New Rock Technologies MX8G User manual

MX Series Voice Gateway User Manual
New Rock Technologies, Inc.
MX Series Voice Gateway
User Manual
HX4E
HX4G
MX8A
MX8G
MX60
MX60E
MX120G
Website: http://www.newrocktech.com
Email: [e-mail]
Document Version: 201711

User Manual MX Series Voice Gateway
Amendment Records
Document Rev. 03 (November 2017)
Added HX4G and MX8G. This manual is applicable to New Rock's HX4G/MX8G Voice Gateway V356,
HX4E/MX8A/MX60E/MX120G Voice Gateway V351, and MX60 Voice Gateway V344.P2.
Document Rev. 02 (March 2017)
Added MX60E, and removed MX120. This manual is applicable to New Rock's MX series Voice
Gateway V351.
Document Rev. 01 (June 2016)
This manual is applicable to New Rock’s MX series Voice Gateway V344.
Copyright © 2017 New Rock Technologies, Inc. All Rights Reserved.
All or part of this document may not be excerpted, reproduced and transmitted in any form
or by any means without prior written permission from the company.

MX Series Voice Gateway User Manual
New Rock Technologies, Inc. 3
Contents
Amendment Records................................................................................................................................. 2
Contents..................................................................................................................................................... 3
Figures ....................................................................................................................................................... 7
Tables....................................................................................................................................................... 10
1 Overview................................................................................................................................................ 13
1.1 Product Introduction...................................................................................................................................................................13
1.2 Functions and Features.............................................................................................................................................................14
1.3 Equipment Structure...................................................................................................................................................................15
1.3.1 HX4E/HX4G....................................................................................................................................................................15
1.3.2 MX8A/MX8G...................................................................................................................................................................17
1.3.3 MX60.................................................................................................................................................................................20
1.3.4 MX60E..............................................................................................................................................................................22
1.3.5 MX120G...........................................................................................................................................................................25
1.4 Web Management Page............................................................................................................................................................28
1.4.1 Layout...............................................................................................................................................................................28
1.4.2 Buttons Used on Gateway Management Interface................................................................................................28
2 Parameters Setting ............................................................................................................................... 29
2.1 Login..............................................................................................................................................................................................29
2.1.1 Obtaining Gateway IP Address ..................................................................................................................................29
2.1.2 Logging On to Web GUI...............................................................................................................................................29
2.1.3 Privileges of Administrator and Operator (Web GUI)............................................................................................30
2.1.4 Accessing Through SSH..............................................................................................................................................31
2.1.5 SSH user Permissions..................................................................................................................................................31
2.2 Basic Configuration ....................................................................................................................................................................32
2.2.1 Status................................................................................................................................................................................32
2.2.2 Network............................................................................................................................................................................32
2.2.3 VLAN.................................................................................................................................................................................34

User Manual MX Series Voice Gateway
2.2.4 System..............................................................................................................................................................................36
2.2.5 SIP.....................................................................................................................................................................................38
2.2.6 High Availability..............................................................................................................................................................40
2.2.7 TLS&SRTP......................................................................................................................................................................41
2.2.8 MGCP...............................................................................................................................................................................42
2.2.9 FoIP...................................................................................................................................................................................44
2.2.10 Alarm..............................................................................................................................................................................46
2.3 Line.................................................................................................................................................................................................47
2.3.1 Phone Number ...............................................................................................................................................................47
2.3.2 Subscriber Line Features.............................................................................................................................................48
2.3.3 Subscriber Line Batch (Unavailable on the HX4E/HX4G)....................................................................................51
2.3.4 Subscriber Line Characteristics..................................................................................................................................52
2.4 Trunk..............................................................................................................................................................................................55
2.4.1 Phone Number ...............................................................................................................................................................55
2.4.2 Trunk Features...............................................................................................................................................................56
2.4.3 Trunk Batch (Unavailable on the HX4E/HX4G)......................................................................................................57
2.4.4 Trunk Characteristics....................................................................................................................................................58
2.5 Routing..........................................................................................................................................................................................60
2.5.1 Digit Map..........................................................................................................................................................................60
2.5.2 Routing Table .................................................................................................................................................................62
2.5.3 Examples of Routing Rules.........................................................................................................................................66
2.6 Advanced Configuration............................................................................................................................................................67
2.6.1 System..............................................................................................................................................................................67
2.6.2 Auto Provisioning...........................................................................................................................................................69
2.6.3 Management System Type..........................................................................................................................................70
2.6.4 Certificate (Available on the HX4E/MX8A/HX4G/MX8G).....................................................................................71
2.6.5 Media Stream .................................................................................................................................................................72
2.6.6 SIP Configuration...........................................................................................................................................................74
2.6.7 RADIUS (Unavailable on the HX4E/HX4G).............................................................................................................77
2.6.8 Greeting ...........................................................................................................................................................................78
2.6.9 Call Progress Tone Plan..............................................................................................................................................79
2.6.10 Feature Access Codes...............................................................................................................................................80
2.6.11 Clock Service................................................................................................................................................................82
2.7 Security.........................................................................................................................................................................................85
2.7.1 Access Security..............................................................................................................................................................85
2.7.2 Access list........................................................................................................................................................................86
2.7.3 Brute Force Login Prevention.....................................................................................................................................88

