HIK VISION DS-7108NI User manual

User Manual of WIFI Network Video Recorder
1
Network Video Recorder
User Manual
UD.6L0202D1984A01

User Manual of WIFI Network Video Recorder
1
Quick Start Guide
COPYRIGHT ©2015 Hangzhou Hikvision Digital Technology Co., Ltd.
ALL RIGHTS RESERVED.
Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou
Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user
manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed,
partially or wholly, by any means, without the prior written permission of Hikvision. Unless otherwise stipulated,
Hikvision does not make any warranties, guarantees or representations, express or implied, regarding to the
Manual.
About this Manual
This Manual is applicable to WIFI NVR (Network Video Recorder).
The Manual includes instructions for using and managing the product. Pictures, charts, images and all other
information hereinafter are for description and explanation only. The information contained in the Manual is
subject to change, without notice, due to firmware updates or other reasons. Please find the latest version in the
company website (http://overseas.hikvision.com/en/).
Please use this user manual under the guidance of professionals.
Trademarks Acknowledgement
and other Hikvision’s trademarks and logos are the properties of Hikvision in various
jurisdictions. Other trademarks and logos mentioned below are the properties of their respective owners.
Legal Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE PRODUCT DESCRIBED, WITH
ITS HARDWARE, SOFTWARE AND FIRMWARE, IS PROVIDED “AS IS”, WITH ALL FAULTS AND
ERRORS, AND HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT
LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR
PURPOSE, AND NON-INFRINGEMENT OF THIRD PARTY. IN NO EVENT WILL HIKVISION, ITS
DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE TO YOU FOR ANY SPECIAL,
CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS,
DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR
DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE
WHOLLY AT YOUR OWN RISKS. HIKVISION SHALL NOT TAKE ANY RESPONSIBILITES FOR
ABNORMAL OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER
ATTACK, HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET SECURITY RISKS;
HOWEVER, HIKVISION WILL PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED.
SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR
JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS
THE APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS
USED WITH ILLEGITIMATE PURPOSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE
LATER PREVAILS.

User Manual of WIFI Network Video Recorder
2
Regulatory information
FCC information
FCC compliance: Please take attention that changes or modification not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
Note: This product has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This product generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this product does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
This equipment should be installed and operated with a minimum distance 20cm between the radiator and your
body.
FCC conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE" and comply
therefore with the applicable harmonized European standards listed under the Low Voltage Directive
2006/95/EC, the R&TTE Directive 1999/5/EC, the RoHS Directive 2011/65/EU.
2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper recycling, return this product to your local
supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection
points. For more information see: www.recyclethis.info.
2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted
municipal waste in the European Union. See the product documentation for specific battery
information. The battery is marked with this symbol, which may include lettering to indicate cadmium
(Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a
designated collection point. For more information see: www.recyclethis.info.
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following
two conditions:
1) this device may not cause interference, and
2) this device must accept any interference, including interference that may cause undesired operation of the
device.

User Manual of WIFI Network Video Recorder
3
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radioexempts de licence.
L'exploitation est autorisée aux deux conditions suivantes :
1) l'appareil ne doit pas produire de brouillage, et
2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and
maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference
to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power
(e.i.r.p.) is not more than that necessary for successful communication.
Conformément àla réglementation d'Industrie Canada, le présent émetteur radio peut
fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvépour l'émetteur par Industrie
Canada. Dans le but de réduire les risques de brouillage radioélectrique àl'intention des autres utilisateurs, il faut
choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse
pas l'intensiténécessaire àl'établissement d'une communication satisfaisante.

