Hilti PP10 User manual

PP 10/11
Operating instructions en
Brugsanvisning da
Bruksanvisning no
Bruksanvisning sv
Käyttöohje fi
Printed: 07.07.2013 | Doc-Nr: PUB / 5070148 / 000 / 00

1
Printed: 07.07.2013 | Doc-Nr: PUB / 5070148 / 000 / 00

2 3
4 5
Printed: 07.07.2013 | Doc-Nr: PUB / 5070148 / 000 / 00

6 7
8 9
Printed: 07.07.2013 | Doc-Nr: PUB / 5070148 / 000 / 00

10 11
12
Printed: 07.07.2013 | Doc-Nr: PUB / 5070148 / 000 / 00

PP 10 / 11 pipe laser
It is essential that the operating instructions
are read before the tool is operated for the
first time.
Always keep these operating instructions
together with the tool.
Ensure that the operating instructions are
with the tool when it is given to other
persons.
Contents Page
1. General information 1
2. Description 3
3. Accessories 4
4. Technical data 4
5. Safety rules 5
6. Before use 6
7. Operation 7
8. Care and maintenance 11
9. Troubleshooting 12
10. Disposal 12
11. Manufacturer’s warranty - tools 13
12. EC declaration of conformity 14
Component parts 1
PP 10 / 11 pipe laser
@Remote control signal receiving window
;Warning / standby LED
=Control panel
%Display
&Grip
(Grip mount
)PPA 84 cable connector
+Battery compartment cover lock
§PPA 82 battery incl. mains adaptor
/Plumb spot
PP 10 / 11 pipe laser
:Laser exit window
·Remote control signal receiving window
$Plumb spot
£Pivot point mark
Control panel
|Direction control / auto-centering button
¡Plumb spot button
QLaser beam mode button
WRemote control signal receiving window
E“Lock” button
RAuto-centering target plate button
TDirection control / auto-centering button
ZSET button
ULaser beam up / down, value-entry button
IWarning / standby LED
OLaser beam up / down, value-entry button
PON / OFF button
1. General information
1.1 Safety notices and their meaning
DANGER
Draws attention to imminent danger that could lead
to serious bodily injury or fatality.
WARNING
Draws attention to a potentially dangerous situation
that could lead to serious personal injury or fatality.
CAUTION
Draws attention to a potentially dangerous situation
that could lead to slight personal injury or damage to
the equipment or other property.
NOTE
Draws attention to an instruction or other useful
information.
1.2 Explanation of the pictograms and other
information
Warning signs
General
warning
en
1
Printed: 07.07.2013 | Doc-Nr: PUB / 5070148 / 000 / 00

CLASS IIIa LASER PRODUCT
675-695nm < 5mW max.
LASER RADIATION - AVOID DIRECT
EYE EXPOSURE
DANGER
CLASS IIIa LASER PRODUCT
520-550nm < 5mW max.
LASER RADIATION - AVOID DIRECT
EYE EXPOSURE
DANGER
3R
CLASS IIIa LASER PRODUCT
620-690nm < 5mW max.
LASER RADIATION - AVOID DIRECT
EYE EXPOSURE
3R
319789
PP 10
Made in Japan
Hilti= registered trademark of the Hilti Corporation, Schaan, Liechtenstein
Power: 6.0V=nom./250 mA
EN 60825-1:2003
This Laser Product
complies with 21CFR
1040 as applicable
DANGER
AVOID EXPOSURE
LASER LIGHT IS EMITTED
FROM THIS APERTURE
Item No.: 319781
Date .:
CLASS IIIa LASER PRODUCT
520-550nm < 5mW max.
LASER RADIATION - AVOID DIRECT
EYE EXPOSURE
3R
319795
PP 11
Made in Japan
Hilti= registered trademark of the Hilti Corporation, Schaan, Liechtenstein
Power: 6.0V=nom./250 mA
EN 60825-1:2003
This Laser Product
complies with 21CFR
1040 as applicable
DANGER
AVOID EXPOSURE
LASER LIGHT IS EMITTED
FROM THIS APERTURE
Item No.: 319791
Date .:
Symbols
Read the
operating
instructions
before use.
Return waste
material for
recycling.
On the tool
Do not stare into the beam.
Laser warning plates for the USA in accordance with
CFR 21 § 1040 (FDA).
On the tool
Do not stare into the beam.
Laser warning plates for the USA in accordance with
CFR 21 § 1040 (FDA).
On the tool
Laser warning plate in accordance with IEC825 /
EN60825-1:2003
Type identification plate
PP 10
Type identification plate
PP 11
1These numbers refer to the corresponding illustra-
tions. The illustrations can be found on the fold-out
cover pages. Keep these pages open while studying
the operating instructions.
In these operating instructions, the designation “the
tool” always refers to the PR 10 / 11 pipe laser.
Location of identification data on the tool
The type designation and serial number can be found
on the type plate on the tool. Make a note of this data
in your operating instructions and always refer to it
when making an enquiry to your Hilti representative
or service department.
Type:
Serial no.:
en
2
Printed: 07.07.2013 | Doc-Nr: PUB / 5070148 / 000 / 00

