HIMO C20 Mounting instructions

Use Manual
Please read the instruction manual carefully before using your bike
Do not use the bike until you know its performance. Please keep the
instruction manual properly

XXXXXXXXXXXXXXX
Notes for using
According to the regulations on the implementation of the road traffic safety law of the People's Republic
of China, e-bike rider must be at least 16 years old.
When driving in the non-motorized lane, the maximum speed shall not exceed 15km/h;On roads
without non-motorized lanes, drive on the right side of the roadway.
Don't cause injury by lending your bike to someone who can't handle it.
Passengers or goods shall be carried according to laws and regulations.
Riding in rain and snow, the braking distance will be extended, pay attention to slow down;Avoid
traveling in bad weather such as heavy rain.
Before riding, check the braking system and clean the reflector to avoid blocking.
Obey traffic rules strictly
Safe of using the product
Please strictly abide by the traffic laws and regulations, prepare helmets, protective
equipment and other protective equipment before riding, and pay attention to driving
safety
Do not ride with one hand or two hands away from the handle.
Do not park in building doors, evacuation staircases, walkways, and safety exits.
Do not charge inside residential building and park, should be far from combustible when
charging, please charge according to regulation time, charging time should not be too long.
Correct use and maintenance of batteries, old batteries can not be disassembled without
authorization, should be organized by the professional departments recycling. Know how
to use charger and warning terms, use original charger.
When adjusting the saddle position, be careful not to expose the safety mark line of the
saddle tube.
Preparation before riding
Whether the power circuit and lighting are good.
Whether the front and rear brake lever are
good.
Whether the handlebars and front and
rear wheels are in a tight state.Whether the
tire pressure is normal.
Cross country and extreme
sports are prohibited
Bike coding position

1470×610×1095mm
965mm
21.6kg
25km/h
≈80km
≈55km
0.654kW·h/100km
≤100kg
31±0.5V
15±1A
10Ah
36V
M
+
25A fuse
+48V
+48V
+5V
-
ACC
TX RX +5V
Electrical schematic
Motor
The controller
Overspeed alarm
The cathode
Overspeed warning signal
The cathode
The cathode
Power signal
Headlight signal
Booster sensor
Headlight
Display
Power interruption brake
The cathode
The signal of handle
The cathode
Note: long press the button for 3-5 seconds to turn on the
machine. After starting up,press the button again to turn
on the headlight and long press to turn off the machine.
Battery
Dimensions L*W*H
Front and rear wheel center distance
Max weight
Maximum design speed
Assisting rang
Electric range
Consumes electricity（100KM）
Loading weight
Motor Spec.
Under voltage protection
Over current protection
Controller Spec.
Battery Spec.
Main technical parameters of the bike
⑴ Under the condition of full power, loading weight is 75kg, the temperature is about 25℃, the environment of flat road is still
without wind, and the driving condition is measured at 15km/h uniform speed under the energy-saving mode. The actual
endurance will be different due to factors such as load, temperature, wind speed, road surface and operating.
Battery type
Capacity
Voltage
Lithium ion battery
250W
260r/min
36V
Brushless dc motor
Motor type
Rated power
Rated speed
Voltage
Knob
5A charging fuse
charging port of the battery.

Operation and use
Steps of using the pump
Folding steps
1. Open the seatclamp, pull out the
seat post
1.Push the handle switch upward and
open the handle outwards
2.Turn the handlebar to one side 3.Press the pedal inward 4.Flip the pedal and fold up
2.Unscrew the cap and extract the
cylinder assembly
3.Put the air nozzle firmly at the
valve nozzle
4.Flip the clasp 90 degrees hold the
cushion and start pumping

2 pcs
Press the power button, the light is blue, the power is about
70% to 100%
Press the power button, the light is green, the power is about
40-70%
Press the power button, the light is red, the power is about
10%-40%
If the light flashes, please charge in time
Check battery level
Taillight is designed as an independent switch.
Press the switch when using.
Prepare 1 suitable phillips screwdriver, 2 no. 7 batteries.
Remove the tail light, unscrew the front panel screw,
open the rear housing, and replace the batt
Buckle the rear shell, screw well, install it on the fixing ery.
plate, and finish replacing the battery.
Taillight opening and maintenance Change battery
Tail light
R/reflector
Switch
Cross screw driver
No. 7 battery
Charging cover
Battery button
Battery indicator light

Display and riding mode
Dashboard introduction
Switch button Speed
The speedometer
Real-time power
Riding mode (assist/medium speed/high speed)
Mode button
Mileage accumulated (switching)
Subtotal mileage (switching)

