HMS Networks Anybus User guide
Anybus®Industrial WLAN Access Point
STARTUP GUIDE
SP2819 1.0 en-US ENGLISH
Important User Information
Disclaimer
The information in this document is for informational purposes only. Please inform HMS Industrial
Networks of any inaccuracies or omissions found in this document. HMS Industrial Networks disclaims
any responsibility or liability for any errors that may appear in this document.
HMS Industrial Networks reserves the right to modify its products in line with its policy of continuous
product development. The information in this document shall therefore not be construed as a
commitment on the part of HMS Industrial Networks and is subject to change without notice. HMS
Industrial Networks makes no commitment to update or keep current the information in this document.
The data, examples and illustrations found in this document are included for illustrative purposes and are
only intended to help improve understanding of the functionality and handling of the product. In view of
the wide range of possible applications of the product, and because of the many variables and
requirements associated with any particular implementation, HMS Industrial Networks cannot assume
responsibility or liability for actual use based on the data, examples or illustrations included in this
document nor for any damages incurred during installation of the product. Those responsible for the use
of the product must acquire sufficient knowledge in order to ensure that the product is used correctly in
their specific application and that the application meets all performance and safety requirements
including any applicable laws, regulations, codes and standards. Further, HMS Industrial Networks will
under no circumstances assume liability or responsibility for any problems that may arise as a result from
the use of undocumented features or functional side effects found outside the documented scope of the
product. The effects caused by any direct or indirect use of such aspects of the product are undefined
and may include e.g. compatibility issues and stability issues.
Anybus®Industrial WLAN Access Point Startup Guide SP2819 1.0 en-US
Preface 3 (24)
1 Preface
1.1 About This Document
This manual describes the installation of Anybus Industrial WLAN Access Point.
For information on how to configure Anybus Industrial WLAN Access Point, refer
to the user manual.
For additional documentation and software downloads, FAQs, troubleshooting
guides and technical support, please visit www.anybus.com/support.
Anybus®Industrial WLAN Access Point Startup Guide SP2819 1.0 en-US
Preface 4 (24)
1.2 Document Conventions
The following conventions are used to indicate safety information and other
important content in this document:
WARNING
Instruction that must be followed to avoid a risk of death or serious injury.
AVERTISSEMENT
Instruction à suivre pour éviter tout risque de décès ou de blessure grave.
Caution
Instruction that must be followed to avoid a risk of personal injury.
Attention
Instruction à suivre pour éviter tout risque de blessure.
Instruction that must be followed to avoid a risk of reduced functionality
and/or damage to the equipment, or to avoid a network security risk.
Additional information which may facilitate installation and/or operation.
1.3 Trademark Information
Anybus®is a registered trademark of HMS Industrial Networks. All other
trademarks mentioned in this document are the property of their respective
holders.
Anybus®Industrial WLAN Access Point Startup Guide SP2819 1.0 en-US
Safety 5 (24)
2 Safety
2.1 General Safety Instructions
Caution
Ensure that the power supply is turned off before connecting it to the
equipment.
Attention
Assurez-vous que l’alimentation électrique est coupée avant de la
brancher sur l’équipement.
Connecting power with reverse polarity or using the wrong type of power
supply may damage the equipment. Make sure that the power supply is
connected correctly and of the recommended type.
This equipment contains parts that can be damaged by electrostatic
discharge (ESD). Use ESD prevention measures to avoid damage.
2.2 Intended Use
The intended use of this equipment is to provide wireless LAN connectivity. The
equipment receives and transmits data on various physical levels and
connection types.
If this equipment is used in a manner not specified by the manufacturer, the
protection provided by the equipment may be impaired.
Anybus®Industrial WLAN Access Point Startup Guide SP2819 1.0 en-US
Preparation 6 (24)
3 Preparation
3.1 Support and Resources
For additional documentation and software downloads, FAQs, troubleshooting
guides and technical support, please visit www.anybus.com/support.
Have the product article number available, to search for the product specific
support web page. You find the product article number on the product cover.
Anybus®Industrial WLAN Access Point Startup Guide SP2819 1.0 en-US
Installation 7 (24)
4 Installation
4.1 Pole Mounting
Option for access point IP67
1. Use the four included screws and washers to attach the mounting bracket
to the access point.
2. Insert the two included metal bands into the mounting bracket strap slots.
3. Position the metal bands and the mounting bracket on the pole as needed.
Anybus®Industrial WLAN Access Point Startup Guide SP2819 1.0 en-US
Installation 11 (24)
4.3 DIN Rail Mounting
Option for access point IP30
Fig. 1 DIN rail mounting option
1. Fasten the DIN clip with 3 (M3x6 flat head) screws on the rear side of the
access point.
2. Insert the upper end of the DIN rail clip into the DIN rail.
3. Push the bottom of the DIN rail clip into the DIN rail.
Anybus®Industrial WLAN Access Point Startup Guide SP2819 1.0 en-US
Installation 12 (24)
4.4 Connecting Ground Screw
Option for access point IP30
To avoid system damage, the equipment should be connected to ground.
Fig. 2
1. Establish a direct connection between the ground screw and the grounding
surface prior to connecting devices.
Anybus®Industrial WLAN Access Point Startup Guide SP2819 1.0 en-US
Installation 13 (24)
4.5 Connecting Access Point IP30 to Power
Caution
Ensure that the power supply is turned off before connecting it to the
equipment.
Attention
Assurez-vous que l’alimentation électrique est coupée avant de la
brancher sur l’équipement.
Connecting power with reverse polarity or using the wrong type of power
supply may damage the equipment. Make sure that the power supply is
connected correctly and of the recommended type.
Anybus®Industrial WLAN Access Point Startup Guide SP2819 1.0 en-US
Installation 14 (24)
4.5.1 Connecting to Power via Terminal Block
Use a power supply of 10-60 VDC for terminal block and 48 VDC for PoE.
Max power consumption: 11.5 W
Fig. 3
P- 10-60 VDC (terminal block)
Max. 11.5 W
P+
1. Insert the positive and negative wires into the P- and P+ contact on the
terminal block.
2. Tighten the 2 wire-clamp screws.
3. Connect the power wires to a DC power supply.
Anybus®Industrial WLAN Access Point Startup Guide SP2819 1.0 en-US
Installation 16 (24)
4.6 Connecting Access Point IP 67 to Power
Caution
Ensure that the power supply is turned off before connecting it to the
equipment.
Attention
Assurez-vous que l’alimentation électrique est coupée avant de la
brancher sur l’équipement.
Connecting power with reverse polarity or using the wrong type of power
supply may damage the equipment. Make sure that the power supply is
connected correctly and of the recommended type.
Fig. 5
Function Power
WAN 1 Gbit/s PoE enabled IEEE 802.3af (48 VDC PoE)
1. Connect the access point to power and an Ethernet network via the WAN/
PoE port.
Anybus®Industrial WLAN Access Point Startup Guide SP2819 1.0 en-US
