Hitachi Virtual Storage Platform F400 Operating and maintenance manual

Hardware Reference Guide
This guide describes the hardware features and specifications of the Hitachi Virtual Storage
Platform F400 and the Hitachi Virtual Storage Platform F600 all-flash arrays.
MK-94HM8045-09
October 2017
Hitachi Virtual Storage Platform
F400 and F600
83-04-4x or later

© 2017 Hitachi Vantara Corporation. All rights reserved.
No part of this publication may be reproduced or transmitted in any form or by any means, electronic or mechanical, including
photocopying and recording, or stored in a database or retrieval system for commercial purposes without the express written permission
of Hitachi, Ltd., or Hitachi Vantara Corporation (collectively, “Hitachi”). Licensee may make copies of the Materials provided that any
such copy is: (i) created as an essential step in utilization of the Software as licensed and is used in no other manner; or (ii) used for
archival purposes. Licensee may not make any other copies of the Materials. "Materials" mean text, data, photographs, graphics, audio,
video and documents.
Hitachi reserves the right to make changes to this Material at any time without notice and assumes no responsibility for its use. The
Materials contain the most current information available at the time of publication.
Some of the features described in the Materials might not be currently available. Refer to the most recent product announcement
for information about feature and product availability, or contact Hitachi Vantara Corporation at https://support.HitachiVantara.com/
en_us/contact-us.html.
Notice: Hitachi products and services can be ordered only under the terms and conditions of the applicable Hitachi agreements. The
use of Hitachi products is governed by the terms of your agreements with Hitachi Vantara Corporation.
By using this software, you agree that you are responsible for:
1) Acquiring the relevant consents as may be required under local privacy laws or otherwise from authorized employees and other
individuals to access relevant data; and
2) Verifying that data continues to be held, retrieved, deleted, or otherwise processed in accordance with relevant laws.
Notice on Export Controls. The technical data and technology inherent in this Document may be subject to U.S. export control laws,
including the U.S. Export Administration Act and its associated regulations, and may be subject to export or import regulations in
other countries. Reader agrees to comply strictly with all such regulations and acknowledges that Reader has the responsibility to
obtain licenses to export, re-export, or import the Document and any Compliant Products.
EXPORT CONTROLS - Licensee will comply fully with all applicable export laws and regulations of the United States and other
countries, and Licensee shall not export, or allow the export or re-export of, the Software, API, or Materials in violation of any such laws
or regulations. By downloading or using the Software, API, or Materials, Licensee agrees to the foregoing and represents and
warrants that Licensee is not located in, under the control of, or a national or resident of any embargoed or restricted country.
Hitachi is a registered trademark of Hitachi, Ltd., in the United States and other countries.
AIX, AS/400e, DB2, Domino, DS6000, DS8000, Enterprise Storage Server, eServer, FICON, FlashCopy, IBM, Lotus, MVS, OS/390,
PowerPC, RS6000, S/390, System z9, System z10, Tivoli, z/OS, z9, z10, z13, z/VM, and z/VSE are registered trademarks or
trademarks of International Business Machines Corporation.
Active Directory, ActiveX, Bing, Excel, Hyper-V, Internet Explorer, the Internet Explorer logo, Microsoft, the Microsoft Corporate Logo,
MS-DOS, Outlook, PowerPoint, SharePoint, Silverlight, SmartScreen, SQL Server, Visual Basic, Visual C++, Visual Studio,
Windows, the Windows logo, Windows Azure, Windows PowerShell, Windows Server, the Windows start button, and Windows Vista
are registered trademarks or trademarks of Microsoft Corporation. Microsoft product screen shots are reprinted with permission from
Microsoft Corporation.
All other trademarks, service marks, and company names in this document or web site are properties of their respective owners.

