HIKOKI RB 27EAP User manual

Blower
Model RB 27EAP / RB 27EP
Handling instructions
Note:
Before using this machine, carefully read through these HANDLING INSTRUCTIONS
to ensure efficient, safe operation. It is recommended that these INSTRUCTIONS be
kept readily available as an important reference when using this machine.
RB 27EAP
00BookRB27EAPAUST.indb100BookRB27EAPAUST.indb1 2018/12/149:23:582018/12/149:23:58

2
MEANINGS OF SYMBOLS
NOTE: Some units do not carry them.
Symbols
WARNING
The following show symbols used for the machine. Be sure that you understand their meaning before use.
Blower Idle speed adjustment
It is important that you read, fully understand before
use, and observe the following safety precautions and
warnings. Careless or improper use of the unit may
cause serious or fatal injury.
Priming pump
Read, understand and follow all warnings and
instructions in this manual and on the unit. Guaranteed sound power level
Always wear eye, head and ear protectors when using
this unit. Displacement
Choke – Run position (Open) Spark plug
Choke – Start position (Closed) Fuel tank capacity
START
On/Start Dry weight (without fuel, with all pipe)
STOP
Off/Stop
LpA, eq
ISO22868
Sound pressure level LpA by ISO 22868 Equivalent*
WARNING DANGER
Keep hands offfrom rotating fan.
LWA, Ra(M)
2000/14/EC
Measured sound power level LwA by 2000/14/EC
Racing
WARNING DANGER
Hot surfaces; The muffler and surrounding cover may
become extremely hot. Always keep clear of exhaust
and muffler area, otherwise serious personal injury
may occur.
LWA, Ra(G)
2000/14/EC
Guaranteed sound power level LwA by 2000/14/EC
Racing
Keep all children, bystanders and helpers 15 m away
from the unit. If anyone approaches you, stop the
engine immediately.
ahv, eq
Vibration level by ISO 22867
Equivalent*
Fuel and oil mixture KUncertainty
Before using your machine
• Read the manual carefully.
• Check that the cutting equipment is correctly assembled and adjusted.
• Start the unit and check the carburetor adjustment. See “MAINTENANCE”.
NOTE: Equivalent noise level / vibration level are calculated as the time-weighted energy total for noise / vibration levels under various
working conditions with the following time distribution:
* 1/7 Idle, 6/7 racing.
00BookRB27EAPAUST.indb200BookRB27EAPAUST.indb2 2018/12/149:23:582018/12/149:23:58

3
WHAT IS WHAT?
Since this manual covers several models, there may be some
difference between pictures and your unit. Use the instructions that
apply to your unit.
A. Fuel cap
B. Throttle trigger
C. Starter handle
D. Fuel tank
E. Carburetor
F. Air cleaner
G. Handle
H. Ignition switch
I. Straight pipe
J. Conic pipe
K. Guard net
L. Spark plug
M. Choke lever
N. Priming bulb
O. Recoil starter
P. Fan-headed pipe
Q. Cruise lever
R. Combi box spanner
S. Handling instructions
T. Knob vol t
U. Vacuum pipe
V. Bent pipe
W. Dust bag
X. Anti-static-electricity pad
G
H
I
D
B
A
C
E
F
L
M
K
P
O
N
Q
K
D
F
B
E
G
I
H
A
C
J
L
M
O
N
RS U
W
V
X
RB 27EAP
RB 27EP
T
00BookRB27EAPAUST.indb300BookRB27EAPAUST.indb3 2018/12/149:23:582018/12/149:23:58

4
WARNING
○Always operate the tool with proper protective equipment and
clothing. Failure to do so may result in accidents such as burns
or injuries. (Fig. 1)
○Do not touch the spark plug area or high voltage during
operation. Doing so may result in electric shock.
○Do not allow children near the tool during operation.
○Do not touch the engine, top cover or exhaust vent during or
shortly after operation. Doing so may result in burn or injury.
