Hitachi UST-5550 User manual

i
Notes for operators and responsible maintenance personnel
★
Please read through this Instruction Manual carefully prior to use.
★
Keep this Instruction Manual together with the ultrasound diagnostic instru-
ment for any future reference.
© Hitachi, Ltd. 2013, 2017. All rights reserved.
Intraoperative Electronic Linear Probe
UST-5550 (Compatible with waterproof cover)
Instruction Manual
M N1-5575 Rev.11

MN1-5575 Rev.11
ii

iii
MN1-5575 Rev.11
This is an instruction for model UST-5550, an ultrasound probe.
Read the manual carefully before using the instrument. Take special note of the items in section 1, "Safety
Precautions".
Keep this manual securely for future reference.
The CE mark on the probe indicates that this probe is valid when it is connected to equipment
bearing the CE mark that is specied as available in section 2 of this document. Therefore, if a
probe bearing the CE mark is connected to equipment that is specied as available but does not
have a CE mark, part of this instruction manual may not apply.
Symbols used in this document
The terms below are used in the safety information provided to prevent hazards and injuries to the operator
or patients. The severity of the hazard and injury that can occur when failing to observe the displayed safety
information are indicated in four levels: "Danger", "Warning", "Caution"and "Note".
Danger
Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury to
the operator or patient.
War ning
Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury to
the operator or patient.
Caution
Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury to
the operator or patient, or property damage only.
Note
Indicates a strong request concerning an item that must be observed in order to prevent damage or
deterioration of the equipment and also to ensure that it is used efciently.
The type of safety information is indicated by the symbols below.
This symbol means attention is required.
This symbol means that the described action is prohibited.
This symbol means the described action is mandatory.
Introduction

MN1-5575 Rev.11
iv
CONTENTS
1. Safety Precautions
1-1. Intended use.....................................................................................................................1
1-2. Usage precautions.............................................................................................................1
1-2-1. Warnings and safety information ....................................................................................2
1-2-2. Cleaning, disinfection and sterilization precautions............................................................4
1-2-3. Labels........................................................................................................................6
2. Specications and Parts name
2-1. Principles of operation....................................................................................................11
2-2. Specications..................................................................................................................12
2-2-1. Specications of the probe..........................................................................................12
2-2-2. Specications of the protect tube ..................................................................................13
2-3. Performance....................................................................................................................14
2-4. Names of each parts........................................................................................................14
2-5. Environmental conditions..............................................................................................15
2-5-1. Operating environmental conditions ............................................................................15
2-5-2. Storage environmental conditions ...............................................................................15
2-6. Classication of ME equipment .....................................................................................15
3. Preparations for Use
3-1. Start up check .................................................................................................................17
3-1-1. Visual check .............................................................................................................17
3-1-2. Deection portion operation check ...............................................................................17
3-1-3. Trocar connection check .............................................................................................17
3-1-4. Probe insertion check .................................................................................................18
3-1-5. Verication of operation ............................................................................................18
3-1-6. Verication of cleaning, disinfection and sterilization .....................................................18
4. Usage
4-1. Operation ........................................................................................................................19
4-1-1. Operation of each part ................................................................................................19
4-1-2. Preparations of the protect tube ....................................................................................20
4-1-3. Insertion of the probe .................................................................................................20
4-1-4. Pulling out the probe ..................................................................................................22
4-2. Connecting to the ultrasound diagnostic instrument ......................................................24