2. Description
2.1 Use of the product as directed
The tool is designed to be used for determining, trans-
ferring or checking alignment in the horizontal and
inclined planes, e.g.: transferring heights and in pipe
laying work. Hilti supplies various accessories which
allow the tool to be used with maximum efficiency.
2.2 PP 10/11 pipe laser
The PP 10/11 is a pipe laser featuring a visible laser
beam (spot) that can be used for alignment in the
horizontal or inclined planes.
2.3 Features
A single person working with the tool can set out any
desired inclination (within the -15% to +40% range)
with great accuracy. The tool levels itself automatically
when set up within ±10% of the horizontal plane.
2.4 Automatic cut-out
The laser beam and the LED on the control panel blink
if the tool is set up outside its self-leveling range. The
direction in which the tool requires to be tilted is also
shown in the display.
2.5 PPA 82 battery
Battery performance drops at low temperatures.
DANGER
Batteries should be stored at room temperature.
DANGER
Never store the battery where it is exposed to the
heat of the sun, on a radiator or behind glass, e.g.
at a window.
2.6 Automatic charging cut-out
The charging operation is stopped automatically to
protect the battery when the temperature exceeds the
specified charging temperature range.
NOTE
Charge the battery every 3 to 4 months. Store the
battery at a maximum temperature of 30°C (86°F).
Allowing the battery to become fully discharged may
have a negative effect on its future performance.
Charging may take less than 9 hours if the battery
was not previously fully discharged.
2.7 Use of various power sources
Three different power sources may be used: the
standard PPA 82 battery supplied or the PPA 83
battery holder or PPA 84 external 12V cable which
are available as accessories.
2.8 Items supplied
1 PP 10 or 11 pipe laser (depending on
version purchased)
1 PPA 20 remote control unit
1 Target plate, short
1 Target plate, long
1 PPA 74 target plate holder
1 PPA 81 charging adaptor
1 PPA 82 battery incl. mains adaptor
1 Set of 4 screw feet, 150 mm
1 Set of 4 screw feet, 200 mm
1 Set of 4 screw feet, 250 mm
1 Set of 4 screw feet, 300 mm
1 PPA 30 centering screw
1 PP 10 / 11 operating instructions
1 PPA 20 operating instructions
4 Batteries (size AAA cells)
1 Manufacturer’s certificate
1 Hilti toolbox
en
3
Printed: 07.07.2013 | Doc-Nr: PUB / 5070148 / 000 / 00

3. Accessories
PP 10 / 11 accessories
PPA 83 battery holder (size D cells)
PPA 84 connecting cable (12V)
PPA 70/71/72 vertical and horizontal adapter
PPA 73 tripod adaptor
PPA 40 telescopic sight
4. Technical data
NOTE
Right of technical changes reserved.
Wavelength, PP 10 633 Nm
Wavelength, PP 11 532 Nm
Accuracy Temperature 24°C (75°F), Horizontal distance 10 m
(33 ft): ತ0.5 - 0.5 mm ({೑೦")
Laser class: class 3R As perIEC 825ತ1:2003
Laser class: class IIIa As perCFR 21 § 1040 (FDA)
Laser beam diameter 12 mm ({೑ೣ")
Self-leveling range ತ10 - 10%
Inclination range ತ15 - 40%
Min. inclination setting 0.001%
Battery life (PP10) Temperature 20°C (+68°F), Alkaline manganese:
70 h
Temperature 20°C (+68°F), NiMH: Min. 48 h
Battery life (PP11) Temperature 20°C (+68°F), Alkaline manganese:
45 h
Temperature 20°C (+68°F), NiMH: Min. 32 h
Operating temperature range ತ20 - 50°C (-4 to 122°F)
Storage temperature range ತ30 - 60°C (-22 to 140°F)
Water and dust resistant Depth of submersion 5 m (15 ft), Duration of
submersion 24 h: Yes
Weight (including 4 batteries) 3.8 kg (8 lbs 6 oz)
Dimensions () Without grip: 122 mm (4 ೕ೑೦") x 330 mm (13")
Automatic target plate seek
Range 5 - 150 m (15 to 500 ft)
en
4
Printed: 07.07.2013 | Doc-Nr: PUB / 5070148 / 000 / 00

