Hitron HSUI-H75DxZ2U8 User manual

PRODUCTION RELEASE & REVISION
REV DESCRIPT'N/BUYER DWG No PARTS No. BY CHK DATE
105(+/-5)mm
148+/-5)mm
TITLE
SIZE REV.
SCALE
MATERIAL
UNLESS OTHERWISE SPECIFIED
ALL DIMENSIONS ARE IN MM.
- TOLERANCE
LABEL +/- 3
MANUAL +/- 5
GUIDE +/- 5
COLOR
DATE
DRAWN
CHKED
APPROVALS
PARTS LIST
DESCRIPTION/MATERIAL
ITEM QTY
A4
DO NOT SCALE
2
MANUAL INSTRUCTION
50303467
NOTES
1.MODEL: HSUI-H75DxZ2U8 /NO BRAND (SDI 88pi AIO)
2.MATERIAL: 모조지
3.COLOR: BLACK
4.SIZE: 105(+/-5)mm x 148(+/-5)mm
WHITE
3
BIND : STAPLES-2
B
전자
J.Y.LIU
W.S.OH
M.J.KWON
A INITIAL ------------------- 50303467 J.Y.LIU M.J.KWON 02-26-M13
04-04-M13
Full HD 20x
Auto-Focus
ZOOM CAMERA
Please read this manual thoroughly before use, and keep it handy for future reference.
Design and specifications are subject to change without notice.
김경기
B INITIAL ------------------- 50303467 J.Y.LIU M.J.KWON 04-04-M13
04-04-M13
04-04-M13
04-04-M13
REV.B - 1p protocol 수정
2p 케이블라벨수정.
15p protocol&power input 수정
(재고 폐기 즉시적용)

Full HD 20x
Auto-Focus
ZOOM CAMERA
Please read this manual thoroughly before use, and keep it handy for future reference.
Design and specifications are subject to change without notice.

WARNING
CAUTION
CAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER(OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
EXPLANATION OF GRAPHICAL SYMBOLS
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of uninsulated "dangerous voltage"
within the product's enclosure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to
the presence of important operating and maintenance (servicing) instructions in the
literature accompanying the product.
Should any liquid or solid object fall into the cabinet,
unplug the unit and have it checked by the qualified
personnel before operating it any further.
Unplug the unit from the wall oulet if it is not going to
be used for several days or more. To disconnect the
cord, pull it out by the plug. Never pull the cord itself.
Allow adequate air circulation to prevent internal heat
build-up. Do not place the unit on surfaces (rugs,
blankets, etc.) or near materials(curtains, draperies)
that may block the ventilation holes.
Height and vertical linearity controls located at the
rear panel are for special adjustments by qualified
personnel only.
Clean the unit with a slightly damp soft cloth.
Use a mild household detergent. Never use
strong solvents such as thinner or benzine as
they might damage the finish of the unit.
Retain the original carton and packing
materials for safe transport of this unit in the
future.
Safety ----------------------------------------- Cleaning --------------------------------------
PRECAUTIONS
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR
MOISTURE. DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE VENTILATION GRILLS OR
OTHER OPENINGS ON THE EQUIPMENT.
ii

iii
FCC INFORMATION : THIS EQUIPMENT HAS BEEN TESTED
AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL
DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE
LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION
AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS
OPERATED IN A COMMERCIAL ENVIRONMENT. THIS EQUIPMENT
GENERATES, USES, AND CAN RADIATE RADIO FREQUENCY
ENERGY AND IF NOT INSTALLED AND USED IN ACCORDANCE WITH
THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL INTERFERENCE
TO RADIO COMMUNICATIONS. OPERATION OF THIS EQUIPMENT IN
A RESIDENTIAL AREA IS LIKELY TO CAUSE HARMFUL
INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
CAUTION : CHANGES OR MODIFICATIONS NOT EXPRESSLY
APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE
COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT.
THIS CLASS A DIGITAL APPARATUS COMPLIES WITH CANADIAN
ICES-003.
NORME NMB-003 DU CANADA.
WARNING
This is a Class A product. In a domestic environment this product
may cause radio interference in which case the user may be required
to take adequate measures.
CE COMPLIANCE STATEMENT
FCC COMPLIANCE STATEMENT

