VF80 EX
8 TRACK DIGITAL
MULTITRACKER
VF160 EX
16 TRACK DIGITAL
MULTITRACKER
E X SERIES
F

Uncompressed Recording to Hard Drive
8 + 16 additional ghost tracks
Non Linear Audio Editing
Non-destructive, non linear Copy/Move-
Paste / Erase audio editing
Digital Mixer
7 x track faders and 1 x Master fader
(stereo buss) - all 60mm
Mic/Line Inputs x 2
With phantom powered balanced XLRs and
unbalanced 6mm jacks. Trim controls, on/off
switches and peak LED indicators
Built-in Digital Channel Effects
Fostex A.S.P.+ technology with 44 effect
types including amp simulations & distortion
Mastering Libraries
10 preset Mastering Libraries: Flat, Wet
Mix, Light Mix, Live Mix, Pop Mix, Dance,
Hard, 70’s, Hall and Lo-Fi modes
Mastering Mode
Using tracks 7 & 8 with EQ, compressor
and effects
Equalization
2-band EQ on channels 1-6 (shelving type)
plus 36 EQ presets
CD Mastering
Master to CD-R/RW
VF80 EX
Uncompressed Recording to Hard Drive
16 + 8 additional ghost tracks. Up to 16
track simultanous recording*
Programs (Songs)
99 user programmable
Non Linear Audio Editing
7 Mark Point on the fly, 7 Edit Memory &
99 Event Memory
Digital Mixer
16 input faders (8 analog/track input + 8
track input). Master fader (stereo buss)
Mic/Line Inputs
Trim on all analog inputs with peak LED.
Balanced XLR with phantom power and
insert points on inputs G & H
Built-in Assignable Compressor
Assignable (ch13+14 or ch15+16 with EQ
off) and master compressors
2 Built-in A.S.P. Digital Effects
38 types of preset channel effects
Equalization
3-band EQ on all 16 channels (HI
parametric, shelving, LPF, MID parametric,
LO shelving). Separate 3-band Master EQ
PC Audio Mixing
Interface to any ADAT compatible system
CD Mastering
Master to CD-R/RW
VF160 EX
The VF80 EX and VF160 EX continue the Fostex tradition of
offering high-value self-contained recording solutions which
simply offer musicians everything they need.
The VF80 EX is ideal for guitarists and musicians wanting a
compact solution capable of capturing ideas and songs with
minimal fuss. The superb amp simulators and flexible input
stages make for easy sound capture.
The VF160 EX meanwhile is a powerhouse offering a larger
mixer with 3-band EQ, up to 16-track simultaneous recording
tracks and powerful ADAT/PC audio mixing.
Both VF EX series machines offer superior un-compressed
digital recording to interal hard drives.
EASY TO USE, SERIOUS
QUALITY ALL-IN-ONE DIGITAL
RECORDING WORKSTATIONS
INTERNAL MIXDOWN
VF160 EX: With mastering EQ & compressor
to 1-2 tracks of new program.
DIGITAL EFFECTS
VF80 EX: 44 superb quality digital effects
including amp & mic simulations.
APPLY EQ
VF160 EX: 3-band EQ can be applied
to recorded tracks.
MASTER EFFECTS
VF80 EX: A preset library of 10 mastering
effects can be applied to tracks 7 & 8.
RECORD A TRACK
VF160 EX: You can record up to 8 at any
one time using analog inputs
TRAINING MODE
VF80 EX: Centre signal cancellation and full
control of audio speed.

VF80 EX
A total 8 track recording studio - complete with digital mixing, digital effects
including stunning amp simulators and CD mastering. 8 main tracks plus 16
'Ghost' tracks mean you can record different versions of vocals, drum grooves,
guitar parts, etc., and choose which of the 8 tracks you wish to reproduce and
mix. There’s a built-in ‘Training Mode’ with ‘auto muting’ of sounds at the centre
of the stereo mix and slow down of playback without altering pitch; high-gain
input stages with balanced XLR / unbalanced jacks, trim control and switchable
+48V phantom power; a great 2-band EQ with 36 presets; and a 99 ‘mix scene’
memory allowing you to store a complete mix for later recall or scene sequence.
Mastering to CD is a snap. Bounce tracks 1-6 to a stereo pair with just one
button push and add unique Mastering Effects.
VF160 EX
Offers full 16-track random-access digital audio recording to hard disc, digital
mixing, audio editing, effects processing and CD mastering with 16-bit audio
resolution in a compact table-top workstation. Main features include 16-track
playback; 16-track simultaneous recording;* 16-channel digital mixer with a 100
mix scene memory, pristine quality mic pre-amps; 3 band EQ, assignable channel
compressor (ch 13+14 or 15+16 with EQ off), master
compressor; 8 ‘Ghost’ tracks; graphical non-linear audio editing;
CD mastering; and a whole arsenal of multi-effects including
awesome reverb, chorus, flange, hall etc. Hook up a VF160 EX to
an ADAT compatible, computer-based audio/MIDI set-up and use
it as a full function mixer with its mic amps available for inputs
and simultaneous monitoring of the PC audio, each with its own
fader.
