ORIGINAL OPERATING INSTRUCTIONS
PD 42 laser range meter
It is essential that the operating instructions
are read before the tool is operated for the
first time.
Always keep these operating instructions to-
gether with the tool.
Ensure that the operating instructions are
with the tool when it is given to other persons.
Contents Page
1 General information 1
2Description 2
3 Insert tools, accessories 5
4 Technical data 5
5 Safety instructions 6
6Beforeuse 7
7 Operation 11
8 Care and maintenance 17
9 Troubleshooting 18
10 Disposal 19
11 Manufacturer’s warranty - tools 19
12 EC declaration of conformity (original) 20
1These numbers refer to the corresponding illustra-
tions. The illustrations can be found on the fold-out cover
pages. Keep these pages open while studying the oper-
ating instructions.
Parts, operating controls and indicators 1
@On/off button
;Side measure button
=Graphic display
%Measure button
&Delete (clear) button
(Horizontal bubble
)FNC-button
+Folding spike
§¹/₄" thread for PDA 71 measuring extension
/Rear contact points
:Minus button
·Plus button
$¹/₄" thread on the underside
£Reference button
|Optical sight
¡Laser exit lens
QReceiving lens
WVertical bubble
1 General information
1.1 Safety notices and their meaning
DANGER
Draws attention to imminent danger that will lead to
seriousbodilyinjuryorfatality.
WARNING
Draws attention to a potentially dangerous situation that
could lead to serious personal injury or fatality.
CAUTION
Draws attention to a potentially dangerous situation that
could lead to slight personal injury or damage to the
equipment or other property.
NOTE
Draws attention to an instruction or other useful informa-
tion.
1.2 Explanation of the pictograms and other
information
Warning signs
General
warning
en
1
Printed: 08.07.2013 | Doc-Nr: PUB / 5070024 / 000 / 01

>1/4s
Symbols
Read the
operating
instructions
before use.
Return waste
material for
recycling.
Laser class II
according to
CFR 21, § 1040
(FDA)
Laser Class
2in
accordance
with IEC/EN
60825‑1:2007
Do not look
into the
beam.
Temperature
indicator
Battery status
indicator Hardware errors Unfavorable operating
conditions
KCC‑REM-
HLT‑PD42
Location of identification data on the tool
The type designation and serial number can be found on
the type identification plate on the tool. Make a note of
this data in your operating instructions and always refer
to it when making an enquiry to your Hilti representative
or service department.
Type:
Serial no.:
2 Description
2.1 Use of the product as directed
The tool is designed for measuring distances, adding and subtracting distances and offers many practical functions
such as a timer, area and volume measurement, min/max calculation, setting out, painter’s area measurement,
Pythagoras function and data memory.
Do not use the tool as a leveling tool.
Measurements taken from plastic foam materials such as polystyrene foam, from snow or from highly reflective
surfaces (mirrors, glass, etc.) may produce inaccurate results.
The tool and its ancillary equipment may present hazards when used incorrectly by untrained personnel or when used
not as directed.
Take the influences of the surrounding area into account. Do not use the appliance where there is a risk of fire or
explosion.
Observe the information printed in the operating instructions concerning operation, care and maintenance.
en
2
Printed: 08.07.2013 | Doc-Nr: PUB / 5070024 / 000 / 01

