1
Features
This unit is available in a 4 or 6 station conguration. Designed
for residential applications, this controller has four separate start
times and each can be programmed individually to suit your
watering needs.
These different areas may require individual watering programs
and often use different types of sprinklers.
Examples: Turf areas generally use pop-up sprinklers and require
less frequent but heavier watering. However, ower beds use
micro sprays and require more frequent watering. The valves
(stations) which water similar garden areas are often grouped
together and put into the same start/program as they need to be
watered on the same days.
These stations (valves) will water in sequential order from the
lowest number at the start time (or times) nominated and on the
days selected. Maximum watering duration for a station (valve) is
12 hours and 59 minutes.
This controller has a 7 day calendar with individual day selection,
even, odd + odd-31 and interval days from 1 to 15.
A key water saving feature is the installation of a rain sensor. This
controller has a rain sensor switch in the fascia so you can enable
or disable the rain sensor control function.
DialEZY Controller 4 & 6 Station Instruction Manual Rev03.indd 1 10/06/2016 11:28 AM

2
Glossary
LCD Display
Easy to read
display.
Selection Dial
Used for
operations &
programming.
Rain
Sensor
Switch
Manually
activate rain
sensor by
switching
to ON/OFF
position.
Fuse
Location
Remove cover
to access fuse
Terminal Cover
Remove to access terminals for
solenoid (valve) wires and to annually
replace 9 volt block battery.
Programming
Buttons
Used for adjusting
the programmed
information.
Indoor Controller Model
DialEZY Controller 4 & 6 Station Instruction Manual Rev03.indd 2 10/06/2016 11:28 AM

3
Introduction
The key elements when programming your controller are:
1. Grouping the stations. (valves)
Group together garden areas which have similiar watering
requirements. Examples are: Turf Areas, Flower Beds, Pergola/
Undercover Areas, or Vegetables. These different groups require
individual settings (programs).
2. Planning out your watering program.
Complete your individual watering planner, supplied at the back of
this book.
3. Setting the current time and correct day of the week.
4. Setting an automatic program.
Use the following 3 steps to set each group.
4.1 Set Start(s).
This sets the time of the day when the watering program will
commence.
4.2 Set Watering Days.
These are the nominated days when the automatic system will
be active.
4.3 Set Station Run Times.
This sets the watering duration required for each station (valve).
Programming Instructions
This controller has been designed with four separate starts
(programming schedules), to allow different garden areas to have their
own individual watering requirements.
A program is basically a method of grouping stations (valves) with
similar watering requirements to water on the same days. These
stations will water in sequential order from the lowest number at the
start time (or times) nominated and on the days selected. The stations
can have different durations.
DialEZY Controller 4 & 6 Station Instruction Manual Rev03.indd 3 10/06/2016 11:28 AM

4
Programming Instructions
A typical 6 station system is illustrated below. This guide will assist you
when completing your watering planner. In this example the lawn areas
are using pop-up sprinklers & require less frequent watering.
The vegetables are watered using drippers, with a longer run time &
the ower beds/pergola areas are watered with micro spray nozzles.
Each area is put into a separate program.
Programming Example
1
2
3
4
START TIME
Start Time 1:
4:00am
20
20
20
30
10
5
MONDAY
WEDNESDAY
FRIDAY
MONDAY
WEDNESDAY
FRIDAY
SUNDAY
MON, TUES
WED, THURS
FRI, SAT
SUN
TUESDAY
THURSDAY
SATURDAY
Start Time 2:
6:00am
Start Time 3:
5:00am
Start Time 4:
7:00am
WATERING
SCHEDULE
RUN TIME
(minutes)
PROGRAM
DialEZY Controller 4 & 6 Station Instruction Manual Rev03.indd 4 10/06/2016 11:28 AM

