Hitachi CP-DW25WN User manual

Super-Short Throw Projector
*Projected images are simulations
Hitachi America, Ltd., Digital Media Division 900 Hitachi Way, Chula Vista, CA 91914-3556, U.S.A. and Canada Tel: [phone] www.hitachi-america.us/digitalmedia
Hitachi Home Electronics Asia (S) Pte. Ltd. 438A Alexandra Road #01-01/02/03, Alexandra Technopark, 119967, Singapore Tel: [phone] www.hitachiconsumer.com.sg
Hitachi Sales (Malaysia) Sdn. Bhd. Lot 12, Jalan Kemajuan, Bangi Industrial Estate, 43650 Bandar Baru Bangi, Selangor Darul Ehsan, Malaysia Tel: [phone] www.hitachiconsumer.com.my
Hitachi Sales (Thailand), Ltd. 994, 996 Soi Thonglor, Sukhumvit 55 Road, Klongtonnua, Vadhana Bangkok 10110, Thailand Tel: [phone] www.hitachi-th.com
Hitachi (Hong Kong), Ltd. 18th Floor, Ever Gain Centre, 28 On Muk Street, Shatin, N.T., Hong Kong Tel: [phone] www.hitachi-hk.com.hk
Hitachi Sales Corp. of Taiwan 2nd Floor, No.65, Nanking East Road, Section 3, Taipei 104, Taiwan Tel: [phone] www.hsct.com.tw
Hitachi Australia Pty Ltd. Suite 801, Level 8, 123 Epping Road, North Ryde NSW 2113, Australia Tel: [phone] www.hitachi.com.au
Hitachi Europe Ltd., Digital Media Group Consumer Affairs Department Whitebrook Park, Lower Cookham Road, Maidenhead, Berkshire, SL6 8YA, UK Tel: [phone] www.hitachidigitalmedia.com
Specifications
Terminals
Model name CP-DW25WN CP-D32WN CP-D27WN
Product name Liquid crystal projector
Liquid Crystal Panel
Lamp 215W UHP
Light output (brightness) 2500lm 3200lm 2700lm
Contrast ratio
(Presentation mode) 3000:1
Speaker 10W
Keystone correction Manual horizontal/vertical keystone
Power supply AC 100-120V/3.3A, AC 220-240V/1.6A
Power consumption AC 100-120V:320 W, AC 220-240V:300W
Temperature range 0 ~ 40°C (Operating)
35 ~ 40°C (The brightness of the lamp is reduced automatically.)
Dimensions(WxHxD) 345 x 85 x 303mm (13.6” x 3.3” x 11.9” ) * Not including protruding parts.
Weight (mass) approx. 3.7 kg (8.2lbs)
Ports
Agency certifications UL/cUL,FCC Part15 class B,
AS/NZS CISPR22 class B, CE, RoHS, GOST-R
Standard accessories
Environment
Dimensions
Projection Distance
On a horizontal surface Suspended from the ceiling
Super-Short Throw Projector
CP-DW25WN
CP-D32WN
CP-D27WN
c2
c2
a
b
c1
c1
USB(A)
AC IN
S-VIDEO
VIDEO MIC
AUDIO OUT
AUDIO IN
AUDIO IN 1,2
USB(B)
LAN
HDMI
COMPUTER IN
MONITOR OUT
RS-232C
345mm(13.6” )
303mm(11.9” )
85mm
(3.3”)
b
These projectors achieve a
projection on an 2m (80”) wide
interactive whiteboard at a throw
distance of only 71.1cm(28”).
