Hirschmann EAGLE One User manual

Installation EAGLE One
Release 06 12/2018
Technical support
https://hirschmann-support.belden.com
User Manual
Installation
Industrial Ethernet Firewall
EAGLE One

The naming of copyrighted trademarks in this manual, even when not specially indicated, should
not be taken to mean that these names may be considered as free in the sense of the trademark
and tradename protection law and hence that they may be freely used by anyone.
© 2018 Hirschmann Automation and Control GmbH
Manuals and software are protected by copyright. All rights reserved. The copying, reproduction,
translation, conversion into any electronic medium or machine scannable form is not permitted,
either in whole or in part. An exception is the preparation of a backup copy of the software for
your own use.
The performance features described here are binding only if they have been expressly agreed
when the contract was made. This document was produced by Hirschmann Automation and
Control GmbH according to the best of the company's knowledge. Hirschmann reserves the right
to change the contents of this document without prior notice. Hirschmann can give no guarantee
in respect of the correctness or accuracy of the information in this document.
Hirschmann can accept no responsibility for damages, resulting from the use of the network
components or the associated operating software. In addition, we refer to the conditions of use
specified in the license contract.
You can get the latest version of this manual on the Internet at the Hirschmann product site
(www.hirschmann.com).
Hirschmann Automation and Control GmbH
Stuttgarter Str. 45-51
72654 Neckartenzlingen
Germany
EAGLE One 30.11.2018

Installation EAGLE One
Release 06 12/2018 3
Contents
Safety instructions 5
About this manual 16
Key 16
1 Description 17
1.1 General description 17
1.2 Device name and product code 18
1.3 Device view 21
1.4 Power supply 22
1.5 Ethernet ports 23
1.5.1 10/100 Mbit/s twisted pair port 23
1.5.2 100 Mbit/s F/O port 23
1.6 Display elements 24
1.6.1 Device state 24
1.6.2 Additional status information 25
1.6.3 Port state 25
1.7 Management interfaces 26
1.7.1 V.24 interface (external management) 26
1.7.2 ACA21-USB interface 27
1.8 Input/output interfaces 27
1.8.1 Signal contact 27
1.8.2 Digital input 27
2 Installation 28
2.1 Overview 28
2.2 Checking the package contents 28
2.3 Installing and grounding the device 29
2.3.1 Installing the device onto the DIN rail 29
2.3.2 Mounting on a vertical flat surface 30
2.3.3 Grounding the device 30
2.4 Connecting the terminal blocks 31
2.4.1 Connecting the power supply and signal lines 31
2.4.2 Wiring the digital input (optional) 33
2.5 Operating the device 33
2.6 Connecting data cables 34
3 Configuration 35

4Installation EAGLE One
Release 06 12/2018
3.1 Making basic settings 35
3.2 Firewall and VPN functions 35
3.2.1 Firewall functions 35
3.2.2 VPN functions 36
3.3 Operating modes 36
3.3.1 Delivery state 36
3.3.2 Transparent mode 37
3.3.3 Router mode 37
3.3.4 PPPoE mode 37
3.4 Starting Configuration 37
4 Monitoring the ambient air temperature 39
5 Maintenance and service 40
6Disassembly 41
7 Technical data 42
A Further support 52

Installation EAGLE One
Release 06 12/2018 5
Safety instructions
General safety instructions
You operate this device with electricity. Improper usage of the device
entails the risk of physical injury or significant property damage. The pro-
per and safe operation of this device depends on proper handling during
transportation, proper storage and installation, and careful operation and
maintenance procedures.
Before connecting any cable, read this document, and the safety
instructions and warnings.
Operate the device with undamaged components exclusively.
The device is free of any service components. In case of a damaged
or malfunctioning the device, turn off the supply voltage and return the
device to Hirschmann for inspection.
Qualification requirements for personnel
Only allow qualified personnel to work on the device.
Qualified personnel have the following characteristics:
Qualified personnel are properly trained. Training as well as practical
knowledge and experience make up their qualifications. This is the
prerequisite for grounding and labeling circuits, devices, and systems
in accordance with current standards in safety technology.
Qualified personnel are aware of the dangers that exist in their work.
Qualified personnel are familiar with appropriate measures against
these hazards in order to reduce the risk for themselves and others.
Qualified personnel receive training on a regular basis.
Intended usage
Use the product only for the application cases described in the
Hirschmann product information, including this manual.
Operate the product only according to the technical specifications.
WARNING
UNCONTROLLED MACHINE ACTIONS
To avoid uncontrolled machine actions caused by data loss, configure all
the data transmission devices individually.
Before you start any machine which is controlled via data transmission, be
sure to complete the configuration of all data transmission devices.
Failure to follow these instructions can result in death, serious injury,
or equipment damage.