To avoid the risk of injury, use only genuine Hilti accessories and additional equipment.
Modification of the tool is not permissible.
NOTE
Observe the permissible operating and storage temperatures.
2.2 Display
The measurements, settings and tool status are shown in the display. When the tool is in measuring mode, the
measurements taken are shown at the bottom of the display area (the result line). When using a function, e.g. area
measurement, the distances measured are shown in the intermediate result lineandthecalculatedresultisshownat
the bottom of the display (the result line).
2.3 Display illumination
In low light conditions, the display is illuminated automatically as soon as a button is pressed. The display illumination
intensity is reduced to 50% after 10 seconds. If no button is pressed over a period of 20 seconds, the display
illumination switches off automatically.
NOTE
Illumination of the display consumes battery power. Shorter battery life is therefore to be expected when this feature
is used frequently.
2.4 Basic principle
The distance is measured along a laser beam emitted by the tool to the point at which the beam strikes a reflective
surface. The target from which the measurement is taken is clearly identified by the red laser measuring spot. The
range of the tool depends on the reflectance and structure of the target surface from which measurements are taken.
2.5 Measuring principle
The tool emits a visible laser beam carrying signal pulses which are reflected by the target. The time between reflected
pulses is used as a basis for determining the distance.
This measuring principle permits highly accurate and reliable measurement of distances to objects without need for
special reflectors.
2.6 Standard measuring display mode
Standard measuring display mode is always activated when the “On/off” or “Measure” button is pressed to switch the
tool on.
2.7 Symbols in the display
Temperature Temperature too high
(>+50°C) / too low (<-10°C). Allow the tool to cool down or warm up.
Unfavorable conditions, poor signal Insufficient reflected laser
light. Observe the minimum measuring dis- tance(50mmfromthefrontedgeofthe
tool); clean the lenses; take measure-
ments from a different surface or use a
target plate.
General hardware error Switch the tool off and on again. If the fault persists, please contact Hilti
Service.
2.8 Control panel
Measure button Activates the laser beam.
Begins distance measurement.
Activates continuous measuring mode (long press, approx. 2 sec.).
Stops continuous measuring mode.
Plus button Initiates distance, area and volume addition.
Adds distances in standard measuring and painter’s measuring modes.
Adds areas and volumes in the relevant modes.
en
3
Printed: 08.07.2013 | Doc-Nr: PUB / 5070024 / 000 / 01

Minus button Initiates distance, area and volume subtraction.
Subtracts distances in standard measuring and painter’s measuring
modes.
Subtracts areas and volumes in the relevant modes.
FNC button Always activates the previously used function.
Press the button repeatedly to activate or select the functions one after
the other (when no measurements have been taken).
When measurements have already been taken: Deletes all measurements
and restarts the function.
Stops continuous measuring (tracking).
Delete (clear) button The C‑button has various
functions depending on op-
erating mode.
Stops continuous measuring (tracking).
Clears the standard measurement display.
Clears the last measurement and returns to “Functions”.
Clears data memory (long press when data memory is displayed).
Ends the function if no measurements have been taken.
On/off button When the tool is switched off, press the button briefly to switch it on.
When the tool is switched off, press and hold the button to activate the
menu.
When the tool is switched on, press the button briefly to switch it off.
Reference button Switches between the various measuring reference points (front, tripod
thread on the underside, rear).
2.9 Battery condition indicator
Number of segments shown Charge status in %
4= 100 % capacity
3= 75 % capacity
2= 50 % capacity
1= 25 % capacity
0 Fully discharged
2.10 Items supplied as standard
1 PD 42 laser range meter
1 Hand strap
1 PDA 51 target plate
2Batteries
1 Battery compartment key
1 Operating instructions
1 Manufacturer’s certificate
2.11 PUA 60 laser visibility glasses
The laser visibility glasses have no protective function and thus do not protect the eyes from laser beams. As these
glasses limit color vision they must not be worn by persons driving on a public road and must not be used to look
directly into the sun.
The PUA 60 laser visibility glasses improve laser beam visibility considerably.
en
4
Printed: 08.07.2013 | Doc-Nr: PUB / 5070024 / 000 / 01