Electric riding Parking mode
Long press the switch for 3 seconds
to start the bike;
The first default gear is "ECO"
assisted riding mode;
This mode can be started by
pedaling for two laps.
Start the electric bike;
Press the mode button to switch the
mode to the gear of "MID" medium
speed electric riding mode;If the
speed exceeds 5km/h, turn the
handle to start the mode.
Press the mode button to switch the
mode to the gear of "HIGH" high-
speed electric riding mode;If the
speed exceeds 5km/h, turn the
handle to start the mode.
Long press the switch for 3
seconds to shut down the electric car;
Ride with pedal
Electric assist riding
Normal riding
In the startup state;
Press the mode button for 3
seconds to switch to park (P)
and open park mode.
Long press the mode button for 3 seconds
to close the parking mode.
In park mode, power is not
available in assist or electric ride
mode.

+
1-2
3-4
5-6
Transmission using
Transmission diagram
When using a gear system, try not to skip gears, which can easily damage the gear. It is not possible to change two gears at a time above, should be
a level of adjustment, can better protect the gear system.
Do not reverse the gear system when the bike stops running, or when it is going downhill. This will not only be bad for the gear system, but also
may cause accidents.
If it is their gear fault, or gear is not accurate situation, will affect the performance of the transmission, at this time should be timely to the
professional bike shop maintenance, in case of aggravation of the fault.
When using the transmission system, also pay attention to the following details
Gear SpeedPower
Relaxed Slow
Fast
ModerateModerate
Hard
To speed up, start with a lower gear and shift to a higher gear as you speed up
When going uphill, the speed will decrease and the gear will be lowered to maintain a certain
pedal strength
Downwind will speed up, increase gear to maintain a certain degree of pedal strength
The above is riding advice, according to personal habits to reasonable use of gear
Shift up
-Shift down
Gear pointer

When using a gear system, try not to skip gears, which can easily damage the gear. It is not possible to change two gears at a time above, should be
a level of adjustment, can better protect the gear system.
Battery instructions
Battery removal and installation
First place one end of the battery in the
slot
Aim the other end of the battery at the
charging port, press it gently and fasten
the latch
Key return, battery installed
Turn the key, the battery pops up,
and the battery is taken out
Battery charging
Open the soft cover on the side of the battery
The power supply pin of the charger is
inserted into the charging port of the battery,
and the power supply pin at the other end is
connected to the power supply
When charging, the charger status light is red
When the battery is fully charged, the charger
status light is green and the charging is finished
Unplug the charger for safekeeping and
close the soft cover
If the battery is charged in the bike, please turn off
the instrument power
The power supply plug
Power supply pin
lamp
Charging port
Soft cover
Key
Buckle
Plug
Frame charging port
Charging port

Before use, confirm that the battery model is the original battery of the whole bike, do not use any other brand of battery.
Check the appearance of lithium battery intact, no damage, leakage, heat and water, smoke and other obvious phenomena.
In order to ensure the safety of transportation, the battery's output power is about 30%. Due to the self-consumption during the transportation
and storage cycle, the battery is low or no electricity in the first use. This is a normal phenomenon.
About batteries
Note before use of lithium battery
The best operating environment is 10℃-45℃
At low temperature, available capacity of lithium battery will decrease to different degrees. The specific reference degree is as follows:
The available capacity is about 70% at -10℃, 85% at 0℃and 100% at 25℃.If the battery has odor, heat, deformation and other abnormal
conditions, please stop using immediately, away from the battery and contact the after-sales department.
The battery is not a part that can be repaired by the user. If there is any abnormal
phenomenon, please contact the after-sales department for maintenance.
Disassembling the battery without permission will not be covered by the three-pack
policy and may cause the battery to generate heat, smoke, fire or explosion.
Using the environment
Warning

Charger port of the battery
When the battery is placed on the bike, it will constantly consume the battery power. After the bike is placed for a period of time, the meter
shows that the decrease of the battery power is normal.
Please store the battery in the ambient temperature from 0℃to 25℃. Do not store the battery in an environment higher than 45℃,
or it will cause irreversible
capacity decay of the battery.If the bike is not in use for a long time (such as winter, summer or other special circumstances), the battery
must be taken out and stored separately and charged regularly. Otherwise, the battery may be completely exhausted and irreversible damage
may occur. For such problems, the battery fault will not be within the scope of three guarantee.
The best storage capacity for a battery is 50%. Long-term storage of less than 10% or more than 90% of the battery will lead to irreversible
capacity decay.
Avoid storing batteries in hazardous locations. Falling may cause uncontrolled damage to the battery interior and may cause battery leakage,
heat, smoke, fire, or explosion.
Storage environment
Use the original charger to charge the battery. Do not use other brand or model charger to charge the battery.
Please charge the battery at the ambient temperature of 10℃~ 40℃to ensure that there are no flammable substances around and
good ventilation.
Charging time indicates that if the charging time of the battery is less than 12 hours, overcharging will affect the battery life and there are
safety risks.
In the early stage of charging, the electric quantity rises quickly, while in the later stage, it is the procedure set for charging safety, which is the
normal situation.
When charging in winter, the outdoor temperature is relatively low. When the environment is below 0℃, the battery will stop charging.
This is a normal phenomenon.
Outdoor charging is strictly prohibited in bad weather.
During the charging process, the charger has a temperature rise effect, and the surface temperature is relatively high, which is a normal
phenomenon. Please feel free to use it, and pay attention to avoid children touching it.