6Installation EAGLE One
Release 06 12/2018
See “Technical data” on page 42.
Connect to the product only components suitable for the requirements
of the specific application case.
National and international safety regulations
Verify that the electrical installation meets local or nationally applicable
safety regulations.
Grounding the device
Grounding the device is by means of a separate ground connection on the
device.
Ground the device before connecting any other cables.
Disconnect the grounding only after disconnecting all other cables.
The overall shield of a connected shielded twisted pair cable is connected
to the ground connector on the front panel as a conductor.
Supply voltage
The supply voltage is electrically isolated from the housing.
Connect only a supply voltage that corresponds to the type plate of
your device.
Every time you connect the electrical conductors, make sure that the
following requirements are met:
The power supply conforms to overvoltage category I or II.
The power supply has an easily accessible disconnecting device
(e.g., a switch or a plug). This disconnecting device is clearly iden-
tified. So in the case of an emergency, it is clear which disconnect-
ing device belongs to which power supply cable.
The electrical wires are voltage-free.
The power supply is Class 2 compliant.
The supply voltage inputs are designed for operation with safety
extra-low voltage. Connect only SELV circuits with voltage restric-
tions in line with IEC/EN 60950-1 to the supply voltage connec-
tions.
Supply with AC voltage:
A fuse is located in the outer conductor of the power supply.
The neutral conductor is on ground potential. Otherwise, a fuse is
also located in the neutral conductor.
Regarding the properties of this fuse: See “General technical data”
on page 42.

Installation EAGLE One
Release 06 12/2018 7
Supply with DC voltage:
A fuse suitable for DC voltage is located in the plus conductor of the
power supply.
The minus conductor is on ground potential. Otherwise, a fuse is
also located in the minus conductor.
Regarding the properties of this fuse: See “General technical data”
on page 42.
The wire diameter of the power supply cable is at least 1 mm²
(North America: AWG16) on the supply voltage input.
The cross-section of the protective conductor is the same size as
or bigger than the cross-section of the power supply cables.
The power supply cables used are permitted for the temperature
range required by the application case.
Relevant for North America:
Use 60/75 or 75 °C copper (Cu) wire only.
Internal fuses are triggered only in the case of a detected error in the
device. In case of damage or malfunction of the device, turn off the
supply voltage and return the device to the plant for inspection.
Input/output interfaces
Every time you connect the electrical conductors, make sure that the fol-
lowing requirements are met:
The electrical wires are voltage-free.
The connected voltage is limited by a current limitation device or a
fuse.
Observe the electrical threshold values for the signal contact.
See “General technical data” on page 42.
Observe the electrical threshold values for the digital input.
See “Digital input” on page 43.
Installation site requirements
Verify that there is at least 4 in (10 cm) of space above and below the
device.
Verify that there is at least 0.8 in (2 cm) of space on the right and left
sides of the device.
Install the device in a fire protected enclosure according to
EN 60950-1.