○Antivibration systems do not guarantee that you will not sustain
Hand-Arm Vibration Syndrome or carpal tunnel syndrome.
Therefore, continual and regular users should monitor closely
the condition of their hands and fingers. If any of the above
symptoms appear, seek medical advice immediately.
○Since this product is engine driven, make sure to wear the
proper protective equipment to minimize the effects of vibration
and sound to your body. Limit a single continuous operation
between 30 to 40 minutes, and rest for 10 to 20 minutes. Also,
limit your day’s work time to 80 minutes.
○If you are using any medical electric/electronic devices such
as a pacemaker, consult your physician as well as the device
manufacturer prior to operating any power equipment.
○If trash or collected waste including fallen leaves become
trapped in the machine, make sure to cut the engine and
remove the debris before resuming use. Using the machine
without removing the obstructions may result in damage.
Unit/machine safety
○Inspect the entire unit/machine before each use. Replace
damaged parts. Check for fuel leaks and make sure all
fasteners are in place and securely tightened.
○Replace parts that are cracked, chipped or damaged in any
way before using the unit/machine. Faulty parts may increase
the risk of accidents and may lead to an injury.
○Keep others away when making carburetor adjustments.
○Use only accessories as recommended for this unit/machine by
the manufacturer.
○Before operation, make sure that there are no tools such as the
adjustment key or spanner still attached to the unit.
WARNING
○Never modify the unit/machine in any way. Do not use your unit/
machine for any job except that for which it is intended.
○Non-authorized modifications and/or accessories may result in
serious personal injury or the death of the operator or others.
○The guard net must be firmly fixed in place.
Fuel safety
○Mix and pour fuel outdoors and where there are no sparks or
flames.
○Use a container approved for fuel.
○Move at least 3 m away from fueling site before starting engine.
○Stop engine before removing fuel cap. Do not remove the fuel
cap during operation.
○Empty the fuel tank before storing the unit/machine. It is
recommended that the fuel be emptied after each use. If fuel is
left in the tank, store so fuel will not leak.
WARNING
○Fuel is easy to ignite or get explosion or inhale fumes, so that
pay special attention when handling or filling fuel.
○Do not smoke or allow smoking near fuel or the unit/machine or
while using the unit/machine.
○Wipe up all fuel spills before starting engine.
○Store unit/machine and fuel in area where fuel vapors cannot
reach sparks or open flames from water heaters, electric
motors or switches, furnaces. etc.
○When using the unit in dry areas, make sure that fire
extinguishing equipment is readily available.
○If you shut offthe engine for refueling, make sure the unit has
cooled down before adding fuel.
WARNINGS AND SAFETY INSTRUCTIONS
Pay special attention to statements preceded by the following
words:
WARNING
Indicates a strong possibility of severe personal injury or loss of
life, if instructions are not followed.
CAUTION
Indicates a possibility of personal injury or equipment damage,
if instructions are not followed.
NOTE
Helpful information for correct function and use.
Operator safety
○Wear head protection (1). (Fig. 1)
○Always wear a safety face shield or goggles (2). (Fig. 1)
○Wear approved hearing protection (3). (Fig. 1)
Long-term exposure to noise can result in permanent hearing
impairment.
Pay attention to your surroundings. Be aware of any bystanders
who may be signaling a problem.
Remove safety equipment immediately upon shutting off
engine.
○Always wear heavy, long-sleeved shirts (4) and long pants (5)
and non-slip boots (6) and gloves (7). (Fig. 1)
Do not wear loose clothing, jewelry, short pants, sandals or go
barefoot.
Secure hair so it is above shoulder length.
1
4
2
5
3
6
7
Fig.1
○Do not operate this tool when you are tired, ill or under the
influence of alcohol, drugs or medication.
○Do not operate the tool at night or under bad weather conditions
when visibility is poor. And do not operate the tool when it is
raining or right after it has been raining.
Working on slippery ground could lead to an accident if you
lose your balance.
○Never let a child or inexperienced person operate the machine.
