Hisense RB11N6CSE Mounting instructions

English
USER’S OPERATION MANUAL
Before operating this unit, please read this manual
thoroughly, and retain for future reference
RB12A2CSE
RB11N6CSE

2
Contents
Safety and warning information...........2
Installing your new appliance...............9
Reversing the door..........................10
Description of the appliance...............14
Display controls.................................15
Helpful hints and tips..........................16
Cleaning and care...............................17
Disposal of the appliance....................18
Safety and warning information
For your safety and correct usage, before installing and
first using the appliance,read this user manual carefully,
including its hints and warnings.To avoid unnecessary
mistakes and accidents,it is important to make sure that all
people using the appliance are thoroughly familiar with its
operation and safety features. Save these instructions and
be sure that they remain with the appliance if it is moved or
sold,so that anyone using it throughout its life,will be
properly informed on its usage and safety notices.
For the safety of life and property,keep the precautions of
these user's instructions as the manufacturer is not
responsible for damages caused by omission.
According to EN standard
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved.Children shall not play with the
appliance.Cleaning and user maintenance shall not be
made by children without supervision.
Children aged from 3 to 8 years are allowed to load and
unload refrigerating appliances.
According to UL standard
This appliance is not intended for use by persons
Safety for children and others who are vulnerable people
●
●
Warranty.............................................20

3
(including children) with reduced physical,sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person being
responsible for their safety.
Children should be supervised to ensure that they do not
play with the appliance.
Keep all packaging away from children as there is a risk
of suffocation.
If you are discarding the appliance, pull the plug out of the
WARNING —This appliance is intended to be used
●
●
●
●
in household and similar applications such as
-staff kitchen areas in shops, offices and other working
environments;
-farm houses and hotels, motels and other residential type
environments;
-bed and breakfast type environments;
-catering and similar non-retail applications.
●WARNING — Do not store explosive substances such as
aerosol cans with a flammable propellant in this appliance.
●WARNING — If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent or similarly
socket, cut the connection cable (as close to the appliance
as you can) and remove the door to prevent children
playing from suffering an electric shock or from closing
themselves inside it.
●If this appliance, featuring a magnetic door seals, is to
replace an older appliance having a spring lock (latch)
on the door or lid, be sure to make the spring lock is
unusable before you discard the old appliance. This will
prevent it from becoming a death trap for a child.
General safety

4
qualified persons in order to avoid a hazard.
WARNING — Keep ventilation openings, in the appliance
WARNING — Do not damage the refrigerant circuit.
WARNING — Do not use electrical appliances inside the
food storage compartments of the appliance,unless they
are of the type recommended by the manufacturer.
WARNING — The refrigerant and insulation blowing gas
WARNING — Do not locate multiple portable socket-
●
enclosure or in the built-in structure, clear of obstruction.
●WARNING — Do not use mechanical devices or
other means to accelerate the defrosting process,
other than those recommended by the manufacturer.
●
●
●
are flammable. When disposing of the appliance,do so only
at an authorized waste disposal centre. Do not expose to
flame.
●WARNING — When positioning the appliance,ensure
the supply cord is not trapped or damaged.
●
outlets or portable power supplies at the rear of the
appliance.
Replacing the illuminating lamps
●WARNING — The illuminating lamps must not be
replaced by the user! If the illuminating lamps are
damaged, contact the customer helpline for assistance.
This warning is only for refrigerators that contain
illuminating lamps.
Refrigerant
The refrigerant isobutane (R600a) is contained within the
refrigerant circuit of the appliance, a natural gas with a high
level of environmental compatibility, which is nevertheless
flammable. During transportation and installation of the
appliance, ensure that none of the components of the
refrigerant circuit get damaged.

The refrigerant (R600a) is flammable.
WARNING — Refrigerators contain refrigerant and gases
-Avoid opening flames and sources of ignition.
-Thoroughly ventilate the room in which the appliance is
situated.
It is dangerous to alter the specifications or modify this
product in any way.
Any damage to the cord may cause a short circuit, fire,
and/or electric shock.
1. The power cord must not be lengthened.
2. Make sure that the power plug is not crushed or
damaged.
A crushed or damaged power plug may overheat and
cause a fire.
3. Make sure that you can access the main plug of the
appliance.
4. Do not pull the main cable.
5. If the power plug socket is loose, do not insert the power
plug. There is a risk of electric shock or fire.
6. You must not operate the appliance without the interior
lighting lamp cover.
7. The fridge is only applied with power supply of single
●
in the insulation. Refrigerant and gases must be disposed
of professionally as they may cause eye injuries or ignition.
Ensure that tubing of the refrigerant circuit is not damaged
prior to proper disposal.
The symbol is a warning and indicates the
refrigerant and insulation blowing gas are flammable.
WARNING : Risk of fire / flammable materials
If the refrigerant circuit should be damaged:
Electrical safety
5

6
Do not store flammable gas or liquids in the appliance,
When unplugging always pull the plug from the mains
Do not place food products directly against the air outlet
on the rear wall.
Store pre-packed frozen food in accordance with the
frozen food manufacture’s instructions.
The appliances manufactures storage recommendations
Frozen food can cause frost burns if consumed straight
phase alternating current of 115V/60Hz. If fluctuation of
voltage in the district of user is so large that the voltage
exceeds the above scope, for safety sake, be sure to apply
A.C. automatic voltage regulator of more than 350W to the
fridge. The appliance should be plugged into a dedicated
circuit and non GFCI or ARC fault protected outlet. Its plug
must match the socket with ground wire.
Daily use
●
there is a risk of an explosion.
●Do not operate any electrical appliances in the
appliance (e.g. electric ice cream makers, mixers etc.).
●
socket, do not pull on the cable.
●Do not place hot items near the plastic components of
this appliance.
●
●
●
should be strictly adhered to. Refer to relevant instructions
for storage.
●Do not place carbonated or fizzy drinks in the freezer
compartment as it creates pressure on the container, which
may cause it to explode, resulting in damage to the
appliance.
●
from the freezer compartment.
●Do not place the appliance in direct sunlight.
●Keep burning candles, lamps and other items with
naked flames away from the appliance so that do not set
the appliance on fire.

