Gateway for integration of DALI devices into KNX TP-1 home and
building automation systems.
ORDER CODE
LEGACY ORDER CODE
INKNXDAL0640000
IBKNXDAL0640000

IntesisTM KNX –DALI User Manual r1.1 EN
© HMS Industrial Networks S.L.U - All rights reserved
This information is subject to change without notice
URL https://www.intesis.com
4 / 34
INDEX
1Description ............................................................................................................................................................5
Introduction....................................................................................................................................................5
Functionality ..................................................................................................................................................6
Gateway’s capacity .......................................................................................................................................6
2KNX interface........................................................................................................................................................7
Description.....................................................................................................................................................7
Points definition.............................................................................................................................................7
KNX Comunication Objects...........................................................................................................................8
2.3.1 Single DALI device signals....................................................................................................................8
2.3.2 DALI groups’ signals............................................................................................................................15
2.3.3 Broadcast signals ................................................................................................................................16
3Connections ........................................................................................................................................................19
Powering the device....................................................................................................................................20
Connection to DALI channel........................................................................................................................20
Connection to KNX......................................................................................................................................20
Connection to PC (Configuration tool) ........................................................................................................20
4Set-up process and troubleshooting ...................................................................................................................21
Pre-requisites ..............................................................................................................................................21
Intesis MAPS. Configuration & monitoring tool for Intesis ..........................................................................21
4.2.1 Introduction..........................................................................................................................................21
4.2.2 Connection...........................................................................................................................................21
4.2.3 Configuration tab .................................................................................................................................22
4.2.4 Signals.................................................................................................................................................22
4.2.5 Sending the configuration to Intesis ....................................................................................................23
4.2.6 Diagnostic............................................................................................................................................23
Set-up procedure.........................................................................................................................................25
5Electrical & Mechanical Features........................................................................................................................26
6Dimensions .........................................................................................................................................................27
Annex A –Quick setup and commissioning of a DALI network...............................................................................28
Create project..............................................................................................................................................28
ECG declaration in project ..........................................................................................................................29
Scan and commissioning of ECGs..............................................................................................................30

IntesisTM KNX –DALI User Manual r1.1 EN
© HMS Industrial Networks S.L.U - All rights reserved
This information is subject to change without notice
URL https://www.intesis.com
5 / 34
1 Description
Introduction
This document describes the integration of DALI lighting ballasts into KNX TP-1 home automation systems using the
Intesis KNX to DALI communication gateway.
The aim of this integration is to monitor and control DALI lighting ballasts, remotely, from a KNX home automation
system, as if it was a part of the own KNX installation and vice-versa.
In current version of the device, following DALI device types are supported:
•DALI Fluorescent lights (DALI type 0)
•Emergency lights (DALI type 1)
•LED modules (DALI type 6)
All of them, regardless of its type, will be referred as ‘ballasts’, ‘DALI devices’ and ‘ECGs’ (Electronic Control Gears)
indistinctively throughout the document.
Up to 64 DALI lighting devices can be fitted in a single DALI channel, and therefore controlled and monitored from
Intesis.
Intesis needs to be configured using Intesis MAPS software configuration tool. In the software, KNX and DALI lighting
ballast parameters must be configured and downloaded to the Intesis.
This document assumes the user is familiar with KNX and DALI technologies and technical terms.
Integration of DALI into KNX TP-1 home or building automation system
USB
configuration
Ethernet TCP
Ethernet
configuration
DALI (up to 64 ballasts in a line)
NOTE: There may be differences in the implementation of DALI among different
ballasts and manufacturers. Intesis is compatible with Ballasts implementing the DALI
standard and certified under the DiiA guidelines for testing and certification. Use only
DALI devices having the DALI logo with Intesis.
!