User Manual of WIFI Network Video Recorder
4
Preventive and Cautionary Tips
Before connecting and operating your device, please be advised of the following tips:
•Ensure unit is installed in a well-ventilated, dust-free environment.
•Unit is designed for indoor use only.
•Keep all liquids away from the device.
•Ensure environmental conditions meet factory specifications.
•Ensure unit is properly secured to a rack or shelf. Major shocks or jolts to the unit as a result of dropping it
may cause damage to the sensitive electronics within the unit.
•Use the device in conjunction with an UPS if possible.
•Power down the unit before connecting and disconnecting accessories and peripherals.
•A factory recommended HDD should be used for this device.
Table 1. 1 Recommended HDDs
Manufacturer
Type
Capacity
Seagate
WD5000LUCT
500G
Seagate
WD10JUCT
1T
Toshiba
MQ01ABD050V
500G
Toshiba
MQ01ABD100V
1T
•Improper use or replacement of the battery may result in hazard of explosion. Replace with the same or
equivalent type only. Dispose of used batteries according to the instructions provided by the manufacturer.

User Manual of WIFI Network Video Recorder
5
Product Key Features
General
Connectable to network cameras, network dome and encoders.
Connectable to the third-party network cameras like ACTI, Arecont, AXIS, Bosch, Brickcom, Canon,
PANASONIC, Pelco, SAMSUNG, SANYO, SONY, Vivotek and ZAVIO, and cameras that adopt ONVIF
or PSIA protocol.
Connectable to the smart IP cameras.
Each channel supports dual-stream.
Up to 8 network cameras can be connected.
Independent configuration for each channel, including resolution, frame rate, bit rate, image quality, etc.
The quality of the input and output record is configurable.
Local Monitoring
Support HDMITM output.
HDMITM output at up to 1920×1080 resolution.
Multiple screen display in live view is supported, and the display sequence of channels is adjustable.
Live view screen can be switched in group, and manual switch and automatic switch live view are also
provided, and the interval of automatic switch can be adjusted.
Quick setting menu is provided for live view.
Motion detection, video tampering, VCA (Video Content Analysis) alarm, video exception alert and video
loss alert functions.
Privacy mask.
Multiple PTZ protocols supported; PTZ preset, patrol and pattern.
Zooming in by clicking the mouse and PTZ tracing by dragging mouse.
HDD Management
Two kinds of HDD capacity are selectable: 500G and 1T.
Support S.M.A.R.T. and bad sector detection.
HDD quota management; different capacity can be assigned to different channel.
Recording and Playback
Holiday recording schedule configuration.
Continuous and event video recording parameters.
Multiple recording types: manual, continuous, alarm, motion, motion | alarm, motion & alarm, and VCA.
8 recording time periods with separated recording types each day.
Pre-record and post-record for alarm, motion detection for recording, and pre-record time for schedule and
manual recording.
Searching record files by events (alarm input/motion detection/VCA).
Tag adding for record files, searching and playing back by tags.
Locking and unlocking record files.
Provide a playback interface with easy and flexible operation.
Searching and playing back record files by camera No., recording type, start time, end time, etc.
Smart search for the selected area in the video.
Zooming in when playback.
Reverse playback of multi-channel.
Supports pause, play reverse, speed up, speed down, skip forward, and skip backward when playback, and
locating by dragging the mouse.
Up to 8-ch synchronous playback.