Contents
Preface................................................................................................. 7
Intended audience................................................................................................... 8
Safety and environmental notices..............................................................................8
Product version........................................................................................................9
Release notes........................................................................................................ 10
Changes in this revision..........................................................................................10
Document conventions........................................................................................... 10
Conventions for storage capacity values...................................................................11
Accessing product documentation........................................................................... 12
Getting help...........................................................................................................12
Comments.............................................................................................................12
1 Hitachi Virtual Storage Platform F400, F600 hardware overview.............. 13
Block configuration.................................................................................................15
Unified configuration.............................................................................................. 15
VSP F400 model.....................................................................................................15
VSP F600 model.....................................................................................................17
Features................................................................................................................19
Scalability.............................................................................................................. 19
Examples of supported VSP F400 configurations................................................. 19
Examples of supported VSP F600 configurations................................................. 20
Maximum number of mounted drive trays...........................................................20
2 Virtual Storage Platform F400, F600 controller...................................... 21
CBLM controller......................................................................................................22
CBLM with front panel bezel.............................................................................. 22
CBLM front panel LEDs (without bezel)...............................................................23
CBLM rear panel............................................................................................... 24
CBLM power supply unit LEDs and connectors.................................................... 26
Host, Network, and Drive Tray Ports and LEDs..........................................................26
Front end module descriptions...........................................................................26
10-Gbps iSCSI board LEDs and connectors (optical).......................................27
3
Hitachi Virtual Storage Platform F400, F600 Hardware Reference Guide

10-Gbps iSCSI board LEDs and connectors (copper)...................................... 27
8-Gbps, 16-Gbps, or 32-Gbps Fibre Channel (4-port) board LEDs and connectors
..................................................................................................................28
16-Gbps Fibre Channel (2-port) board LEDs and connectors...........................30
LAN blade LEDs and connectors.........................................................................31
Back end module LEDs and connectors.............................................................. 32
3 Storage system drive trays.................................................................. 35
Flash module drive (FMD) tray................................................................................ 36
FMD with front panel bezel................................................................................36
FMD front panel without bezel........................................................................... 36
FMD rear panel.................................................................................................38
4 Host port expansion chassis..................................................................41
Host port expansion chassis front panel bezel LEDs.................................................. 42
PCIe switchboard................................................................................................... 42
Host port expansion chassis fan.............................................................................. 43
PCIe cable connector..............................................................................................43
Host port expansion chassis power supply............................................................... 45
5 NAS module........................................................................................ 47
NAS Module Ports and LEDs....................................................................................48
6 VSP service processor server................................................................ 49
Service processor description.................................................................................. 50
SVP front panel......................................................................................................50
SVP rear panel....................................................................................................... 51
Service processor hardware specifications................................................................52
7 Maintaining the storage system.............................................................53
Storing the storage system..................................................................................... 54
Powering off the storage system............................................................................. 54
A Mechanical specifications for VSP F400, F600 .......................................55
VSP F400 and VSP F600 mechanical specifications....................................................56
B Electrical specifications for VSP F400, F600............................................61
Electrical specifications........................................................................................... 62
C Environmental specifications for VSP F400, F600....................................63
Environmental specifications................................................................................... 64
D iSCSI standards and specifications........................................................ 67
iSCSI standards......................................................................................................68
4
Hitachi Virtual Storage Platform F400, F600 Hardware Reference Guide

