Hiland Premium Series User manual

MODEL #YFP-51133D
Questions, problems, missing parts? Before returning to your retailer, call our
customer service department at 1-888-775-1330, 8a.m. - 4 p.m., PST, Monday - Friday.
ATTACH YOUR RECEIPT HERE
Serial Number Purchase Date
36" Slate Top
Wood Burning Firepit

Item Number: YFP-51133D
Product Name: 36"Slate Top Wood Burning Firepit
•This firepit isintended foroutdoor use only. Do not use onwooden decks.
WARNINGS:
•This firepit isintended to burn wood logs only. Donot burn coal, leaves, orother combustible
materials inthefirepit.
•Not for use bychildren. Keep children and pets away from thefirepit.
•The firepit ishot. Use with caution. Donot touch thehot firepit with bare hands.
•Never leave theburning firepit unattended, and always extinguish thefire completely before
leaving thefirepit.
•Do not use near flammable or combustible objects or materials.
•When thefirepit isinuse, thehandle onthemesh screen can reach extreme temperatures that can
cause serious injury toan unprotected hand. Use a poker oran appropriate heat resistant glove or
pad when handling.
•Check local fire regulations and municipal by-laws for safe use.
FIRE PIT PARTS LIST
No. PARTS Qty
A Lift handle 1
B Screen 1
C Triangular Air Vents 3
D Fire bowl 1
E Slate top 1
F Leg frame 4
G Leg 4
H Poker 1
HARDWARE LIST
NO. PARTS QTY
CC M6*12 Bolt 20
AA M6 Nut 1
BB M6*10 Bolt 6
Tools required: Screw driver (not included)
OWNER'S MANUAL

FIG 1 FIG 2
FIG 3 FIG 4

Assembly steps:
Step 1:Place the Tile top(E) upside down on a level flat surface. Then attach one leg(G) to
the tile top by using Bolt(CC). Do not tighten the bolt fully! The same step for the other
three legs.(See FIG 1)
Step 2:Connect one Leg frame(F) between two legs by using 4 Bolts(CC) tightened. Do not
tighten the bolts fully. The same step for the remaining leg frames. Lastly, tighten all the
bolts. (See FIG 2)
Step 3: Turn the assembled table top right side up,put Firebowl (D) onto the table, place
Log grate(C) into firebowl. (See FIG 3)
Step 4: Assemblethe Screen(B) by using Lift handle(A) and Nut(AA). Finally put the
screen on the firepit.
Your firepitisready for usenow! Enjoy!
