HIK VISION DS-2DF5284-A User manual

5 Inch Network High-definition Speed Dome
User Manual
V2.0.0
2010-01

5 Inch Network High-definition Speed Dome User Manual
1
Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact dealer.
This manual is applicable to 5 Inch Network High-definition Speed Dome.
This manual may contain several technically incorrect places or printing errors, and the content is subject to change without notice.
The updates will be added into the new version of this manual. We will readily improve or update the products or procedures described
in the manual.

5 Inch Network High-definition Speed Dome User Manual
2
Safety Instruction
These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution
measure is divided into “Warnings” and “Cautions”:
Warnings: Neglecting any of the warnings may cause serious injury or death.
Cautions: Neglecting any of the cautions may cause injury or equipment damage.
Warnings Follow these safeguards to prevent serious
injury or death.
Cautions Follow these precautions to
prevent potential injury or material
damage.
Warnings
1. In the use of the product, you must be strict compliance with the electrical safety regulations of the nation and region.
2. Please use the power adapter, which is provided by normal company. The standard of the power adapter is AC24V/3A.
3. Do not connect several devices to one power adapter as adapter overload may cause over-heat or fire hazard.
4. Please make sure that the plug is firmly connected on the power socket.
5. When the product is installed on wall or ceiling, the device shall be firmly fixed.
6. If smoke, odors or noise rise from the device, turn off the power at once and unplug the power cable, and then please contact the
service center.
7. If the product does not work properly, please contact your dealer or the nearest service center. Never attempt to disassemble the
camera yourself. (We shall not assume any responsibility for problems caused by unauthorized repair or maintenance.)
Warnings
1. Do not drop the dome or subject it to physical shock, and do not expose it to high electromagnetism radiation. Avoid the equipment
installation on vibrations surface or places subject to shock (ignorance can cause equipment damage).
2. Do not place the dome in extremely hot, cold (the operating temperature shall be -30°C ~ +65°C), dusty or damp locations, or fire or
electrical shock will occur otherwise.
3. The dome cover for indoor use shall be kept from rain and moisture.
4. Exposing the equipment to direct sun light, low ventilation or heat source such as heater or radiator is forbidden (ignorance can
cause fire danger).
5. Do not aim the camera at the sun or extra bright places. A blooming or smear may occur otherwise (which is not a malfunction
however), and affecting the endurance of CCD at the same time.
6. Please use the provided glove when open up the dome cover, avoid direct contact with the dome cover, because the acidic sweat of
the fingers may erode the surface coating of the dome cover.
7. Please use a soft and dry cloth when clean inside and outside surfaces of the dome cover, not to use alkaline detergents.

5 Inch Network High-definition Speed Dome User Manual
3
TABLE OF CONTENTS
TABLE OF CONTENTS............................................................................................................................................. 3
Chapter 1 Brief Introduction........................................................................................................................................ 5
1.1 Description..................................................................................................................................................... 5
1.2 Outline ........................................................................................................................................................... 5
1.3 Functions ....................................................................................................................................................... 5
1.4 Features.......................................................................................................................................................... 7
1.5 Default IP, User Name and Password ............................................................................................................ 8
Chapter 2 Operation Instructions................................................................................................................................. 9
2.1 Power-up Action ............................................................................................................................................ 9
2.2 Presets with Special Functions ...................................................................................................................... 9
2.3 Label Display............................................................................................................................................... 10
Chapter 3 Menu Operation .........................................................................................................................................11
3.1 MAIN MENU.............................................................................................................................................. 12
3.2 SYSTEM INFORMATION ......................................................................................................................... 12
3.3 SYSTEM SETTINGS.................................................................................................................................. 12
3.3.1 SYSTEM INFO SETTINGS ............................................................................................................ 13
3.3.2 CAMERA SETTINGS...................................................................................................................... 14
3.3.3 MOTION SETTINGS....................................................................................................................... 16
3.3.4 LINE SYNC...................................................................................................................................... 18
3.3.5 PRESETS.......................................................................................................................................... 18
3.3.6 PATROLS ......................................................................................................................................... 19
3.3.7 PATTERNS ....................................................................................................................................... 20
3.3.8 PRIVACY MASK............................................................................................................................. 21
3.3.9 AUX.................................................................................................................................................. 22
3.3.10 CLEAR ........................................................................................................................................... 23
3.4 FACTORY SETTINGS................................................................................................................................23
3.5 ....................................................................................................................................... 24RESET CAMERA
3.6 REBOOT SYSTEM..................................................................................................................................... 24
Chapter 4 Access to Network Speed Dome............................................................................................................... 25
4.1Access through IE......................................................................................................................................... 25
4.2Access by Client Software............................................................................................................................ 29
4.2.1 Configuration through Client Software ............................................................................................ 29
4.2.2 3D Intelligent Positioning................................................................................................................. 35
4.2.3 Presets............................................................................................................................................... 38
4.2.4 Patrols ............................................................................................................................................... 39
4.3 Configuration by DS-9000 Series DVR ...................................................................................................... 40
4.4 .................................................................................................................. 41Search and Modify IP by SADP
4.4.1 ...................................................................................................... 41Search active devices online
4.4.2 ........................................................................................................ 42Modify device information
4.4.3 .......................................................................................................... 43Resume default password
4.5 ........................................................................................................................................... 43Access by WAN

