English
7
(Original instructions)
MEANINGS OF SYMBOLS
NOTE: Some units do not carry them.
Symbols
WARNING
The following show symbols used for the machine. Be sure that you understand their meaning before use.
Grass Trimmer / Brush Cutter Priming pump
It is important that you read, fully understand
and observe the following safety precautions
and warnings. Careless or improper use of the
unit may cause serious or fatal injury.
Guaranteed sound power level
Read, understand and follow all warnings and
instructions in this manual and on the unit.
Blade thrust may occur when the spinning
blade contacts a solid object in the critical area.
A dangerous reaction may occur causing the
entire unit and operator to be thrust violently.
This reaction is called blade thrust. As a result,
the operator may lose control of the unit which
may cause serious or fatal injury. Blade thrust is
more likely to occur in areas where it is difficult
to see the material to be cut.
Always wear eye, head and ear protectors when
using this unit.
Do not use metal/rigid blades when this sign is
shown on the unit. Hot Surface – Contact with hot surface can cause serious burns.
Keep all children, bystandards and helpers
15 m away from the unit. If anyone approaches
you, stop the engine and cutting attachment
immediately.
The hedge trimmer attachment cannot be used
on models with this label.
Be careful of thrown objects. Indicate handle location. Arrows which show
limits for handle positioning.
min-1
Shows maximum shaft speed. Do not use the
cutting attachment whose max rpm is below the
shaft rpm. Displacement
Gloves should be worn when necessary, e.g.,
when assembling cutting equipment. Spark plug
Use anti-slip and sturdy footwear. Idle Idling speed
Choke – Run position (Open) Speed of output shaft
Choke – Start position (Closed) PMax. engine output
On/Start Fuel tank capacity
Off/Stop Dry weight (without fuel, cutting attachment,
harness and cutting attachment guard)
Emergency stop Cutting attachment
Fuel and oil mixture
LpA, eq
ISO22868
Sound pressure level LpA by ISO 22868
Equivalent*
Idle speed adjustment
LWA, Ra(M)
2000/14/EC
Measured sound power level LwA by 2000/14/
EC
Racing
000BookCG24ECP(S).indb7000BookCG24ECP(S).indb7 2019/01/169:37:082019/01/169:37:08

English
8
LWA, Ra(G)
2000/14/EC
Guaranteed sound power level LwA by 2000/14/
EC
Racing
ahv, eq(R)
Vibration level by ISO 22867
Rear or Right handle / Equivalent*
ahv, eq(F)
Vibration level by ISO 22867
Front or Left handle / Equivalent* KUncertainty
Before using your machine
• Read the manual carefully.
• Check that the cutting equipment is correctly assembled and adjusted.
• Start the unit and check the carburetor adjustment. See “MAINTENANCE”.
NOTE: Equivalent noise level / vibration level are calculated as the time-weighted energy total for noise / vibration levels
under various working conditions with the following time distribution:
* 1/2 Idle, 1/2 racing.
WHAT IS WHAT? (Fig. 1)
Since this manual covers several models, there may be
some difference between pictures and your unit. Use the
instructions that apply to your unit.
A: Fuel cap
B: Throttle trigger
C: Starter handle
D: Cutting attachment guard
E: Cutting attachment
F: Drive shaft tube
G: Handle
H: Hanger
I: Ignition switch
J: Harness (if so equipped)
K: Throttle trigger lockout
L: Choke lever
M: Engine
N: Gear case
O: Combi box spanner
P: Handling instructions
Q: Goggles
R: Hex bar wrench
S: Blade cover (if so equipped)
WARNINGS AND SAFETY
INSTRUCTIONS
Pay special attention to statements preceded by the
following words:
WARNING
Indicates a strong possibility of severe personal injury or
loss of life, if instructions are not followed.
CAUTION
Indicates a possibility of personal injury or equipment
damage, if instructions are not followed.
NOTE
Helpful information for correct function and use.
Operator safety
○Wear head protection (1). (Fig. 2)
○Always wear a safety face shield or goggles (2). (Fig. 2)
○Wear approved hearing protection (3). (Fig. 2)
Long-term exposure to noise can result in permanent
hearing impairment.
Pay attention to your surroundings. Be aware of any
bystanders who may be signaling a problem.
Remove safety equipment immediately upon shutting off
engine.
○Always wear heavy, long-sleeved shirts (4) and long
pants (5) and non-slip boots (6) and gloves (7). (Fig. 2)
Do not wear loose clothing, jewelry, short pants, sandals
or go barefoot.
Secure hair so it is above shoulder length.
○Do not operate this tool when you are tired, ill or under
the influence of alcohol, drugs or medication.
○Do not operate the tool at night or under bad weather
conditions when visibility is poor. And do not operate the
tool when it is raining or right after it has been raining.
Working on slippery ground could lead to an accident if
you lose your balance.
○Never let a child or inexperienced person operate the
machine.
○Do not start the engine if there are any flammables such
as dry leaves, waste paper or fuel in the vicinity.
○Never start or run the engine inside a closed room or
building. Breathing exhaust fumes can kill.
○Keep handles free of oil and fuel.
○Keep hands away from cutting equipment.
○Do not grab or hold the unit by the cutting equipment.
○Gloves should be worn when installing or removing the
cutting attachment. Failure to do so may result in injury.
○When the unit is shut off, make sure the cutting
attachment has stopped before the unit is set down.
○When operation is prolonged, take a break periodically
so that you may avoid possible Hand-Arm Vibration
Syndrome (HAVS) which is caused by vibration.
WARNING
○Always operate the tool with proper protective equipment
and clothing. Failure to do so may result in accidents
such as burns or injuries. (Fig. 2)
○Do not touch the spark plug area or high voltage during
operation. Doing so may result in electric shock.
○Do not allow children near the tool during operation.
○Do not touch the engine, muffler cover or exhaust vent
during or shortly after operation. Doing so may result in
burn or injury.
○Antivibration systems do not guarantee that you will
not sustain Hand-Arm Vibration Syndrome or carpal
tunnel syndrome. Therefore, continual and regular users
should monitor closely the condition of their hands and
fingers. If any of the above symptoms appear, seek
medical advice immediately.
○If you are using any medical electric/electronic devices
such as a pacemaker, consult your physician as well as
the device manufacturer prior to operating any power
equipment.
Unit/machine safety
○Inspect the entire unit/machine before each use.
Replace damaged parts. Check for fuel leaks and make
sure all fasteners are in place and securely tightened.
○Replace parts that are cracked, chipped or damaged in
any way before using the unit/machine. Faulty parts may
increase the risk of accidents and may lead to an injury.
○Make sure the cutting attachment guard and harness are
properly attached. Do not operate if cutting attachment
guard and harness is not properly attached.
○Keep others away when making carburetor adjustments.
000BookCG24ECP(S).indb8000BookCG24ECP(S).indb8 2019/01/169:37:092019/01/169:37:09

English
9
○Use only accessories as recommended for this unit/
machine by the manufacturer.
○Before operation, make sure that there are no tools such
as the adjustment key or spanner still attached to the
unit.
WARNING
○Never modify the unit/machine in any way. Do not use
your unit/machine for any job except that for which it is
intended.
○Tampering with the engine voids the EU type approval of
this engine.
