Hilti DD 30-W User manual

DD 30-W
English
Printed: 06.07.2017 | Doc-Nr: PUB / 5283534 / 000 / 05

Printed: 06.07.2017 | Doc-Nr: PUB / 5283534 / 000 / 05

English 1
1 Information about the documentation
1.1 About this documentation
• Read this documentation before initial operation or use. This is a prerequisite for safe, trouble-free
handling and use of the product.
• Observe the safety instructions and warnings in this documentation and on the product.
• Always keep the operating instructions with the product and make sure that the operating instructions
are with the product when it is given to other persons.
1.2 Explanation of signs used
1.2.1 Warnings
Warnings alert persons to hazards that occur when handling or using the product. The following signal words
are used in combination with a symbol:
DANGER! Draws attention to imminent danger that will lead to serious personal injury or fatality.
WARNING! Draws attention to a potential hazard that could lead to serious personal injury or
fatality.
CAUTION! Draws attention to a potentially dangerous situation that could lead to minor personal
injury or damage to the equipment or other property.
1.2.2 Symbols in the documentation
The following symbols are used in this document:
Read the operating instructions before use
Instructions for use and other useful information
1.2.3 Symbols in the illustrations
The following symbols are used in illustrations:
These numbers refer to the corresponding illustrations found at the beginning of these operating
instructions.
The numbering reflects the sequence of operations shown in the illustrations and may deviate
from the steps described in the text.
Item reference numbers are used in the overview illustrations and refer to the numbers used in
the product overview section.
These characters are intended to specifically draw your attention to certain points when handling
the product.
1.3 Product-dependent symbols
1.3.1 Symbols on the product
The following symbols are used on the product:
Warning: hazardous electrical voltage
Warning: hot surface
Revolutions per minute
Rated speed under no load
Wear eye protection
Wear a hard hat
Printed: 06.07.2017 | Doc-Nr: PUB / 5283534 / 000 / 05

2 English
Wear ear protection
Wear protective gloves
Wear safety shoes.
Lock symbol
Service indicator
Drilling performance indicator
1.4 Product information
Hilti products are designed for professional use and may be operated, serviced and maintained only by
trained, authorized personnel. This personnel must be informed of any particular hazards that may be
encountered. The product and its ancillary equipment can present hazards if used incorrectly by untrained
personnel or if used not in accordance with the intended use.
The type designation and serial number are stated on the rating plate.
▶Write down the serial number in the table below. You will be required to state the product details when
contacting Hilti Service or your local Hilti organization to inquire about the product.
Product information
Type: DD 30-W
Generation: 01
Serial no.:
1.5 Declaration of conformity
We declare, on our sole responsibility, that the product described here complies with the applicable directives
and standards. A copy of the declaration of conformity can be found at the end of this documentation.
The technical documentation is filed and stored here:
Hilti Entwicklungsgesellschaft mbH | Tool Certification | Hiltistrasse 6 | 86916 Kaufering, Germany
2 Safety
2.1 General power tool safety warnings
WARNING
Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated
(cordless) power tool.
Work area safety
▶Keep work area clean and well lit. Cluttered or dark areas invite accidents.
▶Do not operate power tools in explosive atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
▶Keep children and bystanders away while operating a power tool. Distractions can cause you to lose
control.
Electrical safety
▶Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of
electric shock.
▶Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
▶Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the
risk of electric shock.
Printed: 06.07.2017 | Doc-Nr: PUB / 5283534 / 000 / 05

