Hitachi EP-NZG70J User manual

Read “Safety Precautions” (P.E-8 - E-12)
to ensure correct use.
EP-NZG70J
Model
Hitachi Air Purifier
Instruction Manual
Thank you for purchasing a Hitachi air purifier.
This air purifier is for household use only.
Do not use it for any other purpose besides purifying air.
Please read this instruction manual carefully before
using this product to ensure the unit is operated
correctly.
For future reference, keep this manual in an easily
accessible place.
EP-NZG70J_EN.indd 1EP-NZG70J_EN.indd 1 6/30/2017 10:32:226/30/2017 10:32:22

E-2
Features
1. Wide suction and speedy dust collection in just 9 minutes for a 13m2room.
Standard applicable floor space - 53m2
2. With the Allergen-free HEPA Filter, fine dust particles are thoroughly collected.
EP-NZG70J_EN.indd 2EP-NZG70J_EN.indd 2 6/30/2017 10:32:286/30/2017 10:32:28

E-3
Contents
O
perating Air Purifier
Be
f
ore Us
e
C
leaning and Maintenanc
e
Features············································
Name of Each Component / Accessories ····
Operating the Touch Operation Panel ····
Safety Precautions ··························
Cautions on Use ······························
Air Cleaner Deodorizing Performance ···
Preparations for Operation·············
Setting Filter in Unit ····························
Installation········································
E-2
E-4
E-6
E-8
E-13
E-14
E-14
E-16
Operation··········································
Starting Operation ····································
Switching Airflow Rate ······························
Useful Features································
Operating in Option···································
Eco Saving Operation·······························
PM2.5 Sensor···········································
Stopping Operation Using Off-timer··········
Setting the Lock········································
Memory Function / Sensors /
Auto Detection ·································
Memory Function······································
Air Sensor·················································
Odor Sensor ·············································
Dust Sensor··············································
Auto Detection ··········································
Adjusting Sensory Sensitivity Setting ·······
E-17
E-17
E-17
E-18
E-18
E-19
E-19
E-19
E-20
E-21
E-21
E-21
E-22
E-22
E-21
E-21
Cleaning ···········································
Pre-filter, Filter ··········································
Purifier ······················································
Dust Sensor··············································
Replacing the Filter ·························
Replacement Interval································
Handling the Filter·····································
How to Replace the Filter ·························
Troubleshooting Guide ···················
Replacement Parts ··························
Specifications ··································
E-23
E-23
E-24
E-24
E-25
E-25
E-25
E-26
E-27
E-29
E-29
Before Use Operating Air Purifier Cleaning and Maintenance
E-13
EP-NZG70J_EN.indd 3EP-NZG70J_EN.indd 3 6/30/2017 10:32:286/30/2017 10:32:28

E-4
Name of Each Component / Accessories
Names of Each Component
CAUTION
 Do not subject the glass panel
(made of tempered glass) to impact
Although tempered glass is
stronger and safer than normal
glass, it can break when subject
to strong impact or force.
In case of scratches or breakage,
stop using and immediately
request repairs.
Refrain from touching the broken
glass.
Power plug Power cord
Handle
Air inlet
CAUTION
Do not hold the flaps when
moving the unit.
Doing so may cause unexpected
injury when the unit is damaged
and overturned or dropped.
Air outlet
(stainless steel net)
Glass panel
Power button
Purifier
Touch Operation
Panel (P.E-6, E-7)
Flap
Caster
To prevent falls, the movement is
only in sideways direction. (Located
at the base of the unit)
EP-NZG70J_EN.indd 4EP-NZG70J_EN.indd 4 6/30/2017 10:32:286/30/2017 10:32:28

