Hikmicro Thunder Pro TQ50C User manual

Thermal Monocular
User Manual

Thermal Monocular User Manual
i
Legal Information
© 2021 Hangzhou Microimage Software Co., Ltd. All rights reserved.
About this Manual
The Manual includes instructions for using and managing the Product. Pictures, charts, images and
all other information hereinafter are for description and explanation only. The information
contained in the Manual is subject to change, without notice, due to firmware updates or other
reasons. Please find the latest version of this Manual at the HIKMICRO website
(http://www.hikmicrotech.com).
Please use this Manual with the guidance and assistance of professionals trained in supporting the
Product.
Trademarks
and other HIKMICRO's trademarks and logos are the properties of
HIKMICRO in various jurisdictions.
Other trademarks and logos mentioned are the properties of their respective owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS IS" AND
"WITH ALL FAULTS AND ERRORS". HIKMICRO MAKES NO WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR
A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT
WILL HIKMICRO BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT
DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT
LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKMICRO
HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKMICRO SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK,
VIRUS INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKMICRO WILL PROVIDE
TIMELY TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ILLEGAL HUNTING ANIMALS, INVASION OF PRIVACY OR
ANY OTHER PURPOSE WHICH IS ILLEGAL OR DETRIMENTAL TO THE PUBLIC INTEREST. YOU SHALL

Thermal Monocular User Manual
ii
NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE DEVELOPMENT OR
PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR PRODUCTION OF
CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED TO ANY
NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN RIGHTS
ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER
PREVAILS.

Thermal Monocular User Manual
iii
Regulatory Information
FCC Information
Please take attention that changes or modification not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help
This equipment should be installed and operated with a minimum distance 20cm between the
radiator and your body.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with
"CE" and comply therefore with the applicable harmonized European standards
listed under the EMC Directive 2014/30/EU, the RoHS Directive 2011/65/EU
2012/19/EU (WEEE directive): Products marked with this symbol cannot be
disposed of as unsorted municipal waste in the European Union. For proper
recycling, return this product to your local supplier upon the purchase of
equivalent new equipment, or dispose of it at designated collection points. For
more information see: www.recyclethis.info

Thermal Monocular User Manual
iv
2006/66/EC (battery directive): This product contains a battery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentation for specific battery information. The battery is marked with this
symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the battery to your supplier or to a
designated collection point. For more information see: www.recyclethis.info
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements.
1. This device complies with Industry Canada licence-exempt RSS standard(s). Operation is
subject to the following two conditions: this device may not cause interference, and
2. this device must accept any interference, including interference that may cause undesired
operation of the device.
1. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radioexempts de licence. L'exploitation est autorisée aux deux conditions suivantes : l'appareil
ne doit pas produire de brouillage, et
2. l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a
type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce
potential radio interference to other users, the antenna type and its gain should be so chosen that
the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful
communication.
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut
fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour
l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à
l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la
puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à
l'établissement d'une communication satisfaisante.
This equipment should be installed and operated with a minimum distance 20cm between the
radiator and your body.
Cet équipement doit être installé et utilisé à une distance minimale de 20 cm entre le radiateur et
votre corps.

Thermal Monocular User Manual
v
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Symbol
Description
Danger
Indicates a hazardous situation which, if not avoided, will or could
result in death or serious injury.
Caution
Indicates a potentially hazardous situation which, if not avoided,
could result in equipment damage, data loss, performance
degradation, or unexpected results.
Note
Provides additional information to emphasize or supplement
important points of the main text.