iSCSI specifications................................................................................................ 68
EReplacement parts...............................................................................71
Battery unit........................................................................................................... 72
F Data and power cables.........................................................................73
Fibre Channel cables.............................................................................................. 74
iSCSI cables...........................................................................................................77
Managing data cables.............................................................................................79
AC power cables.................................................................................................... 81
Power cable assemblies.....................................................................................81
AC connections.................................................................................................83
Power cable usage guidelines............................................................................ 84
Three-phase power considerations for racks....................................................... 84
Cable management...........................................................................................85
Cable retention.................................................................................................85
G Port address mapping.......................................................................... 87
Port address mapping.............................................................................................88
H Third-party racks................................................................................. 89
Third-party rack support for VSP Fx00 models.......................................................... 90
Hitachi Universal V2 Rack rail kits............................................................................ 90
Hitachi Universal V2 Rack accessories......................................................................90
Third-party rack support for DB60 dense intermix drive trays.................................... 91
I Hitachi Universal V2 Rack power distribution units..................................93
Americas single-phase PDU 1P30A-8C13-3C19UL.P...................................................94
Americas single-phase PDU 1P30A-15C13-3C19UL.P................................................. 94
Americas three-phase PDU 3P30A-8C13-3C19UL.P....................................................95
Americas three-phase PDU 3P30A-15C13-3C19UL.P..................................................95
Americas three-phase PDU 3P30A-24C13-6C19UL.P..................................................96
APAC and EMEA single-phase PDU 1P32A-9C13-3C19CE.P.........................................97
APAC and EMEA single-phase PDU 1P32A-18C13-3C19CE.P.......................................97
APAC and EMEA three-phase PDU 3P16A-9C13-3C19CE.P......................................... 98
APAC and EMEA three-phase PDU 3P16A-15C13-3C19CE.P........................................98
APAC and EMEA three-phase PDU 3P32A-24C13-6C19CE.P........................................99
J Regulatory compliance....................................................................... 101
Index................................................................................................ 103
5
Hitachi Virtual Storage Platform F400, F600 Hardware Reference Guide

6
Hitachi Virtual Storage Platform F400, F600 Hardware Reference Guide

Preface
This guide describes the hardware features and specifications of the Hitachi
Virtual Storage Platform F400, F600 all-flash arrays.
□Intended audience
□Safety and environmental notices
□Product version
□Release notes
□Changes in this revision
□Document conventions
□Conventions for storage capacity values
□Accessing product documentation
□Getting help
□Comments
Preface 7
Hitachi Virtual Storage Platform F400, F600 Hardware Reference Guide

Intended audience
This document is intended for customers inquiring about the features and
specifications of the VSP Fx00 models.
Readers of this document should be familiar with the following:
• Data processing and RAID storage systems and their basic functions.
• The operating system and web browser software on the system hosting
the storage management software.
Safety and environmental notices
Equipment warranty
The term of guarantee of normal operation of the storage system and free service is one year from
date of purchase.
If a failure occurs multiple times, the storage system might shut off to avoid a serious accident.
Notice of export controls
Export of technical data contained in this document might require an export license from the United
States government, the government of Japan. or both. Contact the Hitachi Legal Department for
guidance about any export compliance questions.
Backup
Hitachi cannot guarantee against data loss due to failures. Therefore, back up your data to minimize
chances for data loss.
Data backup is also critical when hardware components are added or replaced, because performing
such hardware procedures restores parameter settings that can affect how data is managed on the
storage systems.
Disposal
This symbol on the product or on its packaging means that your electrical and electronic equipment
should be disposed at the end of life separately from your household wastes.
There are separate collection systems for recycling in the European Union. For more information,
contact the local authority or the dealer where you purchased the product.
Recycling
A nickel-metal hydride battery is used in the Cache Backup Battery.
A nickel-metal hydride battery is a resource that can be recycled. When you want to replace the
Cache Backup Battery, call the service personnel. They will dispose of it for you. This nickel-metal
hydride battery, which is designated as recycling product by a recycling promotion low, must be
recycled.
The mark posted on the Cache Backup Battery is a three-arrow mark that indicates a recyclable part.
8 Preface
Hitachi Virtual Storage Platform F400, F600 Hardware Reference Guide