○Non-authorized modifications and/or accessories may
result in serious personal injury or the death of the
operator or others.
Fuel safety
○Mix and pour fuel outdoors and where there are no
sparks or flames.
○Use a container approved for fuel.
○Move at least 3 m away from fueling site before starting
engine.
○Stop engine before removing fuel cap. Do not remove
the fuel cap during operation.
○Empty the fuel tank before storing the unit/machine. It is
recommended that the fuel be emptied after each use. If
fuel is left in the tank, store so fuel will not leak.
WARNING
○Fuel is easy to ignite or get explosion or inhale fumes, so
that pay special attention when handling or filling fuel.
○Do not smoke or allow smoking near fuel or the unit/
machine or while using the unit/machine.
○Wipe up all fuel spills before starting engine.
○Store unit/machine and fuel in area where fuel vapors
cannot reach sparks or open flames from water heaters,
electric motors or switches, furnaces. etc.
○When using the unit in dry areas, make sure that fire
extinguishing equipment is readily available.
○If you shut offthe engine for refueling, make sure the unit
has cooled down before adding fuel.
Cutting safety
○Do not cut any material other than grass and brush.
○Inspect the area to be cut before each use.
Remove objects which can be thrown or become
entangled.
Do not operate in areas where there are tree roots or
rocks.
○For respiratory protection, wear an aerosol protection
mask when cutting the grass after insecticide is
scattered.
○Keep others including children, animals, bystanders and
helpers outside the 15 m hazard zone. Stop the engine
immediately if you are approached.
○Please exercise caution as engine startup may be
delayed after pulling the starter handle.
○Always keep the engine on the right side of your body.
○Hold the unit/machine firmly with both hands.
○Keep firm footing and balance. Do not over-reach.
Losing your balance during work may lead to an injury.
○Keep all parts of your body away from the muffler and
cutting attachment when the engine is running.
○Keep cutting attachment below knee level.
○Please exercise caution when operating in areas where
electrical cables or gas pipes are present.
○Do not operate the cutting attachment for anything but
clearing grass or bushes. Avoid operations where the
cutting attachment may touch water such as puddles
or dig into dirt. Failure to do so may result in injury or
damage to the unit.
○Avoid prolonged use at low speed range in which
vibration is high. Doing so may result in engine damage.
○When relocating to a new work area, or inspecting,
adjusting or exchanging the unit’s cutting attachments,
accessories, etc., be sure to shut offthe machine and
ensure that all cutting attachments are stopped.
○Never place the machine on the ground when running.
○Never touch the cutting attachment when it is rotating.
○Always ensure that the engine is shut offand any cutting
attachments have completely stopped before clearing
debris or removing grass from the cutting attachment.
○Always carry a first-aid kit when operating any power
equipment.
○Turn offthe engine and make sure the cutting attachment
has come to a full stop before removing the unit from
your body or before leaving the unit unattended.
○If you accidentally bump or drop the unit, inspect it
immediately to make sure there are no damage, cracks
or deformations.
○If the tool is operating poorly and produces strange noise
or vibrations, turn offthe engine immediately and ask
your dealer to have it inspected and repaired.
Continued use under these conditions could lead to
injury or tool damage.
○Use in accordance with local laws and regulations.
WARNING
KICKBACK DANGER (Fig. 3)
When using metal cutting attachments such as blades,
contact with obstacles such as trees or other hard
surfaces with the front or right portion of the spinning
attachment may force the unit to catch on an obstacle,
resulting in a kickback reaction towards the right side of
the operator.
Kickback may occur when the cutting attachment comes
into contact with tree stumps or rocks hidden behind
weeds. Always make sure there are no obstacles hidden
by weeds before starting work.
To minimize the danger of kickbacks when they do occur,
always position the unit to the right side of the body
during operation. With the operator properly positioned
as the cutting attachment rotates, this will reduce the
danger of the unit’s direct contact with the body.
Maintenance safety
○Maintain the unit/machine according to recommended
procedures.
○Disconnect the spark plug before performing
maintenance except for carburetor adjustments.
○Keep others away when making carburetor adjustments.
○Use only genuine HiKOKI replacement parts as
recommended by the manufacturer.
CAUTION
Do not disassemble the recoil starter. There is a
possibility of personal injury with recoil spring.
WARNING
Improper maintenance could result in serious engine
damage or in serious personal injury.
Transport and storage
○Carry the unit/machine by hand with the engine stopped
and the muffler away from your body.
○Allow the engine to cool, empty the fuel tank, and secure
the unit/machine before storing or transporting. Failure to
do so may result in fire or accidents.
○Empty the fuel tank before storing the unit/machine. It is
recommended that the fuel be emptied after each use. If
fuel is left in the tank, store so fuel will not leak.
○Store unit/machine out of the reach of children.
○Clean and maintain the unit carefully and store it in a dry
place.
○Make sure engine switch is offwhen transporting or
storing.
○When transporting and storing, either remove the cutting
attachment or place the blade cover over the blade.
000BookCG24ECP(S).indb9000BookCG24ECP(S).indb9 2019/01/169:37:092019/01/169:37:09

English
10
○You have to secure the machine during transport to
prevent loss of fuel, damage or injury.
○If a warning label cannot be read, peels offor becomes
indistinct, replace it with a new one. To purchase new
labels, contact HiKOKI Authorized Service Centers.
If situations occur which are not covered in this manual, take
care and use common sense. Contact HiKOKI Authorized
Service Centers if you need assistance.
SPECIFICATIONS
The SPECIFICATIONS of this machine are listed in the table
on page 261.
NOTE
All data subject to change without notice.
ASSEMBLY PROCEDURES
Installation of handle
(1) Loop handle type (Fig. 4)
Attach the handle to the drive shaft tube with the angle
towards the engine.
Adjust the location to the most comfortable position
before operation.
Make sure to securely attach the handle with the 2 bolts.
NOTE
If your unit has handle location label (8) on drive shaft
tube, follow the illustration.
(2) Bike handle type (Fig. 5)
Remove the handle bracket (9) from the assembly.
Place the handle and attach the handle bracket with four
bolts lightly. Adjust to appropriate position. Then attach it
firmly with the bolts.
Installation of harness
(If so equipped)
WARNING
If the product includes a harness, always make sure to
use it.
Attach the harness hook (10) to the hanger (11) on the drive
shaft tube. (Fig. 6)
Adjust the length of the harness for easy operation of the
tool.
NOTE
You may need to adjust the position of the hangar (11)
to balance the unit. To do so, loosen bolt (12) and adjust
the position of hangar (11). After adjusting as necessary,
make sure to securely tighten the bolt (12). (Fig. 6)
Installation of cutting attachment guard
WARNING
If an incorrect or faulty guard is fitted, this may cause
serious personal injury.
CAUTION
Some cutting attachment guards are equipped with
sharp line limiters. Be careful with handling it.
NOTE
○When using a trimmer head with two piece type cutting
attachment guard, attach the guard extension to the
cutting attachment guard, then tighten the bolt (13).
(Fig. 7)
○The guard extension is already attached to the cutting
attachment guard at the time of purchase.
○The guard bracket may come already mounted to the
gear case on some models.
