Hitron HCB-J5FD User manual

PRODUCTION RELEASE & REVISION
REV DESCRIPT'N/BUYER DWG No PARTS No. BY CHK DATE
A INITIAL ------------------- 50302575 A.K.HAN N.C.PARK 10-22-M9
105(+/-5)mm
148(+/-5)mm
11-09-M9
MANUAL LABEL : 50201270
유주현
주임
INSTRUCTION MANUAL
WDR Super High Resolution
Day & Night Color Camera
TITLE
SIZE REV.
SCALE
MATERIAL
UNLESS OTHERWISE SPECIFIED
ALL DIMENSIONS ARE IN MM.
- TOLERANCE
LABEL +/- 3
MANUAL +/- 5
GUIDE +/- 5
COLOR
DATE
DRAWN
CHKED
APPROVALS
PARTS LIST
DESCRIPTION/MATERIAL
ITEM QTY
A4
DO NOT SCALE
2B
MANUAL INSTRUCTION
50302575
A.K.HAN
N.C.PARK 11-09-M9
NOTES
1.MODEL: HCB-J5FD_K5(9)FD/NOBRAND
2.MATERIAL: 모조지
3.COLOR: BLACK
4.SIZE: 105(+/-5)mm x 148(+/-5)mm
5.LABEL: 50201270(81mm x 24mm)
6.ANY CHANGE OR ALTERNATION MUST BE
APPROVED BY HITRON DESIGN TEAM.
WHITE
11-09-M9
3
W.S.CHOI 11-09-M9
BIND : STAPLES-2
B 내용변경 축소 ------------------- 50302575 A.K.HAN N.C.PARK 11-09-M9
재고폐기처분 즉시적용

IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the m
anufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plu
g. A polarized plug has two blades with one wider than the other. A gro
unding type plug has two blades and a third grounding prong. The wid
e blade or the third prong are provided for your safety. If the provided p
lug does not fit into your outlet, consult an electrician for replacement o
f the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from th
e apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use cau
tion when moving the cart/apparatus combination to avoid injury from ti
p-over.
13. Unplug this apparatus during lightning storms or when unused for long
periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-su
pply cord or plug is damaged, liquid has been moisture, does not oper
ate normally, or has been dropped.
15. CAUTION –THESE SERVICING INSTRUCTIONS ARE FOR USE B
Y QUALIFIED SERVICE PERSONNEL ONLY. TO REDUCE THE RIS
K OF ELECTRIC SHOCK DO NOT PERFORM ANY SERVICING OT
HER THAN THAT CONTAINED IN THE OPERATING INSTRUCTION
S UNLESS YOU QRE QUALIFIED TO DO SO.
16. Use Certified/Listed Class 2 power source only.

3
CONTENTS OF PACKAGE
Installation of the camera must be performed by qualified service personnel in
accordance with all local and national electrical and mechanical codes.
Carefully remove the colour camera and its accessories from the carton and verify that
they were not damaged in shipment.
The content of the package includes:
1. Color CCD camera
2. Mini-DIN connector (for video-or dc-type auto-iris lens)
3. CS adapter ring for C mounting "C" lenses
4. This manual
TABLE OF CONTENTS
INTRODUCTION ---------------------------------------------------------------------------------------4
CAMERA OVERVIEW --------------------------------------------------------------------------------5
CAMERA ADJUSTMENT ----------------------------------------------------------------------------6
CONTROL AND CONNECTIONS / DAY&NIGHT I/O TERMINALS-----------------------13
LENS -----------------------------------------------------------------------------------------------------14
SPECIFICATIONS -------------------------------------------------------------------------------------15