MX Series Voice Gateway User Manual
New Rock Technologies, Inc. 5
2.7.4 ACL-based Traffic Filtering..........................................................................................................................................89
2.7.5 Packet Rate Limiting Based Dynamic Blacklisting.................................................................................................90
2.7.6 IP Table............................................................................................................................................................................93
2.7.7 Voice Security.................................................................................................................................................................93
2.7.8 Encryption........................................................................................................................................................................94
2.7.9 VPN (Available on the HX4E/MX8A/HX4G/MX8G) ...............................................................................................95
2.8 Status ............................................................................................................................................................................................96
2.8.2 Call Status.......................................................................................................................................................................96
2.8.3 Call History on FXS.......................................................................................................................................................97
2.8.4 Call History on FXO.......................................................................................................................................................97
2.8.5 SIP Message Count ......................................................................................................................................................97
2.9 Logs ...............................................................................................................................................................................................98
2.9.1 System Status.................................................................................................................................................................98
2.9.2 Call Message..................................................................................................................................................................99
2.9.3 System Startup............................................................................................................................................................ 100
2.9.4 Manage Log................................................................................................................................................................. 100
2.10 Tools......................................................................................................................................................................................... 102
2.10.1 Configuration Management.................................................................................................................................... 102
2.10.2 Upgrade...................................................................................................................................................................... 102
2.10.3 Restore Factory Settings........................................................................................................................................ 104
2.10.4 Capture Recordings on the Port ........................................................................................................................... 104
2.10.5 IP Capture.................................................................................................................................................................. 105
2.10.6 Network Diagnosis (HX4E/MX8A/HX4G/MX8G)............................................................................................... 105
2.11 Product Information............................................................................................................................................................... 106
2.12 Reboot...................................................................................................................................................................................... 106
2.13 Logout....................................................................................................................................................................................... 106
3Appendix: VLAN Configuration.......................................................................................................107
3.1 Automatic Discovery................................................................................................................................................................ 107
3.1.1 LLDP .............................................................................................................................................................................. 108
3.1.2 DHCP............................................................................................................................................................................. 111
3.2 Manual Configuration.............................................................................................................................................................. 113
3.2.1 Single VLAN................................................................................................................................................................ 113
3.2.2 Multi-Service VLAN.................................................................................................................................................. 114

User Manual MX Series Voice Gateway
4 Making an OpenVPN Client Certification (HX4E/MX8A/HX4G/MX8G)...............................................120
5 Appendix: High Availability Configuration ........................................................................................123
6 Appendix: Auto Provisioning Configuration ..................................................................................... 124
7 Appendix: RJ45 and RJ11 Corresponding Relations........................................................................ 125