Align the cutting attachment guard with the guard bracket
and secure it to the drive shaft tube, using the bolt and cover
bracket. (Fig. 8)
WARNING
Remove the guard extension when using metal or plastic
blades. Failure to do so may result in injury or damage to
the cutting attachment guard.
NOTE
To remove the guard extension, refer to the drawings.
Wear gloves as the extension has a sharp line limiter.
Loosen the bolt (13). Then push the three square tabs on
the guard one by one in order. (Fig. 9)
Installation of cutting attachment
WARNING
○Install the cutting attachment properly and securely as
instructed in the handling instructions.
If not attached properly or securely, it may come offand
cause serious and/or fatal injury.
○Do not install or remove cutting attachments while the
engine is running.
○Always use genuine HiKOKI cutting attachments and
metal fittings.
Installation of semi-auto cutting head
1. Function
Automatically feeds more nylon cutting line when it is
tapped at low rpm (not greater than 4500 min-1).
Specifications
Code
No.
Type of
attaching
screw
Direction of
rotation
Size of
attaching
screw
6696454 Female screw Counter-
clockwise M10xP1.25- LH
Applicable nylon cord
Cord diameter: Φ3.0 mm Length: 2 m
Cord diameter: Φ2.4 mm Length: 4 m
2. Precautions
○The case must be securely attached to the cover.
○Check the cover, case and other components for cracks
or other damage.
○Check the case and button for wear.
If the wear limit mark (14) on the case is no longer visible
or there is a hole in the bottom (15) of the button, change
the new parts immediately. (Fig. 10)
○The cutting head must be securely mounted to the unit’s
gear case/cutter case.
○If the cutting head does not feed cutting line properly,
check that the nylon line and all components are properly
installed. Contact HiKOKI Authorized Service Centers if
you need assistance.
WARNING
For HiKOKI heads, use only flexible, non-metallic line
recommended by the manufacturer. Never use wire or
wire ropes. They can break offand become a dangerous
projectile.
3. Installation (Fig. 11)
Insert the allen wrench (16) into the hole of the gear
case/cutter case in order to lock the drive shaft tube.
Install cutting head on gear case/cutter case of grass
trimmers/brush cutters. The mounting nut is left-hand-
threaded. Turn clockwise to loosen/counter-clockwise to
tighten.
NOTE
Since the cutter holder cap is not used here, keep it for
when a metal blade is used, if so equipped.
000BookCG24ECP(S).indb10000BookCG24ECP(S).indb10 2019/01/169:37:092019/01/169:37:09

English
11
4. Adjusting line length
Set the engine speed as low as possible and tap the
head on the ground. The nylon line will be drawn out
about 3 cm with each tap. (Fig. 12)
Also, you can extend the nylon line by hand but the
engine must be completely stopped. (Fig. 13)
Adjust the nylon line to the proper length of 11–14 cm
before each operation.
Installation of cutting blade
CG24ECP (S) / CG27EC (S) / CG27ECP (S) (Fig. 14)
Insert the alien wrench (17) into the hole of the gear case in
order to lock the shaft.
Assemble in the following order: Cutter holder (A) (18),
blade (19), cutter holder (B) (20), nut cover (21).
Tighten the fixing nut with the box wrench. Please note that
the cutter fixing nut (22) has left-handed threads (clockwise
to loosen/ counter-clockwise to tighten).
NOTE
○When installing cutter holder (B) (20), be sure to set
concave side upward.
○When installing or removing a blade, make sure to wear
gloves and place the blade cover over the blade.
CAUTION
Check a nut cover (21) for wear or cracks before
operation. If any damage or wear is found, replace it, as
it is an article of consumption.
WARNING
○When installing a cutting blade, make sure that there are
no cracks or any damage in it and that the cutting edges
are facing the correct direction.
○Remove any surface grit from blade installation fittings
(cutter holder (A) (18), cutter holder (B) (20), nut
cover (21), nut (22)). Failure to do so may result in the
loosening of nuts.
○The protrusion of the cutter holder (A) (18) may become
misaligned with the blade (19) while tightening nut
(22). Before operation, make sure the blade has been
properly installed. (Fig. 15)
○Rotate the blade by hand and make sure there is no
rocking or abnormal noise. Rocking may cause abnormal
vibrations or result in the loosening of nuts.
CG24ECMP (S) / CG27ECMP (S) (Fig. 16)
When installing a cutting blade, make sure that there are no
cracks or any damage in it and that the cutting edges are
facing the correct direction.
NOTE
○When installing cutter holder cap (23), be sure to set
concave side upward.
○Press the stopper pin (24) of the angle transmission in
order to lock the cutter holder (25). Please note that the
cutter fixing bolt or nut (26) has left-handed threads,
(clockwise to loosen/ counter-clockwise to tighten).
Tighten the fixing bolt or nut with the box wrench.
CAUTION
○Before operation, make sure the blade has been properly
installed.
○If your unit is equipped with protection cover under a
cutting blade, check it for wear or cracks before operation.
If any damage or wear is found, replace it, as it is an article
of consumption.
○You have to wear gloves when handling the cutting
blade.
WARNING
For HiKOKI heads, use only flexible, non-metallic line
recommended by the manufacturer. Never use wire or
wire ropes. They can break offand become a dangerous
projectile.
OPERATING PROCEDURES
Fuel (Fig. 17)
WARNING
○The trimmer is equipped with a two-stroke engine.
Always run the engine on fuel, which is mixed with oil.
Provide good ventilation, when fueling or handling fuel.
○Fuel is highly flammable and it is possible to get seriously
injured when inhaling or spilling on your body.
Always pay attention when handling fuel. Always have
good ventilation when handling fuel inside building.
Fuel
○Always use branded 89 octane unleaded gasoline.
○Use genuine two-cycle oil or use a mix between 25:1 to
50:1, please consult about the mixture ratio to HiKOKI
Authorized Service Centers.
○If genuine oil is not available, use an anti-oxidant added
quality oil expressly labeled for air-cooled 2-cycle engine
use (JASO FC GRADE OIL or ISO EGC GRADE). Do not
use BIA or TCW (2-stroke water-cooling type) mixed oil.
○Never use multi-grade oil (10 W/30) or waste oil.
○Never mix fuel and oil in machine’s fuel tank. Always mix
fuel and oil in a separate clean container.
Always start by filling half the amount of gasoline, which is
to be used.
Then add the whole amount of oil. Mix (shake) the fuel
mixture. Add the remaining amount of gasoline.
Mix (shake) the fuel-mix thoroughly before filling the fuel
tank.
Mixing amount of two-cycle oil and gasoline
Gasoline (Liter) Two-cycle oil (ml)
Ratio 50:1 Ratio 25:1
0.5 10 ——— 20
1 20 ——— 40
2 40 ——— 80
4 80 ——— 160
Fueling
WARNING
○Always shut offthe engine and let it cool for a few
minutes before refueling.
Do not smoke or bring flames or sparks near the fueling
site.
○Slowly open the fuel tank, when filling up with fuel, so
that possible over-pressure disappears.
○Tighten the fuel tank cap carefully, after fueling.
○Always move the unit at least 3 m from the fueling area
before starting.
○Always wash any spilled fuel from clothing immediately
with soap.
○Be sure to check any fuel leakage after refueling.
○Before fueling, in order to remove static electricity from
the main body, the fuel container and the operator,
please touch the ground that is slightly damp.
