HIKOKI RB18DC User manual

RB18DC
Handling instructions
使用說明書
취급 설명서
Hướng dẫn sửdụng
คูมือการใชงาน
Petunjuk pemakaian
en
zh
ko
vi
th
ar
id
en
zh
ko
vi
th
id
ar
00BookRB18DCAsia.indb100BookRB18DCAsia.indb1 2021/10/2910:07:072021/10/2910:07:07

2
1
23
45
00BookRB18DCAsia.indb200BookRB18DCAsia.indb2 2021/10/2910:07:152021/10/2910:07:15

3
6
7
+ = + =
8
ab
9
10
00BookRB18DCAsia.indb300BookRB18DCAsia.indb3 2021/10/2910:07:162021/10/2910:07:16

4
English
c) Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking up
or carrying the tool.
Carrying power tools with your finger on the switch
or energising power tools that have the switch on
invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on.
A wrench or a key left attached to a rotating part of
the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times.
This enables better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away
from moving parts.
Loose clothes, jewellery or long hair can be caught in
moving parts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used.
Use of dust collection can reduce dust-related
hazards.
h) Do not let familiarity gained from frequent use
of tools allow you to become complacent and
ignore tool safety principles.
A careless action can cause severe injury within a
fraction of a second.
4) Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application.
The correct power tool will do the job better and safer
at the rate for which it was designed.
b) Do not use the power tool if the switch does not
turn it on and off.
Any power tool that cannot be controlled with the
switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools.
Such preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool.
Power tools are dangerous in the hands of untrained
users.
e) Maintain power tools and accessories. Check
for misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power toolʼs operation. If
damaged, have the power tool repaired before
use.
Many accidents are caused by poorly maintained
power tools.
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions and
the work to be performed.
Use of the power tool for operations different from
those intended could result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean
and free from oil and grease.
Slippery handles and grasping surfaces do not
allow for safe handling and control of the tool in
unexpected situations.
GENERAL POWER TOOL SAFETY
WARNINGS
WARNING
Read all safety warnings, instructions, illustrations and
specifications provided with this power tool.
Failure to follow all instructions listed below may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
power tool.
1) Work area safety
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust.
Power tools create sparks which may ignite the dust
or fumes.
c) Keep children and bystanders away while
operating a power tool.
Distractions can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools.
Unmodified plugs and matching outlets will reduce
risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators.
There is an increased risk of electric shock if your
body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions.
Water entering a power tool will increase the risk of
electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts.
Damaged or entangled cords increase the risk of
electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the
risk of electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply.
Use of an RCD reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired
or under the influence of drugs, alcohol or
medication.
A moment of inattention while operating power tools
may result in serious personal injury.
b) Use personal protective equipment. Always
wear eye protection.
Protective equipment such as a dust mask, non-skid
safety shoes, hard hat or hearing protection used for
appropriate conditions will reduce personal injuries.
00BookRB18DCAsia.indb400BookRB18DCAsia.indb4 2021/10/2910:07:172021/10/2910:07:17

5
English
5) Battery tool use and care
a) Recharge only with the charger specified by the
manufacturer.
A charger that is suitable for one type of battery pack
may create a risk of fire when used with another
battery pack.
b) Use power tools only with specifically
designated battery packs.
Use of any other battery packs may create a risk of
injury and fire.
c) When battery pack is not in use, keep it away
from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects,
that can make a connection from one terminal to
another.
Shorting the battery terminals together may cause
burns or a fire.
d) Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation or
burns.
e) Do not use a battery pack or tool that is damaged
or modified.
Damaged or modified batteries may exhibit
unpredictable behaviour resulting in fire, explosion
or risk of injury.
f) Do not expose a battery pack or tool to fire or
excessive temperature.
Exposure to fire or temperature above 130°C may
cause explosion.
g) Follow all charging instructions and do not
charge the battery pack or tool outside the
temperature range specified in the instructions.
Charging improperly or at temperatures outside
the specified range may damage the battery and
increase the risk of fire.
6) Service
a) Have your power tool serviced by a qualified
repair person using only identical replacement
parts.
This will ensure that the safety of the power tool is
maintained.
b) Never service damaged battery packs.
Service of battery packs should only be performed
by the manufacturer or authorized service providers.
PRECAUTION
Keep children and infirm persons away.
When not in use, tools should be stored out of reach of
children and infirm persons.
CORDLESS BLOWER SAFETY
WARNINGS
1. Do not put your hands or face near the cordless blower’s
blast port or suction port during use.
Doing so might lead to injuries.
2. When cleaning electrical conductors such as an
electrical panel, be sure there is plenty of space between
the conductor and the power tool. Also, make sure to
mount the nozzle when cleaning.
Failure to mount the nozzle while cleaning the conductor
can result in an electric shock.
3. Do not block the blast port and/or suction port. Also, do
not allow dust to accumulate in the suction port.
Blocking the blast port or suction port will abnormally
speed up the motor’s rotation which may damage the fan
within the power tool and cause the motor to excessively
heat up.
4. Do not use the power tool to fill a balloon or swim ring
with air.
5. Do not use in locations where inflammable materials
such as lacquer, paint, benzene, thinner or gasoline are
present. Also do not let items such as lighted cigarette
butts be suctioned inside at such locations.
Explosion or fires might result.
6. Do not use near objects generating high heat such as
stoves; do not blow at lit cigarette butts; and do not stoke
or extinguish flames.
Fires might occur if used near such locations.
7. Do not use in environments subject to heavy doses of
chemicals, etc.
Plastic sections might weaken and break, and injuries
might occur.
8. If you notice that the unit is generating unusually high
temperatures, operating poorly, or making abnormal
noises, immediately stop using and shut offthe power
switch. Request an inspection and repair from the dealer
where you purchased the unit or a HiKOKI Authorized
Service Center.
Continuing to use while operating abnormally might
cause injuries.
9. If the unit is mistakenly dropped or strikes another object,
make a thorough check of the unit for cracks, breakage
or deformation, etc.
Injuries might occur if the unit has cracks, breakage or
deformation.
10. Do not place objects such as screws inside the suction
port or blast port.
Failure to do so may damage the interior parts of the tool.
11. For blowing operation, mount the nozzle to the blast port.
For dust collection, mount the nozzle to the suction port
and mount the dust bag on the blast port.
12. Do not use the tool to suction liquid such as water or
wet dust particles, or items such as bits of glass, cutting
tools, nails, screws, pebbles, or lit cigarette butts.
13. Do not use industrial oil or grease (cutting oil, lubricant,
etc.), or in the vicinity of chemicals.
Doing so may cause parts to deteriorate or cause
damage.
14. Make a thorough inspection if using the cordless blower
to blow or clean viscous powder or dust particles.
Powder or dust particles might be suctioned in and
adhere internally, causing the vanes to break or injuries
to occur.
15. Never touch moving parts.
Never place your hands, fingers or other body parts near
the tool’s moving parts.
16. NEVER leave tool running unattended. Turn power off.
Don’t leave tool until it comes to a complete stop.
17. When operating the tool in high locations, make sure
there is nobody below.
18. Be careful when blowing large amounts of fine dust
in a dry environment as it can cause an accumulation
of static electricity which can result in an unexpected
electric discharge.
19. Never point toward people or animals. The machine
blows small objects at a high velocity and can cause
injury.
20. Never operate from an unstable footing, such as when
on a ladder or step ladder.
Doing so may cause an injury.
21. Do not strike the tool with other objects; avoid strong
impacts such as dropping the tool; and do not allow the
tool to get wet.
Any one of these can damage the built-in precision parts
and result in malfunction.
22. Before operation, remove any objects in the area that
may cause injury or accident.
23. Do not peep into the blast port during operation.
24. Keep the suction port away from your body to avoid
sucking in your work clothes.
00BookRB18DCAsia.indb500BookRB18DCAsia.indb5 2021/10/2910:07:172021/10/2910:07:17