4
INTRODUCTION
The camera provided high-quality image using SONY Wide Dynamic 1/3”Super-HADII
PS 960H CCD and digital signal processing LSIs.
Features:
1/3" Super-HADII PS 960H CCD
Super high-resolution of 650TV lines
Wide Dynamic Range (~x512)
Excessive High-Light Compensation
Back Light Masking (MAX. 15 area)
2D-NR, 3D-NR (DNR Demo)
Day & Night(Auto, Manual, External, Filter delay)
0.4 lux(Color), 0.04 lux(B/W), 0.001 lux(Low-Shutter) @ F1.4 Sensitivity
Sens-Up (~x32)
Various Detection Method (zone detection, motion trace, face trace, mine area,
absent detection, cross object counting, entrance counting)
Scene Change Detection
Various Alarm Method (Period, Snooze, Polarity Select)
Frame Control (Auto, 1~7 sec)
Privacy Mask or Mosaic (MAX. 15 area/4-point polygonal/transparency)
Digital PTZ
White Pixel Remove
Back Light Compensation
Digital Effect (H/V reverse, 180 degree rotate, inverse, freeze)
System Lock (4-Digit password)
Auto Electronic Shutter [1/50 ~ 1/100,000] and manual electronic shutter
modes [1/50 ~ 1/10,000]
C/CS, back-focus cam for easy adjustment
Auto and Manual white balance modes
Support Line-Lock external synchronization
RS-485 Remote camera control
On Screen Display (OSD)
Compatible with Video, DC type lenses with OSD select
Quick connect for Video or DC lens with 4-pin connector
User Certified / Listed Class 2 power source only
Operates in 12VDC or 24VAC

5
CAMERA OVERVIEW
FRONT VIEW
SIDE VIEW
TOP VIEW


REAR VIEW (Free Voltage)







Left Button
Up Button
Enter Button
Right Button
Down Button
Day/Night External I/O
Motion ALARM OUT
RS - 485
UTP(optional)
Power Indicator
Video Output Connector (BNC)
UTP or BNC Transformation Switch
(optional)
AC/DC Compatible Input Terminal
AC Power Cord
REAR VIEW











6
CAMERA ADJUSTMENT
<White Balance>
1) Auto(Auto White Balance) : AWB mode (1800ºK ~10500ºK)
2) Push/Hold : Push&Hold Mode.
To find the Optimal setting for the current luminance environment in this mode,
set the direction towards a sheet of white paper and select Hold and press enter
button. If the environment changes, readjust it.
3) CRS Mode(Color Rolling Suppression) : Decrease color rolling effect.
This operation take some time about 10 seconds and user can stop this
operation by pressing enter button.
When CRS Mode is on, color tone can be weak.
4) Indoor : Set color temperature to indoor (3200ºK)
5) Outdoor : Set color temperature to outdoor (6300ºK)
6) FL(Fluorescent Light) : Set color temperature to fluorescent light fixed gain.
7) User(User Set White Balance) : Adjust red or blue gain.
R(R-GAIN):Adjust R-GAIN value (0-255)
B(B-GAIN):Adjust B-GAIN value (0-255)
<Auto Exposure>
1) SHT(s)(Electronic Shutter) : Select Shutter mode.
Auto(1/60(1/50) ~ 1/100,000 Auto run, Manual 8 step from 1/60(1/50) ~1/10,000).
2) FLC(Flicker-less) : Flicker-less On/Off.
3) AGC(Auto Gain Control) : AGC Gain(Off, Low, Middle, High)
4) Sens-Up(Slow Shutter) : Maximum Low-Shutter select. (x2-x32 and Off)
5) Offset Add : Force the picture to turn up at low luminance environment.
<BLC/WDR>
1) Normal AE : BLC/WDR function off.
2) WDR(Wide Dynamic Range) : Wide dynamic range mode on.
3) EHLC(Excessive High Light Compensation) : EHLC mode on.
excessive lighting compensation is performed when the weighting on the
high-brightness side is increased.
4) Auto(Auto Weighting BLC) : Auto weighting BLC on.
5) Spot(User Setting BLC area) : Spot metering mode on.
Posi : OSD mode to adjust the position of the spot metering area.
Size : OSD mode to adjust the size of the spot metering area.
6) Zone(Preset BLC area) : Fixed metering area mode. (1-9).
<Mask>
1) Mask: Select mask area(1-15).
2) Func: Select mask function.(Privacy, BLM, Both, Off).
Privacy : Area to screen on the display.
BLM : Back Light Mask.
Selected BL Mask area that will be except of the auto exposure
If there is a high light installed in a limited environment such as an
apartment parking garage or gas station entrance, removing the high light
makes it possible to view car license plates efficiently.