8Installation EAGLE One
Release 06 12/2018
Housing
Only technicians authorized by the manufacturer are permitted to open
the housing.
Never insert pointed objects (narrow screwdrivers, wires, etc.) into the
device or into the connection terminals for electric conductors. Do not
touch the connection terminals.
Keep the ventilation slits free to ensure good air circulation.
Install the device in the vertical position.
At ambient temperatures > 140 °F (60 °C):
The surfaces of the device housing may become hot. Avoid touching
the device while it is operating.
LED or laser components
LED or LASER components according to IEC 60825-1 (2014):
CLASS 1 LASER PRODUCT
CLASS 1 LED PRODUCT
CE marking
The labeled devices comply with the regulations contained in the following
European directive(s):
2014/30/EU (EMC)
Directive of the European Parliament and the council for standardizing the
regulations of member states with regard to electromagnetic
compatibility.
2011/65/EU (RoHS)
Directive of the European Parliament and of the Council on the restriction
of the use of certain hazardous substances in electrical and electronic
equipment.
In accordance with the above-named EU directive(s), the EU conformity
declaration will be at the disposal of the relevant authorities at the follo-
wing address:
Hirschmann Automation and Control GmbH
Stuttgarter Str. 45-51
72654 Neckartenzlingen
Germany
The device can be used in the industrial sector.
Interference immunity: EN 61000-6-2
Emitted interference: EN 55032
You find more information on technical and industry standards here:
“Technical data” on page 42

Installation EAGLE One
Release 06 12/2018 9
Warning! This is a class A device. This device can cause interference in
living areas, and in this case the operator may be required to take appro-
priate measures.
Note: The assembly guidelines provided in these instructions must be
strictly adhered to in order to observe the EMC threshold values.
Relevant for use in North America
Use this device solely in Class 2 Circuits.
Relevant for use in explosion hazard areas (Hazardous
Locations, Class I, Division 2)
The relay connections are to be installed and used within their Entity
Parameters as per the following Control Drawing 000174247DNR.
Avertissement - Risque d'explosion - Ne pas débrancher tant que le cir-
cuit est sous tension à moins que l'emplacement soit connu pour ne con-
tenir aucune concentration de gaz inflammable.
Avertissement - Risque d'explosion - La substitution de tout composant
peut rendre ce matériel incompatible pour une utilisation en classe I,
division 2.

10 Installation EAGLE One
Release 06 12/2018
1RQLQFHQGLYH¿HOGZLULQJSDUDPHWHUV
THE RELAY TERMINALS ARE DEPENDENT UPON THE FOLLOWING ENTITY
3$5$0(7(56
Vmax Imax CiLi
30 V 90 mA 3 nF 1 μH
CONTROL DRAWING to EAGLEONE and TOFINOXE series
devices for use in Hazardous Locations
Class I Division 2, Groups A, B, C, D
Rev. 0 2014-12-01 Document No.: 000174247DNR Page 1/2
DI (+) DI (-)
+24V (P2)
+24V (P1)
FAULT
OV
OV
Aufkleber MAC-Adresse
IP-Adresse
EAGLE One
USB
Power ACA LS/DA
Status RR
1 2 VPN
!
!
PB
1
2
V24
FAULT contacts
USB pin 4
USB pin 1
7KH86%FRQQHFWRULVIRUWHPSRUDU\FRQQHFWLRQ
RQO\'RQRWXVHFRQQHFWRUGLVFRQQHFWXQOHVV
DUHDLVNQRZQWREHQRQKD]DUGRXV&RQQHFWLRQ
RUGLVFRQQHFWLRQLQDQH[SORVLYHDWPRVSKHUH
FRXOGUHVXOWLQDQH[SORVLRQ
2UGLQDU\/RFDWLRQ1RQ+D]DUGRXV$UHD
1RQH[SORVLYH$WPRVSKHUH
&ODVV,'LYLVLRQ *URXSV$%&'+D]DUGRXV/RFDWLRQ
The earth conductor must be at least of the same wire size
(mm² or AWG) as the supply conductors.
Any
EAGLEONE-0200xxx
or
TOFINOXE-200xxx-
device

