Hitachi EP-L110E User manual

Read “Safety Precautions” (P.E-8 - E-12)
to ensure correct use.
EP-L110E
Model
Hitachi Air Purifier with
Humidifying Function
Instruction Manual
Thank you for purchasing a Hitachi air purifier.
This air purifier is for household use only.
Do not use it for any other purpose besides purifying air.
Please read this instruction manual carefully before
using this product to ensure the unit is operated
correctly.
For future reference, keep this manual in an easily
accessible place.
EP-L110E_EN.indd 1EP-L110E_EN.indd 1 2/7/2018 10:54:29 AM2/7/2018 10:54:29 AM

E-2
Features
1. Pre-filter is automatically cleaned before dust accumulates.
Cleaning has never been easier!
2. Collects various types of pollutants and odor particles in the air.
Allergen-free HEPA filter for fine dust particles and washable deodorizing filter collect pollutants
and odor particles.
3. Wide-area, high-speed dust collection
By sucking air from a wide area, the air purifier EP-L110E can collect dust in a floor area of up to 79m2.
The larger the applicable floor area is, the faster the air purifier can clean air.
Air Purify Mode
Humidifies clean air and increases humidity for dry rooms.
Humidify Mode
Skin Moist Mode
Increases room humidity and controls it to about 60%.
Gives moisture to dry skin during winter, or during dry weather.
Automatically regulates the airflow according to the condition of the
room air, and performs dust collection and deodorization.
Skin Moist
Humidify
Air Purify
Mode
Skin Moist
Humidify
Air Purify
Mode
Skin Moist
Humidify
Air Purify
Mode
EP-L110E_EN.indd 2EP-L110E_EN.indd 2 2/7/2018 10:54:49 AM2/7/2018 10:54:49 AM

E-3
Contents
Operatin
g
Air Purifier
Be
f
ore Use
C
leaning and Maintenance
Features············································
Name of Each Component / Accessories ····
Operating the Touch Operation Panel ····
Safety Precautions ··························
Cautions on Use ······························
Air Cleaner Deodorizing Performance ···
Preparations for Operation·············
Setting Filter in Unit ····························
Filling Water Tank ·······························
Installation········································
E-2
E-4
E-6
E-8
E-13
E-14
E-14
E-16
E-18
Operation··········································
Starting Operation ····································
Switching Touch Operation Panel Display ····
Selecting Operation Mode (Basic Operations) ····
Switching Airflow Rate······························
Useful Features································
Operating in Option···································
Eco Saving Operation·······························
PM2.5 Sensor···········································
Switching Between Temperature /
Humidity Monitor Display ··························
Stopping Operation Using Off-timer··········
Setting the Lock········································
Setting and Running Auto Self Clean
(Pre-filter Automatic Cleaning)··················
Memory Function / Monitor /
Sensors / Auto Detection················
Memory Function······································
Air Sensor·················································
Odor Sensor ·············································
Dust Sensor··············································
Temperature / Humidity Monitor
(Temperature / Humidity Sensor)··············
Vibration Sensor ·······································
Auto Detection ··········································
Adjusting Sensory Sensitivity Setting ·······
E-19
E-19
E-20
E-21
E-21
E-22
E-22
E-23
E-24
E-24
E-24
E-25
E-28
E-28
E-28
E-28
E-28
E-28
E-29
E-29
E-29
Cleaning ···········································
When the Filter Cleaning Indicator Comes On ····
Replacing Humidifying Filter ·····················
When the “Water Refill” Indicator Comes On ······
Water Tank················································
Humidifying Filter······································
Water Tank, Tank Cover, Water Tank Filter ····
When the Empty Dust Indicator Comes On ···
Auto Self Clean Unit ·································
Rear panel, etc.·········································
Pre-filter, Filter Assembly / Deodorizing Filter ····
Cleaning the Deodorizing Filter ················
Purifier ······················································
Dust Sensor··············································
Replacing the Filter Assembly / De-
odorizing Filter·································
Replacement Interval································
Handling the Filter Assembly /
Deodorizing Filter······································
How to Replace the Filter Assembly /
Deodorizing Filter······································
Troubleshooting Guide ···················
Replacement Parts ··························
Specifications ··································
E-30
E-30
E-33
E-33
E-34
E-35
E-35
E-40
E-39
E-41
E-42
E-42
E-43
E-43
E-43
E-44
E-45
E-50
E-51
Before Use Operating Air Purifier Cleaning and Maintenance
E-13
E-26
E-36
E-38
EP-L110E_EN.indd 3EP-L110E_EN.indd 3 2/7/2018 10:54:50 AM2/7/2018 10:54:50 AM

