HIK VISION DS-2CD4112F-I User guide

1
Camera
Network Dome Camera
Quick Operation Guide
UD.6L0201B1305A01

Network Dome Camera·Quick Operation Guide
1
1
Thank you for purchasing our product. If there are any questions, or
requests, please do not hesitate to contact the dealer.
About This Document
This manual applies to the following models.
Model
Model
DS-2CD4112F-(I)
DS-2CD4124F-(I)
DS-2CD4132F-(I)
DS-2CD4112FWD-(I)
DS-2CD4132FWD-(I)
iDS-2CD6124FWD-I/B
This manual may contain several technical incorrect places or
printing errors, and the content is subject to change without notice.
The updates will be added to the new version of this manual. We will
readily improve or update the products or procedures described in
the manual.
DISCLAIMER STATEMENT
“Underwriters Laboratories Inc. (“UL”) has not tested the
performance or reliability of the security or signaling aspects of this
product. UL has only tested for fire, shock or casualty hazards as
outlined in UL’s Standard(s) for Safety, UL60950-1. UL Certification
does not cover the performance or reliability of the security or
signaling aspects of this product. UL MAKES NO REPRESENTATIONS,
WARRANTIES OR CERTIFICATIONS WHATSOEVER REGARDING THE
PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING
RELATED FUNCTIONS OF THIS PRODUCT.
0501001031227

Network Dome Camera·Quick Operation Guide
2
2
Regulatory Information
FCC Information
FCC compliance: This equipment has been tested and found to
comply with the limits for a digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own
expense.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied
accessories too are marked with "CE" and comply
therefore with the applicable harmonized European
standards listed under the Low Voltage Directive 2006/95/EC, the
EMC Directive 2004/108/EC, the RoHS Directive 2011/65/EU.

Network Dome Camera·Quick Operation Guide
3
3
2012/19/EU (WEEE directive): Products marked
with this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment,
or dispose of it at designated collection points. For more information
see: www.recyclethis.info.
2006/66/EC (battery directive): This product
contains a battery that cannot be disposed of as
unsorted municipal waste in the European Union.
See the product documentation for specific battery
information. The battery is marked with this symbol,
which may include lettering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the battery to your
supplier or to a designated collection point. For more information
see: www.recyclethis.info

Network Dome Camera·Quick Operation Guide
4
4
Safety Instruction
These instructions are intended to ensure that user can use the
product correctly to avoid danger or property loss.
The precaution measure is divided into “Warnings” and “Cautions”
Warnings: Serious injury or death may occur if any of the warnings
are neglected.
Cautions: Injury or equipment damage may occur if any of the
cautions are neglected.
Warnings
●In the use of the product, you must be in strict compliance with
the electrical safety regulations of the nation and region. Please
refer to technical specifications for detailed information.
●Input voltage should meet both the SELV (Safety Extra Low
Voltage) and the Limited Power Source with 24 VAC or 12 VDC
according to the IEC60950-1 standard. Please refer to technical
specifications for detailed information.
Warnings Follow these
safeguards to prevent
serious injury or death.
Cautions Follow these
precautions to prevent
potential injury or material
damage.

Network Dome Camera·Quick Operation Guide
5
5
●Do not connect several devices to one power adapter as
adapter overload may cause over-heating or a fire hazard.
●Please make sure that the plug is firmly connected to the power
socket. When the product is mounted on wall or ceiling, the
device shall be firmly fixed.
●If smoke, odor or noise rise from the device, turn off the power
at once and unplug the power cable, and then please contact
the service center.
Cautions
●Make sure the power supply voltage is correct before using the
camera.
●Do not drop the camera or subject it to physical shock.
●Do not touch sensor modules with fingers. If cleaning is
necessary, use clean cloth with a bit of ethanol and wipe it
gently. If the camera will not be used for an extended period,
please replace the lens cap to protect the sensor from dirt.
●Do not aim the camera at the sun or extra bright places.
Blooming or smearing may occur otherwise (which is not a
malfunction), and affect the endurance of sensor at the same
time.
●The sensor may be burned out by a laser beam, so when any
laser equipment is in using, make sure that the surface of
sensor will not be exposed to the laser beam.