5 Inch Network High-definition Speed Dome User Manual
4
Appendix 1 Network Cable Connection.................................................................................................................... 45
Appendix 2 Lightning & Surge Protection ................................................................................................................ 46
Appendix 3 RS485 Bus Connection .......................................................................................................................... 47
Appendix 4 24VAC Wire Gauge & Transmission Distance ...................................................................................... 50
Appendix 5 Table of Wire Gauge Standards.............................................................................................................. 51

5 Inch Network High-definition Speed Dome User Manual
5
Chapter 1 Brief Introduction
1.1 Description
Integrating the network remote monitoring capability with the functions of the high speed dome, the Network High Speed Dome is a
new product model which features easy installation and operation and facilitated wiring design. With built-in video server, the
Network Speed Dome is capable of providing the following new features: real-time video stream compressed and then transmitted via
network to different clients simultaneously; based on Ethernet, and analog video output supported; TI DAVINCI processing chip and
platform adopted to ensure high reliability and stability of performance; H.264 compression adopted to effectively save network
transmission bandwidth and HD storage space; dynamic configuration of encoding parameters; PPPoE, DHCP, UDP, MCAST and
TCP/IP protocols supported; bidirectional voice talk, OSD overlay and RS-485 serial port control; built-in Web Server allows control
of speed dome via IE browser; main stream and sub stream selectable for transmission; local and remote alarm response actions;
multi-zone motion detection with different sensitivity levels configurable; remote integrated storage based on IPSAN and NAS; and
watermark technology adopted for stream data to prevent unauthorized operation of the record files, etc.
The Network High-definition Speed Dome can be widely applied to various monitoring scenes such as the river, forest, road, railway,
airport, harbor, oil field, sentry, plaza, park, scenic spot, street, station, stadium, etc.
1.2 Outline
Back Bo x
Back Box
Dome Dri ve
Bubble
5 Inch Network High-definition Speed Dome
1.3 Functions
Multi-lingual OSD Menu
The dome provides multi-lingual OSD menu for display of system information and setting of dome parameters.
Self-adaptive to Multiple Protocols
The dome is compatible with PELCO-D, PELCO-P, PRIVATE-Code protocol, etc., and is capable of being self-adaptive to these
protocols without need of selecting protocol by DIP switch settings.
Keyboard Control
The pan/tilt movement and zoom actions of dome can be controlled by the control keyboard, DVR, matrix, etc.