E-4
Name of Each Component / Accessories
Air outlet
(stainless steel net)
Power plug Power cord
Glass panel
Handle
Humidifying filter
Tank cover
Water tank
Names of Each Component
CAUTION
Power button Flap (stainless steel flap) (P.E-21)
The flap controls the wind in vertical direction
according to the operation mode.
Side cover
Purifier
Vibration Sensor (P.E-29)
Senses impact and tilting.
(Installed inside the unit)
Caster
To prevent falls, the movement is
only in sideways direction. (Located
at the base of the unit)
Air inlet
Water tray
Handle
Float switch
CAUTION
Touch Operation
Panel (P.E-6, E-7)
Do not hold the flaps when
moving the unit.
Doing so may cause unexpected
injury when the unit is damaged
and overturned or dropped.

Do not subject the glass panel
(made of tempered glass) to impact
Although tempered glass is
stronger and safer than normal
glass, it can break when subject
to strong impact or force.
In case of scratches or breakage,
stop using and immediately
request repairs.
Refrain from touching the broken
glass.
Senses the presence of cigarette
smoke, dust, pollen, and other
similar air contaminants.
Dust Sensor (P.E-28)
Temperature Sensor (P.E-28)
Odor Sensor (P.E-28)
Senses the odor components in the air.
Senses the air temperature.
Humidity Sensor (P.E-28)
Senses air humidity.
EP-L110E_EN.indd 4EP-L110E_EN.indd 4 2/7/2018 10:54:50 AM2/7/2018 10:54:50 AM

E-5
 (P.E-) Numbers are pages containing the main description each parts.
(x1)
Humidifying filter Pre-filter
(x1)
Accessories
Filter
CAUTION
Dust Filter (x1)
Deodorizing Filter (x1)
Do not lift the rear panel by holding the
auto self clean unit or drive part.
Doing so may cause deformation or damage.
Housed inside the purifier.
The filter must be removed from the
plastic packaging before operating the
unit.
The vibration during transporting the unit might cause deodoriz-
ing agent granules to fall out from the filter.
When removing the plastic cover of the filter and attaching the
filter to the unit, make sure that your hands, clothes, and the
surroundings will not get dirty.
Wipe of any granules that may have fallen or clung to the filter.
This will not affect the deodorizing performance.
*
Deodorizing filter
(Washable deodorizing filter)
Set in the inner part of the unit.
Set in the outer part of the unit.
Filter Assembly
(Allergen-free, HEPA filter)
Rear panel
Drive part
Removes large size dust.
Pre-filter
(stainless steel pre-filter*)
*The surface (one side) of the net
has a stainless steel coating.
Automatically cleans the pre-filter.
Detects if the auto self clean unit is set.
Auto Self Clean Unit Detection Switch
Detects if the rear panel is attached.
Rear Panel Detection Switch
Rotates during auto self clean
operation.
Drive shaft
Do not touch the drive shaft.
Doing so may cause injury.
Detects if the filter assembly is set.
Filter Assembly Detection Switch
CAUTION
Do not place tapes or any materi-
als to press the filter assembly
detection switch, or subject it to
unnecessary force.
It may not be able to detect the
filter and may cause unit failure.
CAUTION
Auto Self Clean Unit (P.E-26)
Auto self
clean unit
CAUTION
Name of Each Component / Accessories
EP-L110E_EN.indd 5EP-L110E_EN.indd 5 2/7/2018 10:54:50 AM2/7/2018 10:54:50 AM

E-6
Operating the Touch Operation Panel
MENU
Touch this button first when the
display or operation panel is off.
When tapped again, it turns off the
display or operation panel.
Lock
(Long-press MENU for about 3 seconds)
Use this to prevent incorrect
operation. (P.E-25)
Note
The air purifying feature works in all operation modes.
The touch operation panel is made of glass.
If the touch operation panel display disappears, touch to display it again.
The touch operation panel display will disappear when is touched again.
The upper part of the touch operation panel is the display section and the lower part is the control section.
Use the touch operation panel to switch settings.
Display Switch
Auto Self Clean (P.E-26)
Temperature/
Humidity Monitor
Filter Cleaning
Water Refill
Cleaning
Empty Dust
Notification Display
Displays the room temperature and humidity while operating.
This should be taken as a guide only. (P.E-28)
Displays notification contents that came out while operating.
Example: , (P.E-45)
Lights up when it is time to clean the humidifying filter. This notification (guide) is
made based on the operation time. (P.E-30 - E-33) (After the indicator lights up,
unplug the power cord to reset and turn off the indicator.)
The indicator lights up when the water in the water tank is nearly empty. (P.E-33, 34)
The indicator lights up when the child lock is set. (P.E-25)
The indicator lights up when the unit is operating on timer. (P.E-24)
The indicator lights up when the unit is operating with PM2.5 sensing. (P.E-24)
The indicator lights up when the unit is operating on humidify mode or skin moisturize mode. (P.E-21)
Lights up when dust should be discarded. This notification (guide) is made based
on the operation time. (P.E-36)
(Once you unplug the power cord after the indicator lights up, the operation time will be reset and the indicator will go off.)
Lights up during the Auto Self Clean operation. (P.E-26)

