SMC Networks EZ Connect SMC2682W User manual

TM
Wireless Access Point/Bridge
◆ Protocol-independent networking functionality
◆ 11 Mbps data rate per channel: provides alternative to
wired LANs that can dramatically cut costs
◆ Seamless connectivity to wired Ethernet LANs augments
existing networks quickly and easily
◆ Direct Sequence Spread-Spectrum (DSSS) technology
provides robust and secure wireless connection
◆ Easy installation
◆ Omni-directional antenna
User Guide
SMC2682W

38 Tesla
Irvine, CA 92618
Phone: [phone]
EZ Connect
User Guide
From SMC’s EZ line of low-cost workgroup LAN solutions
January 2002
Part No: 01-111317-006
Pub No: 150000003400E R02