○Do not start the engine if there are any flammables such as dry
leaves, waste paper or fuel in the vicinity.
○Never start or run the engine inside a closed room or building.
Breathing exhaust fumes can kill.
○Keep handles free of oil and fuel.
○Keep hands away from moving part or heated area.
○Do not grab or hold the unit by the blow pipe.
○When the unit is turned offmake sure the engine has stopped
before the unit is set down.
○When operation is prolonged, take a break periodically so that
you may avoid possible Hand-Arm Vibration Syndrome (HAVS)
which is caused by vibration.
00BookRB27EAPAUST.indb400BookRB27EAPAUST.indb4 2018/12/149:23:592018/12/149:23:59

5
Blowing safety
○Operate unit/machine only at reasonable hours – not
early in the morning or late at night when people might be
disturbed. Comply with times listed in local ordinances. Usual
recommendations are 9:00 a.m. to 5:00 p.m., Monday through
Saturday.
○Never direct discharge of air toward bystanders nor allow
anyone near the area of operation. Use care in directing
discharge to avoid glass enclosures, automobiles, etc.
○Check the work area and surroundings for empty cans, metal
pieces and other obstructions which could cause injury,
accident or damage. If there are any of these objects in the
area, remove them in advance.
○Stay alert for uneven sidewalks, holes in terrain or other
unstable condition when using the tool.
○Take all possible precautions when leaving the tool unattended
such as stopping the engine.
○Never operate the tool without blow pipes or other protective
device in place. (If so equipped.)
○Keep others including children, animals, bystanders and
helpers outside the 15 m hazard zone. Stop the engine
immediately if you are approached.
○Please exercise caution as engine startup may be delayed after
pulling the starter handle.
○Always keep the engine on the right side of your body.
○Keep firm footing and balance. Do not over-reach.
Losing your balance during work may lead to an injury.
○Keep all parts of your body away from the muffler when the
engine is running.
○Always carry a first-aid kit when operating any power
equipment.
○Avoid prolonged use at low speed range in which vibration is
high. Doing so may result in engine damage.
○When relocating to a new work area, or inspecting, adjusting or
exchanging the unit's accessories, etc., be sure to shut offthe
machine.
○Never place the machine on the ground when running.
○If you accidentally bump or drop the unit, inspect it immediately
to make sure there are no damage, cracks or deformations.
○If the tool is operating poorly and produces strange noise or
vibrations, turn offthe engine immediately and ask your dealer
to have it inspected and repaired.
Continued use under these conditions could lead to injury or
tool damage.
○Use in accordance with local laws and regulations.
○Loosen deposits with a rake or a broom before starting any
exhaust or vacuum work.
WARNING
Work from ladders or high place (such as roofs) is
prohibited and could result in severe injury.
Maintenance safety
○Maintain the unit/machine according to recommended
procedures.
○Disconnect the spark plug before performing maintenance
except for carburetor adjustments.
○Keep others away when making carburetor adjustments.
○Use only genuine HiKOKI replacement parts as recommended
by the manufacturer.
CAUTION
Do not disassemble the recoil starter. There is a possibility of
personal injury with recoil spring.
WARNING
Improper maintenance could result in serious engine damage
or in serious personal injury.
Transport and storage
○Carry the unit/machine by hand with the engine stopped and
the muffler away from your body.
○Allow the engine to cool, empty the fuel tank, and secure the
unit/machine before storing or transporting. Failure to do so
may result in fire or accidents.
○Empty the fuel tank before storing the unit/machine. It is
recommended that the fuel be emptied after each use. If fuel is
left in the tank, store so fuel will not leak.
○Store unit/machine out of the reach of children.
○Clean and maintain the unit carefully and store it in a dry place.
○Make sure engine switch is offwhen transporting or storing.
○You have to secure the machine during transport to prevent
loss of fuel, damage or injury.
○If a warning label cannot be read, peels offor becomes
indistinct, replace it with a new one. To purchase new labels,
contact HiKOKI Authorized Service Centers.
