Hikmicro LYNX S Series User manual

Thermal Monocular
LYNX S & LYNX Pro Series
User Manual V5.5.72 202312
Contact Us

Thermal Monocular User Manual
I
CONTENTS
1Overview.......................................................................................................................1
1.1 Main Function ....................................................................................................................................... 1
1.2 Appearance........................................................................................................................................... 1
2Preparation...................................................................................................................5
2.1 Cable Connection ................................................................................................................................. 5
2.2 Power On/Off ........................................................................................................................................ 5
2.3 Auto Screen Off .................................................................................................................................... 6
2.4 Menu Description.................................................................................................................................. 7
2.5 App Connection .................................................................................................................................... 7
2.6 Firmware Status.................................................................................................................................... 8
2.6.1 Check Firmware Status ...................................................................................................................... 8
2.6.2 Upgrade Device ...................................................................................................................................9
3Image Settings...........................................................................................................11
3.1 Adjust Diopter ..................................................................................................................................... 11
3.2 Adjust Focus ....................................................................................................................................... 11
3.3 Adjust Image Brightness .................................................................................................................... 12
3.4 Adjust Display Brightness .................................................................................................................. 12
3.5 Adjust Contrast................................................................................................................................... 13
3.6 Adjust Tone......................................................................................................................................... 13
3.7 Adjust Sharpness................................................................................................................................ 13
3.8 Select Scene ....................................................................................................................................... 14
3.9 Set Palettes......................................................................................................................................... 14
3.10 Set Picture in Picture Mode ............................................................................................................... 16
3.11 Adjust Digital Zoom ............................................................................................................................ 17
3.12 Flat Field Correction ........................................................................................................................... 17
3.13 Correct Defective Pixel....................................................................................................................... 18
4Measure Distance......................................................................................................20
5General Settings.........................................................................................................22
5.1 Set OSD ............................................................................................................................................... 22
5.2 Set Brand Logo ................................................................................................................................... 22
5.3 Burning Prevention ............................................................................................................................. 23

Thermal Monocular User Manual
II
5.4 Capture and Video .............................................................................................................................. 23
5.4.1 Capture Picture..................................................................................................................................23
5.4.2 Record Video .....................................................................................................................................23
5.5 Hot Tracking ....................................................................................................................................... 24
5.6 Export Files ......................................................................................................................................... 25
5.6.1 Export Files via HIKMICRO Sight..................................................................................................... 25
5.6.2 Export Files via PC ............................................................................................................................ 26
6System Settings.........................................................................................................28
6.1 Adjust Date.......................................................................................................................................... 28
6.2 Synchronize Time ............................................................................................................................... 28
6.3 Set Language ...................................................................................................................................... 28
6.4 Set Unit ................................................................................................................................................ 29
6.5 CVBS Output ....................................................................................................................................... 29
6.6 View Device Information .................................................................................................................... 30
6.7 Restore Device .................................................................................................................................... 30
7Frequently Asked Questions......................................................................................31
7.1 Why does the charge indicator flash improperly? ............................................................................ 31
7.2 Why is the power indicator off? ......................................................................................................... 31
7.3 The image is not clear, how to adjust it?........................................................................................... 31
7.4 Capturing or recording fails. What's the problem? ........................................................................... 31
7.5 Why the PC cannot identify the device? ............................................................................................ 31

Thermal Monocular User Manual
1
1 Overview
HIKMICRO LYNX S & LYNX Pro thermal monocular supports hot tracking,
video and snapshot, app connection and so on. The high-sensitivity built-in
thermal detector provides you with clear view even in total darkness. The
monocular is mainly applied to scenarios such as hunting and outdoor
nature observation.
1.1 Main Function
Hot Tracking: The device can detect the highest temperature in the
scene and mark the spot. This function varies according to different
camera models.
Auto Screen Off: The function allows the device to enter standby
mode/wake up through angle changes. The function darkens the
screen to save energy and increase battery time.
Video and Snapshot: The built-in memory module supports video
recording and snapshot capturing.
App Connection: The device can capture snapshots, record videos, and
set parameters by HIKMICRO Sight app after being connected to your
phone via hotspot.
1.2 Appearance
The appearance may vary according to different models. Please take
the actual product for reference.
Pictures in this manual are for illustration purpose only. Please take the
actual product for reference.