Switches the display between temperature /
humidity monitor.
(P.E-24)
 Switches the display of the touch
operation panel. (Long-press for about 3
seconds) (P.E-20)
The glass touch may have a different reaction depending on the sur-
rounding temperature and humidity, physical condition of the user, and
the condition of the electronic appliances near by the unit.
If it does not respond after touching, release and try again.
If the interval between touches is short, the unit may respond incorrectly.
The sensitivity will not change by the force applied when touching.
There may be no response if the operation panel is wet or dirty.
Wipe off with a dry cloth to use.
The display may be difficult to view if the unit is placed in brightly lit
places such as near a window with direct sun light.
Use this to set Auto Self Clean.
Use this to manually perform
Auto Self Clean.
(Long-press Auto Self Clean for
about 3 seconds.)
EP-L110E_EN.indd 6EP-L110E_EN.indd 6 2/7/2018 10:54:52 AM2/7/2018 10:54:52 AM

E-7
Operating the Touch Operation Panel
Off-timer (P.E-24)
Use this to set the off-timer.
Airflow (P.E-21)
Use this to switch the
airflow rate.
Option (P.E-22)
Use to switch to quick cycle.
Mode (P.E-21)
Switches the operation mode.
Air Sensor (P.E-28)
Display
Operation
Panel
The level of air contamination detected
by the odor and dust sensors is
indicated through different colors.
EP-L110E_EN.indd 7EP-L110E_EN.indd 7 2/7/2018 10:54:52 AM2/7/2018 10:54:52 AM

E-8
Safety Precautions
Please read the following safety precautions carefully before using the unit.
To prevent injury to the user or other people and property damage, the following instructions must
be followed. Also read the precautions appearing in the text carefully to ensure correct use.
Definition of each indication
Incorrect operations that are carried out as a result of ignoring instructions will cause harm or dam-
age. The seriousness is classified by the following indications.
WARNING
CAUTION
This symbol indicates the
possibility of death or se-
rious injury.
This symbol indicates
the possibility of injury or
damage to property.
Meaning of Symbols
Indicates “warning or caution”.
Indicates “prohibition”.
Indicates “necessity”.
WARNING
To Prevent Fire, Electric Shock and Injury
AC Outlet, Power Plug and Power Cord
Remove dust from the blade and the blade mounting surface of the power plug.
Otherwise, it may cause a fire.
Be sure to unplug the power cord from the AC outlet when cleaning or not using the
unit for an extended period of time.
Otherwise, it may cause an electric shock or injury.
Be sure to hold the plug when unplugging it.
Otherwise, it may cause an electric shock or short-circuit, which may result in a fire.
Securely insert the power plug into the AC outlet.
Otherwise, it may cause an electric shock, overheating or fire.
Do not stop operation by unplugging the power plug.
Otherwise, it may cause fire, electric shock or malfunction.
Never plug or unplug the power plug with wet hands.
Otherwise, it may cause an electric shock.
Do not use a damaged power cord or power plug, or a loose AC outlet.
Otherwise, it may cause an electric shock, short-circuit or ignition.
Do not damage the power cord.
(Do not break, modify, forcibly bend, pull or twist it. Also do not place any heavy objects on it,
pinch it, or step on it when moving it with the caster.)
Otherwise, it may cause damage to the power cord, fire or ignition.
Make sure to avoid inserting too many plugs into the AC outlet.
Otherwise, it may cause fire or ignition.
Do not immerse the power plug in water, or pour water on it.
Do not use a power plug when wet.
Doing so may cause ground leakage, electrical shock and unit failure.
If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
Do not use with a voltage other than 220-240V AC.
Otherwise, it may cause a fire or electric shock.
EP-L110E_EN.indd 8EP-L110E_EN.indd 8 2/7/2018 10:54:52 AM2/7/2018 10:54:52 AM

E-9
WARNING
Before Use
Ventilate the room frequently when in use with heating appliances.
Otherwise, it may cause carbon monoxide poisoning.
This product cannot remove carbon monoxide.
When there is water leakage due to tilting of the unit, unplug the power cord from
the AC outlet and request repairs.
It may cause fire due to electric shock and ground leakage.
Do not block the air outlet or air inlets with laundry, cloth, curtains, etc.
Poor ventilation may cause overheating or fire.