E-5
 (P.E-) Numbers are pages containing the main description each parts.
Pre-filter
(x1)
Accessories
Filter
CAUTION
Filter (x1)
Housed inside the purifier.
The filter must be removed from the plastic packaging before
operating the unit.
The vibration during transporting the unit might cause deodorizing agent granules
to fall out from the filter.
When removing the plastic cover of the filter and attaching the filter to the unit,
make sure that your hands, clothes, and the surroundings will not get dirty.
Wipe of any granules that may have fallen or clung to the filter.
This will not affect the deodorizing performance.
*
Senses the presence of cigarette
smoke, dust, pollen, and other
similar air contaminants.
Dust Sensor (P.E-21)
Rear panel
Odor Sensor (P.E-21)
Senses the odor components in the air.
Set in the outer part of the unit.
Filter
(Allergen-free, HEPA filter)
Pre-filter
Removes large size dust.
Name of Each Component / Accessories
EP-NZG70J_EN.indd 5EP-NZG70J_EN.indd 5 6/30/2017 10:32:286/30/2017 10:32:28

E-6
Operating the Touch Operation Panel
The indicator lights up when the child lock is set. (P.E-20)
The indicator lights up when the unit is operating on timer. (P.E-19)
The indicator lights up when the unit is operating with PM2.5 sensing. (P.E-19)
MENU
Touch this button first when the
display or operation panel is off.
When tapped again, it turns off the
display or operation panel.
Lock
(Long-press MENU for about 3 seconds)
Use this to prevent incorrect
operation. (P.E-20)
Note
The touch operation panel is made of glass.
If the touch operation panel display disappears, touch to display it again.
The touch operation panel display will disappear when is touched again.
The upper part of the touch operation panel is the display section and the lower part is the control section.
Use the touch operation panel to switch settings.
Notification Display
The glass touch may have a different reaction depending on the sur-
rounding temperature and humidity, physical condition of the user, and
the condition of the electronic appliances near by the unit.
If it does not respond after touching, release and try again.
If the interval between touches is short, the unit may respond incorrectly.
The sensitivity will not change by the force applied when touching.
There may be no response if the operation panel is wet or dirty.
Wipe off with a dry cloth to use.
The display may be difficult to view if the unit is placed in brightly lit
places such as near a window with direct sun light.
EP-NZG70J_EN.indd 6EP-NZG70J_EN.indd 6 6/30/2017 10:32:286/30/2017 10:32:28

E-7
Operating the Touch Operation Panel
Off-timer (P.E-19)
Use this to set the off-timer.
Airflow (P.E-17)
Use this to switch the
airflow rate.
Air Sensor (P.E-21)
Display
Operation
Panel
The level of air contamination detected
by the odor and dust sensors is
indicated through different colors.
Option (P.E-18)
Use to switch to quick cycle.
EP-NZG70J_EN.indd 7EP-NZG70J_EN.indd 7 6/30/2017 10:32:286/30/2017 10:32:28

E-8
Safety Precautions
Please read the following safety precautions carefully before using the unit.
To prevent injury to the user or other people and property damage, the following instructions must
be followed. Also read the precautions appearing in the text carefully to ensure correct use.
Definition of each indication
Incorrect operations that are carried out as a result of ignoring instructions will cause harm or dam-
age. The seriousness is classified by the following indications.
WARNING
CAUTION
This symbol indicates the
possibility of death or se-
rious injury.
This symbol indicates
the possibility of injury or
damage to property.
Meaning of Symbols
Indicates “warning or caution”.
Indicates “prohibition”.
Indicates “necessity”.
WARNING
To Prevent Fire, Electric Shock and Injury
AC Outlet, Power Plug and Power Cord
Remove dust from the blade and the blade mounting surface of the power plug.
Otherwise, it may cause a fire.
Be sure to unplug the power cord from the AC outlet when cleaning or not using the
unit for an extended period of time.
Otherwise, it may cause an electric shock or injury.
Be sure to hold the plug when unplugging it.
Otherwise, it may cause an electric shock or short-circuit, which may result in a fire.
Securely insert the power plug into the AC outlet.
Otherwise, it may cause an electric shock, overheating or fire.
Do not stop operation by unplugging the power plug.
Otherwise, it may cause fire, electric shock or malfunction.
Never plug or unplug the power plug with wet hands.
Otherwise, it may cause an electric shock.
Do not use a damaged power cord or power plug, or a loose AC outlet.
Otherwise, it may cause an electric shock, short-circuit or ignition.
Do not damage the power cord.
(Do not break, modify, forcibly bend, pull or twist it. Also do not place any heavy objects on it,
pinch it, or step on it when moving it with the caster.)
Otherwise, it may cause damage to the power cord, fire or ignition.
Make sure to avoid inserting too many plugs into the AC outlet.
Otherwise, it may cause fire or ignition.
Do not immerse the power plug in water, or pour water on it.
Do not use a power plug when wet.
Doing so may cause ground leakage, electrical shock and unit failure.
If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
Do not use with a voltage other than 220-240V AC.
Otherwise, it may cause a fire or electric shock.
EP-NZG70J_EN.indd 8EP-NZG70J_EN.indd 8 6/30/2017 10:32:296/30/2017 10:32:29