English 3
▶Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the
risk of electric shock.
▶When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric shock.
▶If operating a power tool in a damp location is unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of electric shock.
Personal safety
▶Stay alert, watch what you are doing and use common sense when operating a power tool. Do
not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A
moment of inattention while operating power tools may result in serious personal injury.
▶Use personal protective equipment. Always wear eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
▶Prevent unintentional starting. Ensure the switch is in the off‐position before connecting to power
source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on
the switch or energising power tools that have the switch on invites accidents.
▶Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
▶Do not overreach. Keep proper footing and balance at all times. This enables better control of the
power tool in unexpected situations.
▶Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
▶If devices are provided for the connection of dust extraction and collection facilities, ensure these
are connected and properly used. Use of dust collection can reduce dust-related hazards.
Power tool use and care
▶Do not force the power tool. Use the correct power tool for your application. The correct power tool will
do the job better and safer at the rate for which it was designed.
▶Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
▶Disconnect the plug from the power source and/or the battery pack from the power tool before
making any adjustments, changing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
▶Store idle power tools out of the reach of children and do not allow persons unfamiliar with the
power tool or these instructions to operate the power tool. Power tools are dangerous in the hands
of untrained users.
▶Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and
any other condition that may affect the power tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by poorly maintained power tools.
▶Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
▶Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking
into account the working conditions and the work to be performed. Use of the power tool for
operations different from those intended could result in a hazardous situation.
Service
▶Have your power tool serviced by a qualified repair person using only identical replacement parts.
This will ensure that the safety of the power tool is maintained.
2.2 Drill safety warnings
▶Use auxiliary handle(s), if supplied with the tool. Loss of control can cause personal injury.
▶Hold power tool by insulated gripping surfaces, when performing an operation where the cutting
accessory may contact hidden wiring or its own cord. Cutting accessory contacting a "live" wire may
make exposed metal parts of the power tool "live" and could give the operator an electric shock.
2.3 Additional safety instructions
Personal safety
▶During hand-held use, always hold the machine securely with both hands on the grips provided.
▶The machine and the diamond core bit are heavy. There is a risk of crushing parts of the body. Wear
a hard hat, protective gloves and safety footwear.
Printed: 06.07.2017 | Doc-Nr: PUB / 5283534 / 000 / 05

4 English
▶Keep the grips dry, clean and free from oil and grease.
▶Improve the blood circulation in your fingers by relaxing your hands and exercising your fingers
during breaks between working.
▶Avoid touching rotating parts. Switch the machine on only after bringing it into position at the
workpiece. Touching rotating parts, especially rotating accessory tools, may lead to injury.
▶Always lead the supply cord, the extension cord and, if applicable, the suction hose away from the
machine to the rear when working. This helps to avoid tripping over the cord or hose while working.
▶Do not allow drilling slurry to come into contact with the skin or eyes. Wear protective gloves and
protective glasses.
▶Children are not permitted to play with the machine and must be instructed accordingly.
▶The machine is not intended for use by debilitated persons who have received no special training.
Keep the machine out of reach of children.
▶The accessory tool may become hot during use or during sharpening. There is a risk of burning or
cutting injuries. Wear protective gloves when touching or handling the accessory tool.
▶When the machine is mounted on the drill stand, lay it down safely on the floor or ground during
breaks between use.
▶Never tamper with or modify the machine in any way.
Protection from dust
Dust from material such as paint containing lead, some wood species, minerals and metal may be harmful.
Contact with or inhalation of the dust may cause allergic reactions and/or respiratory diseases to the operator
or bystanders. Certain kinds of dust are classified as carcinogenic such as oak and beech dust especially
in conjunction with additives for wood conditioning (chromate, wood preservative). Material containing
asbestos may be worked on only by specialists.
▶Use a dust removal system that is as effective as possible. To achieve a high level of dust
collection, use a suitable vacuum cleaner of the type recommended by Hilti for wood dust and/or
mineral dust and which is designed for use with this machine. Ensure that the workplace is well
ventilated. The use of a dust mask of filter class P2 is recommended. Follow national requirements
for the materials you want to work with.
Careful handling and use of electric tools and machines
▶Secure the workpiece. Use clamps or a vice to secure the workpiece. The workpiece is thus held
more securely than by hand and both hands remain free to operate the machine.
▶Ensure that the accessory tools used have a mounting system that is compatible with the drilling
machine and that they are secured in the chuck correctly.
▶Switch the machine off and unplug the supply cord in the event of an interruption in the electric
supply in order to avoid inadvertent restarting when the power returns.
▶Operate the machine only when the cooling air slots are unobstructed.
Electrical safety
▶Before beginning the work, check the working area for concealed electrical cables, gas and water
pipes, e.g. using a metal detector. External metal parts of the machine may become live, for example,
when an electric cable is damaged accidentally. This presents a serious risk of electric shock.
▶Never operate the machine without the accompanying PRCD (machines without PRCD: Never
operate the machine without an isolating transformer). Test the PRCD each time before use.
▶Check the machine’s supply cord at regular intervals and have it replaced by a qualified specialist
if found to be damaged. If the machine’s supply cord is damaged it must be replaced with
a specially-prepared and approved supply cord available from Hilti Customer Service. Check
extension cords at regular intervals and replace them if found to be damaged. Do not touch the
supply cord or extension cord if it is damaged while working. Disconnect the supply cord plug
from the power outlet. Damaged supply cords or extension cords present a risk of electric shock.
▶Avoid body contact with earthed or grounded surfaces such as pipes, radiators, cookers, stoves
and refrigerators. There is an increased risk of electric shock if your body is grounded.
▶Do not use a plug adapter.
Workplace
▶Ensure that the workplace is well ventilated. Exposure to dust at a poorly ventilated workplace may
result in damage to the health.
▶Do not drill into hazardous materials (e.g. asbestos).
▶Approval must be obtained from the site engineer or architect prior to beginning drilling work.
Drilling work on buildings and other structures may influence the static equilibrium of the structure,
especially when steel reinforcing bars or load-bearing components are cut through.
▶It is recommended that rubber gloves and non-skid shoes are worn when working outdoors.
Printed: 06.07.2017 | Doc-Nr: PUB / 5283534 / 000 / 05

