Mulrall™ 200
overhead li
Service Manual
Product No. 3130001
3EN250401 Rev. 18
ENGLISH

In this document, this warning symbol indicates that special care should be taken.
If instrucons are not followed there is a risk of serious injury to paent or caregiver.
Spare part statement
Liko AB will as manufacturer of staonary & mobile lis keep spare parts available
for 10 years aer the last manufacturing date of the product.
Spare parts are available in the spare parts list or in the Service Manual for each model of li.
Components (manufacturing parts) are not available aer last manufacturing date.
Repairs and maintenance may only be performed by personnel authorized by Hill-Rom
and using original Liko™ spare parts.
For informaon regarding Service and Maintenance educaon, contact your Hill-Rom representave.
For contact informaon please visit our website: www.hill-rom.com

Service Manual Multirall™ overhead lift • 3EN250401 Rev. 18 3 www.hillrom.com
Table of Contents
Mulrall™ 200 overhead li
Page
1.0 Technical Data
1.1 Dimensions .................................................... 5
1.2 Technical Data................................................ 5
 2.0 Troubleshoong............................................................. 6
 3.0 SparePartsPosions ..................................................... 7
4.0 Spare Parts List .............................................................. 8
 5.0 SparePartsAssemblyInformaon ............................... 10
6.0 PeriodicInspeconInformaon...................................13
 7.0 PrevenveMaintenance..............................................14
8.0 Product Changes...........................................................15

Service Manual Multirall™ overhead lift • 3EN250401 Rev. 18 4 www.hillrom.com
1.1 Dimensions Mulrall™ 200 overhead li
Mulrall is equipped with an SFS (Single Fault Safety) safety drum. This safety design provides protecon against uncontrolled
lowering. The li strap has a tenfold safety.
Component X1 (Murata CSTCC4M00G53) on PCBA contains a SVHC, Lead tanium zirconium oxide (Pb(Ti,Zr)O3), which
exceeds the limit according to REACH Regulaon.
Intermient
power:
Sound level:
Int. Op 10/90, acve operaon max
6 min.
62.2 dB(A)
Protecon class: IP 30 (li unit)
IP 43 (hand control)
Operang forces
of controls: Buon on hand control: 4.5 N
Buon on end cover: 4 N
Ambient
temperature:
Min. + 10°C - Max. + 40°C
(Min. 50° F - Max. 104° F)
Intended for indoor use.
Type B, in accordance with the electrical shock protecon
class.
Class II equipment.
Maximum load: 200 kg (440 lbs)
Baeries: 2 X 12 V DC, (2.4 Ah - 2.6 Ah), Valve-regulated
lead-acid gel-type baeries. New baeries are
provided by Liko.
Baery charger: SMP CC-10-43-24; 100-240 V AC,
40-60 Hz, max 600 m A
Liing speed: 60 mm/s (2.3 in/s)
Liing interval: 1600 mm (63 in)
Electrical data: 24 V DC, 8.5 A
Li motor weight: 8.7 kg (19 lbs)
Emergency
lowering device: Mechanical and electrical
1.2 Technical Data Mulrall™200overheadli
Overhead
view
Lateral view
CSP (Central Suspension Point)
* Min. distance from ceiling to CSP at max. liing height.
** Installaon dimensions: the distance between the aachment point for the li unit on the carriage and the CSP at max. liing height.
*** Liing interval: the distance between max. liing height and min. liing height measured in CSP.
Measurements in mm.
C
A
B
H**
D*
L***
A B CD* H** L***
264 295 210 443 308 1600
Ceiling
A B CD* H** L***
10.4 11.6 8.3 17.4 12.1 63.0
Measurements in inch.