Optional parts
Audio input/output port
AUDIO IN1: Stereo mini x1
AUDIO IN2: Stereo mini x1
AUDIO IN3 (R, L): RCA x2
AUDIO OUT (R, L): RCA x2
Others
USB TYPE A: USB-Ax2
USB TYPE B: USB-Bx1
CONTROL: D-sub 9 pin x1
LAN: RJ45 x1
MIC: Mono mini x1
1,024,000 pixels
(1280 horizontal x 800 vertical)
Computer input port
COMPUTER IN1: D-sub 15 pin mini x1
COMPUTER IN2: D-sub 15 pin mini x1
Computer output port
MONITOR OUT: D-sub 15 pin mini x1
Video input port
S-VIDEO: mini DIN 4 pin x1
VIDEO: RCA x1
HDMI input port
HDMI: HDMI connector x1
786,432 pixels
(1024 horizontal x 768 vertical)
(1) Remote control with the two AA batteries, (2) Power cord,
(3) Computer cable, (4) Lens cover and Strap, (5) User’ s manuals (Book x1, CD x1),
(6) Security label, (7) Application CD, (8) Adapter cover
Lamp: DT01381; Filter set: UX37191; Mounting accessory: HAS-AW100 (Bracket
for ceiling mount), HAS-203L (Fixing adaptor for low ceilings), HAS-P100 (Fixing
adaptor for high ceilings); Laser remote control: RC-R008; USB wireless
adapter: USB-WL-11N
a
CP-D27WN CP-D32WN
CP-DW25WN
NM-E379 112012
Compliance with EU Directive RoHS*1
Reduction of resin usage in production
Use of hot runners in molds for making upper housing in
order to reduce mill ends.
Reduction of CO2emissions
Carton volume has been cut down to 96.2%*2, reducing CO2
emissions during transport.
Power saving mode engaged during standby
Eco mode
Eco mode provides power saving.
*1
RoHS is the acronym of “DIRECTIVE
2002/95/EC OF THE EUROPEAN
PARLIAMENT AND OF THE
COUNCIL of 27 January 2003 on
the restriction of the use of certain
hazardous substances in electrical
and electronic equipment".
*2
Compared to Hitachi CP-D31N
network capable projector on the
basis of one carton box.
CP-DW25WN
CP-D32WN
CP-D27WN
Screen size(diagonal) b:Projection distance c1:Screen height c2:Screen height
type(inch) m m inch m inch m inch
60 1.5 0.510 20.1 0.155 6.1 1.069 42.1
70 1.8 0.610 24.0 0.171 6.7 1.237 48.7
80 2.0 0.711 28.0 0.186 7.3 1.405 55.3
90 2.3 0.812 32.0 0.202 7.9 1.573 61.9
100 2.5 0.913 35.9 0.217 8.6 1.741 68.6
Screen size(diagonal) b:Projection distance c1:Screen height c2:Screen height
type(inch) m m inch m inch m inch
60 1.5 0.547 21.5 0.242 9.5 1.050 41.3
70 1.8 0.653 25.7 0.272 10.7 1.214 47.8
80 2.0 0.760 29.9 0.302 11.9 1.379 54.3
90 2.3 0.866 34.1 0.331 13.0 1.543 60.7
100 2.5 0.972 38.3 0.361 14.2 1.707 67.2
(1024 x 768) (±8%)
(1280 x 800) (±8%)
*
*CP-D32WN/CP-D27WN
−Design and specifications are subject to change without notice.
・The projected images and comparison photos in this catalog are simulations.
・LCD panels, polarizers and other optical components and cooling fans may need replacement after prolonged usage. For more details, please consult a Hitachi sales representative.
・Do not use in places where there is a lot of water, dampness, steam, dust, soot or tobacco smoke. This may result in fire or malfunction.
・Optical components (lamp, LCD panel, polarizing plate, PBS [polarizer beam splitter]) have limited service lives. They must be repaired or replaced if they are used for a long period of time.
・These projectors use a mercury lamp with high internal pressure. Because of its properties, this lamp may burst with a loud noise or burn out if struck or after it has been used for a period of
time. The time until it bursts or burns out varies greatly according to differences between lamps and usage conditions. Turning the lamp’s power on and off frequently shortens its service life.
・Optical components other than the lamp: If the projector is used for six hours or more per day, they may need to be replaced in less than a year.
・LCD panel: If the projector is used continuously for six hours or more, its replacement cycle may be shortened.
・Do not turn projector on again for ten minutes after shutdown. Neglect can shorten the lifetime or the lamp. During use and immediately after use, do not touch anywhere near the lamp and
the vents as these parts are extremely hot.
・Windows®, Windows Vista®and Internet Explorer®are trademarks, or registered trademarks of Microsoft Corporation in the United States and/or other countries.
・Pentium®is trademark of Intel Corporation in the U.S. and/or other countries.
・Crestron®and Crestron RoomView®are registered trademarks of Crestron Electronics, Inc. in the United States and other countries.