Installation EAGLE One
Release 06 12/2018 11
7KHPD[LPXPFDEOHOHQJWKKDVWREHGHWHUPLQHGDVIROORZV
DPD[&DEOH/HQJWK/D/i&DEOHL
³&DEOHL´GHQRWHVWKHLQGXFWDQFHSHUXQLWOHQJWKRIXVHGFDEOHDQG
EPD[&DEOH/HQJWKPD[&DEOH/HQJWK&D&i&DEOH&
³&DEOH&´GHQRWHVWKHFDSDFLWDQFHSHUXQLWOHQJWKRIXVHGFDEOH
7KHORZHUYDOXHRIDDQGELVWRDSSO\
CONTROL DRAWING to EAGLEONE and TOFINOXE series
devices for use in Hazardous Locations
Class I Division 2, Groups A, B, C, D
Rev. 0 2014-12-01 Document No.: 000174247DNR Page 2/2
68,7$%/()2586(,1&/$66,',9,6,21*52836$%&'+$=$5'286
/2&$7,21625121+$=$5'286/2&$7,21621/<
)RUXVHLQ+$=$5'286/2&$7,216RQO\DOORZHGIRUPRGHO1RVZKLFKDUH
ODEHOOHGDFFRUGLQJO\
  1RQLQFHQGLYH¿HOGZLULQJFLUFXLWVPXVWEHZLUHGLQDFFRUGDQFHZLWKWKH   1DWLRQDO(OHFWULFDO&RGH1(&1)3$DUWLFOH   86%$1'5(/$<&217$&76)$8/7,QVWDOOSHU&RQWURO'UDZLQJ    '15
:$51,1*(;3/26,21+$=$5'±68%67,787,212)$1<&20321(1760$< 
 ,03$,568,7$%,/,7<)25&/$66,',9,6,21
:$51,1*(;3/26,21+$=$5''2127',6&211(&7(48,30(17:+,/(7+(
 &,5&8,7,6/,9(2581/(667+($5($,6.12:172%()5((2)  ,*1,7$%/(&21&(175$7,216
1RWHV
7KHQRQLQFHQGLYH¿HOGZLULQJFLUFXLWFRQFHSWDOORZVLQWHUFRQQHFWLRQRIQRQLQFHQGLYH¿HOGZLULQJ
DSSDUDWXVDQGDVVRFLDWHGQRQLQFHQGLYH¿HOGZLULQJDSSDUDWXVXVLQJDQ\RIWKHZLULQJPHWKRGV
SHUPLWWHGIRUXQFODVVL¿HGORFDWLRQVZKHQFHUWDLQSDUDPHWULFFRQGLWLRQVDUHPHW
&DSDFLW\&D&i&&DEOH,QGXFWLYLW\/DLi+ L&DEOH
Manufactured in 72654 Neckartenzlingen / Germany by Hirschmann Automation and
Control GmbH.
DOM: ww/yy (Date of manufactur w - week, y - year. Refer to the device label).

12 Installation EAGLE One
Release 06 12/2018
ATEX directive 2014/34/EU – specific regulations for safe
operation
In Ex Zone 2, only the devices with a corresponding label may be opera-
ted.
The devices are to be installed and used according to the European
Directive 2014/34/EU. Details see the next 2 pages.

Installation EAGLE One
Release 06 12/2018 13
Use of EAGLEONE and TOFINOXE series devices
according to the European directive 2014/34/EU
DI (+) DI (-)
+24V (P2)
+24V (P1)
FAULT
OV
OV
Aufkleber MAC-Adresse
IP-Adresse
EAGLE One
USB
Power ACA LS/DA
Status RR
1 2 VPN
!
!
PB
1
2
V24
FAULT contacts
USB pin 4
USB pin 1
Ordinary Location, Non-Hazardous Area,
Nonexplosive Atmosphere
THE Fault Relays are tested as Sealed Device according to
ATEX EN 60079-15. Switching current max. 1 A,
(resistive load)
Switching voltage max. 60 V DC or 30 V AC, SELV
The USB connector is for temporary connection
only. Do not use, connect, or disconnect unless
area is known to be non-hazardous. Connection
or disconnection in an explosive atmosphere
could result in an explosion.
Temperature Code: T4
Ambient Temperature rating:
Ta: 0 °C to +60 °C for “S” types 7Dí&WR&IRU“T” or “E” types
íUHIHUWRWKHW\SHGHVLJQDWLRQRQWKHGHYLFH
(item 18 of product code: “Temperature range”)
Atex Zone 2 Explosive Atmosphere
The earth conductor must be at least of the same wire size
(mm² or AWG) as the supply conductors.
Any
EAGLEONE-0200xxx
or TOFINOXE-200xxx- device

