Hoist Fitness CL2063 User manual

CL2063
Note: Both Serial Number and Model Number are Required when Ordering Parts
June 2000
OWNERS MANUAL
RECORD SERIAL NUMBER HERE
Customer Service
Fa x
[phone]
[phone]
[phone]
FITNESS SYSTEMS
R
HOIST

ASSEMBLY
INSTRUCTIONS
FITNESS SYSTEMS
R
HOIST
2063 Assembly
CONTENTS
INSTRUCTIONS (Step 1)
FRAME ASSEMBLY (Step 2)
PRE-ASSEMBLED PARTS (Step 3)
PARTS LISTING
HARDWARE LISTING
BOLT SIZING CHART
WASHER SIZING CHART
WEIGHT RATIOS
WEIGHT TRAINING TIPS
WEIGHT TRAINING EXERCISE LOG
LIMITED WARRANTY
2
4
9
11
12
13
14
15
16
17
19
Page - 1

ASSEMBLY
INSTRUCTIONS
INSTRUCTIONS
Page - 22063 Assembly
Standard Allen Wrench Set
(3/32” - 5/16”)
Crescent Wrenches
Rubber Mallet
Tape Measure
Step 1
TOOLS REQUIRED
Before beginning assembly please take the time to read the
instructions thoroughly. Please use the catalog in this manual to
make sure that all parts have been included in your shipment.
Use only Hoist replacement parts when servicing. Failure
to do so will void your warranty and could result in personal
injury.
Hoist equipment is designed to provide the smoothest, most
effective exercise motion possible. After assembly, you should
check all functions to ensure correct operation. If you
experience problems, first recheck the assembly instructions to
locate any possible errors made during assembly. If you are
unable to correct the problem, call your authorized Hoist dealer.
Be sure to have your serial number and this catalog when calling.
When all parts have been accounted for, continue on to Step 2.
When ordering use the part number and description from the
catalog.
FITNESS SYSTEMS
R
HOIST

FITNESS SYSTEMS
R
HOIST
2063 Assembly
Page - 3

ASSEMBLY
INSTRUCTIONS
Page - 42063 Assembly
FITNESS SYSTEMS
R
HOIST
FRAME ASSEMBLY
Step 2

ASSEMBLY
INSTRUCTIONS
FRAME ASSEMBLY
Step 2a
FITNESS SYSTEMS
R
HOIST
1 - Crossover Top Mount Assembly
2 - Mount Bracket
4 - CL2061
Part Descriptions
B - 1/2”-13 x 5” Hex Head Screw
AA - 1/2” Flat Washer
(White Zinc)
(White Zinc)
BA - 1/2” Lock Nut (White Zinc)
Hardware Descriptions
2063 Assembly
Page 5
In this step attach (2) to (1, and (4). Wrench tighten bolts.

ASSEMBLY
INSTRUCTIONS
Page - 62063 Assembly
FITNESS SYSTEMS
R
HOIST
??
??
??
??
??
??
??
??
??
??
??
??
??
??
??
?? AA
B
??
2
??
??
??
??
??
1
4
AA
??
??
??
??
??
??
??
??
??
??
??
??
??
??
??
??
??
4
??
??
??
??
??
BA
BA 2
AA
B
AA

ASSEMBLY
INSTRUCTIONS
FRAME ASSEMBLY
Step 2b
FITNESS SYSTEMS
R
HOIST
1 - Crossover Top Mount Assembly
3 - Mount Plate
4 - CL2061
Part Descriptions
A - 1/2”-13 x 3” Button Head Screw
AA - 1/2” Flat Washer
(White Zinc)
(White Zinc)
BA - 1/2” Lock Nut (White Zinc)
Hardware Descriptions
2063 Assembly
Page 7
In this step attach (3) to the under side of (1), and (4). Wrench
tighten bolts.

ASSEMBLY
INSTRUCTIONS
Page - 82063 Assembly
FITNESS SYSTEMS
R
HOIST
??
??
??
??
??
??
??
??
??
??
??
??
??
??
??
??
AA
A
AA
1
3
?
4
2
4
??
??
??
??
??
??
??
??
??
??
??
??
??
??
??
??
??
A
AA
BA
AA
?
2
??
??
??
BA
3

ASSEMBLY
INSTRUCTIONS
PRE-ASSEMBLED PARTS
Step 3
FITNESS SYSTEMS
R
HOIST
1 - Crossover Top Mount Assembly
Part Descriptions
C - 10-32 x 1/8” Set Screw
CA - 1 1/4” Dia x 3/4” Aluminum Cap
CB - 1 1/4” Dia x 3/8” Aluminum Ring
CC - 1.175”OD x .9375” ID x 5.50” LG Grip
CD - 1.175”OD x .9375” ID x 17.75 LG Grip
CF - 1 1/2” Dia. x 3/4” Aluminum Cap
CG - 1 1/2” Dia. x 3/8” Aluminum Ring
CH - 1.425” OD x 1.188 ID x 5.50 LG Grip
CJ - 1.425” OD x 1.188 ID x 13.75” LG Grip
Hardware Descriptions
2063 Assembly
Page 9
This step shows the installation of rubber grips CC & CD along with
finishing rings CB and caps CA. Wrench tighten.