5
Programming Instructions
This controller can also manually run a selected start once, or an
individual station can be set to run once from 1 minute up to 12
hours and 59 minutes. During winter the automatic start times can
be suspended to prevent watering while it is raining. A test facility for
checking the valves and sprinklers is also provided.
General tips for easy programming:
Tips to help eliminate programming confusion.
• Complete the spare watering planner.
• When setting, one push of the button will increment one unit.
• Holding one button down will fast scroll through the units.
• During programming, only the ashing values are able to be set.
Adjust using or buttons.
• Pressing will scroll forward through the settings in an orderly
sequence.
• Pressing will scroll back to previous settings and ashing values
can be changed.
Other Functions
DialEZY Controller 4 & 6 Station Instruction Manual Rev03.indd 5 10/06/2016 11:28 AM

6
Programming
Turn the dial to Set Clock/Calendar position.
The minutes will be ashing. Use or to adjust.
Press the button and the “hours” will ash.
Use or to adjust. Note: AM / PM must be set correctly.
Press and the “day of the week” will ash.
Use or to set correct day.
Set Current Time & Correct Day
Set Calendar (Optional)
Note: The calendar only needs to be set when selecting ODD/
EVEN day watering in areas where water restrictions may
require this feature.
Press button until the year, month & day are shown. The
“year” will be ashing. Use or to adjust.
Press button and the “month” will ash.
Use or to adjust.
Press and the “day” will ash.
Use or to adjust.
TIP To return to the clock, press ,
or turn dial to another position.
Before proceeding, ensure your watering planner has been completed. From
this, you should be aware of which stations are allocated to each program.
Note: Set one program at a time – this will ensure that all the values are
entered correctly.
DialEZY Controller 4 & 6 Station Instruction Manual Rev03.indd 6 10/06/2016 11:28 AM

7
Programming
Each start time can be programmed individually to suit your watering
requirements
STEP 1. Set Start Times
All valves will activate in sequential order for each start time. Turn the
dial to Set Start Times.
The display will show:
“Start 1” will ash.
Press & the “hour” will ash. Use or to adjust.
Note: AM / PM is set correctly.
Press & the “minutes” will ash. Use or to adjust, if
required.
To turn an active start time off, turn the dial to the Set Start
times position, Select the start number required using the
button and then press until the “hour” is ashing.
Use or until “OFF” is shown.
“OFF” position is between 12 and 11pm.
TIP
TIP
Setting Start
TIP To return to the clock, press ,
or turn dial to another position.
DialEZY Controller 4 & 6 Station Instruction Manual Rev03.indd 7 10/06/2016 11:28 AM

8
Programming
STEP 2. Set Watering Days
This unit has a 7 day calendar with individual day selection.
Turn the dial to Set Watering Days.
Individual Day Selection
This is the selectable day option.
The display will show:
This refers to Mon being Day 1.
To turn Monday off, press button . To leave Monday active, leave as
is & advance to Tuesday (day 2) by pressing the button.
Again press the button to set the day off if required followed by
to advance. Continue until all seven days have been set “ON”
or “OFF” .
Odd / Even Day Selection (Optional)
In some regions, users are only allowed to water their gardens on
ODD dates if their house number is ODD, or on EVEN dates when
their number is EVEN.
This controller allows this to be done simply by setting the relevant
selection of ODD or EVEN and setting the current date into the
controller. The controller will account for leap years.
DialEZY Controller 4 & 6 Station Instruction Manual Rev03.indd 8 10/06/2016 11:28 AM

9
Programming
STEP 3. Set Station Run Times
This is the length of time that each station (valve) is set to water on a
particular program. Maximum watering time is 12 hours 59 minutes for
each station. A station can be assigned from 1 to 4 starts if required,
with different run times. Set one start at a time
Turn the dial to the Set Station Run Times
position and the display will show
the following.
This means station 1 is set to “OFF” in Start 1. “Station 1” will be
ashing.
OFF
If you require the ODD / EVEN day option, simply press the
button until “EVEN” is shown. Press the button and “ODD” will
be shown. Press the button and “ODD-31” . This feature may
be required in areas where water restrictions are enforced.
Note: Remember to set the 365 day calendar when setting the
clock, or this feature will be out of sequence.
Interval Day Selection
“Interval 1” will be ashing.
This means that watering will occur every day.
To change the interval day, press the button.
Examples: Interval 2 means watering will take place every second
day, 3 means watering will be every third day etc.
Interval watering can be set from everyday to every 15th day. The
Run Day refers to the number of days before the next watering
program will occur.
DialEZY Controller 4 & 6 Station Instruction Manual Rev03.indd 9 10/06/2016 11:28 AM