v
MN1-5575 Rev.11
4-3. Removing from the ultrasound diagnostic instrument ...................................................25
4-4. Actions to be taken when an abnormal state is detected.................................................26
4-4-1. Ensuring safety of patients..........................................................................................26
4-4-2. Handling the instrument ............................................................................................26
5. Cleaning, disinfection and sterilization
5-1. Precautions for cleaning, disinfection and sterilization..................................................28
5-2. Reprocessing instruction according to ISO 17664 .........................................................30
5-3. Point of use (Pre-cleaning) .............................................................................................32
5-4. Waterproof cover ............................................................................................................32
5-5. Containment and transportation......................................................................................32
5-6. Manual cleaning and disinfection...................................................................................33
5-6-1. Manual cleaning ........................................................................................................34
5-6-2. Manual disinfection ...................................................................................................35
5-6-3. Cable and connector .................................................................................................................... 36
5-7. Automated cleaning and disinfecting .............................................................................36
5-8. Applicable cleaners and disinfectants / Suppliers List ...................................................38
5-9. Drying.............................................................................................................................40
5-10. Maintenance, inspection and testing.............................................................................40
5-11. Packaging......................................................................................................................40
5-12. Sterilization...................................................................................................................41
5-12-1. Ethylene oxide (EtO) gas sterilization..........................................................................41
5-12-2. STERRAD®sterilization...........................................................................................42
5-12-3. Liquid sterilization (USA only)................................................................................................. 43
5-12-4. STERIS®sterilization................................................................................................................ 43
5-13. Storage..........................................................................................................................43
6. Storage
6-1. Actions before storing the probe..................................................................................45
6-2. Environmental conditions for storage............................................................................45
7. Moving and Transporting
7-1. Moving and transporting ..............................................................................................47
7-2. Preparing the probe and accessories for moving ............................................................47
7-3. Packing for transportation ............................................................................................47
7-4. Environmental conditions during transportation .........................................................47

MN1-5575 Rev.11
vi
8. Periodic Inspection
8-1. Safety tests.....................................................................................................................49
8-2. Testing of measurement tolerances.................................................................................50
8-2-1. Conducting tests ...........................................................................................................50
8-2-2. Result judgement .........................................................................................................50
9. Conguration
9-1. Standard conguration...................................................................................................51
9-2. Options............................................................................................................................51
10. Disposal of the Device .......................................................................................................53
This Instruction Manual contains the main body of 54pages and 6pages until the CONTENTS.

-1-
MN1-5575 Rev. 11
1. Safety Precautions
1-1. Intended use
This probe is intended for use by a doctor when placed into direct contact with human internal organs during
surgery making ultrasonic observations.
Caution
Do not use this equipment for other than its intended purpose.
Use for other purposes can cause burns or other injuries to the patient or operator.
1-2. Usage precautions
The terms below are used in the safety information provided to prevent hazards and injuries to the operator
or patients. The severity of the hazard and injury that can occur when failing to observe the displayed safety
information are indicated in four levels: "Danger", "Warning", "Caution"and "Note".
Danger
Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury to
the operator or patient.
War ning
Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury to
the operator or patient.
Caution
Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury to
the operator or patient, or property damage only.
Note
Indicates a strong request concerning an item that must be observed in order to prevent damage or
deterioration of the equipment and also to ensure that it is used efciently.
The type of safety information is indicated by the symbols below.
This symbol means attention is required.
This symbol means that the described action is prohibited.
This symbol means the described action is mandatory.

-2-
MN1-5575 Rev. 11
1-2-1. Warnings and safety information
War ning
Follow the information in this manual and the documentation supplied with any equipment used
together with this probe.
Use that is not in accordance with the supplied documentation can result in a serious or moderate
injury, equipment breakdown, or physical damage that impairs operation.
Be sure to preparations for use.
Use of the equipment while failing to notice an abnormal condition can result in injury to the operator
or patient. If any abnormalities are noted on the probe in the start up inspection, immediately stop
using it and contact one of our ofces and/or distributor's ofces listed on the back cover. See section
3-1 “Start up check” for the start up inspection content and procedure.
This equipment must not be used in direct contact with the heart.
This may cause patient to receive an electric shock.
Do not use on the eyes.
This probe is not intended for use on the eyes. The acoustic output can have an adverse effect on the eyes.
Do not attempt to disassemble, modify, or repair the probe.
Electric shock or other unforeseen accidents could result. Contact one of our ofces and/or
distributor's ofces listed on the back cover to request repair.
Clean, disinfect and sterilize before using the probe.
Perform proper cleaning, disinfection and sterilization after use.
Otherwise, there is a risk of infection. Note that the probe is not sterilized at the factory.
Before using the probe rst, be sure to clean, disinfect and sterilize it.
Be sure to sterilize the equipment which blood adhered.
Otherwise, there is a risk of infection. Also be sure to remove the cap from the protect tube before
washing.
Always use a protective tube.
If the probe is damaged during operation, the patient can be injured.
Use a trocar outer sheath with a diameter of 12 mm ( length 170mm or less ) for the protect tube.
When the trocar outer sheath is not the right size, the tube can be loose or difcult to insert and could
result in a hazardous situation.
Attach the protective tube correctly to the trocar outer sheath.
The patient can be injured if the protective tube moves unexpectedly or comes off during the
operation. Also, if the cap is not attached correctly, the lled gas inside the patient's body will be
released, making it difcult to perform the procedure.
Do not try to forcibly perform operations.
Excessive force cause injury to the patient. If an abnormal resistance force is felt, stop use of the
equipment.
To pull out the probe, unlock the angle knob, straighten the deection portion and pull out slowly
and gently.
Pulling out with excessive force can result in an injury to the patient. If you feel resistance on the
probe, such as it catching on something, do not apply excessive force and perform an internal visual
check for any problems.

