DS-2CC51A7P(N)-VF (Under R&D)
Key Features
Compact design
SONY Super HAD CCD II
Flickerless mode
75dB Wide Dynamic Range, suitable for strong backlight environment
3D-Digital Noise Reduction (3D-DNR)
Smart IR mode
High Light Reversion
Electronic image stabilization (EIS)
Min. illumination: 0.001 Lux @ F1.2 (Color) , 0.0001 Lux @ F1.2 (B/W)
IR cut filter with auto switch
OSD menu
Auto iris with DC drive
Auto white balance, auto gain control, electronic shutter control and backlight compensation
Support 2.8 - 12 mm auto iris lens
Internal or Power Synchronization
3-axis (pan/tilt/rotation) positioning allows adjustment for optimum camera rotation and placement
Specification
Model
Parameter
DS-2CC51A7P(N)-VF
700 TVL CCD WDR ICR Dome Camera
Camera
Image Sensor
1/3” SONY Super HAD CCD II
Signal System
PAL/NTSC
Effective Pixels
PAL: 976 (H) × 582 (V)
NTSC: 976 (H) × 494 (V)

Hikvision Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
4
Min. Illumination
Color: 0.001 Lux @ (F1.2, AGC ON),
0.0001 Lux @ (F1.2, AGC ON, sensitivity × 512)
B/W: 0.0001 Lux @ (F1.2, AGC ON),
0.00001 Lux @ (F1.2, AGC ON, sensitivity × 512)
Color: 0.0014 Lux @ (F1.4, AGC ON),
0.00014 Lux @ (F1.4, AGC ON, sensitivity × 512)
B/W: 0.00014 Lux @ (F1.4, AGC ON),
0.000014 Lux @ (F1.4, AGC ON, sensitivity × 512)
Shutter Time
PAL: 1/50 s to 1/100,000 s
NTSC: 1/60 s to 1/100,000 s
Lens
2.8 - 12 mm @ F1.4
Angle of view: 92°- 27.2°
Lens Mount
φ14
Auto Iris
DC drive
Angle Adjustment
Pan: 0 - 355°, Tilt: 0 - 180°, Rotation: 0 - 355°
Day & Night
IR cut filter with auto switch
Horizontal Resolution
700 TVL
Wide Dynamic Range
75 dB
Synchronization
Internal/Power synchronization
Video Output
1Vp-p composite output (75 Ω/BNC)
S/N Ratio
More than 62 dB
Menu
Camera ID
On/Off (26 letters, adjusted position)
Auto Gain
Low/Middle/High/Off
D/N Mode
Auto /Day/Night
White Balance
Auto trace WB1/Auto trace WB2/Manual/Auto Control
Private Mask
On/Off, maximum 12 zones
Motion Detection
On/Off
BLC
Area/Value/Off
WDR
Value/ Contrast / Return
Anti-Flicker
On/Off
Language
English/Chinese
Video
SMART IR, High Light Reversion, Digital Noise Reduction,
Sharpness, Brightness, Saturation, Resolution, Electronic
image stabilization, Digital Zoom, Mirror, Blemish
Detection
Scene
Indoor Standard , Indoor Backlight , Outdoor, Low
illumination , Customize
General
Operating Conditions
-10 °C - 60 °C (14 °F - 140 °F)
Humidity 90% or less (non-condensing)
Power Supply
24 V AC ± 10%, 12 V DC ± 10%

Hikvision Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
5
Power Consumption
Max. 4 W
(Max. 4.5 W with IR cut filter on)
Dimension
Φ 136 × 101 mm (Φ 5.35” × 3. 98”)
Weight
800 g (1.76 lbs)
Order Models
DS-2CC51A7P-VF
DS-2CC51A7N-VF
Dimension
Unit: mm