MX Series Voice Gateway User Manual
New Rock Technologies, Inc. 7
Figures
Figure 1-1 HX4E/HX4G Front Panel............................................................................................................................................16
Figure 1-2 HX4E/HX4G Back Panel ............................................................................................................................................16
Figure 1-3 MX8A/MX8G Front Panel...........................................................................................................................................18
Figure 1-4 MX8A/MX8G Back Panel ...........................................................................................................................................18
Figure 1-5 RJ45 to RS232 Serial Cable......................................................................................................................................19
Figure 1-6 USB to RS232 Converter Cable ...............................................................................................................................19
Figure 1-7 MX60 Front Panel ........................................................................................................................................................21
Figure 1-8 MX60 Back Panel-AC..................................................................................................................................................21
Figure 1-9 MX60 Back Panel-DC .................................................................................................................................................21
Figure 1-10 MX60E Front Panel...................................................................................................................................................23
Figure 1-11 MX60E Back Panel-AC ............................................................................................................................................24
Figure 1-12 MX120G Front Panel ................................................................................................................................................25
Figure 1-13 MX120G Back Panel-AC..........................................................................................................................................26
Figure 1-14 MX120G Back Panel-DC .........................................................................................................................................26
Figure 1-15 Web GUI......................................................................................................................................................................28
Figure 2-1 Login Interface for MX8A Gateway Configuration................................................................................................30
Figure 2-2 Status Interface.............................................................................................................................................................32
Figure 2-3 Network Configuration Interface (HX4E/HX4G/MX8A/MX8G)...........................................................................32
Figure 2-4 Network Configuration Interface (MX60/MX60E/MX120G)................................................................................33
Figure 2-5 VLAN Configuration Interface....................................................................................................................................35
Figure 2-6 System Configuration Interface.................................................................................................................................37
Figure 2-7 SIP Configuration Interface........................................................................................................................................39
Figure 2-8 High Availability Configuration Interface.................................................................................................................40
Figure 2-9 TLS&SRTP Configuration Interface.........................................................................................................................41
Figure 2-10 MGCP Configuration Interface................................................................................................................................42
Figure 2-11 Fax Configuration Interface (HX4E/MX8A/HX4G/MX8G) ................................................................................44
Figure 2-12 MX60/MX60E/MX120G Fax Configuration Interface.........................................................................................45
Figure 2-13 Alarm Icon....................................................................................................................................................................47
Figure 2-14 Alarms Interface.........................................................................................................................................................47
Figure 2-15 Configuration Interface for Batch Configuration (Phone Number)..................................................................48
Figure 2-16 Subscriber Line Configuration Interface...............................................................................................................49
Figure 2-17 Feature Batch Configuration Interface..................................................................................................................52
Figure 2-18 Subscriber Line Characteristics Configuration Interface...................................................................................53
Figure 2-19 Phone Number Configuration Interface................................................................................................................55

User Manual MX Series Voice Gateway
Figure 2-20 Trunk Line Features Configuration Interface.......................................................................................................56
Figure 2-21 Trunk Batch Configuration Interface......................................................................................................................58
Figure 2-22 Trunk Characteristics Configuration Interface.....................................................................................................59
Figure 2-23 Configuration Interface for Digit Map.....................................................................................................................61
Figure 2-24 Routing Table Configuration Interface ..................................................................................................................63
Figure 2-25 Interface of system advanced configuration........................................................................................................68
Figure 2-26 Interface of Auto Provisioning Configuration.......................................................................................................69
Figure 2-27 SNMP Configuration Interface................................................................................................................................70
Figure 2-28 TR069 Configuration Interface................................................................................................................................71
Figure 2-29 Certificate Configuration Interface .........................................................................................................................72
Figure 2-30 HX4E/MX8A/HX4G/MX8G Media Stream Configuration Interface................................................................72
Figure 2-31 MX60/MX60E/MX120G Media Stream Configuration Interface......................................................................73
Figure 2-32 SIP Related Configuration Interface......................................................................................................................74
Figure 2-33 RADIUS Configuration Interface.............................................................................................................................77
Figure 2-34 Greeting Interface......................................................................................................................................................78
Figure 2-35 Call Progress Tone Configuration Interface.........................................................................................................79
Figure 2-36 Feature Codes Configuration Interface.................................................................................................................81
Figure 2-37 Clock Service Interface.............................................................................................................................................83
Figure 2-38 Access Configuration Interface...............................................................................................................................85
Figure 2-39 Access list configuration Interface .........................................................................................................................87
Figure 2-40 Brute Force Login Prevention (Login Retry Lockout) Configuration Interface.............................................88
Figure 2-41 Brute Force Login Prevention (Lockout IP Addresses) Interface ...................................................................89
Figure 2-42 Static Defense Configuration Interface.................................................................................................................89
Figure 2-43 Dynamic Defense Configuration Interface ...........................................................................................................91
Figure 2-44 Dynamic Defense (Blocked IP Addresses) Interface.........................................................................................92
Figure 2-45 IP Table Configuration Interface.............................................................................................................................93
Figure 2-46 Voice Security Configuration Interface..................................................................................................................94
Figure 2-47 Encryption Configuration Interface.........................................................................................................................94
Figure 2-48 VPN Configuration Interface....................................................................................................................................96
Figure 2-49 Call Status Interface..................................................................................................................................................97
Figure 2-50 Interface of Call History on FXS.............................................................................................................................97
Figure 2-51 Interface of Call on FXO...........................................................................................................................................97
Figure 2-52 SIP Message Count Interface.................................................................................................................................98
Figure 2-53 System Status Interface...........................................................................................................................................99
Figure 2-54 Call Message Interface.......................................................................................................................................... 100
Figure 2-55 Interface of System Startup.................................................................................................................................. 100