Thermal Monocular User Manual
vi
Safety Instruction
These instructions are intended to ensure that user can use the product correctly to avoid danger
or property loss.
Laws and Regulations
●Use of the product must be in strict compliance with the local electrical safety regulations.
Transportation
●Keep the device in original or similar packaging while transporting it.
●Keep all wrappers after unpacking them for future use. In case of any failure occurred, you need
to return the device to the factory with the original wrapper. Transportation without the
original wrapper may result in damage on the device and the company shall not take any
responsibilities.
●DO NOT drop the product or subject it to physical shock. Keep the device away from magnetic
interference.
Power Supply
●Please purchase the charger by yourself. Input voltage should meet the Limited Power Source (5
VDC, 2A) according to the IEC61010-1 standard. Please refer to technical specifications for
detailed information.
●Make sure the plug is properly connected to the power socket.
●DO NOT connect multiple devices to one power adapter, to avoid over-heating or fire hazards
caused by overload.
Battery
●Improper use or replacement of the battery may result in explosion hazard. Replace with the
same or equivalent type only. The battery type is CR123A*2/RCR123A*2. Dispose of used
batteries in conformance with the instructions provided by the battery manufacturer.
●For long-term storage of the battery, make sure it is fully charged every half year to ensure the
battery quality. Otherwise, damage may occur.
●Do not charge other battery types with the supplied charger. Confirm there is no flammable
material within 2 m of the charger during charging.
Maintenance
●If the product does not work properly, please contact your dealer or the nearest service center.
We shall not assume any responsibility for problems caused by unauthorized repair or
maintenance.
●A few device components (e.g., electrolytic capacitor) require regular replacement. The average
lifespan varies, so periodic checking is recommended. Contact your dealer for details.
●Wipe the device gently with a clean cloth and a small quantity of ethanol, if necessary.
●If the equipment is used in a manner not specified by the manufacturer, the protection
provided by the device may be impaired.

Thermal Monocular User Manual
vii
●It is recommended to reboot the device every 2 hours when using it to ensure the device
performance.
Using Environment
●Make sure the running environment meets the requirement of the device. The operating
temperature shall be -20°C to 55°C (-4°F to 131°F), and the operating humidity shall be 95% or
less.
●DO NOT expose the device to high electromagnetic radiation or dusty environments.
●DO NOT aim the lens at the sun or any other bright light.
Emergency
●If smoke, odor, or noise arises from the device, immediately turn off the power, unplug the
power cable, and contact the service center.
Manufacture Address
Room 313, Unit B, Building 2, 399 Danfeng Road, Xixing Subdistrict,Binjiang District, Hangzhou,
Zhejiang 310052, China
Hangzhou Microimage Software Co., Ltd.
COMPLIANCE NOTICE: The thermal series products might be subject to export controls in various
countries or regions, including without limitation, the United States, European Union, United
Kingdom and/or other member countries of the Wassenaar Arrangement. Please consult your
professional legal or compliance expert or local government authorities for any necessary export
license requirements if you intend to transfer, export, re-export the thermal series products
between different countries

Thermal Monocular User Manual
Table of Contents
Chapter 1 Overview....................................................................................................................1
1.1 Device Description.................................................................................................................1
1.2 Main Function........................................................................................................................1
1.3 Appearance............................................................................................................................1
1.3.1 Button.........................................................................................................................2
1.3.2 Interface......................................................................................................................3
Chapter 2 Preparation................................................................................................................5
2.1 Connect Device......................................................................................................................5
2.2 Install Battery ........................................................................................................................5
2.2.1 Select Battery Type ....................................................................................................6
2.3 Install Adapter.......................................................................................................................6
2.4 Remove Adapter....................................................................................................................7
2.5 Install Daylight Scope............................................................................................................7
2.6 Power On/Off ........................................................................................................................8
2.7 Menu Description..................................................................................................................8
Chapter 3 Image Settings............................................................................................................9
3.1 Adjust Diopter .......................................................................................................................9
3.2 Adjust Brightness...................................................................................................................9
3.3 Adjust Contrast......................................................................................................................9
3.4 Select Scene.........................................................................................................................10
3.5 Set Palettes..........................................................................................................................10
3.6 Correct Defective Pixel........................................................................................................12
3.7 Flat Field Correction ............................................................................................................12
3.8 Set Picture in Picture Mode ................................................................................................13
3.9 Adjust Digital Zoom.............................................................................................................13
3.10 Set OSD ..............................................................................................................................14
3.10.1 Synchronize Time ...................................................................................................14
3.11 Calibrate Image .................................................................................................................14