6
English
25. If any foreign material enters the suction port and stops
the blast of air, immediately switch offthe tool, remove
the battery and then extract the foreign material.
26. Precautions during transport
• Release the switch on the body of the machine and
remove the battery.
• Carry the machine by the handle on its body.
• When transporting it via vehicle, take appropriate steps
to prevent it from falling over or being damaged.
ADDITIONAL SAFETY WARNINGS
1. Always charge the battery at a temperature of 0°C–40°C.
A temperature of less than 0°C will result in over charging
which is dangerous. The battery cannot be charged at a
temperature higher than 40°C.
The most suitable temperature for charging is that of
20°C–25°C.
2. Do not use the charger continuously.
When one charging is completed, leave the charger for
about 15 minutes before the next charging of battery.
3. Do not allow foreign matter to enter the hole for
connecting the rechargeable battery.
4. Never disassemble the rechargeable battery and
charger.
5. Never short-circuit the rechargeable battery.
Shortcircuiting the battery will cause a great electric
current and overheat. It results in burn or damage to the
battery.
6. Do not dispose of the battery in fire. If the battery is burnt,
it may explode.
7. Bring the battery to the shop from which it was purchased
as soon as the post-charging battery life becomes too
short for practical use. Do not dispose of the exhausted
battery.
8. Do not insert object into the air ventilation slots of the
charger. Inserting metal objects or inflammables into the
charger air ventilation slots will result in electrical shock
hazard or damaged charger.
9. When using this unit continuously, the unit may overheat,
leading to damage in the motor and switch. Therefore,
whenever the housing becomes hot, give the tool a
break for a while.
10. Make sure that the battery is installed firmly. If it is at all
loose it could come offand cause an accident.
11. Do not use the product if the tool or the battery terminals
(battery mount) are deformed.
Installing the battery could cause a short circuit that
could result in smoke emission or ignition.
12. Keep the tool’s terminals (battery mount) free of swarf
and dust.
○Prior to use, make sure that swarf and dust have not
collected in the area of the terminals.
○During use, try to avoid swarf or dust on the tool from
falling on the battery.
○When suspending operation or after use, do not leave
the tool in an area where it may be exposed to falling
swarf or dust.
Doing so could cause a short circuit that could result in
smoke emission or ignition.
13. Always use the tool and battery at temperatures between
-5°C and 40°C.
CAUTION ON LITHIUM-ION BATTERY
To extend the lifetime, the lithium-ion battery equips with the
protection function to stop the output.
In the cases of 1 to 3 described below, when using this
product, even if you are pulling the switch, the motor may
stop. This is not the trouble but the result of protection
function.
1. When the battery power remaining runs out, the motor
stops.
In such a case, charge it up immediately.
2. If the tool is overloaded, the motor may stop. In this
case, release the switch of tool and eliminate causes of
overloading. After that, you can use it again.
3. If the battery is overheated under overload work, the
battery power may stop.
In this case, stop using the battery and let the battery
cool. After that, you can use it again.
Furthermore, please heed the following warning and caution.
WARNING
In order to prevent any battery leakage, heat generation,
smoke emission, explosion and ignition beforehand, please
be sure to heed the following precautions.
1. Make sure that swarf and dust do not collect on the
battery.
○During work make sure that swarf and dust do not fall on
the battery.
○Make sure that any swarf and dust falling on the power
tool during work do not collect on the battery.
○Do not store an unused battery in a location exposed to
swarf and dust.
○Before storing a battery, remove any swarf and dust that
may adhere to it and do not store it together with metal
parts (screws, nails, etc.).
2. Do not pierce battery with a sharp object such as a
nail, strike with a hammer, step on, throw or subject the
battery to severe physical shock.
3. Do not use an apparently damaged or deformed battery.
4. Do not use the battery in reverse polarity.
5. Do not connect directly to an electrical outlets or car
cigarette lighter sockets.
6. Do not use the battery for a purpose other than those
specified.
7. If the battery charging fails to complete even when a
specified recharging time has elapsed, immediately stop
further recharging.
8. Do not put or subject the battery to high temperatures or
high pressure such as into a microwave oven, dryer, or
high pressure container.
9. Keep away from fire immediately when leakage or foul
odor are detected.
10. Do not use in a location where strong static electricity
generates.
11. If there is battery leakage, foul odor, heat generated,
discolored or deformed, or in any way appears abnormal
during use, recharging or storage, immediately remove it
from the equipment or battery charger, and stop use.
12. Do not immerse the battery or allow any fluids to flow
inside. Conductive liquid ingress, such as water, can
cause damage resulting in fire or explosion. Store your
battery in a cool, dry place, away from combustible and
flammable items. Corrosive gas atmospheres must be
avoided.
CAUTION
1. If liquid leaking from the battery gets into your eyes,
do not rub your eyes and wash them well with fresh
clean water such as tap water and contact a doctor
immediately.
If left untreated, the liquid may cause eye-problems.
2. If liquid leaks onto your skin or clothes, wash well with
clean water such as tap water immediately.
There is a possibility that this can cause skin irritation.
3. If you find rust, foul odor, overheating, discolor,
deformation, and/or other irregularities when using the
battery for the first time, do not use and return it to your
supplier or vendor.
00BookRB18DCAsia.indb600BookRB18DCAsia.indb6 2021/10/2910:07:172021/10/2910:07:17

7
English
WARNING
If a conductive foreign matter enters in the terminal of lithium
ion battery, the battery may be shorted, causing fire. When
storing the lithium ion battery, obey surely the rules of
following contents.
○Do not place conductive debris, nail and wires such as
iron wire and copper wire in the storage case.
○To prevent shorting from occurring, load the battery in
the tool or insert securely the battery cover for storing
until the ventilator is not seen.
REGARDING LITHIUM-ION BATTERY
TRANSPORTATION
When transporting a lithium-ion battery, please observe the
following precautions.
WARNING
Notify the transporting company that a package contains a
lithium-ion battery, inform the company of its power output
and follow the instructions of the transportation company
when arranging transport.
○Lithium-ion batteries that exceed a power output of
100 Wh are considered to be in the freight classification
of Dangerous Goods and will require special application
procedures.
○For transportation abroad, you must comply with
international law and the rules and regulations of the
destination country.
Wh
Power Output
2 to 3 digit number
USB DEVICE CONNECTION
PRECAUTIONS (UC18YSL3)
This feature is not available in some regions.
When an unexpected problem occurs, the data in a USB
device connected to this product may be corrupted or lost.
Always make sure to back up any data contained in the USB
device prior to use with this product.
Please be aware that our company accepts absolutely no
responsibility for any data stored in a USB device that is
corrupted or lost, nor for any damage that may occur to a
connected device.
WARNING
○Prior to use, check the connecting USB cable for any
defect or damage.
Using a defective or damaged USB cable can cause
smoke emission or ignition.
○When the product is not being used, cover the USB port
with the rubber cover.
Buildup of dust etc. in the USB port can cause smoke
emission or ignition.
NOTE
○There may be an occasional pause during USB
recharging.
○When a USB device is not being charged, remove the
USB device from the charger.
Failure to do so may not only reduce the battery life
of a USB device, but may also result in unexpected
accidents.
○It may not be possible to charge some USB devices,
depending on the type of device.
NAMES OF PARTS (Fig. 1–Fig. 10)
Battery (sold separately)
Handle
Switch
Air volume changing lever
ON lock button
Motor and fan
Blast port
Nozzle
Suction port
Latch
Charge indicator lamp
Battery level indicator switch
Battery level indicator lamp
Pin
Groove
Dust bag (sold separately)
Air volume: low
Air volume: medium
Air volume: high
Rubber cover
USB port
USB cable
SYMBOLS
WARNING
The following show symbols used for the machine.
Be sure that you understand their meaning before
use.
RB18DC: Cordless Blower
To reduce the risk of injury, user must read
instruction manual.
Direct current
V Rated voltage
n0No-load speed
Disconnect the battery
Switching ON
Switching OFF
Lock
Switch locks to the “ON” position
Warning
00BookRB18DCAsia.indb700BookRB18DCAsia.indb7 2021/10/2910:07:172021/10/2910:07:17