Description of component
Display
Battery
Head light
Front disc brake
Folding stem
Saddle
Rear disc brake
Motor
Gear system
folding pedal
License plate integral
tail light
seat upright pump
Controller
Variable speed indicator

Solutions of trouble
Bike is not powered
1.The bike is in the brake status 2.In the parking status
3.The speed did not reach 5km/h 4. Startup switch fault
1.Check whether the battery plug is properly inserted
2. Battery undervoltage, charge the battery
1.Whether the brake lever is on the brake 2.Remove P mode
3.Manpower riding to 5km/h 4.Please contact after-sales service
Problems Reasons for the problem Solution way
When the power is turned on ,
the bike can not be powered on
Turn on the power and turn on
the handlebar,motor does not start
Insufficient mileage
Battery fails to charge
Instrument no display
1.Battery undercharge 2.Tire pressure deficiency
3.Frequent brake start 4.Battery aging or normal
5.Low ambient temperature,Battery capacity attenuation
1.No power supply for bike 2.Power converter damaged
3.Instrument faults
1.Check if the plug is loose
2.Wait for the battery to return to charging temperature
3.Wait for the battery to return to charging temperature
1.Check if the charger damage or not
2.Check tire pressure before using
3.Develop good driving habits 4.Replace the battery
5.Belong to normal phenomenon
1.Check that the battery is plugged properly
2.Battery undervoltage, charge the battery
3.Contact after-sales service to replace damaged parts
1.The charger is not plugged in properly
2.Battery temperature is too low
3.Battery temperature is too high

Maintenance and repair
Whether the fastener is locked or not, whether the joints of all parts are normal:
Whether the tread pattern of the tire is worn and cracked, whether the front and rear tire pressure is appropriate,
Whether the drive system is smooth;
Whether the brake system is working properly.
Regular bike inspection
When this product is not in use for a long time, please do not store it in outdoor environment, under strong light
and below zero, and keep it at least 2m away from heat source (heating equipment, etc.).
Store in a dry, clean, well-ventilated indoor environment where the temperature is 10℃~ 45℃and the relative humidity is no more than 90%.
If you do not use the bike for a long time, pay attention to regular charging (generally about two months apart) to maintain battery performance;
This product should not contact with corrosive liquid to avoid any mechanical impact and heavy weight.
Bike storage method
Should not be subjected to severe mechanical impact, exposure to the sun, rain, chemical corrosive substances and harmful gases during
transportation；
During the process of loading and unloading, the products should be handled with care and be strictly protected against throwing, tumbling
and heavy weight.
The transportation

After-sales service
According to <Product quality of the People's Republic of China>&<Law of the People's Repulic of China on the
protection of user's right and interests>and the regulation of after sales service,the after sales service for HIMO
electric scooter is as below:
If the goods are rejected or intercepted due to non-quality reasons after shipment, the user shall bear the round-trip freight.
Within 7 days after receipt, because of quality problems, in the case of does not affect the goods in good condition (affect the situation of the
goods in good condition including but not limited to: guarantee certification and invoice lost, artificial damage, maintenance and protection
label damage, product appearance, or the outer packing damage, 10 km mileage super, the accessory missing accessories, etc.).Return
freight and wear and tear shall be borne by the customer.If the packaging is lost or damaged, the customer shall bear the original
packaging cost (excluding the packaging cost incurred by logistics during return).
If the goods are returned or replaced due to quality problems within 7 days after signing and receiving, the return freight shall be borne by
the merchant. Offline channel purchase products do not support seven days without reason return.
Free reason in return within 7 days
Do not flush with water to avoid the risk of accident caused by wet internal electronic components and wiring;
Please use neutral cleaner, wipe paint or plastic parts surface dirt with a cloth, and then use dry cloth to wipe;
Please use lubricating oil to wipe the metal parts of the bike body for maintenance;
Do not oil the brake parts to avoid causing brake failure and dangerous.
Maintenance and cleaning instructions

