Hitachi C 7D User manual

POWER TOOLS
TECHNICAL DATA
AND
SERVICE MANUAL
CORDLESS CIRCULAR SAW
C 7D
SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT
LIST No. F851 May 2001
C
MODEL
C 7D

ELECTRIC TOOL PARTS LIST
LIST NO.
CORDLESS CIRCULAR SAW
Model C 7D
2001
•
5
•
10
(E1)
F851
12
3
4
5
67
8910 11
12 13 14 15 16
17 18 19
20
21
22
23
24 25 26
27
28 29 30 31 32 33 34 35 36 37
38 39
40 41 42 43
44
45
46 47
48 49 50
51
52
53 54 55 56
57
58
59 60 61 62 63 64 65 66 67 68
69
67
66
70 71 72 73
501 502 503
73
65
46
74
64 65 66
67
75
65 66 67 68

*ALTERNATIVE PARTS
ITEM
NO. CODE NO. DESCRIPTION REMARKS
NO.
USED
PARTS C 7D
5 -- 01
1 620-1VV BALL BEARING 6201VVCMPS2L 1
2 302-432 RUBBER RING 1
* 3 319-884 GEAR COVER ASS’Y 1 INCLUD.2,6,7
* 3 319-885 GEAR COVER ASS’Y 1 INCLUD.2,4,6,7 FOR USA,CAN
* 4 CAUTION PLATE 1 FOR USA,CAN
5 HITACHI LABEL 1
6 961-729 CUSHION 1
7 949-794 FLAT HD. SCREW M6X20 (10 PCS.) 1
8 319-877 SPINDLE AND GEAR SET 1
9 302-433 BEARING HOLDER 1
10 600-3VV BALL BEARING 6003VVCMPS2L 1
11 961-807 BUSHING 1
12 302-425 SAFETY COVER 1
13 302-442 RETURN SPRING 1
14 302-435 BEARING COVER 1
15 990-430 SEAL LOCK FLAT HD. SCREW M4X10 2
* 16 302-444 WASHER (A) 1
* 16 302-443 WASHER (A) 1 FOR USA,CAN
* 17 302-411 TCT SAW BLADE 185MM-D20 HOLE-NT18 1
* 17 302-410 TCT SAW BLADE 185MM-D16 HOLE-NT18 1 FOR USA,CAN
18 302-423 WASHER (B) 1
19 302-427 BOLT (W/FLANGE) M8X15.5 1
20 319-879 BOLT (SQUARE) M6 1
21 992-013 SEAL LOCK FLAT HD. SCREW M5X14 2
22 302-426 LEVER 1
23 949-215 MACHINE SCREW M4X8 (10 PCS.) 1
24 317-204 LIGHT COVER ASS’Y1
25 319-820 SOCKET 1
26 319-887 LIGHT 24V 5W 1
27 302-434 MACHINE SCREW (W/WASHERS) M5X45 (BLACK) 3
28 319-972 HANDLE COVER 1
29 319-893 BRUSH HOLDER 1
30 319-825 SWITCH (1P SCREW TYPE) W/O LOCK 1
31 319-889 INTERNAL WIRE 1
32 958-715 TAPPING SCREW D4X10 1
33 319-823 TERMINAL (D) 1
34 319-971 HOUSING 1
35 301-631 SPRING (F) 1
36 317-207 TERMINAL (A) 1
37 319-904 KNOB 1
38 NAME PLATE 1
39 319-891 RESISTOR (A) 1
40 319-846 MAGNET 1
41 319-878 FAN GUIDE 1
42 608-VVM BALL BEARING 608VVC2PS2L 1
43 311-435 DUST SEAL (A) 1
44 360-556 ARMATURE ASS’Y DC 24V 1 INCLUD.1,42,43
45 302-431 LOCK LEVER 1
46 302-086 TAPPING SCREW (W/FLANGE) D4X20 (BLACK) 6
47 319-832 TAIL COVER 1
48 319-827 BRUSH HOLDER (WITH RED INTERNAL WIRE) 1

*ALTERNATIVE PARTS
ITEM
NO. CODE NO. DESCRIPTION REMARKS
NO.
USED
PARTS C 7D
5 -- 01
49 999-058 CARBON BRUSH (1 PAIR) 2
50 319-847 BRUSH CAP 2
51 959-141 CONNECTOR 50092 (10 PCS.) 1
52 319-831 GRIP COVER 1
53 319-956 WASHER (B) 2
54 960-108 HEX. HD. TAPPING SCREW D4X60 2
55 319-894 TERMINAL SUPPORT 1
* 56 319-806 BATTERY EB 2420 (W/ENGLISH N.P.) 1 FOR USA,CAN
* 56 319-805 BATTERY EB 2420 (W/ENGLISH N.P.) 1
57 307-898 WING BOLT M6X18 1
58 947-859 LOCK SPRING 1
59 302-438 WING BOLT (A) M6X20 1
60 949-455 SPRING WASHER M6 (10 PCS.) 1
61 949-425 WASHER M6 (10 PCS.) 1
62 302-437 BASE ASS’Y 1 INCLUD.59-61,64,68,69
63 949-686 ROLL PIN D6X40 (10 PCS.) 1
64 306-082 BEVEL PLATE 1
65 303-869 NYLON NUT M6 2
66 949-432 BOLT WASHER M6 (10 PCS.) 2
67 306-083 STEP BOLT M6 2
68 306-085 LINK 1
69 302-439 SLOTTED HD. SET SCREW (SEAL LOCK) M6X8 1
70 319-883 RETAINING RING (E-TYPE) FOR D9 SHAFT 1
71 319-882 CLAMP LEVER 1
72 319-881 CLAMP NUT 1
73 319-880 WASHER (S) 2
74 306-081 BEVEL PLATE ASS’Y 1 INCLUD.64-67
75 306-084 LINK ASS’Y 1 INCLUD.65-68

*ALTERNATIVE PARTS
STANDARD ACCESSORIES
OPTIONAL ACCESSORIES
ITEM
NO. CODE NO. DESCRIPTION REMARKS
NO.
USED
ITEM
NO. CODE NO. DESCRIPTION REMARKS
NO.
USED
Printed in Japan
(010510N) 5 -- 01
C 7D
501 319-836 CASE 1
502 CHARGER (MODEL UC 24YFB) 1
503 302-478 BOX WRENCH 13MM 1
601 302-691 GUIDE 1
602 302-690 DUST COLLECTOR SET 1