Service Manual Multirall™ overhead lift • 3EN250401 Rev. 18 5 www.hillrom.com
2.0 Troubleshoong, Mulrall™ 200 overhead li
The li doesn’t work. 1. Check that the Emergency Stop buon is not
acvated.
2. Check that the baery is charged. If the
baery does not charge check charger
voltage.
3. Check that the hand control is correctly
connected. If connected, check the hoist
switches for operaon.
4. If the li sll does not work sasfactorily,
please contact Hill-Rom.
The li emits a repeated sound or
light signal.
1. Charge the baery immediately.
2. If the li sll does not work sasfactorily,
please contact Hill-Rom.
The li is stuck in the
high posion.
1. Check that the Emergency Stop buon is not
acvated.
2. Check that the baery is charged. If the
baery does not charge check charger
voltage.
3. Check that the hand control is correctly
connected. If connected, check the hoist
switches for operaon.
4. Try to lower the li; the limit switch might
be engaged.
5. Use indicated electrical or mechanical
emergency lowering to lower the paent
onto a rm surface.
6. If the li sll does not work sasfactorily,
please contact Hill-Rom.
You hear unusual sounds. Contact Hill-Rom.

Service Manual Multirall™ overhead lift • 3EN250401 Rev. 18 6 www.hillrom.com
3.0 Spare Parts posions
3130001 Mulrall ™ 200 overhead li
87
164
165
529
90 187
264 311
367
365 366
415
130
494
499
555 556
564
Spare Parts List • Liko™ Overhead Lifts 3EN800803 Rev. 3 26 www.hill-rom.com lwww.liko.com
Spare Parts Posions
PROD. NO. PRODUCT
565
3130001 Mulrall ™ 200 overhead li
87
164
165
529
90 187
264 311
367
365 366
415
130
494
499
555 556
564
Spare Parts List • Liko™ Overhead Lifts 3EN800803 Rev. 3 26 www.hill-rom.com lwww.liko.com
Spare Parts Posions
PROD. NO. PRODUCT
565
Prod. No. Product
3130001 MulrallTM 200 overhead li
529
165
367
499
164
187
90
494
415
365 366
566
564
565

Service Manual Multirall™ overhead lift • 3EN250401 Rev. 18 7 www.hillrom.com
5.0 Spare Parts List
Mulrall ™ 200 overhead li
31190018 87 Latch pair 3EN640271
31290007 90 Baery 2,4-2,6 Ah/12 V pair 3SE630239
3106004 130 Parking Bracket
Fits Instrucon Placard Mulrall,
3136003
pce -
31390004 164 Cable for Hand control with Conn.
Plug
pce 3SE640231
31390005 165 Cover complete MR pce 3SE640232
31390006 187 Baery Cushions MR set 3SE640233
31590011 264 Latch universal pair 3SE630229
31590014 311 Latch, composite
Fits Universal SlingBar from S/N
1299511
pair 3SE640242
31390008 365 Contact Lock washer st 3SE650230
21090026 366 Special tool for Lock washer st -
31390009 367 Fuse 10A, 10pce set 3SE650231
21090061 415 Key pad Hand Control 2-buons
(Replaces Spare Part No. 21090060
and 21090038)
pce 3EN650261
Spare Parts List • Liko™ Overhead Lifts 3EN800803 Rev. 6 24 www.hillrom.com
PROD. NO. POS. NO. NAME UNIT ASSEMBLY INSTR.

Service Manual Multirall™ overhead lift • 3EN250401 Rev. 18 8 www.hillrom.com
5.0 Spare Parts List
31290091 494 Cable grommet, 10 pce set 3SE690214
31390010 499 Electronic Card ll MR pce 3SE690219
31390014 529 Li Strap Mulrall
(including Liming switch)
pce 3SE670220
31390013 555 Extension Arm Mulrall
Fits Carriage S65, Prod. No. 3136011
pce 3EN690245
31390012 556 Helping Hand Mulrall
Fits Carriage S50, Prod. No. 3136010
pce 3EN690244
3136010 564 Carriage S50, MR pce -
31590027 573 Q-Link II pce 3EN690292
3126020 578 Carriage adapter Mulrall for S65 pce 3EN680109
3136015 576 Carriage hook for MR/LR pce 3EN680069
Mulrall ™ 200 overhead li
Spare Parts List • Liko™ Overhead Lifts 3EN800803 Rev. 6 25 www.hillrom.com
PROD. NO. POS. NO. NAME UNIT ASSEMBLY INSTR.

