52 HOBIE 17 / 17 SPORT
GASKET 10092025
DRAIN PLUG WITH GASKET
10091000
To order from your nearest Hobie Cat dealer
U.S.A. hobiecat.com 1-800-HOBIE-49
Australasia hobiecat.com.au 1-800-4-Hobie
H17 HULL/DECK
REPLACEMENT HULL WHITE - LEFT 50101001
REPLACEMENT HULL WHITE - RIGHT 50102001
SCREWS
8030401
CENTERBOARD SPRING
50350140
UPPER GUDGEON
50101301
CENTERBOARD 50351001
LOWER GUDGEON
50101401
DRAIN PLUG HOUSING
10092000
SCREW 8030201
PIVOT PIN 50104001
NOTE: ALL HOBIE 17 MODELS SINCE 1995
HAVE A DEEP PROFILE TRAVELER TRACK THAT
ACCEPTS THE 106 OR 112 TRAVELER CAR
H17 REAR CROSSBAR ASSEMBLY
BLACK 50260000
EXTRUSION
BLACK 50261001
CAP 50262101
BOLT 8032221
EYESTRAP
11470000
SCREW
8030071
NUT
8051301
DEEP PROFILE TRACK 50252021
EYESTRAP
11470000
TRAVELER CAR ASSEMBLY 105
TRAVELER CAR ASSEMNBLY 112 (DEEP TRACK)
END CAP
50251001
PAD FOR CAMCLEAT
1162 SEE PAGE 22
SWIVEL CAMCLEAT
50007 SEE PAGE 22
ANCHOR BAR
50101701
BACKUP PLATE
50253001
H17 FRONT CROSSBAR
BLACK 50220000
EXTRUSION ONLY
BLACK 50221001
CAP 50262101
BOLT 8032221
EYE STRAP 11470000
NUT 8051301
SCREW 8030071
ANCHOR BAR
50101701
STRIKER POST
50212101
STRIKER ROD
50212001
NUT 8050461
WASHER 50254001
COMPRESSION SLEEVE
50212201
NUT 8050511
WASHER 8080611
INBOARD SUPPORT
50213201
CASTING
RIGHT-FWD
LEFT-REAR
50121511
CASTING
RIGHT-REAR
LEFT-FWD
50121611
ANCHOR PIN 20100000
ANCHOR BAR 50101701
CENTERBOARD HANDLE
50702001
CENTERBOARD CLEAT 50102101
SCREW 8030251
NUT 8050201
TRAMP TRACK
50101101
WING SOCKET PLUG, PKG 4
50690001
HOBIE 17 / 17 SPORT
H17 TRAMPOLINE
AFT LACING RH014 WHT X 15' (2 ea)
COMPLETE TRAMPOLINES (Does not include lace line)
5067XXXX
(XXXX = Color / See parts list for available options)
CENTER LACING RH014 WHT X 20'
TRAMP LACING STRIP, H17 AFT 5067XXXX
BALL
50212301

HOBIE 17 / 17 SPORT 53
H17 TILLER
TILLER CROSSBAR
BLACK 20520011
‘95 - NEWER 20521001
TILLER CONNECTOR KIT
11520005
RING
20860000
PIN
8020411
SCREW
8030701
NUT
8050111
RUDDER ADJUSTER KIT
60400011
HINGE YOKE ASSY. 3205
HINGE
10532010
NUT
8050201
FIBERGLASS EXTENSION WITH HINGE 60550001 (106”)
SCREW
8030111
EXTENSION TIP
10560000
H17 WIRES
(See page 55 for 17 Sport-Specific Wires)
THIMBLE
20800000
SLEEVE
8063761
SHACKLE
20700001
FORESTAY
BLACK
50701201 SHROUD
BLACK 20792011
TRAPEZE
BLACK 1471B
WHITE 1471W
BRIDLE
BLACK 50701101
TRAPEZE HANDLE
2011 SEE PAGE 8
TRAPEZE LINE
RH014WHT X 2' 6"
TRAPEZE SHOCK CORD
50701501
ADJUSTER
20830020
PIN
8020381
RING
20860000
SHACKLE
10700000
DOGBONE
2001
SEE PAGE 8
ROPE LOCK
61530000
J/H HANDLE -PAIR
2004 (BLK OR WHT)
SEE PAGE 8
PIN
8020411
H17 MAST
MAST ASSY, BLACK 51410000
COMPTIP ASSY. 50611101
MASTHEAD
50412001
HALYARD LINE
RH014WHT X 70'
CAP PLUG
8090900
TWIST SHACKLE
60670000
RING
61290021
LUFF TRACK
38584001
HALYARD HOOK ASSY.