UEFI Development Kit 2010
This product includes UEFI Development Kit 2010 written by the UEFI Open Source Community. For
more information, see the UEFI Development Kit website:
http://sourceforge.net/apps/mediawiki/tianocore/index.php?title=UDK2010
© 2004, Intel Corporation.
All rights reserved.
Redistribution and use in source and binary forms, with or without modification, are permitted
provided that the following conditions are met:
Redistributions of source code must retain the above copyright notice, this list of conditions and the
following disclaimer.
Redistributions in binary form must reproduce the above copyright notice, this list of conditions and
the following disclaimer in the documentation and/or other materials provided with the distribution.
Neither the name of the Intel Corporation nor the names of its contributors might be used to endorse
or promote products derived from this software without specific prior written permission.
THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS “AS IS” AND ANY
EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT
SHALL THE COPYRIGHT OWNER OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT,
INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED
TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR
BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN
CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY
WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH
DAMAGE.
FDA radiation regulation
The array complies with FDA radiation performance standard 21 CFR subchapter J.
EMI regulation
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference in which case the user will
be required to correct the interference at his own expense. Testing was done with shielded cables.
Therefore, in order to comply with the FCC regulations, you must use shielded cables with your
installation.
This product must not be used in residential areas.
This is a class A product. In a domestic environment this product can cause radio interference in
which case the user can be required to take adequate measures.
Product version
This document revision applies to the following product versions:
• VSP F400, F600 firmware 83-04-4x or later
Preface 9
Hitachi Virtual Storage Platform F400, F600 Hardware Reference Guide

• Hitachi Storage Virtualization Operating System (SVOS) 7.2 or later
•Hitachi NAS firmware version 13.1 or later
Release notes
Read the release notes before installing and using this product. They may
contain requirements or restrictions that are not fully described in this
document or updates or corrections to this document. Release notes are
available on Hitachi Data Systems Support Connect: https://
knowledge.hds.com/Documents.
Changes in this revision
•Added new single- and three-phase power distribution units and
specifications
• Added third-party rack information
Document conventions
This document uses the following typographic conventions:
Convention Description
Bold • Indicates text in a window, including window titles, menus, menu options,
buttons, fields, and labels. Example:
Click OK.
•Indicates emphasized words in list items.
Italic • Indicates a document title or emphasized words in text.
• Indicates a variable, which is a placeholder for actual text provided by the
user or for output by the system. Example:
pairdisplay -g group
(For exceptions to this convention for variables, see the entry for angle
brackets.)
Monospace Indicates text that is displayed on screen or entered by the user. Example:
pairdisplay -g oradb
< > angle brackets Indicates variables in the following scenarios:
• Variables are not clearly separated from the surrounding text or from
other variables. Example:
Status-<report-name><file-version>.csv
•Variables in headings.
[ ] square brackets Indicates optional values. Example: [ a | b ] indicates that you can choose a,
b, or nothing.
{ } braces Indicates required or expected values. Example: { a | b } indicates that you
must choose either a or b.
10 Preface
Hitachi Virtual Storage Platform F400, F600 Hardware Reference Guide

Convention Description
| vertical bar Indicates that you have a choice between two or more options or arguments.
Examples:
[ a | b ] indicates that you can choose a, b, or nothing.
{ a | b } indicates that you must choose either a or b.
This document uses the following icons to draw attention to information:
Icon Label Description
Note Calls attention to important or additional information.
Tip Provides helpful information, guidelines, or suggestions for performing
tasks more effectively.
Caution Warns the user of adverse conditions and/or consequences (for
example, disruptive operations, data loss, or a system crash).
WARNING Warns the user of a hazardous situation which, if not avoided, could
result in death or serious injury.
Conventions for storage capacity values
Physical storage capacity values (for example, disk drive capacity) are
calculated based on the following values:
Physical capacity unit Value
1 kilobyte (KB) 1,000 (10 3) bytes
1 megabyte (MB) 1,000 KB or 1,0002 bytes
1 gigabyte (GB) 1,000 MB or 1,0003 bytes
1 terabyte (TB) 1,000 GB or 1,0004 bytes
1 petabyte (PB) 1,000 TB or 1,0005 bytes
1 exabyte (EB) 1,000 PB or 1,0006 bytes
Logical capacity values (for example, logical device capacity, cache memory
capacity) are calculated based on the following values:
Logical capacity unit Value
1 block 512 bytes
1 cylinder Mainframe: 870 KB
Open-systems:
Preface 11
Hitachi Virtual Storage Platform F400, F600 Hardware Reference Guide