Service Manual Multirall™ overhead lift • 3EN250401 Rev. 18 9 www.hillrom.com
5.0 Spare Parts List
3136016 577 Adapter MR/LR
Fits Carriage hook for MR/LR, Prod.
No. 3136015
pce -
Mulrall ™ 200 overhead li
Spare Parts List • Liko™ Overhead Lifts 3EN800803 Rev. 6 26 www.hillrom.com
PROD. NO. POS. NO. NAME UNIT ASSEMBLY INSTR.

Service Manual Multirall™ overhead lift • 3EN250401 Rev. 18 10 www.hillrom.com
4.0 Spare Parts Assembly Informaon
Assembly Instrucons to Liko™ spare parts are aached with the products.
The assembly instrucons are also available in Agile and on the Partner Web.
Document number to spare parts assembly instrucons can be found in the spare parts list.
Liko technical documentaon can be found on the Partnerweb:
hps://partner.liko.com
“My informaon” - “Documents”
If you don’t have access, send a mail for registraon to: se.customer.ser[email protected]
NOTE
- Always make sure the spare part is mounted according to the assembly instrucon.
- Mandatory: Check all funcons related to the changed spare part according to the assembly instrucon.
- Repairs and maintenance may only be performed by personnel authorized by Hill-Rom
and using original Liko™ spare parts.
Key pad hand control 2-buons
Assembly Instrucon
Product No. 21090061
3EN650261 Rev. 3
ENGLISH
Tools required:
Contains: Qty:
Key pad hand control 2-buons 1
Fits: Prod No. Up to S/N:
HandControl LR 2 buttons 3126031 231 002 414
Handcontrol LR with extralong cable 3126033 233 000 133
HandControl LR S, ES, 2 buttons 3126034 234 020 350
Handkontroll MR 3136001 201 002 904
(Fits only to hand controls up to these S/N. They are without Rev. No.)
www.hill-rom.com lwww.liko.com
NOTE
- Make sure the spare part is mounted according to the assembly instrucon.
- Check all funcons related to the changed spare part.
- Repairs and maintenance may only be performed by personnel authorized by Hill-Rom and using original Liko™ spare parts.
© Copyright Liko R&D AB 2016
Press the plug
Ensure that the cable
gland is located in the
intended track
Remove the tape protection
Remove the old Key pad by
carefully using a sharp tool.
Document Number
INFORMATION

Service Manual Multirall™ overhead lift • 3EN250401 Rev. 18 11 www.hillrom.com
Carriage Adapter MR for S65
Assembly Instructions
Product No. 3126020
3EN680109 Rev. 1
ENGLISH
©2019 Liko R&D AB. All rights reserved.
www.hill-rom.com l www.liko.com
Tools Required:
For safety reasons, it is essential that this component is correctly
fitted to the lift according to these instructions.
This symbol indicates a warning.
Important!
Installing the Carriage Adapter MR for S65:
1. Slide the adapter onto the lift mounting bracket.
2. Place the adapter in the center of the mounting bracket and affix with the accompanying M6 screws (4) and
accompanying 10 mm x 16. 5 mm threaded pins (2). Stabilize the screws on one side using one T30 driver,
while attaching the screws and pins on the opposite side with the other T30 driver. The recommended bolt
torque is 4 N-m (35 in-lbs). Make sure the screws are entirely inserted when tightened. See the illustrations
below.
Front View Side View
Center line
Contains: Part No. Qty:
Carriage Adapter MR for S65 1
Threaded Bushing 901435271 2
M6 Fasteners 930000483 4
Fits:
MultirallTM overhead lift (all models)

Service Manual Multirall™ overhead lift • 3EN250401 Rev. 18 12 www.hillrom.com
©2019 Liko R&D AB. All rights reserved.
3EN680109 Rev. 1
ENGLISH
www.hill-rom.com l www.liko.com
Mounting and Dismounting the Lift Unit with Attached Carriage Adapter MR for S65:
Mounting: Follow the steps below to attach the lift assembly to the S65 carriage hook.
Safety critical assembly!
Dismounting: Follow the steps below to remove the lift assembly from the S65 carriage hook.
NOTE
• Make sure the adapter is attached according to the instructions.
• Check all functions related to the adapter.
• Make sure when mounting the carriage that it is resting securely in the S65 hook and is not angled or leaning to one
side.
• Repairs and maintenance may only be performed by personnel authorized by Hill-Rom and using original LikoTM spare
parts.
Make sure the rolling pin on the
adapter is resting straightly and
securely at the bottom of the
S65 carriage hook!