iv
IMPORTANT SAFETY INSTRUCTIONS

1
IMPORTANT : The user of this camera is responsible for checking
and complying with local, state, and federal laws and statutes concerning
the recording and monitoring of audio signals.
The 1/2.9” 2M full HD CMOS X20 ZOOM camera, especially for closed circuit
television CCTV and security surveillance application.
THE CAMERA FEATURES
INTRODUCTION
High performance SONY 1/2.9” Exmor CMOS.
2.2M 1080p Full HD, Excellent picture quality.
1920x1080p / 30fps, 1280x720p / 60fps.
20x Optical zoom. (x320 Zooming capability / Digital : 16x)
Zoom and Focus Control via Remote or Keyboard Controller.
IR Range distance up to 50M.
Day & Night. (ICR)
OSD. (on screen display)
WDR (Wide Dynamic Range)/ BLC. (Back-light compensation)
DNR. (Digital Noise Reduction, 2D+3D)
Privacy mask Function.
HLC. (High Light Compensation Function)
Motion Detection.
Defog.
Composite Video Output. (700TV Lines)
Protocol. (COMMAND, Fastrax, Pelco-D, Pelco-P, VISCA)
Motion External OUT.
Day & Night External Control.
Operates in AC24V ± 10% / DC12V ± 10%.
Weatherproof housing IP-66.
Use Certified / Listed Class 2 power source only.
Camera Mount : camera mount directly to the wall or ceiling.
TM

2
CAMERA CONNECTIONS
1. Lens : 20x Optical Zoom( f=4.7~94mm) Lens for wide area monitoring.
2. Video(CVBS) : BNC connector used to connect the camera to a monitor,
switcher, etc.
3. Video(HD-SDI) : BNC connector used to connect the camera to a HD-SDI
monitor, HD-SDI convertor, etc.
4. Power : 24 AC input / 12V DC input
Power source from a DC 12V or AC 24V ac +/-10% 60/50Hz +/-1Hz
Use Certified/Listed Class 2 power source only.
* If using DC 12V power adaptor, use a power supply capable of supplying 15 Watts.
5. RS 485 CONTROL
GREEN : RS485+
BLUE : RS485-
6. Day & Night External CONTROL
7. ALRAM OUT
8. GROUND
How to Adjust ZOOM/FOCUS.
- Remote Controller.
Insert the din jack of remote controller to the hall of housing
Adjust the zoom using up/down key.
Adjust the focus using left/right key.
- Keyboard Controller.
Connect the 485(+)(-) of keyboard controller with 485(+)(-) Terminal Block.
Adjust the zoom using tele/wide key.
Adjust the focus using near/far key.
REMINDER:
Never aim the camera directly into the sun.

3
Screw Firmly attach the bracket to the wall or ceiling
DIMENSIONS
WATER INGRESS PREVENTION
UNIT : mm (inches)
REMOTE CONTROL PORT CAP
After using the Remote Control cable,
disconnect it and insert the Remote Control Port Cap.
Secure it tightly.
PACKAGE CONTENTS
Caution : This is a sealed camera with no internal
adjustments and as such opening the case may
invalidate the warranty.
(3.4) (6.5)
(10.9)
SUNSHIELD
SUNSHIELD-BOLT SCREWS REMOTE CONTROLLER
CAMERA

4
CAMERA FIXING
CAMERA ADJUSTMENT

CAMERA CONNECTION
5
Connect the remote control using the 6 pin din connector end to the socket within the camera:
Connect the BNC to a set up monitor to view the picture and On Screen Menus.
To Enter the menus press the button on the remote control.
To Navigate the menus, move the button left/Right/Up and Down, press the button to Enter.
END - takes you back a step in the OSD or exits from the OSD