If situations occur which are not covered in this manual, take care
and use common sense. Contact HiKOKI Authorized Service
Centers if you need assistance.
SPECIFICATIONS
Model RB27EAP RB27EP
(cm3)26.9
— TORCH L7RTC (NGK BPMR7A)
(kg) 4.2 4.4
(cm3)400
LpA, eq /
K(dB(A)) 97 / 1.8
LWA, Ra(M) (dB(A)) 107
LWA, Ra(G) (dB(A)) 108
ahv, eq
/ K(m/s2) 12.0 / 1.0
ASSEMBLY PROCEDURES
WARNING
Make sure the engine is turned off/stopped and not hot before
assembly.
Blow pipes to main body (Fig. 2)
Inspect the main body and accessories.
Connect straight pipe (8) securely. Align projection (9) in straight
pipe with groove (10) on blower housing and slide the pipe into the
blower housing.
Rotate the pipe clockwise to lock it into place.
89
10
1
2
Fig. 2
00BookRB27EAPAUST.indb500BookRB27EAPAUST.indb5 2018/12/149:23:592018/12/149:23:59

6
Nozzle to straight pipe (Fig. 3 - 4)
[RB27EAP]
○Align groove (12) on the conic pipe (13) and projection (11) on
straight pipe (8) and rotate the conic pipe in place.
1
2
12
13 11
8
Fig. 3
[RB27EP]
○Align groove (12) on the Fan-Headed pipe (14) and projection
(11) on straight pipe (8) and rotate the Fan- Headed pipe in
place.
2
1
8
11
1214
Fig. 4
Vacuum assembly [RB27EP]
NOTE ; Safety future
If you try to open the guard net (15) when engine is running, it will
automatically stop the engine. (Fig. 5)
But never try to open the guard net (15) when engine is running
even with this future, otherwise serious personal injury may occur.
Vacuum pipe to main body
• Loosen knob bolt (16). (Fig. 5)
16 15
Fig. 5
• Align the arrow(21) on the vacuum pipe (20) and the arrow (18)
on the fan case (17) as shown Fig. 6. (Fig. 6, 7)
17 18 19
Fig. 6
17
20
21
Fig. 7
• Slide(1) the vacuum pipe into the fan case, and then rotate(2)
the vacuum pipe clockwise(19) as shown Fig. 6 until it clicks.
(Fig. 8)
1
2
Fig. 8
Bent pipe and dust bag to main body
• Connect bent pipe (22), Align projection (23) in bent pipe with
groove (10) on blower housing and slide the pipe onto the
blower housing. Rotate the pipe clockwise to lock it into place.
(Fig. 9)
23 10
22
1
2
Fig. 9
00BookRB27EAPAUST.indb600BookRB27EAPAUST.indb6 2018/12/149:23:592018/12/149:23:59

7
• Connect the dust bag to the installed bent pipe (22) by inserting
the thinner part of the pipe into the opening of the bag. Fasten
the adjuster (24) securely by taping the end of the sawn strap.
(Fig. 10)
22
24
Fig. 10
WARNING
Always connect dust bag (26) to bent pipe (22).
Never try to connect directly to main body (25), otherwise dust bag
might approach near exhaust of muffler and it might cause fires or
injuries. (Fig. 11)
25
26
22
Fig. 11
CAUTION
Static electricity may be generated while vacuuming. Prior to
engaging in the task, attach the anti-static-electricity pad (27)
to the handle and make sure to grip the pad when vacuuming.
• Connect the terminal extending from the engine (28) to the
terminal of the anti-static-electricity pad (29). Next, attach the
anti-static-electricity pad (27) to the handle as shown in the
Fig. 12.
29
28
27
Fig. 12
OPERATING PROCEDURES
Fuel (Fig. 13)
Fig. 13
WARNING
○The unit/machine is equipped with a two-stroke engine. Always
run the engine on fuel, which is mixed with oil.