Logical capacity unit Value
• OPEN-V: 960 KB
•Others: 720 KB
1 KB 1,024 (210) bytes
1 MB 1,024 KB or 1,0242 bytes
1 GB 1,024 MB or 1,0243 bytes
1 TB 1,024 GB or 1,0244 bytes
1 PB 1,024 TB or 1,0245 bytes
1 EB 1,024 PB or 1,0246 bytes
Accessing product documentation
Product user documentation is available on Hitachi Data Systems Support
Connect: https://knowledge.hds.com/Documents. Check this site for the
most current documentation, including important updates that may have
been made after the release of the product.
Getting help
Hitachi Data Systems Support Connect is the destination for technical support
of products and solutions sold by Hitachi Data Systems. To contact technical
support, log on to Hitachi Data Systems Support Connect for contact
information: https://support.hds.com/en_us/contact-us.html.
Hitachi Data Systems Community is a global online community for HDS
customers, partners, independent software vendors, employees, and
prospects. It is the destination to get answers, discover insights, and make
connections. Join the conversation today! Go to community.hds.com,
register
, and complete your profile.
Comments
Please send us your comments on this document to [email protected].
Include the document title and number
, including the revision level (for
example, -07), and refer to specific sections and paragraphs whenever
possible. All comments become the property of Hitachi Data Systems
Corporation.
Thank you!
12 Preface
Hitachi Virtual Storage Platform F400, F600 Hardware Reference Guide

1
Hitachi Virtual Storage Platform F400,
F600 hardware overview
Hitachi Virtual Storage Platform F400, F600 are modular, rack-mountable, all-
flash arrays that deliver high performance, high reliability, and flash-
accelerated scalability.
The storage system contain dual controllers, each controller contains its own
processor, dual in-line cache memory modules (DIMMs), cache flash memory
(CFM), battery, fans and iSCSI and Fibre Channel I/O modules. Each
controller also has an Ethernet connection for out-of-band management. If
the data path through one controller fails, all data drives remain available to
data hosts using a redundant data path through the other controller.
The storage system can be equipped with embedded network-attached
storage (NAS) modules. The NAS modules provide file access through CIFS
and NFS protocols and block access by using iSCSI protocols.
All storage system models allow defective drives to be replaced without the
interruption of data availability to hosts. A hot spare drive can be configured
to replace a failed drive automatically, securing the fault-tolerant integrity of
the logical drives. Self-contained, hardware-based RAID logical drives provide
maximum performance in compact external enclosures.
Essential hardware components are implemented with a redundant
configuration so that the storage system can remain operational if a
component fails. Adding and replacing components, along with firmware
upgrades, can be conducted while the storage system is active.
□Block configuration
□Unified configuration
□VSP F400 model
□VSP F600 model
Hitachi Virtual Storage Platform F400, F600 hardware overview 13
Hitachi Virtual Storage Platform F400, F600 Hardware Reference Guide

□Features
□Scalability
14 Hitachi Virtual Storage Platform F400, F600 hardware overview
Hitachi Virtual Storage Platform F400, F600 Hardware Reference Guide

Block configuration
A storage system configured for block-level storage provides the ability to
access and provision raw storage volumes using protocols such as Fibre
Channel and iSCSI.
A block configuration consists of the following:
• Two controllers
• One or more drive trays
• One 1U service processor server (SVP)
Unified configuration
A unified configuration includes embedded NAS modules that support file
system protocols such as CIFS and NFS and operate across a block-level
setup using iSCSI or FC connections.
• Two controllers
• Two NAS modules for file operations and storage
• One or more drive trays for block-level storage
• One 1U block service processor server (SVP)
VSP F400 model
The VSP F400 is a highly reliable all-flash system that offers high storage
capacity with full redundancy to better protect data and manage storage
operations.
The storage system consists of a 4U enclosure that includes two controllers
and two optional NAS modules to support file operations. Drives are
supported using drive trays connected to the controllers.
Controller Controller chassis Controller model Height
CBLM DW800-CBL DW-F800-CTLM 4U (174.3 mm)
Controller Model number Description
NAS DW-F800-NAS Optional component for file
storage configuration. NAS
modules only provide file
support.
Hitachi Virtual Storage Platform F400, F600 hardware overview 15
Hitachi Virtual Storage Platform F400, F600 Hardware Reference Guide