6
STRUCTURE OF THE SETUP MENU
<SETUP>
<ZOOM LENS>
FOCUS MODE
ZOOM SPEED
FOCUS SPEED
DISTANCE
DZOOM COMBI
ZOOM DISP
LENS INIT
RETURN
<EXPOSURE>
IRIS
SHUTTER
BRIGHTNESS
AGC
DSS
ACE
DEFOG
RETURN
<DAY & NIGHT>
AUTO
COLOR
B&W
EXT
< >WDR/BLC
OFF
WDR
BLC
< >AWB
AUTO
AUTOext
PRESET
MANUAL
LENS
EXPOSURE
AWB
WDR/BLC
DAY & NIGHT
FUNCTION
SYSTEM
EXIT
<SYSTEM>
RS485
CAM TITLE
DISPLAY
OUT MODE
LANGUAGE
VERSION
RESET
RETURN
< >FUNCTION
DNR
MOTION
PRIVACY
SHADING DET
DEFECT DET
RESET
RETURN
< >IMAGE
CHROMA
SHARPNESS
EFFECT
STILL
SHADING
HLMASK
DZOOM
GAMMA
RETURN

7
LENS
EXPOSURE
The EXPOSURE menu is used to set the automatic light control method for the camera. It
provides the ability to adjust the SHUTTER speed, BRIGHTNESS, AGC, DSS and ACE
functions of the camera.
1) IRISSelect the IRIS open. ▶ CLOSE, F1.8 - F32
2) SHUTTERSelect the SHUTTER speed level.
▶Auto,1/30(25), 1/60(50), FLK~ 1/240 - 1/60.000sec)
3) BRIGHTNESSAdjust the BRIGHTNESS level. ▶ 0 ~ 20
4) AGCAdjust the Auto Gain Control level. ▶ 0 ~ 7
5) DSSSelct the Digital Slow Shutter level. ▶ OFF, x2 ~ x8
6) ACESelect the Adaptive Contrast Enhancer. (D-WDR) ▶ ON, OFF
7) DEFOGSelect the DEFOG mode. ▶ OFF, LOW, MIDDLE, HIGH
* When DEFOG is ON. ACE and WDR function can not turn on.
<EXPOSURE>
►
AUTO
OFF
LENS
EXPOSURE
AWB
WDR/BLC
DAY&NIGHT
FUNCTION
SYSTEM
EXIT
<SETUP>
AUTO
AUTO
IIIIIIIII 7
IIIIIIIII 5
OFF
OFF
OFF
IRIS
SHUTTER
BRIGHTNESS
AGC
DSS
ACE
DEFOG
RETURN
1) FOCUS MODESelect the FOCUS MODE. ▶AUTO, PUSHAF, MANUAL
2) ZOOM SPEEDSelect the ZOOM SPEED. ▶ 0~7
3) FOCUS SPEEDSelect the FOCUS SPEED. ▶ 0~7
4) DISTANCESelect the minimum DISTANCE in focus between camera and
object.▶ 0.1 ~ 6.0 m
5) DZOOM COMBISelect the Digital-ZOOM DISPLAY. ▶ ON,OFF
6) ZOOM DISPSelect the ZOOM DISPLAY. ▶ON,OFF
7) LENS INITThe LENS INITIALIZATION.
►
AUTO
OFF
LENS
EXPOSURE
AWB
WDR/BLC
DAY&NIGHT
FUNCTION
SYSTEM
EXIT
<SETUP>
0.1M
FOCUS MODE
ZOOM SPEED
FOCUS SPEED
DISTANCE
DZOOM COMBI
ZOOM DISP
LENS INIT
RETURN
<ZOOM LENS>
OFF
OFF
IIIIIIIII 5
AUTO
IIIII II 2II
<LENS>
<EXPOSURE>
The LENS menu is used to set the AF lens control and initialization. It provides the
ability to adjust zoom speed, focus speed, distance and lens initialization functions
of the camera.