MX Series Voice Gateway User Manual
New Rock Technologies, Inc. 9
Figure 2-56 Manage Log Interface............................................................................................................................................ 101
Figure 2-57 Log Saving Interface.............................................................................................................................................. 101
Figure 2-58 Path Saving Interface............................................................................................................................................. 102
Figure 2-59 Configuration Management Interface................................................................................................................. 102
Figure 2-60 Upgrade Interface................................................................................................................................................... 103
Figure 2-61 Upgrading interface by .img file........................................................................................................................... 103
Figure 2-62 Upgrade Interface................................................................................................................................................... 103
Figure 2-63 Restore Factory Settings Interface (HX4E/MX8A/HX4G/MX8G) ................................................................ 104
Figure 2-64 Restore Factory Settings Interface (MX60/MX60E/MX120G)...................................................................... 104
Figure 2-65 Interface for Capturing Port Recordings............................................................................................................ 104
Figure 2-66 Ethereal Capture Interface.................................................................................................................................... 105
Figure 2-67 Automatic Diagnosis Interface............................................................................................................................. 105
Figure 2-68 Ping Diagnosis Interface .................................................................................................................................... 106
Figure 3-1 Scenario Diagram...................................................................................................................................................... 109
Procedure of Handling LLDP Message Carrying a VLAN ID.......................................................................................... 110
Procedure of Handling the LLDP Message with no VLAN ID ....................................................................................... 110
Figure 3-2 LLDP Message........................................................................................................................................................... 111
Figure 3-3 Adding a VLAN ID to the Message to Be Sent................................................................................................... 111
Figure 3-4 Configuring the Single VLAN.................................................................................................................................. 114
Figure 3-5 A Data Packet Carrying a Corresponding VLAN Tag in the Single VLAN Mode ....................................... 114
Figure 3-6 Configuring Voice VLAN to Work in Mode 1....................................................................................................... 115
Figure 3-7 Configuring Voice VLAN to Work in Mode 2....................................................................................................... 116
Figure 3-8 Configuring Management VLAN............................................................................................................................ 117
Figure 3-9 Network Environment............................................................................................................................................... 117
Figure 3-10 Configuring Multi-Service VLAN.......................................................................................................................... 118
Figure 3-11 IP Addresses of the Device in Multi-Service VLAN......................................................................................... 118
Figure 3-12 SIP Data Packet Carrying VLAN Tag of the Voice VLAN in the Multi-Service VLAN Mode ................. 119
Figure 3-13 RTP Data Packet Carrying VLAN Tag of the Voice VLAN in the Multi-Service VLAN Mode................ 119
Figure 3-14 RTP Data Packet Carrying VLAN Tag of the Management VLAN in the Multi-Service VLAN Mode.. 119
Figure 7-1 Schematic Diagram of Subscriber Line Connection.......................................................................................... 125