8
English
Battery
Lights ;
The battery remaining power is over 75%
Lights ;
The battery remaining power is 50%–75%.
Lights ;
The battery remaining power is 25%–50%.
Lights ;
The battery remaining power is less than 25%
Blinks ;
The battery remaining power is nearly empty.
Recharge the battery soonest possible.
Blinks ;
Output suspended due to high temperature.
Remove the battery from the tool and allow it to
fully cool down.
Blinks ;
Output suspended due to failure or malfunction.
The problem may be the battery so please
contact your dealer.
STANDARD ACCESSORIES
In addition to the main unit (1 unit), the package contains the
accessories listed on page 66.
Standard accessories are subject to change without notice.
APPLICATIONS
○Cleaning facilities and equipment in lumbermills,
cigarette-making plants, spinning mills, etc.
○Cleaning devices and equipment in repair shops.
○Blowing operation.
SPECIFICATIONS
1. Power tool
Model RB18DC
Voltage 18 V
No-Load Speed*10–20000 /min
Air velocity
Maximum*2 0–95 m/s
Average*2 0–78 m/s
Air volume*30–3.5 m3/min
Continuous operating
time*4
3: Approximately 20 minutes
2: Approximately 55 minutes
1: Approximately 130 minutes
Battery available for
this tool*5Multi volt battery, BSL18 Series
Weight 1.8 kg (BSL36A18)
2.1 kg (BSL36B18)
*1 BSL36A18, when fully charged
*2 With nozzle
*3 Without nozzle
*4 For guidance purposes only. Results will differ according
to situations such as operating environment and battery
condition.
*5 Existing batteries (BSL3660/3620/3626, etc.) cannot be
used with this tool.
NOTE
Due to HiKOKI’s continuing program of research and
development, the specifications herein are subject to
change without prior notice.
2. Battery (sold separately)
Model BSL36A18 BSL36B18
Voltage 36 V / 18 V (Automatic Switching*)
Battery capacity 2.5 Ah / 5.0 Ah 4.0 Ah / 8.0 Ah
(Automatic Switching*)
Available cordless
products** Multi volt series, 18 V product
Available charger Sliding charger for lithium ion
batteries
* The tool itself will automatically switch over.
** Please see our general catalogue for details.
3. Charger (sold separately)
Model UC18YSL3
Charging voltage 14.4 V–18 V
Weight 0.6 kg
BATTERY REMOVAL/INSTALLATION
1. Battery removal
Hold the housing tightly and push the battery latches to
remove the battery (see Fig. 2).
CAUTION
Never short-circuit the battery.
2. Battery installation
Insert the battery while observing its polarities (see
Fig. 2).
CHARGING
Before using the power tool, charge the battery as follows.
1. Connect the charger’s power cord to the receptacle.
When connecting the plug of the charger to a receptacle,
the charge indicator lamp will blink in red (At 1- second
intervals).
2. Insert the battery into the charger.
Firmly insert the battery into the charger as shown in
Fig. 3 (on page 2).
3. Charging
When inserting a battery in the charger, the charge
indicator lamp will blink in blue.
When the battery becomes fully recharged, the charge
indicator lamp will light up in green. (See Table 1)
(1) Charge indicator lamp indication
The indications of the charge indicator lamp will be as
shown in Table 1, according to the condition of the
charger or the rechargeable battery.
00BookRB18DCAsia.indb800BookRB18DCAsia.indb8 2021/10/2910:07:182021/10/2910:07:18

9
English
Table 1
Indications of the charge indicator lamp
Charge
indicator
lamp
(RED /
BLUE /
GREEN /
PURPLE)
Before
charging
Blinks
(RED)
Lights for 0.5 seconds. Does not light for
0.5 seconds. (offfor 0.5 seconds) Plugged into power source
While
charging
Blinks
(BLUE)
Lights for 0.5 seconds. Does not light for
1 second. (offfor 1 second) Battery capacity at less than 50%
Blinks
(BLUE)
Lights for 1 second. Does not light
for 0.5 seconds. (offfor 0.5 seconds) Battery capacity at less than 80%
Lights
(BLUE)
Lights continuously Battery capacity at more than 80%
Charging
complete
Lights
(GREEN)
Lights continuously
(Continuous buzzer sound: about
6 seconds)
Overheat
standby
Blinks
(RED)
Lights for 0.3 seconds. Does not light for
0.3 seconds. (offfor 0.3 seconds)
Battery overheated. Unable to
charge. (Charging will commence
when battery cools)
Charging
impossible
Flickers
(PURPLE)
Lights for 0.1 seconds. Does not light for
0.1 seconds. (offfor 0.1 seconds)
(Intermittent buzzer sound: about
2 seconds)
Malfunction in the battery or the
charger
(2) Regarding the temperatures and charging time of the rechargeable battery
The temperatures and charging time will become as shown in Table 2.
Table 2
Charger UC18YSL3
Battery
Type of battery Li-ion
Temperatures at which the
battery can be recharged 0°C–50°C
Charging voltage V 14.4 18
Charging time,
approx. (At 20°C)
BSL14xx series BSL18xx series Multi volt
series
(4 cells) (8 cells) (5 cells) (10 cells) (10 cells)
min
BSL1415S : 15
BSL1415
: 15
BSL1415X
: 15
BSL1420
: 20
BSL1425
: 25
BSL1430C
: 30
BSL1430
: 20
BSL1440
: 26
BSL1450
: 32
BSL1460
: 38
BSL1815S : 15
BSL1815 : 15
BSL1815X : 15
BSL1820 : 20
BSL1825 : 25
BSL1830C : 30
BSL1850C : 32
BSL1830 : 20
BSL1840 : 26
BSL1850 : 32
BSL1860 : 38
BSL36A18 : 32
BSL36B18 : 52
USB Charging voltage V 5
Charging current A 2
NOTE
○The recharging time may vary according to the ambient temperature and power source voltage.
○USB is not available in some regions.
4. Disconnect the charger’s power cord from the
receptacle.
5. Hold the charger firmly and pull out the battery.
NOTE
Be sure to pull out the battery from the charger after use,
and then keep it.
Regarding electric discharge in case of new batteries,
etc.
As the internal chemical substance of new batteries and
batteries that have not been used for an extended period
is not activated, the electric discharge might be low when
using them the first and second time. This is a temporary
phenomenon, and normal time required for recharging
will be restored by recharging the batteries 2–3 times.
00BookRB18DCAsia.indb900BookRB18DCAsia.indb9 2021/10/2910:07:192021/10/2910:07:19