8
<EXPOSURE>
F1.8
F NO
RETURN
<IRIS>
<EXPOSURE>
AUTO
AUTO
IIIIIIIII 7
IIIIIIIII 5
OFF
OFF
OFF
IRIS
SHUTTER
BRIGHTNESS
AGC
DSS
ACE
DEFOG
RETURN
►
AWB
The screen color can be adjusted by using the Auto White Balance function. It
compensates for deviations in the white color caused by changes in the color
temmperature of the light source so that the colors are reproduced correctly.
1) AUTO Automatically adjust color temperature.
2) AUTOext Automatically extended range of color temperature adjustment.
3) PRESET Automatically readjust only by pressing PRESET.
4) MANUAL Manual mode.
User can change Red and Blue gain value manually.
COLOR TEMPERATURE LOW, MIDLE, HIGH
R-GAIN 0 ~ 20
B-GAIN 0 ~ 20
<MANUAL>
►AUTO
OFF
LENS
EXPOSURE
AWB
WDR/BLC
DAY&NIGHT
FUNCTION
SYSTEM
EXIT
<SETUP>
<AWB>
COLOR TEMP
R-GAIN
B-GAIN
RETURN
MIDDLE
IIIIIIIII 10
IIIIIIIII 10
WDR/BLC
The WDR/BLC menu is used to the ability to expand the dynamic range and to prevent
back lighting from the image.
1) WDR Select the Dynamic Range level.
* When WDR is ON, ACE and DEFOG function can not turn on.
GAIN Adjust gain level. ▶ 0 ~ 10
WEIGHT
2) BLC Adjust the size of Back Light Compensation area.
X-POS Adjust the window X-Axis position.
Y-POS Adjust the window Y-Axis position.
X-SIZ Adjust the window X-Axis size.
Y-SIZ Adjust the window Y-Axis size.
Adjust WDR level. ▶ 0 ~ 4

9
<DAY&NIGHT>
The DAY&NIGHT menu is used to configure the day and night related setting for the camera.
1) D&N AUTO
- Input Method SENSOR
DAY&NIGHT mode are changed according to the sensor inputs.
MODE Select input mode. ▶ SENSOR, AGC
D&N LEVEL Adjust levels of transition ▶ 0 - 255
N&D LEVEL Adjust levels of transition ▶ 0 - 255
DELAY 1 - 60 SEC
- Input Method AGC
DAY&NIGHT mode are changed according to the brightness of the image. Use only when the
camera is installed in a dark place but the camera is viewing a bright place.
When used in a normal installation, hunting may occur.
MODE Select input mode. ▶ AGC, SENSOR
D&N LEVEL Adjust levels of transition ▶ 0 - 255
N&D LEVEL Adjust levels of transition ▶ 0 - 255
DELAY 1 - 60 SEC
2) D&N B&W
SMART IR ON, OFF
LEVEL 1 - 20
DAY&NIGHT
►
AUTO
OFF
LENS
EXPOSURE
AWB
WDR/BLC
DAY&NIGHT
FUNCTION
SYSTEM
EXIT
<SETUP> <D&N AUTO>
MODE
D▶N LEVEL
N▶D LEVEL
DELAY
RETURN
SENSOR
IIIIIIIII 20
IIIIIIIII 70
3 SEC
<D&N B&W>
SMART IR
LEVEL
RETURN
ON
IIIIIIIII 7
< WDR/BLC>
►
AUTO
OFF
LENS
EXPOSURE
AWB
WDR/BLC
DAY&NIGHT
FUNCTION
SYSTEM
EXIT
<SETUP> <WDR>
GAIN
WEIGHT
RETURN
IIIIIIIII 10
IIIIIIIII 2
<BLC>
X-POS
Y-POS
X-SIZ
Y-SIZ
RETURN
IIIIIIIII 6
IIIIIIIII 6
IIIIIIIII 7
IIIIIIIII 7