User Manual of WIFI Network Video Recorder
6
Backup
Export video data by USB device.
Export video clips when playback.
Management and maintenance of backup devices.
Alarm and Exception
Configurable arming time of alarm input/output.
Alarm for video loss, motion detection, VCA, video tampering, HDD full, HDD error, network
disconnected, IP confliction, illegal login and abnormal record.
Alarm triggers full screen monitoring, audible warning, notifying surveillance center, sending email and
alarm output.
Manually restore default when system is abnormal.
Other Local Functions
Operable by mouse.
Three-level user management; admin user is allowed to create many operating accounts and define their
operating permission, which includes the limit to access any channel.
Operation, alarm, exceptions and log recording and searching.
Manually triggering and clearing alarms.
Import and export of device configuration information.
Network Functions
1 self-adaptive 10M/100M network interfaces is provided.
IPv6 is supported.
TCP/IP protocol, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, and iSCSI are supported.
TCP, UDP and RTP for unicast.
Auto/Manual port mapping by UPnPTM.
Extranet access by HiDDNS and EZVIZ Cloud P2P.
Remote reverse playback via RTSP.
Support accessing by the platform via ONVIF.
Remote search, playback, download, locking and unlocking of the record files, and the breakpoint resume
is supported for downloading files.
Remote parameters setup; remote import/export of device parameters.
Remote view of the device status, system logs and alarm status.
Remote HDD formatting and program upgrading.
Remote system restart and shutdown.
Alarm and exception information can be sent to the remote host
Remotely start/stop recording.
Remotely start/stop alarm output.
Remote PTZ control.
Voice broadcasting.
Embedded WEB server.
Development Scalability:
SDK for Windows and Linux system.
Source code of application software for demo.
Development support and training for application system.

User Manual of WIFI Network Video Recorder
7
TABLE OF CONTENTS
Product Key Features......................................................................................................................................5
Chapter 1 Introduction........................................................................................................................ 11
1.1 Front Panel and Rear Panel ...........................................................................................................12
1.2 USB Mouse Operation ..................................................................................................................13
1.3 Input Method Description..............................................................................................................14
Chapter 2 Getting Started ...................................................................................................................15
2.1 Starting Up and Shutting Down the NVR......................................................................................16
2.2 Setting Admin Password................................................................................................................17
2.3 Using the Wizard for Basic Configuration.....................................................................................18
2.4 Adding and Connecting the IP Cameras........................................................................................23
2.4.1 Activating the IP Camera..................................................................................................23
2.4.2 Adding the Online IP Cameras .........................................................................................24
2.4.3 Editing Connected IP Cameras and Customized Protocols...............................................28
Chapter 3 Live View.............................................................................................................................31
3.1 Introduction of Live View .............................................................................................................32
3.2 Operations in Live View Mode......................................................................................................33
3.2.1 Using the Mouse in Live View .........................................................................................33
3.2.2 Quick Setting Toolbar in Live View Mode .......................................................................34
3.3 Adjusting Live View Settings........................................................................................................37
Chapter 4 PTZ Controls......................................................................................................................39
4.1 Configuring PTZ Settings..............................................................................................................40
4.2 PTZ Control Panel.........................................................................................................................42
4.3 Setting PTZ Presets, Patrols & Patterns.........................................................................................43
4.3.1 Customizing Presets..........................................................................................................43
4.3.2 Calling Presets ..................................................................................................................43
4.3.3 Customizing Patrols..........................................................................................................44
4.3.4 Calling Patrols ..................................................................................................................45
4.3.5 Customizing Patterns........................................................................................................46
4.3.6 Calling Patterns.................................................................................................................46
4.3.7 Customizing Linear Scan Limit........................................................................................47
4.3.8 Calling Linear Scan ..........................................................................................................48
4.3.9 One-touch Park.................................................................................................................48
Chapter 5 Recording Settings..............................................................................................................50
5.1 Configuring Parameters.................................................................................................................51
5.2 Configuring Recording Schedule ..................................................................................................53
5.3 Configuring Motion Detection Recording.....................................................................................56
5.4 Configuring Alarm Triggered Recording.......................................................................................58
5.5 Configuring VCA Event Recording...............................................................................................60
5.6 Manual Recording.........................................................................................................................62
5.7 Configuring Holiday Recording ....................................................................................................63
5.8 Files Protection..............................................................................................................................64
Chapter 6 Playback..............................................................................................................................66