10
English
How to make the batteries perform longer.
(1) Recharge the batteries before they become completely
exhausted.
When you feel that the power of the tool becomes
weaker, stop using the tool and recharge its battery. If
you continue to use the tool and exhaust the electric
current, the battery may be damaged and its life will
become shorter.
(2) Avoid recharging at high temperatures.
A rechargeable battery will be hot immediately after
use. If such a battery is recharged immediately after
use, its internal chemical substance will deteriorate, and
the battery life will be shortened. Leave the battery and
recharge it after it has cooled for a while.
CAUTION
○If the battery is charged while it is heated because
it has been left for a long time in a location subject to
direct sunlight or because the battery has just been
used, the charge indicator lamp of the charger lights
for 0.3 seconds, does not light for 0.3 seconds (offfor
0.3 seconds). In such a case, first let the battery cool,
then start charging.
○When the charge indicator lamp flickers (at 0.2-second
intervals), check for and take out any foreign objects in
the charger’s battery connector. If there are no foreign
objects, it is probable that the battery or charger is
malfunctioning. Take it to your authorized Service
Center.
○Since the built-in micro computer takes about
3 seconds to confirm that the battery being charged with
UC18YSL3 is taken out, wait for a minimum of 3 seconds
before reinserting it to continue charging. If the battery
is reinserted within 3 seconds, the battery may not be
properly charged.
MOUNTING AND OPERATION
Action Figure Page
Removing and inserting the battery
(sold separately) 22
Charging 3 2
Remaining battery indicator 4 2
Attachment of a Nozzle*1*252
Dust-collecting work*263
Switch operation*373
Charging a USB device from a
electrical outlet*48-a 3
Charging a USB device and battery
from a electrical outlet*48-b 3
How to recharge USB device*493
When charging of USB device is
completed*410 3
Selecting accessories ―67
*1 Before conducting a blowing operation, blow out air in a
location where there is nobody nearby to make sure the
tool is free of any residue.
*2 Turn the nozzle until a click is heard.
*3 During operation, the unit can generate static electricity
which may cause the motor to stop.
This is a protective feature and not a malfunction. Draw
the switch in once again to restart the motor.
*4 This feature is not available in some regions.
MAINTENANCE AND INSPECTION
WARNING
Be sure to turned offthe switch and remove the battery
before maintenance and inspection.
1. Inspecting the mounting screws
Regularly inspect all mounting screws and ensure that
they are properly tightened. Should any of the screws be
loose, retighten them immediately. Failure to do so could
result in serious hazard.
2. Maintenance of the motor
The motor unit winding is the very “heart” of the power
tool.
Exercise due care to ensure the winding does not
become damaged and/or wet with oil or water.
3. Inspection of terminals (tool and battery)
Check to make sure that swarf and dust have not
collected on the terminals.
On occasion check prior, during and after operation.
CAUTION
Remove any swarf or dust which may have collected on
the terminals.
Failure to do so may result in malfunction.
4. Cleaning on the outside
When the cordless blower is stained, wipe with a
soft dry cloth or a cloth moistened with soapy water.
Do not use chloric solvents, gasoline or paint thinner, for
they melt plastics.
If the nose grill is blocked with debris, the blower will
work less efficiently.
Clean it gently when necessary with a soft brush.
5. Storage
Store the cordless blower and the battery in a place in
which the temperature is less than 40°C and out of reach
of children.
NOTE
Storing lithium-ion batteries.
Make sure the lithium-ion batteries have been fully
charged before storing them.
Prolonged storage (3 months or more) of batteries with
a low charge may result in performance deterioration,
significantly reducing battery usage time or rendering
the batteries incapable of holding a charge.
However, significantly reduced battery usage time may
be recovered by repeatedly charging and using the
batteries two to five times.
If the battery usage time is extremely short despite
repeated charging and use, consider the batteries dead
and purchase new batteries.
CAUTION
In the operation and maintenance of power tools, the
safety regulations and standards prescribed in each
country must be observed.
SELECTING ACCESSORIES
The accessories of this machine are listed on page 67.
For details regarding each bit type, please contact the
HiKOKI Authorized Service Center.
Important notice on the batteries for the HiKOKI
cordless power tools
Please always use one of our designated genuine
batteries. We cannot guarantee the safety and
performance of our cordless power tool when used with
batteries other than these designated by us, or when
the battery is disassembled and modified (such as
disassembly and replacement of cells or other internal
parts).
00BookRB18DCAsia.indb1000BookRB18DCAsia.indb10 2021/10/2910:07:192021/10/2910:07:19

11
English
NOTE
Due to HiKOKI’s continuing program of research and
development, the specifications herein are subject to
change without prior notice.
TROUBLESHOOTING
Use the inspections in the table below if the tool does not operate normally. If this does not remedy the problem, consult your
dealer or the HiKOKI Authorized Service Center.
1. Power tool
Symptom Possible cause Remedy
Tool doesn’t run No remaining battery power Charge the battery.
Tool suddenly stopped The battery is overheated. Let the battery cool down.
Poor suction Dust bag is full. Dispose the dust.
Nozzle is plugged. Remove the obstruction.
Nozzle is cracked or damaged. Exchange the unit with a new one.
Battery cannot be installed Attempting to install a battery other than
that specified for the tool.
Please install batteries that are multi volt or
BSL18xx series.
2. Charger
Symptom Possible cause Remedy
The charge indicator lamp
rapidly flickers purple, and
battery charging doesn’t
begin.
The battery is not inserted all the way. Insert the battery firmly.
There is foreign matter in the battery
terminal or where the battery is attached.
Remove the foreign matter.
The charge indicator lamp
blinks red, and battery
charging doesn’t begin.
The battery is not inserted all the way. Insert the battery firmly.
The battery is overheated. If left alone, the battery will automatically
begin charging if its temperature decreases,
but this may reduce battery life. It is
recommended that the battery be cooled in
a well-ventilated location away from direct
sunlight before charging it.
Battery usage time is short
even though the battery is
fully charged.
The battery’s life is depleted. Replace the battery with a new one.
The battery takes a long
time to charge.
The temperature of the battery, the charger,
or the surrounding environment is extremely
low.
Charge the battery indoors or in another
warmer environment.
The charger’s vents are blocked, causing its
internal components to overheat.
Avoid blocking the vents.
The cooling fan is not running. Contact a HiKOKI Authorized Service
Center for repairs.
The USB power lamp
has switched offand the
USB device has stopped
charging.
The battery’s capacity has become low. Replace the battery with one that has
capacity remaining.
Plug the charger’s power plug into an
electric socket.
USB power lamp does not
switch offeven though the
USB device has finished
charging.
The USB power lamp lights up green to
indicate that USB charging is possible.
This is not a malfunction.
It is unclear what the
charging status of a USB
device is, or whether its
charging is complete.
The USB power lamp does not switch off
even when charging is complete.
Examine the USB device that is charging to
confirm its charging status.
00BookRB18DCAsia.indb1100BookRB18DCAsia.indb11 2021/10/2910:07:192021/10/2910:07:19

12
English
Symptom Possible cause Remedy
Charging of a USB device
pauses midway.
The charger was plugged into an electrical
socket while the USB device was being
charged using the battery as the power
source.
This is not a malfunction.
The charger pauses USB charging for about
5 seconds when it is differentiating between
power sources.
A battery was inserted into the charger while
the USB device was being charged using a
power socket as the power source.
Charging of the USB device
pauses midway when the
battery and the USB device
are being charged at the
same time.
The battery has become fully charged. This is not a malfunction.
The charger pauses USB charging for
about 5 seconds while it checks whether
the battery has successfully completed
charging.
Charging of the USB
device doesn’t start when
the battery and the USB
device are being charged
at the same time.
The remaining battery capacity is extremely
low.
This is not a malfunction.
When the battery capacity reaches a certain
level, USB charging automatically begins.
00BookRB18DCAsia.indb1200BookRB18DCAsia.indb12 2021/10/2910:07:192021/10/2910:07:19