Thermal Monocular User Manual
Chapter 4 Burning Prevention ..................................................................................................15
Chapter 5 Highest Temperature Tracking..................................................................................16
Chapter 6 Measure Distance.....................................................................................................17
Chapter 7 Picture and Video.....................................................................................................19
7.1 Capture Picture....................................................................................................................19
7.2 Record Video .......................................................................................................................19
7.3 Export Files ..........................................................................................................................20
Chapter 8 Client Software Connection ......................................................................................21
Chapter 9 CVBS Output ............................................................................................................22
9.1 Cable Connection.................................................................................................................22
Chapter 10 Language Settings...................................................................................................23
Chapter 11 Maintenance ..........................................................................................................24
11.1 View Device Information ..................................................................................................24
11.2 Upgrade Device .................................................................................................................24
11.3 Restore Device...................................................................................................................24
Chapter 12 Frequently Asked Questions ...................................................................................25
12.1 Why is the monitor off? ....................................................................................................25
12.2 The image is not clear, how to adjust it? .........................................................................25
12.3 Capturing or recording fails. What's the problem? .........................................................25
12.4 Why the PC cannot identify the device? ..........................................................................25
Chapter 13 Appendix................................................................................................................26
13.1 Reticle Correction..............................................................................................................26
13.1 Device Command...............................................................................................................26
13.2 Device Communication Matrix .........................................................................................26

Thermal Monocular User Manual
1
Chapter 1 Overview
1.1 Device Description
The thermal monocular is equipped with high-sensitivity IR detector, and adopts advanced
thermal imaging technology, to get clear view in poor visibility or dark environment.
It helps to view the target and measure the distance in outdoor condition. The device can be
widely used for patrolling, searching and rescuing, hiking, and travel, etc.
1.2 Main Function
●Distance Measurement: The device can detect the distance between the target and the device.
●Highest Temperature Tracking: The device can detect the highest temperature in the scene and
mark the spot.
●Client Software Connection: The device can capture snapshots, record videos, and set
parameters by T-Vision App after being connected to your phone via hotspot.
●Image Correction: The device supports DPC (Defective Pixel Correction) and FFC (Flat Field
Correction) which can optimize the image quality.
●Image Calibration: The device adjusts the thermal view to make it consistent with the optical
view.
1.3 Appearance
There are two types of thermal monocular cameras. Please take the actual product for reference.

Thermal Monocular User Manual
2
1.3.1 Button
Figure 1-1 Buttons on Device
Table 1-1 Function of Buttons
No
Icon
Button
Description
1
Power
●Press: Standby Mode/Wake up Device
●Hold: Power On/Off
2
Capture
●Press: Capture
●Hold: Start/Stop Video Recording
3
Shutter
●Press: Correct Non-uniformity of Display
4
Zoom
●Press: Switch Digital Zoom
●Hold: Enable/Disable Reticle
5
Menu
●Press: Enable/Disable OSD
●Hold: Menu Operation
6
Mode
●Press: Switch Palettes
2 + 4
+
Capture + Zoom
●Press: Enter Image Calibration Mode

Thermal Monocular User Manual
3
1.3.2 Interface
Figure 1-2 Interfaces of Device
Table 1-2 Interface Description
No
Component
Function
1
Lens Cover
Protect the lens.
2
Objective Lens
Adjust the distance between the lens and the sensor to

Thermal Monocular User Manual
4
No
Component
Function
view the target much clearer.
3
Data Exchange
Interface
Connect with the output cable.
4
Fixing Ring
Fix the adapter.
5
Battery
Compartment
Install the battery in it.
6
Bolt
Loosen the bolt to install the batteries.
7
Locking Ring
Lock the adapter with the device.
8
Adapter
Connect with a daylight scope.