Do not use flammable materials (hair sprays, insecticides, air fresheners, etc.) near the unit.
Do not use benzene, thinner or alcohol to clean the purifier.
Otherwise, it may lead to cracking, electric shock, ignition, smoke or fire.
Do not use in a kitchen as a substitute for a ventilation fan and range hood fan.
Otherwise, it may cause unit deformation by heat or it may ignite a fire in the filter.
Also, it may cause failure or a decrease in the lifespan of the pre-filter, filter assembly and deodorizing filter.
Keep away from lit candles, mosquito coils, lit cigarettes, etc. Also, do not let smoke
from these materials enter the unit.
Otherwise, it may cause fire.
Do not operate the unit when using fumigating (smoking) type insecticide. Do not let
chemicals enter the unit.
Use of such insecticides will cause chemicals to accumulate in the unit and depending on a
person’s sensitivity to these chemicals, it may be harmful to one’s health.
Do not place in a location where the air from the outlets will blow directly onto heat-
ing appliances.
Otherwise, it may cause incomplete combustion and carbon monoxide poisoning.
Do not use in narrow spaces such as gaps between the furniture or closet.
Poor ventilation may cause overheating or fire.
Do not operate the unit while the water tank or humidifying filter, filter assembly /
deodorizing filter, etc. are detached.
Otherwise it may cause injury, water leakage or failure.
Do not tilt or tip the unit over. Do not put your weight on the unit or step on it.
Also, do not use it in an unstable place or anywhere near infants.
Otherwise, it may cause the unit to tip over due to vibration, which may cause an injury or unit failure.
Also, water may leak from the water tank, which may cause fire due to electric shock or short-circuit.
If the unit is tipped over or tilted, pick up the unit immediately. If water from the tank is leaking,
unplug the power cord from the AC outlet and request repairs.
(When the unit is tipped over or tilted, the operation will stop.)
Cleaning
When cleaning, do not splash water on the unit.
It may cause short-circuiting and electric shock.
Do not add water by submerging or splashing water on the unit.
It may cause short-circuiting and electric shock.
Do not tilt the unit to remove or clean the filter.
The water may spill and may cause electric shock or unit failure.
Safety Precautions
EP-L110E_EN.indd 9EP-L110E_EN.indd 9 2/7/2018 10:54:53 AM2/7/2018 10:54:53 AM

E-10
Safety Precautions (Continued)
WARNING
Place of Use
Do not use in a location where there is huge amount of oily smoke such as in cafete-
rias and eateries.
The oil residue or dust deposited in the unit may cause fire, unit failure and unpleasant odor.
Do not use in a location where there is flammable gas, corrosive gas or metallic
dust, or risk of leakage of oil, flammable gas.
It may cause fire, explosion or unit failure.

Do not use in a location where solvents such as paint and adhesives are being used or stored.
It may cause deterioration of parts or fire.

Do not use in a location where soot from oil, such as machine oil, is floating in the air.
It may cause a crack, electric shock or fire.
Do not use in a location where any chemical is used. (Hospitals, factories, laborato-
ries, beauty salons, photographic laboratories, etc.)
Chemicals and solvents evaporating into the air deteriorate the unit. This causes water leakage
and wets the furniture or may cause electric shock.
Do not place on shelves, desks, tables, etc.
The unit may fall due to its movement and vibration which may cause water leakage and electric shock.
Do not place in a location which has a thick carpet or uneven floor.
The unit may incline and fall which may cause water leakage and electric shock.

Do not use in a humid place or in a place where it may easily be wet, such as in a bathroom.
It may cause electric shock or fire due to ground leakage.
Do not place it near a hot object such as a heater.
It may cause deformation, discoloration, injury and unit failure.
Do not put in places exposed to direct sunlight, wind and rain.
It may cause overheating, electric shock and fire due to ground leakage.
Do not use in a location where a machine tool that produces flammable dust or
sparks (such as a grinder or welder) is installed.
It may cause fire.
Miscellaneous

Even after switching on, sometimes the air purifier is inoperative or air does not come
out. There may be “cracks” and scratches” in the power cord, or the unit has been moved
which causes the operation to stop. There may also be unusual noise and vibration dur-
ing operation. The unit may be deformed and unusually hot. There may be a burnt odor. If
there are abnormalities aside from those mentioned, unplug the power cord immediately
to prevent accidents and contact your dealer to request for checks or repairs.
These may cause fire due to electric shock, ground leakage or short-circuiting.
Pay specific attention when the user of the air purifier is the following:
(Infants, children, the elderly, those who cannot control their body temperature)
When the body is exposed directly to the wind for a long time, health may be compromised.