E-9
WARNING
Before Use
Ventilate the room frequently when in use with heating appliances.
Otherwise, it may cause carbon monoxide poisoning.
This product cannot remove carbon monoxide.
Do not block the air outlet or air inlets with laundry, cloth, curtains, etc.
Poor ventilation may cause overheating or fire.
Do not use flammable materials (hair sprays, insecticides, air fresheners, etc.) near
the unit.
Do not use benzene, thinner or alcohol to clean the purifier.
Otherwise, it may lead to cracking, electric shock, ignition, smoke or fire.
Do not use in a kitchen as a substitute for a ventilation fan and range hood fan.
Otherwise, it may cause unit deformation by heat or it may ignite a fire in the filter.
Also, it may cause failure or a decrease in the lifespan of the pre-filter, filter assembly and deodorizing
filter.
Keep away from lit candles, mosquito coils, lit cigarettes, etc. Also, do not let smoke
from these materials enter the unit.
Otherwise, it may cause fire.
Do not operate the unit when using fumigating (smoking) type insecticide. Do not let
chemicals enter the unit.
Use of such insecticides will cause chemicals to accumulate in the unit and depending on a
person’s sensitivity to these chemicals, it may be harmful to one’s health.
Do not place in a location where the air from the outlets will blow directly onto heat-
ing appliances.
Otherwise, it may cause incomplete combustion and carbon monoxide poisoning.
Do not use in narrow spaces such as gaps between the furniture or closet.
Poor ventilation may cause overheating or fire.
Do not operate the unit while filter, etc. is detached.
Otherwise it may cause injury or failure.
Do not tilt or tip the unit over. Do not put your weight on the unit or step on it.
Also, do not use it in an unstable place or anywhere near infants.
Otherwise, it may cause the unit to tip over due to vibration, which may cause an injury or unit
failure.
Cleaning
When cleaning, do not splash water on the unit.
It may cause short-circuiting and electric shock.
Do not add water by submerging or splashing water on the unit.
It may cause short-circuiting and electric shock.
Safety Precautions
EP-NZG70J_EN.indd 9EP-NZG70J_EN.indd 9 6/30/2017 10:32:296/30/2017 10:32:29

E-10
Safety Precautions (Continued)
WARNING
Place of Use
Do not use in a location where there is huge amount of oily smoke such as in cafete-
rias and eateries.
The oil residue or dust deposited in the unit may cause fire, unit failure and unpleasant odor.
Do not use in a location where there is flammable gas, corrosive gas or metallic
dust, or risk of leakage of oil, flammable gas.
It may cause fire, explosion or unit failure.
Do not use in a location where solvents such as paint and adhesives are being used
or stored.
It may cause deterioration of parts or fire.
Do not use in a location where soot from oil, such as machine oil, is floating in the
air.
It may cause a crack, electric shock or fire.
Do not use in a location where any chemical is used. (Hospitals, factories, laborato-
ries, beauty salons, photographic laboratories, etc.)
Chemicals and solvents evaporating into the air deteriorate the unit. This causes electric shock.
Do not use in a humid place or in a place where it may easily be wet, such as in a
bathroom.
It may cause electric shock or fire due to ground leakage.
Do not place it near a hot object such as a heater.
It may cause deformation, discoloration, injury and unit failure.
Do not put in places exposed to direct sunlight, wind and rain.
It may cause overheating, electric shock and fire due to ground leakage.
Do not use in a location where a machine tool that produces flammable dust or
sparks (such as a grinder or welder) is installed.
It may cause fire.
Miscellaneous
Even after switching on, sometimes the air purifier is inoperative or air does not
come out. There may be “cracks” and “scratches” in the power cord, or the unit has
been moved which causes the operation to stop. There may also be unusual noise
and vibration during operation. The unit may be deformed and unusually hot. There
may be a burnt odor. If there are abnormalities aside from those mentioned, unplug
the power cord immediately to prevent accidents and contact your dealer to request
for checks or repairs.
These may cause fire due to electric shock, ground leakage or short-circuiting.
Pay specific attention when the user of the air purifier is the following:
(Infants, children, the elderly, those who cannot control their body temperature)
When the body is exposed directly to the wind for a long time, health may be compromised.
Cleaning
Do not use detergents when cleaning.
Usage of chlorine-based and acid type detergents will generate toxic gas and can cause a health threat.
Also, do not use neutral detergents as it may affect the plastic.
EP-NZG70J_EN.indd 10EP-NZG70J_EN.indd 10 6/30/2017 10:32:296/30/2017 10:32:29