Provide good ventilation, when fueling or handling fuel.
○Fuel contains highly flammable and it is possible to get the
serious personal injury when inhaling or spilling on your body.
Always pay attention when handling fuel. Always have good
ventilation when handling fuel inside building.
Fuel
○Always use branded 89 octane unleaded gasoline.
○Use genuine two-cycle oil or use a mix between 25:1 to 50:1,
please consult the oil bottle for the ratio or HiKOKI Authorized
Service Centers.
○If genuine oil is not available, use an anti-oxidant added quality
oil expressly labeled for air-cooled 2-cycle engine use (JASO
FC GRADE OIL or ISO EGC GRADE). Do not use BIA or TCW
(2-stroke water-cooling type) mixed oil.
○Never use for four-stroke engine oil or waste oil.
○Always mix fuel and oil in a separate clean container.
Always start by filing half the amount of fuel, which is to be used.
Then add the whole amount of oil. Mix (shake) the fuel mixture. Add
the remaining amount of fuel.
Mix (shake) the fuel-mix thoroughly before filling the fuel tank.
Fueling
WARNING
○Always shut offthe engine and let it cool for a few minutes
before refueling.
○Slowly open the fuel tank, when filling up with fuel, so that
possible over-pressure disappears.
○Tighten the fuel cap carefully, after fueling.
○Always move the unit at least 3 m from the fueling area before
starting.
○Do not smoke and/or allow flames or sparks near fuel when
handling or filling fuel.
○Always wash any spilled fuel from clothing immediately with
soap.
○Be sure to check for any fuel leakage after refueling.
Before fueling, clean the tank cap area carefully, to ensure that
no dirt falls into the tank. Make sure that the fuel is well mixed by
shaking the container, before fueling.
00BookRB27EAPAUST.indb700BookRB27EAPAUST.indb7 2018/12/149:23:592018/12/149:23:59

8
Starting
CAUTION
Do not start if the pipe and guard net is obstructed.
(1) Starting the cold engine
1. Check the switch (30) to ON position. (Fig. 14)
30 ON
Fig. 14
2. Push priming bulb (31) about ten times so that fuel flows into
carburetor. (Fig. 15)
31
Fig. 15
3. Set choke lever to CLOSED position. (Fig. 16)
CLOSED
RUN (OPEN)
Fig. 16
4. Pull starter handle briskly, taking care to keep the handle in
your grasp and not allowing it to snap back. (Fig. 17)
Fig. 17
5. When you hear the engine want to start, return choke lever to
RUN position (open).
6. Then pull starter handle briskly again.
NOTE
If engine does not start, repeat procedures from 2 to 6.
7. After starting engine, allow the engine about 2–3 minutes to
warm up before subjecting it to any load.
(2) Starting the warm engine
Use only 1, 2 and 6 of the starting procedure for a cold engine.
If the engine does not start, use the same starting procedure as
for a cold engine.
Operating blower (Fig. 18)
○A low speed should be used to blow leaves and dry grass.
○A medium speed should be used to clean wet leaves and grass.
○A high speed should be used when moving gravel, dirt or other
heavy materials.
○When working in a dusty area, hose down the area with water.
Fig. 18
WARNING
○Do not direct discharge of air toward people or pet.
○The unit should be operated in a well ventilated area.
○Never perform assembly or disassembly procedures with
engine running or serious personal injury may result.
○Never touch muffler, spark plug, or other metallic parts while
engine is in running or immediately after shutting offengine.
○Do not use this blower indoors.
○Do not operate if there is an open window near the work area
and its surroundings.
CAUTION
This blower has been designed and adjusted to be used with
blowing pipes attached. It must never be operated without the
straight pipe.
NOTE
Blowing Pipe Selection
• Straight Blowing Pipe
Allows operation at maximum blow capacity.
Suitable for operation in widespread areas, engine revolution
is kept at a minimum, resulting in improved fuel consumption
when compared with the conic/fan-shaped blowing pipe.