Drive tray Drive tray model
name
Supported drive
type
Number of drives
supported Height
FMD tray DW-F800-DBF 5.25-inch FMD 12 2U (86.2 mm)
SFF drive tray • DW-F800-DBS
(power supply,
contains
BNST)
• DW-F800-
DBSC
2.5-inch SFF 16 2U (86.2 mm)
High-speed cache memory
The storage system supports 128 GB of high-speed cache memory. The
DIMMs are arranged as 64 GB or 128 GB per controller.
Flash module drives
The VSP F400 storage system supports up to 192 flash module drives. The
total raw flash capacity is 2,702 TB.
Model number Drive type Drive capacity
DKC-F810I-1R6FN FMD DC2 1.6 TiB
DKC-F810I-3R2FN FMD DC2 3.2 TiB
DKC-F810I-6R4FN FMD DC2 6.4 TiB
DKC-F810I-7R0FP FMD HD 7 TB
DKC-F810I-14RFP FMD HD 14 TB
Solid-state drives
The VSP F400 storage system supports up to 384 SSDs. The total raw flash
capacity is 1,451 TB.
Model number Drive type Drive capacity
DKC-F810I-1R9MGM SSD 1.9 TB
DKC-F810I-3R8MGM SSD 3.8 TB
Interface ports
Interface ports for attachment to hosts are provided on the front-end
modules. The system supports up to 16 front-end modules.
16 Hitachi Virtual Storage Platform F400, F600 hardware overview
Hitachi Virtual Storage Platform F400, F600 Hardware Reference Guide

Model number Description Maximum number of ports
supported
DW-F800-2HS10S 10-Gbps iSCSI (Optical) front-
end module
28 (NAS modules not installed)
12 (NAS modules installed)
DW-F800-2HS10B 10-Gbps iSCSI (Copper) front-
end module
28 (NAS modules not installed)
12 (NAS modules installed)
DW-F800-4HF8 8-Gbps Fibre Channel (4-port)
front-end module
56 (NAS modules not installed)
24 (NAS modules installed)
DW-F800-2HF16 16-Gbps Fibre Channel (2-port)
front-end module
28 (NAS modules not installed)
12 (NAS modules installed)
DW-F800-4HF32R 32/16-Gbps Fibre Channel (4-
port) front-end module
56 (NAS modules not installed)
24 (NAS modules installed)
VSP F600 model
The VSP F600 is a highly reliable all-flash system that offers high storage
capacity with full redundancy to better protect data and manage storage
operations.
The storage system consists of a 4U enclosure that includes two controllers,
two optional NAS modules to support file operations. The drives are
supported using drive trays connected to the controllers.
Controller Controller chassis Controller model Height
CBLM DW800-CBL DW-F800-CTLM 4U (174.3 mm)
Controller Model number Description
NAS DW-F800-NAS Optional component for file
storage configuration. NAS
modules only provide file
support.
Drive tray Drive tray model
name
Supported drive
type
Number of drives
supported Height
FMD tray DW-F800-DBF 5.25-inch FMD 12 2U (86.2 mm)
SFF drive tray • DW-F800-DBS
(power supply,
contains
BNST)
• DW-F800-
DBSC
2.5-inch SFF 24 2U (86.2 mm)
Hitachi Virtual Storage Platform F400, F600 hardware overview 17
Hitachi Virtual Storage Platform F400, F600 Hardware Reference Guide