14 Installation EAGLE One
Release 06 12/2018
Use of EAGLEONE and TOFINOXE series devices
according to the European directive 2014/34/EU
For Use in explosive atmospheres according to the European directive 2014/34/EU:
Applied Standards:
The Use in Hazardous Locations with explosive atmospheres is only allowed for EAGLEONE or
TOFINOXE model No´s. which are labeled accordingly - including “([ II 3 G”,
“Ex nA IIC T4 Gc” “DEKRA 13ATEX0184X”.
EN60079-0, 2012 EN60079-15, 2010
SPECIAL CONDITIONS FOR SAFE USE:
The modules shall be installed in a suitable enclosure providing a degree of protection of at
least IP54 according to EN 60529, taking into account the enviromental conditions under
which the equipment will be used.
Provisions shall be made to prevent the rated voltage from being exceeded by transient
disturbances of more than 119 V.
When the temperature under rated conditions exceeds 70 °C at the cable or conduit entry
SRLQWRU&DWWKHEUDQFKLQJSRLQWRIWKHFRQGXFWRUVWKHWHPSHUDWXUHVSHFL¿FDWLRQRIWKH
selected cable shall be in compliance with the actual measured temperature values.
Manufactured in 72654 Neckartenzlingen / Germany by Hirschmann Automation and
Control GmbH.
DOM: ww/yy (Date of manufactur w - week, y - year. Refer to the device label).

Installation EAGLE One
Release 06 12/2018 15
FCC note:
This device complies with part 15 of the FCC rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference; (2) this device must accept any interference received, inclu-
ding interference that may cause undesired operation.
Appropriate testing has established that this device fulfills the require-
ments of a class A digital device in line with part 15 of the FCC regula-
tions.
These requirements are designed to provide sufficient protection against
interference when the device is being used in a business environment.
The device creates and uses high frequencies and can also radiate these
frequencies. If it is not installed and used in accordance with this opera-
ting manual, it can cause radio transmission interference. The use of this
device in a residential area can also cause interference, and in this case
the user is obliged to cover the costs of removing the interference.
Recycling note
After usage, this device must be disposed of properly as electronic waste,
in accordance with the current disposal regulations of your county, state,
and country.

16 Installation EAGLE One
Release 06 12/2018
About this manual
The “Installation” user manual contains a device description, safety instruc-
tions, a description of the display, and the other information that you need to
install the device.
The following manuals are available as PDF files on the Internet on the
Hirschmann product pages (www.hirschmann.com):
Installation user manual
Configuration user manual
Command Line Interface user manual
Reference manual for the graphical user interface
Key
The symbols used in this manual have the following meanings:
Listing
Work step
Subheading

Installation EAGLE One
Release 06 12/2018 17
1 Description
1.1 General description
The EAGLE One devices support the authentication, security and confiden-
tiality of communication within production networks, but also beyond com-
pany boundaries.
The EAGLE One devices support the following network modes:
Transparent mode
Router mode
PPPoE mode
The EAGLE One devices are used everywhere that security-sensitive net-
work cells require a connection from the internal network to the external net-
work. The EAGLE One devices are the link between the internal network and
the external network from which unauthorized access is possible. In its func-
tion as a link, the EAGLE One devices help you to protect the security-sen-
sitive cell from undesired data traffic along the connection to the external
network.
Typical uses are:
Helping protect individual production cells in a flat company network
Helping protect individual production cells in a routed company network
Coupling identical production cells to a company network
Connecting a production cell with the office network via a public network
Helping provide protected service access
Separation of machine common parts
You can choose from between a wide range of variants. You have the option
to set up your device individually based on different criteria:
Types of connectors
Temperature range
Certifications
The EAGLE One devices are designed for the special requirements of indus-
trial automation. They meet the relevant industry standards, provide very
high operational reliability, even under extreme conditions, and also long-
term reliability and flexibility.
The devices allow you to set up switched and routed industrial Ethernet net-
works that conform to the IEEE 802.3 standard.