5. Safety rules
5.1 Basic information concerning safety
The tool is designed to be used for determining,
transferring or checking alignment in the horizontal
and inclined planes.
In addition to the information relevant to safety given
in each of the sections of these operating instructions,
the following points must be strictly observed at all
times.
5.2 Misuse
a) The tool and its ancillary equipment may present
hazards when used incorrectly by untrained per-
sonnel or when used not as directed.
b) To avoid the risk of injury, use only genuine Hilti
accessories and additional equipment.
c) Modification of the tool is not permissible.
d) Observe the information printed in the operat-
ing instructions concerning operation, care and
maintenance.
e) Do not render safety devices ineffective and do
not remove information and warning notices.
f) Keep laser tools out of reach of children.
g) Failure to follow the correct procedures when
opening the tool may cause emission of laser
radiation in excess of class 3. Have the tool
repaired only at a Hilti service center.
h) Take the influences of the surrounding area into
account. Do not use the tool where there is a risk
of fire or explosion.
i) (Statement in accordance with FCC §15.21):
Changes or modifications not expressly approved
by the manufacturer can void the user’s authority
to operate the equipment.
5.3 Proper organization of the work area
a) Secure the area in which you are working and
take care to avoid directing the beam towards
other persons or towards yourself when setting
up the tool.
b) Measurements taken through panes of glass or
other objects may be inaccurate.
c) Ensure that the tool is set up on a steady, level
surface (not subject to vibration).
d) Use the tool only within its specified limits.
5.3.1 Electromagnetic compatibility
Although the tool complies with the strict require-
ments of the applicable directives, Hilti cannot en-
tirely rule out the possibility of the tool being subject
to interference caused by powerful electromagnetic
radiation, leading to incorrect operation. Check the
accuracy of the tool by taking measurements by other
means when working under such conditions or if you
are unsure. Likewise, Hilti cannot rule out the pos-
sibility of interference with other devices (e.g. aircraft
navigation equipment).
5.3.2 Laser classification for tools of the classes
3R and IIIa
a) The tool conforms with laser class 3R in ac-
cordance with IEC 825ತ1:2003 and class IIIa in
accordance with 21 CFR § 1040(FDA).
b) Tools of the laser class 3R and class IIIa should
be operated by trained personnel only.
c) The area in which the tool is in use must be marked
with laser warning signs.
d) The plane of the laser beam should be well above
or well below eye level.
e) Precautions must be taken to ensure that the
laser beam does not unintentionally strike highly
reflective surfaces.
f) Precautions must be taken to ensure that persons
do not stare directly into the beam.
g) The laser beam must not be allowed to project
beyond the controlled area.
h) When not in use, laser tools should be stored in
a place to which unauthorized persons have no
access.
5.4 General safety rules
a) Check the condition of the tool before use. If the
tool is found to be damaged, have it repaired at
a Hilti service center.
b) The user must check the accuracy of the tool
after it has been dropped or subjected to other
mechanical stresses.
c) When the tool is brought into a warm environ-
ment from very cold conditions, or vice-versa,
allow it to become acclimatized before use.
en
5
Printed: 07.07.2013 | Doc-Nr: PUB / 5070148 / 000 / 00