EFFECTS
Fostex A.S.P.
technology digital
multi-effects offer an
arsenal of creative
sound processing. In
addition, the
VF160 EX features
channel and master
compressors.
INPUTS
Both VF80 EX and
VF160 EX offer two
high-gain inputs with
balanced and
unbalanced
connectors, trim
control and
switchable +48V
phantom power.
MASTER
EFFECTS
With the VF80 EX you
can add dedicated
digital master
effects whilst
mastering tracks 7 &
8 to an external
stereo recorder or
internal CD. Choose
from 10 usable
presets which will
enhance any mix.
E X SERIES
F
VF80 EX
8 TRACK DIGITAL
MULTITRACKER
VF160 EX
16 TRACK DIGITAL
MULTITRACKER
ADAT/PC
MIXING
The VF160 EX can be
used as a full
function ADAT/PC
audio mixer with its
mic amps, digital EQ
and FX processing
available for inputs
and simultaneous
monitoring of audio
tracks with fader
control.
* When using ADAT and anlog inputs

VF80EX
RECORDING / PLAYBACK
Recording Medium 3.5 inch, hard disk (E-IDE type)
Recording Format FDMS-3 (*)
Save/Load Format FDIO-1 (**)
Sampling Frequency 44.1kHz
Quantization 16-bit linear (Non expanded)
A/D Converter 20-bit 64 times, over sampling,
Delta-Sigma
D/A Converter 24-bit 128 times, over sampling,
Delta-Sigma
No. of Recording Track 8 real tracks + 16 additional tracks
Simultaneous Recording 2 tracks
Vari Pitch Control +/- 6%
Crossfade 10msec.
Frequency Range 20Hz ~ 20kHz
INPUT / OUTPUT
Input A, B ø6mm Phone jack (Unbalanced)
XLR-3-31 type connector (Balanced)
Input Impedance 50kohm or more (Unbalanced)
1kohm or more (Balanced)
Standard Input Level -50dBV ~ +4dBu
Phantom Power (XLR only) +48VDC (Setting of On/Off
with Phantom switch)
Headphone
Connector ø6mm TRS Phone jack
Load Impedance 10ohm ~ 50ohm
Output Level 20mW or more (at 32ohm)
Stereo Out L, R
Connector ø6mm Phone jack
Load Impedance 10kohm or more
Output Level -10dBV
Digital In/Out
Connector Coaxial
Format IEC 60958 (S/P DIF)
MIDI In/Out
Connector DIN 5 PIN
Punch In/Out 1x ø6mm phone jack
GENERAL
Dimensions 307 (W) x 108 (H) x 217 (D) mm
Weight Approx. 3.3kg
Power Supply 120VAC 60Hz, 230V~ 50/60Hz
(AC inlet type)
Power Consumption 20W
* Fostex Disk Management System-3
** Fostex Data In Out-1
Distributor / Authorised Dealer
In accordance with our policy of continuous development, we reserve the right to change specifications without notice. E&OE.
Fostex Company, 3-2-35 Musashino, Akishima, Tokyo, Japan 196-0021
Tel: [phone] Fax: [phone]
www.fostex.co.jp
VF160EX
RECORDING / PLAYBACK
Recording Medium 3.5 inch, hard disk (E-IDE type)
Recording Format FDMS-3 (*)
Save/Load Format FDIO-1 (**)
Sampling Frequency 44.1kHz
Quantization 16-bit linear (Non expanded)
A/D Converter 20-bit 64 times, over sampling,
Delta-Sigma
D/A Converter 24-bit 128 times, over sampling,
Delta-Sigma
No. of Recording Track 16 real tracks + 8 additional tracks
Simultaneous Recording 16 tracks
Vari Pitch Control +/- 6%
Crossfade 10msec.
