd parity bit for the previous 16 bits (bit 10 to bit 25), as 1.
According to the converting mode(Even parity bit + site data + card data +
odd parity bit), you can get a binary code as: 1 00001011
0011000000111001 1.
3.2 Configure Parameters
3.2.1 Set Wiegand Type as CardID
Steps
1. Go to Configuration->Network->Basic setting->Wiegand.
2. Select the Wiegand Type as Card ID 26bit.

Wiegand Camera ·Operation Manual
6
Figure 3-2 Wiegand Configuration Interface
3.2.2 Enable Vehicle Detection
Steps:
1. Go to Configuration->Road Traffic->Detection Configuration.
2. Check the checkbox of Enable to enable Vehicle Detection.
3. Set the specific detection parameters.
Figure 3-3 Detection Configuration Interface
3.2.3 Configure Blacklist & Whitelist
Steps:
1. Go to Configuration->Road Traffic->Blacklist & Whitelist.
2. Click Export to download Blacklist & Whitelist template.
3. Fill in the template.

Wiegand Camera ·Operation Manual
7
Figure 3-4 Blacklist & Whitelist Excel Template
You can set at most 4096 license plates in whitelist and blacklist in total.
You should enter 8-digit Card ID in the ID row. Otherwise, unknown error may occur.
If you enter Card ID more than 8 digits, the last 8 digits will be kept. 989842118 in the
7th line will be saved as 89842118.
If you enter Card ID less than 8 digits, 0 will be added before the ID until it is 8-digit
number. For example, 9842119 in the 8th line will be saved as 09842119.
If you accidently enter the same plate number in the template, the bigger No. will take
effect.
Update Blacklist & Whitelist Manually
Steps:
1. Go to Configuration->Road Traffic-> Blacklist & Whitelist.
2. Click Browse to select the file you have finished.
3. Click Import to upload the list.
Figure 3-5 Blacklist & Whitelist Importing Interface
Auto Update via FTP
Steps:
1. Set a FTP address.
The Blacklist and Whitelist can be acquired via the FTP address to update the lists.
The update frequency can be set.

Wiegand Camera ·Operation Manual
8
The update frequency, update time, file name, etc. can be set. The
corresponding URL protocol are listed as follows.
When configuring the FTP parameters of the Blacklist & Whitelist via URL, the Blacklist
& Whitelist is off by default.
You can tell whether the configuration succeeds or not by checking the Last
Update and Upload Info.
http://10.5.148.102/ISAPI/System/Network/ftpUploadTimeUrl?enable=1&cycle=1&cust
omDay=2&hour=0&name=test.xls
Key Parameters Description:
10.5.148.102: replace it for the IP address of the device
enable: enable the update for Blacklist &Whitelist. 0 stands for Close, 1
stands for Enable. The default status is 1.
cycle: 1 stands for daily update; 2 stands for weekly update; 3 stands for
customized update. The default cycle is 1.
customDay: when you set cycle as 3(customized), customDay represents
time interval (day). The default day is 1.
hour:it is the time to update. Only integral hour and the 24-hour system
are supported. The default time is 0.
name: it is the file name for Blacklist & Whitelist. The full name should be
kept, including .xls. Only English name and path are supported.

Wiegand Camera ·Operation Manual
9
Figure 3-6 Blacklist & Whitelist Interface
Last Update shows the latest update time.
Upload Info shows the rules to configure via FTP.
2. Configure FTP Server.
Steps:
1. Go to Configuration -> Network -> Advanced Settings -> FTP
2. Fill in the blanks based on the authority distributed by FTP Server.
3. Set the Directory Structure as Save in the root directory.
Figure 3-7 Network Advance Settings
3. Test
Adjust the device time of few seconds prior to the FTP auto update time. Then
the device can update the Blacklist & Whitelist.

Wiegand Camera ·Operation Manual
10
3.3 Transfer Plate Number via Wiegand Interface
3.3.1 Overview
Transfer the plate number via Wiegand interface, which is the private protocol.
3.3.2 Advantage
Compatible directly with PAXTON access control system (managed by NET2 platform).
3.3.3 Applicable Wiegand Protocol
26-bit Wiegand Protocol
3.3.4 Plate Number Encoding Mode
Figure 3-8 Wiegand Protocol Flow Chart
Example
Plate No.: 2180870
The 24 bit encoded by SHA1 mode is 0x54 0x52 0x22
Add parity bit based on 3.1.6 Use Wiegand Protocol to Transfer Card
No
Add parity bit to 26 bit both before and after the number based on 26
bit protocol
3.3.5 Configure Parameters
Set the Wiegand Type as Paxton.
Steps:
1. Go to >Network->Basic setting->Wiegand.
2. Select Wiegand Type as Paxton 26bit.
3. Click Save.
Plate Number
Add parity
bit
SHA1
Keep last
24bit
Send

Wiegand Camera ·Operation Manual
11
Figure 3-9 Settings Interface
4Appendix
4.1 Paxton Configuration
4.1.1 Connect Net2 ACU
Steps
1. The connections for the ANPR Camera and Reader port using a Belden reader
cable (as per Paxton specification) on the Net2 ACU are as follows:
Blue wire: D1 at ANPR –Clock/D1 on Net2 ACU Reader Port.
Yellow wire: D0 at ANPR –Data/D0 on Net2 ACU Reader Port.
Black wire: GND at ANPR –0v on Net2 ACU Reader Port.

Wiegand Camera ·Operation Manual
12
2. In the door settings for the ACU that will be connected to the ANPR camera, set
the door up as follows and apply:
3. In the user record, select the ‘Tokens’ tab and select ‘New Token’ to open the ‘Add
new token’ window:

Wiegand Camera ·Operation Manual
13
4. Select Vehicle number plate and enter the license plate number you wish to add
for the user; e.g. BR07 UMM
5. Click OK then Apply.
6. As the license plate is read by the ANPR camera, it will send the converted token
number to the Net2 ACU.
4.1.2 View ANPR Captured Image in Net2
Hikvision has a second integration with Net2 that allows users to view DVR/NVR video
from within the Net2 UI. This integration can be used in conjunction with the ANPR
camera to show the capture of the licence plate as it is read by the camera.
Steps
1. Download the plugin from here: ftp://Hik_Paxton:Paxton_Hi[email protected]om
2. Once installed, in Net2 go to Options>Camera Integration>Add, and select
Hikvision DVR System from the list of camera servers.

Wiegand Camera ·Operation Manual
14
3. Add the DVR credentials to authenticate and detect the associated cameras:
4. Click OK, then go to the ACU that is associated with the ANPR camera and select it
as the camera that is monitoring the door.

Wiegand Camera ·Operation Manual
15
5. As the ANPR camera generates events in Net2, a camera icon will appear next to
the event. Clicking the icon will show the video associated with the ANPR event.
4.2 FTP Server Creation
Steps
1. Use FTP server tool to create the FTP server in your PC.
2. Set the permission information like user name and password in the server.
3. Set the path for the communication between the terminal and the server.
4. Keep the software turned on.
5. Put the blacklist and whitelist to be updated in the appointed directory in the
server.