d) If mounting on an adapter, check that the tool is
screwed on securely.
e) Keep the laser exit aperture clean to avoid meas-
urement errors.
f) Although the tool is designed for the tough con-
ditions of jobsite use, as with other optical and
electronic instruments (e.g. binoculars, spec-
tacles, cameras) it should be treated with care.
g) Although the tool is protected to prevent entry
of dampness, it should be wiped dry each time
before being put away in its transport container.
h) Check the tool before using it for important meas-
uring work.
i) Check the accuracy of the measurements several
times during use of the tool.
5.4.1 Electrical
a) Keep the batteries out of reach of children.
b) Do not allow the batteries to overheat and do not
expose them to fire. The batteries may explode or
release toxic substances.
c) Do not charge the batteries.
d) Do not solder the batteries into the tool.
e) Do not discharge the batteries by short circuiting
as this may cause them to overheat and present
a risk of personal injury (burns).
f) Do not attempt to open the batteries and do not
subject them to excessive mechanical stress.
6. Before use
NOTE
The tool may be powered only by the PPA 82 battery
or by batteries manufactured in accordance with IEC
285.
NOTE
Do not use damaged batteries, do not mix old and
new batteries and do not mix batteries from vari-
ous manufacturers or batteries with different type
designations.
6.1 Switching the tool on
Press the ON / OFF button.
NOTE
The PP 10/11 is capable of leveling itself within a
range of +/- 10%. The tool levels itself automatically
when set up within this range. The LED begins to
blink when the inclination of the tool is more than +/-
10% from the set inclination. The tool should then be
rotated in the direction indicated by the arrow.
6.2 Battery warning indicator 2
1 Adequate voltage The tool can be used.
2 Low voltage The tool can still be used.
3 The battery is discharged. Charge the NiMH battery or insert new alkaline
batteries.
4 The display blinks The PPA 84 12V connecting cable is used for
charging the laser tool.
6.3 Removing the PPA 83 battery holder or PPA
82 battery
1. Turn the battery locking knob to “OPEN” and
remove the battery holder.
2. In addition, the battery compartment in the PPA
83 battery box can be opened. To do this, turn
the knob on the battery compartment cover to the
“OPEN” position.
6.4 Replace the batteries.
1. Replace the used batteries in the battery holder
with new ones.
en
6
Printed: 07.07.2013 | Doc-Nr: PUB / 5070148 / 000 / 00

6.5 Fitting the PPA 83 battery holder or PPA 82
battery
1. Refit the battery holder after replacing the batter-
ies.
2. Turn the knob to the “LOCK” position.
6.6 Connecting the PPA 84 cable
NOTE
If using a battery fitted to a motor vehicle, please first
switch off the engine.
NOTE
Take care to ensure correct polarity when connecting
both terminals.
NOTE
Switch the tool off before connecting or disconnecting
the external power cable.
The connecting cable is designed for connecting to a
12 V battery.
1. Connect the red clip to the positive (+) pole.
2. Connect the black clip to the negative (-) pole.
6.7 Charging the PPA 82 battery
Charging should take place in a room where the
temperature is between +10|C and +40|C.
The battery is charged automatically when the laser
is operated at a temperature of [+10|C to +40|C] with
an external battery.
1. Fit the PPA 81 charging adapter to the PPA 82
battery.
2. Connect the power supply unit to the charging
adapter.
3. Plug the power supply unit into a power outlet.
4. Check that the correct voltage has been set on the
power supply unit.
The charging control lamp lights green when the
charging operation is complete.
6.8 Charging status
Charging status Red LED lights Charging
Green LED lights Charging completed
Blinks green Error during charging
Blinks red The protective cut-out has been activated. The PP 10
/ 11 may be used while in this status.
7. Operation
7.1 Button functions 3
1 Plumb spot button Switches the plumb spot on and off (switches off
automatically after 30 minutes).
2 Laser beam mode button The laser beam can be switched over by pressing
the laser beam mode button. PP 10: constant beam
or blinking beam PP 11: constant beam, blinking
beam, high-power mode
3“Lock” button This button locks all data entry functions. Values can
then no longer be changed. The data entry functions
can be unlocked by pressing the LOCK button again.
4 Auto-centering target plate button The laser beam finds the center of the target plate
automatically.
5 Direction control Moves the laser beam to the left or right.
5 Parameter selection Used to select the parameters to be set.
en
7
Printed: 07.07.2013 | Doc-Nr: PUB / 5070148 / 000 / 00