5 Inch Network High-definition Speed Dome User Manual
6
Limit Stops
The dome can be programmed to move within the limit stops (left/right, up/down) which are configurable by the control keyboard,
DVR or client application software.
Auto Scan
The dome provides 5 scanning modes: pan scanning, tilt scanning, frame scanning, random scanning and panorama scanning. The
scanning speed can be set by OSD menu from level 1 to 40, with the corresponding speed ranging from 1°/second to 40°/second.
Preset Freeze Frame
This feature freezes the scene on the monitor when going to a preset. This allows for smooth transition from one preset scene to
another and also guarantees that masked area will not be revealed when going to a preset.
Presets
Each of the user-definable presets can be programmed to use pan, tilt, camera settings and other settings. When preset is called, the
dome will automatically move to the defined position. User is allowed to add, modify, delete and call each preset.
Label Display
The on-screen label of the preset title, azimuth/elevation, zoom and other operations can be programmed by menu and displayed on the
monitor.
Auto Flip
In manual tracking mode, when a target object goes directly beneath the dome, the dome will automatically rotate 180 degrees in
horizontal direction to maintain continuity of tracking. When the dome rotates (flips), the camera starts moving upward as long as you
continue to hold the joystick in the down position. This function can be realized by image center flip depending on different camera
models. The feature can be enabled/disabled through the menu.
Privacy Mask
The privacy mask allows a user to program user-defined areas that cannot be viewed by the operator of the dome system. A masked
area will move with pan and tilt functions and automatically adjust in size as the lens zooms telephoto and wide.
3D Intelligent Positioning
The speed dome can be controlled with the 2 buttons and scroll of mouse can be used under PRIVATE-Code protocols with devices
and client software. Click on a certain area and the device will move to the scene with corresponding point as the center. When a
rectangular area is selected by left-clicking the mouse, device will move to its center and enlarge it. With right-clicking, the lens will
zoom in, and the scroll can easily make the lens zooming, and mouse operation automatically incorporates zooming effect.
Note: Please refer to Section 4.2.2 3D Intelligent Positioning for the specific instructions.
Proportional Pan/Tilt
Proportional pan/tilt automatically reduces or increases the pan and tilt speeds in proportion to the amount of zoom. At telephoto zoom
settings, the pan and tilt speeds will be slower for a given amount of joystick deflection than at wide zoom settings. This keeps the
image from moving too fast on the monitor when there is a large amount of zoom.
Auto Focus
The auto focus enables the camera to focus automatically to maintain clear video images.
IR Cut Filter
The IR cut filter can be set to Auto, Day and Night.In auto mode, the camera is capable of automatically switching Black & White
mode (Night) and Color mode (Day) with regard to environment lightening conditions. In manual switch mode, user can increase
sensitivity in low light conditions by switching to Black & White mode, while the Color mode is preferred in normal lighting
conditions.
Low Light Electronic Shutter
The shutter speed will automatically slow down in low illumination conditions to maintain clear video images by extending the
exposure time. The feature can be enabled/disabled by the menu.
Backlight Compensation (BLC)

5 Inch Network High-definition Speed Dome User Manual
7
If a bright backlight is present, the subjects in the picture may appear dark or as a silhouette. Backlight compensation (BLC) enhances
objects in the center of the picture. The dome uses the center of the picture to adjust the iris. If there is a bright light source outside of
this area, it will wash out to white. The camera will adjust the iris so that the object in the sensitive area is properly exposed.
Wide Dynamic Range (WDR)
When the Wide Dynamic Range (WDR) function is on, the dome is able to balance the brightest and darkest sections of a scene to
produce a picture that is better balanced in lighting and provides more details.
White Balance (WB)
This feature automatically processes the viewed image to retain color balance over a color temperature range. The default setting for
white balance is AUTO.
Patrol
The high speed dome provides up to 8 patrols. In each patrol, user is allowed to specify the scanning track by a group of user-defined
presets, with the scanning speed between two presets and the dwell time at the preset separately programmable.
Pattern
A pattern is a memorized, repeating series of pan, tilt, zoom, and preset functions that can be recalled with a command from a
controller or automatically by a configured function (alarm, park, time task, or power-up). By default the focus and iris are in auto
status during the pattern is being memorized.
Power Loss Position
The dome supports the power loss position capability with the predefined dwell time. It allows the dome to resume its previous
position after power is restored.
Alarm Response Action
The speed dome supports 1 alarm inputs which can be set to NO (normally open), NC (normally closed). Upon having received the
alarm input signal, the dome will automatically activate a user-defined action, which can be programmed to patrol, pattern or preset
callup.
AUX Output
An auxiliary output is a configurable signal from the dome back box that can trigger another device to operate. The dome provides 1
auxiliary outputs: AUX1. The auxiliary output type can be set to NO or NC by menu. And the alarm dwell time is configurable as well.
User Management
The dome allows the users to be edited in groups with different levels of permission. In the admin login status, the user is allowed to
configure the user groups and user parameters. Multiple users are allowed to access and control the same network speed dome via
network simultaneously.
1.4 Features
Built-in WEB Server
1 channel of compressed video stream transmitted via network and decoded for local display;
Up to 6 domes can be simultaneously connected via network;
Support multiple network transmission protocols;
WEB access for WAN applications;
Management of dome configuration and user permission administration via Ethernet;
IP address dynamic allocation.
Built-in Driver/Receiver
Full-digital design, with power-off protection for all data;
Integrated design ensures high reliability;
256 presets and 8 patrols programmable; each patrol with a maximum of 32 presets configurable;