Service Manual Multirall™ overhead lift • 3EN250401 Rev. 18 13 www.hillrom.com
6.0 Periodic Inspecon Informaon, Mulrall™ 200 overhead li
According to ISO 10535:2006 Annex B, Periodic Inspecon of medical device Liko™ overhead li should be
performed at least once a year. For Liko™ overhead lis Periodic Inspecon Liko overhead lis
(3EN191001) is available on the Partner Web (and internally in Agile).
Liko™ overhead lis must be thoroughly inspected at least once per year. Inspecon and service must be carried out by Hill-Rom authorized personnel.
If the li is installed in a corrosive environment such as indoor pool or bathroom, see inspecon point 11 before starng inspecon.
NOTE! For inspecon of the rail system, use Periodic Inspecon Liko™ Rail System (3EN111001)
If printed: Make a colour print of this instrucon.
Periodic Inspecon
Liko™ overhead lis
3EN191001 Rev. 2
Valid for following overhead lifts: LikoGuard™, Likorall™, Multirall™, Masterlift™
Li informaon Customer reference
Li: Agreement No:
Product Number: Name:
Serial Number: Address:
Producon year: Post Code
Inspecon sign o
Complete inspecon according to Instrucons for the check points (page 2-8), ll in this page and sign below.
Approval to use the overhead li Approved Not approved
If the overhead li has one or more inspecon points “Not approved”, the li must not be used.
Acon required: Acons according to the inspecon items "NOT APPROVED" should be performed immediately. Aer performed acons
sign below. If anything is unclear or if you have quesons, please contact Hill-Rom or your local Hill-Rom representave.
Contact informaon is to be found at www.hill-rom.com.
Inspecon performed by: Date:
Next inspecon:
Inspecon performed in accordance with ISO 10535:2006 Annex B- Periodic inspecon
OVERHEAD LIFT
Acon required:
Approved Not
approved
1 Product Decal
2 General Inspecon
3 Carriages
4Hand Control
5Emergency Stop
6Emergency Lowering
7Limit Switch
(Not valid for MasterLi)
8 Charger
(Not valid for MasterLi)
9 SlingBar
10 Li Strap
ENVIRONMENTAL IMPACT N/A
Acon required:
Approved Not
approved
11 Corrosive environments
LOAD TESTING
Max Load applied:
Approved Not
approved
12 Maximum Load overhead li Kg: Lbs:
Emergency lowering Maximum Load Kg: Lbs:
Required Measurements:
Measured dimensions:
Approved Not
approved
12 Load tesng / Li strap dri mm: Inch:
Clear service N/A
Acon required:
Approved Not
approved
13 Service Symbol reset
Liko technical documentaon can be found on the Partnerweb:
hps://partner.liko.com - “My informaon” - “Documents”
If you don’t have access, send a mail for registraon to: se.customer.ser[email protected]
Periodic Inspecon may only be performed by personnel authorized by Hill-Rom and using
original Liko™ spare parts.
Available Liko Periodic Inspecons:
• 3EN371001PeriodicInspeconLikoMobilelis
• 3EN111001PeriodicInspeconLikoOHRailsystem
• 3EN191001PeriodicInspeconOverheadLis
• 3EN301001 PI FreespanTM Freestand
• 3EN601001PeriodicInspeconLikoaccessories
Also available is Periodic Inspecon Slings. This inspecon should be performed by a person who is
suitable, has good experience and sucient knowledge about design, use and maintenance of the sling.
• 7EN160834GeneralPeriodicInspeconProtocolLikoSlingsandSabinaSupportVests
NOTE!
Periodic Inspecon shall be performed at least once per year.
INFORMATION