User Manual MX Series Voice Gateway
Tables
Table 1-1 MX Series Gateway Hardware Specifications..........................................................................................................13
Table 1-2 Configuration Combination of HX4E/HX4G ..............................................................................................................15
Table 1-3 Description of HX4E/HX4G Front Panel....................................................................................................................16
Table 1-4 Description of HX4E/HX4G Back Panel.....................................................................................................................16
Table 1-5 Indicator Status of HX4E/HX4G...................................................................................................................................16
Table 1-6 Configuration Combination of MX8A/MX8G .............................................................................................................17
Table 1-7 Voice Interface Cards Supported by the MX8A/MX8G ..........................................................................................18
Table 1-8 Description of MX8A/MX8G Front Panel...................................................................................................................18
Table 1-9 Description of MX8A/MX8G Back Panel....................................................................................................................19
Table 1-10 Indicator Status of MX8A/MX8G ...............................................................................................................................19
Table 1-11 Configuration Combination of MX60 ........................................................................................................................20
Table 1-12 Description of MX60 Front Panel..............................................................................................................................21
Table 1-13 Description of MX60 Back Panel...............................................................................................................................22
Table 1-14 Meanings of MX60 Indicators.....................................................................................................................................22
Table 1-15 Configuration Combination of MX60E......................................................................................................................22
Table 1-16 Description of MX60E Front Panel............................................................................................................................23
Table 1-17 Description of MX60E Back Panel............................................................................................................................24
Table 1-18 Meanings of MX60E Indicators..................................................................................................................................24
Table 1-19 MX60E System Operation Status.............................................................................................................................24
Table 1-20 MX120G Interface Card ..............................................................................................................................................25
Table 1-21 Configuration Combination of MX120G...................................................................................................................25
Table 1-22 Description of MX120G Front Panel.........................................................................................................................25
Table 1-23 MX120G Back Panel....................................................................................................................................................26
Table 1-24 Meanings of MX120G Indicators...............................................................................................................................27
Table 1-25 MX120GSystem Operation State..............................................................................................................................27
Table 1-26 Web GUI Layout Description......................................................................................................................................28
Table 2-1 Default IP Address of Gateway....................................................................................................................................29
Table 2-2 Default Passwords for logging to Web GUI...............................................................................................................30
Table 2-3 Network Configuration Parameters.............................................................................................................................33
Table 2-4 VLAN Configuration Parameters.................................................................................................................................35
Table 2-5 System Configuration Parameters..............................................................................................................................37
Table 2-6 Codec Methods Supported by Gateways..................................................................................................................38
Table 2-7 SIP Configuration Parameters .....................................................................................................................................39
Table 2-8 Parameters.......................................................................................................................................................................40

MX Series Voice Gateway User Manual
New Rock Technologies, Inc. 11
Table 2-9 TLS&SRTP Configuration Parameter.........................................................................................................................42
Table 2-10 MGCP Configuration Parameters.............................................................................................................................43
Table 2-11 Fax Configuration Parameters...................................................................................................................................45
Table 2-12 Alarm Type.....................................................................................................................................................................46
Table 2-13 Configuration Parameters of Batch Configuration (Phone Number).................................................................48
Table 2-14 Subscriber Line Configuration Parameters.............................................................................................................49
Table 2-15 Subscriber Line Characteristics Configuration Parameter..................................................................................53
Table 2-16 Configuration Parameters of FXO Phone Number ...............................................................................................55
Table 2-17 Configuration Parameters of Trunk Features.........................................................................................................56
Table 2-18 Trunk Characteristics Configuration Parameter.....................................................................................................59
Table 2-19 Description of Digit Map..............................................................................................................................................61
Table 2-20 Routing Table Format..................................................................................................................................................64
Table 2-21 Number Transformations ............................................................................................................................................64
Table 2-22 Routing Destination......................................................................................................................................................65
Table 2-23 NAT Configuration Parameters..................................................................................................................................68
Table 2-24 Auto Provisioning Configuration Parameters .........................................................................................................69
Table 2-25 SNMP Configuration Parameters..............................................................................................................................70
Table 2-26 TR069 Configuration Parameters.............................................................................................................................71
Table 2-27 Media Stream Configuration Parameter..................................................................................................................73
Table 2-28 SIP Related Configuration Parameter......................................................................................................................75
Table 2-29 RADIUS Configuration Parameter............................................................................................................................78
Table 2-30 Greeting Configuration Parameters..........................................................................................................................79
Table 2-31 Call Progress Tone Configuration Parameters......................................................................................................79
Table 2-32 Feature Codes Configuration Parameter................................................................................................................81
Table 2-33 Clock Service Parameters..........................................................................................................................................84
Table 2-34 Access security setting parameters..........................................................................................................................86
Table 2-35 Login Retry Lockout Parameters...............................................................................................................................88
Table 2-36 Brute Force Login Prevention (Lockout IP Addresses) Information..................................................................89
Table 2-37 Static Defense Configuration Parameters...............................................................................................................89
Table 2-38 Dynamic Defense (Rule Configuration) Parameters ............................................................................................91
Table 2-39 Dynamic Defense (Blocked IP Addresses) Information.......................................................................................92
Table 2-40 Subsequent choices for moving the Blocked IP Addresses to static defense................................................92
Table 2-41 Encryption Configuration Parameters......................................................................................................................94
Table 2-42 VPN Configuration Parameters.................................................................................................................................96
Table 2-43 System Status Parameters.........................................................................................................................................99
Table 2-44 Log Management Configuration Parameters ...................................................................................................... 101

