Hitachi Zaxis 17u-2 User manual

INTRODUCTION

Read this manual carefully to learn how to operate

and service your machine correctly. Failure to do so

could result in personal injury or equipment damage.

This standard specification machine can be

operated under the following conditions without being

modified.

Atmospheric Temperature: −20°C to 40°C (−4°F to

104°F)

Altitude: 0 m to 1500 m (0 ft to 4900 ft)

In case the machine is used under conditions other

than described above, consult your nearest Hitachi

dealer.

This manual should be considered a permanent

part of your machine and should remain with the

machine when you sell it.

This machine is of metric design. Measurements in

this manual are metric. Use only metric hardware and

tools as specified.

• SI Units (International System of Units) are used in

this manual.

For reference MKS system units and English units

are also indicated in parentheses after the SI units.

Example : 24.5 MPa (250 kgf/cm2, 3560 psi)

Right-hand and left-hand sides are determined by

facing in the direction of forward travel.

Write product identification numbers in the

Machine Numbers section. Accurately record all the

numbers to help in tracing the machine should it be

stolen. Your dealer also needs these numbers when

you order parts. If this manual is kept on the machine,

also file the identification numbers in a secure place off

the machine.

Warranty is provided as a part of Hitachi's support

program for customers who operate and maintain their

equipment as described in this manual. The warranty

is explained on the warranty certificate which you

should have received from your dealer.

This warranty provides you the assurance that Hitachi

will back its products where defects appear within the

warranty period. In some circumstances, Hitachi also

provides field improvements, often without charge to

the customer, even if the product is out of warranty.

Should the equipment be abused, or modified to

change its performance beyond the original

factory specifications, the warranty will become

void and field improvements may be denied.

Setting fuel delivery above specifications or otherwise

overpowering machines will result in such action.

Only qualified, experienced operators officially

licensed (according to local law) should be allowed to

operate the machine. Moreover, only officially licensed

personnel should be allowed to inspect and service the

machine.

Prior to operating this machine in a country other than

a country of its intended use, it may be necessary to

make modifications to it so that it complies with the

local regulatory standards (including safety standards)

and legal requirements of that particular country.

Please do not export or operate this machine outside

of the country of its intended use until such compliance

has been confirmed.

Please contact Hitachi Construction Machinery Co.,

Ltd. or any of our authorized distributor or dealer if you

have any questions concerning compliance.