User Manual of WIFI Network Video Recorder
8
6.1 Playing Back Record Files ............................................................................................................67
6.1.1 Playing Back by Channel..................................................................................................67
6.1.2 Playing Back by Time.......................................................................................................69
6.1.3 Playing Back by Event Search..........................................................................................69
6.1.4 Playing Back by Tag.........................................................................................................71
6.1.5 Smart Playback.................................................................................................................73
6.1.6 Playing Back by System Logs ..........................................................................................75
6.1.7 Playing Back External File ...............................................................................................76
6.2 Auxiliary Functions of Playback ...................................................................................................78
6.2.8 Playing Back Frame by Frame..........................................................................................78
6.2.9 Digital Zoom.....................................................................................................................78
6.2.10 Reverse Playback of Multi-channel..................................................................................78
Chapter 7 Backup ................................................................................................................................80
7.1 Backing up Record Files ...............................................................................................................81
7.1.1 Quick Export.....................................................................................................................81
7.1.2 Backing up by Normal Video Search................................................................................82
7.1.3 Backing up by Event Search.............................................................................................86
7.1.4 Backing up Video Clips ....................................................................................................87
7.2 Managing Backup Devices............................................................................................................89
Chapter 8 Alarm Settings....................................................................................................................92
8.1 Setting Motion Detection Alarm....................................................................................................93
8.2 Setting Sensor Alarms ...................................................................................................................95
8.3 Detecting Video Loss Alarm..........................................................................................................98
8.4 Detecting Video Tampering Alarm..............................................................................................100
8.5 Handling Exceptions Alarm.........................................................................................................102
8.6 Setting Event Hint Display..........................................................................................................105
8.7 Triggering or Clearing Alarm Output Manually..........................................................................106
Chapter 9 VCA Alarm.......................................................................................................................107
9.1 Face Detection.............................................................................................................................108
9.2 Vehicle Detection ........................................................................................................................109
9.3 Line Crossing Detection.............................................................................................................. 111
9.4 Intrusion Detection...................................................................................................................... 113
9.5 Region Entrance Detection.......................................................................................................... 115
9.6 Region Exiting Detection ............................................................................................................ 116
9.7 Loitering Detection...................................................................................................................... 116
9.8 People Gathering Detection......................................................................................................... 116
9.9 Fast Moving Detection ................................................................................................................ 116
9.10 Parking Detection........................................................................................................................ 117
9.11 Unattended Baggage Detection ................................................................................................... 117
9.12 Object Removal Detection........................................................................................................... 117
9.13 Audio Exception Detection ......................................................................................................... 118
9.14 Sudden Scene Change Detection................................................................................................. 119
9.15 Defocus Detection....................................................................................................................... 119
9.16 PIR Alarm ................................................................................................................................... 119

User Manual of WIFI Network Video Recorder
9
Chapter 10 VCA Search ......................................................................................................................120
10.1 Face Search .................................................................................................................................121
10.2 Behavior Search ..........................................................................................................................123
10.3 Plate Search.................................................................................................................................124
10.4 People Counting..........................................................................................................................125
10.5 Heat Map.....................................................................................................................................127
Chapter 11 Network Settings ..............................................................................................................128
11.1 Configuring General Settings......................................................................................................129
11.2 Configuring Advanced Settings...................................................................................................130
11.2.1 Configuring Wireless Network .......................................................................................130
11.2.2 Configuring EZVIZ Cloud P2P ......................................................................................131
11.2.3 Configuring DDNS.........................................................................................................132
11.2.4 Configuring NTP Server.................................................................................................136
11.2.5 Configuring SNMP.........................................................................................................137
11.2.6 Configuring Remote Alarm Host....................................................................................137
11.2.7 Configuring Multicast.....................................................................................................138
11.2.8 Configuring RTSP ..........................................................................................................138
11.2.9 Configuring Server and HTTP Ports...............................................................................139
11.2.10 Configuring Email ..........................................................................................................139
11.2.11 Configuring NAT............................................................................................................141
11.3 Checking Network Traffic...........................................................................................................144
11.4 Configuring Network Detection..................................................................................................145
11.4.1 Testing Network Delay and Packet Loss.........................................................................145
11.4.2 Exporting Network Packet..............................................................................................145
11.4.3 Checking the Network Status..........................................................................................146
11.4.4 Checking Network Statistics...........................................................................................147
Chapter 12 HDD Management............................................................................................................149
12.1 Initializing HDD..........................................................................................................................150
12.2 Configuring Quota Mode.............................................................................................................152
12.3 Checking HDD Status .................................................................................................................153
12.4 HDD Detection............................................................................................................................154
12.5 Configuring HDD Error Alarms..................................................................................................156
Chapter 13 Camera Settings ...............................................................................................................157
13.1 Configuring OSD Settings...........................................................................................................158
13.2 Configuring Privacy Mask...........................................................................................................159
13.3 Configuring Video Parameters ....................................................................................................160
Chapter 14 NVR Management and Maintenance .............................................................................161
14.1 Viewing System Information.......................................................................................................162
14.1.1 Viewing Device Information...........................................................................................162
14.2 Searching & Export Log Files.....................................................................................................163
14.3 Importing/Exporting IP Camera Info...........................................................................................166
14.4 Importing/Exporting Configuration Files....................................................................................167
14.5 Upgrading System.......................................................................................................................168
14.5.1 Upgrading by Local Backup Device...............................................................................168