When carrying the air purifier, unplug the power cord and drain the water in the water tank.
It may cause water leakage which may cause electric shock and ground leakage, and wets the furniture.
Cleaning
Do not use detergents when cleaning.
Usage of chlorine-based and acid type detergents will generate toxic gas and can cause a health threat.
Also, do not use neutral detergents as it may affect the plastic.
(Except when cleaning the humidifying filter)
Do not use detergents when cleaning the water tank or water tray.
The detergent ingredients may damage the unit, which may cause water leakage, electric
shock, injury and unit failure.
EP-L110E_EN.indd 10EP-L110E_EN.indd 10 2/7/2018 10:54:53 AM2/7/2018 10:54:53 AM

E-11
Miscellaneous

Do not put your finger or any other object (metal, paper, etc.) into the air inlet or outlet.
It may cause injury, electric shock and fire.

Do not drink or allow anyone to drink water from the water tank. Do not use for other purposes.
It may cause a health threat or accident.
Never attempt to disassemble, modify or carry out repairs by yourself.
It may cause fire, electric shock or injury. (Contact your dealer for repairs)
Do not operate detection switches (for the dust filter, auto self clean unit, and rear
panel) using your fingers, rod, or tape.
Doing so may result in an injury, failure, or unexpected accident.
Children should be supervised to ensure that they do not play with the appliance.
CAUTION
Moving the Air Purifier
Move only in sideways direction with the caster (to prevent from falling)
There are cases when the floor may be damaged based on the type of flooring. When the wa-
ter tank has water contents, move slowly on an even floor to avoid spilling.
Unplug the power cord from the AC outlet.
Lift the air purifier when moving it along a mat, a floor susceptible to scratches, an
uneven floor or a thick carpet.
It may damage the mat, floor and carpet and may cause unit failure and injury when tipped over.
When carrying the air purifier, hold the handle firmly.
If you hold parts other than the handle, the unit may tip over and be damaged, and may cause an accident.
Unplug the power cord from the AC outlet.
When moving the unit without unplugging, the power plug and power cord may be damaged.
Do not carry the unit when it is filled with water.
· It may cause water leakage and injury.
· Carrying the unit while it is filled with water may cause the water to spill during operation.
·
When carrying the air purifier, drain the water in the water tank and operate with the unit’s set status.
Do not touch, hold, or lift the moving flap.
It may cause an injury and unit failure.
When carrying the air purifier, hold the handle.
Do not pull the power cord when moving the unit.
It may damage the power cord.
Place of Use
Do not use the air purifier near a wall that cannot be scrubbed, such as a white
cloth-covered wall.
The air purifier will take in the surrounding air and may stain a wall near its air outlet.

Do not use in storerooms for artworks and academic materials, or for other business purposes
It may deteriorate the quality of the stored products.

Do not put water containers such as flower vases and fish bowls on top or near the unit.
Water deposited in the unit may cause electric shock, fire and unit failure.
Do not use in locations near cooking appliances
It may cause deterioration of parts, electric shock and fire due to heat and oily smoke.
Do not use on floors susceptible to scratches such as Cypress floors
It may damage the floor.
Safety Precautions
WARNING
EP-L110E_EN.indd 11EP-L110E_EN.indd 11 2/7/2018 10:54:54 AM2/7/2018 10:54:54 AM