5 Inch Network High-definition Speed Dome User Manual
8
4 patterns, with the recording time reaching up to 10 minutes;
RS-485 bus control;
Up to 24 privacy mask areas programmable (depending on camera models)
Self-adaptive to PELCO-D, PELCO-P, PRIVATE-Code, etc., with various baud rates selectable.
Built-in Pan/Tilt
High-precision motor drive, stable operation, sensitive reaction and precise positioning;
Integrated design with compact construction;
360° continuous rotation;
Low-speed movement ensures high image stability;
Preset positioning tolerance less than 0.1°
Built-in Zoom Lens
High sensibility and high resolution
Auto focus
Auto gain
Auto white balance
Auto IR cut filter
1.5 Default IP, User Name and Password
Default IP: 192.0.0.64
User Name: admin
Password: 12345

9
5 Inch Network High-definition Speed Dome User Manual
Chapter 2 Operation Instructions
2.1 Power-up Action
After the power is applied, the speed dome will perform self-test action that begins with lens actions and then pan and tilt movement.
After completion of power-up self-test actions, the interface as shown in Figure 2.1 will be displayed on screen for 40 seconds.
The System Information displayed on the screen includes the Dome Address, Protocol, Version and other information. The
COMMUNICATION refers to the baud rate, parity,data bit and stop bit of the dome, e.g., “2400, N,8, 1” indicates the dome is
configured with the baud rate of 2400, no parity,8 data bits and 1 stop bit. Please refer to Section 3.3.1 for detailed information.
MODEL DS-2DF1-571
ADDRESS 0
COMMUNICATION 2400,N,8,1
SOFTWARE VERSION 2. 0.1
LANGUAGE ENGLISH
Figure 2.1
2.2 Presets with Special Functions
The following presets are predefined with special functions:
Call Preset Function Call Preset Function
33 Auto flip 93 Set manual limit stops
34 Pan zero 94 Remote reboot
35 Patrol 1 95 Access main menu
36 Patrol 2 96 Stop a scan
37 Patrol 3 97 Start random scanning
38 Patrol 4 98 Start frame scanning
39 IR cut filter in 99 Start pan scanning
40 IR cut filter out
41 Pattern1
42 Pattern2
43 Pattern3
44 Pattern4
92 Enable limit stops setting

5 Inch Network High-definition Speed Dome User Manual
10
2.3 Label Display
The dome allows you to configure how labels are displayed on the monitor. The following labels are available:
Zoom: Identifies the amount of magnification.
Direction: Displays compass direction, with the format of PXXX TXXX. The XXX following P refers to the degrees in pan direction,
while the XXX following T indicates the degrees in tilt position. The north direction can be set by menu.
Alarm Message: Displays activated alarm message.
Time: Support for time display.
Preset Title: Identifies preset being called.

5 Inch Network High-definition Speed Dome User Manual
11
Chapter 3 Menu Operation
Note: The menu varies depending on camera models.
Menu Tree