User Manual of WIFI Network Video Recorder
10
14.5.2 Upgrading by FTP ..........................................................................................................168
14.6 Restoring Default Settings...........................................................................................................170
Chapter 15 Others................................................................................................................................171
15.1 Configuring General Settings......................................................................................................172
15.2 Configuring DST Settings ...........................................................................................................173
15.3 Configuring More Settings for NVR ...........................................................................................174
15.4 Managing User Accounts.............................................................................................................175
15.4.1 Adding a User.................................................................................................................175
15.4.2 Deleting a User...............................................................................................................177
15.4.3 Editing a User.................................................................................................................178
Chapter 16 Appendix...........................................................................................................................180
16.1 Glossary.......................................................................................................................................181
16.2 Troubleshooting...........................................................................................................................182
16.3 Summary of Changes ..................................................................................................................188
16.4 List of Compatible IP Cameras....................................................................................................190
List of Hikvision IP Cameras ......................................................................................................190
List of Third-party IP Cameras ..................................................................................................191

User Manual of WIFI Network Video Recorder
11
Chapter 1 Introduction

User Manual of WIFI Network Video Recorder
12
1.1 Front Panel and Rear Panel
Figure 1. 1 Front Panel
Figure 1. 2 Rear Panel
Table 1. 1 Description of Rear Panel Interface
No.
Name
Description
1
LAN Interface (1 ~ 3)
3 RJ-45 10 /100Mbps network interfaces for LAN (Local Area
Networks).
2
WAN Interface
1 RJ-45 10 /100 Mbps network interface for WAN (Wide Area
Networks).
3
USB Interface
Universal Serial Bus (USB) ports for additional devices such as USB
mouse and USB writer.
4
HDMI
HDMI video output connector.
5
POWER
12VDC Power supply.

User Manual of WIFI Network Video Recorder
13
1.2 USB Mouse Operation
A regular 3-button (Left/Right/Scroll-wheel) USB mouse can also be used with this NVR. To use a USB mouse:
1. Plug USB mouse into the USB interface on the rear panel of the NVR.
2. The mouse should automatically be detected. If in a rare case that the mouse is not detected, the possible
reason may be that the two devices are not compatible, please refer to the recommended the device list from
your provider.
The operation of the mouse:
Table 1. 2 Description of the Mouse Control
Name
Action
Description
Left-Click
Single-Click
Live view: Select channel and show the quick set menu.
Menu: Select and enter.
Double-Click
Live view: Switch between single-screen and multi-screen.
Click and Drag
PTZ control: pan, tilt and zoom.
Video tampering, privacy mask and motion detection: Select target area.
Digital zoom-in: Drag and select target area.
Live view: Drag channel/time bar.
Right-Click
Single-Click
Live view: Show menu.
Menu: Exit current menu to upper level menu.
Scroll-Wheel
Scrolling up
Live view: Previous screen.
Menu: Previous item.
Scrolling down
Live view: Next screen.
Menu: Next item.