High-speed cache memory
The storage system supports 256 GB of high-speed cache memory. The
DIMMs are arranged as 64 GB or 128 GB per controller.
Flash module drives
The VSP F600 storage system supports up to 288 flash module drives. The
total raw flash capacity is 4,053 TB.
Model number Drive type Drive capacity
DKC-F810I-1R6FN FMD DC2 1.6 TiB
DKC-F810I-3R2FN FMD DC2 3.2 TiB
DKC-F810I-6R4FN FMD DC2 6.4 TiB
DKC-F810I-7R0FP FMD HD 7 TB
DKC-F810I-14RFP FMD HD 14 TB
Solid-state drives
The VSP F600 storage system supports up to 576 SSDs. The total raw flash
capacity is 2,177 TB.
Model number Drive type Drive capacity
DKC-F810I-1R9MGM SSD 1.9 TB
DKC-F810I-3R8MGM SSD 3.8 TB
Interface ports
Interface ports for attachment to hosts are provided on the front-end
modules. The system supports up to 16 front-end modules.
Model number Description Maximum number of ports
supported
DW-F800-2HS10S 10-Gbps iSCSI (Optical) front-
end module
28 (NAS modules not installed)
12 (NAS modules installed)
DW-F800-2HS10B 10-Gbps iSCSI (Copper) front-
end module
28 (NAS modules not installed)
12 (NAS modules installed)
DW-F800-4HF8 8-Gbps Fibre Channel (4-port)
front-end module
56 (NAS modules not installed)
24 (NAS modules installed)
DW-F800-2HF16 16-Gbps Fibre Channel (2-port)
front-end module
28 (NAS modules not installed)
12 (NAS modules installed)
DW-F800-4HF32R 32/16-Gbps Fibre Channel (4-
port) front-end module
56 (NAS modules not installed)
24 (NAS modules installed)
18 Hitachi Virtual Storage Platform F400, F600 hardware overview
Hitachi Virtual Storage Platform F400, F600 Hardware Reference Guide

Features
The features described in the table are included with VSP F400 and VSP
F600.
Feature Value
Maximum cache memory supported VSP F400: 128 GB
VSP F600: 256 GB
Maximum number of spare drives 32
Maximum number of RAID groups 16
Maximum volume size 3 TB (4 TB when using the LDEVs of other
Storage Systems)
Maximum number of volumes per host groups 2,048
Maximum number of host groups per port 255
Maximum number of volumes per port 2,048
Maximum number of volumes per RAID group 2,048
Maximum number of iSCSI hosts connected
through a network switch
255
Maximum number of Fibre Channel devices
connected through a Fibre Channel switch
255
Scalability
All storage systems offer pay-as-you-grow scalability by allowing you to hot-
add drives as you need them.
Examples of supported VSP F400 configurations
The following table lists the maximum number of drive trays and drives
supported in a system configuration. A diskless configuration does not include
any drive trays.
Drive tray Maximum number of
drive trays supported Maximum number of drives supported
SFF drive tray 16 384 SSDs
FMD tray 16 192 Hitachi Accelerated Flash (HAF) flash
module drives
FMD2 tray 1 8 DC2 flash module drives + 1 spare
Hitachi Virtual Storage Platform F400, F600 hardware overview 19
Hitachi Virtual Storage Platform F400, F600 Hardware Reference Guide

Examples of supported VSP F600 configurations
The following table lists the maximum number of drive trays and drives
supported in a system configuration. A diskless configuration does not include
any drive trays.
Drive tray Maximum number of
drive trays supported Maximum number of drives supported
SFF drive tray 24 576 SSDs
FMD drive tray 24 288 HAF flash module drives
FMD2 drive tray 2 16 DC2 flash module drives + 1 spare
Maximum number of mounted drive trays
The following table lists the maximum number of mountable drive trays and
mountable drives for each drive type.
Note: If a drive is inserted into a slot of a dense intermix drive tray when the
installed number of drives exceeds 240 slots per path, the drive is blocked.
VSP F400 controller Drive trays Maximum number of
trays
Maximum number of
drives
CBLM FMD 16 192 FMDs (HAF)
4 48 FMDs
FMD 1 8 FMDs + 1 spare
(DC2)
SFF 16 384 SSDs
VSP F600 controller Drive trays Maximum number of
trays
Maximum number of
drives
CBLM FMD 24 288 FMDs (HAF)
4 48 FMDs
FMD 2 16 FMDs + 1 spare
(DC2)
SFF 24 576 SSDs
20 Hitachi Virtual Storage Platform F400, F600 hardware overview