5 Inch Network High-definition Speed Dome User Manual
12
3.1 MAIN MENU
After logon to IE browser or client software, call preset 95 to access the main menu of the dome. Refer to Figure 3.1.1.
Click the direction buttons on PTZ control section to move the cursor to the selected menu item. Press IRIS+ to confirm, i.e., operation
can be done on this menu options. If current menu contains sub-menu, enter the corresponding sub-menu.
To perform operation on menu option, the selected number behind menu item can be changed by clicking up and down buttons. Click
IRIS+ to confirm and return to previous menu. The same procedure is followed for the next operation for which no description is given.
Select Exit menu option to confirm and exit from menu operation.
MAIN MENU
<SYSTEM INFORMATION>
<SYSTEM SETTINGS>
<FACTORY SETTINGS>
<RESETCAMERA>
<REBOOT SYSTEM>
EXIT
<SYSTEM INFORMATION>
MODEL DS-2DF1-571
ADDRESS 0
COMMUNICATION 2400,N,8,1
SOFTWARE VERSION 2. 0.1
LANGUAGE ENGLISH
BACK EXIT
Figure3.1.1 Figure3.2.1
3.2 SYSTEM INFORMATION
This menu displays current dome system information, as shown in Figure 3.2.1. Information in menu option cannot be changed and
Temperature refers to internal temperature of dome.
Move the cursor to Back and click IRIS+ to return to the previous menu, or move the cursor to Exit and click IRIS+ to save the settings.
Operation is similar to all other submenus.
3.3 SYSTEM SETTINGS
Enter the SYSTEM SETTINGS menu, as shown in Figure 3.3.1 and Figure 3.3.2.
Note: Enter the next page by moving the cursor beside NEXT PAGE and click IRIS+ button.
<SYSTEM SETTINGS>
<SYSTEM INFO SETTINGS>
<CAMERA>
<MOTION>
<LINE SYNC>
<PRESETS>
<PATROLS>
NEXT PAGE
BACK EXIT
<SYSTEM SETTINGS>
<PATTERNS>
<PRIVACY MASK>
<AUX>
<CLEAR>
BACK EXIT
Figure3.3.1 Figure3.3.2

5 Inch Network High-definition Speed Dome User Manual
13
3.3.1 SYSTEM INFO SETTINGS
The SYSTEM INFO SETTINGS menu is used for setting the soft address, date and time, display information, etc. Refer to Figure
3.3.3 and Figure 3.3.4.
SOFT ADDRESS
When the ENABLE SOFT ADDRESS option is set to ENABLE, the speed dome will use the soft address, and the addresses from 1 to
255 selectable. Please note the dome address range supported by the current control keyboard. When the ENABLE SOFT ADDRESS
option is set to DISABLE, the address set by DIP switch is used. When the address is set to 0, the dome is capable of receiving the
control command from the control device of any address; when the address of the control device is set to 0, then the speed dome of any
address can be controlled as well. Refer to Figure 3.3.3.
<SYSTEM INFO SETTINGS>
SOFT ADDRESS 0
ENABLE SOFT ADDRESS DISABLE
<DATE AND TIME>
<ZERO POINT SETTING>
<DISPLAY SETTINGS>
<IP ADDRESS>
NEXT PAGE
BACK EXIT
<SYSTEM INFO SETTINGS>
POWER LOSS POSITION DISABLE
REBOOT PERIOD DISABLE
PT ADJUST PERIOD DISABLE
BACK EXIT
Figure3.3.3 Figure3.3.4
Y. M. D. 09 12 30
H. M. S. 14 39 17
IRIS+OK
IRIS- CANCEL
Figure 3.3.5
DATE AND TIME
The DATE AND TIME allows user to set the date and time of the dome. As shown in Figure 3.3.5, the message indicates the current
date and time is 14:39:17 on December 30th,2009.
Use the Left and Right buttons to select the option, and click the Up and Down buttons to modify the value.
ZERO POINT SETTING
Enter the ZERO POINT SETTING menu and then use the direction buttons to define the amount of pan from zero degrees vertical and
the amount of tilt from zero degrees horizontal, and finally press the Iris+ button to save settings and exit the current menu.
DISPLAY SETTINGS
The DISPLAY SETTINGS menu is displayed in one page, as shown in Figure 3.3.6.
Each item can be set with the separate display time on screen from 2sec, 5sec and 10sec selectable, or set to be ON or OFF. The preset
display position can overlapped the display positions of azimuth/elevation and zoom. If both of the ZOOM SHOW and the PT SHOW
are set to ON, then in the preset operation status, the preset label will be displayed all the time; while in other operation status, the

