Hilti SF 22-A User manual

SF 22-A
SFH 22-A English
Printed: 24.09.2018 | Doc-Nr: PUB / 5152424 / 000 / 05

Printed: 24.09.2018 | Doc-Nr: PUB / 5152424 / 000 / 05

SF 22-A
SFH 22-A
Original operating instructions
Printed: 24.09.2018 | Doc-Nr: PUB / 5152424 / 000 / 05

Printed: 24.09.2018 | Doc-Nr: PUB / 5152424 / 000 / 05

English 1
1 Information about the documentation
1.1 About this documentation
• Read this documentation before initial operation or use. This is a prerequisite for safe, trouble-free
handling and use of the product.
• Observe the safety instructions and warnings in this documentation and on the product.
• Always keep the operating instructions with the product and make sure that the operating instructions
are with the product when it is given to other persons.
1.2 Explanation of symbols used
1.2.1 Warnings
Warnings alert persons to hazards that occur when handling or using the product. The following signal words
are used:
DANGER
DANGER !
▶Draws attention to imminent danger that will lead to serious personal injury or fatality.
WARNING
WARNING !
▶Draws attention to a potential threat of danger that can lead to serious injury or fatality.
CAUTION
CAUTION !
▶Draws attention to a potentially dangerous situation that could lead to slight personal injury or damage
to the equipment or other property.
1.2.2 Symbols in the documentation
The following symbols are used in this document:
Read the operating instructions before use.
Instructions for use and other useful information
Dealing with recyclable materials
Do not dispose of electric equipment and batteries as household waste
1.2.3 Symbols in the illustrations
The following symbols are used in illustrations:
These numbers refer to the corresponding illustrations found at the beginning of these operating
instructions
The numbering reflects the sequence of operations shown in the illustrations and may deviate
from the steps described in the text
Item reference numbers are used in the overview illustrations and refer to the numbers used in
the product overview section
This symbol is intended to draw special attention to certain points when handling the product.
1.3 Product-dependent symbols
1.3.1 Symbols on the product
The following symbols can be used on the product:
Printed: 24.09.2018 | Doc-Nr: PUB / 5152424 / 000 / 05

2 English
Wireless data transfer
Hilti Li-ion battery type series used. Observe the information given in the section headed In-
tended use.
Rated speed under no load
Revolutions per minute
Drilling without hammer action
Drilling with hammer action (hammer drilling)
1.4 Product information
products are designed for professional users and only trained, authorized personnel are
permitted to operate, service and maintain the products. This personnel must be specifically informed about
the possible hazards. The product and its ancillary equipment can present hazards if used incorrectly by
untrained personnel or if used not in accordance with the intended use.
The type designation and serial number are printed on the rating plate.
▶Write down the serial number in the table below. You will be required to state the product details when
contacting Hilti Service or your local Hilti organization to inquire about the product.
Product information
Drill/driver SF 22-A | SFH 22-A
Generation: 01
Serial no.:
1.5 Declaration of conformity
We declare, on our sole responsibility, that the product described here complies with the applicable directives
and standards. A copy of the declaration of conformity can be found at the end of this documentation.
The technical documentation is filed here:
Hilti Entwicklungsgesellschaft mbH | Tool Certification | Hiltistrasse 6 | 86916 Kaufering, Germany
2 Safety
2.1 General power tool safety warnings
WARNING
Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
Work area safety
▶Keep work area clean and well lit. Cluttered or dark areas invite accidents.
▶Do not operate power tools in explosive atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
▶Keep children and bystanders away while operating a power tool. Distractions can cause you to lose
control.
Electrical safety
▶Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
▶Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the
risk of electric shock.
Personal safety
▶Stay alert, watch what you are doing and use common sense when operating a power tool. Do
not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A
moment of inattention while operating power tools may result in serious personal injury.
Printed: 24.09.2018 | Doc-Nr: PUB / 5152424 / 000 / 05