5 Automatic centering The laser beam centers itself automatically when
both direction control buttons are pressed at the
same time.
6 Laser beam up / down Moves the laser beam up or down.
6 Value entry Positive or negative values may be entered. When
both buttons are pressed at the same time, inclination
is set automatically to 00.000% .
7SET button This button is used to confirm the selected
parameters.
8ON / OFF button This button is used to switch the tool on or off.
7.2 Symbols in the display 4
1 Plumb spot indicator. Shows that the plumb spot is active.
2 Alignment indicator Indicates laser beam alignment.
3 Battery status indicator Remaining battery capacity is shown in 3 levels.
4Self-leveling indicator Blinks while the laser is leveling itself. The display
subsequently changes to the laser mode set.
5 Inclination indicator Shows the selected inclination.
6 Percentage Shows the unit of measurement selected (percentage
or per thousand).
7 Lock symbol The values entered cannot be changed.
8 Electronic bubble level Shows whether the tool is leveled correctly.
9 Laser mode display The laser modes “blinking”, “normal” and “high-
power” (PP11) are shown.
7.3 Warnings displayed 5
1 Battery status warning Operation is no longer possible. Replace / recharge
the battery or connect an external power source.
2 Leveling warning The laser is tilted beyond its self-leveling range. Tilt
the laser tool in the direction of the arrow shown in
the display.
3 Transverse inclination warning The laser tool has been rotated beyond its self-
leveling range. Rotate the laser tool in the direction
of the arrow shown in the display.
7.4 Switching the tool on
Press the ON / OFF button.
NOTE
The PP 10/11 is capable of leveling itself within a
range of +/- 10%. The tool levels itself automatically
when set up within this range. The LED begins to
blink when the inclination of the tool is more than +/-
10% from the set inclination. The tool should then be
rotated in the direction indicated by the arrow.
7.5 Setting the inclination 6
Inclination can be set either manually or automatically.
Inclination can be set within the -15% to +40% range
(for inclinations over 10%, an accessory or other aid
is used to provide initial inclination of the laser tool).
7.5.1 Automatic entry of inclination 6
1. Switch the tool on by pressing the ON / OFF
button.
en
8
Printed: 07.07.2013 | Doc-Nr: PUB / 5070148 / 000 / 00

2. Press the SET button. The set value is displayed
and the ± indicator blinks.
3. Press the laser beam UP or DOWN button to
change the sign.
4. Press the right-hand direction control button in
order to reach the correct position (the left direc-
tion control button can be used to move back).
5. Press the laser beam UP or DOWN button to
change the value.
6. Press the right-hand direction control button to
move to the next position.
7. Press the laser beam UP or DOWN button to
change the value. Repeat the steps described
above to change other numerical values.
8. Press the SET button when the value entered is
correct.
The laser beam then begins to move to the spe-
cified setting.
7.5.2 Manual entry of inclination
NOTE
Inclination can also be set directly by moving the laser
beam. Check that the locking function has not been
activated.
The value indicated becomes higher or lower as the
laser beam is moved.
1. Press the laser beam UP or DOWN button. The
laser beam then moves up or down.
2. Press the laser beam UP and DOWN buttons at
the same time to move the laser beam to the zero
position.
The laser beam moves immediately to the 0.000%
position.
7.6 Aligning the target line 7
Use the direction control buttons on the PP 10/11 or
PPA 20 remote control unit to move the laser beam
horizontally to the right or left.
7.7 Beam position indicator 7
1 Beam position indicator Shows the direction of the laser beam relative to the
tool.
2End position left Shows that the laser beam cannot be aimed further
to the left.
3 End position right Shows that the laser beam cannot be aimed further
to the right.
7.8 Adjusting the position of the beam 7
The maximum lateral adjustment range is 9m at a
distance of 30m. The speed of movement can be
varied.
If the button is pressed briefly, the laser beam moves
slowly.
If the button is pressed for longer, the laser beam
moves quickly.
The current position of the beam can be read from
the display at any time.
7.8.1 Adjusting the beam end position left / right
The display informs the operator when the beam has
reached the left or right end position and cannot
be moved further. The display blinks to inform the
operator of this status.
If this position is reached frequently it is recommen-
ded that the tool is pivoted slightly to the left or right
and the beam then realigned.
7.9 Automatic centering
Press the two direction control buttons (left and right)
at the same time.
The laser beam returns to the center automatically.
7.10 Automatic alignment with the target
plate 8
1. Set up the target plate with the reflective stripes
facing the laser tool.
2. Press the target plate auto-centering button.
NOTE This function may take up to 2 minutes
before starting.
The tool then searches for the target plate within
its alignment range (left/right).
en
9
Printed: 07.07.2013 | Doc-Nr: PUB / 5070148 / 000 / 00