18 Installation EAGLE One
Release 06 12/2018
The following installation options are available:
simply snapping them onto a DIN rail
Mounting on a vertical flat surface
The devices work without a fan.
There are convenient options for managing the device. Manage your devices
via:
Web browser
V.24 interface (locally on the device)
HiDiscovery (software for putting the device into operation)
SSH
Network management software (for example Industrial HiVision)
The Industrial HiVision Network Management software provides you with
additional options for smooth configuration and monitoring: You find
further information on the Internet at the Hirschmann product pages:
www.hirschmann.com/en/Hirschmann_Produkte/Industrial_Ethernet/
network-management-software/index.phtml
The device provides you with a large range of functions, which the manuals
for the operating software inform you about. You can download these
manuals as PDF files from the Internet on the Hirschmann product pages
(www.hirschmann.com).
1.2 Device name and product code
The device name corresponds to the product code. The product code is
made up of characteristics with defined positions. The characteristic values
stand for specific product properties.

Installation EAGLE One
Release 06 12/2018 19
Item Product characteristic Character-
istic value
Description
1 ... 8 Device EAGLEONE 2 port Eagle router
9–
10 ... 11 Number:
Fast Ethernet ports
02 2 × Fast Ethernet ports
12 ... 13 Number:
Gigabit Ethernet ports
00 0 × Gigabit Ethernet ports
14 ... 15 Ethernet port 1
INTERN
T1 1 × RJ45 socket for 10/100 Mbit/s twisted
pair connections
M2 1 × DSC multimode socket for 100 Mbit/s
F/O port
S2 1 × DSC singlemode socket for 100 Mbit/s
F/O port
16 ... 17 Ethernet port 2
EXTERN
T1 1 × RJ45 socket for 10/100 Mbit/s twisted
pair connections
M2 1 × DSC multimode socket for 100 Mbit/s
F/O port
S2 1 × DSC singlemode socket for 100 Mbit/s
F/O port
18 Temperature range E Extended with confor-
mal coating
−40 °F ... +158 °F
(−40 °C ... +70 °C)
S Standard +32 °F ... +140 °F
(0 °C ... +60 °C)
T Extended −40 °F ... +158 °F
(−40 °C ... +70 °C)
19 ... 20 Supply voltage DD 2 voltage inputs for redundant power
supply
Rated voltage range DC
12 V ... 48 V
Nominal voltage AC
24 V
21 ... 22 Certificates and declara-
tions
Note: You will find detailed information on the certificates
and declarations applying to your device in a separate
overview.
See table 2 on page 20.
23 ... 26 Software packages 0000 Basic Software-Packages
27 ... 28 Customer-specific ver-
sion
HH Hirschmann standard
29 Software configuration E Entry (Hirschmann Standard)
30 ... 34 Software version 05.3 Software version 05.3
XX.X Current software version
35 ... 36 Bug fix 00 Bugfix version 00
XX Current bugfix version
Table 1: Device name and product code

20 Installation EAGLE One
Release
06
12/2018
Application case Certificates and
declarations
Characteristic value
T9 TY U9 UT UX UY V9 VT VU VY W9 WX X9 Y9 Z9
Standard applications CE X X X X X XXXXXXXXXX
EN 60950-1 X X X X X XXXXXXXXXX
EN 61131-2 X X X X X XXXXXXXXXX
FCC XXXX X XXXXXXXXXX
UL508 X X X X XXX XXX
Oil and gas applications ATEX Zone 2 XX
ISA 12.12.01 –
Class I, Div. 2
XXX
Substation applications IEC 61850-3 XXXX
IEEE1613 XXXX
Navy applications GL X X X X X
Railway applications (track-
side)
EN 50121-4 X X X X
Table 2: Assignment: application cases, certificates and declarations, characteristic values