The straight blowing pipe is recommended for normal use.
• Conic/Fan-Shaped Blowing Pipe
Allows operation at maximum blow speed.
Ideal for blowing wet leaves stuck to the ground or releasing a
powerful air discharge in limited spaces.
Operating vacuum (Fig. 19)
WARNING
Do not vacuum bottles, cans or any other hard materials,
which may cause damage or serious injuries.
○Do not use a bag with holes or tears in it. Even a small hole
can cause a lot of dust to come out. Repair or replace it
immediately.
○Make sure zipper of the bag is completely closed.
00BookRB27EAPAUST.indb800BookRB27EAPAUST.indb8 2018/12/149:23:592018/12/149:23:59

9
○Wear shoulder strap over right or left shoulder.
○Make sure bevel at end of suction pipe faces downward.
○The unit should be operated In a well ventilated area.
○Use rakes and brooms to loosen debris before vacuuming.
○A low speed should be used to vacuum small leaves and dry
grass.
○A medium speed should be used to vacuum large leaves and
grass.
○A high speed should be used to vacuum larger or wet leaves
and grass.
○Dispose of debris in the bag more frequently in dusty condition.
Fig. 19
NOTE
When you hear or feel strange sound or vibration, stop engine
immediately and check if anything blocks fans or pipes, If so,
remove it and check for damage.
Stopping (Fig. 20)
Decrease engine speed and run at an idle for a few minutes, then
turn offignition switch (30).
30
OFF
Fig. 20
MAINTENANCE
MAINTENANCE, REPLACEMENT OR REPAIR OF THE EMISSION
CONTROL DEVICES AND SYSTEMS MAY BE PERFORMED BY ANY
NON-ROAD ENGINE REPAIR ESTABLISHMENT OR INDIVIDUAL.
Carburetor adjustment (Fig. 21)
The carburetor is a precision part that mixes air and fuel, and it is
designed to ensure high performance from the engine. Before the
tool is shipped from the factory, its carburetor is adjusted during
a test run. Only make adjustments if it is necessary because of
environmental conditions (the climate or atmospheric pressure), the
type of fuel, the type of two-cycle oil, etc.
WARNING
○Because the carburetor is manufactured with a high degree of
precision, do not disassemble it.
○For this product, the only setting of the carburetor that can be
adjusted is the idle speed (T).
T = Idle speed adjustment screw.
Idle speed adjustment (T)
Check that the air filter is clean. If adjustment is required, turn
IDLE speed Adjustment Screw (T) close (clockwise) to increase
engine speed, open (counterclockwise) to decrease engine speed.
Standard Idle rpm is 2800-3200 rpm.
CAUTION
The above adjusting procedure must be followed when
adjustment is MADE or DAMAGE to engine will occur because
of the incorrect condition.
NOTE
Some models sold areas with strict exhaust emission
regulation do not have high and low speed carburetor
adjustments. Such adjustments may allow the engine to be
operated outside of their emission compliance limits. For these
models, the only carburetor adjustment is idle speed.
Fig. 21
RECOMMENDATION
CARBURETOR ADJUSTMENT NEEDS THE SKILL OF
EXPERIENCED OR WELL TRAINED PEOPLE, OR IS
RECOMMENDED TO TAKE THE UNIT TO HiKOKI AUTHORIZED
SERVICE CENTERS.
Air filter (Fig. 22)
The air filter must be cleaned from dust and dirt in order to avoid:
○Carburetor malfunctions
○Starting problems
○Engine power reduction
○Unnecessary wear on the engine parts
○Abnormal fuel consumption
Clean the air filter daily or more often if working in exceptionally
dusty areas.
Fig. 22
Cleaning the air filter
Open the air filter cover and remove the air filter. Clean it. Check
that the filter is dry before reassembly. An air filter that has been
used for some time cannot be cleaned completely. Therefore, it
must regularly be replaced with a new one. A damaged filter must
always be replaced.
Fuel filter (Fig. 23)
Remove the fuel filter from the fuel tank, and replace it if it is dirty.