User Manual MX Series Voice Gateway
Table 7-45 Pin Specifications for RJ45 Socket Port............................................................................................................... 125

MX Series Voice Gateway User Manual
New Rock Technologies, Inc. 13
1 Overview
1.1 Product Introduction
MX Series intelligent VoIP Gateways (MX Gateways) are designed to bridge the traditional telecom
terminal device into IP networks through SIP or MGCP protocols. The main applications include:
For carriers and value-added service providers to provide telephone, fax and voice-band data services
to subscribers using IP access methods such as FTTB, HFC, and ADSL;
To bridge the traditional telecom terminal equipment, such as PBXs, to the VoIP core networks of
carriers;
To connect with an enterprise PBX to provide IP-based voice private network solutions for
institutions, enterprises and schools;
To be used as remote access equipment for IP-PBXs in call center deployment
The MX family has four sub-series: HX4E, MX8A, HX4G, MX8G, MX60, MX60E and MX120G, which
mainly differ in port capacities.
Table 1-1 MX Series Gateway Hardware Specifications
Model
Voice
ports
Chassis
Installation
CPU
RAM
Flash
Power
HX4E
2/4
Plastic
Casing
Desktop
MIPS34Kc,
700MHz, SOC
64MB
16MB
12 VDC
HX4G
2/4
Plastic
Casing
Desktop
Dual-core
processor, 880MHz
256MB
16MB
12 VDC
MX8A
8
Metal
Desktop or rack
MIPS34Kc,
700MHz, SOC
128MB
16MB
12 VDC
MX8G
8
Metal
Desktop or rack
Dual-core
processor, 880MHz
256MB
16MB
12 VDC
MX60
16 - 48
19-inch
wide and 1U
High
Rack
AT91SAM9G20B
64MB
16MB
100-240
VAC, -48
VDC
(Optional)
MX60E
16 - 48
19-inch
wide and 1U
High
Rack
TI A8, 1GHz
128MB
32MB
100-240
VAC, -36 to
-72 VDC
(optional)
Dual power
(optional)

User Manual MX Series Voice Gateway
14 New Rock Technologies, Inc.
Model
Voice
ports
Chassis
Installation
CPU
RAM
Flash
Power
MX120G
48- 96
19-inch
wide and 2U
High
Rack
TI A8, 1GHz
256MB
32MB
100-240
VAC, -36 to
-72 VDC
(optional)
Dual power
(optional)
Hardware for MX series gateways uses high-performance CPUs, ensuring that each product of the series
can achieve full-capacity concurrent calls with high speech quality.
MX gateways software adopts the stable and reliable embedded Linux operating system (OS),
implementing scores of business phone functions, including: call forwarding, call transfer, call hold,
teleconference, caller identification, Do Not Disturb, ring-back tone, hunt group simultaneous ring,
distinctive ring, one phone with two numbers, and fax. In addition, MX gateways are featured with FXO
port second stage dialing with voice prompt, routing table with a maximum of 500 entries, phone digit
manipulation, and PSTN failover upon power-off or network disconnection.
MX gateways support local and remote management operations through Web GUI or SSH, SNMPv2-
based and TR069/TR104/TR106-based centralized management schemes, and auto provisioning.
Maintenance tasks such as modifying configuration, upgrading software, collecting statistical data,
downloading logs, and fault alarms can be performed.
Note: PSTN failover upon power-off or network disconnection is supported by devices with both the FXS
port and the FXO port.
1.2 Functions and Features
Connect analog telephone, PBX, facsimile machine and POS machine to the IP core network, or
PSTN
Work with a service platform to provide various telephone supplementary services
Support protocols: SIP, MGCP
Support STUN. Detecting changes of the reflexive address of the device via STUN, and then
triggering re-registration to the SIP registrar server.
Flexible configuration of subscriber/trunk interfaces
Support G.711, G.729
Support echo cancellation
Up to 500 routing rules can be stored in gateways
Intercom
Support concurrent calls under full load
Support call progress tones for various countries and regions
Support Line second stage dialing or voice prompt
Support PSTN failover on power or network failure