Network Dome Camera·Quick Operation Guide
6
6
●Do not place the camera in extremely hot, cold (the operating
temperature shall be-30℃~+60℃,or -40°C ~ 60°C if the camera
model has an “H” in its suffix), dusty or damp locations, and do
not expose it to high electromagnetic radiation.
●To avoid heat accumulation, good ventilation is required for
operating environment.
●Keep the camera away from liquid while in use.
●While in delivery, the camera shall be packed in its original
packing, or packing of the same texture.
●Regular part replacement: a few parts (e.g. electrolytic
capacitor) of the equipment shall be replaced regularly
according to their average enduring time. The average time
varies because of differences between operating environment
and using history, so regular checking is recommended for all
the users. Please contact with your dealer for more details.
●Improper use or replacement of the battery may result in
hazard of explosion. Replace with the same or equivalent type
only. Dispose of used batteries according to the instructions
provided by the battery manufacturer.
●If the product does not work properly, please contact your
dealer or the nearest service center. Never attempt to
disassemble the camera yourself. (We shall not assume any
responsibility for problems caused by unauthorized repair or
maintenance.)

Network Dome Camera·Quick Operation Guide
7
7
Table of Contents
1 Appearance Description ................................................................. 8
2 Installation.................................................................................... 11
3 Setting the Network Camera over the LAN .................................. 18
4 Accessing via Web Browser .......................................................... 24

Network Dome Camera·Quick Operation Guide
8
8
1Appearance Description
The overview of the dome camera is shown below:
Overview (1)Figure 1-1
The overview of the components and the interface are shown below:
Overview (2)Figure 1-2
The interfaces on the rear panel are shown below:
468
7
5
2
3

Network Dome Camera·Quick Operation Guide
9
9
Overview (3)Figure 1-3
Overview (4)Figure 1-4
10
9

Network Dome Camera·Quick Operation Guide
10
10
Description of Overview (2~3)Table 1-1
No.
Description
No.
Description
1
Black Liner
2
Bubble
3
Lens
4
BNC Interface
5
Reset
6
Status Indicator
7
Test Serial Port
8
Micro SD Card Slot
9
Adapter Plate
10
Side Outlet
Description of Overview (4)Table 1-2
No.
Description
LAN（PoE）
10M/100M Self-adaptive Ethernet Port(PoE
Supported)
AUDIO OUT/IN：
Audio Out/In
CVBS，GND
Auxiliary video output
1A，1B
Alarm Out
D+，D-
RS-485 Interface
IN，GND
Alarm In
DC12V
Power Supply Interface（12 VDC ）
Press RESET about 10s when the camera is powering on or rebooting
to restore the default settings, including the user name, password, IP
address, port No., etc.

Network Dome Camera·Quick Operation Guide
11
11
2Installation
Before you start:
Make sure the device in the package is in good condition and all
the assembly parts are included.
Make sure all the related equipment is power-off during the
installation.
Check the specification of the products for the installation
environment.
Make sure the power supply is matched with your required
voltage to avoid damage.
If the product does not function properly, please contact your
dealer or the nearest service center. Do not disassemble the
camera for repair or maintenance by yourself.
Make sure that the wall is strong enough to withstand three times
the weight of the camera.
For the camera that supports IR, you are required to pay attention to
the following precautions to prevent IR reflection:
●Dust or grease on the dome cover will cause IR reflection.
Please do not remove the dome cover film until the installation
is finished. If there is dust or grease on the dome cover, clean
the dome cover with clean soft cloth and isopropyl alcohol.