7
Both : Privacy function and BLM function on.
Off : Function off.
3) Edit : Mask area edit.
Edit mode take effect during Func not Off.
Size : adjust the size of the Privacy and BLM mask area.
Posi : adjust the position of the Privacy and BLM mask area.
Tilt : adjust tilting of Privacy and BLM mask area.
Color: Select Privacy and BLM mask (0-14).
Transparency: Select Privacy mask transparency (Default 3/0-3).
Mosaic: Select Privacy and BLM mask mosaic On/Off
Adj. Mosaic: Adjust Privacy and BLM mask mosaic level (0-31).
<Detection>
Func : Detection function selection.
Sens Down : Adjust to Motion Sensitivity using left/right Buttons.
1) OFF : Detection function off.
2) Zone : Area motion detection mode.
Zone : Select Motion detection zone (Zone1-4).
Func : Select Motion detection on/off.
Size : Press Enter button to adjust the size of the Motion detection area.
Posi : Press Enter button to adjust the position of the Motion detection area.
Link Zoom : Select Motion detection with D-PTZ function that On/Off .
When the motion triggered in the area, zoom and move to the area with
D-PTZ.
3) Motion Trace : Motion trace mode on.
Tracks an object through a scene and generates an alarm.
4) Face Trace : Face Trace mode on.
Tracks face through a scene and generates an alarm.
Sens Down : lower value is more widen the scope to judge face. (0~127)
Min Size : Minimum face size configuration (0 : minimum face size is to none)
The result of face trace can be inaccuracy.
5) Mine : Mine area mode.
By this function, User can draw motion detection area with free dotting
Set Mine : Press the Enter button to Set Mine mode.
< > : Move : Mine Zone move using the Left and Right buttons.
UP:Set : Mine Zone setting using the Up button.
DN:Clr : Mine Zone clear using the Down buttons.
ENT:End : Press the Enter button to set Mine mode end.
Clr All : Press the Enter button to set Mine area clear.
Display : Select Mine Display On/Off.
6) Absent : Press the Enter button to Absent detection mode.
Absent : Detect object appeared or removed the scene.
Sens Down : Adjust sensitivity of Absent check(0-255).

8
In low luminance environment, the accuracy is down of the result.
Because object color is effect to auto exposure, the accuracy is down of the result
If the object is too big, the accuracy is down of the result.
7) Cross : Cross counting mode.
Zone : Select Cross Zone using the Left and Right buttons (Zone 1, Zone 2).
Size : Adjust the size of the Cross zone.
Posi : Adjust the position of the Cross zone.
Direction : Select Cross Direction.
Alarm Cnt : Set alarm out cross count. Alarm count number is delaying number
before output alarm.
Reset Cnt : Cross count reset.
If object is passing so fast through the two area, counting is not operating. In this case,
adjust to expand space between two area or adjust to decrease size of
area.
If passing object is too long, counting result can be inaccuracy. In this case, adjust to
expand space between two area or adjust to decrease size of area.
If two object passing the area in the same time, the result can be inaccuracy.
8) Entrance : Entrance counting mode. The object move in through the entrance,
counting number increases.
Size : Press Enter button adjust the size of the Entrance zone.
Posi : Press Enter button adjust the Position of the Entrance zone.
Alarm Cnt : Set alarm out entrance count. Alarm count number is delaying
number before output alarm.
Reset Cnt : Entrance count reset.
Crossing object is not considered. / Several object will not be detected.
If the distance is increases between the camera and entrance, the result can be
inaccuracy.