5 Inch Network High-definition Speed Dome User Manual
14
azimuth/elevation and zoom label are displayed all the time in other status. The external alarm response actions can be activated in
non-menu programming mode while disabled in the menu programming mode.
IPADDRESS
Enter the IP ADDRESS menu and then use the direction buttons to define of value of IP address and sub mask. Finally click the Iris+
button to save settings and exit the current menu.
POWER LOSS POSITION
The dome supports the power loss position capability with the predefined dwell time. It allows the dome to resume its previous
position after power is restored. The function can be set to 30 sec, 60 sec, 300 sec, 600 sec or Disable.
REBOOT PERIOD
The dome reboots at 00:00:00 of the current day for the first time, and the second reboot action will take place after the predefined
period which can be set to 1~7 days or Disable.
PTADJUST PERIOD
The dome performs pan and tilt self-test at 00:00:00 of the current day for the first time, and the second pan/tilt self-test action will
take place after the predefined period which can be set to 1~7 days or Disable. If the reboot time and the PT adjust time are overlapped
with each other, the system will perform the scheduled reboot with the priority, and no scheduled PT adjust action will be taken.
IP ADDR: 172 008 003 205
SUB MASK: 255 255 255 000
IRIS+OK
IRIS- CANCEL
Figure3.3.6 Figure3.3.7
3.3.2 CAMERA SETTINGS
Note: The menu varies depending on camera models.
Enter the Camera Settings menu, as shown in Figure 3.3.8, Figure 3.3.9 and Figure 3.3.10.
<CAMERA>
AUTO FOCUS ENABLE
ZOOM LIMIT 36
ZOOM SPEED HIGH
SLOW SHUTTER ENABLE
IR CUT FILTER NIGHT
IRCUT SENSITIVITY N/A
NEXT PAGE
BACK EXIT
<CAMERA>
SHARPNESS 9
BLC/WDR DISABLE
EXPOSURE MODE AUTO
IRIS 10
SHUTTER 60
GAIN 1
NEXT PAGE
BACK EXIT
Figure3.3.8 Figure3.3.9

5 Inch Network High-definition Speed Dome User Manual
15
<CAMERA>
EXP COM/NOISE REDUCE 7
PICTURE FLIP DISABLE
WHITE BALANCE ATW
R GAIN 210
B GAIN 150
FOCUS NEAR LIMIT 1M
INITIALIZE LENS DISABLE
BACK EXIT
Figure 3.3.10
AUTO FOCUS
The camera provides three focus modes for selection: ENABLE, DISABLE and PTZ TRIGGER.
In auto focus mode (ENABLE), the camera will allow the lens to remain in focus when using pan, tilt and zoom (PTZ) functions.
In manual focus mode (DISABLE), the focus can be operated manually.
In half-auto focus mode (PTZ TRIGGER), the camera will remain in a fixed focus position when all PTZ motions are stopped. And
when the PTZ motions are resumed, the camera will focus automatically.
ZOOM LIMIT
Zoom limit allows the user to define a limitation on the amount of telephoto zoom. The settings vary depending on camera models.
Zoom amount=optical zoom× digital zoom. When the ZOOM LIMIT is set to the minimum value, it indicates the digital zoom is
disabled, and the optical zoom is in its maximum value.
ZOOM SPEED
Zoom speed allows the user to define the speed at which the dome will go from full wide zoom to the optical zoom, with three levels
selectable: HIGH, MIDDLE and LOW. The default setting is HIGH.
SLOW SHUTTER
The shutter will automatically slow down to obtain clearer figure through exposure time extension under low lightening. The default
setting is ENABLE.
DAY/NIGHT
The IR cut filter can be set to AUTO, DAY and NIGHT.In auto mode, the camera is capable of automatically switching Black &
White mode (NIGHT) and Color mode (DAY) with regard to environment lightening conditions. In manual switch mode, user can
increase sensitivity in low light conditions by switching to Black & White mode, while the Color mode is preferred in normal lighting
conditions. The default setting is AUTO.
The DAY mode can be set by calling preset 39, and the NIGHT mode set by preset 40.
IRCUT SENSITIVITY
The IR cut sensitivity is the light level at which the IR cut filter switches DAY or NIGHT. Three levels are selectable: HIGH, MID and
LOW. The default setting is MID.
Note: This feature varies depending on camera models.
SHARPNESS
The sharpness function enhances picture detail by increasing the aperture gain of the camera and sharpening the edges in the picture.
Levels from 1 to 16 are selectable, with the default setting of level 9.
BLC/WDR
If a bright backlight is present, the subjects in the picture may appear dark or as a silhouette. Backlight compensation (BLC) enhances
objects in the center of the picture. The dome uses the center of the picture to adjust the iris. If there is a bright light source outside of
this area, it will wash out to white. The camera will adjust the iris so that the object in the sensitive area is properly exposed.