English 5
▶Suitable protective glasses, a hard hat, ear protection, protective gloves and safety footwear must
be worn while the machine is in use. Other persons in the vicinity must also wear personal protective
equipment.
3 Description
3.1 Overview of the product
@Chuck
;Side handle DD-SH-30
=Chuck locking lever
%Water flow rate indicator
&Water regulating lever
(Switch lockbutton for operation on drill
stand
)Circular bubble level for vertical drilling
+On/off switch
§Grip
/Tubular bubble level for horizontal drilling
Printed: 06.07.2017 | Doc-Nr: PUB / 5283534 / 000 / 05

6 English
:Supply cord with PRCD
∙Water connection
$Carbon brush cover
£Suction hose holder
|Depth gauge for hand-guided drilling
¡Service indicator
QDrilling performance indicator
3.2 Ground fault circuit interrupter (PRCD)
WPRCD in the supply cord
ELED on the PRCD
RReset button on the PRCD
TTEST button on the PRCD
3.3 Water collection system
ZSlider for longitudinal adjustment of the
water collector holder
UWater collector holder release catch
IWater collector holder
Printed: 06.07.2017 | Doc-Nr: PUB / 5283534 / 000 / 05

English 7
3.4 Accessories
OCentering ring
PWater collector
ÜWater collector hose
[Spray guard
3.5 DD-ST 30 drill stand accessories
]End stop screw
ÆColumn
ºClamping piece
~Locking screw
ARetaining pin
SHand wheel
DCarriage
FCarriage lock
GGrip
HClamping lever
JVacuum hose connector
KPressure gauge
LVacuum seal
ÖAdapter plate
Printed: 06.07.2017 | Doc-Nr: PUB / 5283534 / 000 / 05

8 English
ÄVacuum base plate
†Leveling screws
ŒVacuum release valve
3.6 Intended use
The product described is an electrically powered diamond core drilling system. It is designed to be used hand-
held or mounted on a drill stand, for wet drilling in concrete and other mineral materials. The drill stand can
be fastened to the working surface by a suitable anchor (accessory) or by the vacuum base plate (accessory).
▶Connect the machine only to an electric supply providing the voltage and frequency specified on the type
identification / rating plate.
▶Depending on the application and drilling direction (see following table → page 8), the diamond core
drilling machine’s water collection system must be connected to an all-purpose vacuum cleaner of a type
recommended by Hilti and the necessary additional equipment selected accordingly.
Product sticker
The water collection system and the correct combination
of core bit and sealing ring, with the correct length set-
ting, must be fitted and used for all drilling applications.
Product sticker
Drilling in an upwards direction is permissible only when
the water collection system and additional spray guard
are used.
Drilling in an upwards direction using the drill stand is
not permissible as the spray guard cannot be fitted when
the machine is mounted on the drill stand.
3.7 Inadmissible misuse
• This product is not suitable for working on hazardous materials.
• Drilling into materials that produce electrically conductive dust (e.g. magnesium) is not permissible.
• Dry drilling is not permissible.
3.8 Application-specific equipment
Equipment required for various applications / drilling directions
Application Drilling
direction
Equipment
Hand-held use Horizontal and
in a downwards
direction
With/without vacuum cleaner, without
spray guard
Hand-held use In an upwards
direction
With vacuum cleaner and spray guard
Mounted on a drill stand, fastened with
the vacuum base plate
Downwards With/without vacuum cleaner, without
spray guard
Mounted on the drill stand, fastened with
the vacuum base plate
Horizontal With/without vacuum cleaner, without
spray guard and with the drill stand
secured additionally
Mounted on the drill stand, fastened with
an anchor
Downwards
and horizontal
With/without vacuum cleaner, without
spray guard
Printed: 06.07.2017 | Doc-Nr: PUB / 5283534 / 000 / 05