10
The IMAGE menu provides the ability to adjust the CHROMA, SHARPNESS, EFFECT,
STILL, SHADING, HLMASK, DZOOM and GAMMA functions of the camera.
1) CHROMA Adjust the CHROMA level. ▶ 0 ~ 20
2) SHARPNESS Adjust the SHARPNESS level. ▶ 0 ~ 10
3) EFFECT OFF, MIRROR, FLIP, ROTATE
4) STILL Select real or still mode. ▶ ON, OFF
5) SHADING Select the lens SHADING compensation. ▶ ON, OFF
6) HLMASK Mask the high light zone with specific color & level.
- MLASK
LEVEL Adjust High Light Mask level. ▶ 0 - 20
COLOR Select Color mask. ▶ BLACK, WHITE, YELLOW, CYAN,
GREEN, MAGENTA, RED, BLUE
-SMART HLC
LEVEL Adjust High Light Mask level. ▶ 0 - 15
DELAY Adjust DELAY time. ▶ 1 - 15 SEC
7)DZOOM Adjust the Digital ZOOM level. ▶ 0 ~ 120
8)GAMMA Adjust the GAMMA level. ▶ 0 ~ 4
<IMAGE>
►
AUTO
OFF
LENS
EXPOSURE
AWB
WDR/BLC
DAY&NIGHT
FUNCTION
SYSTEM
EXIT
<SETUP>
OFF
CHROMA
SHARPNESS
EFFECT
STILL
SHADING
HLMASK
DZOOM
GAMMA
RETURN
<IMAGE>
OFF
OFF
OFF
IIIIIIIII 15
IIIIIIIII 5
IIIIIIIII 0
IIIIIIIII 1
<HLMASK>
<HLMASK>
LEVEL
COLOR
RETURN
IIIIIIIII 17
BLACK
<SMART HLC>
LEVEL
DELAY
RETURN
IIIIIIIII 8
3 SEC
OFF
CHROMA
SHARPNESS
EFFECT
STILL
SHADING
HLMASK
DZOOM
GAMMA
RETURN
<IMAGE>
OFF
OFF
OFF
IIIIIIIII 15
IIIIIIIII 5
IIIIIIIII 0
IIIIIIIII 1
►

11
FUNCTION
The IMAGE menu provides the ability to adjust the DNR, MOTION DET, PRIVACY,
SHADING DET, DEFECT DET and PRESET functions of the camera.
1) DNR Select Digital Noise Reduction.▶ OFF, LOW, MIDDLE, HIGH
2) MOTION Detects the Motioned Object in the image. ▶ ON, OFF
RESOLUTION
SENSITIVITY
WINDOW USE
X-POS Adjust the AREA X-Axis position. ▶ 0 - 58
Y-POS Adjust the AREA Y-Axis position. ▶ 0 - 32
X-SIZ Adjust the AREA X-Axis size. ▶ 2 - 60
Y-SIZ Adjust the AREA Y-Axis size. ▶ 2 - 34
ALARM Motion Alarm ▶ ON, OFF
PRESET ▶ ON, PRESET - 6.
DWELL TIME Keep alarm out during dwell time. ▶ 3 - 60 SEC
3) PRIVACY Hide an area you want to hide on the screen.
4) SHADING DET Compensates for lens SHADING.
5) DEFECT DET Compensates for bad pixels.
6) PRESET ▶PRESET - 6.
<FUNCTION>
►
AUTO
OFF
LENS
EXPOSURE
AWB
WDR/BLC
DAY&NIGHT
FUNCTION
SYSTEM
EXIT
<SETUP>
DNR
MOTION
PRIVACY
SHADING DET
DEFECT DET
PRESET
RETURN
<FUNCTION>
OFF
MIDDLE
OFF