Before fueling, clean the tank cap area carefully, to ensure
that no dirt falls into the tank. Make sure that the fuel is well
mixed by shaking the container, before fueling.
Starting
WARNING
○Before starting the tool, ensure that the cutting
attachment is not touching any objects or the ground.
Otherwise, the cutting attachment may unexpectedly
rotate and cause an injury.
000BookCG24ECP(S).indb11000BookCG24ECP(S).indb11 2019/01/169:37:092019/01/169:37:09

English
12
○Ensure that the cutting attachment does not rotate while
the engine is idling. If it does rotate, adjust the idle speed
according to the instructions in “Idle speed adjustment” in
the “MAINTENANCE” section. If the cutting attachment
still rotates after this adjustment, immediately stop the
engine and cease use, then bring the tool to the nearest
HiKOKI Authorized Service Center.
CAUTION
For the CG24ECP / CG27EC / CG27ECP, ensure that
the throttle outer end is in the holder.
(1) Starting the cold engine
1. Set ignition switch (27) to ON position. (Fig. 18)
2. Push priming bulb (28) about ten times so that fuel flows
into carburetor. (Fig. 19)
3. Set choke lever (30) to START position (closed) (A).
(Fig. 20)
4. Pull recoil starter briskly, taking care to keep the handle
in your grasp and not allowing it to snap back. (Fig. 21)
5. When you hear the engine want to start, return choke
lever to RUN position (open) (B). (Fig. 20)
6. Pull recoil starter briskly again. (Fig. 21)
NOTE
If engine does not start, repeat procedures from 2 to 5.
7. Then allow the engine about 2–3 minutes to warm up
before subjecting it to any load.
8. Check that the cutting attachment does not rotate when
the engine is idling.
(2) Starting the warm engine
Use only 1, 2, 6 and 8 of the starting procedure for a cold
engine.
If the engine does not start, use the same starting
procedure as for a cold engine.
Cutting
WARNING
○Always use the harness (if so equipped) and wear the
proper attire and protective equipment when operating
the unit. (Fig. 22)
○Keep others including children, animals, bystanders and
helpers outside the 15 m hazard zone. Stop the engine
immediately if you are approached. (Fig. 23)
○When grass or vines wrap around attachment, stop
engine and attachment and remove them. Continuing
operation with grass or vines wrapped around the
attachment may result in damages such as early
abrasion of the clutch.
CAUTION
Use and points of caution will vary depending on the type
of cutting attachment. For safe use, make sure to follow
the instructions and guidelines provided with each type.
NOTE
○Press the quick release button or pull emergency release
flap (If so equipped) in the event of emergency. (Fig. 24)
○Use in accordance with local laws and regulations.
CG24ECMP/CG27ECMP only
●Governor mechanism
The tool is equipped with a feature that keeps the engine
rotation speed consistent at the speed that is set. This
maintains a stable engine rotation speed even when the
burden applied to the tool bit becomes large, allowing for
steady operation.
However, if a burden larger than the tolerance is applied,
the engine rotation will decrease; in this case, adjust the
burden by decreasing the amount of material being cut.
The governor mechanism does not function when the
throttle is fully open.
(1) Using a semi-auto cutting head
○Set the engine at high speed when using this attachment.
○Cut grass from left to right. The cut grass will be
discharged away from the body, minimizing transfer to
your clothes. (Fig. 25)
○With nylon cord, use about 2 cm of the end of the cord
to cut grass. Using the full length of the cord will reduce
rotation speed and make cutting difficult.
NOTE
Automatically feeds more nylon cutting line when it is
tapped at low rpm (not greater than 4500 min-1).
WARNING
○This product is equipped with a line limiter that will
automatically cut any excess cord. When operating the
unit, do not remove the guard or line limiter.
As the resistance is greater for nylon cords as opposed
to blades, mishandling could increase engine load and
result in damage.
○Do not use with the engine set at low speeds. If the
engine speed is low, grass may wrap around the
attachment, causing the clutch to slip which could result
in clutch abrasion.
○With nylon cord cutters, always use over 15 cm of cord.
If the length of the cord is too short, rotation speed will
increase and may cause damage to the nylon cord
cutter. As the curved drive shaft tube model in particular
is not equipped with a deceleration mechanism, the
possibility of increased rotation speed for the cutting
attachment is high.
(2) Using a blade
○Adjust engine speed according to the resistance of the
grass. For soft grass, use low speeds, For tough clumps
of grass, use high speeds.
○Cut grass from right to left, using the left side of the blade
to cut. (Fig. 26)
○Slightly tilting the blade to the left while cutting will pile
the cut grass to the left, making collection easy.
NOTE
Excessively increasing rotation speed may cause
increased blade wear, vibration and noise. It will also
result in increased fuel consumption.
WARNING
○Blade thrust may occur when the spinning blade contacts
a solid object in the critical area.
A dangerous reaction may occur causing the entire unit
and operator to be thrust violently. This reaction is called
blade thrust. As a result, the operator may lose control
of the unit which may cause serious or fatal injury. Blade
thrust is more likely to occur in areas where it is difficult
to see the material to be cut.
○If cutting attachment should strike against stones or
other debris, stop the engine and make sure that the
attachment and related parts are undamaged.
Stopping (Fig. 27)
Decrease engine speed and run at an idle for a few minutes,
then turn offignition switch (27).
WARNING
A cutting attachment can injure while it continues to spin
after the engine is stopped or power control is released.
When the unit is turned off, make sure the cutting
attachment has stopped before the unit is set down.
Throttle adjustment knob (Fig. 28)
The cutting blade speed setting for when the throttle trigger
is fully pulled can be adjusted.
To increase the speed setting, turn the throttle adjustment
knob (31) clockwise, and to decrease the speed setting, turn
the knob counter-clockwise.
000BookCG24ECP(S).indb12000BookCG24ECP(S).indb12 2019/01/169:37:092019/01/169:37:09

English
13
WARNING
○While operating the tool, do not make adjustments using
one hand.
○Hold the tool securely and pull the throttle trigger while
ensuring that the cutting blade is not touching the ground
or any objects.
MAINTENANCE
MAINTENANCE, REPLACEMENT OR REPAIR OF THE
EMISSION CONTROL DEVICES AND SYSTEMS MAY
BE PERFORMED BY ANY NON-ROAD ENGINE REPAIR
ESTABLISHMENT OR INDIVIDUAL.
Carburetor adjustment (Fig. 29)
The carburetor is a precision part that mixes air and fuel, and
it is designed to ensure high performance from the engine.
Before the tool is shipped from the factory, its carburetor is
adjusted during a test run. Only make adjustments if it is
necessary because of environmental conditions (the climate
or atmospheric pressure), the type of fuel, the type of two-
cycle oil, etc.
WARNING
○Because the carburetor is manufactured with a high
degree of precision, do not disassemble it.
○For this product, the only setting of the carburetor that
can be adjusted is the idle speed (T).
○Never start the engine without the complete clutch cover
and tube assembled! Otherwise the clutch can come
loose and cause personal injuries.
T = Idle speed adjustment screw.
Idle speed adjustment (T)
WARNING
○When the engine is stopped, do not excessively turn
the idle speed adjustment screw (T) in a clockwise
direction. Otherwise, when the engine starts, the cutting
attachment may unexpectedly rotate and cause an
injury.
