ELECTRIC TOOL PARTS LIST
LIST NO. E283
DISC GRINDER
Model G 18SCY
2006
•
10
•
19
(E1)
Hitachi Power Tools
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
21
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
41
42
43
18
19
44
45
46
47 48
50
51
59
54
52
58
60
61
63
65
66
67
64
22
23
53
50
50
55
51
52
62
50
49
56
57
20
1
501 502 503
40

*ALTERNATIVE PARTS--- 2 ---
ITEM
NO. CODE NO. DESCRIPTION REMARKS
NO.
USED
PARTS
10 -- 06
G 18SCY
1984-509 SEAL LOCK HEX. SOCKET HD. BOLT M5X14 2
2323-209 TAPPING SCREW (W/FLANGE) D5X35 (BLACK) 4
3306-888 PUSHING BUTTON 1
4320-219 SPRING 1
5326-717 GEAR COVER ASS’Y 1 INCLUD. 3, 4, 16, 18, 19
6320-226 SPECIAL NUT M10 1
7320-221 SEAL WASHER 1
8320-222 FELT PACKING 1
9630-1VV BALL BEARING 6301VVCMPS2L 1
10 994-208 RUBBER RING (B) 1
11 320-220 BEARING COVER (A) 1
*12 360-594U ARMATURE ASS’Y 110V-120V 1 INCLUD. 8, 9, 44, 45
*12 360-777E ARMATURE 220V-230V 1
*12 360-594F ARMATURE 240V 1
13 320-215 FAN GUIDE 1
14 984-271 HEX. HD. TAPPING SCREW D5X75 2
*15 340-682C STATOR 110V-120V 1
*15 340-682E STATOR 220V-240V 1
16 937-033 FELT WASHER 1
17 322-411 SIDE HANDLE 1
18 320-218 O-RING 1
19 306-890 LOCK PIN 1
*20 326-719 GEAR AND PINION SET 1
*20 326-718 GEAR AND PINION SET 1 FOR USA, CAN
21 939-540
RETAINING RING FOR D10 SHAFT (10 PCS.) 1
22 326-722 COUPLING COVER 1
23 326-721 COUPLING DAMPER 4
24 326-720 COUPLING 1
25 949-236 MACHINE SCREW M5X10 (10 PCS.) 2
26 326-723 BEARING COVER (B) 1
27 630-2VV BALL BEARING 6302VVCMPS2L 1
28 990-852 FELT PACKING (B) 1
*29 326-727 SPINDLE 1
*29 326-728 SPINDLE 1 FOR USA, CAN
30 320-228 SEAL PLATE 1
31 320-227 PACKING GLAND 1
32 994-192
HEX. SOCKET HD. BOLT (W/FLANGE) M5X16 4
33 311-492 LABEL 1
34 321-546 SET PIN 1
35 321-545 LEVER 1
36 306-887 BOLT M8X22 1
37 949-457 SPRING WASHER M8 (10 PCS.) 1
38 321-544 SET PIECE 1
39 673-489
RETAINING RING (E-TYPE) FOR D5 SHAFT 1
*40 321-543 WHEEL GUARD ASS’Y 1 INCLUD. 33-39
*40 324-266 WHEEL GUARD ASS’Y 1 INCLUD. 33-39 FOR USA, CAN
*41 937-907Z WHEEL WASHER (A) 1
*41 937-922P WHEEL WASHER (B) FOR D5/8” HOLE 1 FOR USA, CAN
*41 937-908Z WHEEL WASHER (B) 1 FOR AUS
*42 316-824 D. C. WHEELS 180MM A24R (25 PCS.) 1
EXCEPT FOR GBR, HOL, ESP, SWE, AUT, USA, CAN
*43 937-909Z WHEEL NUT M14X2 1

*ALTERNATIVE PARTS --- 3 ---
ITEM
NO. CODE NO. DESCRIPTION REMARKS
NO.
USED
PARTS
10 -- 06
G 18SCY
*43 937-923P WHEEL NUT 5/8”-11UNC 1 FOR USA, CAN
*43 937-917Z WHEEL NUT (B) 1 FOR AUS
44 320-216 DUST SEAL 1
45 600-0VV BALL BEARING 6000VVCMPS2L 1
46 321-536 BEARING BUSHING 1
47 326-712 HOUSING ASS’Y 1 INCLUD. 46
48 326-716 BRUSH COVER 1
49 326-726 HANDLE DAMPER 1
50 305-812 TAPPING SCREW (W/FLANGE) D4X16 (BLACK) 6
*51 999-061 CARBON BRUSH 7X17X22.5 (1 PAIR) 2
*51 999-061 CARBON BRUSH 7X17X22.5 (1 PAIR) 1 FOR EUROPE
*51 999-089 CARBON BRUSH (AUTO STOP TYPE) (1 PAIR) 1FOR EUROPE
52 322-323 BRUSH HOLDER SET 2
53 326-715 BRUSH COVER 1
54 HITACHI LABEL 1
55 NAME PLATE 1
56 326-724 O-RING 1
57 326-725 O-RING 1
*58 320-238 SWITCH (2P PILLAR TYPE) W/SAFETY LOCK 1OFF/LOCK
*58 320-239 SWITCH (2P PILLAR TYPE) W/SAFETY LOCK 1W/LOCK
*58 322-614 SWITCH (2P PILLAR TYPE) W/SAFETY LOCK 1 W/LOCK INCLUD. 62 FOR USA,CAN
59 326-714 HANDLE (B) 1
60 960-266 CORD CLIP 1
61 984-750 TAPPING SCREW (W/FLANGE) D4X16 2
*62 322-549 SWITCH COVER 1 FOR USA, CAN
63 326-713 HANDLE (A) 1
*64 930-804 TERMINAL M4.0 (10 PCS.) 2 FOR USA, CAN
65 981-373 TUBE (D) 2
*66 940-778 CORD ARMOR D10.7 1
*66 958-049 CORD ARMOR D8.2 1 FOR AUS, SIN, INA
*67 321-537 CORD 1 (CORD ARMOR D10.7)
*67 321-539 CORD 1 (CORD ARMOR D10.7) FOR GBR (110V)
*67 500-460Z CORD 1 (CORD ARMOR D10.7) FOR GBR (230V)
*67 321-538 CORD 1 (CORD ARMOR D10.7) FOR USA, CAN
*67 500-408Z CORD 1 (CORD ARMOR D8.8) FOR AUS
*67 500-245Z CORD 1 (CORD ARMOR D10.7) FOR SYR
*67 500-234Z CORD 1 (CORD ARMOR D8.8) FOR INA
*67 500-474Z CORD 1 (CORD ARMOR D10.7) FOR TPE, VEN
*67 500-423Z CORD 1 (CORD ARMOR D8.8) FOR SIN

*ALTERNATIVE PARTS
--- 4 --- 10 -- 06
OPTIONAL ACCESSORIES
ITEM
NO. CODE NO. DESCRIPTION REMARKS
NO.
USED
STANDARD ACCESSORIES
ITEM
NO. CODE NO. DESCRIPTION REMARKS
NO.
USED
G 18SCY
Printed in Japan
(061019N)
501 937-913Z WRENCH 1
502 937-907Z WHEEL WASHER (A) 1
503 937-917Z WHEEL NUT (B) 1 FOR AUS
601 316-824 D. C. WHEELS 180MM A24R (25 PCS.) 1
602 310-337 SUPER WASHER 1
603 323-993 PIPE HANDLE SET 1 INCLUD. 604
604 985-597 BOLT M14 1 FOR PIPE HANDLE