10
Programming
STEP 3. Set Station Run Times. (Continued)
Should you need a second start Start.
Turn the dial to “Set Start Times” and “Start 1” will ash.
Press and change to Start 2 position and follow the same 3
steps to set an automatic watering program.
1. Set Start Time
2. Set Watering Days
3. Set Station Run Times
Remember to return the dial to the “AUTO” position after
completing the set up of an automatic program.
This will ensure that the automatic cycles will take place.
TIP
To adjust the Run time in minutes press , and use or .
To set the run time in hours, press and “0” will appear and ash.
To adjust use or .
If not required, press , and advance to station 2 by pressing the
button.
Continue until all the stations in Start 1 have been set with a run
time, or if a station (or stations) are not required to be active in this
particular program, ensure that the run time is set to “OFF”.
Note: To set a station to “OFF”.
Use when the “RUN TIME” is ashing.
This completes the setting up procedure for automatic watering of
start 1.
DialEZY Controller 4 & 6 Station Instruction Manual Rev03.indd 10 10/06/2016 11:28 AM

11
Manual Operations
System Test Facility
Turn the dial to Run System Test.
There will be a one second pause
The display will show:
Use this feature to check that your valves & sprinklers are working
correctly. The unit will run all stations in sequential order. The factory
preset time of 2 minutes per station can be adjusted. The new
adjusted run time will become the new default time.
Use or to adjust and to advance.
Run A Single Station
Turn the dial to Run Single Station. There
will be a one second pause. Use to
advance to the required station and to
adjust the run time, then or .
Maximum run time is 12 hours 59 minutes.
If the water supply is from a pump system, it is critical to
ensure all outputs are connected to a valve. Any output NOT
connected to a valve, should be linked back with a wire to the
nearest output with a valve.
TIP
This prevents the pump running against a closed head.
DialEZY Controller 4 & 6 Station Instruction Manual Rev03.indd 11 10/06/2016 11:28 AM

12
Other Features
Stop
To stop an automatic or manual watering schedule, turn the dial to the
Off position.
Stacking Start Times
Should you accidently set the same watering start time on more than
one program, the controller will stack them in sequential order from
the lowest number. All the programmed start times will be watered,
but the start times will be shunted along.
Automatic Back Up Program
When the battery is not tted or is at during a power outage, The
automatic program will be retained in a permanant memory chip. Also
the clock time will be retained in the memory at the time of the outage.
A standard 9 volt alkaline block battery should be tted to the battery
snap supplied to maintain the clock accuracy and hold the automatic
programs during power outs.
Manual Operations (cont.)
Run A Start
To manually run a complete start once for the run times as set in the
automatic schedule, turn the dial to the Run a Start position. “Start 1” will be
shown in the display. To run start 1, leave, or advance to start 2 by pressing
.
The display has a warning indicator to let you know when the
battery is low or not tted. The word BAT is displayed under
the AM / PM indicator in the clock mode.
TIP
For automatic watering, remember to turn the dial back
to the Auto Run position. The Off position will stop any
watering from occuring.
TIP
DialEZY Controller 4 & 6 Station Instruction Manual Rev03.indd 12 10/06/2016 11:28 AM

13
Other Features
Fitting a Rain Sensor (optional)
A rain sensor can be wired directly into the terminal block. When the
sensor is wet, all automatic and manual watering will not operate.
2. Connecting the rain sensor wires:
a) Remove the link connector by
loosening both screws and slide
out. (Link located under the terminal
cover.)
b) Connect the two sensor wires into
the terminal block and replace where
the link was. Fasten one wire into
the common (C), the other into the
24VAC. Polarity not applicable.
It is important to move the sensor switch back to the “ON”
position after completing your manual watering cycle.
TIP
New Sensor wires
Remove link
connector
NOTE: Far left 24VAC Terminal is active.
To t a rain sensor follow this procedure:
1. The sensor switch, accessed on the fascia,
must be up in the “ON” position. To over-ride the
sensor when it is wet, simply move the sensor
switch down to the “OFF” position. This will allow
automatic and manual watering cycles to operate.
DialEZY Controller 4 & 6 Station Instruction Manual Rev03.indd 13 10/06/2016 11:28 AM