English 9
3.9 Service indicator
LED display / operating status Service status
Lights red / the machine runs. The carbon brushes are badly worn. When the indicator lights for
the first time the machine may continue to be used for several hours
until it switches itself off automatically. Have the carbon brushes
changed in good time so that the machine is always ready for use.
Lights red / the machine doesn’t
run.
Have the carbon brushes replaced.
Blinks red Temporary fault, see “Troubleshooting”
3.10 Drilling performance indicator
LED display Contact pressure
Orange Too low
Green Optimal
Red Too high
3.11 Speed settings
The machine has two speeds: low speed for starting holes and high speed for normal drilling.
When the control switch is pressed only half way, only the low-speed hole-starting mode is active. The
water flow rate should also be set while the machine is running at this speed. Maximum drilling speed for the
selected speed setting will be reached when the control switch is pressed in all the way.
3.12 Items supplied
machine with side handle, chuck and operating instructions
You can find other system products approved for use with your product at your local Hilti Center or online
at: www.hilti.group.
3.13 Accessory tools
Designation Designation
Diamond core bit DDC
Core breaking tool DDCB
3.14 Accessories
Designation Designation
Drill stand DDST 30
Core bits DD-C, 8 ‒ 35 mm diameter
Accessory set for fastening the drill stand with an
anchor
DD M12 S
Depth gauge for the drill stand DD-ST 30-ES
Spray guard DD-30-W-CV
4 Technical data
4.1 Diamond coring machine
Note
For details of the rated voltage, current, frequency and input power, please refer to the machine’s
country-specific type identification plate.
When powered by a generator or transformer, the generator or transformer’s power output must be at
least twice the rated input power shown on the rating plate of the machine. The operating voltage of the
transformer or generator must always be within +5% and -15% of the rated voltage of the machine.
Printed: 06.07.2017 | Doc-Nr: PUB / 5283534 / 000 / 05