English 3
▶Use personal protective equipment. Always wear eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
▶Prevent unintentional starting. Ensure the switch is in the off‐position before connecting to battery
pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising
power tools that have the switch on invites accidents.
▶Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
▶Do not overreach. Keep proper footing and balance at all times. This enables better control of the
power tool in unexpected situations.
▶Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
▶If devices are provided for the connection of dust extraction and collection facilities, ensure these
are connected and properly used. Use of dust collection can reduce dust-related hazards.
Power tool use and care
▶Do not force the power tool. Use the correct power tool for your application. The correct power tool
will do the job better and safer at the rate for which it was designed.
▶Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
▶Disconnect the battery pack from the power tool before making any adjustments, changing
accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the
power tool accidentally.
▶Store idle power tools out of the reach of children and do not allow persons unfamiliar with the
power tool or these instructions to operate the power tool. Power tools are dangerous in the hands
of untrained users.
▶Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and
any other condition that may affect the power tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by poorly maintained power tools.
▶Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
▶Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking
into account the working conditions and the work to be performed. Use of the power tool for
operations different from those intended could result in a hazardous situation.
Battery tool use and care
▶Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used with another battery pack.
▶Use power tools only with specifically designated battery packs. Use of any other battery packs may
create a risk of injury and fire.
▶When battery pack is not in use, keep it away from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects, that can make a connection from one terminal to
another. Shorting the battery terminals together may cause burns or a fire.
▶Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritation or burns.
Service
▶Have your power tool serviced by a qualified repair person using only identical replacement parts.
This will ensure that the safety of the power tool is maintained.
2.2 Additional safety precautions for screwdrivers
Personal safety
▶Only use the product if it is in perfect working order.
▶Never tamper with or modify the tool in any way.
▶Use the auxiliary grip supplied with the tool. Loss of control can cause personal injury.
▶Always hold the power tool with both hands on the grips provided. Keep the grips clean and dry.
▶Hold the power tool by the insulated gripping surfaces when performing an operation where the accessory
tool may come into contact with concealed wiring. If the accessory tool comes into contact with a live
wire, metal parts of the power tool may also become live, causing the operator to receive an electric
shock.
▶Avoid touching rotating parts – risk of injury!
Printed: 24.09.2018 | Doc-Nr: PUB / 5152424 / 000 / 05

4 English
▶Wear suitable protective glasses, a hard hat, ear protection, protective gloves and light respiratory
protection while using the tool.
▶Wear protective gloves also when changing the accessory tool. Touching the accessory tool presents a
risk of injury (cuts or burns).
▶Wear eye protection. Flying fragments present a risk of injury to the body and eyes.
▶Before starting work, check the hazard class of the dust that will be produced when working. Use
an industrial vacuum cleaner with an officially approved protection class in compliance with the locally
applicable dust protection regulations. Dust from materials such as lead-based paint, certain types of
wood and concrete/masonry/stone containing quartz, minerals or metal may be harmful to health.
▶Make sure that the working area is well ventilated and, where necessary, wear a respirator appropriate
for the type of dust generated. Contact with or inhalation of dust may cause allergic reactions and/or
respiratory or other diseases to the operator or bystanders. Certain kinds of dust, such as oak and beech
dust, are classified as carcinogenic, especially in conjunction with additives for treating wood (chromate,
wood preservative). Materials containing asbestos may only be handled by specialists.
▶Take breaks between working and do physical exercises to improve the blood circulation in your fingers.
Exposure to vibration during long periods of work can lead to disorders of the blood vessels and nervous
system in the fingers, hands and wrists.
Electrical safety
▶Before starting work, check the working area for concealed electric cables or gas and water pipes. If
you damage an electric cable accidentally, external metal parts of the power tool may become live and
present a risk of electric shock.
Careful handling and use of power tools
▶Switch the power tool off immediately if the accessory tool jams. The power tool may go off course and
veer to the side.
▶Wait until the power tool has come to a complete stop before setting it down.
Printed: 24.09.2018 | Doc-Nr: PUB / 5152424 / 000 / 05

English 5
3 Description
3.1 Overview of the product
Printed: 24.09.2018 | Doc-Nr: PUB / 5152424 / 000 / 05