9
<Picture/DNR>
1) Sharpness : Adjust sharpness of outlines (0~15)
2) Resolution : Select high resolution mode (Low/Mid/High)
3) 2D-NR : Select 2D noise reduction level (0~6)
2D-NR : Noise reduction on a frame
4) 3D-NR : Select 3D noise reduction level (0~31)
3D-NR : Noise reduction through the several frame
5) DNR Demo : Select DNR Demo Display On/Off using the Left and Right Buttons
None DNR Effect
Display
DNR Applied
Display
<Effect/Special>
1) d-Effect(Digital Effect) : Select digital Flip/Rotate state (Off/Rotation/Mirror/V Flip )
2) Nega : Select negative color state(on/off)
3) d-PTZ (Digital Pan, Tilt, Zoom) : Adjust d-PTZ.
Func : Press the Enter button to turn digital zoom on/off.
Zoom : Use the Left and Right buttons adjust to digital zoom(0-255).
Pan&Tilt : Press the Enter button to access the Pan&Tilt.
Use the Left and Right buttons adjust to digital pan
Use the Up and Down buttons adjust to digital tilt
Press the Enter button to exit.
PT Reset(Pan & Tilt Reset) : Press the Enter button to reset digital pan and tilt.
4) Freeze : Select the still mode on/off
5) Frame Control: Select term of refresh rate for output video. This function is useful to
reduce the recording data storage.
Func : Select frame control mode to ON/OFF, and Auto.
Auto mode : When motion is not detected, output video is being refresh
in configured interval. And when the motion is detected, output video is
switched to real time video.
ON : Always refresh in configured interval.
OFF : Always real time video.
Renewal(sec) : Select an interval between two frame.
When object start moving, The output video possible to cut a little time.
Several Object
Crossing Object
Camera Installed at the ceiling
Crossing object is none
One object is passing.
The distance is too long

10
A. Title
B. Delete character
C. Character table
D. Command line
- Clear : Clear Title
- Cancel: Cancel editing
- Accept: Save Title
6) ScnChg/Unfoc : Select scene change/unfocus detection On/Off .
Inform that whether scene have been changed or not. Detect breaking or
changing in the watching scene (Spray, Screen Camera, Changing Scene…)
This function is linked with alarm out
In low luminance environment, the accuracy is down of the result.
In very low luminance environment, operation is not be performed.
It is not be performed when moving object is exist.
<System Setup>
1) Cam Info : Camera basic information display
Cam ID/Baud rate/Protocol/Firmware Ver./CCD Type/Lens Type
2) General Setup
System Lock : Configuration Lock.
When system lock is set to “Lock”, User must to input 4-character
password to enter OSD menu.
Default password is “0000”.
Change PID : Change the administrator’s password
Move cursor with OSD Key and Press Enter to input the character.
Comm(RS 485 Communication) : Press the Enter button to access the Comm.
Cam ID : Select the camera ID (001 - 255).
Baud Rate : Select serial communication speed (2400/4800/9600/19200).
Protocol : RS-485 protocol. (COMMAND/FASTRAX/PELCO-D/Pelco-D)
Title : Edit camera title.
Display : Display item select.
Cam ID : Camera ID display On/Off.
Title : Title display On/Off.
Title Site_0
☞< > ENT:Del
Clear Cancel Accept
ABCDEFGHIJKLM
NOPQRSTUVWXYZ
abcdefghijklm
n o p q r s t u v w x y z
-. 0123456789
A
B
C
D