50403011
BOLT 8040381
NUT 8050311
MAST TANG (1994 & EARLIER) 50405001
NEWER 20690000
MAST WARNING LABEL
13440010
DANGER!
ALWAYS USE EXTREME CAUTION
WHEN RAISING OR LOWERING
YOUR MAST. CONTACT WITH A
POWERLINE COULD BE FATAL.
"INTERNAL"
FOAM PLUG
60060000
PLATE
61080000
RING
20860000
SAIL FEEDER KIT
80100501
NUT
8050101
SHEAVE
H160
MAST CAUTION LABEL
13440000
ROTATION ARM
31210001
MAST BASE ASSY.
BLACK 50416011
BOLT
8040381
NUT
8050311
PIN
50406301
RING
10860001
SINGLE BLOCK
H224
SHACKLE
10870000
BOLT
8041111
GOOSENECK
50406231
LUFF
TRACK
UPDATE
50404111
NUT
8050111
BOLT
8040021
H17 RUDDER ASSEMBLY
* = SUB ASSEMBLY PART / INCLUDED wITH CASTING
*BOLT
8040301
UPPER CASTING
LEFT BLACK 50321001
RIGHT BLACK 50341001
*WASHER
8080181
TILLER TUBE
BLACK 50321111
END CAP
10400010
BOLT
8040331
NUT
8050311
PLASTIC RUDDER
BLADE
20493000
EPO2 BLADE
CARBON 20490020
*CAM
10480000
*PIN
50312301
COTTER PIN
8060111
RUDDER PIN
60880001
*ADJUSTMENT SCREW
8032001
*PLUNGER
50312201
*SPRING
10430000
*TENSION SCREW
60450000
LOWER CASTING
BLACK 50322001
NYLINER
8061011
*CAM PLATE
203520000
VERTEX
50772031

54 HOBIE 17 / 17 SPORT
H17 WINGS
SET W/O TRAMPOLINES
50650000
RIGHT-WING ASSY.
50680001
LEFT-WING ASSY.
50660001
FWD CASTING INSIDE TUBE AFT CASTING CAP
50663001 50666001 50662001 50665001
WING TRAMP SET
5065XXXX
(XXXX = Color / See parts
list for available options)
HEAD PLATE-SET
68330011
H17 SAIL
TWIST SHACKLE
60670000
DOUBLE BLOCK
H226
CLEW PLATE-PAIR
62270000
TELL TALE
335 SEE PAGE 16
LOGO
BLACK 12430011
WHITE 12430001
#0 WHITE 12700000
#0 BLACK 12700030
#1 WHITE 12710000
#1 BLACK 12710030
#2 WHITE 12720000
#2 BLACK 12720030
#3 WHITE 12730000
#3 BLACK 12730030
#4 WHITE 12740000
#4 BLACK 12740030
#5 WHITE 12750000
#5 BLACK 12750030
#6 WHITE 12760000
#6 BLACK 12760030
#7 WHITE 12770000
#7 BLACK 12770030
#8 WHITE 12780000
#8 BLACK 12780030
BATTEN POCKET PROTECTOR KIT
80550005
"HOBIE" PROTECTOR KIT
12480001
DOWNHAUL LINE
RH316WHT X 5'
BATTEN TIE
RH112WHT X 18"
CLASS INSIGNIA
50991700
MIAN SAIL
5299XXXX
SEE SEQUENTIAL PARTS LIST
H17 BLOCK SET
CAM
H150
FAIRLEAD
11470000
LOWER BLOCK
H194 SEE PAGE 23
MAINSHEET
RM038XXX
X 46'
UPPER BLOCK
H153 SEE
PAGE 23
H17 Rivet Guide
( ) indicates quantity needed to fasten part
Mast
Head 8010131 (2)
Halylard Hook 8011231 (3)
Base 8010131 (2)
Rear Crossbar
Swivel Jammer 8010201 (1)
8031501 (2)
8031231 (2)
8080011 (1)
8050801 (1)
Dead Eye 8010181 (4)
Back Up Plate 8010201 (4)
Track 8010201 (44)
Hull
Trampoline Track 8010121 (9)
(backup washers required on above,61360000)
Boom
End Cap (gooseneck) 8010131 (2)
Block Hanger 8010181 (4)
End Cap 8010131 (2)