7
●
●
●
●
●
The appliance is intended for keeping food stuff and/or
beverages in normal household as explained in this
instruction booklet. You should take care when move it as
the appliance is heavy.
●Do not remove or touch items from the freezer
compartment if your hands are damp/wet, as this could
cause skin abrasions or frost/freezer burns.
Never use the base, drawers, doors etc. to stand on or as
supports.
Frozen food must not be refrozen once it has been
thawed out.
Do not consume ice popsicles or ice cubes straight from
the freezer as this can cause freezer burn to the mouth and
lips.
●To avoid items falling and causing injury or damage to
the appliance, do not overload the door racks or put too
much food in the crisper drawers.
●This refrigerating appliance is not intended to be used
as a a built-in appliance.
●Keep medications away from the freezer compartment
and away from the air vents to avoid formation of ice
crystals that can damage the medications. Do not store
medications at the refrigerator door because they will be
exposed to uneven temperature every time the
refrigerator door is opened.
Before maintenance, switch off the appliance and
disconnect the mains plug from the mains socket.
●Do not clean the appliance with metal objects, steam
cleaner,ethereal oils,organic solvents or abrasive
cleansers.
Caution!
Care and cleaning

8
It is advisable to wait at least four hours before
connecting the appliance to allow the oil to flow back in the
compressor.
Adequate air circulation should be around the appliance,
lacking this leads to overheating. To achieve sufficient
ventilation, follow the instructions relevant to installation.
Wherever possible the back of the product should not be
Make sure that the mains plug is accessible after the
installation of the appliance.
Any electrical work required to do the servicing of the
appliance should be carried out by qualified electrician or
competent person.
This product must be serviced by an authorized Service
Center, and only genuine spare parts must be used.
1)If the appliance is Frost Free.
2)If the appliance contains freezer compartment.
●
●
●
●
●
●
Service
too close to a wall to avoid touching or catching warm parts
(compressor, condenser) to prevent the risk of a fire, follow
the instructions relevant to installation.
●The appliance must not be locate close to radiators or
cookers.
●Do not use a sharp objects instead of a plastic scraper
to remove frost from the appliance.
Installation - Important!
●For electrical connection carefully, follow the instructions
given in this manual. Unpack the appliance and check if
there are damages on it.
●Do not connect the appliance if it is damaged. Report
possible damages immediately to the place you bought it.
In this case retain packing.

Note:
●This appliance is intended to operate
in the climate class from 55~110°F. It
may not work properly if being left at a
temperature above or below the
indicated range for a long period.
●Install your appliance in a dry place to
avoid high moisture.
●Keep the appliance out of direct
sunlight, rain or frost. Place the
appliance away from heat sources
such as stoves, fires or heaters.
Leveling of appliance
●For sufficient leveling and air
circulating in the lower rear section of
the appliance, the bottom feet may need
to be adjusted. You can adjust
them manually by hand or by using a
suitable spanner.
●To allow the doors to self-close, tilt the
top backwardsby about 10mm .
9
Installing your new appliance
Before using the appliance for the first
time, you should be informed of the
following tips.
Ventilation of appliance
In order to improve efficiency of
the cooling system and save
energy, it is necessary to
maintain good ventilation around the
appliance for the dissipation of heat. For
thisreason, sufficientclear spaceshould
beavailablearound therefrigerator.
Suggest: Itisadvisable for there to be
50-70mmofspace from the backto the
wall,atleast100mm fromitstop,atleast
100mmfrom its side to the wall and a
clear space upfrontto allow the doorsto
open 115°.Asshown in follow。
831
717
115

10
Reversing the door
The side at which the door opens
can be changed, from the right side
(as supplied) to the left side, if the
installation site requires.
When reversing the door,
the appliance must not be connected
to the mains. Ensure that the plug is
removed from the mains socket.
When required, tilt the refrigerator
back in order to gain access to the
base, you should rest the appliance
on soft foam packaging or similar
material to avoid damaging the
backboard of the refrigerator. To
reverse the door, the following steps
are generally recommended.
Different models may correspond to
different pictures. Models will be
written in the picture. If some parts
are not shown in the picture, please
ignore the relevant description.
1. Stand the refrigerator upright.
Open the upper door to take out all
door racks (to avoid racks damaged)
and then close the door.
Warning!
Tools you will need
●
2.Remove part loose part from
the top right side of refrigerator.
3.Remove screws and hinge
.When the refrigerator with
display on door, you need to pass
connector through the hole of
hinge (Please hold upper door by
hand when installing).
①, ②
③
①
②
②.
Not provided
8mm socket wrench Thin-blade screwdriver
8mm wrench
Cross-shaped screwdriver
Door racks
MODEL WITHOUT DISPLAY
①screwsSpecial flange
Upper hinge②
MODEL WITH DISPLAY
①screwsSpecial flange
Upper hinge
Electrical connector
②
③
①screwsSelf-tapping
Upper hinge cover②
