Hitachi iH-110 Series User manual

Are you searching for a high efficient banknote detector?
Then look no further!
iH-110 is a machine to obtain all your needs and requirements.
It can accurately count notes and safely detect counterfeit all at high speed operation.
This compact machine performs more than you might imagine.
Experience one for yourself and you will find your search is finally over!
Rev. 2.0.0
Date: 2017. 10. 23
Cash Counter & Discriminator

iH-110 User Guide
Hitachi Terminal Solutions Korea Co., Ltd. 2
- Contents –
Introduction .................................................................................................................................3
For Safety Use...............................................................................................................................3
Packing List.................................................................................................................................10
Options........................................................................................................................................10
Series...........................................................................................................................................10
Appearance.................................................................................................................................11
Before Using ...............................................................................................................................12
1. Key Operation .........................................................................................................................13
2. Display Operation ...................................................................................................................16
3. Normal Operation
3-1. Basic Count Mode (Mix/SP/SG) .........................................................................................17
3-2. SN Reading........................................................................................................................19
3-3. Barcode Reading................................................................................................................20
3-4. Check Reading (MICR) ......................................................................................................21
3-5. FITNESS............................................................................................................................21
3-6. Multi Mix.............................................................................................................................24
3-7. Multi SC .............................................................................................................................25
3-8. Bookmark...........................................................................................................................26
4. Machine Settings
4-1. ETC....................................................................................................................................27
4-2. Operation...........................................................................................................................35
4-3. System Setting...................................................................................................................38
4-4. Comm. Info.........................................................................................................................41
4-5. USER Setting.....................................................................................................................47
4-6. Local Setting ......................................................................................................................48
4-7. Machine Info.......................................................................................................................49
5. Machine Status........................................................................................................................50
6. Specification............................................................................................................................52
7. Error Code...............................................................................................................................53
8. Maintenance............................................................................................................................55

iH-110 User Guide
Hitachi Terminal Solutions Korea Co., Ltd. 3
Introduction
Thank you for purchasing iH-110.
The iH-110 is the new paradigm of counterfeit detection so your banknotes will be safe, and has
added many functions and options to make your duties even easier.
The iH-110 is an enhanced high speed banknote counter that has accurate OCR (up to 800
notes/min) for reading the serial numbers on banknotes.
Through a visible 4.3 inch color Graphic LCD, convenient audio alert, LAN/USB for
networking/upgrading, flexibly designed menu, GUI, and duplicated keys for two tellers, the iH-110
offers a highly convenient and easy operation.
Safety Guidelines
In this section, the compliance matters are described in order to use the product safely,
and to prevent you and other people from the damages brought by the product to
the human bodies or properties.
Please read this instruction manual thoroughly in advance to use in the correct way.
Warning
Caution
It denotes the contents in which mishandling of the product by
neglecting this indication may cause people light injury or, physical
damage.
It denotes the contents in which mishandling of the product by
neglecting this indication may cause people serious injury.

iH-110 User Guide
Hitachi Terminal Solutions Korea Co., Ltd. 4
This symbol indicates that the precautions for handling the product.
Please read the indications well and utilize the product safely.
This symbol indicates prohibited matters, do not attempt. Please
read the indications well. Never try any prohibited matters.
This symbol denotes that there are indication matters which should be
done without fail. Please read the indicated matters thoroughly and
always perform them as shown.