2.12 PDA 50 / 51 / 52 target plate
The PDA 50 target plate is made of durable plastic with a special reflective coating. Use of the target plate is
recommended at distances greater than 10 m in poor light conditions.
The PDA 51 target plate has no reflective coating and its use is recommended in poor light conditions and at short
distances. The PDA 52 target plate is equipped with the same reflective coating as the PDA 50 but is considerably
larger in size (A4 format, 210 x 297 mm). This makes it much easier to aim the tool at the target plate over long
distances.
NOTE
For reliable distance measurements, care should be taken to ensure that the laser beam strikes the target plate at
right angles as far as possible. The laser spot on the target plate and the measuring reference point (starting point)
may otherwise be in different planes (parallax error).
NOTE
When the target plate is used and very high accuracy is required, 1.2 mm should be added to the measurement
obtained.
2.13 PDA 71 measuring extension
The measuring extension is made from aluminium and is equipped with a non-conductive plastic grip. The screw on
the measuring extension should be screwed into the threaded bush on the rear contact surface of the PD 42. When
the measuring extension is screwed onto the tool, the rear reference is then relocated to the tip of the measuring
extension, i.e. the rear reference is extended by 1270 mm (50 inches).
3 Insert tools, accessories
Designation Description
Target plate PDA 50
Target plate PDA 51
Target plate PDA 52
Measuring extension PDA 71
Designation Description
Hand strap PDA 60
Soft pouch PDA 65
Laser visibility glasses PUA 60
4 Technical data
Right of technical changes reserved.
Technical data Values
Power supply 3V DC AA-size batteries
Battery condition check Battery condition indicator with 4 segments show-
ing 100%, 75%, 50%, 25% charge : No segments
shown: The batteries are exhausted
Measuring range 0.05…200 m
Typical measuring range without target plate Drywall panel, white: 100 m
Concrete, dry: 70 m
Brick, dry: 50 m
Accuracy Typically ±1.0 mm for single and continuous measure-
ment
Smallest unit displayed 1 mm
en
5
Printed: 08.07.2013 | Doc-Nr: PUB / 5070024 / 000 / 01

Technical data Values
Beam diameter Beam length 10 m: Max. 6 mm
Beam length 50 m: Max. 30 mm
Beam length 100 m: Max. 60 mm
Basic operating modes Single measuring, continuous measuring,
calculation/functions
Display Illuminated dot-matrix display with permanent indica-
tion of operating mode and battery condition
Laser Visible 635 nm, Output power less than 1 mW: Laser
Class 2: IEC/EN 60825-1:2007; Laser Class II CFR 21
§1040 (FDA)
Optical sight Side-mounted, with laser reference
Automatic cut-out Laser: 1 min
Tool: 10 min
Battery life Max. number of measurements with laser beam
switched on for a time of 10 s Alkaline 8,000…
10,000 NiMH 6,000…8,000
Operating temperature range -10…+50°C
Storage temperature -30…+70°C
Protection class (except battery compartment) IP 54 protection against dust and water jets
IEC 60529
Weight without batteries 170 g
Dimensions 120 mm x 55 mm x 28 mm
Menu / units Distance Area Volume
mMeters m² m³
cm Centimeters m² m³
mm Millimeters m² m³
In Inches, decimal Inches² Inches³
In ¹/₈ ¹/₈ inch Inches² Inches³
In ¹/₁₆ ¹/₁₆ inch Inches² Inches³
In ¹/₃₂ ¹/₃₂ inch Inches² Inches³
Ft Feet, decimal Feet² Feet³
Ft ¹/₈ Feet-inches-¹/₈ Feet² Feet³
Ft ¹/₁₆ Feet-inches-¹/₁₆ Feet² Feet³
Ft ¹/₃₂ Feet-inches-¹/₃₂ Feet² Feet³
Yd Yards, decimal Yards² Yards³
5 Safety instructions
In addition to the information relevant to safety given
in each of the sections of these operating instructions,
the following points must be strictly observed at all
times.
5.1 Basic information concerning safety
a) Do not render safety devices ineffective and do
not remove information and warning notices.
b) Keep laser tools out of reach of children.
c) Failure to follow the correct procedures when open-
ing the tool may cause emission of laser radiation in
excess of class 2. Have the tool repaired only at a
Hilti service center.
d) Check that the tool functions correctly each time
before use.
e) Operation of the tool in the proximity of pregnant
women is not permissible.
f) Measurements taken from surfaces with low reflectiv-
ity in highly reflective surroundings may be inaccur-
ate.
g) Measurements taken through panes of glass or other
objects may be inaccurate.
en
6
Printed: 08.07.2013 | Doc-Nr: PUB / 5070024 / 000 / 01