MX Series Voice Gateway User Manual
New Rock Technologies, Inc. 15
Security strategy: IP filter, encryption
Support PSTN failover through FXO ports
Support G.711 fax pass-through and T.38 fax relay
Support polarity inverse detection and busy tone detection
3-way calling
Compatible with unified communication solutions, such as Call Manager, Lync, Asterisk and Free
SWITCH
Support SNMPv2 and TR069/TR104/TR106
Support Web GUI-based management , SSH, automatic software upgrades, and configuration
downloading
Support high availability, implementing a cloud of SIP servers working in primary-standby or load
balancing mode
Support auto provisioning
Support security settings such as accessing whitelists
Message waiting indications (MWI) with high voltage, FSK, or reversed polarity
Support accessing the Web GUI by using HTTPS
Support Ping blocking
Support optional voice interface cards (only supported by the MX8A/MX120G)
Support the VPN client (only available with the HX4E/MX8A/HX4G/MX8G)
Support VLAN
Support New Rock Cloud, allowing New Rock devices located behind NAT or firewall to be easily
accessed.
1.3 Equipment Structure
1.3.1 HX4E/HX4G
The HX4E/HX4G adopts a compact plastic structural design and can be placed on a desk.
It provides either two or four FXS/FXO ports.
The HX4E/HX4G supports the following models.
Table 1-2 Configuration Combination of HX4E/HX4G
Models
Number of FXS Ports
Number of FXO Ports
HX402E/HX402G
2
0
HX420E/HX420G
0
2
HX422E/HX422G
2
2
HX440E/HX440G
0
4
HX404E/HX404G
4
0

User Manual MX Series Voice Gateway
16 New Rock Technologies, Inc.
Figure 1-1 HX4E/HX4G Front Panel
Table 1-3 Description of HX4E/HX4G Front Panel
Item
Description
Power Indicator
WAN
WAN interface indicator
PC
PC interface indicator
FXO/FXS
FXS /FXO port indicator
Figure 1-2 HX4E/HX4G Back Panel
Table 1-4 Description of HX4E/HX4G Back Panel
Item
Description
PWR
Power interface, 12 VDC input
PC and
WAN
The PC port is used to connect a computer.
The WAN port is used to connect the uplink network.
Both are 10/100 Mbps Ethernet ports (RJ45). They share one IP address, which, by default, is obtained
through DHCP. If no IP address is obtained, 192.168.2.218 is used by default, and you can change it on
Basic > Network page.
FXO/FXS
FXS port or FXO port
Table 1-5 Indicator Status of HX4E/HX4G
Indicator
Status
Description
PWR(green)
Blinking green
The device is starting.

MX Series Voice Gateway User Manual
New Rock Technologies, Inc. 17
Indicator
Status
Description
Steady green
The device is running.
Off
The device is powered off or a power supply fault occurred
STU
(red, green)
Steady red
The WAN interface failed to acquire the IP address. Possibly the WAN
interface is not connected to a network cable, the WAN interface
address failed to be acquired by DHCP, the IP addresses are conflicted,
and the PPPoE dialing failed.
Blinking red
The device is starting or the KUPDATE is upgrading.
Steady green
Registration is successful.
Blinking
alternatively
between red and
green
Registration failed.
Blinking green
Calling.
Off
Registration has not started.
WAN
(green)
Steady green
A WAN connection is established without any service flow.
Blinking green
A WAN connection is established with service flow.
Off
WAN interface is disconnected.
PC
(green)
Steady green
A link is connected without any service flow.
Blinking green
A service flow is being transmitted.
Off
A link is not connected.
FXS/FXO
(green)
Steady green
Off-hook or call established
Blinking green
Ringing on incoming call
Off
The port is in idle status
1.3.2 MX8A/MX8G
The MX8A/MX8G adopts a compact metal structural design. It can be placed on a desk or installed in a
standard communications cabinet and provides eight analog ports. MX8A/MX8G supports the following
types of configuration.
Table 1-6 Configuration Combination of MX8A/MX8G
Models
Number of FXS Ports
Number of FXO Ports
MX8A-4S/4
MX8G-4S/4
4
4
MX8A-8S
MX8G-8S
8
0
MX8A-8FXO
MX8G-8FXO
0
8