11
Alarm .
Period : Alarm out period (5sec/10sec/20sec/30sec/1min/5min/Cont.)
Snooze : Alarm out snooze(Off/5sec/10sec/20sec/30sec/1min/5min)
Active pol : Alarm output active state configuration. (Low, High)
System Init
Cancel : Back to General Setup Menu.
Confirm : Initialize all data. (Factory Default)
3) Lens
Iris : DC, Video, Manual Lens selected Iris : adjust AE Speed
DC lens and video lens can adjust AE Speed
Normal AE Ref (Auto Exposure Reference Level) : Press the Enter button to
access the AE Ref.
Ref Lvl : Adjust AE base reference level.
WDR Ref : Press the Enter button to access the WDR Ref.
Ref Lvl : Adjust the WDR long-time control Base Reference Level.
4) LLC(Line Lock Control) : Press the Enter button to access the Line Lock mode.
Func : Select Line Lock function On/Off using the Left and Right buttons.
Phase : Adjust Line Lock sync phase using the Left and Right buttons. (0~100)
Activate only AC power inputted.
5) White Pixel
Det Exe : Press Enter button to turn White Pixel Compensation mode Start.
ENT to Adj : Press Enter button to start White Pixel Compensation start.
Proc : Process to find white pixel.
Done : Process ended
Det Count : Result of white pixel detection.
Func : Select erasing white pixel function On/Off using the Left and Right buttons.
Det Level : Select the judgment level of white pixel using the Left and Right
buttons (1~16)
Det View : Select display of detected white pixel.
6) Day/Night
Mode : Select D&N mode.
Auto : Filter operates automatically according to brightness.
Day : The camera outputs the video image only in color.
Night : The camera outputs the video image only in black and white.
Ext : This menu automatically converts the COLOR Mode into the B/W
Mode or vice versa depending on illumination with an external sensor.
Night Mode : Select B/W Burst On/Off
Delay(s) : Adjust the working time of the filter when D&N mode is Auto (1-60 sec).
D>N Level : Select switching level Day to Night when D&N mode is Auto (0-15).
N>D Level : Select switching level Night to Color when D&N mode is Auto (0-15).

12
<Bottom Line Menus>
When user entered in main menu and sub-menus, following menus will be appeared.
I. Main Manu (menu in bottom lines)
A. Exit : Save & Exit.
B. Load : Load Default Value.
II. Sub Menu (menu in bottom lines)
A. Return : Return to previous menu.
B. Exit : Save & Exit
1) Exit Menu
Save&Exit : Current environment values save.
Exit : Disappear menu osd.
2) Load Default Setup
Yes : Load default to current configuration. and return to previous menu.
No : No operation, and return to previous menu.

13
CONTROL AND CONNECTIONS/DAY&NIGHT
I/O / ALARM OUT TERMINALS
1
2
3
4
5
6
7
8
UTP-
(optional)
UTP+
(optional)
D&N I/O
COM
ALARM
RS-485
IN
OUT
GND
OUT
RS-485+(RX)
RS-485-(TX)
1) UTP Connections/Video output (optional)
●1 PIN: UTP-
●2 PIN: UTP+
2) DAY&NIGHT I/O Terminals
To select Day/Night mode using external equipment, by connecting control lines
to the appropriate terminals.
●DAY&NIGHT OUTPUT (4pin)
Is the camera function that can turn on an external IR LED Lamp by detecting the
sensitivity on the AGC level when the D&N mode is set "AUTO" on the OSD menu of the
camera
●DAY&NIGHT EXTERNAL INPUT (3pin)
Is the camera function that can be switched to DAY Mode or NIGHT mode by receiving
the D&N on/off signal from external light sensor or IR LED LAMP. This needs the D&N
Mode to be set to "External" on the OSD menu of the camera to work
3) ALARM OUT (6pin)
Motion detection signals are output through this port. Active state is configurable.
4) POWER INPUT TERMINAL
●This terminal accepts a DC12V or AC24V power
source from a DC12V or AC24V ac +/-10%
60/50Hz +/- 1Hz.
●Use Certified/Listed Class 2 power supply only.
●It is recommended to use the DC power supply that can
support inrush current over 0.75A
●AC Power Cord - This power cord accepts a
100-240V ~ 50Hz +/- 1Hz
5) CAMERA CONTROL
●7 PIN: RS 485+
●8 PIN: RS 485-
4 DAY&NIGHT OUTPUT
5 COM
5 COM
3 DAY&NIGHT INPUT
CLASS 2
+ DC 12V -
~ AC 24V ~
AC 100-240V
●5V/10mA : IR LED ON (NIGHT)
●0V : IR LED OFF (DAY)
Open contact: DAY
Close contact: NIGHT