Service Manual Multirall™ overhead lift • 3EN250401 Rev. 18 14 www.hillrom.com
7.0 Prevenve Maintenance, Mulrall™ 200 overhead li
Part Part No. Replacement
interval:
Replacement:
Hand Control 3136001 2 years Can be used more than 2 years if no malfuncon is detected.
Baery 31290007 3 years Can be used more than 3 years if no malfuncon is detected.
Li Strap 31390014 5 years Must be replaced aer 5 years of use, or if wear and tear are detected.
Expected Life Time
Normal use is dened as 8-12 normal lis/day
Year
Mulrall™ 200 overhead li 10
Expected Life Time
The expected life me of a Mulrall™ overhead li is 10 years of normal use provided that required
Periodic Inspecon and Prevenve Maintenance is performed by personnel authorized by Hill-Rom
and using original Liko™ spare parts.
However certain parts have a shorter life cycle and will need to be replaced in order for the overhead li
to meet its expected life me. They are listed below:
Parts that needs to be replaced:

Service Manual Multirall™ overhead lift • 3EN250401 Rev. 18 15 www.hillrom.com
8.0 Product Changes, Mulrall™ 200 overhead li
Changes From S/N Project
Prod. No. 3130001
2017
Inial release of new Mulrall rail aachment system.
New Mulrall Carriage, Helping Hand and Adapter created.
3136015, Carriage Hook for MR/LR (replacing obsoleted 3136011, S65 Carriage)
3136016, Carriage adapter
3136040, Extension Arm Adapter with new strap lock holder.
New spare parts:
3136010, Carriage S50 MR
31390012, Helping Hand Mulrall. New spare part, increased length of extension tube.
(replacing obsoleted 3136006)
31390013, Extension Arm Mulrall. New spare part, increased length of extension tube.
(replacing obsoleted 3136004)
-SUS001865
SUS002097
2019
Changes Type Prod. No. Rev. From S/N Proj.
The Q-link changed to the Q-link II Mulrall 3130001 3 6511785 PRJ01055
New listrap with Q-link II
31390014 is replacing 31390011
LiStap Mulrall 31390014 - - PRJ01055
The S65 carriage with Single Hook has been reintroduced
The Carriage adapter MR for S65 has been introduced
Mulrall 3136011
3126020
2
-
-
-
PRJ01055
2021
Changes Type Prod. No. Rev. From S/N Proj.
Q-link 31590005 removed as spare part to Mulrall.
Replaced by Q-link II 31590027.
MOD1322
Improved design of hook R2R. The new design of hook R2R
is idened with an added label “R2R II” and is backwards
compable and work on both Q-link II and old Q-link.
Univ SlingBar 450 R2R
Univ SlingBar 350 R2R
Carriage D45 with
double hook
Hook R2R
3156095
3156094
3136100
31290056
2
2
2
-
1210645
1210645
-
From January
2021
SUS003769
Multirall
Multirall
Multirall
Multirall
Multirall
Multirall

Service Manual Multirall™ overhead lift • 3EN250401 Rev. 18 16 www.hillrom.com
© Liko R&D AB 2019. All rights reserved.
8.0 Product Changes, Mulrall™ 200 overhead li
Prod. No. 3130001
Changes From S/N Project
2013
The li straps has been modied. New type of seam and new
treaded bolt.
The Li Strap Spare Part has got new spare part number:
3139011 LiStrap Mulrall.
6 506 400 1799
2011
New version of the electronic card. 6 505 000 1220
2009
New version of emergency stop -962
New version of liming prole. 6 503 288
New Hand control hanger introduces. 6 503 150
2008
Contact lock washer and Hand control hanger introduces.
New decals.
6 502 936 523
2005
Twist protecon plate introduces .
Hang-up is added.
6 501 823
6 501 619 183
2003
New distributor of the electronic card.
New Li strap joint.
New screws (M4x145, M6x180 and MC6S M6x70).
Tape 25x25 for the baeries.
New S/N decal.
6 501 077
6 500 859
6 500 829
6 500 763
6 500 753
-
2002
New electronic card Version V9.6.
New version of Liming switch. Cover is also new.
New version of quick release hook (TDM), ts carriage with. extension
belt.
6 500 591
6 500 505
6 500 503
-
2001
New electronic card and cover.
Four schims 15x22x0,3 mounted on axis 15x202.
6 500 332
6 500 026
-