10 English
Note
Switching other power tools, machines or appliances on and off may cause undervoltage and / or
overvoltage peaks, resulting in damage to the machine or appliance. Never operate other power tools,
machines or appliances from the generator or transformer at the same time.
Weight in accordance with EPTA procedure 01 7.6 kg
Dimensions (L x W x H) 441 mm x 191 mm x 120 mm
Core bit diameter 8 mm …35 mm
Protection class I
Rated speed under no load 8,700 /min
4.2 Rated voltage
The machine is available in various voltage ratings. Please refer to the machine’s type identification plate for
details of its rated voltage and rated input power.
Rated voltage
Rated voltage 100 V 110 V 220 V 220240 V
Mains frequency [Hz] 50/60 50/60 50/60 50/60
Rated power [W] 1450 1400 1400 1450
4.3 Noise and vibration values
The vibration emission level given in this information sheet has been measured in accordance with a
standardized test given in EN 60745 and may be used to compare one electric machine with another. It may
be used for a preliminary assessment of exposure.
The declared vibration level represents the main applications of the machine. However, if the machine is
used for different applications, with different accessory tools or is poorly maintained, the vibration level may
vary. This may significantly increase the exposure to vibration over the total working period.
An accurate estimation of exposure to vibration should also take into account the times when the machine
is switched off, or when it is running but not actually being used for a job. This may significantly reduce the
exposure to vibration over the total working period.
Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the
machine and accessory tools, keep the hands warm, organization of work patterns.
Noise emission values in accordance with EN 60745-2-1
Emission sound pressure level LpA 87 dB(A)
Uncertainty for the sound pressure level KpA 3 dB(A)
Sound power level LWA 98 dB(A)
Uncertainty for the sound power level KWA 3 dB(A)
Total vibration in accordance with EN 60745-2-1
Vibration emission value for hand-guided drilling (with DD-C-
18/150 T4 core bit) in concrete ah, DD
6.0 m/s²
Uncertainty for hand-guided drilling in concrete K 1.5 m/s²
Vibration emission value for hand-guided drilling (with DD-C-
24/300 T4 core bit) in concrete ah, DD
8.0 m/s²
Uncertainty for hand-guided drilling in concrete K 1.5 m/s²
Total vibration in accordance with EN 62841-3-6
Vibration emission value for drilling with the machine on the drill
stand (with DD-C-18/150 T4 core bit) in concrete ah, DD
5.0 m/s²
Uncertainty for drilling in concrete using the drill stand K 1.5 m/s²
Vibration emission value for drilling with the machine on the drill
stand (with DD-C-24/300 T4 core bit) in concrete ah, DD
6.5 m/s²
Uncertainty for drilling in concrete using the drill stand K 1.5 m/s²
Printed: 06.07.2017 | Doc-Nr: PUB / 5283534 / 000 / 05

English 11
5 Preparations at the workplace
5.1 Before you begin
▶The machine should remain disconnected from the electric supply while it is being set up or prepared for
use.
WARNING
Drilling presents a possible risk of structural damage to the building. Drilling work on buildings
and other structures may influence the statics of the structure, especially when steel reinforcing bars
or load-bearing components are cut through.
▶Approval must be obtained from the site engineer or architect prior to beginning drilling work.
WARNING
Danger of electric shock! Drilling inadvertently into electric cables or gas and water pipes presents
a risk of accident. Exterior metal parts of the drilling system may become live if an electric cable is
contacted while drilling.
▶Use a metal detector, for example, to check for electric cables or gas and water pipes in the
working area before beginning drilling.
▶Obtain permission from the structural engineer responsible before drilling through reinforcing bars.
▶Check that the electric supply voltage complies with the details given on the type identification plate.
▶Disconnect the supply cord plug from the power outlet before relocating the machine, e.g. before moving
the machine to the next drilling position.
▶Always position the supply cord and hoses so that they do not come into contact with rotating parts of
the equipment.
▶Do not lift the diamond core drilling machine and/or the drill stand by crane.
▶Before using a vacuum pump, make yourself familiar with the content of the operating instructions and
observe the directions given.
▶Make sure that the pointer on the pressure gauge remains within the green area while drilling is taking
place.
▶Check that the rim (cutting edge) of the core bit has a height of at least 2 mm. If this is not the case,
replace the core bit as it may otherwise get stuck in the hole drilled.
▶To avoid injury, use only genuine Hilti DD-C core bits and DD 30-W accessories.
5.2 Preparing the drilling machine for hand-held use
5.2.1 Positioning the side handle
1. Unplug the supply cord from the power outlet.
2. Release the side handle clamping band by turning the handle counterclockwise.
3. Secure the side handle in the desired position.
Note
A depth gauge can be fitted together with the side handle ( → page 12).
Printed: 06.07.2017 | Doc-Nr: PUB / 5283534 / 000 / 05