IntesisTM KNX –DALI User Manual r1.1 EN
© HMS Industrial Networks S.L.U - All rights reserved
This information is subject to change without notice
URL https://www.intesis.com
6 / 34
Functionality
IntesisTM continuously polls (reads) all the signals of the DALI lighting ballasts in each line and maintains the updated
values to be served in KNX.
Each of the mentioned DALI point is associated to a KNX group address, with this, the DALI system is seen as one
more KNX device from the KNX system point of view, with the same configuration and operation characteristics
When a change in any DALI point occurs, a write telegram is sent to the KNX bus, of the associated KNX Group. See
details in section 4.
When a telegram is received from the KNX bus, of a KNX Group address associated to a DALI point, a message is
sent immediately to the corresponding DALI lighting ballast device to perform the corresponding action.
In the continuous polling process of the DALI channel, if there is no answer, it is indicated with a virtual signal of
communication error for this ballast in its line.
The KNX physical address address and all relative KNX group addresses must be set in the MAPS configuration tool.
From the configuration tool, it is also possible to scan each DALI channel for available ballasts, add them in
configuration, and configure its individual parameters (short address, preset levels, scenes, etc), according to their
device type (fluorescent light, emergency light, LED module).
Gateway’s capacity
Intesis capacity is listed below:
Element
Max.
Notes
Number of DALI channels
1
Number of independent DALI channels
Number DALI lighting devices
per line
64
64 DALI lighting devices are supported per line
Max number of KNX variables
per DALI device
61
Number of available signals will vary according to device
type
Max number of KNX variables
per DALI group
16
Number of available signals will vary according to device
type
Max number of variables per
LINE
4176
16 broadcast signals + 16 signals/DALI group + 61
signals/DALI device

IntesisTM KNX –DALI User Manual r1.1 EN
© HMS Industrial Networks S.L.U - All rights reserved
This information is subject to change without notice
URL https://www.intesis.com
7 / 34
2 KNX interface
In this section, a common description for all Intesis KNX series gateways is given, from the point of view of KNX
system which is called from now on internal system. The DALI system is also called from now on external system.
Description
Intesis KNX connects directly to the KNX TP-1 (EIB) bus and behaves as one more device into the KNX system, with
the same configuration and operational characteristics as other KNX devices.
Internally, the circuit part connected to the KNX bus is opto-isolated from the rest of the electronics.
Intesis-KNX receives, manages and sends all the telegrams related to its configuration to the KNX bus.
On receiving telegrams of KNX Groups associated to internal datapoints, the corresponding messages are sent to
the external system (DALI) to maintain both systems synchronised in every moment.
When a change in a signal of the external system is detected, a telegram is sent to the KNX bus (of the associated
KNX group) to maintain both systems synchronised in every moment.
The status of the KNX bus is checked continuously and, if a bus drops down is detected, due to a failure in the bus
power supply for example, when the KNX bus is restored again, Intesis will retransmit the status of all the KNX groups
marked as "T" Transmit. Also Updates for the groups marked as "U" will be performed on corresponding Group
Address. The behaviour of each individual point into Intesis is determined by the flags configured for the point. See
details in section below.
Points definition
Every internal datapoint to define has the following KNX properties:
Property
Description
Description
Descriptive information about the Communication Object or Signal.
Signal
Signal's Description. Only for informative purposes, allows identifying the signal
comfortably.
DPT
It is the KNX data type used to code the signal's value. It will depend on the type of
signal associated in the external system in every case. In some integrations, it is
selectable, in others it is fixed due to the intrinsic characteristics of the signal.
Group
It is the KNX group to which the point is associated. It is also the group to which the
read (R), write (W), transmit (T) and update (U) flags are applied. Is the sending group.
Listening
addresses
They are the addresses that will actuate on the point, apart of the main Group address.
R
Read. If this flag is activated, read telegrams of this group address will be accepted.
Ri
Read. If this flag is activated, the object will be read on initialization.
W
Write. If this flag is activated, write telegrams of this group address will be accepted.
T
Transmit. If this flag is activated, when the point's value changes, due to a change in
the external system, a write telegram of the group address will be sent to the KNX bus.
U
Update. If this flag is activated, on Intesis start-up or after a KNX bus reset detection,
objects will be updated from KNX.
Active
If activated, the point will be active in Intesis, if not, the behaviour will be as if the point
is not defined. This allows deactivating points without the need of delete them for
possible future use.
These properties are common for all Intesis KNX series gateways. Although each integration may have specific
properties according to the type of signals of the external system.