14
Other Features
Rain Off Mode
To stop the automatic watering cycles during winter, turn the dial
to the Off position. The word “Off” will appear in the display. This
means the automatic programs will not come on, but the programmed
information is still retained in the memory. To re-activate the automatic
start times, turn the dial back to the Auto position.
DialEZY Controller 4 & 6 Station Instruction Manual Rev03.indd 14 10/06/2016 11:28 AM

15
Installation Instructions
Mounting The Controller
This controller unit is an INDOOR MODEL and MUST NOT be
exposed to rain or water ingress, or direct sunlight.
Install the controller near a 240V AC mains outlet, preferably located
in a house, garage or other covered area. For ease of operation, eye
level placement is recommended.
Drive one #8 screw into the wall, leaving about 4mm of the screw
exposed. If necessary, use a toggle bolt or masonary shield.
Hang the controller from the key slot located in the back of the case.
Make sure the head is properly seated inside the controller case.
Additional screws may be inserted through the holes in the lower
corners of the controller case.
WARNING
1 All electrical work must be carried out in
accordance with these instructions following all
applicable Local, State and Federal codes, or
warranty will be void.
2 Disconnect mains power supply before
maintenance work to controller or valves and
when connecting and disconnecting eld wiring
and pump or master valve hook-ups.
Electrical Hook-Up
DialEZY Controller 4 & 6 Station Instruction Manual Rev03.indd 15 10/06/2016 11:28 AM

16
Field Wiring Connections
PREPARATION
1. Prepare wires for hook-up by cutting the wires to the correct length
and stripping approximately 6mm (¼ inch) of insulation from the end
to be connected to the controller.
2. Ensure terminal block screws are loosened sufciently to permit
easy access for wire ends. Insert stripped wire ends into the
clamp aperture and tighten screws. Do not over tighten as this
may damage the terminal block.
3. A maximum of 0.5 Amps may be supplied by any output. Check
the inrush current of your solenoid coils before connecting more
than two valves to any one station.
Installation Instructions
Terminal Block Layout
The terminal block is laid out as follows:
GLOSSARY
24VAC 24VAC Power Supply
C Common valve wire input
P Master valve or pump start active wire
ST1 to ST6 Station (Valve) active wire connection
DialEZY Controller 4 & 6 Station Instruction Manual Rev03.indd 16 10/06/2016 11:28 AM

17
Installation Instructions
Power Supply Connections
The controller itself can run off a 240V AC to 24V AC external
transformer. It is recommended that the transformer is not connected
to a 240V AC supply which is also servicing or supplying motors.
(i.e. Air conditioners, pool pumps, refrigerators, etc.)
Lighting circuits are suitable as a power source.
Connections to the unit are as follows:
Valve wires can enter the controller through rear.
Connection Of Valves
Up to two 24VAC Solenoid Valves can be connected to each station
output and wired back to the common (COM) thus:
DialEZY Controller 4 & 6 Station Instruction Manual Rev03.indd 17 10/06/2016 11:28 AM

18
Installation Instructions
Pump Hook-Up Connections
DO NOT attempt to drive a pump starter directly from the controller.
Pump start is provided by connecting one side of the coil of a suitable
relay to the Master Valve/Pump Start output of the controller and the
other side to the controller common.
For systems supplied with water from a pump, unused stations MUST
be connected back to the last used station to eliminate the possibilty
of the pump running against a closed head.
Failure to do so could lead to pump damage!
The diagram shows an 6 station controller with 4 active stations (valves):
Unused stations must be
linked back to the last
used station.
Use insulated cable.
DialEZY Controller 4 & 6 Station Instruction Manual Rev03.indd 18 10/06/2016 11:28 AM