○Do not adjust the idle speed adjustment screw (T) for
any reason other than to adjust the idling.
Run the engine while adjusting the idling.
(1) If the engine stops during idling
Start the engine, and slowly turn the idle speed
adjustment screw (T) in a clockwise direction until it is in
a position at which the engine rotates smoothly. At that
time, ensure that the cutting attachment is not spinning.
(2) If the cutting attachment rotates during idling
Slowly turn the idle speed adjustment screw (T) in a
counter-clockwise direction until it is in a position at
which the cutting attachment does not rotate. At that
time, ensure that the rotation of the engine is smooth.
WARNING
If the cutting attachment still rotates after adjustment of
the idle speed adjustment screw (T), immediately stop
the engine and cease use, then contact the nearest
HiKOKI Authorized Service Center.
Air filter (Fig. 30)
The air filter (32) must be cleaned from dust and dirt in order
to avoid:
○Carburetor malfunctions.
○Starting problems.
○Engine power reduction.
○Unnecessary wear on the engine parts.
○Abnormal fuel consumption.
Clean the air filter daily or more often if working in
exceptionally dusty areas.
Loosen the screw (33), then open the air filter cover and
remove the air filter (32). Rinse it in warm soap suds.
Check that the filter is dry before reassembly.
An air filter that has been used for some time cannot be
cleaned completely. Therefore, it must regularly be replaced
with a new one. A damaged filter must always be replaced.
Fuel filter (Fig. 31)
Remove the fuel filter (34) from the fuel tank, and replace it if
it is dirty.
NOTE
A blocked fuel filter (34) can prevent the supply of fuel and
cause a rotation malfunction of the engine.
Spark plug (Fig. 32)
The spark plug condition is influenced by:
○An incorrect carburetor setting.
○Wrong fuel mixture (too much oil in the gasoline)
○A dirty air filter.
○Hard running conditions (such as cold weather).
These factors cause deposits on the spark plug electrodes,
which may result in malfunction and starting difficulties. If
the engine is low on power, difficult to start or runs poorly at
idling speed, always check the spark plug first.
If the spark plug is dirty, clean it and check the electrode
gap. Re-adjust if necessary. The correct gap is 0.6 mm. The
spark plug should be replaced after about 100 operation
hours or earlier if the electrodes are badly eroded.
NOTE
In some areas, local law requires using a resistor spark
plug to suppress ignition signals. If this machine was
originally equipped with resistor spark plug, use same
type of spark plug for replacement.
Gear case (Fig. 33)
Check gear case or angle gear for grease level about every
50 hours of operation by removing the grease filler plug on
the side of gear case.
If no grease can be seen on the flanks of the gears, fill the
gear case with quality lithium based multipurpose grease up
to 3/4. Do not completely fill the gear case.
CAUTION
○Make sure to remove any dirt or grit when attaching the
plug to its original position.
○Before attempting inspection or maintenance of the gear
case, make sure the case has cooled.
Semi-auto cutting head
Nylon line replacement
1. Remove the case (35) by firmly pushing inward the
locking tabs with your thumbs as shown in Fig. 34.
2. After removing the case, take out the reel and discard
the remaining line.
3. Fold the new nylon line unevenly in half as shown in
picture.
Hook the U-shaped end of the nylon line into the groove
(36) on the center partition of the reel.
Wind both halves of the line on the reel in the same
direction, keeping each half of the line on its own side of
the partition. (Fig. 35)
4. Push each line into the stopper holes (37), leaving the
loose ends approx. 10 cm in length. (Fig. 36)
5. Insert both loose ends of the line through the cord guide
(38) when placing the reel in the case. (Fig. 37)
NOTE
When placing a reel in the case, try to line up the stopper
holes (37) with the cord guide (38) for easier line release
later.
6. Place the cover over the case so that the cap locking
tabs (39) on the case meet the long holes (40) on the
cover. Then push the case securely until it clicks into
place. (Fig. 38)
000BookCG24ECP(S).indb13000BookCG24ECP(S).indb13 2019/01/169:37:092019/01/169:37:09

English
14
7. The initial cutting line length should be approx. 11–14 cm
and should be equal on both sides. (Fig. 39)
Blade (Fig. 40)
WARNING
Wear protective gloves when handling or performing
maintenance on the blade.
○Use a sharp blade. A dull blade is more likely to snag and
thrust.
Replace the fastening nut if it is damaged and hard to
tighten.
○When replacing blade, purchase one recommended by
HiKOKI, with a 25.4 mm (one inch) fitting hole.
○In the case of a 3 or 4 tooth blade (41), it can be used on
either side.
○Use the correct blade for the type of work.
○When replacing blades, use appropriate tools.
○When cutting edges become dull, re-sharpen or file
as shown in the illustration. Incorrect sharpening may
cause excessive vibration.
○Discard blades that are bent, warped, cracked, broken
or damaged in any way.
NOTE
When sharpening blade it is important to maintain an
original shape of radius at the base of the tooth to avoid
cracking.
For long-term storage
Drain all fuel from the fuel tank. Start and let engine run until
it stops. Repair any damage which has resulted from use.
Clean the unit with a clean rag, or the use of high pressure
air hose. Put a few drops of two-cycle engine oil into the
cylinder through the spark plug hole, and spin the engine
over several times to distribute oil.
Cover the unit and store it in a dry area.
Maintenance schedule
Below you will find some general maintenance instructions.
For further information please contact HiKOKI Authorized
Service Centers.
Daily maintenance
○Clean the exterior of the unit.
○Check that the harness is undamaged.
○Check the cutting attachment guard for damage or
cracks. Change the guard in case of impacts or cracks.
○Check that the cutting attachment is properly centered,
sharp, and without cracks. An off-center cutting
attachment induces heavy vibrations that may damage
the unit.
○Check that the cutting attachment nut is sufficiently
tightened.
○Make sure that the blade cover is undamaged and that it
can be securely fitted.
○Check that nuts and screws are sufficiently tightened.
○Check that the unit is undamaged and free of defects.
Weekly maintenance
○Check the starter, especially the cord and return spring.
○Clean the exterior of the spark plug.
○Remove the spark plug and check the electrode gap.
Adjust it to 0.6 mm, or change the spark plug.
○Check that the angle gear is filled with grease up to 3/4.
○Clean the air filter.
Monthly maintenance
○Rinse the fuel tank with gasoline.
○Clean the exterior of the carburetor and the space
around it.
○Clean the fan and the space around it.
SELECTING ACCESSORIES
The accessories of this machine are listed on page 262.
000BookCG24ECP(S).indb14000BookCG24ECP(S).indb14 2019/01/169:37:092019/01/169:37:09

English
15
SELECTING CUTTING ATTACHMENTS
Recommended accessories for each model are presented in the table below.
For purchases, contact HiKOKI Authorized Service Centers.
Please check carefully as those accessories not marked with “●” cannot be attached.