E-11
Miscellaneous

Do not put your finger or any other object (metal, paper, etc.) into the air inlet or outlet.
It may cause injury, electric shock and fire.
Never attempt to disassemble, modify or carry out repairs by yourself.
It may cause fire, electric shock or injury. (Contact your dealer for repairs)
Do not operate detection switches (for the dust filter and rear panel) using your fin-
gers, rod, or tape.
Doing so may result in an injury, failure, or unexpected accident.
Children should be supervised to ensure that they do not play with the appliance.
CAUTION
Moving the Air Purifier
Move only in sideways direction with the caster (to prevent from falling).
There are cases when the floor may be damaged based on the type of flooring.
Unplug the power cord from the AC outlet.
Lift the air purifier when moving it along a mat, a floor susceptible to scratches, an
uneven floor or a thick carpet.
It may damage the mat, floor and carpet and may cause unit failure and injury when tipped over.
When carrying the air purifier, hold the handle firmly.
If you hold parts other than the handle, the unit may tip over and be damaged, and may cause
an accident.
Unplug the power cord from the AC outlet.
When moving the unit without unplugging, the power plug and power cord may be damaged.
Do not touch, hold, or lift the moving flap.
It may cause an injury and unit failure.
When carrying the air purifier, hold the handle.
Do not pull the power cord when moving the unit.
It may damage the power cord.
Place of Use
Do not use the air purifier near a wall that cannot be scrubbed, such as a white
cloth-covered wall.
The air purifier will take in the surrounding air and may stain a wall near its air outlet.
Do not use in storerooms for artworks and academic materials, or for other business
purposes.
It may deteriorate the quality of the stored products.
Do not put water containers such as flower vases and fish bowls on top or near the
unit.
Water deposited in the unit may cause electric shock, fire and unit failure.
Do not use in locations near cooking appliances.
It may cause deterioration of parts, electric shock and fire due to heat and oily smoke.
Do not use on floors susceptible to scratches such as Cypress floors.
It may damage the floor.
Safety Precautions
WARNING
EP-NZG70J_EN.indd 11EP-NZG70J_EN.indd 11 6/30/2017 10:32:296/30/2017 10:32:29

E-12
Safety Precautions (Continued)
CAUTION
Miscellaneous
Do not move or stop the flap by hand or by any object
Otherwise, it may cause unit failure.
If using the purifier around pets, do not subject any parts to urine and keep pets
away from the power cord
Otherwise it can cause electric shock and fire. If there are damages, unplug and request repairs.
Do not subject the glass panel (made of tempered glass) to impact
Although tempered glass is stronger and safer than normal glass, it can break when subjected
to strong impact or force.
In case of scratches or breakage, stop using and immediately request repairs.
Refrain from directly touching the broken glass.
Use only a genuine filter for the Hitachi Air Purifier
Other filters may cause unit failure.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, un-
less they have been given supervision or instruction concerning use of appliance
by a person responsible for their safety.
Cleaning
Perform panel removal and installation carefully.
It may cause injuries such as pinching your fingers.
When cleaning, lay a soft cloth on the floor and place the unit and detached parts
(panel, etc.) on it
Otherwise, it may scratch the floor.
Attach the parts securely after cleaning
Do not use with the rear panel, pre-filter, filter, and any other parts detached. Otherwise, it may
cause unit failure.
EP-NZG70J_EN.indd 12EP-NZG70J_EN.indd 12 6/30/2017 10:32:296/30/2017 10:32:29