User Manual of WIFI Network Video Recorder
14
1.3 Input Method Description
Figure 1. 3 Soft Keyboard (1)
Figure 1. 4 Soft Keyboard (2)
Description of the buttons on the soft keyboard:
Table 1. 3 Description of the Soft Keyboard Icons
Figure 1. 5
Icon
Description
Icon
Description
~
Number
~
English letter
Lowercase/Uppercase
Backspace
Switch the keyboard
Space
Positioning the cursor
Exit
Symbols
Reserved

User Manual of WIFI Network Video Recorder
15
Chapter 2 Getting Started

User Manual of WIFI Network Video Recorder
16
2.1 Starting Up and Shutting Down the NVR
Purpose:
Proper startup and shutdown procedures are crucial to expanding the life of the NVR.
Before you start:
1. Establish the connection between the NVR and Internet via the WAN interface.
2. Check that the voltage of the extra power supply is the same with the NVR’s requirement, and the ground
connection is working properly.
Starting up the NVR:
Step:
Check the power supply is plugged into an electrical outlet. It is HIGHLY recommended that an Uninterruptible
Power Supply (UPS) be used in conjunction with the device.
During the starting up program, a splash screen appears on the monitor.
Shutting down the NVR
Steps:
1. Enter the Shutdown menu.
Menu > Shutdown
Figure 2. 1 Shutdown Menu
2. Click the Shutdown button.
3. Click the Yes button.
4. Unplug the power supply when the attention pops up.
Figure 2. 2 Shutdown Attention
Rebooting the NVR
In the Shutdown menu, you can also reboot the NVR.
Steps:
1. Enter the Shutdown menu by clicking Menu > Shutdown.
2. Click the Logout button to lock the NVR or the Reboot button to reboot the NVR.

User Manual of WIFI Network Video Recorder
17
2.2 Setting Admin Password
Purpose:
For the first-time access, you need to activate the device by setting an admin password. No operation is allowed
before activation.
Steps:
1. Input the same password in the text field of Create New Password and Confirm New Password.
Figure 2. 3 Settings Admin Password
STRONG PASSWORD RECOMMENDED–We highly recommend you create a strong
password of your own choosing (using a minimum of 8 characters, including upper case letters,
lower case letters, numbers, and special characters) in order to increase the security of your
product. And we recommend you reset your password regularly, especially in the high security
system, resetting the password monthly or weekly can better protect your product.
2. Click OK to save the password and activate the device.
For the old version device, if you update it to the new version, the following dialog box will pop up once the
device starts up. You can click YES and follow the wizard to set a strong password.
Figure 2. 4 Warning

User Manual of WIFI Network Video Recorder
18
2.3 Using the Wizard for Basic Configuration
Purpose:
After admin password is set, the setup wizard pops up automatically. It can walk you through some basic settings
of the NVR.
Figure 2. 5 Start Wizard Interface
Steps:
1. If you don’t want to use the setup wizard at that moment, click the Exit button. You can also choose to use
the Setup Wizard next time by leaving the “Start wizard when the device starts?” checkbox checked.
2. Click the Next button to enter the Date and Time Settings interface.
Figure 2. 6 Date and Time Settings
3. After the time settings, click Next button which takes you to the WAN Setup Wizard window.

User Manual of WIFI Network Video Recorder
19
Figure 2. 7 WAN Settings
4. Select the Connection Mode as PPPoE and input Account and Password.
5. Click Next button to enter WIFI settings interface.
Figure 2. 8 WIFI Settings
6. Edit SSID and select Security Type. Input Network Security Key if Security Type does not set as Disable.
7. Click Next button which takes you to the General Network Configuration window.