12 English
4. Fasten the side handle securely by turning the grip until tight.
5.2.2 Fitting the depth gauge
1. Unplug the supply cord from the power outlet.
2. Release the side handle clamping band by turning the handle counterclockwise.
3. Slide the depth gauge from the front into the opening provided in the side handle.
4. Set the depth gauge to the desired depth.
5. Secure the depth gauge by turning the grip of the side handle until tight.
5.2.3 Fitting the spray guard
WARNING
Risk of electric shock! If the machine is used for hand-guided drilling in an upwards direction without
the necessary safety precautions, water may enter the machine and present a risk of electric shock.
▶When carrying out hand-guided drilling in an upwards direction, always use a water collection
system with a wet/dry industrial vacuum cleaner and the spray guard.
1. Disconnect the supply cord plug from the power outlet.
2. Slide the spray guard over the chuck from the front and push it onto the gear housing on the drilling
machine.
5.2.4 Fitting the water collector holder
Note
Drilling is permissible only under the following conditions:
The supplied water collector holder is fitted and adjusted to match the length of the core bit used.
A core bit sealing ring that matches the diameter of the core bit must be fitted in the water collector
holder.
Printed: 06.07.2017 | Doc-Nr: PUB / 5283534 / 000 / 05

English 13
1. Unplug the supply cord from the power outlet.
2. Push the water collector holder into the opening provided at the front of the machine until it engages with
a click.
3. Use the slider to set the correct length range for the core bit used. Set the slider to the 150 position for
core bits with a length of up to 150 mm and set it to 300 for core bits with a length of 300 mm or 600 mm.
5.2.5 Fitting or replacing the sealing ring
WARNING
Danger of electric shock! Use of the wrong sealing ring when drilling overhead may cause water to
find its way into the interior of the diamond core drilling machine.
▶Always use a sealing ring of the same diameter as the core bit.
1. Disconnect the supply cord plug from the power outlet.
2. Fit the sealing ring into the groove in the water collector and push the sealing ring down until it is heard
to engage.
3. To remove the sealing ring, turn it counterclockwise and pull it up out of the water collector.
5.2.6 Fitting the core bit
WARNING
Risk of injury caused by flying fragments or debris. Use of cracked, broken or badly worn core bits
may result in flying fragments (parts of the workpiece or broken core bit) presenting a risk of injury to
the operator or bystanders, even outside the working area.
▶Check the core bit for cracks, breakage, heavy wear or other damage each time before use and
replace the core bit if necessary.
Printed: 06.07.2017 | Doc-Nr: PUB / 5283534 / 000 / 05

14 English
Note
Diamond core bits must be replaced when the cutting performance and/or rate of drilling progress
drops significantly. This generally is the case when the segments reach a height of less than 2 mm.
Note
Spraying the chuck with Hilti lubricant spray at regular intervals makes it easier to fit the core bit.
1. Unplug the supply cord from the power outlet.
2. Open the chuck by pulling the chuck locking lever upwards as far as it will go.
Note
Check that the core bit connection end and the chuck are clean and undamaged.
3. Tip the water collector about its mounting axis as far as it will go.
4. Guide the cutting edge of the core bit into the sealing ring in the water collector from above.
5. Align the connection end of the core bit with the corresponding openings and insert it into the chuck.
6. Turn the core bit as far as it will go while applying light pressure.
7. Secure the core bit by closing the chuck locking lever.
5.2.7 Connecting the vacuum removal system
1. Make sure that the suction hose from the all-purpose vacuum cleaner is securely connected to the core
drilling machine’s water collection hose. Use a hose adapter for this purpose.
2. Connect the all-purpose vacuum cleaner suction hose to the vacuum cleaner.
3. When drilling overhead, use the retaining clip on the side handle to secure the water collection hose.
5.3 Preparing to drill using the drill stand
WARNING
Risk of injury. The drill stand may tip over or rotate if inadequately fastened.
▶Before using the diamond coring machine, fasten the drill stand securely to the working surface
with an anchor or with a vacuum base plate.
▶Use only anchors of a type suitable for the applicable material and observe the installation
instructions issued by the anchor manufacturer.
▶Use a vacuum base plate only when the working surface is suitable for fastening the drill stand by
way of the vacuum fastening method.
The drill stand and the machine can be fastened either using the vacuum base plate or the DD M12 S
accessory set, i.e. using an HKD-D M12x50 anchor, the DD-LR-CLS clamping spindle and the DD-LR-CLN
nut.
Printed: 06.07.2017 | Doc-Nr: PUB / 5283534 / 000 / 05