13
中國語
c) 防止意外啟動。在連接電源及或電池組、拿
起或攜帶工具前，請確認開關是在「off」（關閉）
的位置。
以手指放在開關握持電動工具，或在電動工具
的開關於“on”的狀況下插上插頭，都會導致
意外發生。
d) 在將電動工具啟動前，先卸下任何調整用鑰匙
或扳手。
扳手或鑰匙遺留在電動工具的轉動部位時，可
能導致人員傷害。
e) 身體勿過度伸張，任何時間要保持站穩及平衡。
以便在不預期的狀態下，能對電動工具有較好
的控制。
f) 衣著要合宜，別穿太鬆的衣服或戴首飾。
保持您的頭髮、衣服遠離轉動部位。
寬鬆的衣服、手飾及長髮會被捲入轉動部位。
g) 如果裝置要用於粉塵抽取及集塵設施，要確保
其連接及正當使用。
使用集塵裝置可減少與灰塵相關的危險。
h) 請勿因頻繁使用本工具，熟悉操作而忽略本工
具的安全原則。
粗心的行動有可能瞬間即造成嚴重傷害。
4) 電動工具之使用及注意事項
a) 勿強力使用電動工具，使用正確之電動工具為
你所需。
正確使用電動工具會依其設計條件使工作做得
更好更安全。
b) 如果開關不能轉至開及關的位置，勿使用電動
工具。
任何電動工具不能被開關所控制是危險的，必
須要修理。
c) 在進行任何調整、更換配件或收存電動工具之
前，請斷開插頭與電源的連接，且 / 或將電池
從電動工具中取出 ( 如果電池為可拆卸式 )。
此種預防安全措施可減少意外開啟電動機之危
險。
d) 收存停用之電動工具，遠離兒童，且不容許不
熟悉電動工具或未瞭解操作電動工具說明書的
人操作電動工具。
在未受過訓練的人手裡，電動工具極為危險。
e) 保養電動工具和配件。檢核是否有可動零件錯
誤的結合或卡住、零件破裂及可能影響電動工
具操作的任何其他情形。電動工具如果損壞，
在使用前要修好。
許多意外皆肇因於不良的保養。
f) 保持切割工具銳利清潔。
適當的保養切割工具，保持銳利之切削鋒口，
可減少卡住並容易控制。
g) 按照說明書使用電動工具、配件及刀具時，必
須考量工作條件及所執行之工作。
若未依照這些使用說明操作電動工具時，可能
造成相關之危害情況。
一般安全規則
警告
閱讀本電動工具提供的所有安全警告、指示、說明
和規範。
未遵守下列之說明可能導致觸電、火災及 / 或嚴重傷
害。
請妥善保存所有警告與說明，以供未來參考之用。
「電動工具」一詞在警告中，係指電源操作（有線）
之電動工具或電池操作（無線）之電動工具。
1) 工作場所安全
a) 保持工作場所清潔及明亮。
雜亂或昏暗的區域容易發生意外。
b) 勿在易產生爆炸之環境中操作，譬如有易燃液
體、瓦斯或粉塵存在之處。
電動工具產生火花會引燃粉塵或煙氣。
c)
當操作電動工具時，保持兒童及過往人員遠離。
分神會讓你失去控制。
2) 電氣安全
a) 電動工具插頭必須與插座配合，絕不可以任何
方法修改插頭，且不得使用任何轉接插頭於有
接地之電動工具。
不修改插頭及所結合之插座可減少電擊。
b) 避免身體接觸到接地面諸如管子、散熱器、爐
灶及冰箱。
如果你的身體接地或搭地，會增加電擊的危險。
c) 勿讓電動工具淋雨或曝露在潮濕的環境下。
電動工具進水會增加電繫的危險。
d) 勿濫用電源線。絕勿使用電源線去纏繞、拖拉
電動工具或拔插頭，保持電源線遠離熱氣、油
氣、尖角或可動零件。
損壞或纏繞的電源線會增加電繫之危險。
e) 電動工具在室外操作時要使用一適合室外用的
延長線。
使用合適之室外用延長線會減少電擊的危險。
f) 若無法避免在潮濕地區操作電動工具，請使用
以殘餘電流裝置 (RCD) 保護的電源。
使用 RCD 可降低觸電危險。
3) 人員安全
a) 保持機警，注意你正在做什麼，並運用普通常
識操作電動工具。
當你感到疲勞或受藥品、酒精或醫療影響時，
勿操作電動工具。
操作中瞬間的不注意可能造成人員嚴重的傷
害。
b) 使用個人防護裝備，經常配戴安全眼鏡。
配戴防塵口罩、防滑安全鞋、硬帽等防護裝備，
或在適當情況下使用聽覺防護，可減少人員傷害。
00BookRB18DCAsia.indb1300BookRB18DCAsia.indb13 2021/10/2910:07:192021/10/2910:07:19

14
中國語
h) 保持把手和握持面乾燥、清潔，且未沾到油脂
和潤滑油。
滑溜的把手和握持面在操作時會有安全上的問
題，且可能造成本工具意外失去控制。
5） 電池式工具的使用及注意事項
a) 需再充電時，僅能使用製造商指定的充電器。
因充電器僅適合同一型式的電池組，若使用任
何其它電池組時，將導致起火的危險。
b) 使用電動工具時，僅能使用按照其特性設計的
電池組。
因使用其它任何電池組時，將導致人員傷害及
起火的危險。
c) 當電池組不在使用時，需保存遠離其它的金屬
物件，例如：迴紋針、錢幣、鑰匙、圖釘、螺
釘，或類似能造成端子與端子間連接的其它較
小金屬物件。
因電池組端子間短路時，將導致燃燒或起火的
危險。
d) 在誤用情況下，電解液可能自電池中噴出；請
避免接觸。當發生意外接觸時，請用清水沖
洗。若電解液觸及眼睛時，請儘速尋求醫療協
助。
因自電池中噴出的電解液，將導致灼傷或刺激
皮膚。
e) 請勿使用損壞或改造的電池組或工具。
損壞或改造的電池可能會發生不可預知的行
為，進而導致火災、爆炸或受傷的風險。
f) 請勿使電池組或工具接觸到火源或處於溫度過
高的地方。
接觸火源或溫度超過 130°C 可能會引起爆炸。
g) 請遵循所有充電指示，並且不要在說明書指定
的溫度範圍之外為電池組或工具充電。
充電不當或溫度超出指定範圍可能會損壞電池
並增加火災的風險。
6) 維修
a) 讓你的電動工具由合格修理人員僅使用相同的
維修零件更換。
如此可確保電動工具的安全得以維持。
b) 切勿對損壞的電池組進行維修。
電池組的維修只能由製造商或授權服務商進
行。
注意事項
不可讓孩童和體弱人士靠近工作場所。
應將不使用的工具存放在孩童和體弱人士伸手不及
的地方。
充電式吹風機安全警告
1. 使用過程中請勿將手或臉靠近充電式吹風機的吹
風口或吸入口。
否則可能會導致受傷。
2. 清潔電氣面板等的電導體時，請確保導體和本電
動工具之間有足夠的空間。此外，清潔時務必安
裝噴嘴。
清潔導體時未安裝噴嘴可能會導致觸電。
3. 請勿堵塞吹風口和或吸入口。此外，請勿讓灰
塵積聚在吸入口。
堵塞吹風口或吸入口將導致馬達轉速異常加快，
可能會損壞電動工具內的風扇並導致馬達過熱。
4. 請勿使用本電動工具對氣球或游泳圈充氣。
5. 請勿在有易燃物質（如噴漆、油漆、苯、稀釋劑
或汽油）的地方使用。此外，請勿讓點燃的菸蒂
等物品在這些地方被吸入。
否則可能會導致爆炸或火災。
6. 請勿在爐灶等會產生高熱源的物體附近使用；請
勿對著點燃的菸蒂吹風； 並且不要撥旺或熄滅火
焰。
如果在這些地方附近使用，可能會發生火災。
7. 請勿在有大量化學品等的環境中使用。
塑料部分可能會變弱和斷裂，並可能導致受傷。
8. 如果您發現本機產生異常高溫、運作不良或發出
異常噪音，請立即停止使用並關閉電源開關。請
要求您所購買本機的經銷商或 HiKOKI 授權服務
中心進行檢查和維修。
在異常運作時繼續使用可能會導致受傷。
9. 如果本機不慎掉落或撞擊到其他物品，請仔細檢
查本機是否有裂痕、破損或變形等。
如果本機有裂痕、破損或變形，可能會導致受傷。
10. 請勿在吸入口或吹風口內放置螺絲等物品。
否則可能會損壞本工具的內部零件。
11. 用於吹氣操作時，請將噴嘴安裝在吹風口。用於
集塵時，請將噴嘴安裝在吸入口，並將集塵袋安
裝在吹風口上。
12. 請勿使用本工具吸取水或濕塵粒等液體，或玻璃
碎片、切割工具、釘子、螺絲、鵝卵石或點燃的
菸蒂等物品。
13. 請勿使用工業油或油脂（切削油、潤滑油等），
或在化學品附近使用。
否則可能會導致零件劣化或造成損壞。
14. 如果使用充電式吹風機吹掃或清潔粘性粉末或塵
粒，請進行徹底檢查。
粉末或塵粒可能被吸入並粘附在工具內部，導致
葉片斷裂或發生人身傷害。
15. 切勿觸摸移動中的零件。
切勿將手、手指或其他身體部位靠近工具的移動
中的零件。
00BookRB18DCAsia.indb1400BookRB18DCAsia.indb14 2021/10/2910:07:202021/10/2910:07:20