14
LENS
The lens is not supplied with this camera. Purchase a lens suitable for your
requirements. These cameras accept both C-and CS-mount type lens.
<INSTALLING AUTO IRIS LENS>
1. Remove the cover from the iris lens plug supplied, and solder the lens cable to the
plug as shown below.
2. Remove the protective cap, and attach the lens to the camera by turning clockwise.
<Notes >
●For using main functions it is recommended to use Auto Iris Lens with DC
type.
●If the lens is marked with fingerprints other marks, the image quality might
be poor.
●It is recommended to use a high quality lens to improve the image quality
under low illumination.
●Video type:
Pin 1 --- Red (Power source)
Pin 2 --- N.C
Pin 3 --- White (Video signal)
Pin 4 --- Black (GND)
●DC type:
Pin 1 --- Damping-
Pin 2 --- Damping+
Pin 3 --- Drive+
Pin 4 --- Drive-
Pin 3
Pin 1
Rib
Pin 4
Pin 2
Connector
Cover
Heat
Shrinkable
Tubes
Automatic
Iris Lens
Iris Control
Cable
Connector

15
SPECIFICATIONS
MODEL
NTSC
PAL
PAL(Free Voltage)
G
E
N
E
R
A
L
Image sensor
1/3" Super-HADII PS 960H CCD
Effective pixels
976x494
976x582
Scanning system
2:1 interlace
Scanning frequency
15.734KHz(H), 59.94Hz(V)
15.625KHz(H), 50Hz(V)
Sync. system
Internal / Line lock
Resolution
650 TVL
Min. illumination
0.4 Lux (COLOUR), 0.04 Lux (B/W), 0.001 Lux (Low-shutter)
Video output
1.0 Vp-p (75 ohm, composite)
S/N Ratio
50dB (AGC OFF)
Camera Control
RS485 (Faxtrax, Pelco D, Pelco P)
F
U
N
C
T
I
O
N
White Balance
Auto / CRS / Push&Hold / Indoor / Outdoor / FL / User
Exposure
Auto / Manual Shutter / Flickerless/ Low Light Control / Offset Add
BLC/WDR
EHLC / AUTO / SPOT / ZONE/ BLM WDR: x512 (Level Adjust)
AGC Control
Low / Middle / High / Off
Shutter Speed
1/60-1/10,000
(Auto:1/100,000)
1/50-1/10,000 (Auto:1/100,000)
Sens-Up
x32
Day/Night
Auto / Day / Night / Ext
Video Analytics
Zone / Motion trace/ Face trace/ Minefield/ Absent / Cross / Entrance/
Scene Change Detection
D-Zoom
~ x256(Zoom) / D-PTZ Support
DNR
2DNR, 3D NR :Gain Adjust, DNR Demo
Privacy Zone
Max 15 (Tilt, Color, Transparency, Mosaic)
Camera Title
Alpha Numeric
Display
On / Off (Cam ID, Title)
Cam ID
001~255
Effect
V-Flip / Mirror / Rotation / Nega&Posi / Freeze / Sharpness
Bad Pixel
Adj/Done (Max 64 point), Detected pixel display
System Lock
Lock/Unlock (need Password input when Locked)
Frame Control
Auto, Off ~ 7Sec( Use for saving storage)
Language
English
Other Function
Admin Password, Alarm Setting(Period, Snooze, Polarity)
P
O
W
E
R
Power source
DC 12V / AC 24V ± 10%
100-240V~50Hz ±
1Hz
Power consumption
4.5 Watts
Power input
2-Pin Terminal block
Power Cord
E
T
C
Video output
BNC, UTP (optional)
Auto iris output
4-Pin mini din jack (standard connection)
Lens mount
C/CS mount (Selected through back focus)
Mounting hole
1/4''-20 UNC (top or bottom)
Operating Temp.
-10ºC to +50ºC
Operating humidity
Less than 90%
External dimension
66 (W) x 56 (H) x 120 (D)mm/Weight : 265g
66 (W) x 56 (H) x 120
(D)mm / Weight :
450g

50302575B