E-13
Cautions on Use
Do not operate with the filter detached
Otherwise, no cleaning effect can be expected. It
may also cause unit failure.
Do not block or touch the odor and
dust sensors
It may reduce the sensitivity of the sensors.
Do not directly fan plants and animals
It may adversely affect them.
Refrain from moving (changing the orienta-
tion or lifting the unit, etc.) during operation
Moving the unit while in operation may cause the fan
to hit the inner case, generate noise, pull and discon-
nect the power cord, and cause unit failure.
Do not use in locations near cooking appliances
It may cause deformation and dis-
coloration due to heat or oily smoke,
unit damage or fire.
Place the purifier and the cooking appli-
ance at least 1m apart from each other.
Ventilate closed rooms occasionally
The purifier does not have
a ventilation effect (remov-
al of carbon monoxide
and other contaminants).
* The purifier cannot re-
move harmful substanc-
es in cigarettes (carbon
monoxide, etc.).
Refrain from placing any ob-
ject on the unit and blocking
the air inlet and outlet
Doing so may cause unit failure
and injury.
Do not use near television or radio
Doing so may interfere with
broadcasts.
Please them at least 2m apart
from each other.
The same applies for cord-
less phones and wireless mi-
crophones.
Safety Precautions Cautions on Use Air Cleaner Deodorizing Performance
Air Cleaner Deodorizing Performance
The filter of the air purifier does not remove all odors at once, but rather circulates the air in the room, re-
moving odors gradually.
The filter is disposable. The deodorizing performance of the filter decreases with use.
When the odor emitted from the vent becomes bothersome, clean the filter. (P.E-23)
When the filter has absorbed strong odors or has been continually used in an odorous room, the odor com-
ponents remain in the filter and unit, causing the odor to be emitted from the vent.
If this happens, you can decrease the amount of odor that remains in the unit by continuing to operate the
purifier while ventilating the room.
The dust and other contaminants attached to the filter and unit also contain odor components.
Periodically clean the filter and unit so that odor is less likely to be emitted from the vent. (P.E-23, E-24)
If the odor emitted from the vent remains bothersome after cleaning, replace the filter. (P.E-25)
EP-NZG70J_EN.indd 13EP-NZG70J_EN.indd 13 6/30/2017 5:08:48 PM6/30/2017 5:08:48 PM

E-14
Preparations for Operation

Movement with casters should be done slowly. The movement is only in sideways direction. (To prevent from falling)

No cleaning effect will be experienced if the filter is set without detaching the plastic cover. It will also cause unit failure.
Do not tip over or tilt the unit.
Setting Filter in Unit
Setting procedure is the same with filter replacement. (Use only genuine Hitachi Air Purifier filters.)
Remove the filter
1
2
3
Remove the filter from the
unit.
Remove the filter from the
plastic packaging.
Remove rear panel and pre-filter
Place the unit on a flat and stable location.
Remove the pre-filter.
4
Hold the bottom part of the rear panel
(2 locations), pull it out gently, and shift
slightly upward to remove it.
Slide the switch upwards (2 locations)
to release the lock.
Switch
Slide the switch upward.
Pre-filter
Plastic packaging
Filter
Filter
Filter
CAUTION
Install the filter to the unit
Do not put excessive force and deform
the filter.
Set the filter so that you can see the label
CAUTION
EP-NZG70J_EN.indd 14EP-NZG70J_EN.indd 14 6/30/2017 10:32:306/30/2017 10:32:30

