Feature / Function Benefits
Performance High interface transfer rate Faster system boot-up
Quicker screen refreshes
Up to 16MB buffer Faster data processing
NCQ (Native Command Queuing) Faster data processing
Capacity 500GB, 400GB, 320GB, and 250GB Popular capacity points
Reliability Thermal Fly Height Control (TFC) Improves error rate
Head load/unload Protects disk during non-operation
Reduces power during idle periods
ECC and CRC protection Data integrity enhanced throughout circuits
SMART Command Transport (SCT) Adaptive error correction
Internal thermal sensor Improves data integrity
High Performance Storage.
500GB, 400GB, 320GB and 250GB |7200 RPM |Parallel ATA 133 and Serial ATA 3.0Gb/s
Hitachi Deskstar® T7K500
3.5-INCH HARD DISK DRIVES
Features and Benefits
www.hitachigst.com
Highlights
> SATA 3.0 Gb/s and PATA 133 interfaces
> Capacities from 250GB up to 500GB
> Native Command Queuing for maximum
data speeds
> Thermal Monitoring and Fly Height
Control for enhanced reliability
> SMART Command Transport optimized
response times
Applications
> Consumer computers
> Low duty cycle servers
> External storage
> Extreme PC gaming
> Video editing arrays
Serial ATA Features
>3.0Gb/s interface data rate
>Native Command Queuing
>Staggered spin up
>Hot plug capability
>Click connect connector
>Scalable performance
>System improvements
Deskstar T7K500
The Deskstar T7K500 builds on Hitachi’s
award winning tradition with new 160GB per
platter areal density technology. Consumer
personal computers and low duty cycle servers
demand high capacity and high performance
storage to meet consumers digital media
needs and growth ATA server application
requirements. The Deskstar T7K500 meets
these performance requirements and delivers
the high capacity for today’s applications.
Hitachi Quality and Service
The Hitachi Deskstar T7K500 extends on the companies reliability and performance leadership.
Hitachi’s standardized features in consumer and low duty cycle server solutions enable faster
transfer rates, scalable performance and quicker boot up times.
Hitachi is dedicated to providing a breadth of hard disk drive products to satisfy all of today’s
demanding computing needs. Hitachi hard drives are backed by an array of technical support
and services which may include customer and integration service.

Hitachi Global Storage Technologies
1GB equals one billion bytes when referring to hard drive capacity; accessible capacity may be less.
2Buffer capacity includes 270 or less KB used for drive firmware.
3Does not include command overhead
4Low duty cycle, non mission-critical applications in PC, nearline and consumer electronics customer environments
are different from application to application .
5 RoHS refers to the European Union Directive 2002/95/EC on the restriction of certain hazardous substances in
electrical and electronic equipment.
Specific application environments such as temperature and duty cycle will affect the overall reliability rates.
For specific application environment reliability rates, please consult Hitachi technical support.
© 2006 Hitachi Global Storage Technologies
Hitachi Global Storage Technologies
3403 Yerba Buena Road
San Jose, CA 95135
Produced in the United States 3/06
All rights reserved.
Deskstar® is a trademark of Hitachi Global Storage Technologies.
References in this publication to Hitachi Global Storage
Technologies products, programs or services, do not imply that
Hitachi Global Storage Technologies intends to make these
available in all countries in which it operates.
Product information is provided for information purposes only,
and does not constitute a warranty. Information is true as of
the date of publication and is subject to change. Actual results
may vary. This publication is for general guidance only. Photo-
graphs may show design models.
How to Read the Deskstar Model Number
Example:
HDT725050VLA360 = 500GB/16MB
H= Hitachi
D= Deskstar
T= Two- or three-disk
72 = 7200 RPM
50 = full capacity = 500GB
50 = model capacity = 500GB
(40 = 400GB, 32 = 320GB, 25 = 250GB)
V= generation code
L= 1-inch form factor
A3 = SATA 3.0 Gb/s (AT = Parallel ATA)
6= 16 buffer (8 = 8M buffer)
0= Reserved
For more information:
Internet:
>www.hitachigst.com (Main Web site)
>www.hitachigst.com/vpp (Reseller Web site)
Technical Support E-mail:
>[email protected] (N. America)
>[email protected] (Asia Pacific)
>[email protected] (EMEA and UK)
Technical Support Phone Numbers:
>1 888 426-5214 (N. America)
>65 6840 9595 (Asia Pacific)
>44 20 7133 0032 (EMEA and UK)
>49 6929 993601 (Germany Support)
Hitachi Deskstar® T7K500
Product Deskstar T7K500 Deskstar T7K500
Model numbers HDT725050VLAT80 HDT725050VLA360
HDT725040VLAT80 HDT725050VLA380
HDT725032VLAT80 HDT725040VLA360
HDT725025VLAT80 HDT725040VLA380
HDT725032VLA360
HDT725032VLA380
HDT725025VLA360
HDT725025VLA380
Specifications
Configuration Parallel-ATA Serial-ATA
Interface PATA-133 SATA 3.0Gb/s
Capacity (GB) 1500 / 400 / 320 / 250 
Data heads (physical) 6 / 6 / 4 / 4 
Data disks 3 / 3 / 2 / 2 
Performance
Data buffer 28 MB 16 MB / 8 MB
Rotational speed (rpm) 7,200 
Media transfer rate (max. Mbits/sec) 998 
Interface transfer rate (max. MB/sec) 133 300
Average seek time (ms) (read, typical) 3 8.5 
Reliability
Error rate (non-recoverable) 1 in 10E14 
Start/stops (at 40° C) 50,000 
Availability 424x7 
Acoustic
Idle (Bels, typical) 3.0 (3 disk) 2.8 (2 disk) 
Power
Requirement +5 VDC (+/- 5%) 
+12 VDC (+10 %/-8%) 
Dissipation
Startup current (max. A) 2.0 (+12V) &1.1 (+5V) 2.0 (+12V) &1.3 (+5V)
Idle (W) 6.0 (3 disk) 5.0 (2 disk) 7.0 (3 disk) 6.0 (2 disk)
Physical Size
Height (max. mm) 26.1 
Width (mm) 101.6 
Depth (mm) 147 
Weight (max. g) 640 
Environmental characteristics
Operating
Ambient temperature (C) 0° to 60° 
Relative humidity (non-condensing) 8% to 90% 
Shock (half sine wave, 2ms) (G) 70 
Vibration (random (RMS)) (G) 0.67 for horizontal 
0.67 for vertical
Non-operating
Ambient temperature (C) -40° to 65° 
Relative humidity (non-condensing) 5% to 95% 
Shock (half sine wave, 2ms) (G) 300 (3 disk) 350 (2 disk) 
Vibration (random (RMS)) (G) 1.04 rms (XYZ) 
RoHS compliant 5Yes 
