1.Key Features
System function:
z1/4’’ SONY high performance CCD
zHigh-precision motor with sensitive response and reliable movement. Precision
bias less than 0.1°.No vibration under any selected speed
zAuto adaptive to HIKVISION, Pelco-P/D protocol in RS-485 control mode
z3D intelligent positioning function. Through software or DVR, it can realize
tracking and enlarging
zOSD menu in multiple languages and operation hint capability
zPower-off protection of setup parameters
zPower-off memory function: restore PTZ & Lens status after reboot
zBuilt-in temperature sensor designed, with display of internal temperature
zLightning protection, surge protection and voltage transient protection
capabilities
zOutdoor dome meets IP66 standard
zRS-485 connection failure diagnosis capability, with failure information, e.g.,
wrong address, baud rate errors, et., displayed on the video screen in text
zManchester code and connection failures diagnosis capability, with failure
information, e.g., wrong address, baud rate errors s displayed on the video
screen in special characters
zScheduled enabling of preset /patrol / pattern / pan scan / tilt scan / random scan
/ frame scan / panorama scan
zPassword protection to prevent unauthorized operation
zCamera title programmable, with display of Chinese/English characters on video
screen
zScanning within programmed zone without need of receiving control command;
display zone title
Camera function:
zAuto iris, auto focus, auto white balance, backlight compensation and
auto/manual day & night switch, and WDR function option
z24 privacy masks programmable, with location and size adjustable; a maximum
of 8 zones can be masked simultaneously on the same video screen(depending
on different camera models)
PTZ function:
z360° endless pan range and -5°-90° tilt range; auto flip capability
zMax. pan preset speed of 400°/s and max. tilt preset speed of 200°/s
zManual pan speed of 0.3°~160°/220°/300°/s and manual tilt speed of
0.3°~60°/75°/90°/s

Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
5
z256 presets programmable; preset image freezing capability
z8 patrols, each patrol up to 32 presets
z4 patterns, with the total recording time not less than 10 min
zProportional zoom function, with rotation speed adjusted automatically according
to zoom multiples
zPark action: auto callup of preset / patrol / pattern / pan scan / tilt scan / random
scan / frame scan / panorama scan, after a defined time of inactivity
z7 alarm inputs (priority configurable) and 2 alarm outputs, providing alarm
response actions of relay out/preset /patrol / pattern / pan scan / tilt scan /
random scan / frame scan / panorama scan

Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
6
2.Application

It can be widely used in wide range environments which required high-speed
monitoring, e.g. river, forest, highroad, railway, airport, port, oil field, sentry, piazza,
park, scenic zone, street, station, venue, and etc.

Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
7
3.Specifications

Model
DS‐2AF1‐611X
DS‐2AF1‐601X
DS‐2AF1‐613X
DS‐2AF1‐603X
DS‐2AF1‐615X
DS‐2AF1‐605X
DS‐2AF1‐617X
DS‐2AF1‐607X
ImageSensor1/4inchSONYEXVIEWCCD
EffectivePixel
PAL:752(H)×582(V)
NTSC:768(H)×494(V)
HorizontalResolution480TVL
480TVL(Color)
520TVL(B/W)
SignalSystemPAL/NTSC
Min.Illumination1.0Lux/F1.4
0.7Lux/F1.4(Color)
0.01Lux/F1.4(B/W)
1.0Lux/F1.4(Color)
0.01Lux/F1.4(B/W)
1.4Lux/F1.4(Color)
0.01Lux/F1.4(B/W)
WhiteBalanceAuto/Manual/ATW/Indoor/Outdoor
AGCAuto/Manual
S/NRatioMorethan50dB
BLC/WDRBLC(On/Off)
ElectronicShutter
PAL:1/50~1/10,000s
NTSC:1/60~1/10,000s
PAL:1/3~1/10,000s
NTSC:1/4~1/10,000s
Day&NightElectronicICR
DigitalZoom12x
PrivacyMask 24privacymasksprogrammable;amaximumof8zonescanbemaskedsimultaneously
onthesamevideoscreen
Camera
FocusModelAuto/Semiautomatic/Manual
FocalLength4.1‐73.8mm,18X3.5‐91mm,26X3.4‐122.4mm,36X
ZoomSpeedApprox.2.1s(OpticalWide‐Tele)Approx.4.0s(OpticalWide‐Tele)
AngleofView48‐2.8degree(Wide‐Tele)
48‐1.6degree(Wide‐Tel
e)
57.8‐1.7degree(Wide‐T
ele)
Min.WorkingDistance10‐800mm(Wide‐Tele)10‐1500mm(Wide‐Tele)
Lens
ApertureRangeF1.4‐F3.0F1.4‐F3.8F1.6‐F4.5
PanRange360°endless
PanSpeedPanManualSpeed:0.3°~160°/220°/300°/s,
PanPresetSpeed:400°/s
TiltRange‐5°~90°(AutoFlip)
TiltSpeedTiltManualSpeed:0.3°~60°/75°/90°/s,
TiltPresetSpeed:200°/s
Panand
Tilt
ProportionalZoomSupport

Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
8
NumberofPreset256
Patrol 8patrols,eachpatrolupto32presets
Pattern 4patterns,withthetotalrecordingtimenotlessthan10min
Power‐offMemorySupport
ParkActionPreset/Patrol/Pattern/Panscan/Tiltscan/Randomscan/Framescan/Panoramascan
PTZPositionDisplayOn/Off
FreezeFrame—Support
PasswordProtectionSupport
ZoneScanning/Display Support
CameraTitle Support
CompassSupport,thenorthcanbeset
ScheduledTaskPreset/Patrol/Pattern/Panscan/Tiltscan/Randomscan/Framescan/Panoramascan
RS‐485connection
failurediagnosis
Support
Manchestercodeand
connectionfailures
diagnosis
Support
AlarmInput7inputs,priorityconfigurable
AlarmOutput2relayoutputs,alarmresponseactionsoption
Alarm
AlarmAction
Preset/Patrol/Pattern/Panscan/Tiltscan/Randomscan/Framescan/Panoramascan/Relay
output
Input/
Output
MonitorOutput1.0V[p‐p]/75Ω,NTSC(orPAL)composite,BNC
MenuLanguageEnglish,Chinese
RS‐485ProtocolsHIKVISION,Pelco‐P,Pelco‐D(addible),self‐adaptive
PowerSupply24VAC(12VDCoption)
PowerConsumption15Wmax(30Wmaxwithheater,outdoordome)
WorkingTemperature/
Humidity
‐30℃~65℃(outdoor)/‐10℃~50℃(indoor)
90%orless
ProtectionLevel
IP66standard(outdoordome)
TVS3000Vlightningprotection,surgeprotectionandvoltagetransientprotection
MountingVariousmountingmodesoption
Dimension Φ243(mm)×287(mm)
Weight(approx.)5kg
General
MountOption
WallMount:DS‐1611ZJ(White);CornerMount:DS‐1632ZJ(White);
Indoorpendantmount:DS‐1651ZJ(White);CeilingMount:DS‐1642ZJ(White)