12
FUNCTION
<MOTION>
<ALARM>
RESOLUTION
SENSITIVITY
WINDOW USE
X-POS
Y-POS
X-SIZ
Y-SIZ
ALARM
RETURN
<MOTION>
IIIIIIIII 2
IIIIIIIII 10
ON
IIIIIIIII 20
IIIIIIIII 6
IIIIIIIII 20
IIIIIIIII 20
OFF
►
DWELL TIME
RETURN
<ALARM>
3 SEC
RESOLUTION
SENSITIVITY
WINDOW USE
X-POS
Y-POS
X-SIZ
Y-SIZ
ALARM
RETURN
<MOTION>
IIIIIIIII 2
IIIIIIIII 10
ON
IIIIIIIII 20
IIIIIIIII 6
IIIIIIIII 20
IIIIIIIII 20
OFF
DNR
MOTION
PRIVACY
SHADING DET
DEFECT DET
RETURN
<FUNCTION>
OFF
MIDDLE
OFF
►
<PRIVACY>
DNR
MOTION
PRIVACY
SHADING DET
DEFECT DET
PRESET
RETURN
<FUNCTION>
OFF
MIDDLE
OFF
►
ZONE SELECT
ZONE USE
X-POS
Y-POS
X-SIZ
Y-SIZ
COLOR
TRANS
RETURN
<PRIVACY>
0
OFF
IIIIIIIII 9
IIIIIIIII 4
IIIIIIIII 3
IIIIIIIII 3
WHITE
IIIIIIIII 4
<SHADING DET>
TURN LENS TO LOOK WHITE
ENTER KEY FOR START
OTHER KEYS FOR RETURN
<SHADING DET>
PROCESSING
<SHADING DET>
<DEFECT DET>
COVER THE LENS
ENTER KEY FOR START
OTHER KEYS FOR RETURN
<DEFECT DET>
DIR KEYS FOR THRESHOLD ADJ
ENTER KEY FOR FINISH
THRESHOLD 0000000009
<DEFECT DET>

13
1) RS485
CAM ID Select the CAMERA ID. ▶ 1 - 255
PROTOCOL Select RS485 PROTOCOL. ▶ FASTRAX, PELCO-P, PELCO-D,COMMAND
BAUD RATE Select serial communication speed.▶2400, 4800, 9600, 19200, 38400 BPS
SAVE Save the current settings.
2) CAM TITLE Maximum of 10 characters are allowed.
3) DISPLAY Set the position of the camera ID. & title.
4) OUT MODE Image output method.
RESOLUTION Select Digital output 1080P or 720P. ▶ 1080P, 720P
VIDEO MODE Select NTSC or PAL.
CVBS SCALE Select image scale. ▶ CROP(4:3), OFF, FULL(4:3)
COLOR RANGE Select image color range. ▶ CLIP, FULL
5) LANGUAGE OSD menu LANGUAGE.
6) VERSION Firmware VERSION.
7) RESET Factory initialization of camera settings. ▶ NTSC, PAL
SYSTEM
The IMAGE menu provides the ability to adjust the RS485, CAM TITLE, DISPLAY,
OUT MODE, LANGUAGE, VERSION and RESET functions of the camera.
<SYSTEM>
►
AUTO
OFF
LENS
EXPOSURE
AWB
WDR/BLC
DAY&NIGHT
FUNCTION
SYSTEM
EXIT
<SETUP>
RS485
CAM TITLE
DISPLAY
OUT MODE
LANGUAGE
VERSION
RESET
RETURN
<SYSTEM>
NTSC/60Hz
<RS485>
ENGLISH
1.0
CAM ID
PROTOCOL
BAUD RATE
SAVE
RETURN
<RS485>
9600 BPS
IIIIIIIII 1
FASTRAX
RS485
CAM TITLE
DISPLAY
OUT MODE
LANGUAGE
VERSION
RESET
RETURN
<SYSTEM>
NTSC/60Hz
ENGLISH
1.0
►

