Hisense BCD-543WP2BF1Z6/HC1(H) User manual

重要度
产品
名称
●: 冷藏冷冻箱
产品
型号：
BCD-543WP2BF1Z6/HC1(H)
型号包括原手册中已有型号和维修手册整合计划中的型号
每次更改需要增加型号
文件
名称：
售后服务技术资料
文件
编号：
BSSJ00004976
编制
日期：
2022年4月15日
借(通)用件登记
冰箱开发
中心
旧底图总号
底图总号
A
●
售后服务
技术资料
版本
更改单编号
签字 日期 重 量 比例
出图审查 设计
审核
标准化
共 张
第 张 BSSJ00004976
日期 批准

1
Refrigerator
Service Manual
Model: BCD-543WP2BF1Z6/HC1(H)

2
Contents
1. Warnings and precautions for safety .......................................3
2. Appearance and structure
2.1 View of the appliance .......................................................4
2.2 Wind channel structure ....................................................5
2.3 Evaporator structure ........................................................6
2.4 Compressor room structure ................................................
●
6
3. Basic parameters .........................................................8
4. Operation and functions
4.1 Display controls.............................................................9
4.2 Using the appliance........................................................12
4.3 Defrost mode .............................................................18
4.4 Error display ............................................................19
5. Troubleshooting
5.1 Common problem and checking ...........................................25
5.2 Faulty start .......................................
●
........................27
5.3 Refrigeration failure ......................................................28
5.4 Thick frost in freezer compartment .........................................30
5.5 Dew in refrigerator compartment ............................................31
5.6 Breaking of light .........................................................32
5.7 Noise ..................................................................33
6. Circuit and checking
6.1 Circuit diagram ..........................................................34
6.2 Mainboard ..............................................................35
6.3 Compressor ..............................................................35
6.4 Fan motor................................................................36
6.5 Light ...................................................................37
6.6 Door switch ...............................................................38
6.7 Defrost heater ............................................................39
6.8 Removing the Display Component .........................................40
6.9 The system of water supplies ...............................................41
6.10 Ice maker ...............................................................43
7. Cooling system repairing
7.1 Refrigeration system .....................................................45
7.2 Summary of repair .......................................................46
7.3 Regulation of repair ......................................................47
7.4 Practical work of repair ...................................................48
7.5 Brazing reference drawing ................................................49


3
1. Warning and precautions for safety
Please observe the following safety precautions in order to use safely and correctly the
refrigerator and to prevent accident and danger during repair.
1. Be care of an electric shock. Disconnect power cord from wall outlet and wait for more
than three minutes before replacing PCB parts. Shut off the power whenever replacing
and repairing electric components.
2. When connecting power cord, please wait for more than five minutes after power cord
was disconnected from the wall outlet.
3. Please check if the power plug is pressed down by the refrigerator against the wall. If
the power plug was damaged, it may cause fire or electric shock.
4. If the wall outlet is over loaded, it may cause fire. Please use its own individual
electrical outlet for the refrigerator.
5. Please make sure the outlet is properly earthed, particularly in wet or damp area.
6. Use standard electrical components when replacing them.
7. Make sure the hook is correctly engaged. Remove dust and foreign materials from the
housing and connecting parts.
8. Do not fray, damage, machine, heavily bend, pull out or twist the power cord.
9. Please check the evidence of moisture intrusion in the electrical components. Replace
the parts or mask it with insulation tapes if moisture intrusion was confirmed.
10. Do not touch the ice maker with hands or tools to confirm the operation of geared
motor.
11. Do not let the customers repair, disassemble and reconstruct the refrigerator for
themselves. It may cause accident, electric shock, or fire.
12. Do not store flammable materials such as ether, benzene, alcohol, chemicals, gas, or
medicine in the refrigerator.
13. Do not put flower vase, cup, cosmetics, chemicals, etc., or container with full of water
on the top of the refrigerator.
14. Do not put glass bottles with full of water into the freezer. The contents shall freeze
and break the glass bottles.
15. When you scrap the refrigerator, please disconnect the door gasket first and scrap it

4
2.Appearanceandstructure
2.1 View of the appliance
Note！
Due to unceasing modification of our products, your refrigerator may be slightly different
●
from this instruction manual, but its functions and using methods remain the same.
To get the best energy efficiency of this product, please place all shelves, drawers and
baskets on their original position as the illustration above.