List of recommended accessories
Type Name
Specification LOOP HANDLE BIKE HANDLE
Diameter
Feed System Adapter
or
No. of Teeth (Blade)
Blade Thickness (mm)
or
Trimmer line Diameter
(mm)
CG24ECP (SL) CG27ECP (SL) CG24ECP (S) CG24ECMP (S) CG27EC (S) CG27ECP (S) CG27ECMP (S)
ALUMINUM HEADS
NYLON HEAD
CH-100
(W/NYLON LINE) 4” Pre-Cut
Line 2.2 – 3.0
●●●●
NYLON HEAD
CH-100 ●●●●
NYLON HEAD
CH-300
(W/CUTTER HOLDER
CAP) 5” Manual line
feed 2.2 – 2.7
●●
NYLON HEAD
CH-300 ●●
TAP & GO
NYLON HEADS
NYLON HEAD
BF-4 4” R M8 x 1.25
Nut 2.2 – 3.0
NYLON HEAD
BF-5 5”
L M10 x
1.25 Nut
L M8 x 1.25
Nut
2.2 – 3.0 ●●●●
BLADES
BLADE
B4/9/1.6 9” 4 1.6 ●●●●
BLADE
B4/10/1.6 10” 4 1.6 ●●●●
BLADE
B3/10/1.8 10” 3 1.8 ●●●●
000BookCG24ECP(S).indb15000BookCG24ECP(S).indb15 2019/01/169:37:092019/01/169:37:09

English
16
TROUBLESHOOTING
Use the inspections in the table below if the tool does not operate normally. If this does not remedy the problem, consult your
dealer or the HiKOKI Authorized Service Center.
Condition Cause Remedy
Engine does not
start
Fuel
system
Fuel tank is empty or fuel level is low Fill the fuel tank with the correct fuel mix
(25:1-50:1)
Fuel tank contains old fuel (offensive odor) Replace with new fuel
Too much fuel is absorbed and spark
plug is wet
1.
Disconnect the spark plug and allow to dry
2.Pull the starter handle 5 or 6 times to
remove the surplus fuel
3.Attach the spark plug
4.Set the choke lever to RUN position and
pull the starter handle
Fuel filter is clogged with dirt Clean the fuel filter
Fuel pipe is bent or disconnected Ensure that the fuel flows smoothly
Carburetor malfunction Contact HiKOKI Authorized Service Centers
Electrical
system
Stop switch lead has short-circuited Contact HiKOKI Authorized Service Centers
Spark plug is dirty Replace or clean the spark plug
Electrode gap is too big Adjust the gap to 0.6mm
Poor connection between high tension
cable and spark plug Reconnect
Electrical system malfunction Contact HiKOKI Authorized Service Centers
Other Muffler exhaust port is clogged with
carbon Contact HiKOKI Authorized Service Centers for repair
Engine starts
but cuts out
straightaway
Engine is apt to
cut out
Fuel
system
Fuel tank is empty or fuel level is low Fill the fuel tank with the correct fuel mix
(25:1-50:1)
Fuel tank contains old fuel (offensive odor) Replace with new fuel
Two-cycle oil has not been added Contact HiKOKI Authorized Service Centers
Choke lever is in START position Set the choke lever to RUN position
Air has got into fuel system Reconnect the fuel pipe or joint
Carburetor malfunction Contact HiKOKI Authorized Service Centers
Electrical
system
Ignition failure
Spark plug failure Replace with new spark plug
Electrical system failure Contact HiKOKI Authorized Service Centers
Other
Engine overheating
Wrong spark plug model Replace with designated part
See “SPECIFICATIONS”
Dirty air cleaner Clean
Carbon clogging (muffler exhaust port) Clean
Insufficient compression (piston, piston
ring, cylinder) Contact HiKOKI Authorized Service Centers
Abnormal vibration
Cutting attachment is not properly
installed See “Installation of cutting attachment”
Handle, handle bracket or other
fastening part is loose Check and tighten
Blade is bent or damaged Replace with new blade
Grass is wrapped round gear case Remove grass
Engine is running but blade
does not move
Movement is poor
Grass is wrapped round gear case Remove grass and dirt
000BookCG24ECP(S).indb16000BookCG24ECP(S).indb16 2019/01/169:37:092019/01/169:37:09

English
17
Condition Cause Remedy
Engine does not stop Stop switch failure
Set the choke lever to START position to
stop the engine
Cease use immediately and contact HiKOKI
Authorized Service Centers
Engine stops when throttle is
closed
Idle speed is too low Contact HiKOKI Authorized Service Centers
Blade continues rotating when
throttle is closed
Idle speed is too high
Throttle wire is too taut Contact HiKOKI Authorized Service Centers
000BookCG24ECP(S).indb17000BookCG24ECP(S).indb17 2019/01/169:37:092019/01/169:37:09

Deutsch
18
(Übersetzung der Original-Gebrauchsanweisung)
SYMBOLBEDEUTUNGEN
HINWEIS: Nicht alle Geräte sind mit diesen Symbolen versehen.
Symbole
WARNUNG
Die folgenden Symbole werden für dieses Gerät verwendet. Achten Sie darauf, diese vor der Verwendung zu
verstehen.
Rasentrimmer / Heckenschere Kraftstoff-Öl-Gemisch
Es ist wichtig, dass Sie sich mit den
nachfolgenden Vorsichtsmaßnahmen und
Warnungen vertraut machen und diese
befolgen. Unvorsichtige oder unsachgemäße
Handhabung des Geräts kann schwere oder
tödliche Verletzungen zur Folge haben.
Einstellung des Leerlaufs
Lesen, verstehen und befolgen Sie alle
Warnungen und Anweisungen in dieser
Anleitung und am Gerät selbst. Ansaugpumpe
Bei Gebrauch des Geräts immer Gesichts-,
Kopf- und Gehörschutz tragen. Garantierter Schallleistungspegel
Wenn dieses Zeichen am Gerät angebracht ist,
keine starren Messer/Metallmesser verwenden.
Ein Messerstoß ist möglich, wenn das rotierende
Messer im kritischen Bereich mit einem massiven
Gegenstand in Berührung kommt. In diesem Fall
kann es zu einer gefährlichen Reaktion kommen,
bei der das gesamte Gerät und der Bediener
einem heftigen Stoß ausgesetzt werden.
Diese Reaktion wird als Messerstoß bezeichnet.
Das Resultat ist u.U., dass der Bediener die
Kontrolle über das Gerät verliert und schwere
oder lebensgefährliche Verletzungen davonträgt.
Messerstöße sind in Arbeitsbereichen, wo das
zu schneidende Vegetationsmaterial nur schwer
einsehbar ist, wahrscheinlicher.
Halten Sie alle Kinder, Zuschauer und Helfer
15 m vom Gerät entfernt. Falls sich jemand nähert,
den Motor und das Zubehör sofort ausschalten.
Auf hochgeschleuderte Gegenstände achten. Heiße Oberfläche – Kontakt mit heißer
Oberfläche kann zu schweren Verbrennungen
führen.
min-1
Zeigt die maximale Drehzahl der Welle an.
Verwenden Sie kein Schneidzubehör, dessen
Maximaldrehzahl unter diesem Wert liegt.
Das Heckenschneide-Zubehör kann für Modelle
mit diesem Aufkleber nicht verwendet werden.
Handschuhe sind dann zu tragen, wenn
dies notwendig ist, z.B. bei der Montage der
Schneide-Ausrüstung.
Bezeichnet den Griffstangenplatz. Pfeile, die
den Grenzwert für die Griffposition anzeigen.