Network Dome Camera·Quick Operation Guide
12
12
●Make sure that there is no reflective surface too close to the
camera lens. The IR light from the camera may reflect back into
the lens causing reflection.
●The foam ring around the lens must be seated flush against the
inner surface of the bubble to isolate the lens from the IR LEDS.
Fasten the dome cover to camera body so that the foam ring
and the dome cover are attached seamlessly.
Steps:
1. Drill the screw holes and the cable hole according to the supplied
drill template.
Drill TemplateFigure 2-1
(Optional)Routing the cable from the side outlet instead of the
cable hole drilled on the ceiling is supported. Use a plier to
remove the part shown in the figure below, and you can route the
cables from the side outlet.
BOTTOM
Hole
2
2
1
1
1
1

Network Dome Camera·Quick Operation Guide
13
13
Side OutletFigure 2-2
2. Fix the adapter plate to the ceiling with the supplied screws.
Install the Adapter PlateFigure 2-3
Side Outlet

Network Dome Camera·Quick Operation Guide
14
14
3. Align the mounting base with the adapter plate and route the
mounting base anticlockwise to get it fitted with the adapter plate,
and then fix it by tightening the lock screw.
Install the Mounting BaseFigure 2-4
4. Adjust the surveillance angle according to the figure below.
Panning angle [0~80°], tilting angle [0~355°], and azimuth angle of
the lens [0~355°].
3-axis AdjustmentFigure 2-5
Lock
Screw
0~80°
0~355°
0~355°

Network Dome Camera·Quick Operation Guide
15
15
5. Adjust the focus and zoom.
1). Connect the VIDEO OUT interface of the camera to the
debugging monitor.
2). Set the iris type to MANUAL first.
3). Adjust the No.1 Zoom Lever (T~W) to select a proper angle of
view.
4). Adjust the NO.2 Focus Lever (F~N) to obtain a perfect image
on the monitor.
5). Set the iris type as MANUAL if the environment has a good
and stable illumination, and set the iris type as AUTO if the
environment has a strong and changeable illumination.
Adjust the LensFigure 2-6
For the cameras adopts electronic lens, you can adjust the zoom and
focus by visiting the device, and adjust it from the PTZ control
interface.
1
2

Network Dome Camera·Quick Operation Guide
16
16
Zoom and Focus Adjustment of Electronic LensFigure 2-7
6. Attach the black liner to the dome drive.
7. Attach the bubble to the dome drive and rotate it to get
tightened.
Install the Black Liner and BubbleFigure 2-8
8. Tighten the lock screw to complete the installation.
Black Liner
Dome Drive Bubble

Network Dome Camera·Quick Operation Guide
17
17
Complete the InstallationFigure 2-9

Network Dome Camera·Quick Operation Guide
18
18
3Setting the Network Camera over the
LAN
Purpose:
To view and configure the camera via LAN (Local Area Network), you
need to connect the network camera in the same subnet with your
PC. Then, install the SADP or PCNVR software to search and change
the IP of network camera.
The following figure shows the cable connection of network
camera and PC:
Wiring over LANFigure 3-1
Set the IP address of the camera for accessing via LAN.
Steps:
1. To get the IP address, you can choose either of the following
methods:
Use SADP, a software tool which can automatically detect
network camera in the LAN and list the device information like IP
address, subnet mask, port number, device serial number, device
version, etc., shown in Figure 3-2.

Network Dome Camera·Quick Operation Guide
19
19
Use PCNVR software and to list the online devices. Please refer
to the user manual of PCNVR client software for detailed
information.
2. Change the IP address and subnet mask to the same subnet as of
your PC.
Refer to the following introductions to set IP address with SADP
software:
Search active devices online
Search online devices automatically:
After launch the SADP software, it automatically searches the
online devices every 15 seconds from the subnet where your
computer locates. It displays the total number and
information of the searched devices in the Online Devices
interface. Device information including the device type, IP
address, port number, gateway, etc. will be displayed.