Rudder (Upper Casting)
Casting 8011231 (4)
End Cap 8010131 (2)
Sail Hardware
Headboard 8010020 (16)
Main Clew Plate 8010020 (10)
Batten Pocket 8010020 (4)
Jib Clew Plate 8010020 (6)
(above rivets require setting machine which is
not available in a hand tool)
Wing
End Cap 8010051 (1)
Castings 8010131 (8)
Forward Cross Bar - Sport
Swivel Cam Cleats 8010131 (4)
(FOR INDIVIDUAL BATTENS SEE UNIVERSAL BATTENS ON PAGE 14)
‘94/OLDER SPORT
BATTEN #6 36 1/2”
BATTEN #5 51 3/4”
BATTEN #4 74”
BATTEN #3 85 1/8”
BATTEN #2 90 5/8”
BATTEN #1 89”
NEWER SPORT / SE
BATTEN #6 37”
BATTEN #5 53”
BATTEN #4 74 3/4”
BATTEN #3 87”
BATTEN #2 94”
BATTEN #1 95 1/4”
H17 / 17 SPORT BATTENS
H17 BOOM
BLACK 50510000
OUTHAUL WIRE ASSY. 50504001
SLIDE
50504101
H224
SHEAVE
96621110
PIN
96610000
CLAM CLEAT
61070000
SCREW
8030071
NUT
8051301
SHACKLE
10700000
GOOSENECK PIN W/ROLL PIN
10772010
ROLL PIN
50502201
BOOM CAP-AFT
BLACK 50513011 BLOCK HANGER
10760000
OUTHAUL LINE
RH316WHT X 4'
BOOM CAP-FWD
BLACK 50512001
(Lengths Updated 2006)
SAIL BAG
21310000

HOBIE 17 / 17 SPORT 55
H17 SPORT MAST ASSY. & DOWNHAUL
EYE STRAP
31470001
MICRO BLOCK
H224
STOPPER KNOB
52721111
CLAM CLEAT, ALUM.
61070010
SHEAVE
H160 (3) SPACER
52411001
CLEVIS PIN
8020421
DOWNHAUL
RM014RED X 8'
DOUBLE BULLET BLOCK
H084
DOWNHAUL HOOK
52410011
MAST ASSY. SPORT
51410000
NOTE: WHERE A SPECIFIC
ITEM IS NOT IDENTIFIED, USE
THE STANDARD HOBIE 17 LINE
DRAWINGS.
SWIVEL CAM CLEAT
50007
BASE 1162
FORWARD CROSSBAR ASSY.
52220001
BLOCK
H082
SHACKLE
92870000
JIB SHEET
RM516XXX X 32'
EYESTRAP
11470000
H17 SPORT FRONT CROSSBAR
H17 SPORT SPREADER POLE & FURLER
SPREADER POLE
ASSY.
52500001
SPDR BAR END CAP (PLASTIC)
52009001
SPDR POLE END CAP CASTING
52502021
SPDR POLE YOKE ASSY
52503001
LOWER BRIDLE
52500101
UPPER BRIDLE
52500201
ADJUSTER
60830000
FURLER ASSY.
61900000
CLEVIS PIN 8020371
RING 20860000 SHACKLE H138
H17 SPORT FORESTAY
UPPER FORESTAY
52812011
JIB HALYARD WIRE
52661001
LOWER FORESTAY
52812001
BLOCK, JIB HALYARD
20240001
JIB HALYARD LINE
RH112WHT X 19'
ORIGINAL H17 SPORT REAR CROSSBAR, MAINSHEET
SYSTEM AND OUTHAUL SYSTEM–1994 AND EARLIER
TRAVELER CAR
H171
SPORT BOOMLET ASSEMBLY (NEWER, 95 - CURRENT) 52722011
END CAP
H174 TRAVELER ASSY. SAIL
FOOT
52720011 CLAM CLEAT, ALUM.
61070010
BLOCK
H082
UPPER BLOCK
H153
STOPPER KNOB
52721111
BELL SHACKLE 1/4"
10700000
LOWER RATCHET
BLOCK H194
TRAVELER CAR ONLY H159
TRAVELER CAR MNTG PLATE-H5265
USES 42 BEARINGS
H177 (20 PACK)
EYESTRAP
31470001
SCREW 8030061
END CAP
31850001
SCREW
8030251
TRAVELER CAR ASSY. W/SWIVEL CAM CLEAT
HC1063S
MAINSHEET
RM038XXX X 42'
TRAVELER TRACK
HSB57 (LTD STOCK)
HOBIE 17 SPORT SPECIFIC