-3-
MN1-5575 Rev. 11
War ning
During surgery, be sure to wear sterilized medical gloves.
Conducting examinations with the bare hands can expose the operator to a risk of infection.
For the acoustic medium, use sterilized physiological saline.
Using an unsterilized ultrasound medium can cause an infection on the patient.
Dispose the probe used for patients with Creutzfeldt-Jakob disease.
Otherwise, there is a risk of infection to the operator or patient. Our ultrasound probe is not compatible
with any disinfection/sterilization method for Creutzfeldt-Jakob disease.
When using ultrasound contrast agent, follow the supplied documentation.
Unexpected accidents could result. Check the state of the patient and take appropriate precautions
to avoid side effects.
Do not use the equipment fallen on to oor.
Ohterwise, there is a risk of infection. Stop the operation and perform the procedure in section 8
"Periodic Inspection", section 5 "Cleaning, disinfection and sterilization" and section 3-1 "Start up
check".
Caution
Constantly check for anything abnormal about the patient’s condition and equipment.
Continued use without noticing that an abnormal condition has occurred can result in an electric
shock and injury to the operator or patient. If an abnormal condition occurs, immediately move the
equipment away from the patient and stop use of the equipment.
The equipment is vulnerable to damage by impact. Therefore, handle it with care.
There is a risk of damage to the equipment when the equipment is fallen or hit somewhere.
Do not use this probe with other equipment except for those specically approved in the manual.
Use with unapproved equipment can result in an electric shock, burn, or other injury to the patient or
operator and damage to the probe and the other equipment.
Scan for the minimum length of time necessary for the diagnosis and at the lowest suitable output.
Overuse can adversely affect the internal tissues of the patient.
For details about the acoustic output, please refer to the documentation supplied with the ultrasound
diagnostic instrument.
Do not use it in continuous contact with the human body more than 60 minutes.
Overuse can adversely affect the internal tissues of the patient.
Regularly perform maintenance inspection and safety tests of the equipment.
If you use equipment for a long period of time, it can reduce the performance, or cause smoke or
re. If anything unusual occurs, immediately stop using it and contact one of our ofces and/or
distributor's ofces listed on the back cover.
Use, move and transport the equipment under the environmental conditions specied in this
manual.
Otherwise, it may be damaged.
See section 2-5 "Environmental conditions" and section 7-4 "Environmental conditions during
transportation".

-4-
MN1-5575 Rev. 11
1-2-2. Cleaning, disinfection and sterilization precautions
War ning
Wear protective gloves and other protective gear during cleaning, disinfection and sterilization.
Handling of the equipment with your bare hands before sterilization can result in an infection.
After soaking in cleaning agents, thoroughly wash the probe with running water.
Residual cleaning agents can cause an adverse reaction on the bodies of the operator or patient.
After soaking in a disinfectant, throughly wash the equipment with deionized water. Leavings of the
disinfectant can cause an adverse reaction on the bodies of the operator or patient.
Perform aeration completely after gas sterilization.
Residual gas can cause an adverse reaction on the bodies of the operator or patient.
Do not clean, disinfect or sterilize using procedures other than those specied in this manual.
Infection could result due to incomplete cleaning, disinfection and sterilization. It can also result in
damage to the equipment or reduced performance. The equipment cannot withstand autoclave steril-
ization or boiling and other types of sterilization at temperatures exceeding 60°C (140°F).
For details on the usage conditions of chemicals and sterilization procedures, refer to the documentation
supplied with the respective chemical or sterilization equipment.
Infection could result due to incomplete sterilization. This could also cause deterioration of the
equipment.