NOTE
A blocked fuel filter can prevent the supply of fuel and cause a
rotation malfunction of the engine.
00BookRB27EAPAUST.indb900BookRB27EAPAUST.indb9 2018/12/149:24:002018/12/149:24:00

10
Fig. 23
Spark plug (Fig. 24)
When removing the spark plug, twist and remove the plug cap
covering the spark plug as shown in the illustration. (Fig. 25)
The spark plug condition is influenced by:
○An incorrect carburetor setting
○Wrong fuel mixture (too much oil in the gasoline)
○A dirty air filter
○Hard running conditions (such as cold weather)
These factors cause deposits on the spark plug electrodes, which
may result in malfunction and starting difficulties. If the engine
is low on power, difficult to start or runs poorly at idling speed,
always check the spark plug first. If the spark plug is dirty, clean it
and check the electrode gap. Re-adjust if necessary. The correct
gap is 0.6 mm. The spark plug should be replaced after about 100
operation hours or earlier if the electrodes are badly eroded.
0.6 mm
Fig. 24
Fig. 25
NOTE
In some areas, local law requires using a resistor spark plug
to suppress ignition signals. If this machine was originally
equipped with resistor spark plug, use same type of spark plug
for replacement.
For long-term storage
Drain all fuel from the fuel tank. Start and let engine run until it
stops. Repair any damage which has resulted from use. Clean the
unit with a clean rag, or the use of high pressure air hose. Put a few
drops of two-cycle engine oil into the cylinder through the spark
plug hole, and spin the engine over several times to distribute oil.
Cover the unit and store it in a dry area.
Maintenance schedule
Below you will find some general maintenance instructions. For
further information please contact your HiKOKI Authorized Service
Centers.
Daily maintenance
○Clean the exterior of the unit.
○Check that the air intake at the guard net is not clogged.
○Check the guard net for damage or cracks. Change the guard
net in case of impacts or cracks.
○Check that nuts and screws are sufficiently tightened.
Weekly maintenance
○Check the starter, especially the cord.
○Clean the exterior of the spark plug.
○Remove the spark plug and check the electrode gap. Adjust it
to 0.6 mm, or change the spark plug.
○Clean the air filter.
Monthly maintenance
○Rinse the fuel tank with gasoline, and clean fuel filter.
○Clean the exterior of the carburetor and the space around it.
Quarterly maintenance
○Clean the cooling fins on the cylinder.
○Clean the fan and the space around it.
○Clean the muffler of carbon.
CAUTION
Cleaning of cylinder fins, fan and muffler shall be done by a
HiKOKI Authorized Service Center.
SELECTING ACCESSORIES
The accessories of this machine are listed on page 11.
SELECTING ATTACHMENTS
Recommended accessories for each model are presented in the table below.
For purchases, contact HiKOKI Authorized Service Centers.
Please check carefully as those accessories not marked with “●” cannot be attached.
List of recommended accessories
Code No. Description RB27EAP RB27EP
6601600 NOZZLE (A) ●●
6698394 NOZZLE (B) ●●
6699184 FAN-HEADED PIPE ●●
6684946 VACUUM PIPE - ●
6601497 BENT PIPE - ●
6601601 DUST BAG - ●
6601500 EARTH GRIP - ●
00BookRB27EAPAUST.indb1000BookRB27EAPAUST.indb10 2018/12/149:24:032018/12/149:24:03

11
6601600
6698394
6684946
6601497
6684764
6699184
6601601
6601500
00BookRB27EAPAUST.indb1100BookRB27EAPAUST.indb11 2018/12/149:24:032018/12/149:24:03

901
Code No. E99703712 NA
Printed in China
Shinagawa Intercity Tower A, 15-1, Konan 2-chome,
Minato-ku, Tokyo, Japan
00BookRB27EAPAUST.indb1200BookRB27EAPAUST.indb12 2018/12/149:24:032018/12/149:24:03