6 English
@Side handle
;Keyless chuck
=Function setting ring
(screwdriving/drilling/hammer drilling)
%Gear selector switch
&Forward/reverse selector switch with safety
lock
(Control switch (with electronic speed
control)
)Grip
+Release buttons with additional function
(charge status display activation)
§Rating plate
/Belt hook (optional)
:Charge state and fault display (Li-ion
battery)
3.2 Intended use
The product described is a hand-held cordless drill / driver. It is designed to be used for driving and removing
screws and for drilling in steel, wood and plastic. The “'SFH” model is also suitable for hammer drilling in
masonry.
▶Use only Hilti Li-ion batteries of the B22 series with this product.
▶Use only the Hilti battery chargers of the C4/36 series for these batteries.
3.3 Liion battery display
The charge status of the Li-ion battery and malfunctions of the power tool are indicated by the display on
the Liion battery. The charge status of the Liion battery is displayed after pressing one of the two battery
release buttons.
Status Meaning
4 LEDs light. • Charge status: 75 % to 100 %
3 LEDs light. • Charge status: 50 % to 75 %
2 LEDs light. • Charge status: 25 % to 50 %
1 LED lights. • Charge status: 10 % to 25 %
1 LED blinks, the power tool is ready for use. • Charge status: < 10 %
1 LED blinks, the power tool is not ready for use. • The battery has overheated or is completely
discharged.
4 LEDs blink, the power tool is not ready for use. • The power tool is overloaded or has overheated.
Battery charge status cannot be displayed while the control switch is pressed and for up to 5 seconds
after releasing the control switch.
If the battery display LEDs blink, please observe the instructions given in the Troubleshooting section.
3.4 Items supplied
Drill / driver, side handle, operating instructions.
• Other system products approved for use with this product can be found at your local Hilti Store or online
at: www.hilti.group | USA: www.hilti.com
4 Drill/driver
SF 22-A SFH 22-A
Rated voltage 21.6 V 21.6 V
Weight in accordance with EPTA procedure 01 2.52 kg 2.58 kg
Speed 1st gear 0 /min … 370 /min 0 /min … 370 /min
2nd gear 0 /min … 1,250 /min 0 /min … 1,250 /min
3rd gear 0 /min … 2,140 /min 0 /min … 2,140 /min
Torque (soft joint) ≤ 50 Nm ≤ 50 Nm
Torque range (15 settings) 2 Nm … 12 Nm 2 Nm … 12 Nm
Ø drill bit (softwood) 1.5 mm … 32 mm 1.5 mm … 32 mm
Printed: 24.09.2018 | Doc-Nr: PUB / 5152424 / 000 / 05

English 7
SF 22-A SFH 22-A
Ø drill bit (hardwood) 1.5 mm … 20 mm 1.5 mm … 20 mm
Ø drill bit (metal) 1.5 mm … 13 mm 1.5 mm … 13 mm
4.1 Noise information and vibration values in accordance with EN 60745
The sound pressure and vibration values given in these instructions have been measured in accordance with
a standardized test and may be used to compare one power tool with another. They may be used for a
preliminary assessment of exposure.
The data given represents the main applications of the power tool. However, if the power tool is used for
different applications, with different accessory tools or is poorly maintained, the data may vary. This may
significantly increase exposure over the total working period.
An accurate estimation of exposure should also take into account the times when the power tool is switched
off, or when it is running but not actually being used for a job. This may significantly reduce exposure over
the total working period.
Identify additional safety measures to protect the operator from the effects of noise and/or vibration, for
example: Maintaining the power tool and accessory tools, keeping the hands warm, organization of work
patterns.
Noise emission values
SF 22-A SFH 22-A
Emission sound pressure level (LpA)75 dB(A) 96 dB(A)
Uncertainty for the sound pressure level (KpA)3 dB(A) 3 dB(A)
Sound (power) level (LWA)86 dB(A) 107 dB(A)
Uncertainty for the sound power level (KWA)3 dB(A) 3 dB(A)
Total vibration
SF 22-A SFH 22-A
Vibration emission value for screwdriving (ah)< 2.5 m/s² < 2.5 m/s²
Uncertainty for screwdriving (K) 1.5 m/s² 1.5 m/s²
Drilling in metal (ah,D)< 2.5 m/s² < 2.5 m/s²
Uncertainty for drilling in metal (K) 1.5 m/s² 1.5 m/s²
5 Operation
5.1 Preparations at the workplace
CAUTION
Risk of injury by inadvertent starting!
▶Before inserting the battery, make sure that the product is switched off.
▶Remove the battery before making any adjustments to the power tool or before changing accessories.
Observe the safety instructions and warnings in this documentation and on the product.
5.1.1 Charging the battery
1. Before charging the battery, read the operating instructions for the charger.
2. Make sure that the contacts on the battery and the contacts on the charger are clean and dry.
3. Use an approved charger to charge the battery.
5.1.2 Inserting the battery
CAUTION
Risk of injury by short circuit or falling battery!
▶Before inserting the battery, make sure that the contacts on the battery and the contacts on the product
are free of foreign matter.
▶Make sure that the battery always engages correctly.
1. Charge the battery fully before using it for the first time.
Printed: 24.09.2018 | Doc-Nr: PUB / 5152424 / 000 / 05