7.11 Display while searching 8
1The laser tool is not yet ready for
automatic alignment. The tool has not yet completed the self-leveling procedure.
NOTE
This procedure will first be completed.
2The display indicates stabilization of the
laser beam after self-leveling.
Please wait until this operation has been completed.
3 The display indicates that searching (auto
centering) is in progress. Searching (auto centering) then begins.
4 Automatic alignment has been completed. Check the position of the laser spot on the target
plate.
NOTE
If necessary, the remote control or the direction
control buttons on the tool (left / right) can be used
to readjust the position of the beam.
5 Error during automatic alignment. If the beam loses contact with the target plate while
searching, the procedure must be restarted.
7.12 Selecting the laser beam mode
Press the laser beam mode button as often as neces-
sary until the desired display mode is shown in the
display.
Constant beam
Blinking beam
High-power mode (only with the PP 11)
7.13 Adjusting the electronic bubble level 9
When the tool is pivoted, the bubble level appears
clearly in the display.
Adjust the tool until the “bubble” is in the center of
the display.
The LED begins to blink as soon as the tool’s com-
pensation range is exceeded.
7.14 Fitting the screw feet and centering
screw 
Fit the appropriate feet for the pipe diameter before
setting up the laser in the pipe.
NOTE
Feet are available in the sizes 150 mm, 200 mm,
250 mm and 300 mm (6", 8", 10", 12").
7.15 Setting the target plate size 
Set the target plate size to a value suitable for the pipe
diameter you are working with.
7.16 Target plate, front 
1 Locking screw Secures the target plate at the desired height.
2 Target plate, small Target plate for 150 mm to 250 mm.
3 Bubble level For setting up the target plate horizontally.
4 Target plate holder For automatic alignment.
7.17 Target plate, rear (2) 
5Reflective stripes (only for the PP 11)
7.18 Setting parameters
7.18.1 Setting units of measurement to % or ‰
1. Press the ON / OFF button and the LOCK button
at the same time.
The set values are shown in the display.
2. Use the laser beam UP / DOWN button to move
to the “unit” line.
3. Select the value you wish to change by pressing
the direction control button.
en
10
Printed: 07.07.2013 | Doc-Nr: PUB / 5070148 / 000 / 00

4. Press the SET button to confirm the entry.
The tool then returns to the normal operating
mode.
7.18.2 Setting and activating the security code
Unauthorized persons can be prevented from using
the laser tool by entering a 4-digit security code.
Please note that once the security code has been
activated, the laser tool can no longer be operated
without entering this code. The code will be requested
automatically after the tool is switched on.
1. Press the ON / OFF button and the LOCK button
at the same time.
The set values are shown in the display.
2. Use the laser beam UP / DOWN button to move
to the “input S code” line.
3. Press the SET button to enter the correct mode.
4. The laser beam UP / DOWN button and direction
control button can be used to navigate to the
corresponding number. Press the SET button
to confirm the number selected. Press the SET
button to confirm the code as soon as the four
desired digits are displayed in the “code” area of
the display.
5. The display then returns to the previous mode.
The security code can then be activated (“on”
by pressing the SET button) or deactivated later
(“off” by pressing the SET button again).
The tool then returns to the normal operating
mode.
7.18.3 Entering the name of the company
These instructions describe how to enter or change
the name of the company. A maximum of 32 charac-
ters (16 characters in 2 rows) can be entered.
1. Press the ON / OFF button and the LOCK button
at the same time.
The set values are shown in the display.
2. Use the laser beam UP / DOWN button to move
to the “change name” line.
3. Press the SET button to enter the correct mode.
4. Use the laser beam UP / DOWN button and
direction control button to navigate to the corres-
ponding characters / digits. Press the SET button
to confirm the character selected. Press the SET
button to confirm the entry as soon as the correct
name / designation is displayed.
The tool then returns to the normal operating
mode.
7.19 Checking the tool’s accuracy 
1. Set the laser to an inclination of 0.000%.
2. Set up a leveling staff at a distance of 1m and a
second leveling staff at a distance of 60m. Note
the heights at which the laser beam strikes the
staffs.
3. Set up an optical level in the middle between the
two leveling staffs and read the heights from both
staffs.
4. Calculate the difference in height indicated by the
optical level and the rotating laser on staffs 1 and
2. If both values are identical, then the laser tool
is correctly adjusted.
NOTE If the differences X1 and X2 are not equal,
please contact your local Hilti Center or Hilti
representative.
8. Care and maintenance
8.1 Cleaning and drying
1. Blow dust off the lenses.
2. Do not touch the glass with your fingers.
3. Use only a clean, soft cloth for cleaning. If neces-
sary, moisten the cloth slightly with pure alcohol
or a little water.
NOTE Do not use any other liquids as these may
damage the plastic components.
4. Observe the temperature limits when storing your
equipment. This is particularly important in winter
/ summer if the equipment is kept inside a motor
vehicle (-30°C to +60°C).
8.2 Storage
Remove the tool from its case if it has become wet.
The tool, its carrying case and accessories should be
cleaned and dried (at maximum 40°C / F). Repack the
equipment only once it is completely dry.
Check the accuracy of the equipment before it is used
after a long period of storage or transportation.
Remove the batteries from the tool before storing it
for a long period.
en
11
Printed: 07.07.2013 | Doc-Nr: PUB / 5070148 / 000 / 00