5
2.2 Wind channel structure

6
2.3 Evaporator structure
2.3.1 Freezer evaporator structure
1－Fuse
2－Accumulator
●
3－Sensor
4－Heater
5－Evaporator
2.4 Compressor room structure
10 1
2
3
4
5
6
7
8
9

7
1-Dry filter
2-Power cord
3-Compressor
4-Fan Motor
5-Bottom condenser
6-Evaporation dish
7-Water valve(SOLENOID –VALVE)
8- Water tube
9-Connector（Water tube ）
10-Drive board
3.Basicparameters
SPECIFICATIONS
●
DESIGN PRESSURE
●
HIGH SIDE/LOW SIDE 250psig/88psig
REFRIGERANT/AMOUNT R600a/57g
RATED VOLTAGE AC115V
RATED FREQUENCY 60Hz
RATED CURRENT 3A
DEFROST POWER 240W
FOAMING AGENT Cyclopentane
NET WEIGHT 113kg
WxDxH(with hinges) 91.4x72.7x177.8cm
WxDxH(without hinges) 91.4x72.7x177.8cm

8
4.Operationandfunctions

9

10
4.2 Using the appliance
●
This section tells you how to use most of the useful features. We recommend that you read
through them carefully before using the appliance.
Getting cold water
The water dispenser is located in the left side of fridge room. Open the refrigerator doors,
and push the water dispenser button to get water,. Then move your glass down the
dispenser lever in the suggested position and press it.
Hold the glass underneath the dispenser for 2~3 seconds after releasing the dispenser
button. Water may continue to dispense after the button is released.
Water clouding phenomenon
●
All water provided to the refrigerator flows through the filter which is an alkaline water filter.
In the filtering process, the pressure of the water that has flowed out of the filter is increased,
and the water becomes saturated with oxygen and nitrogen. When this water flows out into
the air, the pressure plummets and the oxygen and nitrogen get supersaturated, which
results in gas bubbles. The water may temporarily look misty or cloudy due to these oxygen
bubbles. After a few seconds, the water will look clear.
.
1. Changing the water filter
To drink the freshest and cleanest water from your refrigerator, change the filter on time.
To change the water filter, follow these steps:
1. Shut off the water supply. Then turn out the water filter (A) about 1/4 turn, counter-
clockwise.

11
Hisense Refrigerator
2. Pull the water
●filter (A) from the filter holder (B).
Note:
To change the water filter more
●easily, shut off the water supply valve.
Sometimes, it is hard to disassemble the water filter because impurities in the water cause
it to stick. If you are having difficulties, grip the water filter firmly and pull it out.
When you pull the water filter, a little water can leak from the opening. This is normal. To
minimize the water leaks, keep the filter cartridge horizontal when pull it.
To prevent overflow, empty the water filter tray (C) and dry around the filter case.
You should re-install the water filter tray before inserting the new filter followed the
direction below.
3. Insert the new filter into the filter holder.
4. Push the filter, and then turn it clockwise until it locks.
If you have trouble inserting the water filter because of high water pressure, shut off the

