HMS Networks Intesis INMBSMEB 0100 Series Assembly instructions

Installaon Sheet for INMBSMEBxxx0100
xxx stands for the gateway capacity and varies depending on the specic gateway
purchased.
Version: 1.0.0
Owner's record
Find the serial number on the silver label on the right side of the gateway. For sales
or technical assistance, we recommend wring it in the space below:
SN:
Safety Informaon
Follow these instrucons carefully. Improper work may seriously harm
your health and damage the gateway and/or any other equipment
connected to it.
Only technical personnel, following these instrucons and the country legislaon for
installing electric equipment, can install and manipulate this gateway.
Install this gateway indoors, in a restricted access locaon, avoiding exposure to
direct solar radiaon, water, high relave humidity, or dust.
All wires for communicaon and power supply (if needed) must only
be connected to networks without roung to the outside plant. All
communicaon ports are considered for indoor use and must only be
connected to SELV circuits.
Mount the gateway, preferably, on a DIN rail inside a grounded metal cabinet
following the instrucons below.
In the case of wall mounng, rmly x the gateway on a non-vibrang surface
following the instrucons below.
Disconnect power wires before manipulang and connecng them to the gateway.
Use SELV-rated NEC class 2 or limited power source (LPS) power supply.
Supply the correct voltage to power the gateway. See the Technical Specicaons
table at the end of this document.
Respect the expected polarity of power (if needed) and communicaon cables when
connecng them to the gateway.
This gateway is designed for installaon inside an enclosure. When working inside
an enclosure (ex. to make adjustments, set switches, etc.) observe the common
anstac precauons before manipulang the gateway.
Take precauons when installing it outside an enclosure, in environments with stac
levels above 4 kV, to avoid electrostac discharges.
For safety instrucon in other languages, see
hps://intesis.com/docs/manuals/v6-safety
Conguraon
Use the Conguraon tool to congure the gateway.
1. See instrucons on how to download and install the latest version at:
hps://www.intesis.com/products/intesis-maps.
2. Use the Ethernet port to connect the gateway to a PC running the Conguraon
tool. For more info, refer to the User manual.
Mounng
Do not mount the gateway in air-handling units or conducts.
DIN rail mounng inside a grounded metallic cabinet is
recommended.
Wall mounng
1. Press the rear panel clips unl you hear a click.
2. Use the clip holes to screw the gateway to the wall.
3. Make sure the gateway is rmly xed.
DIN rail mounng
Keep the top side clip in its original posion.
1. Insert the gateway in the upper edge of the DIN rail.
2. Fit the low side of the gateway in the DIN rail.
3. Push the boom clip back to its original posion, locking the gateway to the rail.
4. Make sure the gateway is rmly xed.
Installaon Sheet | Publicaon date: 2023-06-07
© HMS Industrial Networks SLU | www.hms-networks.com

Wiring
• Read the Safety Instrucons before wiring the gateway.
• Disconnect all installaon equipment from the power source before
wiring the Intesis gateway.
Figure 1. Wiring diagram (wire colors are indicave only)
Connectors
1 Power supply (24 VDC) 2 Port A: M-Bus 3 Ethernet: Modbus TCP
and console
Wiring procedure
1. Connect a SELV-rated NEC class 2 or limited power source (LPS) power supply to
the Intesis gateway.
• This power supply must not be shared with other devices.
• Apply the correct voltage and power. Recommended: 24 VDC +/-10% (see the
Technical Specicaons table at the end of this document).
• Connect the gateway's ground terminal to the installaon grounding.
• Use a circuit breaker before the power supply. Rang: 250 V, 6 A.
2. Connect the Modbus TCP bus to the Ethernet port of the gateway.
• Use an Ethernet CAT5 or higher cable.
• In using the building LAN, contact the network administrator and make sure
trac is allowed.
• When starng up the gateway for the rst me, DHCP will be enabled for 30
seconds. Aer that me, the default IP 192.168.100.246 will be set.
3. Connect the M-BUS bus to the Port A of the gateway.
• Respect the polarity:
Port A connectors M-Bus wires
A1 +
A2 -
• The gateway provides 36 VDC voltage to the M-BUS bus.
Keep communicaon cables away from power and ground wires.
Technical Specicaons
Enclosure
Plasc, type PC (UL 94 V-0)
Net dimensions (DxWxH): 93 x 53 x 58 mm / 3.7 x 2.1 x 2.3”
Recommended space for installaon (DxWxH): 100 x 60 x 70
mm / 4 x 2.4 x 2.8"
Color: Light grey. RAL 7035
Weight 175 g (6.2 oz)
Terminal wiring
for low-voltage
signals
Per terminal: solid wires or stranded wires (twisted or with
ferrule). Wire cross-secon/gauge:
1 core: 0.5 to 2.5 mm2 (24 to 11 AWG)
2 cores: 0.5 to 1.5mm2 (24 to 15 AWG)
3 cores: not permied
Power supply
1 x Green pluggable terminal block (3 poles)
24 VDC, Max.: 220 mA, 5.2 W
Use SELV-rated NEC class 2 or limited power source (LPS)
power supply
Mounng Wall or DIN rail
Ethernet port
1 x Ethernet 10/100 Mbps RJ45
2 x Ethernet LED: port link and acvity
Port A: M-Bus
1 x Green pluggable terminal block (2 poles)
M-Bus power consumpon: 90 mA
Voltage rang: 36 VDC
Operaonal
temperature
Celsius: 0 to +60°C
Fahrenheit: 32 to 140°F
Operaonal
humidity 5% to 95%, non-condensing
Protecon IP20 (IEC60529)
Disposal and Recycling
This product contains electronic components and must be properly
disposed of according to local laws and regulaons. For further
informaon, refer to: hps://www.intesis.com/weee-regulaon
For further informaon on the installaon, connecon, and conguraon of this
gateway, refer to the User manual.