User Manual MX Series Voice Gateway
18 New Rock Technologies, Inc.
Table 1-7 Voice Interface Cards Supported by the MX8A/MX8G
Voice Interface Card Types
Number of FXS Ports
Number of FXO Ports
401A-4FXS
4
0
401A-4FXO
0
4
401A-2FXS/2FXO
2
2
Figure 1-3 MX8A/MX8G Front Panel
Table 1-8 Description of MX8A/MX8G Front Panel
Item
Description
PWR
Power indicator
STU
Status indicator
WAN
WAN interface indicator
PC
PC interface indicator
VOICE
FXS/FXO port indicator
Figure 1-4 MX8A/MX8G Back Panel

MX Series Voice Gateway User Manual
New Rock Technologies, Inc. 19
Table 1-9 Description of MX8A/MX8G Back Panel
Item
Description
CON
The console port is used for local management and testing. PCs can be connected to device by linking
the RS232 port to CON port.
Connecting cables need to be produced or purchased.
If the connection is established between the device and the mobile PC with no RS232 ports, please use
the cable together with a USB to an RS232 converter cable.
Cables are shown below in Figure 1-5 and Figure 1-6.
PC/WAN
The PC port is used to connect a computer.
The WAN port is used to connect the uplink network.
Both are 10/100 Mbps Ethernet ports (RJ45). They share one IP address, which, by default, is obtained
through DHCP. If no IP address is obtained, 192.168.2.218 is used by default, and you can change it on
Basic > Network page.
FXO/FXS
FXS port or FXO port
Figure 1-5 RJ45 to RS232 Serial Cable
Figure 1-6 USB to RS232 Converter
Cable
Table 1-10 Indicator Status of MX8A/MX8G
Indicator
Status
Description
PWR (green)
Blinking green
The device is starting.
Steady green
The device is running.
Off
The device is powered off or a power supply fault occurred.
STU
(red, green)
Steady red
The WAN interface failed to acquire the IP address. Possibly the WAN
interface is not connected to a network cable, the WAN interface
address fails to be acquired by DHCP, the IP addresses are conflicted,
and the PPPoE dialing fails.
Blinking red
The device is starting or the KUPDATE is upgrading.
Steady green
Registration is successful.
Blinking
alternatively
between red and
green
Registration failed.

User Manual MX Series Voice Gateway
20 New Rock Technologies, Inc.
Indicator
Status
Description
Blinking green
Calling
Off
Registration has not started.
WAN
(green)
Steady green
A WAN connection is established without any service flow.
Blinking green
A WAN connection is established with service flow.
Off
WAN interface is disconnected.
PC
(green)
Steady green
A link is connected without any service flow.
Blinking green
A service flow is being transmitted.
Off
A link is not connected.
VOICE
(Green-FXS,
yellow-FXO)
Indicates line type and device status:
Blinking yellow
The device is starting and the port is an FXO port.
Blinking green
The device is starting and the port is an FXS port.
Off
No line is detected. Possibly the voice interface card is not inserted or
the port is damaged.
Indicates running status:
Steady yellow
Calling in or out via an analog trunk.
Blinking yellow
Ringing of calling in for an analog trunk.
Steady green
Off-hook or call established
Blinking green
Ringing on incoming call
Off
The port is in idle status
Note: The device starts up for approximate 30s to indicate line type, then indicates running
status.
Indicator of button:
RST
To restore the MX8A to factory default, press the RST for more than 3 seconds and release it
when the STU light starts blinking in red. This setting will be valid after rebooting the device.
1.3.3 MX60
Designed with a 1U high and 19-inch wide compact chassis, MX60 is suitable for installation in a standard
cabinet. MX60 has a built-in power module with the rating voltage of 100-240 V AC or -48 V DC (DC is
optional). The interface card of MX60 uses a RJ-45 socket and is connected to the distribution panel in
equipment room using CAT-5 cables supplied with the unit. MX60 offers up to 48 interfaces of FXS/FXO.
MX60 supports the following types of configuration.
Table 1-11 Configuration Combination of MX60
Models
Number of FXS Ports
Number of FXO Ports
MX60-16S
16
0
MX60-32S
32
0
MX60-48S
48
0
MX60-16FXO
0
16
MX60-32FXO
0
32
MX60-48FXO
0
48
MX60-8S/8
8
8