15
中國語
16. 切勿讓工具處於無人看守的狀態。關閉電源。
在完全停止之前不要離開工具。
17. 在高處操作本工具時，確保下方無人。
18. 在乾燥的環境中吹掃大量細塵時需小心，因為其
會造成靜電積聚，從而導致意外放電。
19. 切勿將本機器朝向人或動物。本機器以高速吹走
小物品並可能造成受傷。
20. 請勿在如梯子或階梯上等腳步不穩定的地方操
作。
否則可能會造成受傷。
21. 請勿以其他物體撞擊工具；避免工具掉落等強烈
撞擊；並且不要讓工具弄濕。
這其中任何一種行為都可能損壞內建精密零件並
導致故障。
22. 操作前，請先清除該區域內可能造成受傷或事故
的任何物體。
23. 操作過程中請勿窺視吹風口。
24. 保持吸入口遠離您的身體，以避免工作服被吸入。
25. 如果任何異物進入吸入口並停止吹氣，請立即將
工具關機，移除電池，然後取出異物。
26. 運輸時的注意事項
• 釋放機器機體上的開關並取出電池。
• 握住機體上的握把搬運機器。
• 使用車輛運輸時，請採取適當措施，防止其掉落
或損壞。
附加安全警告
1. 給電池充電時溫度必須為 0℃－40℃。溫度低於
0℃ 會導致過度充電，這是很危險的。不能在溫
度高於 40℃ 時給電池充電。
最合適的充電溫度是 20℃－25℃。
2. 請勿連續使用充電器。
完成一次充電後，將充電器放置約 15 分鐘後才
能再次給電池充電。
3. 勿讓雜質進入充電池連接口內。
4. 切勿拆卸充電電池與充電器。
5. 切勿使充電電池短路。
電池短路將會造成很大的電流和過熱，從而燒壞
電池。
6. 請勿將電池丟入火中。電池受熱會爆炸。
7. 充電後電池壽命若太短不夠使用，請儘快將電池
送往經銷店。不可將用過的電池丟棄。
8. 請勿將異物插入充電器的通風口。若將金屬異物
或易燃物插入通風口，將引起觸電事故或使充電
器受損。
9. 連續使用本機時，鎚鑽可能出現過熱而導致馬達
和開關損壞。因此，每當機殼變熱時，讓工具休
息一會兒。
10. 確保電池安裝牢固。如果有鬆動，可能會脫落而
造成事故。
11. 如果工具或電池端子（電池座）變形，請勿使用
本產品。
安裝電池可能會造成短路，從而導致冒煙或起火。
12. 保持工具的端子（電池座）沒有削屑和灰塵。
○ 使用前請確認端子區域沒有堆積削屑和灰塵。
○ 使用過程中盡量避免工具上的削屑或灰塵掉落在
電池上。
○ 暫停操作或使用後，請勿將工具留在可能暴露於
有掉落削屑或灰塵的區域。
否則可能會造成短路，從而導致冒煙或起火。
13. 務必在 -5℃至 40℃的溫度下使用本工具和電池。
鋰離子電池使用注意事項
為延長使用壽命，鋰離子電池備配停止輸出的保護
功能。
若是在使用本產品時發生下列 1 至 3 的情況，即使
按下開關，馬達也可能停止。這並非故障，而是啟
動保護功能的結果。
1. 在殘留的電池電力即將耗盡時，馬達會停止。
在這種情況下，請立即予以充電。
2. 若工具超過負荷，馬達亦可能停止。在這種情況
下，請鬆開工具的開關，試著消除超過負荷的原
因。之後您就可以再度使用。
3. 若電池在過載工作情況下過熱，電池電力可能會
中止。
在這種情況下，請停止使用電池，讓電池冷卻。
之後您就可以再度使用。
此外，請留心下列的警告及注意事項。
警告
為事先防止電池發生滲漏、發熱、冒煙、爆炸及起
火等事故，請確保留意下列事項。
1. 確保電池上沒有堆積削屑及灰塵。
○ 在工作時確定削屑及灰塵沒有掉落在電池上。
○ 確定所有工作時掉落在電動工具上的削屑和灰塵
沒有堆積在電池上。
○ 請勿將未使用的電池存放在曝露於削屑和灰塵的
位置。
○ 在存放電池之前，請清除任何可能附著在上面的
削屑和灰塵，並請切勿將它與金屬零件（螺絲、
釘子等）存放在一起。
2. 請勿以釘子等利器刺穿電池、以鐵錘敲打、踩踏、
丟擲電池，或將其劇烈撞擊。
3. 切勿使用明顯損壞或變形的電池。
4. 使用電池時請勿顛倒電極。
5. 請勿直接連接電源插座或汽車點煙器孔座。
6. 請依規定方式使用電池，切勿移作他用。
7. 如果已過了再充電時間，電池仍無法完成充電，
請立即停止繼續充電。
8. 請勿將電池放置於高溫或高壓處，例如微波爐、
烘乾機或高壓容器內。
00BookRB18DCAsia.indb1500BookRB18DCAsia.indb15 2021/10/2910:07:202021/10/2910:07:20