-5-
MN1-5575 Rev. 11
Caution
Attach the waterproof cover if the connector will be soaked in liquid.
If the connector is soaked in liquid without the waterproof cover, liquid can get inside and result in
malfunction.
Attach the waterproof cover to the probe and use it by following the instructions in the waterproof
cover manual. Using the wrong combination of the probe and the waterproof cover, incorrectly
mounting the waterproof cover, or using the probe without properly mounting the cover can cause
the probe to malfunction.
Do not use a waterproof cover where a problem has been found.
Using a waterproof cover in an abnormal state can cause injury to the user. Contact one of our ofces
and/or distributor's ofces listed on the back cover.
Do not use the waterproof cover in sterilization that applies changes in pressure.
Using ethylene oxide gas sterilization, low-temperature plasma sterilization, or other sterilization
methods that apply changes in pressure can damage the probe and the waterproof cover. In these
cases, do not use the waterproof cover.
After soaking in chemical solution, check that no liquid has entered into the connector.
If liquid appears to have entered the connector, immediately stop use and contact one of our ofces
listed on the back cover.
Do not use the waterproof cover if the packing has been removed before.
The waterproof cover will not function correctly even if packing that was removed is returned to its
original location. Replace it by a new waterproof cover.
When cleaning the waterproof cover, do not deform the packing by applying unnecessary force.
Use of the waterproof cover while the packing is deformed can cause liquid to enter the probe
resulting in malfunction.
Do not rub the packing of the waterproof cover with a brush.
This could damage the packing. Use of the waterproof cover while the packing is damaged can cause
liquid to enter the probe resulting in malfunction.
Be sure to store the waterproof cover by removing it from the connector.
If the waterproof cover is stored while connected to the probe, the packing can become deformed.
Replace the waterproof cover around two years after it is commercing for use.
The packing for preventing liquid deteriorates with time.
For safe use, replace the waterproof cover by a new one typically two years.

-6-
MN1-5575 Rev. 11
㻞㻙㻝㻢㻙㻝㻘㻌㻴㼕㼓㼍㼟㼔㼕㻙㼁㼑㼚㼛㻘㻌㼀㼍㼕㼠㼛㻙㼗㼡㻘㻌㼀㼛㼗㼥㼛㻘㻌 㻝㻝㻜㻙㻜㻜㻝㻡㻘㻌㻶㼍㼜㼍㼚㻌㻌㻌㼀㻱㻸㻌㻗㻤㻝㻙㻟㻙㻢㻞㻤㻠㻙㻟㻢㻢㻤
Label 3
Label 2
Label 1
Label 1
1-2-3. Labels
(1) Probe unit
Electronic linear probe mark
Frequency

-7-
MN1-5575 Rev. 11
Label 3 Model
Serial No.
Manufacturer
Address
Rx Only:
By prescription only. U.S. Federal Law
restricts this device to sale on order of
a physician only.
Label 2
STERRAD sterilization compatibility mark
See section 5.
IPX7 mark
See section 2-2, “Specications”.
Type BF applied part
Do not waste the instrument as general waste. Comply
with a local regulation.
See section 10.
Safety warning sign
Biohazard
See section 5.
Follow the instruction manual to operate this instrument.
If not avoided, may result in injury, property damage, or
the equipment trouble.
IPX7
㻞㻙㻝㻢㻙㻝㻘㻌㻴㼕㼓㼍㼟㼔㼕㻙㼁㼑㼚㼛㻘㻌㼀㼍㼕㼠㼛㻙㼗㼡㻘㻌㼀㼛㼗㼥㼛㻘㻌
㻝㻝㻜㻙㻜㻜㻝㻡㻘㻌㻶㼍㼜㼍㼚㻌㻌㻌㼀㻱㻸㻌㻗㻤㻝㻙㻟㻙㻢㻞㻤㻠㻙㻟㻢㻢㻤
This instrument complies with Directive 93/42/EEC
relating to Medical Device and Directive 2011/65/EU
relating to RoHS.