Rutschfestes Schuhwerk tragen, das guten Halt
bietet. Verschiebung
Choke – Betriebsposition (Offen) Zündkerze
Choke – Start Position (Geschlossen) Idle Leerlaufdrehzahl
Ein/Start Drehzahl der Ausgangswelle
Aus/Stopp PMax. Motorleistung
Notfallstopp Kraftstofftankvolumen
000BookCG24ECP(S).indb18000BookCG24ECP(S).indb18 2019/01/169:37:092019/01/169:37:09

Deutsch
19
Trockengewicht (ohne Kraftstoff, Schneide-
Zubehör, Gurtzeug und Schutz-Schneide-
Zubehör)
LWA, Ra(G)
2000/14/EC
Garantierter Schalldruck-Leistungspegel LwA
nach 2000/14/EC
Hochdrehen
Schneide-Zubehör
ahv, eq(F)
Vibrationspegel nach ISO 22867
Vorderer oder linker Griff/ Entsprechung*
LpA, eq
ISO22868
Schalldruckpegel LpA nach ISO 22868
Entsprechung*
ahv, eq(R)
Vibrationspegel nach ISO 22867
Hinterer oder rechter Griff/ Entsprechung*
LWA, Ra(M)
2000/14/EC
Gemessener Schalldruck-Leistungspegel LwA
nach 2000/14/EC
Hochdrehen KUnsicherheit
Vor dem Gebrauch Ihres Geräts
• Bedienungsanleitung sorgfältig durchlesen.
• Montage und Einstellung der Schneide-Ausrüstung kontrollieren.
• Gerät starten und Vergasereinstellung prüfen. Siehe „WARTUNG“.
HINWEIS: Die entsprechenden Geräusch- / Vibrationspegel werden als zeitgewichtete Energiesumme für Geräusch- /
Vibrationspegel unter verschiedenen Arbeitsbedingungen mit folgender Zeitaufteilung berechnet:
* 1/2 Leerlauf, 1/2 Hochgedreht.
WAS IST WAS? (Abb. 1)
Da dieses Handbuch für mehrere Modelle gilt, können die
Abbildungen gegebenenfalls von Ihrem Gerät abweichen.
Verwenden Sie die für Ihr Gerät geltenden Anweisungen.
A: Tankdeckel
B: Gaszug
C: Startergriff
D: Schutz Schneide-Zubehör
E: Schneide-Zubehör
F: Antriebswellenrohr
G: Griff
H: Aufhänger
I: Zündschalter
J: Gurtzeug (je nach Ausstattung)
K: Gaszugsperre
L: Chokehebel
M: Motor
N: Getriebegehäuse
O: Kombischlüssel
P: Bedienungsanleitung
Q: Brille
R: Sechskantschlüssel
S: Klingenabdeckung (je nach Ausstattung)
WARN- UND SICHERHEITSHINWEISE
Abschnitte, denen besondere Aufmerksamkeit gewidmet
werdensollte,werdendurchfolgendeWörterhervorgehoben:
WARNUNG
Kennzeichnet Anweisungen, deren Nichtbefolgung eine
schwere Verletzung oder den Tod zur Folge haben kann.
VORSICHT
Kennzeichnet Anweisungen, deren Nichtbefolgung eine
Verletzung oder Sachschaden zur Folge haben kann.
HINWEIS
Kennzeichnet nützliche Informationen für den
vorschriftsmäßigen Gebrauch.
Bedienersicherheit
○Kopfschutz tragen (1). (Abb. 2)
○Immer einen Gesichtsschutz oder Schutzbrille tragen
(2). (Abb. 2)
○Vorschriftsmäßigen Gehörschutz tragen (3). (Abb. 2)
Über einen längeren Zeitraum Lärm ausgesetzt sein,
kann zu bleibenden Hörschäden führen.
Die Umgebung im Auge behalten. Auf Beistehende
achten, die unter Umständen ein Problem signalisieren.
Die Schutzbekleidung erst nach Abstellen des Motors
wieder ablegen.
○Immer schwere, langärmlige Shirts tragen (4) und lange
Hosen (5) und rutschfeste Stiefel (6) und Handschuhe
(7). (Abb. 2)
Das Arbeiten mit lockerer Kleidung, Schmuck, kurzen
Hosen, Sandalen oder barfuß ist zu vermeiden.
Das Haar ist so zu sichern, dass es nicht bis zu den
Schultern herunterhängt.
○Bedienen Sie das Gerät nicht, wenn Sie übermüdet
oder krank sind oder unter Alkohol-, Drogen- oder
Medikamenteneinfluss stehen.
○Bedienen Sie das Werkzeug nicht bei Nacht oder unter
schlechten Wetterbedingungen, wenn die Sicht schlecht
ist. Und bedienen Sie das Werkzeug nicht, wenn es
regnet oder unmittelbar, nachdem es geregnet hat.
Arbeiten auf rutschigem Untergrund kann zu einem
Unfall führen, wenn Sie Ihr Gleichgewicht verlieren.
○Lassen Sie niemals ein Kind oder eine unerfahrene
Person die Maschine bedienen.
○
Starten Sie den Motor nicht, wenn leicht Entflammbares wie
trockenes Laub, Papierabfall oder Kraftstoffin der Nähe sind.
○Starten oder betreiben Sie denn Motor niemals innerhalb
geschlossener Räume oder in einem Gebäude.
Einatmen der Abgase kann den Tod zur Folge haben.
○Halten Sie die Griffe frei von Öl und Kraftstoff.
○Berühren Sie nicht die Schneide-Ausrüstung.
○Fassen oder halten Sie das Gerät nicht an der
Schneideausrüstung.
○Beim Anbau oder Entfernen der Schneide-Ausrüstung
sollten Handschuhe getragen werden. Wird dies nicht
beachtet, kann es zu Verletzungen kommen.
○Wenn das Gerät ausgeschaltet wird, achten Sie darauf,
dass die Schneide-Ausrüstung gestoppt hat, bevor Sie
das Gerät auf den Boden stellen.
○
Bei längerem Betrieb regelmäßig eine Pause einlegen, als
vorbeugende Maßnahme gegen die Weißfingerkrankheit,
die durch Vibrationen verursacht wird.
WARNUNG
○
Bedienen Sie das Werkzeug immer mit geeigneter
Schutzausrüstung und -kleidung. Nichtbeachtung kann zu
Unfällen wie Verbrennungen und Verletzungen führen. (Abb. 2)
○Berühren Sie während des Betriebs nicht den Bereich
der Zündkerze oder Hochspannung. Dadurch könnte es
zu einem elektrischen Schlag kommen.
○Gestatten Sie Kindern nicht, sich während des Betriebs
in der Nähe des Werkzeugs aufzuhalten.
000BookCG24ECP(S).indb19000BookCG24ECP(S).indb19 2019/01/169:37:092019/01/169:37:09

Deutsch
20
○Berühren Sie während oder kurz nach dem Betrieb
nicht den Auspuff, Schalldämpfer oder das Abgasventil.
Dadurch könnte es zuVerbrennungen oder Verletzungen
kommen.