Thermal Monocular User Manual
5
Chapter 2 Preparation
2.1 Connect Device
Before You Start
●Remove batteries from the device before connecting to your PC, or it may cause device damage.
●Turn on the device after connecting it to your PC, and keep the device on for 10 to 15 seconds
before other operations.
Steps
1. Turn on the device and make sure the hotspot function is disabled.
2. Lift the cable interface cover.
3. Connect the device and power adapter with a type-C cable to power on the device.
Alternatively, connect the device and PC to export files.
Figure 2-1 Cable Interface
2.2 Install Battery
Insert the batteries into the battery compartment.
Before You Start
●The device supports 3.0 V or 3.7 V rechargeable lithium battery or 3.0 V non-rechargeable dry
battery.
●Select the correct battery voltage in the device menu, or it may cause abnormal shutdown.
Steps
1. Rotate the bolt anticlockwise to loosen it.

Thermal Monocular User Manual
6
Figure 2-2 Loosen Hand Screw
2. Make sure the battery's positive terminal and negative terminal are installed correctly.
Figure 2-3 Install Batteries
3. Rotate the hand screw clockwise to tighten it.
Take the battery away if the device is not used for a long time.
2.2.1 Select Battery Type
The device supports multiple types of batteries and you can change the battery type according to
your need. Select the battery voltage according to the actual situation, so that the device can
display the remaining power correctly.
Steps
1. In the view mode, hold to show the menu.
2. Select , and press to switch the voltage.
2.3 Install Adapter
Steps
1. Make sure the red dot of the adapter align with the red dot of the eyepiece, and insert the
adapter as arrow 1.
2. Rotate the locking ring anticlockwise (as arrow 2 shows).

Thermal Monocular User Manual
7
Figure 2-4 Install Adapter
Note
The selectable types of the adapter are 38, 40, 50, and 62.
2.4 Remove Adapter
Steps
1. Rotate only the locking ring clockwise, and make sure the device or other parts of the adapter
are not rotated or moved.
2. Plug out the adapter after it is loosen.
2.5 Install Daylight Scope
You can use the device together with a daylight scope to view the target clear in daytime.
Steps
1. Install the daylight scope into the transfer ring as arrow 1.
2. Lock the buckle to fix the daylight scope as arrow 2.
Figure 2-5 Install Daylight Scope

Thermal Monocular User Manual
8
2.6 Power On/Off
Power On
When the battery is enough, press to power on the device.
Power Off
When the device is turned on, hold for 2 seconds to power off the device.
2.7 Menu Description
When the device is turned on, press to display the OSD menu.
●Press to move the cursor up.
●Press to move the cursor down.
●Press to move the cursor left.
●Press to move the cursor right.
●Press to confirm.
Figure 2-6 Menu Interface

Thermal Monocular User Manual
9
Chapter 3 Image Settings
3.1 Adjust Diopter
Steps
1. Power on the device.
2. Open the lens cover.
3. Hold the device and make sure the eyepiece covers your eye.
4. Rotate the adjust ring until the OSD text or image is clear.
Figure 3-1 Adjust Diopter
Note
When adjusting diopter, DO NOT touch the surface of lens to avoid smearing the lens.
3.2 Adjust Brightness
In the menu mode, select and press to adjust brightness. In white hot mode, the higher
the value of brightness is, the brighter the image is. The image effect in white hot mode is showed
as picture below and effect in black hot mode is opposite.
Figure 3-2 Adjust Brightness in White Hot Mode
3.3 Adjust Contrast
In the menu mode, select and press to adjust image contrast.

Thermal Monocular User Manual
10
3.4 Select Scene
You can select proper scene according to actual using scene to improve the display effect.
Steps
1. Hold to go to the menu.
2. Select and press to switch scene.
–refers to recognition mode and is recommended in normal scene.
–refers to jungle mode and is recommended in hunting environment.
3. Hold to save settings and exit.
3.5 Set Palettes
You can select different palettes to display the same scene in different effects. Press to
switch palettes.
White Hot
The hot part is light-colored in view. The higher the temperature is, the lighter the color is.
Black Hot
The hot part is black-colored in view. The higher the temperature is, the more black the color is.