5 Inch Network High-definition Speed Dome User Manual
16
When the Wide Dynamic Range (WDR) function is on, the dome is able to balance the brightest and darkest sections of a scene to
produce a picture that is better balanced in lighting and provides more details.
Note: The BLC/WDR feature varies depending on camera model. The default setting is for BLC function.
EXPOSURE MODE
The exposure mode can be set to IRIS PRIORITY, SHUTTER PRIORITY, GAIN/MANUAL or AUTO. When it is set to AUTO, the
auto iris, auto shutter and auto gain functions are all enabled; when it is set to IRIS PRIORITY, the iris function adopts the defined
value while the auto shutter and auto gain remain to be enabled; when it is set to SHUTTER PRIORITY, the shutter function adopts
the defined value while the auto iris and auto gain remain to be enabled; and when it is set to GAIN/MANUAL, the gain value can be
adjusted, or the iris, gain and shutter values are all adjustable. The default setting is AUTO.
Note: The Gain/Manual feature varies depending on camera models.
IRIS
The iris is the lens function that opens and closes the iris in response to changing light conditions, with the numeric values from 0 to 17
selectable.
SHUTTER
The Shutter is the duration of the electronic shutter. User can set the shutter speed to 1, 2, 4, 8, 15, 30, 60, 125, 180, 250, 500, 1000,
2000, 4000 or 10000. The numeric value of X indicates the shutter speed is 1/X second.
GAIN
The Gain indicates the amplification degree of the original image signal, with the numeric values from 0 to 15 selectable.
EXP COMP/NOISE REDUCE
The exposure compensation effect can be adjusted through exposure volume adjustment. The numeric values from 0 to 14 are
selectable, with the default setting of 7.
The noise reduce function can be set to OFF, HIGH, MID and LOW. The default setting is MID.
Note: This feature varies depending on camera models.
IMAGE FLIP
This feature allows the video image to be mirrored horizontally and vertically on the screen.
WHITE BALANCE
This feature automatically processes the viewed image to retain color balance over a color temperature range. The dome provides 5
modes for selection: AUTO, INDOOR, OUTDOOR, SELFDEFINE and ATW. When the SELFDEFINE is selected, set the value of
RED and BLUE.
FOCUS NEAR LIMIT
The focus near limit can be set to 1CM, 30CM, 1M or 3M. The feature allows the camera to perform auto focus out of the focus near
limit.
INITIALIZE LENS
This feature enables the camera to perform daily lens initiation action at 00:00:00 to ensure the normal operation.
3.3.3 MOTION SETTINGS
The MOTION menu is displayed in two pages, as shown in Figure 3.3.11 and Figure 3.3.12.

5 Inch Network High-definition Speed Dome User Manual
17
Figure 3.3.11
PROPORTIONAL PAN
When the PROPORTIONAL PAN is set to ENABLE, the dome will automatically reduce or increases the pan and tilt speeds in
proportion to the amount of zoom. At telephoto pan and tilt speeds will be slower for a given amount of joystick deflection than at
wide zoom settings. This keeps the image fast on the monitor when there is a large amount of zoom.
When the PROPORTIONAL PAN is set to DISABLE, it will be difficult to trace the object at low pan and tilt speeds or no movement
in large amount of zoom.
PARK TIME (SECS)
This feature allows the dome to begin a specified operation (scan, preset, or pattern) after a configured period of inactivity.
Park time can be configured from 5 to 720 seconds.
Note: If no control signal is received for a period of time under the following circumstances, no automatic actions will be performed:
1. In the process of performing dome actions by callup of special presets; 2. In the process of performing external alarm response
actions.
PARK ACTION
This feature will define the activity when the dome parks. The selectable park actions include: presets1-8, patterns 1-4, patrols 1-8,
auto scan, tilt scan, random scan, frame scan, panorama scan, or disable.
SCAN SPEED
Scan speed is the degrees per second of the auto scan, tilt scan, frame scan, random scan and panorama scan. Scan speed is adjustable
from 1 to 40 degrees per second through the camera menu.
FRESET FREEZE FRAME
This feature freezes the scene on the monitor when going to a preset. This allows for smooth transition from one preset scene to
another.
LIMIT SETTINGS
Limit stops are configurable stops that limit the pan and tilt range of the dome. There may be left/right and up/down limit stops
configurable to define an area. When the LIMIT ENABLE function is set to DISABLE, the movement of dome will not be limited
despite of defined limit stops. Refer to Figure 3.3.12.