iH-110 User Guide
Hitachi Terminal Solutions Korea Co., Ltd. 5
Warning
Installation
1. At installation and relocation of the products, please contact our distributor near
you or our designated dealers. If installation is not perfect, there is a risk of a falling
accident, electric shock, fire, or burn injury.
2. At installation and use of the products, keep the space sufficient for opening and
closing the door, cover and operation. If a part of the product touches a human body
incorrectly, it may cause an accident.
3. In case of installing the product at the following places, you should confirm the
Road Law, Road Traffic Law and Fire Protection Law, etc. If compliance conditions
are not clear, please consult with the authorities concerned.
- The place which may disturb traffic or accident prevention.
- The place adjacent to the fire extinguishing and detecting apparatus.
- The place adjacent to the road signs or traffic signals.
- The place where combustible materials or gas are treated (gas stations, etc.)
Passages and facilities for evacuation Illegal installation may cause an accident.
4. Keep an installation space as described in the instruction manual, and do not
block or close the ventilation inlet. If the ventilation inlet is blocked, heat is
accumulated inside and it may cause fire.
5. Depending on the installation place, mounting of an earth leakage breaker is
required by Electricity Enterprises Law. Illegal installation may cause an accident.
1. Do not install the product in any place where water may spill on it. If water enters
into the product, insulation performance degrades and it may cause fire and/or
electric shock.
2. Do not install the product at the place where the floor cannot bear the load of the
product, or at any unstable place with inclination and/or irregularity. It may cause
floor caving and sudden movement accidents of the product to occur.
3. Installation at the following places should be avoided:
- 1m or less from volatile combustible materials or curtains.
- 1m or less from heating apparatus such as stoves, heaters etc.
- Any place with direct winds blown from air conditioners, ventilating openings
etc.
- There are safety problems and deterioration of the product may be
accelerated, which leads to any cause for failure.

iH-110 User Guide
Hitachi Terminal Solutions Korea Co., Ltd. 6
Grounding work should be made for safety and prevention of static electricity and
noise failure. In addition, a ground wire should be installed independently without
sharing the wire with other products. At grounding work, please be sure to contact
our distributor near you or our designated dealers. In case of electrical leakage
when grounding is insufficient or not connected, it may cause fire and/or electric
shock.
The place where a ground wire can be fitted:
- Ground terminals for power receptacle.
- The copper piece etc. with a length of 65 cm or more, buried in the ground.
- The ground terminals on which grounding work is made.
The place where is a ground wire must not be fitted.
- Gas pipes
- Telephone wires for exclusive use
- Lightning rods
- Water pipes or faucets with plastic materials at their intermediate part.
-Any place with high temperature, high humidity, or low temperature.
-Any place with direct sunlight.
-Any place with large amounts of dust.
When installing the product at the following places, please contact our distributor
near you or our designated dealers.
-Any place exposed to salty winds or corrosive gas.
-Any place with a large amount of swinging or vibration.
Do not use or put the combustible materials such as thinner, combustible gas, or a
high-volatile object around/inside the product. Otherwise, it may cause explosion
and/or fire due to heating from the product or flashing from power supply..

iH-110 User Guide
Hitachi Terminal Solutions Korea Co., Ltd. 7
Warning
Power Supply
1. When using the product, connect it to the power supply specified in the instruction
manual. If it is connected to the power supply, other than the product’s specification,
it may become a cause of fire, electric shock, and/or electrical leakage.
2. Do not use a power supply cord and the plug other than the attached ones. If a
current that exceeds the rating flows in the power supply cord, it may cause fire.
3. Be sure to insert the blade part of the power supply plug into an outlet. Insufficient
insertion may cause fire.
1. When the earth leakage breaker frequently operates, please contact our
distributor near you or our designated dealers. If the product is used or left as it is, it
may cause fire and/or electric shock.
2. Do not modify, process, or repair the power supply cord and the plug. In addition,
do not convert a 3-prong power supply plug into a two-pole type. Grounding
becomes insufficient and there may cause electric shock.
Please follow the items below to prevent electric shock and/or fire due to damage
of the power supply cord.
- Do not pull the cord part when pulling out the power supply plug.
- Do not put anything on the cord part.
- Do not pass the cord near a source of heat.
- Do not bend or pinch the cord.
- Do not tread or twist the cord.
- Do not spill chemicals on the cord.
- Do not use it while it is bundled.
- Do not fix it with a stapler etc.
1. Do not use the power supply cord and the plug for other products or purposes.
Further, when they are lost or damaged, please purchase them at our distributor
near you or our designated dealers. The attached power supply cord and the plug
are designed and confirmed the safety for connecting to this product to use. If
they are used for other products or purposes, it may cause fire and/or electric
shock.
2. The product should be used at the specified frequency. If it is used at other than
the specified frequency, it may cause an accident.