E-15
5
4Install the pre-filter to the unit
Securely plug the tabs of the pre-filter to the matching holes in the unit.
Slide the switch downwards (2 locations) to lock.
Gently pull the pre-filter to make sure it is not out of place.
Pre-filter
Switch
Slide the switch downward.
Plug the tabs of the pre-filter
Tab
Insertion hole
Attach the rear panel to the unit
Plug the tabs (2 locations) of the
upper part of the rear panel to
the matching holes in the unit.
Gently push the bottom sides of
the panel one after another, and
close it securely until it clicks.
Insert to the hole
Preparations for Operation
EP-NZG70J_EN.indd 15EP-NZG70J_EN.indd 15 6/30/2017 10:32:306/30/2017 10:32:30

E-16
Installation
A caster is attached at the base of the unit, thus it should be set on an even, stable and sturdy floor.
(No stopper attached to the caster)
Avoid places near heating or cooling equipment and other similar equipment, and choose a location with a good air
circulation.
Keep the rear at least 3cm away from the wall. Depending on the operating environment, walls or floors near the
outlet may be stained as the unit draws in air. If this is a concern, move it from its current location and clean the sur-
rounding walls and floors regularly.
Be sure to provide space around the sides of the unit so that the inlets and vents are not blocked by curtains or
furniture.
WARNING
Do not place on shelves, desks, tables or other similar places
Unit may fall due to vibration or tilting, and may cause injury and electric shock.
Moving the unit with the caster can be done on a sturdy and even floor. To move the unit on a mat,
carpet, or places with uneven surface, carry the unit by its handle.
Be careful not to pull or pinch the power cord.
Leaving the unit at the same place for an extended period of time may leave stains on the walls and floors.
When cleaning the unit, move it to another place and also include cleaning the floor.
* Leave space * Leave space
At least 3cm
*Air inlet and outlet must not
be covered by curtains or
furnitures
EP-NZG70J_EN.indd 16EP-NZG70J_EN.indd 16 6/30/2017 10:32:306/30/2017 10:32:30

E-17
Operation
Starting Operation
Securely insert the power plug to the outlet
1
2Press the power button
Operation will start, and indicator
will light up.
Pressing the power button
while the unit is operating will
dim the indicator and stop the
operation of the unit.
After all indicators have light up at once,
“Auto” will light up.
For the first 3 minutes, the unit will
check and store the condition of the
room air.
During that time, the “Air Sensor” will
flash a green light.
Blinking
Power button
“Air Purify” mode is set as a factory default.
From the second use onward, the memory function enables operation based on the saved status. (P.E-21)
For power saving, the display and operation panel other than the notification display and the air sensor will turn off
approximately one minute after the unit stops operating.
Standby Power Consumption
As long as the power plug is inserted in the outlet, the unit consumes approximately 2W of power, even if the unit
is not in use.
(Unplug from the outlet if the unit will not be used for an extended period of time.)
Installation Operation
Switching Airflow Rate
Each time Air
flow button is pressed while the unit is operating, the mode switches in the following order.
Airflow
“Medium” “High”“Silent” … MaxAuto Auto
EP-NZG70J_EN.indd 17EP-NZG70J_EN.indd 17 6/30/2017 10:32:306/30/2017 10:32:30

E-18
Operating in Option
Rapid
For the first hour, the unit operates in “High” airflow rate, and depending on the level of air contamination, the unit
will operate in either “High” or “Medium” airflow rate. For approximately 8 hours, room air will be forcefully circulated
in “High” airflow rate for approximately 10 minutes once every hour. Sensitivity of odor sensors will increase, and de-
pending on the level of air contamination, the unit will operate in either “High” or “Medium” airflow rate. Afterwards,
high-speed will be deactivated and the airflow rate will return to its previous “Auto” operation mode.
Use this when grilling, cooking hot pot, or in similar instances where the room is exposed to a great deal of strong
odor.
Odor
Once every hour, room air will be forcefully circulated in “High” airflow rate. Sensitivity of odor sensor will increase,
and depending on the level of air contamination, the unit will operate in either “High” or “Medium” airflow rate.
Use this regularly for environments with strong odors such as garbage, drainage, pet and other similar odors.
You can select Option while operating.
The Quick Cycle will be switched at each touch.
Touch the button
(If it returns to No Display (Clear), it is in [Auto] airflow)
Option
Pollen Odor Rapid AbsenceNo Display (Clear) PM2.5 sensor
Useful Features
Pollen
Once every hour, room air will be forcefully circulated in “High” airflow rate. Sensitivity of odor and dust sensors will
increase, and depending on the level of air contamination, the unit will operate in either “High” or “Medium” airflow
rate. The flap direction will be diagonal.
Use this when worried about pollens getting into the air.
Absence
The unit will operate on “Max” airflow rate for the first five minutes (flap direction: upward), then it will operate for
about 55 minutes in “High” airflow rate (flap direction: swing (30 minutes) upward), and the unit will stop operating
afterwards.
Use this to clean the room air while away.
The unit automatically stops operation when the air becomes clean, saving electricity cost. (P.E-19)
(Eco Saving Operation)
PM2.5 sensor
Switch to sensing that is suitable for small particles, like PM2.5 (general term for micro particles below 2.5µm).
(P.E-19)
EP-NZG70J_EN.indd 18EP-NZG70J_EN.indd 18 6/30/2017 10:32:306/30/2017 10:32:30