14
<CAM TITLE>
^ ^ ^ ^ ^ ^ ^ ^ ^ ^
0 1 2 3 4 5 6 7 8 9
A B C D E F G H I J
KLMNOPQRST
UVWXYZ @#$
/ & * ( ) - = : , .
< > CLR RET
<CAM TITLE>
RS485
CAM TITLE
DISPLAY
OUT MODE
LANGUAGE
VERSION
RESET
RETURN
<SYSTEM>
NTSC/60Hz
ENGLISH
1.0
►
<DISPLAY>
CAM ID
ID POS
CAM TITLE
TITLE POS
RETURN
<DISPLAY>
RS485
CAM TITLE
DISPLAY
OUT MODE
LANGUAGE
VERSION
RESET
RETURN
<SYSTEM>
NTSC/60Hz
ENGLISH
1.0
►
<OUT MODE>
RS485
CAM TITLE
DISPLAY
OUT MODE
LANGUAGE
VERSION
RESET
RETURN
<SYSTEM>
NTSC/60Hz
ENGLISH
1.0
►
OFF
TOP-LEFT
OFF
TOP-LEFT
RESOLUTION
VIDEO MODE
CVBS SCALE
COLOR RANGE
RETURN
<OUT MODE>
1080P
NTSC/60HZ
CROP(4:3)
CLIP
SYSTEM

SPECIFICATIONS
Scanning system
Image Sensor
Scanning Mode
Zoom Movement Speed
Digital Zoom
Min. Working Distance
Focusing System
Effective Pixels (H x V)
Image Size (H x V)
Min. illumination
Back Light Compensation
Electronic Shutter Speed
White Balance
AE Control
Wide Dynamic Range
True Day and Night (ICR)
Noise Reduction (2D, 3D)
Slow Shutter
Color Enhancement
Aperture Control
Lens Shading
Defect Suppression
Video Out
Day&Night Ext-In
ALARM Out (Motion Detect)
Camera Control
Camera Title / ID Display
Privacy Zone Masking
Video Preset
Video Motion Detection
Digital PTZ
Video Flip / Mirror / Freeze
Protocol
IR LED/SENSOR
LED Lighting Distance
Power Input
Video Output
Operating Temperature
IP Rating
Meterials
Operating humidity
External Dimension
* Specifications are subject to change without notice.
Progressive
1/2.9” CMOS 2.1M
Progressive Scan
Optical WIDE to Optical TELE: 2.0 sec (Variable)
Digital WIDE to Digital TELE: 4.0 sec
16x (320x with optical zoom)
30 mm (WIDE end), 1000 mm (TELE end)
AUTO, ONE PUSH AF, MANUAL
1920 x 1080
1920 x 1080, 1280 x 720
1.7 Lux(Color), 0Lux (IR LED ON) at F1.6, 50 IRE
Yes (ON/OFF)
1/30 sec ~ 1/60,000 sec (12 steps)
AUTO, AUTOext(Sodium Vapor Lamp), PRESET(One Push), Manual
AUTO, IRIS Manual, SHUTTER Manual
Yes (ON/OFF, Max 15 fps)
0 ~ 96% (non-condensing)
88 (Dia) x 166.8(L) / 286.8(L)mm including bracket
Die-Casting Aluminum
Ip66
-10° ~ +50° C [14℉ ~ 122℉]
BNC Connector
2-Pin Wire (RED, WHITE)
50M
IR LED 90EA, Sensor 1EA
COMMAND, FASTRAX, PELCO-D, PELCO-P, VISCA
Yes
Yes
Yes
Yes
Yes
HD: Digital(SDI), SD: Analog(CVBS)
Yes
Yes
External remote control(ADKEY), RS485
Yes
Max 24
Yes
Specific Area/Full Screen
x16
Yes
Yes (ON/OFF)
YES
MODEL HSUI-H75DxZ2U8
Composite Out NTSC/PAL Selectable
Lens Optical Zoom 20x(f=4.7mm ~ 94.0mm) F1.6(wide)~ F3.5(tele)
Power Source
AC24V / DC12V ± 10%
Power Consumption
10.0Watts (700mA)
POWER
VIDEO Resolution
1080p@30fps, 720p@60fps
Connector
&
ETC
IR LED