iH-110 User Guide
Hitachi Terminal Solutions Korea Co., Ltd. 8
Caution
Handling
1. The product should be used under the environment specified in the instruction
manual. If it is used under the other environment of the specification, there may
cause fie and electric shock.
2. When operating inside the product for error or clearing or cleaning etc., the
operation should be made in accordance with the description in the instruction
manual. Operation other than the description may cause an accident.
1. Do not turn off the power, pull out the power supply plug, or open the cover of
the product during the operation. Otherwise, it may cause an accident.
2. Do not put a vase or glass with an object and/or water etc. on the product.
Otherwise, it may cause fire, electric shock, and/or injury by spilling water or
dropping.
3. Do not apply shock on the product. There is a risk of damaging the product and
normal operation cannot be performed.
4. Do not use chemicals such as thinner or benzene when removing dirt of the
product. Otherwise, it may cause damages.
5. Do not use a interface cable other than the attached one. When cables are other
than the attachment, it may cause the interface error or machine trouble.
Do not use a combustible spray etc. around product. If spraying gas etc. contacts
the electrical parts inside the product, it may cause explosion and fire.
1. When touching inside the product for cleaning or parts replacement etc., be sure
to turn off the power. If you work with turning the power on, it may cause electric
shock and/or injury.
2. Do not touch the product, power supply plug, and cord with a wet hand. There is
a risk of electric shock.
3. The electrical parts inside the product should not get wet by rain or water at
cleaning etc. if they get wet, it may cause electric shock and/or shock.
4. Do not turn off air heating suddenly when the product is completely cold.
Moisture may adhere inside the product due to sudden air heating and it may
cause electric shock.

iH-110 User Guide
Hitachi Terminal Solutions Korea Co., Ltd. 9
5. There is a charging part inside. Be sure to turn off the power before opening
any cover. If the cover is opened without turning off the power, it may cause
electric shock.
1. Do not drop any metallic piece such as a clip, staple etc. inside or in a clearance
of the product. If a metallic piece drops inside the product and contacts the electric
circuit, it may cause fire and/or damage to the product.
2. When the product is not use for a long time, be sure to pull out the power supply
plug from an outlet for safety. Otherwise, it may cause heating and/or firing due to
dust accumulation.
Do not modify the product or mount modified parts on the product. Further, do not
dismount the portion which is not indicated to be opened/closed in the manual or
the cover and parts etc. fixed with screws etc. Otherwise, it may cause fire,
electric shock, and/or injury.
1. Keep your hand or clothes away from the machine during operation or any
moving parts of the product reachable. This may cause body injury and/or
damage to personal property.
2. When closing a door, pay attention not to not cause body injury or damage
property.
3. When working ensure that all doors of the machine are locked. If a door is left
open it may cause body injury or damage to property.
Do not touch the gear etc. It may cause injury.

iH-110 User Guide
Hitachi Terminal Solutions Korea Co., Ltd. 10
Warning
Maintenance
1. For repairing the product, please contact our distributor near you or our
designated dealers. Insufficient repair may cause fire, electric shock, and/or injury.
2. When the product has sunk under the water due to a disaster etc., stop using it
and please ask for repair/check to our distributor near you or our designated
dealers. If used as it is, it may cause fire and/or electric shock.
3. Check periodically whether its installation place is unstable or not. If there is any
abnormality, please contact our distributor near you or our designated dealers. If it
is continuously used with insufficient installation, it may cause a falling accident.
4. Check and clean the power supply plug and the cord regularly. It the power
supply plug is broken or the cord is damaged, stop using and please replace it by
contacting our distributor near you or our designated dealers. It may cause fire
and/or electric shock.
When smoke, abnormal smell or abnormal sound is generated from the product,
stop using it immediately, cut off power supply and pull out the plug from the outlet.
Then, please contact our distributor near you or our designated dealers. It used or
left as it is, it may cause fire and/or electric shock.
Warning
1. This is a class A product. In a domestic environment, this product may cause radio
interference in which case the user may be required to take adequate measures.
2. The socket-outlet shall be installed near the equipment and shall be easily accessible.
3. Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries
according to the instructions.
Other