English 15
WARNING
Water running out presents a risk of electric shock! The spray guard cannot be used when the
machine is mounted on the drill stand. The machine is therefore not protected against entry of water
when mounted on the drill stand.
▶Never drill in an upwards direction with the machine mounted on the drill stand!
Note
The side handle and spray guard (if fitted) must be removed before using the machine on the drill stand.
5.3.1 Fitting the water collector holder
Note
Drilling is permissible only under the following conditions:
The supplied water collector holder is fitted and adjusted to match the length of the core bit used.
A core bit sealing ring that matches the diameter of the core bit must be fitted in the water collector
holder.
1. Unplug the supply cord from the power outlet.
2. Push the water collector holder into the opening provided at the front of the machine until it engages with
a click.
3. Use the slider to set the correct length range for the core bit used. Set the slider to the 150 position for
core bits with a length of up to 150 mm and set it to 300 for core bits with a length of 300 mm or 600 mm.
5.3.2 Fastening the machine and drill stand with the vacuum base plate
WARNING
Risk of injury Hazard presented by a falling diamond core drilling machine.
▶When drilling horizontally, the drill stand must be secured additionally by a chain.
Printed: 06.07.2017 | Doc-Nr: PUB / 5283534 / 000 / 05

16 English
5.3.2.1 Positioning the vacuum base plate
1. Mark the center of the hole to be drilled with a cross. The lines of the cross should be longer than the
diameter of the water collector.
Note
The water collector has four protruding marks that can be aligned with the cross.
2. Turn the 4 leveling screws on the vacuum base plate until they project approx. 5 mm below the underside
of the vacuum base plate.
3. Position the vacuum base plate at a distance of 21 cm from the hole center.
4. Connect the vacuum connector on the vacuum base plate to the vacuum pump.
5. Switch on the vacuum pump.
6. Keep the vacuum release valve pressed in while correcting the position of the vacuum base plate.
5.3.2.2 Fastening the drill stand on the vacuum base plate
1. Switch on the vacuum pump.
2. Use the clamping spindle to fasten the drill stand on the vacuum base plate.
3. Level the drill stand by turning the two leveling screws.
5.3.3 Mounting the machine on the drill stand
Note
If vacuum fastening is used, check to ensure that the drill stand is securely fastened to the working
surface before mounting the machine on the drill stand.
Printed: 06.07.2017 | Doc-Nr: PUB / 5283534 / 000 / 05

English 17
1. Unplug the supply cord from the power outlet.
Printed: 06.07.2017 | Doc-Nr: PUB / 5283534 / 000 / 05

18 English
2. Lock the carriage on the drill stand at the maximum distance from the working surface.
Note
The carriage must be locked in the uppermost position. The machine with the water collector
holder can then be mounted on the drill stand without the water collector coming into contact with
the working surface.
3. Open the clamping piece by turning the locking bolt.
4. Fit the drilling machine onto the carriage.
5. Close the clamping piece by turning the locking bolt.
6. Make sure that the drilling machine is correctly fastened to the drill stand.
5.3.4 Fastening the machine and drill stand with an anchor
Note
Fastening the drill stand with an anchor requires use of the DD M12 S accessory set which, among
other items, includes the DD-LR-CLS anchor spindle and the DD-LR-CLN nut.
1. Mark the center of the hole to be drilled with a cross. The lines of the cross should be longer than the
diameter of the water collector.
Note
The water collector has four protruding marks that can be aligned with the cross.
2. Set the Hilti HKD-D M12x50 anchor for fastening the drill stand adapter plate at a distance of 12 cm
from the hole center mark.
Note
When setting the anchor, observe the instructions for use enclosed with the anchor.
3. Mount the machine on the drill stand. → page 16
4. Turn back the two leveling screws until they no longer project.
5. Place the drill stand, with the machine mounted on it, over the clamping spindle and then secure the drill
stand temporarily by screwing on the clamping nut (DD M12 S accessory set).
Note
Tighten the spindle securely only after the core bit has been positioned exactly over the center
point of the hole to be drilled ( → page 20).
6. Level the drill stand by turning the two leveling screws.
5.3.5 Fitting the hand wheel
Note
The hand wheel can be fitted on either side of the drill stand.
1. Fit the hand wheel onto the axle.
Printed: 06.07.2017 | Doc-Nr: PUB / 5283534 / 000 / 05