E-19
Useful Features
Eco Saving Operation
The unit automatically stops operation when air becomes clean, saving electricity cost.
Also, if this status continues for longer than 8 hours, the unit will automatically stop operating.
Normal Auto Operation
When the air is clean, the unit will continuously operate in “Silent” airflow rate and not stop.
Eco Saving Operation
When the air is clean and “Silent” airflow rate operation continues for 10 minutes or longer, the fan stops for about
50 minutes and the unit intermittently operates using “Silent” for about 10 minutes.
If this status continues for longer than 8 hours, the unit will automatically stop operating.
* During eco saving operation, the level of air contamination is detected by the odor and dust sensors. When the
sensors detect odors and dust, the airflow rate will switch depending on the level of air contamination.
When the air is clean and the “Silent” airflow rate operation continues for 10 minutes or longer, the unit will start
intermittent operation again.
Stop
10 minutes
50 minutes 50 minutes
10 minutes 10 minutes
“Silent” Airflow
Operation
PM2.5 Sensor
Note
Operation modes other than “Air Purify” cannot be set.
While operating in PM2.5 sensing, the air sensor will light up, then enlarge and shrink slowly.
For the first 90 seconds of operation, the unit will operate in “Max” airflow rate (air sensor: red).
The flap direction will be diagonal.
It will not respond to the switching of sensor sensitivity. (P.E-22)
Change into a sensor that is suitable for small particles, like PM2.5 (general term for micro particles be-
low 2.5µm). The level of contamination in the air will be detected by the dust sensor, and the unit will op-
erate automatically between “Medium” to “Max” airflow rate.
(Odor sensor control will not be performed)
Stopping Operation Using Off-timer
Touch to set the timer.
At each touch the following display will be appear on the display for setting.
No Display 4hr
Timer
Display Setting Description
No Display
Automatic stop after about 4 hours of operation4hr
Not Set
Set the off-timer to automatically stop the unit after the set operation time.
EP-NZG70J_EN.indd 19EP-NZG70J_EN.indd 19 6/30/2017 10:32:306/30/2017 10:32:30

E-20
Setting the Lock
Prevents accidental operation by children through restricting the operation.
This can be set while the unit is operating.
The same process goes for unlocking the unit.
Long-press for about 3 seconds
1
To cancel the child lock, long-press for about 3 seconds.Then the buzzer will ring
twice (beep, beep), and the child lock will be canceled.
Each time is long-pressed for about 3 seconds, the child lock be set or cleared.
The light will go off when the child lock is canceled.
After long-pressing for about 3 seconds, a buzzer will ring once (beep) and the
child lock indicator will lit.
·
Lock
Indicator
Note
After setting “Lock”, no other buttons can be used except the power button and .
In the event of a power interruption, restoring the power does not deactivate the child lock setting, even after
pressing the power button and after removing the power plug from the outlet. Hold for 3 seconds
and cancel the settings.
Useful Features (Continued)
EP-NZG70J_EN.indd 20EP-NZG70J_EN.indd 20 6/30/2017 10:32:316/30/2017 10:32:31