16
中國語
9. 發現有滲漏或異味時，請立即將電池遠離火源處。
10. 請勿在會產生強烈靜電的地方使用。
11. 如電池出現滲漏、 異味、發熱、褪色或變形，或
在使用、充電或存放時出現任何異常，請立即將
它從裝備或電池充電器拆下，並停止使用。
12. 請勿將電池浸入任何液體，或讓任何液體流入電
池內。若水等具有傳導性的液體滲入，可能會造
成損壞，進而導致火災或爆炸。將電池存放在陰
涼、乾燥的地方，遠離可燃及易燃物品。必須避
免腐蝕性氣體環境。
注意
1. 若電池滲漏出的液體進入您的眼睛，請勿搓揉眼
睛，並以自來水等乾淨清水充分沖洗，立刻送醫。
若不加以處理，液體可能會導致眼睛不適。
2. 若液體滲漏至您的皮膚或衣物，請立即以自來水
等清水沖洗。
上述情況可能會使皮膚受到刺激。
3. 若初次使用電池時發現生銹、異味、過熱、褪色、
變形及或其他異常情況時，請勿使用並將該電
池退還給供應商或廠商。
警告
若具有導電性的異物進入鋰離子電池的端子，可能
會造成短路，進而引發火災。請在存放電池時遵循
以下事項。
○ 請勿將導電物品，如鐵釘、鐵絲等金屬絲，銅線
和電線放入儲存箱內。
○ 為了防止發生短路，將電池裝入工具內或確實壓
下電池蓋儲存電池，直至遮住通風孔為止。
關於鋰離子電池的運輸
運輸鋰離子電池時，請遵守以下注意事項。
警告
安排運輸時，請通知運輸公司包裹中含有鋰離子電
池，告知該電池之輸出功率，並按照運輸公司的指
示。
○ 輸出功率超過 100 Wh 的鋰離子電池被視為貨物
分類中的危險物品，將需要特殊的申請程序。
○ 對於國外的運輸，必須遵守國際法規則和目的國
法規。
Wh
輸出功率
2至3位數
連接 USB 裝置的注意事項
(UC18YSL3)
此功能在某些地區不可用。
發生未預期的問題時，連接到本產品的 USB 裝置內
的數據可能會損壞或丟失。使用本產品之前，請務
必將 USB 裝置內的所有數據進行備份。
請注意，本公司對任何存儲於 USB 裝置內已損壞或
丟失的數據以及任何可能發生於連接裝置的損害，
恕不負任何責任。
警告
○ 使用前，請檢查連接的 USB 電纜是否有缺陷或損
壞。
使用有缺陷或損壞的 USB 電纜可能會導致冒煙或
起火。
○ 產品不使用時，請用橡膠蓋蓋住 USB 端口。
USB 端口堆積灰塵可能會導致冒煙或起火。
註
○ USB 充電期間有可能偶爾停頓。
○ 當 USB 裝置未被充電時，請從充電器取出 USB
裝置。
若未進行此動作，不僅可能減少 USB 裝置的電池
壽命，並可能導致意外事故的發生。
○ 根據裝置的類型，可能無法對某些 USB 裝置進行
充電。
各部位名稱（圖1–圖10）
電池 （另售）
握把
開關
風量變更桿
ON 鎖定按鈕
馬達和風扇
吹風口
噴嘴
吸入口
卡榫
充電信號燈
電池電量指示開關
電池電量指示燈
插銷
凹槽
集塵袋 （另售）
風量 : 低
風量 : 中
00BookRB18DCAsia.indb1600BookRB18DCAsia.indb16 2021/10/2910:07:212021/10/2910:07:21

17
中國語
風量 : 高
橡膠罩
USB 端口
USB 電纜
符號
警告
以下為使用於本機器的符號。請確保您在使用前
明白其意義。
RB18DC : 吹風機
使用前請詳讀使用說明書。
直流電流
V額定電壓
n0無負荷速度
取出電池
開關 ON
開關 OFF
Lock
將鎖切換至「開」位置
警告
電池
亮起：
電池剩餘電量超過 75%。
亮起：
電池剩餘電量為50%－75%。
亮起：
電池剩餘電量為25%－50%。
亮起：
電池剩餘電量少於 25%。
閃爍：
電池剩餘電量幾近零。請盡快進行充電。
閃爍：
由於高溫導致輸出被暫停。從工具中取出
電池，並使其完全冷卻。
閃爍：
由於故障或機能失常導致輸出被暫停。問
題可能是電池，請聯繫您的經銷商。
標 準 附 件
除了主機身 (1台)以外，包裝盒內包含第 66 頁所列
之附件。
標準附件可能不預先通告而徑予更改。
用 途
○ 清潔鋸木廠、菸廠、紡紗廠等的設施和設備。
○ 清潔維修店鋪的裝置和設備。
○ 吹氣操作。
規 格
1. 電動工具
機型 RB18DC
電壓 18 V
無負荷速度*10－20000 /分
空氣速率 最大*20－95 m/s
平均*20－78 m/s
風量*30－3.5 m3/min
連續運轉時間*4
3：約 20 分鐘
2：約 55 分鐘
1：約 130 分鐘
可用於本工具的電
池*5多伏特電池 , BSL18 系列
重量 1.8 kg (BSL36A18)
2.1 kg (BSL36B18)
*1 BSL36A18，充滿電時
*2 有噴嘴
*3 無噴嘴
*4 僅供參考。結果將因操作環境和電池狀況等情況
而異。
*5 本工具不能使用現有的電池（BSL3660/3620/
3626 等）。
註:
為求改進，本手冊所載規格可能不預先通告而徑
予更改。
2. 電池（另售）
機型 BSL36A18 BSL36B18
電壓 36 V / 18 V （自動切換 *）
電池容量 2.5 Ah / 5.0 Ah 4.0 Ah / 8.0 Ah
（自動切換 *）
可用的充電式
產品 ** 多伏特系列，18V 產品
可用的充電器 鋰離子電池用滑動式充電器
00BookRB18DCAsia.indb1700BookRB18DCAsia.indb17 2021/10/2910:07:212021/10/2910:07:21

18
中國語
* 工具本身將自動切換。
** 詳情請參閱本公司的綜合目錄。
3. 充電器（另售）
機型 UC18YSL3
充電電壓 14.4 V－18 V
重量 0.6 kg
電池的拆卸 / 安裝
1 拆卸電池
緊抓外殼，並推動電池閂鎖以取出電池
（見 圖 2）。
注意
請勿使電池短路。
2 安裝電池
請先確認了電池的正負極後，再將電池插進去
（見圖 2）。
充 電
使用電動工具之前，按下述方法將電池進行充電。
1. 將充電器的電源線連接到插座。
當充電器的插頭連接到插座時，充電信號燈會閃
爍紅燈（間隔為 1 秒）。
2. 將電池裝入充電器。
將電池確實插入充電器如 圖3 （第 2 頁）所示。
3. 充電
當電池插入充電器時，充電信號燈會閃爍藍燈。
當電池完全充電時，充電信號燈會亮起綠燈。( 見
表 1)
(1) 充電信號燈指示
依據充電器或充電池的狀態，充電信號燈會有不
同的指示，如表 1 所示。
表 1
充電信號燈的指示
充電信
號燈
(紅/藍/
綠/紫)
充電前 閃爍
(紅)
亮起 0.5 秒，熄滅 0.5 秒。（熄滅
間 0.5 秒） 插入電源
充電時
閃爍
(藍)
亮起 0.5 秒，熄滅 1 秒。（熄滅 間
1 秒） 電池容量少於 50％
閃爍
(藍)
亮起 1 秒，熄滅 0.5 秒。（熄滅 間
0.5 秒） 電池容量少於 80%
亮起
(藍)
持續亮起 電池容量超過 80%
充電完成 亮起
(綠)
持續亮起
( 連續的蜂鳴聲：約6秒)
過熱待機 閃爍
(紅)
亮起 0.3 秒，熄滅 0.3 秒。（熄滅
間 0.3 秒）
電池過熱。
無法充電。
（待電池降溫後便會開始充電）
無法充電 快速閃爍
(紫)
亮起 0.1 秒，熄滅 0.1 秒。（熄滅
間 0.1 秒）
( 間歇的蜂鳴聲：約2秒)
電池或充電器故障
00BookRB18DCAsia.indb1800BookRB18DCAsia.indb18 2021/10/2910:07:222021/10/2910:07:22