12
Hisense Refrigerator
water supply valve.
5. If you turned off the water supply, turn it back on.
Removing any residual matter inside the water supply line after installing the water
●
filter
1.Turn on the main water supply and supply water from water supply line.
2.After the water filter is replaced, dispense 2.5 gallons of water (flush for approximately 5
minutes) to remove trapped air and contaminants from the system.
3. Additional flushing may be required in some households.
4. Open the refrigerator door and make sure there are no water leaks coming from the
water filter.
Note:
Be sure to flush the dispenser thoroughly, otherwise water may drip from the dispenser.
This means that there is still air in the line.
Do not dispense the entire 2.5 gallon amount continuously. Depress and release the
dispenser pad for cycles of 30 seconds ON and 60 seconds OFF.
Reverse osmosis water supply important:
The pressure of the water supply coming out of a reverse osmosis system going to the
water inlet valve of the refrigerator needs to be between 30 and 125 psi (207 and 862
kPa).If a reverse osmosis water system is connected to your cold water supply, the water
pressure to the reverse osmosis system needs to be a minimum of 40 to 60
●psi (276 to
414 kPa).If the water pressure to the reverse osmosis system is less than 40 to 60 psi (276
to 414 kPa):
Check to see whether the sediment filter in the reverse osmosis system is blocked.
Replace the filter if necessary.
Allow the storage tank on the reverse osmosis system to refill after heavy usage.
If your refrigerator has a water filter, it may further reduce the water press when used in
conjunction with a reverse osmosis system. Remove the water filter.
2. Using your fridge compartment
The refrigerator compartment is suitable for storage of vegetables and fruit. Food inside
should be packed to store in order to avoid losing moisture or flavor permeating into other
foods.
Caution! Never close the refrigerator door while the shelves, crisper and/or telescopic
slides are extended. It may damage both them and the refrigerator.
Door baskets
The refrigerator compartment is provided with six same door baskets, which are suitable
for the storage of canned liquid,
bottled drink sand packed food.
To remove the door baskets, simply lift the racks up and pull straight out.
To relocate the door baskets, slide it in above the desired location and push down until it
stops.

13
Hisense Refrigerator
Warning!
Do not place too many
●heavy things in the baskets. Before you lift up the door shelf
vertically, please take the food out.
Glass shelves
To remove the glass shelves, tilt up the front of the shelf in the direction shown (1) and lift
it up vertically (2).Pull the shelf out.
To re-install the glass shelves, tilt the front of the shelf up and guide the shelf hooks into
the slots at a desired height (1). Then lower the front of the shelf so that the hooks can
drop into the slots (2).
Vegetable and fruit crispers
The crispers are suitable for storage of vegetable and fruit. To take them out, open the door
to the final location first.
Then pull out the draw and tilt up the front of the crisper after moving slightly in the directing
of the arrow.
Using the freezer compartment
The freezer compartment is provided with
●an upper drawer, a lower drawer and a ice box.

14
Hisense Refrigerator
To remove all of them, refer to page 8 for disassembly instruction.
Disassembling the freezer door
1. Pull out the freezer door and the upper freezer drawer (A) to the final position.
2. Take out the ice storage box (B) by lifting it up in the direction of the arrow.
3. Take out the upper freezer drawer (A) by lifting it up from the rail system.
4. Remove
●the lower freezer drawer (C) by lifting it up.
5. Remove the 4 screws attached to the supporting frame (D).

15
Hisense Refrigerator
6. Pull out the freezer door and lift it up in the direction of the arrow.
Re-assembling the freezer door
To reattach the drawer after you moved the appliance to its final
●
location, assembling the
parts in reverse order.
Remove the ice maker part
1. Open freezer door, take upper drawer out.
2. Disassemble two fixed screws with a cross screwdriver (+).
3. Pull out the ice maker part.

16
Hisense Refrigerator
4. Unplug two terminals, then take out the ice maker part.
Remove the water pipe connector part
1. Remove the ice maker part
●
.
2. Unplug the terminal.

17
Hisense Refrigerator
3. Remove wire line from two buckles in the direction of arrow one by one.
4. Disassemble
●
the fixed screw with a cross screwdriver (+), then pull the ice maker inlet
cover down.
5. Pull the blue water tube out in the direction of arrow.
6. Disassemble the fixed screw with a cross screwdriver (+).
7. Pull the water pipe connector part
●
out with pliers.

18
Hisense Refrigerator

19
Hisense Refrigerator
4.3 Defrost mode
4.3.1 Start condition
When compressor accumulated running time reach the setting point (depends on the
environment temperature), it will enter defrost mode automatically.
Forced defrost mode: Opened the freezer door, touch and hold “Ice On/Off”button
+“Freezer” button for 3 seconds in 10 minutes after power-on, the freezer heater will turn
on at the same time.
4.3.2 Defrost flow
Start
Compressor stops
●
Evaporator fan stops
Damper stops
Defrost heater works
Evaporator temperature reach the
setting point,exit defrost mode
Defrost heater stops
Compressor starts several
minutes delay
Evaporator fan starts
●
several
minutes delay
Damper starts