8.3 Transport
Use the Hilti toolbox or packaging of equivalent quality
for transporting or shipping your equipment.
CAUTION
Always remove the batteries before shipping the
tool.
8.4 Hilti calibration service
We recommend that the tool is checked by the Hilti
calibration service at regular intervals in order to
verify its reliability in accordance with standards and
legal requirements.
Use can be made of the Hilti calibration service
at any time, but checking at least once a year is
recommended.
The calibration service provides confirmation that the
tool is in conformance, on the day it is tested, with
the specifications given in the operating instructions.
The tool will be readjusted if deviations from the
manufacturer’s specification are found. After check-
ing and adjustment, a calibration sticker applied to
the tool and a calibration certificate provide written
verification that the tool operates in accordance with
the manufacturer’s specification.
Calibration certificates are always required by com-
panies certified according to ISO 900x.
Your local Hilti Center or representative will be pleased
to provide further information.
9. Troubleshooting
Fault Possible cause Remedy
E02/03 An internal measurement problem
has occurred. Switch the tool off and then on
again. An error message may be
displayed if the tool is knocked or
shaken. In this case, eliminate the
cause of the disturbance.
E99 An internal memory problem has
occurred. Switch the tool off and then on
again.
ERROR The tool was moved while in standby
mode. Switch the tool off and then on
again and check that it is set up
correctly.
NOTE
Contact your nearest Hilti Service
Center if the fault persists.
10. Disposal
WARNING
Improper disposal of the equipment may have serious consequences:
The burning of plastic components generates toxic fumes which may present a health hazard.
Batteries may explode if damaged or exposed to very high temperatures, causing poisoning, burns, acid burns
or environmental pollution.
Careless disposal may permit unauthorized and improper use of the equipment. This may result in serious
personal injury, injury to third parties and pollution of the environment.
en
12
Printed: 07.07.2013 | Doc-Nr: PUB / 5070148 / 000 / 00