8 English
2. Push the battery into the battery holder until it engages with an audible click.
3. Check that the battery is seated securely.
5.1.3 Removing the battery
1. Press the release buttons on the battery.
2. Pull the battery out of its holder in the device.
5.1.4 Fitting the belt hook (optional)
WARNING
Risk of injury. A falling power tool may present a risk of injury to yourself and others.
▶Check that the belt hook is fitted securely before beginning work.
▶Fit the belt hook.
➥ The belt hook allows the power tool to be attached close to the body on a belt worn by the operator.
The belt hook can be fitted to allow attachment on the left or right side of the body.
5.1.5 Fitting and adjusting the side handle
▶Fit or adjust the side handle.
5.1.6 Fitting the accessory tool
1. Set the forward/reverse switch to the middle position or remove the battery from the power tool.
2. Check that the connection end of the accessory tool is clean. Clean the connection end if necessary.
3. Open the keyless chuck.
4. Insert the accessory tool into the keyless chuck and then turn the chuck firmly by hand until tight and
several clicks are heard.
5. Check that the accessory tool is held securely.
Printed: 24.09.2018 | Doc-Nr: PUB / 5152424 / 000 / 05

English 9
5.1.7 Removing the accessory tool
1. Set the forward/reverse switch to the middle position or remove the battery from the power tool.
2. Open the keyless chuck.
3. Pull the accessory tool out of the keyless chuck.
5.2 Types of work
ATTENTION
Risk of damage by incorrect handling!
▶Do not operate the switches for direction of rotation and/or function selection during operation.
Observe the safety instructions and warnings in this documentation and on the product.
5.2.1 Setting forward or reverse rotation
▶Set the forward/reverse switch to the desired direction of rotation.
➥ An interlock prevents switching while the motor is running. In the middle position the switch is locked
(safety lock).
5.2.2 Selecting the gear
▶Select the gear.
5.2.3 Switching on
▶Press the control switch.
➥ Speed can be controlled steplessly right up to maximum by varying how far the control switch is
pressed in.
5.2.4 Switching off
▶Release the control switch.
Printed: 24.09.2018 | Doc-Nr: PUB / 5152424 / 000 / 05

10 English
5.2.5 Drilling
1. Set the function selector ring to the symbol.
2. Set the forward/reverse switch to the “forward” position.
5.2.6 Drilling with hammering action (hammer drilling)
1. Set the function selector ring to the symbol.
2. Set the forward/reverse switch to the “forward” position.
5.2.7 Screwdriving
1. Set the function selector ring to the required torque setting.
2. Set the forward/reverse switch to the desired direction of rotation.
6 Care and maintenance
WARNING
Risk of injury with battery inserted !
▶Always remove the battery before carrying out care and maintenance tasks!
Care and maintenance of the tool
• Carefully remove stubborn dirt.
• Clean the air vents carefully with a dry brush.
• Use only a slightly damp cloth to clean the casing. Do not use cleaning agents containing silicone as
these can attack the plastic parts.
Care of the Liion batteries
• Keep the battery free from oil and grease.
• Use only a slightly damp cloth to clean the casing. Do not use cleaning agents containing silicone as
these may attack the plastic parts.
• Avoid ingress of moisture.
Maintenance
• Check all visible parts and controls for signs of damage at regular intervals and make sure that they all
function correctly.
• Do not operate the product if signs of damage are found or if parts malfunction. Have it repaired
immediately by Hilti Service.
• After cleaning and maintenance, fit all guards or protective devices and check that they function correctly.
To help ensure safe and reliable operation, use only genuine Hilti spare parts and consumables. Spare
parts, consumables and accessories approved by Hilti for use with the product can be found at your
local Hilti Store or online at: www.hilti.group | USA: www.hilti.com
7 Transport and storage
Transport
CAUTION
Accidental starting during transport !
▶Always transport your products with the batteries removed!
▶Remove the battery.
▶Transport the tool and battery individually packaged.
▶Never transport batteries in bulk form (loose, unprotected).
▶Check tools and batteries for damage before use after long periods of transport.
Storage
CAUTION
Accidental damage caused by defective or leaking batteries !
▶Always store your products with the batteries removed!
▶Store the tool and battery in a place that is as cool and dry as possible.
▶Never store batteries in direct sunlight, on heating units or behind a window pane.
Printed: 24.09.2018 | Doc-Nr: PUB / 5152424 / 000 / 05