・HDMI, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
・ImageCare is a trademark or a registered trademark of Royal Philips Electronics in the United States and other countries.
・All other trademarks are the properties of their respective owners.

Short Throw Length
3000:1
High Contrast Ratio
High Brightness of
3200 Lumens*
Mic. Input and 10W
Internal Speakers
PC-less Presentation
and Two USB Inputs
These projectors achieve a projection on
an 2.0m (80”) wide interactive whiteboard
at a throw distance of only 71.1cm*(28.0”) .
Since they can project a large image from
directly in front of an interactive
whiteboard, teachers can conduct
enjoyable lessons effectively using limited
classroom space. Students can
concentrate on lessons without being
distracted by the projector’s light source, or
the teacher’s shadow cast on the screen.
Normal mode Saver Mode
Saver mode is a feature developed by
Hitachi that reduces the projector lamp
brightness and consumption power,
resulting in considerable energy savings.
You can set the Saver mode time 1 to 30
minutes, and if the projected image does
not change in that time, Saver mode
activates. Saver mode can also be activated
manually.
Intelligent Eco Mode
Intelligent Eco mode is a feature developed
by Hitachi that automatically changes the
brightness of the lamp according to the
level of the input signal. Lamp brightness is
reduced when a darker image is projected
returns to normal when a brighter image is
projected, eliminating unnecessary energy
consumption from the lamp.
Hybrid Filter
The Hybrid Filter requires less frequent
maintenance and cleaning, making longer
operation possible.
Easy Maintenance
The lamp door is on the top and the filter
cover is on the back, so maintenance and
replacement of these parts can be done
easily.
Template Function*
The Template Function equipped in these
projectors projects pre-installed templates
on a whiteboard, blackboard, or other
surface. Templates include a line template
to make writing on a board easier, a grid
template, a world map, and more.
*Patent pending
The projectors are equipped with a
microphone input, so you can use a
microphone system, even when the
projector is in standby. Projectors also
have built-in 10W high power speakers.
By using a USB memory stick or other
storage device*, you can use the projectors
without a PC. Menus are easy to see with
a thumbnail display, and there is also a
slideshow function. Projectors are
equipped with two USB Type A inputs.
*Not compatible with all USB storage
devices.
3 LCD chips with
Inorganic Alignment Layers
These projectors incorporate three LCD
panels with inorganic alignment layers that
are extremely light resistant, increasing
brightness and contrast ratio. They ensure
smooth images and high reliability.
Centralized Reporting
With just one PC in an administration room,
you can collect reports from all projectors
connected to the network.
Wireless Capability
You can use a wireless network by connecting
the projector to a computer using the optional
USB wireless adapter. The adapter supports
IEEE802.11 b/g/n.
2.0m (80”) wide
interactive whiteboard
300cm
CP-X4021N
71.1cm
CP-D32WN
Optional USB
wireless
adapter
Saver Mode
Super-Short Throw Projector
53cm
CP-A302WN
Hardware and software requirements for network capability OS: One of the following. Windows®XP Home Edition/Professional Edition (32bit version only), Windows Vista®Home Basic/Home
Premium/Business/Ultimate/Enterprise, Windows®7 Starter/Home Basic/Home Premium/Professional/Ultimate/Enterprise CPU: Pentium®4 (2.8GHz or higher) Graphic card: 16bit, XGA or higher (When using the “Live
Viewer” it is recommended that the display resolution of your computer be set to 1024x768.) Memory: 512 MB or higher Hard disk space: 100MB or higher Web browser: Internet Explorer®6.0 or higher CD-ROM drive
*If many computers are connected to the network or the connected computer is under excessive load, higher specifications may be required.
*CP-D32WN/CP-D27WN
*CP-D32WN
Throw distance : 76.0cm (29.9”)
Screen size : 2.0m (80”)
CP-D32WN CP-D27WN
CP-DW25WN
WXGA 2500lm XGA 3000lm XGA under 2700lm
Throw distance : 71.1cm (28.0” )
Screen size : 2.0m (80”)
Throw distance : 71.1cm (28.0” )
Screen size : 2.0m (80”)
Administration
Room
With access point
Without access point
Black lines on a white grid World map
Black lines on a white
background
Circles
LAN
x
y
a
b
b c d
A
f g h i
E
25%
