ELECTRIC TOOL PARTS LIST
LIST NO. G829
CORDLESS IMPACT DRIVER
Model WH 14DMR
2005
•
7
•
8
(E1)
Hitachi Power Tools
44
501
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
28
29
30
31 32
33
33
34
35
36
37
38
39
37
40
41
42
43
45
46
47
501 502
27

*ALTERNATIVE PARTS--- 2 ---
ITEM
NO. CODE NO. DESCRIPTION REMARKS
NO.
USED
PARTS
7 -- 05
WH 14DMR
1315-984 RETAINING RING 1
2315-983 WASHER (D) 1
3321-657 GUIDE SPRING (A) 1
4322-717 GUIDE SLEEVE (D) 1
5324-238 FRONT CAP (C) 1
6324-239 PROTECTOR (D) 1
7307-851
TAPPING SCREW (W/SP. WASHER) D4X30 (BLACK) 4
8324-216 HAMMER CASE 1
9319-535 STEEL BALL D3.5 (10 PCS.) 2
*10 324-236 ANVIL 1
*10 324-602 ANVIL (B) 1 FOR KOR
11 959-154 STEEL BALL D5.556 (10 PCS.) 2
12 324-218 HAMMER 1
13 959-148 STEEL BALL D3.175 (10 PCS.) 28
14 315-978 WASHER (J) 1
15 324-224 HAMMER SPRING (F) 1
16 316-172 WASHER (S) 1
17 324-222 STOPPER (B) 1
18 324-232 SPINDLE 1
19 321-667 IDLE GEAR SET (2 PCS.) 2
20 324-234 NEEDLE ROLLER (A) 2
21 320-877 RING GEAR (C) 1
22 319-911 WASHER (E) 1
23 690-1VV BALL BEARING 6901VVCMPS2L 1
24 324-230 DAMPER (A) 2
25 324-229 INNER COVER (B) 1
26 360-712 ARMATURE AND PINION SET 1
27 324-607 SIDE YOKE (A) 1
28 324-235 MAGNET (F) ASS’Y 1 INCLUD. 27
29 324-228 DUST GUARD FIN (B) 1
30 324-226 BRUSH BLOCK 1
31 999-054 CARBON BRUSH 5X6X11.5 (1 PAIR) 2
32 319-918 BRUSH CAP 2
33 302-086
TAPPING SCREW (W/FLANGE) D4X20 (BLACK) 8
34 NAME PLATE 1
35 324-237 HOUSING (A).(B) SET 1
36 324-513 HITACHI PLATE 1
37 994-532 MACHINE SCREW (W/SP. WASHER) M3X5 2
38 324-227 DC-SPEED CONTROL SWITCH 1
39 324-225 PUSHING BUTTON (B) 1
40 321-918 HOOK ASS’Y (W/LIGHT) 1 INCLUD. 41, 42
41 321-672 TAPPING SCREW D2X6 2
42 320-288 V-LOCK NUT M5 1
43 306-952 STRAP (BLACK) 1
*44 CAUTION PLATE (B) 1 FOR USA, CAN
45 319-926 HOOK SPRING 1
46 320-881 SPECIAL SCREW (A) M5 1
*47 322-883 BATTERY EB 1426H (W/ENGLISH N.P.) 2
*47 315-129 BATTERY EB 14B (W/ENGLISH N.P.) 2
*47 315-130 BATTERY EB 14B (W/ENGLISH N.P.) 2 FOR NZL, AUS, KOR
*47 318-372 BATTERY EB 1430H (W/ENGLISH N.P.) 2

OPTIONAL ACCESSORIES
ITEM
NO. CODE NO. DESCRIPTION REMARKS
NO.
USED
*ALTERNATIVE PARTS --- 3 ---7 -- 05
STANDARD ACCESSORIES
ITEM
NO. CODE NO. DESCRIPTION REMARKS
NO.
USED
WH 14DMR
*501 CHARGER (MODEL UC 14YFA) 1
*501 CHARGER (MODEL UC 18YG) 1
502 323-230 CASE 1
601 321-823 DRILL CHUCK AND ADAPTER SET 1 INCLUD. 616, 618
602 309-922 GREASE FOR IMPACT DRIVER (500G) 1
603 992-671 + DRIVER BIT (B) NO. 2 50L 1
604 992-672 + DRIVER BIT (B) NO. 3 50L 1
605 996-177 NON-MAGNETIC HEX. SOCKET 8MM 65L 1
606 985-329 NON-MAGNETIC HEX. SOCKET 10MM 65L 1
607 996-178 NON-MAGNETIC HEX. SOCKET 12MM 65L 1
608 996-179 NON-MAGNETIC HEX. SOCKET 13MM 65L 1
609 996-180 NON-MAGNETIC HEX. SOCKET 14MM 65L 1
610 996-185 NON-MAGNETIC HEX. SOCKET 15MM 65L 1
611 996-181 NON-MAGNETIC HEX. SOCKET 16MM 65L 1
612 996-182 NON-MAGNETIC HEX. SOCKET 17MM 65L 1
613 996-186 NON-MAGNETIC HEX. SOCKET 19MM 65L 1
614 996-197 HEX. SOCKET (LONG) 21MMX166L 1
615 996-184 BIT PIECE 1
616 987-575 CHUCK WRENCH FOR 10VLB-D, 10VLR-D 1
617 930-119 CHUCK WRENCH 6.5G 1
618 307-543 CHUCK ADAPTER 1

--- 4 ---
ITEM
NO. CODE NO. DESCRIPTION REMARKS
NO.
USED
7 -- 05
WH 14DMR
Printed in Japan