19
中國語
(2) 關於充電池的溫度和充電時間
溫度和充電時間如表 2 中所示。
表 2
充電器 UC18YSL3
電池
電池類型 Li-ion
電池可充電的溫度 0°C－50°C
充電電壓 V 14.4 18
充電時間，
約（於 20℃）
BSL14xx 系列 BSL18xx 系列 多伏特系列
（4 個電池芯）（8 個電池芯） （5 個電池芯）（10 個電池芯）（10 個電池芯）
分鐘
BSL1415S : 15
BSL1415 : 15
BSL1415X : 15
BSL1420 : 20
BSL1425 : 25
BSL1430C : 30
BSL1430 : 20
BSL1440 : 26
BSL1450 : 32
BSL1460 : 38
BSL1815S : 15
BSL1815 : 15
BSL1815X : 15
BSL1820 : 20
BSL1825 : 25
BSL1830C : 30
BSL1850C : 32
BSL1830 : 20
BSL1840 : 26
BSL1850 : 32
BSL1860 : 38
BSL36A18 : 32
BSL36B18 : 52
USB 充電電壓 V 5
充電電流 A 2
註:
○ 根據環境溫度和電源電壓，充電時間可能會有所不同。
○ USB 在某些地區不可用。
4. 將充電器的電源線從插座拔下。
5. 拿穩充電器並取出電池。
註:
充電結束後，務必從充電器取出電池，然後妥善
存放。
使用新電池或其他電池，產生電量較弱的問題時。
由於新電池及長時間未使用之電池的內部化學物
質未活化，因此初次及第二次使用時的電量會較
弱。此為暫時現象；在充電 2 至 3 次後，電量
就會恢復正常。
怎樣讓電池使用時間更長。
(1) 在電池電量完全耗盡之前給電池充電。
在感覺工具的動力變弱時，停止使用工具並為電
池充電。如果繼續使用工具消耗電流，可能會造
成對電池的損壞，電池使用壽命會縮短。
(2) 避免在高溫下充電。
充電電池在剛使用後會發熱。如果在電池剛使用
後為電池充電，電池的內部化學物質的性能會下
降，電池使用壽命會縮短。請先將電池放置一會
兒，待電池冷卻後再進行充電。
注意
○ 電池因長時間放置在直射陽光處遭到日曬或剛使
用後會發熱，若在此時進行充電，充電器的信號
燈會亮起 0.3 秒，非亮起 0.3 秒（熄滅 0.3 秒）。
此時您必須先待電池冷卻，再進行充電。
○ 充電信號燈快速閃爍時（間隔時間為 0.2 秒），
請檢查充電器的電池連接處是否有異物並加以清
除。 若沒有異物，則表示電池或充電器可能發
生故障，請將其送往當地授權服務中心。
○ 由於 UC18YSL3 內置微電腦需要約 3 秒的時間確
認進行充電的電池已被取出，請等待至少 3 秒後
再將電池重新插入繼續充電。如果電池在 3 秒之
內重新插入，電池可能無法正常充電。
安裝和操作
動作 圖表 頁數
取出和安裝電池（另售） 2 2
充電 3 2
電池剩餘量指示燈 4 2
安裝噴嘴 *1*252
集塵作業 *263
開關操作 *373
從電源插座進行 USB 裝置的充電 *48-a 3
從電源插座進行 USB 裝置和電池的
充電 *48-b 3
USB 裝置的充電方法 *493
USB 裝置充電完成後 *410 3
選擇附件 ─67
00BookRB18DCAsia.indb1900BookRB18DCAsia.indb19 2021/10/2910:07:232021/10/2910:07:23

20
中國語
*1 在進行吹氣操作之前，請在附近無人的地方吹出
空氣，以確保工具沒有任何殘留物。
*2 轉動噴嘴，直到聽到咔嗒聲。
*3 在操作過程中，本機可能會產生靜電而導致馬達
停止。
此為一種保護功能，並非故障。再次拉動開關以
重新啟動馬達。
*4 此功能在某些地區不可用。
維護和檢查
警告
進行維修和檢查之前，務必要關閉開關，並取出
電池。
1. 檢查安裝螺釘
要經常檢查安裝螺釘是否緊固妥善。若發現螺釘
鬆了，應立即重新扭緊，否則會導致嚴重的事
故。
2. 電動機的維護
電動機繞線是電動工具的心臟部。應仔細檢查有
無損傷，是否被油液或水沾濕。
3. 端子的檢查（工具和電池）
檢查以確保端子上沒有堆積削屑和灰塵。
有時於操作前、操作期間和操作後檢查。
注意
去除任何可能已堆積在端子上的削屑或灰塵。
否則可能會導致故障。
4. 清理外部
充電式吹風機髒汙時，請使用乾的軟布或沾肥皂
水的布擦拭。切勿使用氯溶液、汽油或稀釋劑，
以免塑膠部分溶化。
如果機頭格柵被碎屑堵住，吹風機的作業效率就
會降低。
必要時用軟刷輕輕清潔。
5. 收藏
充電式吹風機和電池應收藏於溫度低於 40℃且
為小孩拿不到的地方。
註:
存放鋰離子電池。
存放鋰離子電池前，確保其已完全充電。
電池在低電力的狀態下長期存放（3 個月以上），
可能會導致性能劣化，電池的使用時間顯著降低
或無法再進行充電。
然而，反覆將電池充電和暫停充電二至五次，可
能會改善電池使用時間的顯著降低情況。
反覆充電後，若電池的使用時間仍呈現極短現象，
表示電池壽命已盡，請購買新的電池。
注意
在操作和維修電動工具中，必須遵守各國的安全
規則和標準規定。
選擇配件
本機器的配件列在第 67 頁。
有關每種鑽頭類型的詳情，請聯繫 HiKOKI 授權服務
中心。
HiKOKI 充電式工具電池重要注意事項
請務必使用本公司所指定的原廠電池。若未使用本
公司所指定的電池，或使用經拆解及改裝的電池
（例如，拆解後更換電池芯或其他內部零件 )，則
本公司無法保證充電式工具的性能及操作安全。
註:
為求改進，本手冊所載規格可能不預先通告而徑
予更改。
疑 難 排 解
若電動工具無法正常運作，請參閱下表的檢查項目。若問題仍無法解決，請洽當地經銷商或 HiKOKI 所認可
的維修中心。
1. 電動工具
情況 可能原因 解決方法
工具無法運轉 無剩餘電池電量 為電池充電。
工具突然停止 電池過熱。 讓電池冷卻下來。
吸力差 集塵袋已滿。 丟棄灰塵。
噴嘴堵塞。 移除障礙物。
噴嘴破裂或損壞。 更換新的組件。
電池無法安裝 試圖安裝非該工具所指定的電池。 請安裝多伏特型或 BSL18xx 系列電池。
00BookRB18DCAsia.indb2000BookRB18DCAsia.indb20 2021/10/2910:07:232021/10/2910:07:23