Frequency 20Hz ~ 20kHz
INPUT / OUTPUT
Input 1 ~ 6 ø6mm Phone jack (Unbalanced)
Input Impedance 50kohm or more (Unbalanced)
Standard Input Level -50dBV ~ 2dBV
Input 7 and 8 ø6mm Phone jack (Unbalanced)
XLR-3-31 type (Balanced)
Input Impedance 50kohm or more (Unbalanced),
10kohm or more (Balanced)
Standard Input Level -50dBV ~ 2dBV
Phantom Power (XLR only) +48VDC (On/Off with SETUP mode)
Output (Tip)
Load Impedance 10kohm or more
Input Level -10dBV
Insert Input/Output ø6mm TRS Phone jack,
(Output (Tip), Input (Ring))
Load Impedance 10kohm or more
Input / Output Level -10dBV
Monitor Output ø6mm Phone jack (Unbalanced)
Load Impedance 10kohm or more
Output Level -10dBV
Headphone ø6mm TRS Phone jack
Load Impedance 10ohm ~ 50ohm
Output Level 20mW or more (at 16ohm)
AUX Send 1 + 2 ø6mm TRS Phone jack
(Tip: Send 1, Ring: Send 2)
Load Impedance 10kohm or more
Output Level -10dBV
Stereo Out L, R RCA pin jack
Load Impedance 10kohm or more
Output Level -10dBV
Digital In/Out 2 x Optical
Format ADAT optical / IEC60958 (S/P DIF)
MIDI In/Out 2 x DIN 5 pin / MIDI standard
Punch In/Out 1x ø6mm phone jack
GENERAL
Dimensions 402 (W) x 110 (H) x 370 (D) mm
Weight Approx. 6.1kg
Power Supply 120VAC 60Hz, 230V~ 50/60Hz
(AC inlet type)
Power Consumption 22W
VF80 EX INTERFACING
1Input A unbalanced input
2Inputs A balanced XLR input
3Input B unbalanced input
4Input B balanced XLR input
5Headphone Out
6Master Stereo Out
7Footswitch
9Optical S/P DIF In & Out
8Phantom Power On/Off
10 MIDI IN, OUT
1 2 3 4 5 7
6
VF160 EX INTERFACING
1Inputs A - F unbalanced phone
2Inputs G - H balanced XLR or
unbalanced phone with +48V
Phantom Power & inserts
3Monitor Out
4Headphone Out
5Auxiliary Send
6Master Stereo Out
7MIDI IN, OUT
8ADAT optical / S/P DIF In & Out
9Footswitch
1 2
5 96
8
87
3 4
9 10
•Normal Hall
•Presence Hall
•Wet Hall
•No E/R Hall
•Lo-Freq Hall
•Stadium
•Auditorium
•Hallway
•Normal Room
•Dead Room
•Presence Room
•Drum Booth
•Garage
•Normal Plate
•Old Plate
•Presence Plate
•Wet Plate
• Digital Plate
•Normal Vocal
•Presence Vocal
•Solo Vocal
•Arena Vocal
•Arena Chorus
•Karaoke
•Mono Delay-Hall
•Mono Delay-Plate
• Panning Delay-Hall
• Panning Delay-Plate
•Mono Delay
•Panning Delay
•Mono Bpm Delay
•Panning Bpm Delay
•Short Delay
•Doubling
•Chorus
•Flange
•Mono Pitch
•Delay Pitch
VF160 EX CHANNEL EFFECT TYPES
•LightKick
•TightKick
•Ana.Kick
•Snappy_SD
•Power_SD
•Deep_SD
•Talk_Tom
•Melo_Tom
•W.GongTom
•LoFi_Cym
•Perc.
•Tamb.
•Fat_Bass
•Norm.Bass
•Loud_Bass
•Bright_Pf
•Loud_Pf
•Power_Pf
•E.Pf
•Clean_EG
•CrunCh_EQ
•OverDrvEG
•Dist.EG
•Metal.EG
•Stroke_AG
•Arpeg.EAG
•Arpeg.AG
•Brass_Sec
•W.WindSec
•Male_Vo
•Female_Vo
•Chorus
•SpeeCh
•Digi.Mix
•AnalogMix
•Telephone
VF80 EX EQ LIBRARY PRESETS - 36
Uses a combination of compressor,
3-band EQ and ambience to offer
10 ultra-usable mixdown settings.
• Flat • Wet
• Light • Live
• Pop • Dance
• Hard • 70s
• Hall • Lo-Fi
VF80 EX MASTERING EFFECTS - 10
•Normal Hall
•Presence Hall
•Wet Hall
•No E/R Hall
•Lo-Freq Hall
•Stadium
•Auditorium
•Hallway
•Normal Room
•Dead Room
•Presence Room
•Drum Booth
•Garage
•Normal Plate
•Old Plate
•Presence Plate
•Wet Plate
• Digital Plate
•Normal Vocal
•Presence Vocal
•Solo Vocal
•Arena Vocal
•Arena Chorus
•Karaoke
•Mono Delay-Hall
•Mono Delay-Plate
• Panning Delay-Hall
• Panning Delay-Plate
•Mono Delay
•Panning Delay
•Mono Bpm Delay
•Panning Bpm Delay
•Short Delay
•Doubling
• Chorus • Flange
•Mono Pitch
•Delay Pitch
•Distortion (Guitar)
•Distortion (Bass)
•Distortion (Drum)
•Distortion (Voice)
•Guitar Amp
Simulation
•Mic Simulation
VF80 EX CHANNEL EFFECT TYPES - 44
E X SERIES
F