○Antivibrationssysteme sind kein garantierter
Schutz gegen die Weißfingerkrankheit oder
Karpaltunnelsyndrom. Daher ist bei regelmäßigem
Dauereinsatz des Geräts der Zustand von Fingern
und Handwurzel aufmerksam zu beobachten. Falls
Symptome der obengenannten Krankheiten auftreten,
sofort einen Arzt aufsuchen.
○Träger eines medizinischen elektrischen bzw.
elektronischen Geräts (Herzschrittmacher u.dgl.) sollten
sich vor dem Gebrauch eines Motorgeräts von Ihrem
Arzt sowie dem Hersteller des Geräts diesbezüglich
beraten lassen.
Geräte-/Maschinensicherheit
○Das Gerät/die Maschine vor jedem Einsatz einer
eingehenden Kontrolle unterziehen. Beschädigte
Teile ersetzen. Das Gerät auf auslaufenden
Kraftstoffuntersuchen und sicherstellen, dass alle
Befestigungsteile vorhanden und sicher angezogen
sind.
○Ersetzen Sie Teile, die gerissen, gebrochen oder
anderweitig beschädigt sind, bevor Sie das Gerät/die
Maschine verwenden. Fehlerhafte Teile können das
Risiko von Unfällen erhöhen und zu einer Verletzung
führen.
○Achten Sie darauf, dass der Schutz der Schneide-
Ausrüstung und das Gurtzeug korrekt befestigt sind.
Funktioniert nicht, wenn der Schutz der Schneide-
Ausrüstung und das Gurtzeug nicht korrekt befestigt
sind.
○Halten Sie während der Vergasereinstellung andere
Personen fern.
○Verwenden Sie nur Zubehör, das vom Hersteller für
dieses Gerät/diese Maschine empfohlen wurde.
○Achten Sie vor der Inbetriebnahme darauf, dass keine
Werkzeuge wie der Einstellschlüssel oder Spanner noch
am Gerät befestigt sind.
WARNUNG
○Bauen Sie das Gerät/die Maschine in keiner Weise um.
Das Gerät nur für die Zwecke verwenden, für die es
bestimmt ist.
○Durch Eingriffe am Motor erlischt die EU-
Betriebserlaubnis für diesen Motor.
○Nichtautorisierter Umbau und/oder Zubehör können zu
schweren Verletzungen oder zum Tod des Bedieners
oder anderer Personen führen.
Kraftstoffsicherheit
○Mischen und füllen Sie den Kraftstoffdraußen ein, wo
sich keine Funken oder Flammen befinden.
○Verwenden Sie einen Behälter, der für Kraftstoff
zugelassen ist.
○Gehen Sie mindestens 3 m von der Betankungsstelle
weg, bevor Sie den Motor starten.
○Stoppen Sie den Motor, bevor Sie den Tankdeckel
entfernen. Entfernen Sie den Tankdeckel nicht während
des Betriebs.
○Leeren Sie den Kraftstofftank, bevor Sie das Gerät/die
Maschine einlagern. Es wird empfohlen, den Kraftstoff
nach jedem Einsatz abzulassen. Mit gefülltem Tank ist
das Gerät so zu lagern, dass kein Kraftstoffausläuft.
WARNUNG
○Kraftstoffist leichtentzündlich oder kann explodieren
oder die Dämpfe eingeatmet werden, lassen Sie deshalb
besondere Sorgfalt walten, wenn Sie mit Kraftstoff
umgehen oder ihn einfüllen.
○Rauchen Sie nicht und erlauben Sie anderen Personen
nicht das Rauchen in der Nähe des Geräts/der
Maschine oder während der Verwendung des Geräts/
der Maschine.
○Wischen Sie vor dem Starten des Motors alle
Kraftstoffspritzer weg.
○Gerät und Kraftstoffan einem Ort lagern, wo
Kraftstoffdämpfe nicht mit Funken oder offenen Flammen
von Wassererhitzern, Elektromotoren oder elektrischen
Schaltern, Öfen usw. in Berührung kommen können.
○Wenn dieses Gerät in trockenen Bereichen verwendet
wird, achten Sie darauf, dass eine Feuerlöschausrüstung
bereit steht.
○Wenn Sie den Motor zum Nachtanken abschalten,
lassen Sie das Gerät erst abkühlen, bevor Sie Kraftstoff
nachfüllen.
Schneidsicherheit
○Schneiden Sie keine anderen Materialien außer Gras
und Hecken.
○Inspizieren Sie vor jeder Verwendung den zu mähenden
Bereich.
Entfernen Sie Gegenstände, die hochgeschleudert
werden oder sich verfangen können.
Nicht in Bereichen mit Baumwurzeln oder Felsen
verwenden.
○Tragen Sie zum Schutz der Atemwege eine Aerosol-
Schutzmaske, wenn Sie Gras schneiden, auf dem
Insektenvernichtungsmittel versprüht wurde.
○Halten Sie andere Personen einschließlich Kinder,
Zuschauer und Helfer außerhalb der 15 m Gefahrenzone.
Den Motor sofort abstellen, wenn sich jemand nähert.
○Seien Sie vorsichtig, da der Motorstart nach dem Ziehen
des Startgriffs verzögert auftreten kann.
○Halten Sie den Motor immer auf Ihrer rechten
Körperseite.
○Halten Sie das Gerät/die Maschine mit beiden Händen
fest.
○Achten Sie auf sicheren Stand und Gleichgewicht. Nicht
zu weit vorbeugen.
Wenn Sie während der Arbeit das Gleichgewicht
verlieren, kann das zu einer Verletzung führen.
○Halten Sie alle Körperteile vom Schalldämpfer und der
Schneide-Ausrüstung entfernt, wenn der Motor läuft.
○Halten Sie die Schneide-Ausrüstung unterhalb Ihrer
Knie.
○Seien Sie besonders vorsichtig beim Betrieb in
Bereichen mit Elektrokabeln oder Gasleitungen.
○Verwenden Sie die Schneide-Ausrüstung nicht für
etwas anderes außer zum Schneiden von Gras oder
Hecken.Vermeiden Sie den Betrieb, wenn die Schneide-
Ausrüstung Wasser, wie Pfützen berühren oder sich in
die Erde eingraben könnte. Nichtbeachtung kann zu
Verletzungen oder Beschädigung des Geräts führen.
○Vermeiden Sie längeren Betrieb bei niedriger Drehzahl,
bei der die Vibrationen stark sind. Dadurch kann es zu
einem Motorschaden kommen.
○Beim Wechsel in einen anderen Arbeitsbereich oder
Inspektion, Einstellung oder Austausch der Schneide-
Ausrüstung, Zubehör, usw. des Geräts, achten Sie
darauf, dass die Maschine ausgeschaltet ist und alle
Schneide-Ausrüstungen gestoppt haben.
○Stellen Sie die Maschine niemals auf den Boden,
während sie läuft.
○Berühren Sie niemals die Schneide-Ausrüstung,
während sie sich dreht.
○Achten Sie immer darauf, dass der Motor ausgeschaltet
ist und die Schneide-Ausrüstung komplett gestoppt
ist, bevor Sie Schmutz oder Gras von der Schneide-
Ausrüstung entfernen.
○Führen Sie bei Arbeiten mit Motorgeräten immer einen
Verbandkasten mit.
000BookCG24ECP(S).indb20000BookCG24ECP(S).indb20 2019/01/169:37:102019/01/169:37:10