E-12
Safety Precautions (Continued)
CAUTION
Miscellaneous
Do not put water directly in the water tray
Doing so may cause water to overflow.
Do not use the unit in case of water leakage
In case of water leakage, unplug the power plug from the outlet and request repairs.
Do not allow the water to freeze
Otherwise, it may cause damage to the water tank and cause unit failure or electric shock.
Whenever there is risk the water may freeze, drain the water tank.
Do not move or stop the flap by hand or by any object
Otherwise, it may cause unit failure.
If using the purifier around pets, do not subject any parts to urine and keep pets
away from the power cord
Otherwise it can cause electric shock and fire. If there are damages, unplug and request repairs.
Do not subject the glass panel (made of tempered glass) to impact
Although tempered glass is stronger and safer than normal glass, it can break when subjected
to strong impact or force.
In case of scratches or breakage, stop using and immediately request repairs.
Refrain from directly touching the broken glass.
Use only a genuine filter for the Hitachi Air Purifier
Other filters may cause unit failure.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, un-
less they have been given supervision or instruction concerning use of appliance
by a person responsible for their safety.
Cleaning
Perform panel and water tank removal and installation carefully.
It may cause water leakage and may cause injuries such as pinching your fingers.
Hold the unit in place when pulling out the water tank and humidifying filter so that
it will not move.
Otherwise, the unit may suddenly move and cause water leakage and accidents.
When cleaning, lay a soft cloth on the floor and place the unit and detached parts
(panel, water tray, water tank, etc.) on it
Otherwise, it may scratch the floor.
Attach the parts securely after cleaning
Do not use with the rear panel, pre-filter, dust filter, deodorizing filter, humidifying filter and any
other parts detached. Otherwise, it may cause unit failure.
Refill the water tank with fresh water daily, and clean on a regular basis as instruct-
ed on “Cleaning”.
Continued use without regular cleaning may cause propagation of molds and bacteria due to
dirt and water scale, which can result in unpleasant odors. In rare cases, it may cause health
risk to users who have hypersensitive immune system. In this case, please seek medical advice.
Only use fresh tap water (drinking water) for the water tank
Otherwise, it may cause deformation and deterioration of parts, unit failure or unpleasant odors
due to propagation of molds and bacteria. Do not use hot water (over 40°C), purified water, al-
kali ion water, mineral water, well water or other similar types of water. Also, refrain from putting
organic solvents, chemicals, perfumes, air fresheners or other similar items in the water tank.
When filling the tank with water, do not drop or subject the tank to impact
Otherwise, it may cause the water from the tank to leak and wet the floor. It may damage the
float switch in the tank, which results in the water supply indicator not lighting up.
Do not remove or subject the water tank’s float switch to excessive force.
The indicator will not light up even if the water tank is empty.
EP-L110E_EN.indd 12EP-L110E_EN.indd 12 2/7/2018 10:54:54 AM2/7/2018 10:54:54 AM

E-13
Cautions on Use
Do not operate with the filter detached
Otherwise, no cleaning effect can be expected. It
may also cause unit failure.
Do not block or touch the odor and
dust sensors
It may reduce the sensitivity of the sensors.
Do not directly fan plants and animals
It may adversely affect them.
Refrain from moving (changing the orienta-
tion or lifting the unit, etc.) during operation
Moving the unit while in operation may cause the fan
to hit the inner case, generate noise, pull and discon-
nect the power cord, and cause unit failure.
Do not use in locations near cooking appliances
It may cause deformation and dis-
coloration due to heat or oily smoke,
unit damage or fire.
Place the purifier and the cooking appli-
ance at least 1m apart from each other.
Ventilate closed rooms occasionally
The purifier does not have
a ventilation effect (remov-
al of carbon monoxide
and other contaminants).
* The purifier cannot re-
move harmful substanc-
es in cigarettes (carbon
monoxide, etc.).
Refrain from placing any ob-
ject on the unit and blocking
the air inlet and outlet
Doing so may cause unit failure
and injury.
Do not use near television or radio
Doing so may interfere with
broadcasts.
Please them at least 2m apart
from each other.
The same applies for cord-
less phones and wireless mi-
crophones.
Safety Precautions Cautions on Use Air Cleaner Deodorizing Performance
Air Cleaner Deodorizing Performance
The deodorizing filter of the air purifier does not remove all odors at once, but rather circulates the air in the
room, removing odors gradually.
The deodorizing filter is disposable. The deodorizing performance of the filter decreases with use.
When the odor emitted from the vent becomes bothersome, soak and wash the deodorizing filter. (P.E-41)
When the deodorizing filter has absorbed strong odors or has been continually used in an odorous room,
the odor components remain in the filter and unit, causing the odor to be emitted from the vent.
If this happens, you can decrease the amount of odor that remains in the unit by continuing to operate the
purifier while ventilating the room.
The dust and other contaminants attached to the filter and unit also contain odor components.
Periodically clean the filter and unit so that odor is less likely to be emitted from the vent. (P.E-40 - E-42)
If the odor emitted from the vent remains bothersome after cleaning, replace the filter. (P.E-43, E-44)
EP-L110E_EN.indd 13EP-L110E_EN.indd 13 2/7/2018 10:54:54 AM2/7/2018 10:54:54 AM

E-14
Preparations for Operation

Movement with casters should be done slowly. The movement is only in sideways direction. (To prevent from falling)