-8-
MN1-5575 Rev. 11
(2) Storage case
Label A
Label C
Label B
Label D

-9-
MN1-5575 Rev. 11
Label A Model
Label B
2016-09
Label C
Label D DATE OF MANUFACTURE
(in case of 2016-09)
Serial No.
2016-09
DATE OF MANUFACTURE
(in case of 2016-09)
MANUFACTURER
AUTHORISED REPRESENTATIVE IN EUROPEAN
COMMUNITY
This instrument complies with Directive 93/42/EEC
relating to Medical Device and Directive 2011/65/EU
relating to RoHS.
2016-09
Hitachi Medical Systems GmbH
Otto-von-Guericke-Ring 3 D-65205
Wiesbaden, Germany
P-3258F

-10 -
MN1-5575 Rev. 11

-11-
MN1-5575 Rev. 11
2. Specications and Parts name
2-1. Principles of operation
This probe and the ultrasound diagnostic instrument enable image diagnosis using ultrasonic waves. These
instruments operate under the principles described below.
(1) When an electric pulse signal is applied from the transmitter to the transducer of the probe, the transducer
operates by converting electrical vibrations to mechanical vibration energy for emitting pulse-shaped
ultrasonic waves into the body part contacting the transducer or into liquid or other medium.
(2) The emitted ultrasonic waves are reected by boundaries with different acoustic characteristics (acoustic
impedance) within the body.
(3) The transducer is also used to receive reected ultrasonic waves. The transducer vibrates mechanically due
to the received ultrasonic vibrations and uses an electro-mechanical conversion operation to convert the
received mechanical vibrations to electric energy. The received echo is also converted to electric signals
and a brightness modulation operation is used to convert the electric pulses to shades of brightness for
forming an image.

-12-
MN1-5575 Rev. 11


2-2. Specications
2-2-1. Specications of the probe
Application regions: Intraoperative diagnosis
Form of application to patient: Intraoperative
Connectable instruments: SSD-α10, Prosound α7, Prosound α6, F37, ARIETTA 70, ARIETTA 60
Field of view: 38mm
Frequency: 7.5MHz
Range of deection: UP120° DOWN120°
Outer diameter of exible shaft: φ10mm
Effective insertion distance: 380mm
Cable length: 2.9 m
Weight: 1200 g
Service life: Three years
Range of applied part: As shown in the gure below.
Parts treated as applied parts: As shown in the gure below.
IPX7 range: As shown in the gure below.(waterproof cover MP-2790 unattached)
Whole parts of the probe. (waterproof cover attached)
External dimensions: As shown in the gure below.
Unit: mm
Remarks
The dimensions and weight are within ±10% of the indicated values.
Cable length
IPX7 range
1000
Range of applied part
Parts treated as applied parts

-13-
MN1-5575 Rev. 11
2-2-2. Specications of the protect tube
Material: Polyetherimide ( Protect tube ), Silicon rubber ( Cap )
Compatible trocar size: 12mm
Service life: Three years
External dimensions: As shown in the gure below.
Unit: mm
Remarks
The dimensions and weight are within ±10% of the indicated values.

-14 -
MN1-5575 Rev. 11
2-3. Performance
For measurement tolerances, operating tolerances and other data, refer to the instruction manual for the
ultrasound diagnostic instrument.
2-4. Name of each parts
Cable
This cable propagates the
ultrasonic signals that are
sent and received.
Caution
Do not pull, bend, twist, or apply excessive force to the cable.
The conductors may break and the cable may become unusable.
Do not subject the ultrasonic radiation part to hard impact.
The impact may cause damage to the transducer, and that results in noise or no echo in the image.
In most cases, the ultrasonic radiation part itself is not damaged because the part is made of elastic
material. .
Do not bend or twist it unnecessarily and frequently.
This could make the probe unusable.
While bending the deection portion, set free the angle knob.
Bending it while it is locked could make the probe unusable.
Angle markers
The angle marker is a white
line that indicats the angle
of deection portion.
Connector
This is the part
that connects
the ultrasound
diagnostic
instrument and
probe. Follow the
instructions in
section 4-2.
Lock lever
This part make the angle knob
xed any direction.
Protect tube
Protects the probe from the
external tube of trocar.
Angle knob
This part is used to operate
the deection portion.
Tip
Cap
The cap eliminates the gap
with the probe and keeps
airtightness.
Operating head
When using the probe, hold
this part by hand.
Deection portion
Operating the angle knob allows
this part to be bent in any desired
direction.
Insertion tube
The part is inserted into the pa-
tient's body with the ultrasonic
irradiation area and deection
portion.
Ultrasonic irradiation area
This incorporates an
electronic linear transducer.
Near the deection portion
corresponds the front mark
(direction mark) on the im-
age display.