English 11
▶Store the tool and batteries in a place where they cannot be accessed by children or unauthorized
persons.
▶Check the tool and batteries for damage before use after long periods of storage.
8 Troubleshooting
If the trouble you are experiencing is not listed in this table or you are unable to remedy the problem by
yourself, please contact Hilti Service.
8.1 Troubleshooting
Trouble or fault Possible cause Action to be taken
The power tool doesn’t run. The battery is not fully inserted. ▶Insert the battery. → page 7
The battery is discharged. ▶Charge the battery. → page 7
The power tool doesn’t work
and all four LEDs blink.
The power tool has been over-
loaded briefly.
▶Release the control switch and
then press it again.
The overheating cut-out has been
activated.
▶Allow the power tool to cool
down. Clean the air vents.
The power tool doesn’t work
and one LED flashes.
The battery is discharged. ▶Charge the battery. → page 7
The battery is too hot or too cold. ▶Bring the battery to the recom-
mended operating temperature.
The on/off button can’t be
pressed, i.e. the button is
locked.
The forward/reverse selector
switch is in the middle position.
▶Set the forward/reverse switch
to the desired position.
→ page 9
No hammering action. The operating mode is not set cor-
rectly at the selector ring.
▶Set the power tool to “hammer
drilling”. → page 10
The battery runs down more
quickly than usual.
Very low ambient temperature. ▶Allow the battery to warm up
slowly to room temperature.
The battery doesn’t engage
with an audible double click.
The retaining lugs on the battery
are dirty.
▶Clean the retaining lugs and
push the battery in until it
engages. Contact Hilti Service
if the problem persists.
The tool or battery gets very
hot.
The tool is overloaded (application
limits exceeded).
▶Pay attention to the power
and performance rating of the
product before using it, i.e
check its suitability for the job
on hand. See the “Technical
data” section.
9 Disposal
Most of the materials from which Hilti tools and appliances are manufactured can be recycled. The
materials must be correctly separated before they can be recycled. In many countries, your old tools,
machines or appliances can be returned to Hilti for recycling. Ask Hilti Service or your Hilti representative
for further information.
Battery disposal
Improper disposal of batteries can result in health hazards from leaking gases or fluids.
▶DO NOT send batteries through the mail!
▶Cover the terminals with a non-conductive material (such as electrical tape) to prevent short circuiting.
▶Dispose of your battery out of the reach of children.
▶Dispose of the battery at your Hilti Store, or consult your local governmental garbage disposal or public
health and safety resources for disposal instructions.
▶Do not dispose of power tools, electronic equipment or batteries as household waste!
Printed: 24.09.2018 | Doc-Nr: PUB / 5152424 / 000 / 05

12 English
10 RoHS (Restriction of Hazardous Substances)
Click on the links to go to the table of hazardous substances: qr.hilti.com/r4223 (SF 22-A) and
qr.hilti.com/r4224 (SFH 22-A).
There is a link to the RoHS table, in the form of a QR code, at the end of this document.
11 Manufacturer’s warranty
▶Please contact your local Hilti representative if you have questions about the warranty conditions.
Printed: 24.09.2018 | Doc-Nr: PUB / 5152424 / 000 / 05

Printed: 24.09.2018 | Doc-Nr: PUB / 5152424 / 000 / 05

Printed: 24.09.2018 | Doc-Nr: PUB / 5152424 / 000 / 05

Printed: 24.09.2018 | Doc-Nr: PUB / 5152424 / 000 / 05

Hilti = registered trademark of Hilti Corp., Schaan 20180830
Printed: 24.09.2018 | Doc-Nr: PUB / 5152424 / 000 / 05