No cleaning effect will be experienced if the filter is set without detaching the plastic cover. It will also cause unit failure.
Do not tip over or tilt the unit.
Setting Filter in Unit
Setting procedure is the same with filter replacement. (Use only genuine Hitachi Air Purifier filters.)
Remove rear panel and pre-filter
Remove the filter
(filter assembly and deodorizing filter)
Install the deodorizing filter to the unit
Place the unit on a flat and stable
location.
Remove the pre-filter.
1
2
3
CAUTION
4
Set the filter at the deodorizing filter set position.
Deodorizing filter set position
Deodorizing filter set position
Unit tab
Deodorizing filter tab
Remove the deodorizing filter.
Deodorizing filter
Press the buttons (2 locations on
the left and right) on the lower side
of the rear panel, slowly pull the
pre-filter toward yourself, and slide
it slightly upward to remove it.
Slide the switch upwards
(2 locations) to release the lock.
Remove the filter assembly
from the unit.
Remove the filter from the plastic
packaging.
While pressing the tabs on the unit, set the
deodorizing filter and hook the tabs of the
deodorizing filter with the tabs of the unit.
The filter must be removed from the plastic
packaging.
Do not block the front side of the filter with
cloth, paper or other materials.
Switch
Slide the switch upward.
Pre-filter
Button (2 locations, left and right)
Plastic packaging
Deodorizing filter
Filter assembly
CAUTION
EP-L110E_EN.indd 14EP-L110E_EN.indd 14 2/7/2018 10:54:55 AM2/7/2018 10:54:55 AM

E-15
Install the pre-filter to the unit
Attach the rear panel to the unit
Filter assembly
5
6
4
Securely plug the tabs of the pre-filter to the matching holes in the unit.
Slide the switch downwards (2 locations) to lock.
Gently pull the pre-filter to make sure it is not out of place.
Deodorizing filter
CAUTION
Install the filter assembly to the unit
Do not put excessive force and deform
the filter assembly.
If the filter assembly is deformed, it will
not be detected by the unit.
“ ” will be displayed on the
temperature / humidity monitor, and the
unit will not be able to operate. (P.E- 45)
When the rear panel cannot be attached properly or " " is displayed
on the temperature / humidity monitor after the panel is attached
Plug the tabs (2 locations) of the
upper part of the rear panel to
the matching holes in the unit.
Gently push the bottom sides of
the panel one after another, and
close it securely until it clicks.
The drive connection part does not
properly engage in some cases.
In this case, remove the rear panel, slowly
turn the drive connection part on the rear
panel about 45 degrees to the left or right,
and then attach the panel.
Set the filter assembly so that you can see the label
Pre-filter
Switch
Slide the switch downward.
Plug the tabs of the pre-filter
Tab
Insertion hole
Insert to the hole
Note
Rear panel
Drive connection part
Preparations for Operation
Continued on next page
EP-L110E_EN.indd 15EP-L110E_EN.indd 15 2/7/2018 10:54:56 AM2/7/2018 10:54:56 AM

E-16
Preparations for Operation
(Continued)
Filling Water Tank
(When Running on “Humidify” and “Skin Moisture” Modes)
Remove the water tank from the unit
Remove the tank cover from the water tank
1
2
CAUTION
CAUTION
CAUTION
3
Rinse in running water for 2-3 times.
Do not use detergent.
Check if the float switch can move up and down.
Water tank
Float switch
Water tank
Tank cover
Water tank filter
Tank cover
Grab the water tank handle, and while slightly
lifting it, gently pull the water tank.
 When removing the water tank from the unit, pull the water
tank gently while pressing down the unit since a caster is
attached on its base. (The caster does not have a stopper)
Be careful not to injure your finger or nails when
removing the tank cover.
Make sure that the water tank filter is not subject to
unnecessary force. If damaged, it will not be able to
pump up water.
Rinse the water tank and tank cover with water
and check the movement of the float switch.
Do not to remove the float switch, or subject it to
unnecessary force.
Otherwise “Water Refill” will not be detected.
Water tank
Handle
7
Humidifying filter
Water tray
Set by aligning the broad sides
CAUTION
Check that the water tray set with
humidifying filter is installed in
the unit.
 If the humidifying filter is not installed, “ ” will
appear in the temperature / humidity monitor
and the unit will not operate. (P.E-45)

Do not forcibly open the side cover.
Doing so may break the part.
 Securely insert the humidifying filter, making sure
that it is pressed until it reaches the back of the unit.
If it is not securely inserted, it may cause water
leakage during operation.
Also, attach the filter while holding down the unit.
Insert the filters
with caution as
they may get stuck
inside the unit.
Side cover
Humidifying filter
EP-L110E_EN.indd 16EP-L110E_EN.indd 16 2/7/2018 10:54:59 AM2/7/2018 10:54:59 AM