No return for cycling more than 100 km;
It can be replaced within 15 days due to quality problems;
Beyond 15 days, within the warranty period, can be repaired.
During the warranty period, HIMO official customer service center will provide you with free after-sales service.If the service period and scope of
"three guarantees" are exceeded, HIMO official customer service center will provide you with paid after-sales service according to the local market
situation and maintenance price.
If the product you purchased cannot drive due to quality problems, the HIMO official customer service center will provide you with maintenance
services.
The warranty period of online sold products shall start from the date of delivery receipt signed by the user.
The warranty policy

During the warranty period, HIMO official customer service center will provide you with free after-sales service.If the service period and scope of
"three guarantees" are exceeded, HIMO official customer service center will provide you with paid after-sales service according to the local market
situation and maintenance price.
If the product you purchased cannot drive due to quality problems, the HIMO official customer service center will provide you with maintenance
services.
The warranty period of online sold products shall start from the date of delivery receipt signed by the user.
Non-warranty policy
The following circumstances are not within the scope of warranty service, we will provide you with paid after-sales service.
Three guarantees of validity have been issued;Missing or changed invoice;Damage caused by force majeure.
Repair, misuse, collision, negligence, abuse, accident, modification, incorrect use of this product without HIMO's approval, frame serial
number destroyed.
The model of "three guarantees" certificate is inconsistent with or changed from the model of the repaired product;Do not follow the instructions
for proper maintenance.
Due to improper use, direct impact deformation;External force collision or car crash resulting in parts damage;Puncture and air leakage caused
by spikes, glass, sharp small stones, etc.Consumable wear and tear is not replaced in time, causing damage to other parts;The surface of the
cushion is scratched;Violence or man-made damage to the frame, are not covered by the warranty.
The surface of the paint on the frame and parts may be corroded due to rain, collision, friction and other external environmental factors. The
paint may fall off,or the storage place is not good. The surface of the paint may flake after long-term use, and the metal surface or plastic parts
may fade naturally.
Exceeding the scope of use, such as extreme road conditions, performing special effects, climbing stairs, jumping and other abnormal riding
actions, and causing damage to parts or functional failure;
Due to over-limit use caused by deformation or cracking of the frame, also does not belong to the scope of warranty.
Note: HIMO electric vehicle after-sales service policy is final interpreted by Shanghai HIMO electric technology co., LTD.

24 month
24 month
12 month
12 month
Tire, Inner tube, Saddle, Chain,
Brake plate, Brake wire,Grip,
Reflector ,Pedal, and accessories.
Battery
Frame Fork
Responsibilities and obligations
Three guarantee policy
Item Allowance for depreciation The warranty period
Hub,Freewheel,Chainwheel,Crank,
BB Set,handlebar,Folding stem,
Seat post, Head set, Wire
Display,Controller , Head light,
Charger
From the date of receipt and signature, the HIMO authorized
after-sales service center will provide after-sales service for
you within the warranty period
Natural open welding, off welding, fracture, deformation, paint off
due to poor manufacturing quality problems
Distortion, breakage, fading, blistering, cracking, paint detachment,
etc due to the poor manufacturing quality problem
Performance failure or quality problem caused by the
product and cannot be repaired
Quick-wear part Consumables are
not guaranteed

The HIMO guarantee service standard for electric vehicle parts exceeds the specified service period and scope.
Failure or damage of the HIMO electric vehicle product caused by the user's failure to properly use, drive, maintain and adjust the HIMO
electric vehicle product according to the instructions.
Products sold due to rain, snow immersion, smoke, drugs, chemicals corrosion caused by damage or natural product failure or damage.
Loss is not covered by the warranty.And failure or damage caused by force majeure (including but not limited to earthquake, typhoon, fire,
flood, social event, group event, violent crime, etc.) of the products sold.
The battery was not normally used and maintained by the user, and the battery was placed for a long time (the battery was connected to the
vehicle for a month, and the initial power of the battery was stored separately for less than 50% and more than 3 months), and the battery was
not charged in time, resulting in battery feeding and undervoltage that could not be repaired.
The user refits, disassembles, repairs or destroys the whole product and the normal use of the parts.
The HIMO electric vehicle parts are damaged or the circuit or circuit configuration is changed without permission by the user using
non-original parts.
Product failure or damage caused by human factors such as car crash, car crash, overload and overspeed.
There is no valid three-guarantee voucher, after-sales service card or purchase invoice, voucher or card number inconsistent with the product.
Warranty exemption scope
If the product is sold in the following circumstances, it is not within the scope of warranty service, and users
shall pay for maintenance and related services:

The principal:Shang hai HIMO Electric Technology Co. LTD
Manufacturers:Tianjin Fuji-ta Technology Co. LTD
Manufacturer add:Taian road and AIMA road, south distr development zone, tianjin
Service number:400-182-9808
HIMO official public number