Most of the materials from which Hilti tools or machines are manufactured can be recycled. The materials must
be correctly separated before they can be recycled. In many countries, Hilti has already made arrangements
for taking back old tools and appliances for recycling. Ask Hilti customer service or your Hilti representative
for further information.
For EC countries only
Disposal of electric tools together with household waste is not permissible.
In observance of European Directive 2002/96/EC on waste electrical and electronic equipment
and its implementation in accordance with national law, electric tools that have reached the end
of their life must be collected separately and returned to an environmentally compatible recycling
facility.
Dispose of the batteries in accordance with national regulations.
11. Manufacturer’s warranty - tools
Hilti warrants that the tool supplied is free of defects
in material and workmanship. This warranty is valid
so long as the tool is operated and handled correctly,
cleaned and serviced properly and in accordance with
the Hilti Operating Instructions, and the technical
system is maintained. This means that only original
Hilti consumables, components and spare parts may
be used in the tool.
This warranty provides the free-of-charge repair or
replacement of defective parts only over the entire
lifespan of the tool. Parts requiring repair or replace-
ment as a result of normal wear and tear are not
covered by this warranty.
Additional claims are excluded, unless stringent na-
tional rules prohibit such exclusion. In particular,
Hilti is not obligated for direct, indirect, incidental
or consequential damages, losses or expenses in
connection with, or by reason of, the use of, or
inability to use the tool for any purpose. Implied
warranties of merchantability or fitness for a par-
ticular purpose are specifically excluded.
For repair or replacement, send the tool or related
parts immediately upon discovery of the defect to
the address of the local Hilti marketing organization
provided.
This constitutes Hilti's entire obligation with regard
to warranty and supersedes all prior or contempor-
aneous comments and oral or written agreements
concerning warranties.
en
13
Printed: 07.07.2013 | Doc-Nr: PUB / 5070148 / 000 / 00

12. EC declaration of conformity
Designation: Pipe laser
Type: PP 10 / 11
Year of design: 2005
We declare, on our sole responsibility, that this
product complies with the following directives and
standards: EN 61000ತ6ತ2, EN 61000ತ6ತ3.
Hilti Corporation
Matthias Gillner Dr. Heinz
ತ
Joachim Schneider
Head BU Measuring Systems Executive Vice President
BU Measuring Systems Business Area Electric
Tools & Accessories
07 2005 07 2005
en
14
Printed: 07.07.2013 | Doc-Nr: PUB / 5070148 / 000 / 00

PP 10 / 11 Rørlægningslaser
Læs brugsanvisningen grundigt igennem,
inden apparatet tages i brug.
Opbevar altid brugsanvisningen sammen
med apparatet.
Sørg for, at brugsanvisningen altid følger
med ved overdragelse af apparatet til
andre.
Indholdsfortegnelse side
1. Generelle anvisninger 15
2. Beskrivelse 17
3. Tilbehør 17
4. Tekniske specifikationer 18
5. Sikkerhedsanvisninger 18
6. Ibrugtagning 20
7. Anvendelse 21
8. Rengøring og vedligeholdelse 25
9. Fejlsøgning 25
10. Bortskaffelse 26
11. Producentgaranti - Produkter 26
12. EF-overensstemmelseserklæring 27
Instrumentets dele 1
Rørlægningslaser PP 10/11
@Modtagevindue for fjernbetjening
;Advarsel / Standby LED
=Anvendelsesområde
%Display
&Bæregreb
(Grebsfastgørelse
)Tilslutning Forbindelseskabel PPA 84
+Batterilukning
§Batteri PPA 82 inkl. strømforsyning
/Lodlyspunkt
Rørlægningslaser PP 10 / 11
:Laserudgangsvindue
·Modtagevindue for fjernbetjening
$Lodlyspunkt
£Trepunktmarkering
Anvendelsesområde
|Retningskontrol / Tast til automatisk centrering
¡Lodlyspunkttast
QLaserstrålefunktionstast
WModtagevindue Fjernbetjening
ELåsetast
RAutomatisk centrering Målpladetast
TRetningskontrol / Tast til automatisk centrering
ZSET-tast
ULaserstråle op / ned, tast til indlæsning af vær-
dier
IAdvarsel / Standby LED
OLaserstråle op / ned, tast til indlæsning af vær-
dier
PTænd/sluk-tast
1. Generelle anvisninger
1.1 Signalord og deres betydning
FARE
Står ved en umiddelbart truende fare, der kan medføre
alvorlige kvæstelser eller døden.
ADVARSEL
Advarer om en potentielt farlig situation, der kan
forårsage alvorlige personskader eller døden.
FORSIGTIG
Advarer om en potentielt farlig situation, der kan
forårsage lettere personskader eller materielle skader.
BEMÆRK
Står ved anvisninger om brug og andre nyttige oplys-
ninger.
1.2 Forklaring af piktogrammer og yderligere
anvisninger
Advarselssymboler
Generel fare
da
15
Printed: 07.07.2013 | Doc-Nr: PUB / 5070148 / 000 / 00