E-17
Install the water tank to the unit
5
CAUTION
CAUTION
Wipe off water drops in the water tank holder (inner part)
during installing the water tank.
The water tank may be heavy when filled with water. Be
careful not to injure your fingers, nails, or your back
while handling.
Securely install the tank, making sure that it is pressed
until the back of the unit.
If it is not securely installed, it may cause water leakage
during operation.
Also, hold down the unit to make sure that the unit will not
move during installation.
Water level
Water level
4
CAUTION
Water tank
Tank cover
Fill the water tank, making sure that it does not
exceed the line.
Wipe the moisture around the water tank.
When filling the water tank away from the unit, attach
the tank cover and hold it in place.
Put water in the water tank and place
the tank cover.
If the water exceeds the fill line of the water supply, it
may cause water leakage.
Securely attach the tank cover.
If it is not securely attached, it may cause water leakage
during operation.
Make sure that the water
does not exceed the line.
Water tank holder
Water tank
Preparations for Operation
EP-L110E_EN.indd 17EP-L110E_EN.indd 17 2/7/2018 10:55:00 AM2/7/2018 10:55:00 AM

E-18
Installation
A caster is attached at the base of the unit, thus it should be set on an even, stable and sturdy floor.
(No stopper attached to the caster)
Avoid places near heating or cooling equipment and other similar equipment, and choose a location with a good air
circulation.
Keep the rear at least 3cm away from the wall. Depending on the operating environment, walls or floors near the
outlet may be stained as the unit draws in air. If this is a concern, move it from its current location and clean the sur-
rounding walls and floors regularly.
Be sure to provide space around the sides of the unit so that the inlets and vents are not blocked by curtains or
furniture.
WARNING
Do not place on shelves, desks, tables or other similar places
Unit may fall due to vibration or tilting, and may cause injury, water leakage and electric shock.
Using the unit in a tilted state may cause water leakage.
Moving the unit with the caster can be done on a sturdy and even floor. To move the unit on a mat,
carpet, or places with uneven surface, carry the unit by its handle.
Be careful not to pull or pinch the power cord.
Leaving the unit at the same place for an extended period of time may leave stains on the walls and floors.
When cleaning the unit, move it to another place and also include cleaning the floor.
* Leave space * Leave space
At least 3cm
*Air inlet and outlet must not
be covered by curtains or
furnitures
EP-L110E_EN.indd 18EP-L110E_EN.indd 18 2/7/2018 10:55:00 AM2/7/2018 10:55:00 AM

E-19
Operation
Starting Operation
Securely insert the power plug to the outlet
1
2Press the power button
Operation will start, and indicator
will light up.
Pressing the power button
while the unit is operating will
dim the indicator and stop the
operation of the unit.
After all indicators have light up at once,
“Air Purify” and “Auto” will light up.
For the first 3 minutes, the unit will
check and store the condition of the
room air.
During that time, the “Air Sensor” will
flash a green light.
Power button
Blinking
“Air Purify” mode is set as a factory default.
From the second use onward, the memory function enables operation based on the saved status. (P.E-28)
Standby Power Consumption
As long as the power plug is inserted in the outlet, the unit consumes approximately 3W of power, even if the unit
is not in use.
(Unplug from the outlet if the unit will not be used for an extended period of time.)
Installation Operation
EP-L110E_EN.indd 19EP-L110E_EN.indd 19 2/7/2018 10:55:00 AM2/7/2018 10:55:00 AM

E-20
Operation Panel
Display Display Contents Example
Display 1
Select operation mode and airflow rate by
tapping the panel.
For power saving, the display and operation
panel other than the notification display and
the air sensor will turn off approximately one
minute after the unit stops operating.
Display 2
When all indicators are on, tapping the op-
eration panel and selecting operation mode,
airflow rate or other similar buttons will make
the display light of the selected buttons
brighter.
* The display may not be clear to look at
when the unit is placed near windows with
direct sunlight, and other similarly bright
places.
Off
Display is the same as Display 1.
The display, operation panel, notification dis-
play, and clean monitor go off approximately
one minute after the unit stops operating.
Switching Touch Operation Panel Display
Use this to adjust the unit to your preferred setting.
Display Contents of the Operation Panel
In this instruction manual, the following examples are described in Display 1.
The touch operation panel display will switch at each press.
Display 1 Display 2 Off (When switching from Off to Display 1, the buzzer will ring twice
(beep, beep) and the display will blink once. )
Long-press for about 3 seconds and select touch operation panel
display
Display
·
Dimmer
Type 1/2/Off
(When selecting Air Purify / Max)
(When selecting Air Purify / Max)
(When indicators are dimmed)
If the lights in the touch operation panel display are turned off, tap the and operate after the panel is dis-
played.
(Tapping the again turns off the indicator of the touch operation panel display.)
Operation (Continued)
EP-L110E_EN.indd 20EP-L110E_EN.indd 20 2/7/2018 10:55:00 AM2/7/2018 10:55:00 AM