Thermal Monocular User Manual
2
Figure 1-1 Appearance
Table 1-1 Description of Components
No.
Component
Description
1
Lens Cover
Protects the lens.
2
Focus Ring
Adjusts focus to obtain clear targets.
3
Buttons
To set functions and parameters.
4
Diopter
Adjustment Knob
Adjusts the dioptric setting.
5
Eyepiece
The piece placed closest to the eye to view
the target.

Thermal Monocular User Manual
3
6
Charging
Indicator
Indicates the charging status of the device.
Flashing Red & Green: Error occurred.
Solid Red: Charging.
Solid Green: Fully charged.
7
Type-C Interface
Power the device or transmit data with a
type-C cable.
8
Tripod Mount
Mounts the tripod.
9
Wrist Strap Hole
Mounts the wrist strap.
Button Description
Table 1-2 Button Description
Icon
Button
Function
Power
Press: Standby mode/Wake up device.
Hold: Power on/off.
Capture
Non-Menu Mode:
Press: Capture snapshots.
Hold: Start/Stop recording videos.
Menu Mode: Press to move up.
Mode
Non-Menu Mode:
Press: Switch palettes.
Hold: Enter the menu.
Menu Mode:
Press: Confirm/Set parameters.
Hold: Save and exit menu.
Zoom
Non-Menu Mode:
Press: Switch digital zoom.
Hold: Correct non-uniformity of display (FFC).
Menu Mode: Press to move down.

Thermal Monocular User Manual
4
When the auto screen off function is enabled, if you press to enter
standby mode, you can also tilt or rotate the device to wake up the device.
Refer to Auto Screen Off for detailed operation.

Thermal Monocular User Manual
5
2 Preparation
2.1 Cable Connection
Connect the device and power adaptor with a type-C cable to power on the
device. Alternatively, connect the device and PC to export files.
Figure 2-1 Cable Connection
Charge the device for more than 5 hours before first use.
The charging temperature should be from 0 °C to 45 °C (32 °F to
113 °F).
2.2 Power On/Off
Power On
When the device is connected to cable or the battery is enough, hold to
power on the device.
Power Off
When the device is turned on, hold to power off the device.

Thermal Monocular User Manual
6
Power-off countdown will appear when you power off the device. You
can press any key to interrupt the countdown and cancel the power-off.
Automatic low battery power-off cannot be canceled.
Auto Power Off
You can set the auto power off time for your device.
Steps
Hold to show the menu.
Go to Advanced Settings, and select General Settings.
Press or to select , and press to enter the
configuration interface.
Press or to select the auto power off time as required, and
press to confirm.
Hold to save and exit.
See the battery icon for the battery status. means the battery is
fully charged, means that the battery is low, and means the
battery charging is abnormal.
When the low power note shows, charge the battery.
The auto power off takes effect only when the device enters the
standby mode and the device isn’t connected with HIKMICRO Sight app
at the same time.
The auto power off countdown will start again when the device reenters
standby mode, or the device is restarted.
2.3 Auto Screen Off
Auto screen off function darkens the screen to save energy and increase
battery time.
Steps
Enable auto screen off.

Thermal Monocular User Manual
7
Hold to show the menu.
Go to Advanced Settings, and press or to select
.
Press to enable auto screen off.
Hold to save settings and exit.
You can do one of the following methods to enter the standby mode
when the display is turned on:
Tilt the device downwards more than 70°.
Rotate the device horizontally more than 75°.
Keep the device still and do not move it for 5 minutes.
You can do one of the following methods to wake up the device when
the display is turned off:
Tilt the device downwards from 0° to 60° or upwards .
Rotate the device horizontally from 0° to 75°.
Press to wake up the device.
2.4 Menu Description
In the live view interface, hold to show the menu.
Figure 2-2 Menu Description
2.5 App Connection
Connect the device to the HIKMICRO Sight app via hotspot, then you can
capture picture, record video, or configure parameters on your phone.
Steps