5 Inch Network High-definition Speed Dome User Manual
18
<LIMIT SETTINGS>
LIMIT ENABLE DISABLE
<SET MANUAL STOPS>
<CLEAR MANUAL STOPS>
<SET SCAN STOPS>
<CLEAR SCAN STOPS>
<SET PANORAMA SCAN STOPS
<CLEAR PANORAMA SCAN STOPS>
BACK EXIT
Figure 3.3.12
SET MANUAL STOPS:
To set limit stops manually:
1. Enter the SET MANUAL STOPS menu.
2. Follow the directions (SET LEFT LIMIT) displayed on the monitor and use the joystick or direction buttons to the desired
location of left limit stop.
3. Press the IRIS + button to finish the setting of left limit stop.
4. Follow the same steps to set the right, up and down limit stops in sequence according to the directions displayed on the
monitor.
When the limit stops have been defined, the left or right limit stop can be reached by moving the joystick to the left or right.
The new settings of limit stops will overwrite the existed settings.
CLEAR MANUAL STOPS:
The defined manual left or right limit stops can be cleared by this menu.
SET SCAN STOPS:
The auto san stops can be set by this menu. Follow the same instructions with the SET MANUAL STOPS section described
above to set the auto scan stops.
Note: When the manual limit stops have been set, the auto scan stops function is invalid, and the operation will be subject
to the defined manual limit stops.
CLEAR SCAN STOPS:
The defined auto scan limit stops can be cleared by this menu.
SET PANORAMA SCAN STOPS:
The panorama scan stops can be set by this menu. Follow the same instructions with the SET MANUAL STOPS section
described above to set the auto scan stops.
CLEAR PANORAMA SCAN STOPS:
The defined panorama scan limit stops can be cleared by this menu.
3.3.4 LINE SYNC
Note: This feature is not supported currently.
3.3.5 PRESETS
The PRESETS menu is displayed as shown in Figure 3.3.13.

5 Inch Network High-definition Speed Dome User Manual
19
<PRESETS>
PRESET NUMBER 1
PRESET LABEL PRESET1
<SET PRESET LABEL>
<EDIT PRESET SCENE>
<CLEAR PRESET>
BACK EXIT
Figure 3.3.13
PRESET NUMBER
The dome provides 256 presets. The PRESET NUMBER displays the preset under current operation. If the preset has been defined, the
corresponding number will appear; while no preset is defined, it will display UNDEFINED. The presets which are predefined for
specific functions will not be displayed and no change is allowable. Please refer to page 9 for presets with specific functions.
SET PRESET LABEL
Select SET PREST LABEL to enter the menu shown in Figure 3.3.14, and then press IRIS+ button to enter the menu for editing the
preset label. Refer to Figure 3.3.15.
UsethefollowingfunctionsbuttonsonthekeyboardortheDVRfrontpaneltoeditpresetlabel:
IRIS+: Confirm and save the current settings and return to the previous menu.
IRIS-: Cancel the current operation and return to the previous menu.
FOCUS+: Select and enter the character.
FOCUS-: Delete the character currently entered.
Direction Buttons: Move the cursor to select the numbers/lowercases/capitals/symbols.
PRESET LABEL PRESET1
IRIS- CANCEL
IRIS+ OK
Figure3.3.14 Figure3.3.15
EDIT PRESET SCENE
Select EDIT PREST SCENE to enter the menu, use the direction buttons to move PTZ to the desired scene and then press the IRIS+ to
confirm the settings and return to the previous menu, or press IRIS- to cancel settings.
Note: the setting of preset scene will be restricted by the limit stops if defined.
CLEAR PRESET
This feature is used for clearing the current preset.
3.3.6 PATROLS
The PATROLS settings menu is shown in Figure 3.3.16.
